1. Animal preparation for surgery
NOTE: Use Sprague Dawley Rat (8-10 weeks old) without the sex bias for this experiment.
<ol>
	<li>Anesthetize the rat with 90 mg/kg ketamine and 10 mg/kg xylazine cocktail intraperitoneally. To maintain the desired depth of anesthesia throughout the surgery, provide...

<ol>
	<li>Leergaard, T. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rat+somatosensory+cerebropontocerebellar+pathways:+spatial+relationships+of+the+somatotopic+map+of+the+primary+somatosensory+cortex+are+preserved+in+a+three-dimensional+clustered+pontine+map.">Rat somatosensory cerebropontocerebellar pathways: spatial relationships of the somatotopic map of the primary somatosensory cortex are preserved in a three-dimensional clustered pontine map.</a> Journal of Comparative Neurology. 422 (2), 246-266 (2000).</li><li>Craner, S. L., Ray, R. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Somatosensory+cortex+of+the+neonatal+pig:+I.+Topographic+organization+of+the+primary+somatosensory+cortex+(SI).">Somatosensory cortex of the neonatal pig: I. Topographic organization of the primary somatosensory cortex (SI).</a> Journal of Comparative Neurology. 306 (1), 24-38 (1991).</li><li>Benison, A. M., Rector, D. M., Barth, D. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hemispheric+mapping+of+secondary+somatosensory+cortex+in+the+rat.">Hemispheric mapping of secondary somatosensory cortex in the rat.</a> Journal of Neurophysiology. 97 (1), 200-207 (2007).</li><li>Lee, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Graphene-electrode+array+for+brain+map+remodeling+of+the+cortical+surface.">Graphene-electrode array for brain map remodeling of the cortical surface.</a> NPG Asia Materials. 13 (1), (2021).</li><li>Yang, S. C., Weiner, B. D., Zhang, L. S., Cho, S. J., Bao, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Homeostatic+plasticity+drives+tinnitus+perception+in+an+animal+model.">Homeostatic plasticity drives tinnitus perception in an animal model.</a> Proceedings of the National Academy of Sciences of the United States of America. 108 (36), 14974-14979 (2011).</li><li>Yang, S., Zhang, L. S., Gibboni, R., Weiner, B., Bao, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Impaired+development+and+competitive+refinement+of+the+cortical+frequency+map+in+tumor+necrosis+factor-alpha-deficient+mice.">Impaired development and competitive refinement of the cortical frequency map in tumor necrosis factor-alpha-deficient mice.</a> Cerebral Cortex. 24 (7), 1956-1965 (2014).</li><li>Miyakawa, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tinnitus+correlates+with+downregulation+of+cortical+glutamate+decarboxylase+65+expression+but+not+auditory+cortical+map+reorganization.">Tinnitus correlates with downregulation of cortical glutamate decarboxylase 65 expression but not auditory cortical map reorganization.</a> Journal of Neuroscience. 39 (50), 9989-10001 (2019).</li><li>Yang, S., Su, W., Bao, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Long-term,+but+not+transient,+threshold+shifts+alter+the+morphology+and+increase+the+excitability+of+cortical+pyramidal+neurons.">Long-term, but not transient, threshold shifts alter the morphology and increase the excitability of cortical pyramidal neurons.</a> Journal of Neurophysiology. 108 (6), 1567-1574 (2012).</li><li>Beniczky, S., Schomer, D. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electroencephalography:+basic+biophysical+and+technological+aspects+important+for+clinical+applications.">Electroencephalography: basic biophysical and technological aspects important for clinical applications.</a> Epileptic Disorders. 22 (6), 697-715 (2020).</li><li>Kim, S. G., Richter, W., U&#287;urbil, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Limitations+of+temporal+resolution+in+functional+MRI.">Limitations of temporal resolution in functional MRI.</a> Magnetic Resonance Medicine. 37 (4), 631-636 (1997).</li><li>Cho, Z. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+fusion+PET-MRI+system+with+a+high-resolution+research+tomograph-PET+and+ultra-high+field+7.0+T-MRI+for+the+molecular-genetic+imaging+of+the+brain.">A fusion PET-MRI system with a high-resolution research tomograph-PET and ultra-high field 7.0 T-MRI for the molecular-genetic imaging of the brain.</a> Proteomics. 8 (6), 1302-1323 (2008).</li><li>Viventi, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Flexible,+foldable,+actively+multiplexed,+high-density+electrode+array+for+mapping+brain+activity+in+vivo.">Flexible, foldable, actively multiplexed, high-density electrode array for mapping brain activity in vivo.</a> Nature Neuroscience. 14 (12), 1599-1605 (2011).</li><li>Masvidal-Codina, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-resolution+mapping+of+infraslow+cortical+brain+activity+enabled+by+graphene+microtransistors.">High-resolution mapping of infraslow cortical brain activity enabled by graphene microtransistors.</a> Nature Materials. 18 (3), 280-288 (2019).</li><li>Blaschke, B. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mapping+brain+activity+with+flexible+graphene+micro-transistors.">Mapping brain activity with flexible graphene micro-transistors.</a> 2D Materials. 4 (2), 025040 (2017).</li><li>Park, S. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Epidural+electrotherapy+for+epilepsy.">Epidural electrotherapy for epilepsy.</a> Small. 14 (30), 1801732 (2018).</li><li>Lim, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hybrid+graphene+electrode+for+the+diagnosis+and+treatment+of+epilepsy+in+free-moving+animal+models.">Hybrid graphene electrode for the diagnosis and treatment of epilepsy in free-moving animal models.</a> NPG Asia Materials. 15 (1), 7 (2023).</li><li>Hermanns, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+mechanisms+of+action+of+systemic+lidocaine+in+acute+and+chronic+pain:+a+narrative+review.">Molecular mechanisms of action of systemic lidocaine in acute and chronic pain: a narrative review.</a> British Journal of Anaesthesia. 123 (3), 335-349 (2019).</li><li>Tchoe, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+brain+mapping+with+multithousand-channel+PtNRGrids+resolves+spatiotemporal+dynamics.">Human brain mapping with multithousand-channel PtNRGrids resolves spatiotemporal dynamics.</a> Science Translational Medicine. 14 (628), (2022).</li><li>Wilent, W. B., Contreras, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamics+of+excitation+and+inhibition+underlying+stimulus+selectivity+in+rat+somatosensory+cortex.">Dynamics of excitation and inhibition underlying stimulus selectivity in rat somatosensory cortex.</a> Nature Neuroscience. 8 (10), 1364-1370 (2005).</li><li>Insanally, M. N., K&#246;ver, H., Kim, H., Bao, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Feature-dependent+sensitive+periods+in+the+development+of+complex+sound+representation.">Feature-dependent sensitive periods in the development of complex sound representation.</a> Journal of Neuroscience. 29 (17), 5456-5462 (2009).</li></ol>

The presented protocol provides an in-depth, step-by-step process that explains how to access and map the somatosensory responses of rats using a graphene electrode array. The protocol-acquired data are SEPs that provide somatosensory information that is synaptically linked to each body part.
Several aspects of this protocol should be considered. When extracting cerebrospinal fluid to prevent brain edema and mitigate inflammation, it is crucial for the experimenter not to damage the brainstem ...

A cortical map is a set of local patches representing response properties to sensorimotor stimuli in the cerebral cortex. They are a spatial formation of neural networks and enable prediction for perception and cognition. Therefore, cortical maps are useful in evaluating neural responses to external stimuli and processing sensorimotor information1,2,3,4. Invasive and noninvasive methods are available for cortical mapping. One of the most common invasive methods involves the use of intracortical (or penetrating) electrodes for mapping5,6,7,8.
Assessing the on-demand high-resolution cortical maps using penetrating electrodes has faced several obstacles. The method is too laborious to obtain a decent map and too invasive to implement for clinical use, prohibiting further development. More recent technologies such as electroencephalography (EEG), positron emission tomography (PET), magnetoencephalography (MEG), and functional magnetic resonance imaging (fMRI) have gained popularity because these are less invasive and reproducible. However, given their prohibitive costs and poor resolution, they are used in a limited number of cases9,10,11. Recently, flexible surface electrodes with superior signal reliability have attracted considerable attention. Graphene-based surface electrodes demonstrate long-term biocompatibility and mechanical flexibility, providing stable recordings in a convoluted brain12,13,14,15,16. Our group has recently developed a graphene-based multichannel array for high-resolution recording and site-specific neurostimulation on the cortical surface. This technology allows us to keep track of the cortical representations of sensory information for an extended period.
This article describes the steps involved in acquiring a brain map of the somatosensory cortex using a 30-channel graphene multielectrode array. To measure brain activity, a graphene electrode array is placed on the subdural area of the cortex, while the forepaw, forelimb, hind paw, hindlimb, trunk, and whiskers are stimulated with a wooden stick. The somatosensory-evoked-potentials (SEPs) are recorded for somatosensory areas. This protocol can also be applied to other brain areas, such as the auditory, visual, and motor cortex.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>1mL syringe</td>
			<td>KOREAVACCINE CORPORATION</td>
			<td></td>
			<td>injecting the drug for anesthesia&#160;</td>
		</tr>
		<tr>
			<td>3mL syringe</td>
			<td>KOREAVACCINE CORPORATION</td>
			<td></td>
			<td>injecting the drug for anesthesia&#160;</td>
		</tr>
		<tr>
			<td>Bone rongeur</td>
			<td>Fine Science Tools</td>
			<td>16220-14</td>
			<td>remove the skull</td>
		</tr>
		<tr>
			<td>connector</td>
			<td>Gbrain</td>
			<td></td>
			<td>Connect graphene electrode to headstage</td>
		</tr>
		<tr>
			<td>drill</td>
			<td>FALCON tool</td>
			<td></td>
			<td>grind the skull</td>
		</tr>
		<tr>
			<td>drill bits</td>
			<td>Osstem implant</td>
			<td></td>
			<td>grind the skull</td>
		</tr>
		<tr>
			<td>Graefe iris forceps slightly curved serrated</td>
			<td>vubu</td>
			<td>vudu-02-73010</td>
			<td>remove the tissue from the skull or hold wiper</td>
		</tr>
		<tr>
			<td>graphene multielectrode array</td>
			<td>Gbrain</td>
			<td></td>
			<td>records signals from neuron</td>
		</tr>
		<tr>
			<td>isoflurane</td>
			<td>Hana Pharm Corporation</td>
			<td></td>
			<td>sacrifce the subject</td>
		</tr>
		<tr>
			<td>ketamine</td>
			<td>yuhan corporation</td>
			<td></td>
			<td>used for anesthesia</td>
		</tr>
		<tr>
			<td>lidocaine(2%)</td>
			<td>Daihan pharmaceutical&#160;</td>
			<td></td>
			<td>local anesthetic</td>
		</tr>
		<tr>
			<td>Matlab R2021b</td>
			<td>Mathworks</td>
			<td></td>
			<td>Data analysis Software</td>
		</tr>
		<tr>
			<td>mosquito hemostats</td>
			<td>Fine Science Tools</td>
			<td>91309-12</td>
			<td>fasten the scalp</td>
		</tr>
		<tr>
			<td>ointment</td>
			<td>Alcon</td>
			<td></td>
			<td>prevent eye from drying out&#160;</td>
		</tr>
		<tr>
			<td>povidone</td>
			<td>Green Pharmaceutical corporation</td>
			<td></td>
			<td>disinfect the incision area</td>
		</tr>
		<tr>
			<td>RHS 32ch Stim/Record headstage</td>
			<td>intan technologies</td>
			<td>M4032</td>
			<td>connect connector to interface cable and contain intan RHS stim/amplifier chip</td>
		</tr>
		<tr>
			<td>RHS 6-ft (1.8m) Stim SPI interface cable</td>
			<td>intan technologies</td>
			<td>M3206</td>
			<td>connect graphene electrode to headstage</td>
		</tr>
		<tr>
			<td>RHS Stim/Recording controller software</td>
			<td>intan technologies</td>
			<td></td>
			<td>Data Acquisition Software</td>
		</tr>
		<tr>
			<td>RHS stimulation/ Recording controller</td>
			<td>intan technologies</td>
			<td>M4200</td>
			<td></td>
		</tr>
		<tr>
			<td>saline</td>
			<td>JW Pharmaceutical</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>scalpel</td>
			<td>Hammacher</td>
			<td>HSB 805-03</td>
			<td></td>
		</tr>
		<tr>
			<td>stereotaxic instrument</td>
			<td>stoelting</td>
			<td></td>
			<td>fasten the subject</td>
		</tr>
		<tr>
			<td>sterile Hypodermic Needle</td>
			<td>KOREAVACCINE CORPORATION</td>
			<td></td>
			<td>remove the dura mater</td>
		</tr>
		<tr>
			<td>Steven Iris Tissue Forceps</td>
			<td>KASCO</td>
			<td>50-2026</td>
			<td>remove the dura mater</td>
		</tr>
		<tr>
			<td>surgical blade no.11</td>
			<td>FEATHER</td>
			<td></td>
			<td>inscise the scalp</td>
		</tr>
		<tr>
			<td>surgical sicssors</td>
			<td>Fine Science Tools</td>
			<td>14090-09</td>
			<td>inscise the scalp and remove the dura mater</td>
		</tr>
		<tr>
			<td>wooden stick</td>
			<td></td>
			<td></td>
			<td>whisker stimulation</td>
		</tr>
		<tr>
			<td>xylazine</td>
			<td>Bayer Korea</td>
			<td></td>
			<td>used for anesthesia</td>
		</tr>
	</tbody>
</table>

brain mapping using a graphene electrode array

Cortical maps represent the spatial organization of location-dependent neural responses to sensorimotor stimuli in the cerebral cortex, enabling the prediction of physiologically relevant behaviors. Various methods, such as penetrating electrodes, electroencephalography, positron emission tomography, magnetoencephalography, and functional magnetic resonance imaging, have been used to obtain cortical maps. However, these methods are limited by poor spatiotemporal resolution, low signal-to-noise ratio (SNR), high costs, and non-biocompatibility or cause physical damage to the brain. This study proposes a graphene array-based somatosensory mapping method as a feature of electrocorticography that offers superior biocompatibility, high spatiotemporal resolution, desirable SNR, and minimized tissue damage, overcoming the drawbacks of previous methods. This study demonstrated the feasibility of a graphene electrode array for somatosensory mapping in rats. The presented protocol can be applied not only to the somatosensory cortex but also to other cortices such as the auditory, visual, and motor cortex, providing advanced technology for clinical implementation.

This protocol describes how a graphene multichannel array is mounted on the surface of the brain. The somatosensory map was constructed by acquiring neural responses to physical stimuli and calculating the amplitude of the response. Figure 1 shows the schematic of this experiment.
Figure 2A presents the structural characteristics of a graphene electrode array. There are thru-holes of the substrate between the electrodes. These holes h...
