1. System characteristics and design
NOTE: The setup for this protocol consists of the following elements: (1) EMG sensors and base, (2) EMG data acquisition (DAQ) software, (3) a motion capture system, and (4) a VR headset with corresponding software. These components are visualized in Figure 1.
<ol>
	<li>Setup of the system components
	<ol>
		<li>Connect the EMG system.
		<ol>
			<li>Plug in the EMG base station to power.</li>
			<li>Connect the EMG base station to a dedicated computer (Figure 1C) containing the DAQ scripts.
			NOTE: Example scripts can be found at:&#160;https://www.dropbox.com/sh/7se5lih4noxj584/AACqFDZytpDm-L8jAULFwfTHa?dl=0. Some commercial products may come with licensed DAQ software, which may also be used.</li>
		</ol>
		</li>
		<li>Connect the motion capture system.
		<ol>
			<li>Connect a second dedicated computer (Figure 1A) to a network router.</li>
			<li>Connect the network router to a motion capture server.</li>
			<li>Connect the motion capture server to a computer monitor for visualization.</li>
			<li>Connect the cameras to the motion capture server.</li>
		</ol>
		</li>
		<li>Connect the VR system.
		<ol>
			<li>Connect the VR headset to a third dedicated computer with the corresponding DAQ scripts (Figure 1B).
			NOTE: Example scripts can be found at: https://www.dropbox.com/sh/7se5lih4noxj584/AACqFDZytpDm-L8jAULFwfTHa?dl=0</li>
			<li>Load the VR gaming environment containing the intended tasks to the computer linked to the VR headset (Figure 1B).</li>
		</ol>
		</li>
		<li>Prepare the area where the subject will complete the task.
		<ol>
			<li>Use an arm-less, sturdy chair to ensure that there is no interference with the subject&#39;s normal reaching.</li>
			<li>For the safety and accuracy of the data collected, confirm that the testing area is clear of all obstacles.</li>
		</ol>
		</li>
		<li>Synchronize the systems.
		<ol>
			<li>Use a custom software function to synchronize systems in time to a one-time server.</li>
			<li>Alternatively, use one computer or a preferred message manager.</li>
		</ol>
		</li>
	</ol>
	</li>
</ol>
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/65736/65736fig01.jpg" />
Figure 1: Experimental equipment setup. (A) The marker motion capture cameras are positioned on the floor and in the ceiling around the experimental space, establishing an optimal space for tracking motion. A dedicated computer is used to run the motion capture software and save the data. (B) The headset used to display the modified BBT in VR is connected to a dedicated computer where the virtual assessment and task data are saved. (C) The EMG base is connected to a dedicated computer where muscle activity data is recorded and saved during the task execution. EMG sensors and LED markers for motion capture are both placed on the subject&#39;s arm during the session (see Figure 2). Abbreviations: VR = virtual reality; EMG = electromyography. <a href="https://www.jove.com/files/ftp_upload/65736/65736fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
2. Experimental procedures
NOTE: a visual representation of the experimental flow described in this protocol is shown in Figure 2.
<ol>
	<li>Setup EMG
	<ol>
		<li>To determine EMG sensor placement for best signal quality, palpate the muscle belly while the participant contracts the relevant muscle27. See Table 1 for the muscle selection used in this protocol.</li>
		<li>Using an alcohol wipe, carefully clean each electrode and the intended sensor placement site on the subject&#39;s arm.
		NOTE: Thorough cleaning of both the EMG sensors and the subject&#39;s skin will ensure a low electrode-to-skin impedance. This ensures that recorded EMG data has a high signal-to-noise ratio. Excess hair at the sensor placement site may cause low-quality data even if properly cleaned. In this case, it may be necessary to shave the hair.</li>
		<li>After preparing the EMG electrodes and the subject&#39;s skin, place the EMG sensors on the subject, ensuring good contact between the electrodes and skin. Bipolar electrodes should be positioned so that the sensors are parallel to the direction of the muscle fibers.</li>
	</ol>
	</li>
	<li>Setup motion capture system
	NOTE: This may not be necessary if only a VR headset is being used to track hand movements for kinematics.
	<ol>
		<li>Calibrate the motion tracking cameras using the manufacturer&#39;s instructions. Move the calibration wand throughout the experimental space to calibrate the motion tracking cameras and set the 3D axis of the space.
		NOTE: The marker motion capture system used in this protocol includes a calibration wand with LED markers.</li>
		<li>Place the LED motion capture markers on the bony landmarks of the subject&#39;s upper extremity and trunk that are needed to construct the desired biomechanical models.</li>
		<li>Use the provided motion capture software to ensure that all markers are recognized and tracked by the motion capture cameras. Instruct the subject to perform several practice movements while study personnel visually monitor marker data in real time.</li>
	</ol>
	</li>
	<li>Setup VR skill assessment task
	<ol>
		<li>Position a chair in the center of the motion capture experimental space. Use a chair that is similar to that used for the traditional, real-world test.</li>
		<li>Calibrate the VR headset in the chair where the subject will perform the assessment task. Once calibrated, instruct the subject to sit in the chair and place the VR headset on their head.</li>
		<li>While the subject is seated, measure the distance between the subject&#39;s shoulder and the ground, as well as the length of the subject&#39;s arm. Use these distances to set the location where the table and assessment task will spawn in VR.</li>
		<li>In the VR task control script, input the subject&#39;s measurements and program the desired number of block spawn repetitions.
		NOTE: In this Modified BBT, individual blocks will spawn one at a time to increase reproducibility.</li>
	</ol>
	</li>
	<li>Instruct the subject to perform the modified BBT assessment in VR.
	<ol>
		<li>Provide a brief explanation of the task to the subject.
		<ol>
			<li>The virtual block will spawn on the left or right side, as determined by the experimenter.</li>
			<li>Explain to the subject that they will need to pick up the virtual block, transport it over the partition, and place it onto the target in the opposing compartment (Figure 2).
			NOTE: In the virtual modified BBT used here, the block will automatically disappear and re-spawn at the starting position as many times as determined by the experimenter.</li>
		</ol>
		</li>
		<li>Start collecting EMG data.</li>
		<li>Start collecting motion capture data.</li>
		<li>Start the VR skill assessment task.
		<ol>
			<li>Let the task run for the preset number of repetitions before automatically ending.</li>
		</ol>
		</li>
		<li>Save the EMG and kinematic data for post-hoc analysis.</li>
		<li>Determine a clinically relevant score for the Modified BBT post-hoc as the number of blocks successfully carried over the barrier or repetitions of the task in 60 s.</li>
	</ol>
	</li>
</ol>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/65736/65736fig02.jpg" />
Figure 2: Experimental protocol, VR task, and subject setup. (A) Flow diagram describing the experimental protocol used here. (B) Example view of modified BBT implemented in VR environment. Anatomical measurements are used to calibrate the VR task, ensuring that the virtual table spawns at the correct relative location. (C) Placement of LED motion capture markers and EMG sensors on the subject. EMG sensors are placed on the muscles of interest and LED motion capture markers are positioned over bony landmarks. Abbreviations: VR = virtual reality; EMG = electromyography; LED = light-emitting diode. <a href="https://www.jove.com/files/ftp_upload/65736/65736fig02large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
