El autor desea agradecer a Li Zhang, Xian-Zhi Li, Aaron Hinz y Clayton Hall por la ayuda editorial con este manuscrito. Este ensayo se desarrolló inicialmente en el laboratorio de George O'Toole, de la Escuela de Medicina Geisel en Dartmouth. La investigación en el laboratorio del Dr. Mah está respaldada por subvenciones del Consejo de Investigación de Ciencias Naturales e Ingeniería de Canadá y Cystic Fibrosis Canada.

1. MBC-B
<ol><li>
Cultivo de un biofilm (adaptado de O'Toole9).
	<ol>
<li>Cultivar un cultivo de tipo salvaje cepa de interés y cepa mutante durante 16 horas en un medio rico a 37 °C.</li>
		<li>Diluir los cultivos saturados durante la noche 1:100 en un medio fresco para ensayos de resistencia a los antibióticos. Un medio estándar para P. aeruginosa es el medio mínimo M63 suplementado con sulfato de magnesio y arginina (ver Tabla 1). Este medio estimula la formación de un biofilm más robusto.</li>
		<li>Añadir 100 μl de dilución por pozo en una antena parabólica de microtiter de 96 pozos (ver Tabla 1). Dado que estos ensayos se realizan normalmente por triplicado para cada cepa, debe haber 24 pozos de cada cepa.</li>
		<li>Incubar la placa de microter durante 24 horas a 37 °C.</li>
	</ol>
</li>
	<li>
Exponer la biopelícula preformada a un gradiente de concentración de antibióticos
	<ol>
<li>Prepare una serie de dilución de 10x de antibióticos para 7 pozos. Ejemplo: para el antibiótico tobramicina, las concentraciones finales en los pozos son 0,4, 0,2, 0,1, 0,05, 0,025, 0,0125 y 0,006 mg/ml 5-8. A partir de un stock de 25 mg/ml, prepare 10x diluciones de 4, 2, 1, 0,5, 0,25, 0,125 y 0,06 mg/ml. Dejar en el hielo.</li>
		<li>Retire el sobrenadante gastado (que contiene células planctónicas) utilizando una pipeta multicanal (véase la Tabla 1).</li>
		<li>Agregue 90 μl M63 (Mg/Arg) a todos los pozos.</li>
		<li>Añadir 10 μl de cada 10x concentración de antibióticos para lograr las concentraciones finales deseadas. Añadir 10 μl de agua (sin control antibiótico) al pozo final para cada réplica y cepa.</li>
		<li>Incubar la placa de microter durante 24 horas a 37 °C.</li>
	</ol>
</li>
	<li>
Refrescar los medios y permitir el desprendimiento de células vivas.
	<ol>
<li>Retire el sobrenadante gastado (que contiene células planctónicas) utilizando una pipeta multicanal.</li>
		<li>Agregue 115 μl M63 (Mg/Arg) a todos los pozos.</li>
		<li>Incubar la placa de microter durante 24 horas a 37 °C.</li>
	</ol>
</li>
	<li>
Ensayo para células vivas.
	<ol>
<li>Etiquete dos placas de agar LB por placa de microtíter de 96 pozos.</li>
		<li>Esterilice el dispositivo multipróngo (ver Tabla 1)sumergiendo las puntas en etanol al 100% y pasando las puntas a través de la llama abierta de un quemador Bunsen. repetir. Deja que las puntas se enfríen ligeramente. Usando el dispositivo multiprong, transfiera ~3 μl (cantidad que normalmente se retiene en las puntas de las puntas) de cultivo planctónico desde cada pozo de la placa de microter a la superficie de una placa de agar LB.</li>
		<li>Incubar las placas de agar LB durante 16 horas a 37 °C.</li>
		<li>Determinar la concentración bactericida mínima del antibiótico identificando, a ojo, el corte para el crecimiento bacteriano (Figura 1).</li>
	</ol>
</li>
</ol>2. MBC-P
<ol><li>
Preparación de cepas bacterianas
	<ol>
<li>Cultivar un cultivo de tipo salvaje cepa de interés y cepa mutante durante 16 horas en un medio rico a 37 °C.</li>
		<li>Diluir los cultivos saturados durante la noche 1:100 en un medio fresco para ensayos de resistencia a los antibióticos. Un medio estándar para P. aeruginosa es el medio mínimo M63 suplementado con sulfato de magnesio y arginina (ver Tabla 1).</li>
		<li>Añadir 90 μl de dilución por pozo en una antena parabólica de 96 kódteres (ver Tabla 1). Dado que estos ensayos se realizan normalmente por triplicado para cada cepa, debe haber 24 pozos de cada cepa.</li>
	</ol>
</li>
	<li>
Exposición de las células planctónicas a un gradiente de concentración de antibióticos
	<ol>
<li>Preparar 10x series de dilución de antibióticos para 7 pozos. Ejemplo: para el antibiótico tobramicina, las concentraciones finales en los pozos son 0,032, 0,016, 0,008, 0,004, 0,002, 0,001 y 0,0005 mg/ml. A partir de un stock de 25 mg/ml, preparar diluciones de 0,32, 0,16, 0,08, 0,04, 0,02, 0,01 y 0,005 mg/ml. Dejar en el hielo.</li>
		<li>Añadir 10 μl de cada 10x concentración de antibióticos para lograr las concentraciones finales deseadas. Añadir 10 μl de agua (sin control antibiótico) al pozo final para cada réplica y cepa.</li>
		<li>Incubar la placa de microter durante 24 horas a 37 °C.</li>
	</ol>
</li>
	<li>
Ensayo para células vivas.
	<ol>
<li>Etiquete dos placas de agar LB por placa de microtíter de 96 pozos.</li>
		<li>Esterilice el dispositivo multipróngo (ver Tabla 1)sumergiendo las puntas en etanol al 100% y pasando las puntas a través de la llama abierta de un quemador Bunsen. repetir. Deja que las puntas se enfríen ligeramente. Usando el dispositivo multiprong, transfiera ~3 μl (cantidad que normalmente se retiene en las puntas de las puntas) de cultivo planctónico desde cada pozo de la placa de microter a la superficie de una placa de agar LB.</li>
		<li>Incubar las placas de agar LB durante 16 horas a 37 °C.</li>
		<li>Determinar la concentración bactericida mínima del antibiótico mediante la identificación, a simple vista, del corte para el crecimiento bacteriano (Figura 2).</li>
	</ol>
</li>
</ol>

<ol>
	<li>Hoiby, N., Bjarnsholt, T., Givskov, M., Molin, S., Ciofu, O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Antibiotic+resistance+of+bacterial+biofilms.">Antibiotic resistance of bacterial biofilms.</a> Int. J. Antimicrob. Agents. 35 (4), 322-332 (2010).</li><li>Mah, T. F., O'Toole, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+of+biofilm+resistance+to+antimicrobial+agents.">Mechanisms of biofilm resistance to antimicrobial agents.</a> Trends Microbiol. 9 (1), 34-39 (2001).</li><li>Mah, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biofilm-specific+antibiotic+resistance.">Biofilm-specific antibiotic resistance.</a> Future Microbiol. 7 (9), 1061-1072 (2012).</li><li>Mah, T. F., Pitts, B., Pellock, B., Walker, G. C., Stewart, P. S., O'Toole, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+genetic+basis+for+Pseudomonas+aeruginosa+biofilm+antibiotic+resistance.">A genetic basis for Pseudomonas aeruginosa biofilm antibiotic resistance.</a> Nature. 426 (6964), 306-310 (2003).</li><li>Zhang, L., Mah, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Involvement+of+a+Novel+Efflux+System+in+Biofilm-Specific+Resistance+to+Antibiotics.">The Involvement of a Novel Efflux System in Biofilm-Specific Resistance to Antibiotics.</a> J. Bacteriol. 190 (13), 4447-4452 (2008).</li><li>Zhang, L., Hinz, A. J., Nadeau, J. P., Mah, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pseudomonas+aeruginosa+tssC1+Links+Type+VI+Secretion+and+Biofilm-specific+Antibiotic+Resistance.">Pseudomonas aeruginosa tssC1 Links Type VI Secretion and Biofilm-specific Antibiotic Resistance.</a> J. Bacteriol. 193 (19), 5510-5513 (2011).</li><li>Beaudoin, T., Zhang, L., Hinz, A. J., Parr, C. J., Mah, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Biofilm-Specific+Antibiotic+Resistance+Gene,+ndvB,+is+Important+for+Expression+of+Ethanol+Oxidation+Genes+in+Pseudomonas+aeruginosa+Biofilms.">The Biofilm-Specific Antibiotic Resistance Gene, ndvB, is Important for Expression of Ethanol Oxidation Genes in Pseudomonas aeruginosa Biofilms.</a> J. Bacteriol. 194 (12), 3128-3136 (2012).</li><li>O'Toole, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microtiter+Dish+Biofilm+Formation+Assay.">Microtiter Dish Biofilm Formation Assay.</a> J. Vis. Exp. (47), e2437 (2011).</li><li>Lewis, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multidrug+tolerance+of+biofilms+and+persister+cells.">Multidrug tolerance of biofilms and persister cells.</a> Curr. Top. Microbiol. Immunol. 322, 107-131 (2008).</li><li>Merritt, J. H., Kadouri, D. E., O'Toole, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Growing+and+Analyzing+Static+Biofilms.">Growing and Analyzing Static Biofilms.</a> Curr. Protoc. Microbiol. 1, 1B.1.1-1B.1.17 (2005).</li><li>Ramey, B. E., Parsek, M. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chapter+1.+Growing+and+analyzing+biofilms+in+fermenters.">Chapter 1. Growing and analyzing biofilms in fermenters.</a> Curr. Protoc. Microbiol. 1, 1B.3.1-1B.3.14 (2005).</li></ol>

La autora declara que no tiene intereses financieros contrapuestos.

La resistencia a los antibióticos en las células planctónicas se define como un aumento en la concentración inhibitoria mínima (MIC) de un antibiótico debido a un cambio permanente en las células(por ejemplo, una mutación). Los mecanismos de resistencia o tolerancia específicos de la biopelícula que se han identificado hasta la fecha son el resultado de la expresión de genes de tipo salvaje dentro de las biopelículas. Por lo tanto, la definición clásica de resistencia no se aplica a las biopelícul...

Los ensayos de resistencia a los antibióticos se desarrollaron inicialmente para probar la resistencia de los cultivos planctónicos (de natación libre) de bacterias. Dado que muchas infecciones bacterianas involucran biopelículas (células adheridas a la superficie), estábamos interesados en desarrollar un método para ensayar la resistencia a los antibióticos específicos de la biopelícula. Sin embargo, la mayoría de los ensayos de resistencia a los antibióticos son poco adecuados para medir la resistencia de las biopelículas. Por ejemplo, la determinación de la concentración inhibitoria mínima (MIC) es el patrón oro para determinar la resistencia a los antibióticos de los cultivos bacterianos planctónicos 1. Este ensayo implica mezclar un cultivo planctónico diluido con una serie de dilución de antibióticos.  La concentración de antibiótico que inhibe el crecimiento visible de las células planctónicas es el MIC. Dado que este ensayo se basa en la inhibición del crecimiento, por definición, no puede funcionar con cultivos de biopelículas, lo que requiere examinar la sensibilidad a los antibióticos de las células en una biopelícula precrecida. En lugar de medir la inhibición del crecimiento, el ensayo MBC-B descrito aquí determina la concentración de antibiótico que mata las células que ya existen en una biopelícula. Por lo tanto, este ensayo tiene como objetivo imitar los tratamientos antibióticos de las infecciones por biopelículas establecidas, y proporcionar una visión más relevante de la resistencia bacteriana a los antibióticos in vivo.
Dado que las biopelículas son generalmente más resistentes a los antibióticos que los cultivos planctónicos 2-4, fue necesario idear un método que relacione directamente la resistencia a los antibióticos de una biopelícula con la de un cultivo planctónico. Por lo tanto, otro objetivo de este método es poder comparar directamente el nivel de resistencia a los antibióticos entre las células planctónicas y de biopelículas. Los ensayos MBC-P y MBC-B descritos aquí hacen esto posible porque las células se cultivan en condiciones similares. Hemos utilizado este método para estudiar varios genes que son importantes para la resistencia a antibióticos específicos de biopelículas 5-8.

<table border="1" cellpadding="0" cellspacing="0">
	<tbody>
		<tr>
			<td style="width:160px;">
			1x&#160;M63
			</td>
			<td style="width:160px;">

			</td>
			<td style="width:160px;">

			</td>
			<td style="width:160px;">
			Prepare as a 5x&#160;M63 stock by dissolving 15g KH2PO4, 35g K2HPO4 and 10g (NH4)2SO4 in 1 L of water. This stock does not need to be autoclaved and can be stored at room temperature.&#160; Dilute 5x&#160;stock 1:5, autoclave, cool, then add the desired components.
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			KH2PO4
			</td>
			<td style="width:160px;">
			Fisher
			</td>
			<td style="width:160px;">
			P285-500
			</td>
			<td style="width:160px;">

			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			K2HPO4
			</td>
			<td style="width:160px;">
			Fisher
			</td>
			<td style="width:160px;">
			P288-500
			</td>
			<td style="width:160px;">

			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			(NH4)2SO4
			</td>
			<td style="width:160px;">
			Sigma
			</td>
			<td style="width:160px;">
			A5132
			</td>
			<td style="width:160px;">

			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			Magnesium sulfate
			</td>
			<td style="width:160px;">
			Fisher
			</td>
			<td style="width:160px;">
			M63-500
			</td>
			<td style="width:160px;">
			Add to 1 mM final concentration.&#160; Prepare as a 1 M stock in water and autoclave.
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			Tobramycin
			</td>
			<td style="width:160px;">
			Sigma
			</td>
			<td style="width:160px;">

			</td>
			<td style="width:160px;">
			Prepare 50 mg/m&#160;stock. Aliquot and store at -20&#176;C.
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			Arginine
			</td>
			<td style="width:160px;">
			Sigma
			</td>
			<td style="width:160px;">
			A5131
			</td>
			<td style="width:160px;">
			Add to 0.4% final concentration.&#160; Prepare as a 20% stock in water and filter sterilize.&#160; This alternative carbon/energy source can replace glucose and casamino acids
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			96-well microtiter plates
			</td>
			<td style="width:160px;">
			Corning
			</td>
			<td style="width:160px;">
			3595
			</td>
			<td style="width:160px;">
			Sterile, flat-bottom, low evaporation
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			Tranferpette (multichannel pipette)
			</td>
			<td style="width:160px;">
			BrandTech
			</td>
			<td style="width:160px;">
			2703610
			</td>
			<td style="width:160px;">
			8-channel, 20-200 &#956;l
			</td>
		</tr>
		<tr>
			<td style="width:160px;">
			Multiprong device
			</td>
			<td style="width:160px;">
			Dan-Kar
			</td>
			<td style="width:160px;">
			MC48
			</td>
			<td style="width:160px;">
			48 prongs fit into &#189; of a 96-well microtiter plate
			</td>
		</tr>
	</tbody>
</table>

establishing the minimal bactericidal concentration of an antimicrobial agent for planktonic cells (mbc-p) and biofilm cells (mbc-b)

Este protocolo permite una comparación directa entre la resistencia planctónica y la de biopelícula para una cepa bacteriana que puede formar una biopelícula in vitro. Las bacterias se inoculan en los pozos de una placa de microtíter de 96 pozos. En el caso del ensayo planctónico, se añaden diluciones en serie del agente antimicrobiano de elección a las suspensiones bacterianas. En el ensayo de biopelícula, una vez inoculadas, las bacterias se dejan formar una biopelícula durante un período de tiempo determinado. Las células no unidas se eliminan de los pocillos, se reponen los medios y se añaden diluciones en serie del agente antimicrobiano de elección. Después de la exposición al agente antimicrobiano, las células planctónicas se ensayan para el crecimiento. Para el ensayo de biopelícula, el medio se actualiza con medios frescos que carecen del agente antimicrobiano y las células de la biopelícula se dejan recuperar. La viabilidad de las células de biopelículas se ensaya después del período de recuperación. El MBC-P para el agente antimicrobiano se define como la concentración más baja de droga que mata las células en el cultivo planctónico.  En contraste, el MBC-B para una cepa se determina exponiendo biopelículas preformadas a concentraciones crecientes de agente antimicrobiano durante 24 horas. El MBC-B se define como la concentración más baja de agente antimicrobiano que mata las células en el biofilm.

Se realizaron ensayos MBC-P y MBC-B, comparando la sensibilidad del tipo salvaje PA14 con PA14 ∆ndvB. La tobramicina se utilizó como antibiótico. Se presentan los resultados correspondientes a los pasos 1.4.4 (Figura 1) y 2.3.4 (Figura 2). PA14 y ∆ndvB fueron inoculados en los ensayos MBC-P y MBC-B por triplicado. Después de completar los pasos 1.0-1.4 del protocolo MBC-B y los pasos 2.0-2.3 del protocolo MBC-P, las células viables fueron plateadas sobre una pla...

Watch this Scientific Journal Video about Establishing the Minimal Bactericidal Concentration of an Antimicrobial Agent for Planktonic Cells MBC-P and Biofilm Cells MBC-B at JoVE.com

Establishing the Minimal Bactericidal Concentration of an Antimicrobial Agent for Planktonic Cells MBC-P and Biofilm Cells MBC-B

Este protocolo permite una comparación directa entre la resistencia planctónica y la de biopelícula para una cepa bacteriana que puede formar una biopelícula in vitro utilizando una placa de microtíter de 96 pozos. Las bacterias planctónicas o de biopelículas están expuestas a diluciones en serie del agente antimicrobiano de elección. La viabilidad se ensa prueba por el crecimiento en placas de agar.

Establecimiento de la concentración bactericida mínima de un agente antimicrobiano para las células planctónicas (MBC-P) y las células de biopelícula (MBC-B)

This protocol allows for a direct comparison between planktonic and biofilm resistance for a bacterial strain that can form a biofilm in vitro. Bacteria ...
