The authors would like to thank Mauna Kea Technologies for technical support. The authors also thank Shelly Hsiao for technical assistance and Kathleen E. Mach for critical review. This work was supported in part by NIH R01CA160986 to J.C.L.

1. Patient Preparation
<ol>
	<li>Consent patient scheduled for diagnostic cystoscopy and other endourological procedures such as transurethral resection of bladder tumor (TURBT) for CLE. Include in the consent a description of the use of intravesical and/or intravenous fluorescein as the contrast agent. Inquire history of hypersensitivity reaction to fluorescein.</li>
	<li>Patient is positioned for cystoscopy (typically in lithotomy position) and prepared in a sterile fashion.</li>
	<li>Proceed with standard white ...

<ol>
	<li>Thiberville, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+in+vivo+fluorescence+microimaging+of+the+alveolar+ducts+and+sacs+during+bronchoscopy.">Human in vivo fluorescence microimaging of the alveolar ducts and sacs during bronchoscopy.</a> Eur. Respir. J. 33, 974-985 (2009).</li><li>Dunbar, K. B., Okolo, P., Montgomery, E., Canto, M. I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Confocal+laser+endomicroscopy+in+Barrett's+esophagus+and+endoscopically+inapparent+Barrett's+neoplasia:+a+prospective,+randomized,+double-blind,+controlled,+crossover+trial.">Confocal laser endomicroscopy in Barrett's esophagus and endoscopically inapparent Barrett's neoplasia: a prospective, randomized, double-blind, controlled, crossover trial.</a> Gastrointest. Endosc. 70, 645-654 (2009).</li><li>Buchner, A. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparison+of+probe-based+confocal+laser+endomicroscopy+with+virtual+chromoendoscopy+for+classification+of+colon+polyps.">Comparison of probe-based confocal laser endomicroscopy with virtual chromoendoscopy for classification of colon polyps.</a> Gastroenterology. 138, 834-842 (2010).</li><li>Pech, O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Confocal+laser+endomicroscopy+for+in+vivo+diagnosis+of+early+squamous+cell+carcinoma+in+the+esophagus.">Confocal laser endomicroscopy for in vivo diagnosis of early squamous cell carcinoma in the esophagus.</a> Clin. Gastroenterol. Hepatol. 6, 89-94 (2008).</li><li>Goetz, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+confocal+laser+endo+microscopy+of+the+human+liver:+a+novel+method+for+assessing+liver+microarchitecture+in+real+time.">In vivo confocal laser endo microscopy of the human liver: a novel method for assessing liver microarchitecture in real time.</a> Endoscopy. 40, 554-562 (2008).</li><li>Meining, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+cholangiocarcinoma+in+vivo+using+miniprobe-based+confocal+fluorescence+microscopy.">Detection of cholangiocarcinoma in vivo using miniprobe-based confocal fluorescence microscopy.</a> Clin. Gastroenterol. Hepatol. 6, 1057-1060 (2008).</li><li>Wu, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+real-time+microscopy+of+the+urinary+tract+using+confocal+laser+endomicroscopy.">Dynamic real-time microscopy of the urinary tract using confocal laser endomicroscopy.</a> Urology. 78, 225-231 (2011).</li><li>Sonn, G. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+biopsy+of+human+bladder+neoplasia+with+in+vivo+confocal+laser+endomicroscopy.">Optical biopsy of human bladder neoplasia with in vivo confocal laser endomicroscopy.</a> J. Urol. 182, 1299-1305 (2009).</li><li>Sonn, G. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fibered+confocal+microscopy+of+bladder+tumors:+an+ex+vivo+study.">Fibered confocal microscopy of bladder tumors: an ex vivo study.</a> J. Endourol. 23, 197-201 (2009).</li><li>Adams, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparison+of+2.6-+and+1.4-mm+imaging+probes+for+confocal+laser+endomicroscopy+of+the+urinary+tract.">Comparison of 2.6- and 1.4-mm imaging probes for confocal laser endomicroscopy of the urinary tract.</a> J. Endourol. 25, 917-921 (2011).</li><li>Wiesner, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Confocal+laser+endomicroscopy+for+the+diagnosis+of+urothelial+bladder+neoplasia:+a+technology+of+the+future?.">Confocal laser endomicroscopy for the diagnosis of urothelial bladder neoplasia: a technology of the future?.</a> BJU Int. 107, 399-403 (2011).</li><li>Wallace, M. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+safety+of+intravenous+fluorescein+for+confocal+laser+endomicroscopy+in+the+gastrointestinal+tract.">The safety of intravenous fluorescein for confocal laser endomicroscopy in the gastrointestinal tract.</a> Aliment. Pharmacol. Ther. 31, 548-552 (2010).</li><li>Konda, V. J. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=First+assessment+of+needle-based+confocal+laser+endomicroscopy+during+EUS-FNA+procedures+of+the+pancreas+(with+videos.">First assessment of needle-based confocal laser endomicroscopy during EUS-FNA procedures of the pancreas (with videos.</a> Gastrointest. Endosc. 74, 1049-1060 (2011).</li><li>Liu, J. -. J., Droller, M., Liao, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=New+Optical+Imaging+Technologies+in+Bladder+Cancer:+Considerations+and+Perspectives.">New Optical Imaging Technologies in Bladder Cancer: Considerations and Perspectives.</a> J. Urol. 188, 361-368 (2012).</li><li>Hsiung, P. -. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+colonic+dysplasia+in+vivo+using+a+targeted+heptapeptide+and+confocal+microendoscopy.">Detection of colonic dysplasia in vivo using a targeted heptapeptide and confocal microendoscopy.</a> Nat. Med. 14, 454-458 (2008).</li></ol>

No conflicts of interest declared.

Attaining and maintaining solid en face contact between the imaging probe and the bladder mucosa is the most critical step in acquiring optimal image quality. There is approximately a 3-5 patient learning curve to develop the dexterity to manipulate the imaging probe and to hold the probe steady during image acquisition. Additionally, as this procedure is conducted in vivo, patient movements (i.e. respiratory) and vascular pulsations may affect the imaging probe contact with the bladder....

<table border="1">
 <tbody>
 <tr>
 <td>Name of the reagent</td>
 <td>Company</td>
 <td>Catalogue number</td>
 <td>Comments (optional)</td>
 </tr>
 <tr>
 <td>Cellvizio 100 Series</td>
 <td>Mauna Kea Technologies</td>
 <td>100 Series</td>
 <td>Includes confocal processor and LSU: F400-v2 at 488 nm</td>
 </tr>
 <tr>
 <td>Cellvizio Confocal Miniprobe</td>
 <td>Mauna Kea Technologies</td>
 <td>Gastroflex UHD </td>
 <td></td>
 </tr>
 <tr>
 <td>AK-FLUOR 10%</td>
 <td>Akorn, Inc.</td>
 <td>NDC 17478-253-10 </td>
 <td></td>
 </tr>
 </tbody>
</table>

probe-based confocal laser endomicroscopy of the urinary tract: the technique

Probe-based confocal laser endomicroscopy (CLE) is an emerging optical imaging technology that enables real-time in vivo microscopy of mucosal surfaces during standard endoscopy. With applications currently in the respiratory1 and gastrointestinal tracts,2-6 CLE has also been explored in the urinary tract for bladder cancer diagnosis.7-10 Cellular morphology and tissue microarchitecture can be resolved with micron scale resolution in real time, in addition to dynamic imaging of the normal and pathological vasculature.7
The probe-based CLE system (Cellvizio, Mauna Kea Technologies, France) consists of a reusable fiberoptic imaging probe coupled to a 488 nm laser scanning unit. The imaging probe is inserted in the working channels of standard flexible and rigid endoscopes. An endoscope-based CLE system (Optiscan, Australia), in which the confocal endomicroscopy functionality is integrated onto the endoscope, is also used in the gastrointestinal tract. Given the larger scope diameter, however, application in the urinary tract is currently limited to ex vivo use.11 Confocal image acquisition is done through direct contact of the imaging probe with the target tissue and recorded as video sequences. As in the gastrointestinal tract, endomicroscopy of the urinary tract requires an exogenenous contrast agent&mdash;most commonly fluorescein, which can be administered intravenously or intravesically. Intravesical administration is a well-established method to introduce pharmacological agents locally with minimal systemic toxicity that is unique to the urinary tract. Fluorescein rapidly stains the extracellular matrix and has an established safety profile.12 Imaging probes of various diameters enable compatibility with different caliber endoscopes. To date, 1.4 and 2.6 mm probes have been evaluated with flexible and rigid cystoscopy.10 Recent availability of a &lt; 1 mm imaging probe13 opens up the possibility of CLE in the upper urinary tract during ureteroscopy. Fluorescence cystoscopy (i.e. photodynamic diagnosis) and narrow band imaging are additional endoscope-based optical imaging modalities14 that can be combined with CLE to achieve multimodal imaging of the urinary tract. In the future, CLE may be coupled with molecular contrast agents such as fluorescently labeled peptides15 and antibodies for endoscopic imaging of disease processes with molecular specificity.

CLE images are saved as grayscale video sequence files at 12 frames per second. Image interpretation is done in real time and may be used to impact clinical decision making under an investigational protocol. Offline analysis, which includes reviewing of the video sequence, additional image processing such as mosaicing,7 and comparison with standard pathology, are important during the learning curve phase associated with the technology. Figures 1B and 1C are representative CLE images obtained from two different...

Watch this Scientific Journal Video about Probe-based Confocal Laser Endomicroscopy of the Urinary Tract: The Technique at JoVE.com

Probe-based Confocal Laser Endomicroscopy of the Urinary Tract: The Technique

Probe-based confocal laser endomicroscopy enables real-time microscopy of the human urinary tract during cystoscopy, providing dynamic, intravital imaging of pathological states such as bladder cancer with cellular resolution. Endomicroscopy may augment the diagnostic accuracy of standard white light endoscopy and provide intraoperative image guidance to improve surgical resection.

Probe-based  confocal laser endomicroscopy (CLE) is an emerging optical imaging technology  that enables real-time in vivo microscopy of mucosal surfaces ...
