Generating Rabbit Model of Bone Infection: A Technique of Inducing Chronic Infection by Injecting Bacteria Directly in Bone Marrow

Protokoll

All procedures involving animal models have been reviewed by the local institutional animal care committee and the JoVE veterinary review board.

1. Preparation of Bone Infection Models

1. Keep male New Zealand white rabbits, aged 3 months, in individual cages, under air-controlled conditions (20 ± 1 °C) and 12 h/12 h light-dark illumination cycles. Offer routine diet and tap water daily.
2. Ensure that at the time of surgery that the rabbit weighs more than 3 kg.
3. Anaesthetize rabbits by intraperitoneal injection with pentobarbital sodium (3 mg per 100 g of body weight). Make sure rabbits are fully anesthetized by a failure to respond to a paw pinch. Fix rabbits on the operating table during operation procedure.
   NOTE: Make sure that the modeling procedure duration is less than 1 h.
4. Shave the proximal tibia region using an electric shaver against the direction of hair growth. Disinfect the skin by applying a povidone-iodine solution.
5. Mark the upper end of the tibia and the drilling hole position for injection with S. aureus (the distance to the upper end of the tibia is 1.5 cm) with pen and ruler. Make sure the drilling hole positions are in the middle of the tibial plateau horizontally (Figure 1A).
6. Cut tibia skin using a No. 11 scalpel and make a 1 cm incision in the periosteum (Figure 1B, C). Punch a 2 mm diameter hole in the tibia using an electric bone drill unit (Figure 1D).
7. Press the 2 mm diameter holes in the tibial plateau with a cylinder of bone wax of 2 mm diameter and 2 mm height (Figure 1E). Remove the spare bone wax along the horizontal plane of the tibial plateau (Figure 1F). Check that the 2 mm hole is full of bone wax (Figure 1G).
   NOTE: Ensure that the holes are full of bone wax by checking the hole with or without blood overflow.
8. Sew up the periosteum and skin with absorbable surgical suture in a vertical mattress suture to prevent the animal from chewing the sutures (Figure 1H).
9. Inject 1 x 10⁸ CFU/mL of S. aureus solutions (30 µL per 100 g of body weight) with a 1 mL asepsis injector (Figure 1I). Make sure the needles penetrate the bone wax and inject the S. aureus solution into bone marrow slowly.
10. Keep the animal in warm and clean conditions to avoid heat loss after modelling. Monitor respiratory rate and heart rate. After waking up, house the rabbits in individual cages with free access to food and water.

Ergebnisse

Figure 1. Surgical preparation of the bone infection model. (A) Shows the punching position on the tibia. The distance between the drilling hole position for injection with S. aureus to the upper end of tibia is 1.5 cm. (B) Incision made in the skin to expose the periosteum. (C) Shows incision made through the periosteum t...

Materialien

Name	Company	Catalog Number	Comments
absorbable surgical suture	Jinghuan	18S0604A
asepsis injector	Jinglong	20170501
bone wax	ETHICON	JH5CQLM
Electric bone drill unit	Bao Kang	BKZ-1
Electric shaver	Codos	3800
New Zealand white rabbits	Zhejiang Experimental Animal Center	SCXK 2014-0047
No. 11 scalpel	Yuanlikang	20170604
pentobarbital sodium	Merk	2070124
S. aureus freeze drying powder	China General Microbiological Culture Collection Center	ATCC 6538
