This study was supported by Human Frontier Science Program and the Sasakawa Scientific Research Grant from the Japan Science Society.

All procedures for the use of animals were approved by the Animal Care and Use Committee at the Okinawa Institute of Science and Technology.
1. Animals
<ol>
	<li>Obtain male Long-Evans rats (250-300 g on arrival).</li>
	<li>Upon arrival, house a group of two or three rats together for a week and later separate them into individual cages. Note that this experimental design involves food-restriction and needs to hold an animal in each cage to control the amount food consumed.</li>
	<li>Provide all animals with food and water ad libitum, and house them under standard conditions (12 hr/12 hr light/dark cycle, at 23 &#176;C).</li>
	<li>5 days before the beginning of behavioral experiments, food-restrict animals at approximately 85% of their average weight with free access to water throughout experiments.</li>
	<li>Handle animals for 5 min a day for a minimum of 5 days before the beginning of experiments in order to familiarize them with an experimenter.</li>
</ol>
2. Hardware and Software for Behavioral Tests and Analyses
<ol>
	<li>Hardware
	<ol>
		<li>Use an operant chamber equipped with a sound attenuating box.</li>
		<li>The chamber is incorporated with several additional attachments: two receptacle levers on the front panel, two light cues just above the levers, a magazine spot with a sensor for detection of head entry between two levers, a food dispenser, a pure tone generator and a house light on the rear panel.</li>
	</ol>
	</li>
	<li>Software
	<ol>
		<li>Control all the behavioral events under a programmed code written by Trans IV software. Use Med-PC IV software to signal and detect all the behavioral events during training and a test.</li>
		<li>Use Trans IV for writing code for behavioral testing. Open a new file for writing.</li>
		<li>Once the program is written, translate and compile it within the software. Modify the code if errors are detected and retry.</li>
		<li>Upon successful debugging of a program, check if user&#39;s code works properly by conducting a trial-run before actual initiation of experiments.</li>
		<li>Using MED-PC IV, run behavioral experiments. Open the software, click &#34;open session&#34; and assign a single program to each box.</li>
		<li>After all the programs have been properly assigned to each box, send signals necessary to start experiments.</li>
		<li>After the completion of the task, save data as clicking &#34;Save Data&#34; or write code to automatically save data (for details, see programmer&#39;s manual for MED-PC IV).</li>
		<li>Once data is exported to a designated folder, rename the data as acquisition date and animal ID numbers for later use. The collected data is imported into Matlab for behavioral analyses described below (Protocol, 3.7).</li>
	</ol>
	</li>
</ol>
3. Behavioral Training and Testing
<ol>
	<li>Habituation and Magazine training.
	<ol>
		<li>Present no levers to animals during those phases.</li>
		<li>During the habituation phase, place animals in an operant chamber for 20 minutes a day. On the same day, give 10 sucrose pellets (45 mg) to animals in their home cage, which familiarize them to the sucrose reward.</li>
		<li>Next, begin magazine training. Place animals in the chamber and give 20 sucrose pellets (1 pellet per a minute) to the animals, providing an opportunity to learn the location of the food tray and acquisition of the pellets.
		NOTE: Those phases can be skipped due to potential confusion of animals on obtaining a pellet without an operant response, even though we adopted them to make animals familiarized with a chamber and eating from a food tray.</li>
	</ol>
	</li>
	<li>Continuous reinforcement schedule
	<ol>
		<li>Train animals on a continuous reinforcement schedule to obtain a reward by pressing a lever. A session of this training lasts until 60 pellets have been received (60 lever-presses) or 40 min has elapsed.</li>
		<li>Present either the left or right lever throughout the first half of a session (until 30 pellets are obtained), followed by the presentation of the opposite lever during the second half. The order is alternated on a daily basis.</li>
		<li>Continue this reinforcement schedule until animals have successfully obtained 60 rewards for at least 2 consecutive days. Note that there may be high variability among animals of how quickly they make the first lever-press and this may affect the progress of reinforcement. In this case, put a few sucrose pellets on a presented lever to motivate them to approach toward the lever when no response has been made over the first session.
		NOTE: A possible alternative is to put sucrose pellets when the lever is first presented to animals in order to make the completion of this phase faster.</li>
	</ol>
	</li>
	<li>Time schedule for a trial in lever-press training and testing.
	<ol>
		<li>Start a single trial with a 3 sec (s) tone.</li>
		<li>2 sec after the termination of tone, present two levers and allow animals to press either lever within 10 sec. In case that no response is made within 10 s, retract both levers and count this trial as an omission trial.</li>
		<li>In the case of the lever press training, present only a single lever on either side.</li>
		<li>In most of experimental conditions, there was a light stimulus above one of levers. Turn the light cue on immediately after the tone ceases and turn off when animals have either made a response or in 10 sec after lever insertion when no response has been made.</li>
		<li>Set inter-trial intervals at 20~30 sec.</li>
	</ol>
	</li>
	<li>Lever-press training
	<ol>
		<li>In this training phase, present no light to animals.</li>
		<li>Train animals under lever-press training for 5-8 sessions with the same time schedule for a trial as testing sessions described below.</li>
		<li>In this training, present either left or right lever randomly, and the lever has to be pressed within 10 sec after the lever is presented, or the trial is counted as an omission without a response. A session for the lever press training comprised of 80 trials.</li>
		<li>Once the animals have scored fewer than 10% of omissions out of 80 trials, move them to the following side-bias test.</li>
	</ol>
	</li>
	<li>Side-bias test
	<ol>
		<li>Perform a side-bias test to determine the animal&#39;s preference to either left or right lever1. A trial entails two lever-presses on both sides.</li>
		<li>Place animals in an operant chamber and allow them to choose either lever. In the next attempt, animals have to select the opposite lever in order to obtain a reward. If animal&#39;s second attempt is on the same side of the first response, give no reward and continue the trial until a response is made on the opposite side.</li>
		<li>Conduct a total of 7 trials to determine animal&#39;s side preference.</li>
	</ol>
	</li>
	<li>Testing.
	<ol>
		<li>A daily session consists of 80 trials.</li>
		<li>Prepare three different conditions for set-shifting procedures as shown in Figure 1.</li>
		<li>All the three conditions require animals to similarly change behavioral strategies from choosing one lever that is consistently on the same side (Phase 1, response strategy) to following a light cue that indicates a correct side (Phase 2, visual cue strategy).</li>
		<li>Begin with initial learning of a response strategy (Phase 1) for 4 sessions, in which animals have to press a lever based on the location of levers. In this phase, set the correct side to the lever opposite to their preference based on a preliminary side-bias test as mentioned above.</li>
		<li>Next, commence visual cue learning (Phase 2) for 10 sessions. A light cue illuminated above either lever indicates a correct lever. In this shifting phase, three different patterns of attentional shifts can be compared among three experimental conditions as described below (3.3.6-3.3.8).</li>
		<li>In set-shift condition 1 (Figure 1A), give no light in phase 1, but a light cue indicates the correct side in phase 2. In condition 1, therefore, animals need to attend to a novel stimulus.</li>
		<li>In set-shift condition 2 (Figure 1B), present a light cue above the correct lever in phase 1, and again in phase 2. In this condition, the light cue had been relevant, but not necessarily required for making a choice in phase 1. Thus animals have to attend to a previously relevant cue.</li>
		<li>In set-shift condition 3 (Figure 1C), turn on a light cue randomly above either left or right lever in phase 1. Thus it has to be ignored. In phase 2 animals are required to pay attention to the light stimulus that has been previously irrelevant.</li>
	</ol>
	</li>
	<li>Behavioral analysis.
	<ol>
		<li>Throughout sessions, measure the percentage of correct responses on a daily basis, excluding omission trials.</li>
		<li>Count errors accumulated during 10 sessions of visual cue learning and classify them into perseverative, regressive or never-reinforced errors as described in a previous study1. There, a detailed analysis of error types suggests separate functions in set-shifting.</li>
		<li>Define perseverative errors as incorrect responses to the previously correct lever while animal&#39;s performance was still below chance level4,6,13,14,15. Similar criteria have been used in previous studies1,3,7,11.</li>
		<li>Based on a principled way, determine the criterion to separate between perseverative and regressive errors as the point at which the animal first scored fewer than 8 out of 10 incorrect responses (probability of making 8/10 errors or more = 0.054, based on cumulative binomial distribution) in a moving window of 10 trials.</li>
		<li>In order to find this point, start calculating a moving average of the 10 trial window from 1st trial and then advance it by one trial at a time until &#60;8/10 errors are measured. Conduct this analysis across all trials in which a light cue is illuminated above the previously incorrect lever during visual cue strategy.</li>
		<li>Define all the subsequent errors committed after this point as regressive errors.</li>
		<li>During visual cue learning, count never-reinforced errors when animals responded to a previously incorrect lever on which the light cue was not illuminated. Divide them into an early or late portion based on the learning phase; errors made in the first half of 10 sessions (session 1-5) are considered early and those in the second half (session 6-10) are regarded as late ones.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Floresco, S. B., Block, A. E., Tse, M. T. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inactivation+of+the+medial+prefrontal+cortex+of+the+rat+impairs+strategy+set-shifting,+but+not+reversal+learning,+using+a+novel,+automated+procedure.">Inactivation of the medial prefrontal cortex of the rat impairs strategy set-shifting, but not reversal learning, using a novel, automated procedure.</a> Behavioural Brain Research. 190, 85-96 (2008).</li><li>Nicolle, M. M., Baxter, M. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Glutamate+receptor+binding+in+the+frontal+cortex+and+dorsal+striatum+of+aged+rats+with+impaired+attentional+set-shifting.">Glutamate receptor binding in the frontal cortex and dorsal striatum of aged rats with impaired attentional set-shifting.</a> European Journal of Neuroscience. 18, 3335-3342 (2003).</li><li>Ragozzino, M. E., Ragozzino, K. E., Mizumori, S. J. Y., Kesner, R. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Role+of+the+dorsomedial+striatum+in+behavioral+flexibility+for+response+and+visual+cue+discrimination+learning.">Role of the dorsomedial striatum in behavioral flexibility for response and visual cue discrimination learning.</a> Behavioral Neuroscience. 116, 105-115 (2002).</li><li>Dias, R., Robbins, T. W., Roberts, A. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dissociation+in+prefrontal+cortex+of+affective+and+attentional+shifts.">Dissociation in prefrontal cortex of affective and attentional shifts.</a> Nature. 380, 69-72 (1996).</li><li>Monchi, O., Petrides, M., Petre, V., Worsley, K., Dagher, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Wisconsin+Card+Sorting+Revisited:+Distinct+Neural+Circuits+Participating+in+Different+Stages+of+the+Task+Identified+by+Event-Related+Functional+Magnetic+Resonance+Imaging.">Wisconsin Card Sorting Revisited: Distinct Neural Circuits Participating in Different Stages of the Task Identified by Event-Related Functional Magnetic Resonance Imaging.</a> The Journal of Neuroscience. 21, 7733-7741 (2001).</li><li>Dias, R., Robbins, T. W., Roberts, A. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dissociable+Forms+of+Inhibitory+Control+within+Prefrontal+Cortex+with+an+Analog+of+the+Wisconsin+Card+Sort+Test:+Restriction+to+Novel+Situations+and+Independence+from+&amp;#34;On-Line&amp;#34;+Processing.">Dissociable Forms of Inhibitory Control within Prefrontal Cortex with an Analog of the Wisconsin Card Sort Test: Restriction to Novel Situations and Independence from &amp;#34;On-Line&amp;#34; Processing.</a> The Journal of Neuroscience. 17, 9285-9297 (1997).</li><li>Floresco, S. B., Ghods-Sharifi, S., Vexelman, C., Magyar, O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dissociable+Roles+for+the+Nucleus+Accumbens+Core+and+Shell+in+Regulating+Set+Shifting.">Dissociable Roles for the Nucleus Accumbens Core and Shell in Regulating Set Shifting.</a> The Journal of Neuroscience. 26, 2449-2457 (2006).</li><li>Ragozzino, M. E., Detrick, S., Kesner, R. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Involvement+of+the+Prelimbic-Infralimbic+Areas+of+the+Rodent+Prefrontal+Cortex+in+Behavioral+Flexibility+for+Place+and+Response+Learning.">Involvement of the Prelimbic-Infralimbic Areas of the Rodent Prefrontal Cortex in Behavioral Flexibility for Place and Response Learning.</a> The Journal of Neuroscience. 19, 4585-4594 (1999).</li><li>Ragozzino, M. E., Jih, J., Tzavos, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Involvement+of+the+dorsomedial+striatum+in+behavioral+flexibility:+role+of+muscarinic+cholinergic+receptors.">Involvement of the dorsomedial striatum in behavioral flexibility: role of muscarinic cholinergic receptors.</a> Brain Research. 953, 205-214 (2002).</li><li>Witten, I. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recombinase-Driver+Rat+Lines:+Tools,+Techniques,+and+Optogenetic+Application+to+Dopamine-Mediated+Reinforcement.">Recombinase-Driver Rat Lines: Tools, Techniques, and Optogenetic Application to Dopamine-Mediated Reinforcement.</a> Neuron. 72, 721-733 (2011).</li><li>Floresco, S. B., Magyar, O., Ghods-Sharifi, S., Vexelman, C., Tse, M. T. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiple+Dopamine+Receptor+Subtypes+in+the+Medial+Prefrontal+Cortex+of+the+Rat+Regulate+Set-Shifting.">Multiple Dopamine Receptor Subtypes in the Medial Prefrontal Cortex of the Rat Regulate Set-Shifting.</a> Neuropsychopharmacology. 31, 297-309 (2006).</li><li>Aoki, S., Liu, A. W., Zucca, A., Zucca, S., Wickens, J. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Role+of+Striatal+Cholinergic+Interneurons+in+Set-Shifting+in+the+Rat.">Role of Striatal Cholinergic Interneurons in Set-Shifting in the Rat.</a> The Journal of Neuroscience. 35, 9424-9431 (2015).</li><li>Dias, R., Aggleton, J. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+selective+excitotoxic+prefrontal+lesions+on+acquisition+of+nonmatching-+and+matching-to-place+in+the+T-maze+in+the+rat:+differential+involvement+of+the+prelimbic-infralimbic+and+anterior+cingulate+cortices+in+providing+behavioural+flexibility.">Effects of selective excitotoxic prefrontal lesions on acquisition of nonmatching- and matching-to-place in the T-maze in the rat: differential involvement of the prelimbic-infralimbic and anterior cingulate cortices in providing behavioural flexibility.</a> European Journal of Neuroscience. 12, 4457-4466 (2000).</li><li>Hunt, P. R., Aggleton, J. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neurotoxic+Lesions+of+the+Dorsomedial+Thalamus+Impair+the+Acquisition+But+Not+the+Performance+of+Delayed+Matching+to+Place+by+Rats:+a+Deficit+in+Shifting+Response+Rules.">Neurotoxic Lesions of the Dorsomedial Thalamus Impair the Acquisition But Not the Performance of Delayed Matching to Place by Rats: a Deficit in Shifting Response Rules.</a> The Journal of Neuroscience. 18, 10045-10052 (1998).</li><li>Jones, B., Mishkin, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Limbic+lesions+and+the+problem+of+stimulus-Reinforcement+associations.">Limbic lesions and the problem of stimulus-Reinforcement associations.</a> Experimental Neurology. 36, 362-377 (1972).</li><li>Chen, K. C., Baxter, M. G., Rodefer, J. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Central+blockade+of+muscarinic+cholinergic+receptors+disrupts+affective+and+attentional+set-shifting.">Central blockade of muscarinic cholinergic receptors disrupts affective and attentional set-shifting.</a> European Journal of Neuroscience. 20, 1081-1088 (2004).</li><li>Bradfield, L. A., Bertran-Gonzalez, J., Chieng, B., Balleine, B. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+thalamostriatal+pathway+and+cholinergic+control+of+goal-directed+action:+interlacing+new+with+existing+learning+in+the+striatum.">The thalamostriatal pathway and cholinergic control of goal-directed action: interlacing new with existing learning in the striatum.</a> Neuron. 79, 153-166 (2013).</li><li>Okada, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enhanced+flexibility+of+place+discrimination+learning+by+targeting+striatal+cholinergic+interneurons.">Enhanced flexibility of place discrimination learning by targeting striatal cholinergic interneurons.</a> Nat Commun. 5, (2014).</li><li>Ragozzino, M. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Acetylcholine+actions+in+the+dorsomedial+striatum+support+the+flexible+shifting+of+response+patterns.">Acetylcholine actions in the dorsomedial striatum support the flexible shifting of response patterns.</a> Neurobiology of Learning and Memory. 80, 257-267 (2003).</li><li>Ravizza, S. M., Carter, C. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Shifting+set+about+task+switching:+Behavioral+and+neural+evidence+for+distinct+forms+of+cognitive+flexibility.">Shifting set about task switching: Behavioral and neural evidence for distinct forms of cognitive flexibility.</a> Neuropsychologia. 46, 2924-2935 (2008).</li><li>Rushworth, M. F. S., Hadland, K. A., Paus, T., Sipila, P. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Role+of+the+Human+Medial+Frontal+Cortex+in+Task+Switching:+A+Combined+fMRI+and+TMS+Study.">Role of the Human Medial Frontal Cortex in Task Switching: A Combined fMRI and TMS Study.</a> Journal of Neurophysiology. 87, 2577-2592 (2002).</li><li>Bissonette, G. B., Roesch, M. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rule+encoding+in+dorsal+striatum+impacts+action+selection.">Rule encoding in dorsal striatum impacts action selection.</a> European Journal of Neuroscience. 42, 2555-2567 (2015).</li></ol>

The authors have nothing to disclose.

We developed new variations on the established set-shifting paradigm for use in rats. Using those paradigms, cholinergic lesions of the striatum were found to impair set-shifting, suggesting a specific role of striatal cholinergic interneurons in set-shifting: suppression of an old rule and facilitation of exploration for a new rule. The effects differed between dorsomedial and ventral striatum, in accordance with the different role of these structures in learning.
A set-shifting task has been...

Behavioral flexibility is a key requirement for survival in a changing world. One of the established behavioral paradigms for testing this ability is set-shifting, in which a shift of attention from one stimulus dimension to another is necessary for changing action strategies after a change in rule. Several brain regions such as the prefrontal cortex and striatum are implicated in set-shifting2,3,4,5. Neural mechanisms for this function have been investigated across several species including humans5, monkeys6 and rats1,7,8,9. However, the rat versions of set-shifting tasks have not been as extensively developed. The cost-effectiveness of rats, their appropriate size for stereotaxic surgery, and the availability of recently developed genetic methods10, motivate further development of set-shifting paradigms for use in rats.
A typical set-shifting paradigm for rats requires a change between two behavioral strategies: for example, a response strategy and a visual-cue strategy. Rats initially have to choose one of two available options (such as left or right levers in an operant automated version1 or left or right arms in a T-maze version7,8,9,11). After a set shift, they have to switch to using a visual-cue strategy, such as a light cue indicating the correct side. In those conventional set-shifting tasks, it is necessary to shift attention from one stimulus dimension to another dimension that had been previously irrelevant.
In addition to changing to a dimension that had been previously irrelevant, there is also the logical possibility that a stimulus was previously relevant, or previously absent and now novel. Real life situations in nature may entail attention to a novel, or historically relevant but not crucial cue. Therefore, we considered these subtypes of set-shift, in a new variation of rodent set-shifting based on a previously established automated set-shifting task1.
We have recently demonstrated the use of the new version of set-shifting paradigms in an experiment to determine the effect of neurochemically specific lesions of the striatum12. In our previous study, we targeted cholinergic interneurons releasing acetylcholine (ACh) of the dorsomedial or ventral striatum since ACh and those subregions have been implicated in behavioral flexibility. All the experimental conditions demanded the same strategic shift but each involved different types of attentional shift: to a novel, previously relevant or previously irrelevant cue. We here describe detailed procedures of the paradigms, and highlight representative results suggesting that striatal cholinergic systems play a fundamental role in set-shifting, which is dissociable between different striatal subregions depending on behavioral contexts12.

<table><tbody><tr><td>Standard Modular Test Chamber</td><td>Med Associates</td><td>ENV-008</td><td></td></tr><tr><td>Low Profile Retractable Response Lever</td><td>Med Associates</td><td>ENV-112CM</td><td></td></tr><tr><td>Stimulus Light for Rat</td><td>Med Associates</td><td>ENV-221M</td><td></td></tr><tr><td>Switchable Dual Pellet/Dipper Receptacle for Rat</td><td>Med Associates</td><td>ENV-202RM-S</td><td></td></tr><tr><td>Head Entry Detector for Rat Receptacles</td><td>Med Associates</td><td>ENV-254-CB</td><td></td></tr><tr><td>Modular Pellet Dispenser; 45 mg for Rat</td><td>Med Associates</td><td>ENV-203M-45</td><td></td></tr><tr><td>Sonalert Module for Rat</td><td>Med Associates</td><td>ENV-223AM</td><td>4.5 kHz available (ENV-223HAM)</td></tr><tr><td>House Light for Rat Chambers</td><td>Med Associates</td><td>ENV-215M</td><td></td></tr><tr><td>SmartCtrl Interface Module, 8 input/16 output</td><td>Med Associates</td><td>DIG-716B</td><td></td></tr><tr><td>SmartCtrl Connection Panel, 8 input/16 output</td><td>Med Associates</td><td>SG-716B</td><td></td></tr><tr><td>45 mg Tablet-Fruit Punch</td><td>TestDiet</td><td>1811255</td><td>Several flavors available</td></tr></tbody></table>
