1. 实验设置 注意: 吸附式制冷系统由吸附床、蒸发器、冷凝器、真空泵和太阳能槽收集器 (图 1 )。研制了一种带抛物槽的自动太阳跟踪装置, 并将其应用于系统中, 提高了太阳能集热器的效率。自动太阳跟踪槽由蜗轮传动装置驱动, 如 图 2 所示。该装置由步进电机、蜗杆、齿轮、移动限位块和手动轮组成。蜗轮传动装置的尺寸为 21 x 80 cm 2 。槽收集器将太阳光线集中到吸附床上, 沿着抛物槽的焦点线放置.
 <img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/55925/55925fig1v2.jpg"/> 图 1: 太阳能实验系统吸附式制冷。系统的 (顶部) 示意图;底部)实验装置的照片。顶部面板介绍了实验系统的组成, 包括蒸发器、冷凝器、真空泵、#160 等; 等 和 #160; 底部面板显示了组装的吸附式制冷系统的照片。在系统中, 蒸发器和冷凝器是翅片管结构的一种紧凑型换热器。吸附床由真空太阳能集热器进行改造, 能有效地捕获太阳能. #160; <a href="//ecsource.jove.com/files/ftp_upload/55925/55925fig1v2large.jpg" target="_blank"> 请单击此处查看更大版本的这个数字. </a>
 <img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/55925/55925fig2v2.jpg"/> 图 2: 蜗轮齿轮箱的结构. 蜗轮箱是将步进电机的旋转转变为抛物槽的太阳跟踪运动的装置。除步进电机外, 蜗轮蜗杆箱还涉及减速机、手动轮、蜗杆轴、#160; 等 和 #160;P ulling 手动/自动开关手柄向左, 齿轮5a 和5b 脱离。因此, 可以通过旋转手轮手动控制槽。拉动手动/自动开关手柄的权利, 齿轮5a 和5b 是一起从事。因此, 它是由步进电机自动控制的.
<ol> <li> 通过焊接方法将跟踪太阳能收集器连接到蜗轮轴。通过匹配齿轮和蜗杆, 将步进电机的旋转传给太阳能集热器。将管式吸附床与收集器固定在一起, 用一对管子领.
	注: 由步进电机驱动, 系统每天从东向西旋转, 自动跟踪太阳运动. </li>
	根据不同季节的太阳高度变化, 将槽的倾斜角调整到地面水平。通过局部纬度和 #934 确定槽的倾斜角度和 #946; 太阳偏角和 #948; 以及公式和 #946; = 和 #934; #160; #948;手动旋转位于角度调整拉杆底部的小轮, 以调节槽的倾斜角度 (No. 13、 图 1 部分).
	注意: 通过这种方式, 太阳辐射是尽可能正常的槽。实验系统位于北京工业大学校园, 纬度39.89 和 #176; 东经116.38 和 #176; E。吸附床采取圆柱形。它从电子管的真空太阳能接收器 ( 图 3 ) 进行了改造. </li>
</ol> <img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/55925/55925fig3v2.jpg"/> 图 3 : 吸附床的结构和温度的部署探讨.床结构的 (顶部) 示意图;底部)床内温度探头和传质通道。顶部面板显示了床的基本结构。将吸附剂材料放在吸热管与铜冷却通道之间的环形腔内。太阳射线穿透玻璃管, 落在太阳能吸收管的表面上。然后, 通过导热, 将太阳能转移到床内的吸附剂材料。底部面板显示温度探头的位置。这些探头用于监测在吸附/解吸过程中的床层温度变化. #160; <a href="//ecsource.jove.com/files/ftp_upload/55925/55925fig3v2large.jpg" target="_blank"> 请单击此处查看更大版本这个数字. </a>
<ol start="3"> <li> 为了促进太阳能的捕获, 用真空镀膜法将一层黑色铬镀层覆盖在床的太阳能吸收管上 (用 d = 64.5 毫米的不锈钢制成)。有关此技术的更多信息, 请参阅以前发表的关于选择性涂层的文献 13 。确保镀膜层的太阳吸收率为 0.95, 红外辐射度为 0.15, 涂层厚度为 0.08 mm.
	注: 该涂层层有助于有效地捕捉太阳辐射, 但其本身的排放非常轻微。因此, 太阳能能很容易地进入吸附床, 并能有效地转化为吸附剂的热焓. </li>
	<li> 沿吸附床的轴线插入一个铜管 (d = 20 mm)。将铜管固定在带法兰的床上 (请参见 图 3 , 顶部面板)。在吸附过程中, 铜管作为床的冷却通道发挥作用. </li>
	<li> 填充床管和铜冷却通道形成的床内的环形腔中的吸附剂材料。用 SAPO-34 沸石作为吸附剂材料, 以水为制冷剂。把3.171 公斤的 SAPO-34 沸石放到床上。颗粒状 SAPO-34 沸石直径为5.7 毫米. </li>
	<li> 在床的三横截面上部署九温度探头, 以便在吸附/解吸过程中监视床的温度变化 ( 图 3 , 底部面板)。固定在铜冷却通道上的每个小型支架上安装探头. </li>
	<li> 将探头1和2放在 a a a 区, 靠近吸附床的入口。将探头8和9靠近床的死角。修复中间 b-b 部分的其他探测器 (请参见 图 3 ). </li>
	<li> 将 d = 10 mm 轴向质量传输通道插入到床上。确保质量通道具有网状管的形式, 并且与吸附床的长度相同 (d 床 = 64.5 mm)。将通道从进口处向下延伸, 使其与吸附剂材料的挤出力处于正确位置。网状管帮助水蒸气迅速进入床的深层区域. </li>
</ol> 2。实验方法 注意: 吸附制冷是基于固体吸附剂材料在低温下吸附制冷剂蒸气的原理, 同时在较高的温度下 desorbs 蒸气。以热为动力, 达到制冷的目的。吸附系统的制冷循环主要涉及四步骤, 即 , 太阳能升温过程中, 脱附过程、床层冷却过程和吸附过程。在吸附过程完成后, 解吸过程再次开始。实验的所有步骤都同样重要, 因为它们相互关联, 相互影响.
<ol> <li> 通过以下步骤调节实验设置, 以启动太阳的加热和对床的解吸.
	<ol> <li> 手动翻转抛物槽, 直到它在实验前正向东, 以便在中午时阳光照射抛物槽收集器. </li>
		<li> 关闭所有连接到吸附床的阀门, 并确保床的压力和管道低于 800 Pa. 使其可以进行太阳能加热. </li>
		<li> 当太阳光与地平线平行时, 在系统的控制平台上切换。使槽自动旋转以跟踪太阳运动. </li>
		<li> 允许在封闭条件下通过太阳辐射加热吸附饱和床。因此, 床的温度和床的压力将逐渐增加. </li>
		<li> 用压力表 (数字6在 图 1 ) 监视床压力, 直到它高于与环境的冷凝温度对应的压力值。根据热力学, 水的冷凝压力在30和 #176; C 是 4246 Pa. </li>
	</ol> </li> <li> 启动解吸过程.
	#8203; 注意: 在解吸过程中, 水蒸气的凝结发生。冷凝温度由当地天气情况决定在测试天。
	<ol> <li> 打开连接床和冷凝器的阀门。让水蒸气通过连接管流入冷凝器。当水蒸气进入冷凝器时, 冷凝器的温度会逐渐上升. </li>
		<li> 同时, 保持太阳对吸附床的加热, 使床压保持在足够高的高度, 使其解吸。不要停止太阳能加热, 直到过程完成. </li>
		当床的压力等于冷凝器的压力时, <li> 结束解吸过程。当解吸过程结束时, 关闭阀门. </li>
	</ol> </li> <li> 在吸附过程前将床冷却下来, 因为床在高温解吸后仍处于高温状态。吸附剂材料只能在低温下吸附.
	<ol> <li> 启动吸附过程, 用铝箔板屏蔽吸附床, 使床与太阳辐射切断. </li>
		<li> 关闭连接蒸发器和冷凝器的所有阀门. </li>
		<li> 打开床的循环水环, 冷却吸附剂材料。随着水在床上的不断循环, 内部焓被取出, 床层压力相应降低. </li>
		<li> 结束冷却过程时, 床压力下降低于饱和蒸气压在蒸发器和 #39; s 温度.
		注意: 在床的冷却后, 准备好吸附制冷过程。现在, 床的温度是周围的空气温度, 和床的压力已达到最低水平. </li>
		<li> 在吸附过程中保持循环水环处于工作状态。吸附是一个放热过程, 产生的热量需要尽快排出室外. </li>
		<li> 打开床和蒸发器之间的阀门。让水蒸气从蒸发器冲进床里.
		注: 蒸发器蒸气的减少使蒸发的水分增加, 导致蒸发器温度的急剧下降。因此, 蒸发器吸收蒸发器所在水箱的热量, 并获得制冷效果. </li>
		<li> 保持吸附过程持续进行, 并记录床温和床压的变化.
		注: 在吸附过程中, 蒸发器内的蒸气压降低, 但床层温度迅速升高. </li>
		当床压力等于蒸发器压力时, <li> 结束吸附过程。之后, 解吸过程将再次执行. </li>
	</ol> </li> </ol> 3。数据缩减方法 <ol> <li> 根据制冷容量和 heat-to-cold 转换的效率来评估制冷系统的性能.
	#8203; 注意: 对于当前系统, 制冷量是由蒸发水的质量量和蒸发器本身的温度变化来计算的。
	<ol> <li> 要确定系统的总制冷容量 (Q ref ), 请计算出罐内冷冻水、金属蒸发器的焓减量和在吸附后的蒸发器中的残余水的总和, 如下所示: <img alt="Equation 1" src="/files/ftp_upload/55925/55925eq1.jpg"/> 在 Eq 中的 c p (1) 是恒定压力下的比热, m 表示质量。考虑到水箱与周围环境之间的传热, c 是蒸发器制冷容量的一个修正因子, 根据传热原理假定为 c = 1.15。下标 w 和 e 分别代表水和蒸发器。在等式 m w, tan 和 m w, ev 是水箱中的冷水质量和蒸发器中的剩余水的质量, 对应于温度降和 #916; t w 和 #916; t e, 分别.
		注: 对床的太阳能输入需要评估 heat-to-cold 转换的效率. </li>
		<li> 确定太阳能输入 Q s as:
		<img alt="Equation 2" src="/files/ftp_upload/55925/55925eq2.jpg"/> 其中, i s、i (t) 是 actinometer 在解吸过程中记录的瞬态太阳强度。数据获取到 s, i (t) 的时间间隔和 #916 的 t 是十年代。抛物槽的孔径面积为 p , 槽面和 #961 的反射效率; 管玻璃和 #964 的透光率; 以及涂层表面和 #945 的太阳吸收系数; Eq (1) , 都列在 表 1 中。
		<li> 基于 q ref 和 q 在上面获得的 , 确定制冷系统的 COP 为 14 :
		<img alt="Equation 3" src="/files/ftp_upload/55925/55925eq3.jpg"/> 和 #946; 1 和 #946; 2 是对太阳能输入 Q 的修正因子. 和 #946; 1 是 non-parabolic 程度的修正因子槽, 由于制造工艺的局限性, 考虑了槽体的变形, 并假定和 #946; 1 = 0.85。和 #946; 2 是床的实际获得热量的修正因子。由于金属床管的尺寸比外玻璃管小, 实际得到的热量小于玻璃管上反射的热量。和 #946; 2 是由金属床径的比率 d 2 到玻璃管直径 d 1 决定的。使用 d 1 = 100 mm 和 d 2 = 64.5 mm, 计算该值和 #946; 2 = 0.645. </li>
		<li> 根据实验的参数确定床的特定冷却功率为 14 : g alt = "方程式 4" src = "/文件/ftp_upload/55925/55925eq4. jpg"/>> 其中 m a 是吸附剂材料的质量和 t 广告 是吸附过程的时间长短. </li>
	</ol> </li> </ol> <img alt="Table 1" src="/files/ftp_upload/55925/55925table1v2.jpg"/> 表 1: eq (1) 和 eq (2) 的参数值. 所涉及的和 #160 的参数; eq (1) 和 #160; 和 #160; eq (2) 和 #160; 在此表中列出。参数包括 c p 、 p、#160; 和 #945; 等.

<ol>
	<li>Hu, P., Yao, J. J., Chen, Z. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+for+composite+zeolite/foam+aluminum-water+mass+recovery+adsorption+refrigeration+system+driven+by+engine+exhaust+heat.">Analysis for composite zeolite/foam aluminum-water mass recovery adsorption refrigeration system driven by engine exhaust heat.</a> Energ Convers Manage. 50, 255-261 (2009).</li><li>Sutuki, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Application+of+adsorption+cooling+system+to+automobiles.">Application of adsorption cooling system to automobiles.</a> Heat Recov Syst CHP. 4 (13), 335-340 (1993).</li><li>Li, M., Wang, R. Z., Xu, Y. X., Wu, J. Y., Dieng, A. O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+study+on+dynamic+performance+analysis+of+a+flat-plate+solar+solid-adsorption+refrigeration+for+icemaker.">Experimental study on dynamic performance analysis of a flat-plate solar solid-adsorption refrigeration for icemaker.</a> Renew Energy. 27, 211-221 (2002).</li><li>Liu, Y. L., Wang, R. Z., Xia, Z. Z. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+study+on+a+continuous+adsorption+water+chiller+with+novel+design.">Experimental study on a continuous adsorption water chiller with novel design.</a> Int J Refrig. 28 (2), 218-230 (2005).</li><li>Sumathy, K., Li, Z. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experiments+with+solar-powered+adsorption+ice-maker.">Experiments with solar-powered adsorption ice-maker.</a> Renew Energy. 16, 704-707 (1999).</li><li>Hadj Ammar, M. A., Benhaoua, B., Balghouthi, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Simulation+of+tubular+adsorber+for+adsorption+refrigeration+system+powered+by+solar+energy+in+sub-Sahara+region+of+Algeria.">Simulation of tubular adsorber for adsorption refrigeration system powered by solar energy in sub-Sahara region of Algeria.</a> Energ Convers Manage. 106, 31-40 (2015).</li><li>Wang, R. Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experiment+on+a+continuous+heat+regenerative+adsorption+refrigerator+using+spiral+plate+heat+exchanger+as+adsorbers.">Experiment on a continuous heat regenerative adsorption refrigerator using spiral plate heat exchanger as adsorbers.</a> Appl Therm Eng. 18, 14-19 (1998).</li><li>Abu-Hamdeh, N. H., Alnefaie, K. A., Almitani, K. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Design+and+performance+characteristics+of+solar+adsorption+refrigeration+system+using+parabolic+trough+collector:+experimental+and+statistical+optimization+technique.">Design and performance characteristics of solar adsorption refrigeration system using parabolic trough collector: experimental and statistical optimization technique.</a> Energ Convers Manage. 74, 162-170 (2013).</li><li>El Fadar, A., Mimet, A., P&#233;rez-Garc&#237;a, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Study+of+an+adsorption+refrigeration+system+powered+by+parabolic+trough+collector+and+coupled+with+a+heat+pipe.">Study of an adsorption refrigeration system powered by parabolic trough collector and coupled with a heat pipe.</a> Renew Energy. 34, 2271-2279 (2009).</li><li>Restuccia, G., Freni, A., Russo, F., Vasta, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+investigation+of+a+solid+adsorption+chiller+based+on+a+heat+exchanger+coated+with+hydrophobic+zeolite.">Experimental investigation of a solid adsorption chiller based on a heat exchanger coated with hydrophobic zeolite.</a> Appl Therm Eng. 25, 1419-1428 (2005).</li><li>Al Mers, A., Azzabakh, A., Mimet, A., El Kalkha, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimal+design+study+of+cylindrical+finned+reactor+for+solar+adsorption+cooling+machine+working+with+activated-ammonia+pair.">Optimal design study of cylindrical finned reactor for solar adsorption cooling machine working with activated-ammonia pair.</a> Appl Therm Eng. 26 (16), 1866-1875 (2006).</li><li>Louajari, M., Mimet, A., Ouammi, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Study+of+the+effect+of+finned+tube+adsorber+on+the+performance+of+solar+driven+adsorption+cooling+machine+using+activated+carbon-ammonia+pair.">Study of the effect of finned tube adsorber on the performance of solar driven adsorption cooling machine using activated carbon-ammonia pair.</a> Appl Energ. 88, 690-698 (2011).</li><li>Mattox, D. M., Kominiak, G. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deposition+of+semiconductor+films+with+high+solar+absorptivity.">Deposition of semiconductor films with high solar absorptivity.</a> J Vac Sci Technol. 12, 182-185 (1975).</li><li>Du, S. W., Li, X. H., Yuan, Z. X., Du, C. X., Wang, W. C., Liu, Z. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Performance+of+solar+adsorption+refrigeration+in+system+of+SAPO-34+and+ZSM-5+zeolite.">Performance of solar adsorption refrigeration in system of SAPO-34 and ZSM-5 zeolite.</a> Sol Energ. 138, 98-104 (2016).</li><li>Ron, M., Gruen, D., Mendelsohn, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+and+properties+of+porous+metal+hydride+compacts.">Preparation and properties of porous metal hydride compacts.</a> J. Less- Common Metals. 74 (2), 445-448 (1980).</li><li>Liu, Z. Q., Wu, F., Tan, Z. H., Chen, S., Wang, G. Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+experimental+study+of+thermal+conductivity+enhancement+on+solid+adsorption+refrigeration.">An experimental study of thermal conductivity enhancement on solid adsorption refrigeration.</a> Mater Rev. 15 (12), 61-63 (2001).</li><li>Gordeeva, L. G., Freni, A., Restuccia, G., Aristov, Y. I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Adsorptive+air+conditioning+systems+driven+by+low+temperature+energy+sources:+choice+of+the+working+pairs.">Adsorptive air conditioning systems driven by low temperature energy sources: choice of the working pairs.</a> J Chem Eng Jpn. 40 (13), 1287-1291 (2007).</li><li>Kakiuchi, H., Shimooka, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Water+vapor+adsorbent+FAM-Z02+and+its+applicability+to+adsorption+heat+pump.">Water vapor adsorbent FAM-Z02 and its applicability to adsorption heat pump.</a> Kagaku Kogaku Ronbun, Jpn. 31 (4), 273-277 (2005).</li><li>Li, X. H., Hou, X. H., Zhang, X., Yuan, Z. X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+review+on+development+of+adsorption+cooling-Novel+beds+and+advanced+cycles.">A review on development of adsorption cooling-Novel beds and advanced cycles.</a> Energ Convers Manage. 94, 221-232 (2015).</li></ol>

作者没有什么可透露的。

作为一种热力系统, 太阳能吸附式制冷装置的性能取决于系统的优化设计和合理运行。床的热供应和冷却方式都是保证系统工作正常运行的重要因素。水冷是由于水的对流换热强度高, 所以更倾向于空气冷却。吸附剂材料的导电性差通常决定了床的传热速率有限。为了改善床的传热, 许多测量都被认为是内部插入的翅片的增强结构。19硅胶是另一种受欢迎的吸附剂材料。如果在太?...

随着传统蒸气压缩制冷技术的日益严重, 取代传统的制冷和绿色科技已成为近年来的热门话题。在这些绿色技术中, 太阳能吸附制冷已经引起了研究者的广泛关注。在低品位热能驱动下, 吸附式制冷系统具有环保、小巧、灵活等优点。这种吸附系统也可以用灯的能量来驱动, 例如由热设备排出的废热或来自车辆的发动机废气, 如胡et al所述。1
在吸附冷却系统中, 吸附床是关键部件。它的工作直接影响整个系统的性能。因此, 吸附床的设计是 Sutuki 所指出的最重要的问题。2 10 年前, 该平床主要用于吸附式冷却系统。3,4,5没有任何聚光装置, 平坦的床层温度通常较低, 因此系统的 COP 不理想。相比之下, 管状吸附床改善了 COP。据报, 该缔约方会议可由阿马尔et al.在撒哈拉以南地区达到0.216此外, 王et al.7开发了一种由连续热再生特性所区别的螺旋板吸附。新型吸附床的设计缩短了系统的循环时间。阿布-Hamdeh et al.8报告了其对带抛物线槽集热器的太阳能吸附式制冷系统的研究。他们的测试结果显示, 该系统的 COP 从0.18 到0.20 不等。El Fadar et al.9研究了一个与热管耦合的吸附式制冷系统, 并利用抛物线槽集热器对其进行了分析, 结果显示了最佳 COP 0.18。
为提高管状床的传热性, 考虑了翅片管吸附, 并对其强化效果进行了研究。Restuccia et al.提出了一种采用壳管式换热器形式的创新型床。10. 内翅片管涂有沸石层, 使金属表面与吸附剂材料之间的热/质量接触传递阻力降低。在15-20 秒的循环时间内, 系统产生了30-60 瓦特/千克的特定冷却功率的输出. et al.11表明, 增强的吸附与5-6 鳍可以显著减少吸附的热损失的气氛, 从而改善 COP 45%。Louajari et al.研究了翅片管吸附对太阳驱动系统性能的影响。12. 以活性炭-氨水为工作副, 证明了翅片吸附的循环传质比无翅片大。
在本研究中, 我们研究了一种改进的太阳能吸附式制冷系统, 采用了太阳能跟踪抛物槽收集器, 并部署了内部冷却隧道。该系统以 SAPO-34/ZSM-5 沸石和水蒸气为工作副, 在热力学和制冷方面表现出了有趣的特点。实验方法以及典型的测试结果将在本报告中介绍和讨论。

<table><tbody><tr><td>evaporator</td><td>home-made</td><td></td><td>finned heat exchange</td></tr><tr><td>condenser</td><td>home-made</td><td></td><td>finned heat exchange</td></tr><tr><td>evaporator water tank</td><td>home-made</td><td></td><td>volume:9L</td></tr><tr><td>condenser water tank</td><td>home-made</td><td></td><td>volume:9L</td></tr><tr><td>vacuum pump</td><td>Beijing Jing Rui Ze Xiang Instrument Co. Ltd.</td><td></td><td>rotation speed:1400 motor pover:370W</td></tr><tr><td>condenser pressure sensor</td><td>Beijing Li Nuo Tian Sheng Instrument Co. Ltd.</td><td>16P2623</td><td>maximum:2200Pa</td></tr><tr><td>bed pressure sensor</td><td>Beijing Li Nuo Tian Sheng Instrument Co. Ltd.</td><td></td><td>maximum:2200Pa</td></tr><tr><td>adsorption bed</td><td>home-made</td><td></td><td>cylundrical glass tube</td></tr><tr><td>parabolic trough</td><td>home-made</td><td></td><td>high reflective aluminum sheet</td></tr><tr><td>water pump</td><td>home-made</td><td></td><td>motor pover:250W, water head:8m</td></tr><tr><td>water tank</td><td>home-made</td><td></td><td>volume:500L</td></tr><tr><td>DRT-2-2 direct solar actinometer</td><td>Beijing Tian Yu De Technology Co. Ltd.</td><td>03140132</td><td>sensitivity:13.257&amp;mu;V/W&amp;bull;m&lt;sup&gt;2&lt;/sup&gt;</td></tr><tr><td>TBQ-2 solar pyranometer</td><td>Jinzhou Sunshine Technology Development Co., Ltd., China</td><td>209079</td><td>sensitivity:12.733&amp;mu;V/W&amp;bull;m&lt;sup&gt;2&lt;/sup&gt;</td></tr><tr><td>SAPO-34 zeolite</td><td>Langfang Peng Cai Co., Ltd., China</td><td></td><td>20mm in length and 2.2mm in diameter</td></tr><tr><td>ZSM-5 zeolite</td><td>Langfang Peng Cai Co., Ltd., China</td><td></td><td>5.7mm in diameter</td></tr></tbody></table>

experimental system of solar adsorption refrigeration with concentrated collector

为提高太阳能吸附式制冷的性能, 建立了太阳能浓缩集热器实验系统, 并进行了研究。系统的主要组成部分是吸附床、冷凝器、蒸发器、冷却子系统和太阳能集热器。在实验的第一步, 在封闭条件下, 太阳辐射加热了蒸汽饱和床, 导致床温升高, 压力增大。当床的压力变得足够高, 床被交换连接到冷凝器, 因此水蒸汽从床持续流动到冷凝器被液化。接下来, 床需要降温后解吸。在太阳保护条件下, 通过铝箔实现了循环水循环。随着床内水的不断循环, 床内的储热被取出, 床层压力相应降低。当床压在蒸发温度下下降到饱和压力下时, 就打开了蒸发器的阀门。大量水蒸气冲进床中, 被沸石物质吸附。随着蒸发器中水的大量汽化, 最终产生了制冷效应。实验结果表明, 无论吸附时间是否长, SAPO-34 沸石的 COP (系统性能系数) 和系统的 SCP (具体冷却功率) 均大于 ZSM-5 沸石;或更短。该系统的 SAPO-34 沸石产生了最大的 COP 0.169。

吸附过程中床层传质特性的研究 吸附床在吸附制冷系统中始终是最重要的组成部分, 其传热传质特性是影响整个系统性能的主要因素。通过分析图 3(底部面板) 中所示剖面的记录温度变化, 可以了解床的传热和传质特性。图 4显示了吸附过程中床层温度的动态变化。该图表明, SAPO-34 沸石的传质性能良好, 对不同截?...
