1. Downloading the CT images
<ol>
	<li>Gain access to a picture archiving and communication system (PACS).
	NOTE: Each software package has a different way of accessing a PACS, but all of them have a way to download a study in the DICOM format. If there is a question regarding how this is done, ask the system administrator of the center or the radiologists of the center.</li>
	<li>Download the full CT scan in the DICOM format while maintaining patient anonymity.</li>
</ol>
2. Obtaining the 3D biomodel (Supplementary File 1-Figure S1)
<ol>
	<li>Download the software 3D Slicer (see the Table of Materials). Install the program on the computer.</li>
	<li>Import the CT images in the DICOM format.
	<ol>
		<li>Click on the DCM icon on the top-left corner of the screen.</li>
		<li>Click on Import DICOM Files on the left side of the screen, and wait for a window to open that makes it possible to choose the folder where the CT study is saved in the DICOM format.</li>
		<li>Click on &#34;DummyPatName!&#34; on the top right of the screen. If the folder has more than one CT study, click on the series &#34;DummySeriesDesc!&#34; with the most images at the bottom of the screen.</li>
		<li>Click on Load on the lower-right margin.</li>
	</ol>
	</li>
	<li>Create the 3D biomodel.
	<ol>
		<li>Click the menu bar at the top of the screen, and wait for the DICOM to appear.</li>
		<li>In the dropdown menu, choose the Legacy | Editor option. Press ok on the message that appears (Supplementary File 1-Figure S2).</li>
		<li>Wait for a new menu to appear on the left side of the screen. Click on the Threshold Effect icon.</li>
		<li>Move the bar in the lower box until only the bone is painted in the images on the right. In this way, select the value of the Hounsfield units to be included in the model.</li>
		<li>Once the desired paint level is achieved, click on Apply. The selection is marked with the color green (Supplementary File 1-Figure S3).</li>
		<li>Select the option Make Model Effect from the side menu (the same as the previous one). Select Apply (Supplementary File 1-Figure S4).</li>
		<li>In the upper-right window, the 3D model is generated. Click on the golden frame, Center the 3D view on the scene, to center the image in the center of the window (Supplementary File 1-Figure S4).</li>
	</ol>
	</li>
	<li>Save the biomodel (Supplementary File 1-Figure S5).
	<ol>
		<li>Click on Save in the upper-left margin.</li>
		<li>In the box that appears, only select the file &#34;tissue&#34; (Supplementary File 1-Figure S5).</li>
		<li>In the second column, in the dropdown menu, select STL.</li>
		<li>In the third column, in the dropdown menu, choose where to save ithe STL file. Click on Save. This is the file that will be used in the following steps.</li>
	</ol>
	</li>
</ol>
3. Preparation of the biomodel
<ol>
	<li>Download the MeshMixer software (see the Table of Materials). Install the program on the computer.
	<ol>
		<li>Import the STL image by selecting the Import option in the center of the screen (Supplementary File 1-Figure S6).</li>
	</ol>
	</li>
	<li>Select the biomodel.
	<ol>
		<li>Look for the Select option in the menu on the left side. Use any of the following main methods to select.</li>
		<li>Use the Select tool, select the thickness of the brush, and double-click on the femur (Supplementary File 1-Figure S7). If it is not possible to separate only the femur, it means that it has direct contact with other bone structures or soft parts; in that case, select Edit | Generate face Groups from the menu (Supplementary File 1-Figure S7). Use the Angle Threshold option and move the bar until the different structures have a different color, indicating that the pieces have been recognized as separate (Supplementary File 1-Figure S8).
		<ol>
			<li>With the Select tool, hold down the left mouse button while painting the part of the biomodel of interest.</li>
			<li>With the Select tool, click on a point outside the model, and hold down the left mouse button while painting a circle that includes the part that is of interest.</li>
		</ol>
		</li>
		<li>Use the Select tool to select the part of interest. Look for the option Select | Modify | Invert in the side menu, and press Delete&#160;(Supplementary File 1-Figure S9) to delete the unselected parts. At this juncture, the biomodel of the clean femur is obtained (Supplementary File 1-Figure S9).</li>
		<li>Make the model solid (Supplementary File 1-Figure S10).</li>
		<li>Navigate to Edit | Make Solid | Solid Type| Accurate.</li>
		<li>Maximize the Solid Accuracy and Mesh Density values.</li>
	</ol>
	</li>
	<li>Save the biomodel. Select the Export option from the side menu. Select the STL format and the folder to which the biomodel is exported.</li>
</ol>
4. Calculation of the proximal femoral anteversion
<ol>
	<li>Download the 3D Builder software (see the Table of Materials). Install the program on the computer.
	NOTE: The program can only be downloaded if the operating system of the computer is Windows.</li>
	<li>Click on the Insert icon at the top of the screen (Supplementary File 1-Figure S11). Click on Add to import the biomodel to the scene (Supplementary File 1-Figure S12).
	NOTE: The left mouse button makes it possible to rotate the object to see it in a 360&#176; view. With the right button, it is possible to scroll along the object. The central wheel of the mouse allows for zooming in.</li>
	<li>Click on Object | Settle to fix the object to the work plane so that it rests on the femoral condyles and the trochanter mayor.
	NOTE: It is advisable to put the object vertically parallel to the y-axis and perpendicular to the x-axis marked on the working plane (Supplementary File 1-Figure S13).</li>
	<li>Perform the femoral osteotomy.
	<ol>
		<li>Click on Edit | Split from the top menu . When a rectangular cut plane appears, select Keep Both (Supplementary File 1-Figure S14).
		<ol>
			<li>Use the Move Mode button on the bar in the lower margin of the screen to move the cutting plane horizontally and vertically.</li>
		</ol>
		</li>
		<li>Use the Rotate Mode button on the bar in the lower margin of the screen to rotate the plane around the femur (Roll: 90&#176;, Pitch: 0&#176;, Yaw: 0&#176;) (Supplementary File 1-Figure S14).</li>
		<li>Put the cutting plane parallel to the x-axis and perpendicular to the y-axis. Click on Split. In this case, perform the osteotomy above the trochanter minor (intertrochanteric) (Supplementary File 1-Figure S15).</li>
	</ol>
	</li>
	<li>Calculate the femoral anteversion.
	<ol>
		<li>Insert the guides, which help to establish the reference points to measure the femoral anteversion in the image in the 3D environment of the program according to Murphy&#39;s method (Supplementary File 1-Figure S16A,B). To insert the guides, click on Insert | Add, and choose the 3mf Supplementary File 2.
		NOTE: These guides were designed in-house, and the 3mf file Supplementary File 2 is accessible as a supplementary material provided in this article. The Murphy 3D method was implemented by establishing three measurement points in the same way as in the conventional method11 but in a 3D environment. The usual circumference at the level of the femoral head was replaced by a sphere, and the measurement was established by a circumference at the level of the trochanter minor. As a distal reference, the posterior intercondylar line was taken, as defined in the original Murphy method.</li>
		<li>Select only the proximal part of the femur on the right side of the screen and click on CTRL + X to cut the selection. This is how the femoral diaphysis appears (Supplementary File 1-Figure S17).</li>
		<li>Select the red circular guide and the purple circular guide (doing this means that they will be together) on the right side of the screen. Use the commands in the bottom margin panel to move the guides.
		NOTE: The red guide represents the rotational axis of the osteotomy, while the violet guide represents the rotational axis of the femur.</li>
		<li>Put the guides in the center of the femoral diaphysis, and use the commands of the inferior margin panel to adjust the size. Ensure that all the edges touch the cortex of the bone (Supplementary File 1-Figure S18).
		NOTE: When the two guides, the red circumference and the purple circumference, are used for the first time, they are selected together so that they move as a block, as if they were one guide, to measure the FAV, and they are placed in the femoral diaphysis just above the lesser trochanter at the osteotomy line.</li>
		<li>Click on CTRL + V to paste the proximal femur again (Supplementary File 1-Figure S19).</li>
		<li>Select only the sphere on the right side of the screen. Use the commands in the bottom margin panel to move the sphere and place it on top of the femoral head. Adjust the size, including all the edges touching the bone cortex (Supplementary File 1-Figure S20).</li>
		<li>Select the proximal femur on the right side, and cut it (CTRL + X).</li>
		<li>Select only the red plane on the right side of the screen (Supplementary File 1-Figure S21).</li>
		<li>Use the commands in the lower margin panel to move the red plane, and place it so that it passes through the center of the sphere and through the center of the circular guides.
		NOTE: The grades marked by the panel in the lower margin correspond to the pathological femoral anteversion calculated on the CT using Murphy&#39;s method.</li>
		<li>Press CTRL + V to paste the proximal femur again (Supplementary File 1-Figure S22 A,B) .</li>
	</ol>
	</li>
	<li>Perform the rotational osteotomy of the proximal femur.
	<ol>
		<li>Select the proximal femur + the red circumference (only the red) + the sphere on the right side.</li>
		<li>Make an internal derotational proximal femoral osteotomy of 20&#176; (use the commands on the panel of the lower margin; add 20 on Pitch) (Supplementary File 1-Figure S23).</li>
		<li>Measure the new femoral anteversion (Supplementary File 1-Figure S24).
		NOTE: The two guides are used again to perform the osteotomy. In this case, only the red guide is selected together with the proximal femur (so that when the proximal femur rotates, the red guide also rotates; step 4.6.1), while the violet guide is not selected (Supplementary File 1-Figure S25). In this way, the violet guide remains in the femoral diaphysis and does not participate in the rotation of the proximal femur.
		<ol>
			<li>Select the proximal femur + the red circumference, and press CTRL + X to cut these two elements.</li>
			<li>Select only the red plane, and place it so that it passes through the center of the sphere and through the center of the purple circular guide.
			NOTE: A 1:1 relationship between the magnitude of the osteotomy and the correction of the deformity is not achieved because the derotation of the proximal femur does not follow the anatomical axis of the femur.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Perform the adjustment of the rotational osteotomy.
	<ol>
		<li>Select the femoral diaphysis + the red plane. Press CTRL + X to cut (Figure 27). (Supplementary File 1-Figure S25).</li>
		<li>Select the proximal femur + the sphere + the red circumference.</li>
		<li>Move the three elements en bloc so that the center of the red circumference matches the center of the purple circumference&#160;(Supplementary File 1-Figure S26).</li>
		<li>Recalculate the new femoral anteversion with the adjustment made (Supplementary File 1-Figure S27).
		NOTE: Through this 3D method, it is shown that the rotation axis of the femur and the rotation axis of the osteotomy do not coincide. For this reason, it is necessary to make an adjustment that involves realigning the two guides so that the original femoral axis and the osteotomy axis coincide.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Teitge, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Does+lower+limb+torsion+matter.">Does lower limb torsion matter.</a> Techniques in Knee Surgery. 11 (3), 137-146 (2012).</li><li>Teitge, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+power+of+transverse+plane+limb+mal-alignment+in+the+genesis+of+anterior+knee+pain-Clinical+relevance.">The power of transverse plane limb mal-alignment in the genesis of anterior knee pain-Clinical relevance.</a> Annals of Joint. 3, 70 (2018).</li><li>Delgado, E. D., Schoenecker, P. L., Rich, M. M., Capelli, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Treatment+of+severe+torsional+malalignment+syndrome.">Treatment of severe torsional malalignment syndrome.</a> Journal of Pediatric Orthopedics. 16 (4), 484-488 (1996).</li><li>Bruce, W. D., Stevens, P. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Surgical+correction+of+miserable+malalignment+syndrome.">Surgical correction of miserable malalignment syndrome.</a> Journal of Pediatric Orthopedics. 24 (4), 392-396 (2004).</li><li>Teitge, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patellofemoral+syndrome+a+paradigm+for+current+surgical+strategies.">Patellofemoral syndrome a paradigm for current surgical strategies.</a> The Orthopedic Clinics of North America. 39 (3), 287-311 (2008).</li><li>Leonardi, F., Rivera, F., Zorzan, A., Ali, S. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bilateral+double+osteotomy+in+severe+torsional+malalignment+syndrome:+16+years+follow-up.">Bilateral double osteotomy in severe torsional malalignment syndrome: 16 years follow-up.</a> Journal of Orthopaedics and Traumatology. 15 (2), 131-136 (2014).</li><li>Stevens, P. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Success+of+torsional+correction+surgery+after+failed+surgeries+for+patellofemoral+pain+and+instability.">Success of torsional correction surgery after failed surgeries for patellofemoral pain and instability.</a> Strategies in Trauma and Limb Reconstruction. 9 (1), 5-12 (2014).</li><li>Dickschas, J., Harrer, J., Reuter, B., Schwitulla, J., Strecker, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Torsional+osteotomies+of+the+femur.">Torsional osteotomies of the femur.</a> Journal of Orthopaedic Research. 33 (3), 318-324 (2015).</li><li>Naqvi, G., Stohr, K., Rehm, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Proximal+femoral+derotation+osteotomy+for+idiopathic+excessive+femoral+anteversion+and+intoeing+gait.">Proximal femoral derotation osteotomy for idiopathic excessive femoral anteversion and intoeing gait.</a> SICOT-J. 3, (2017).</li><li>Iobst, C. A., Ansari, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femoral+derotational+osteotomy+using+a+modified+intramedullary+nail+technique.">Femoral derotational osteotomy using a modified intramedullary nail technique.</a> Techniques in Orthopaedics. 33 (4), 267-270 (2018).</li><li>Stambough, J. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Knee+pain+and+activity+outcomes+after+femoral+derotation+osteotomy+for+excessive+femoral+anteversion.">Knee pain and activity outcomes after femoral derotation osteotomy for excessive femoral anteversion.</a> Journal of Pediatric Orthopedics. 38 (10), 503-509 (2018).</li><li>Murphy, S. B., Simon, S. R., Kijewski, P. K., Wilkinson, R. H., Griscom, N. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femoral+anteversion.">Femoral anteversion.</a> Journal of Bone and Joint Surgery. American Volume. 69 (8), 1169-1176 (1987).</li><li>Gracia-Costa, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Análisis por elementos finitos de las presiones femoropatelares previas y posteriores a osteotomía desrrotadora. , (2019).</li><li>Ferr&#224;s-Tarrag&#243;, J., Sanchis-Alfonso, V., Ram&#237;rez-Fuentes, C., Rosell&#243;-A&#241;&#243;n, A., Baixauli-Garc&#237;a, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+3D-CT+Analysis+of+femoral+symmetry-Surgical+implications.">A 3D-CT Analysis of femoral symmetry-Surgical implications.</a> Journal of Clinical Medicine. 9 (11), 3546 (2020).</li><li>Chen, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Treatment+of+die-punch+fractures+with+3D+printing+technology.">Treatment of die-punch fractures with 3D printing technology.</a> Journal of Investigative Surgery. 31 (5), 385-392 (2017).</li><li>Wells, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femoral+morphology+in+the+dysplastic+hip:+Three-dimensional+characterizations+with+CT.">Femoral morphology in the dysplastic hip: Three-dimensional characterizations with CT.</a> Clinical and Orthopaedics and Related Research. 475 (4), 1045-1054 (2016).</li><li>Liang, H., Ji, T., Zhang, Y., Wang, Y., Guo, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reconstruction+with+3D-printed+pelvic+endoprostheses+after+resection+of+a+pelvic+tumour.">Reconstruction with 3D-printed pelvic endoprostheses after resection of a pelvic tumour.</a> The Bone and Joint Journal. 99-B (2), 267-275 (2017).</li><li>Wang, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Computer-aided+designed,+three+dimensional-printed+hemipelvic+prosthesis+for+peri-acetabular+malignant+bone+tumour.">Computer-aided designed, three dimensional-printed hemipelvic prosthesis for peri-acetabular malignant bone tumour.</a> International Orthopaedics. 42 (3), 687-694 (2018).</li><li>Wong, K. C., Kumta, S., Geel, N. V., Demol, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=One-step+reconstruction+with+a+3D-printed,+biomechanically+evaluated+custom+implant+after+complex+pelvic+tumor+resection.">One-step reconstruction with a 3D-printed, biomechanically evaluated custom implant after complex pelvic tumor resection.</a> Computed Aided Surgery. 20 (1), 14-23 (2015).</li><li>Fang, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Surgical+applications+of+three-dimensional+printing+in+the+pelvis+and+acetabulum:+From+models+and+tools+to+implants.">Surgical applications of three-dimensional printing in the pelvis and acetabulum: From models and tools to implants.</a> Der Unfallchirurg. 122 (4), 278-285 (2019).</li><li>Upex, P., Jouffroy, P., Riouallon, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Application+of+3D+printing+for+treating+fractures+of+both+columns+of+the+acetabulum:+Benefit+of+pre-contouring+plates+on+the+mirrored+healthy+pelvis.">Application of 3D printing for treating fractures of both columns of the acetabulum: Benefit of pre-contouring plates on the mirrored healthy pelvis.</a> Orthopaedics &amp; Traumatology, Surgery &amp; Research. 103 (3), 331-334 (2017).</li><li>Xie, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Three-dimensional+printing+assisted+ORIF+versus+conventional+ORIF+for+tibial+plateau+fractures:+A+systematic+review+and+meta-analysis.">Three-dimensional printing assisted ORIF versus conventional ORIF for tibial plateau fractures: A systematic review and meta-analysis.</a> International Journal of Surgery. 57, 35-44 (2018).</li><li>Scorcelletti, M., Reeves, N. D., Rittweger, J., Ireland, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femoral+anteversion:+Significance+and+measurement.">Femoral anteversion: Significance and measurement.</a> Journal of Anatomy. 237 (5), 811-826 (2020).</li><li>Seitlinger, G., Moroder, P., Scheurecker, G., Hofmann, S., Grelsamer, R. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+contribution+of+different+femur+segments+to+overall+femoral+torsion.">The contribution of different femur segments to overall femoral torsion.</a> The American Journal of Sports Medicine. 44 (7), 1796-1800 (2016).</li><li>Kaiser, P., Attal, R., Kammerer, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Significant+differences+in+femoral+torsion+values+depending+on+the+CT+measurement+technique.">Significant differences in femoral torsion values depending on the CT measurement technique.</a> Archives of Orthopaedic and Trauma Surgery. 136 (9), 1259-1264 (2016).</li><li>Schmaranzer, F., Lerch, T. D., Siebenrock, K. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Differences+in+femoral+torsion+among+various+measurement+methods+increase+in+hips+with+excessive+femoral+torsion.">Differences in femoral torsion among various measurement methods increase in hips with excessive femoral torsion.</a> Clinical Orthopaedics and Related Research. 477 (5), 1073-1083 (2019).</li><li>Sanchis-Alfonso, V., Domenech-Fernandez, J., Ferras-Tarrago, J., Rosello-A&#241;on, A., Teitge, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+incidence+of+complications+after+derotational+femoral+and/or+tibial+osteotomies+in+patellofemoral+disorders+in+adolescents+and+active+young+patients:+A+systematic+review+with+meta-analysis.">The incidence of complications after derotational femoral and/or tibial osteotomies in patellofemoral disorders in adolescents and active young patients: A systematic review with meta-analysis.</a> Knee Surgery, Sports Traumatology, Arthroscopy. 30 (10), 3515-3525 (2022).</li></ol>

The authors have no conflicts of interest to disclose.

The most important finding of this study is that 3D technology allows the planning of proximal external derotational femoral osteotomy. This technology can simulate the surgery that is to be performed on a specific patient on the computer. It is a simple, reproducible, and free technique that uses software adaptable to most computers. The only technical problem may be that the 3D builder software works only with the Windows operating system. The major limitation is the learning curve. This protocol is still in the prelim...

Anterior knee pain (AKP) is a common clinical issue among adolescents and young adults. There is a growing body of evidence that increased femoral anteversion (FAV) plays an important role in the genesis of AKP1,2,3,4,5,6,7,8,9,10,11. In addition, this same evidence suggests that a derotational femoral osteotomy is beneficial for these patients, as good clinical results have been reported1,2,3,4,5,6,7,8,9,10,11. However, this type of surgery is not widely used in daily clinical practice among orthopedic surgeons, especially in the cases of adolescents and young active patients with anterior knee pain27, because the many controversial aspects generate uncertainty. For example, it has been observed that sometimes the correction obtained after the osteotomy is not what was previously planned. That is, there is not always a 1:1 ratio between the amount of rotation planned when performing the osteotomy and the amount of FAV corrected. This finding has not been studied to date. Therefore, it is the subject of the present paper. To explain the discrepancy between the magnitude of the rotation performed with the osteotomy and the magnitude of the correction of FAV, it was hypothesized that the axis of rotation of the osteotomy and the axis of rotation of the femur may not coincide.
One of the main problems to be addressed is accurately locating the femoral axis of rotation and the axis of rotation of the osteotomy. The first femoral axis is the femoral axis measured on the CT scan at the time of the patient&#39;s diagnosis, while the second femoral axis is the femoral axis measured after performing the osteotomy. Over the last decade, 3D technology has become increasingly important in preoperative planning, especially in orthopedic surgery and traumatology, for simplifying and optimizing surgical techniques15,16. The development of 3D technology has supported the creation of anatomical biomodels based on 3D imaging tests such as CT, in which customized prosthetic implants can be adapted17,18,19 and osteosynthesis plates can be molded in the case of fractures20,21,22. Additionally, 3D planning has already been used in previous studies to analyze the origin of the deformity in unilateral torsional alterations of the femur14. Currently, there are several software programs that are completely free and adaptable to most computers and 3D printers on the market, making this technology easily accessible to most surgeons in the world. This 3D planning allows for the accurate calculation of the initial axis of rotation of the femur and the axis of rotation of the femur after the intertrochanteric osteotomy has been performed. The main purpose of this study is to demonstrate that the axis of rotation of the femoral intertrochanteric osteotomy and the axis of rotation of the femur do not coincide. This 3D technology makes it possible to visualize this discrepancy between the axes and correct it through an adjustment of the osteotomy. The ultimate goal is to stimulate greater interest from orthopedic surgeons in this type of surgery.
This protocol with a 3D methodology is conducted in four fundamental steps. First, CT images are downloaded, and the 3D biomodel is created from the DICOM (Digital Imaging and Communication in Medicine) files of the CT scan. Higher-quality CT scans allow for better biomodels but mean the patient receives more ionizing radiation. For surgical planning with biomodels, the quality of conventional CT is sufficient. The DICOM image of a CT scan consists of a folder with many different files, with one file for each CT cut made. Each of these files contains not only the CT cut&#39;s graphical information but also the metadata (data associated with the image). To open the image, it is essential to have a folder with all the files of the series (the CT). The biomodel is extracted from the totality of the files.
Second, to obtain the 3D biomodel, it is necessary to download the 3D Slicer computer program, an open-source program with many utilities. Furthermore, this is the most widely used computer software in international 3D laboratories and has the advantage of being completely free of cost and downloadable from its main page. As this software is an X-ray image viewer, the DICOM image must be imported into the program.
Third, the first biomodel obtained with 3D Slicer will not match with the definitive one, because there will be regions such as the CT table or bones and soft parts nearby that are of no interest. The biomodel is &#34;cleaned&#34; almost automatically with the 3D design software, MeshMixer, which can also be downloaded directly from its official website for free. Finally, femoral anteversion is calculated, and the osteotomy is simulated using another free software from the Windows Store, 3D Builder.
