We would like to thank all members of the Kong Lab and Dr. Yan Deng at Microscopy Core, Office of Collaborative Science, NYUMC for their assistance and technical support. This work was supported by a pilot grant from the New York University Center for AIDS Research (CFAR, NIH grant AI027742).

1. Plasmid DNA Purification
<ol>
 <li>Transform the eukaryotic plasmid DNA encoding EGFP (pCX-EGFP) into DH5&alpha; E.coli competent cells. The empty pCX vector may also be used as a negative control. </li>
 <li>Culture and harvest the DH5&alpha; E.coli cells and purify the pDNA according to the Qiagen EndoFree Plasmid Purification Handbook. </li>
 <li>Filter pDNA solution through a 0.22 &mu;m PVDF sterile filter, and store it at -20 &deg;C until use. </li>
</ol>
2. Tattoo System Preparation
<ol>
 <li>Connect the handheld unit and the control pedal to the power supply unit per the manufacturer's instructions. </li>
 <li>Set the needle oscillation frequency to approximately 100 Hz. For the tattooing device we chose (Stealth Rotary Tattoo System), the dial on the power supply should be set to 4 volts. Refer to user manuals or technical support for other tattooing systems. </li>
 <li>Sterilize the needle array before use. We recommend using one needle array per animal. The needles can be reused after being cleaned with soapy water and autoclaved.</li>
 <li>Install the needle array into the handheld unit and loosely attach the plastic grip. </li>
 <li>Adjust the needle depth to an appropriate setting by moving the plastic grip up or down. We used a needle depth of approximately 0.5 mm for our mouse experiment. </li>
 <li>Tighten the plastic grip when the needle depth is properly set, and the tattoo system is ready for use. </li>
</ol>
3. Animal Shaving
<ol>
 <li>Choose the site for the tattooing treatment. The site should be a relatively firm, flat, and fleshy area of the skin, for example, the side of the animal's hindleg. </li>
 <li>Anesthetize a balb/c mouse with a mixture of ketamine (90 mg/kg) and xylazine (5 mg/kg) according to the animal's body weight. For other animals, refer to the anesthesia guidelines of your institution. </li>
 <li>Check the animal's reflexes by pinching its foot to confirm the animal is properly anesthetized.</li>
 <li>Use the electrical trimmer to trim down the hair at the animal's hindlegs slowly and carefully. Remove the hair from the planned tattooing site and the surrounding area. </li>
 <li>Remove the residual shorter hair with the disposable safety razor. Be careful not to cut the animal's skin. Note that depilatory cream may be used as an alternative hair-removal method; however, we prefer shaving over depilatory cream. </li>
 <li>Remove stray cut hairs from the skin with compressed air if necessary. </li>
</ol>
4. Delivery of Plasmid DNA by Tattooing
<ol>
 <li>If an immunization protocol has been established previously, the dose and volume of DNA solution to be applied should be calculated accordingly. We recommend using as small a volume as practical to make the tattooing process more manageable. In this EGFP demonstration, we used 7.5 &mu;l of DNA solution at a concentration of 0.25 mg/ml, which was applied onto a tattooing area of approximately 1 cm2. For immunization experiments, higher pDNA concentrations may be required to induce strong immune responses1,2. </li>
 <li>Apply the DNA solution by pipetting directly onto the tattooing site. Alternatively, load the DNA solution into the plastic grip by pipetting, so the liquid is suspended between the needle and the tip of plastic grip. Refer to the video for a demonstration. We have observed no noticeable difference between the two methods. However, loading the solution into the plastic grip may be advantageous on vertical skin surfaces, for example. </li>
 <li>Start the needle oscillation and place the needle array with light pressure on the animal's skin at the tattooing site. Then move the oscillating needle gently and slowly in a linear fashion to deliver plasmid DNA over the entire tattooing area. Maintain a 90-degree angle between the needle and the skin to avoid lacerations to the skin.</li>
 <li>Observe the skin. Abrasion and inflammation are normal. If bleeding happens, stop the tattooing process and decrease the needle depth. </li>
 <li>Continue the needle movement for approximately 1 min, and then stop the tattooing process. </li>
 <li>Use a clean cotton swab to apply a thin layer of topical analgesic on the tattooing site. Topical analgesics such as Silver Sulfadiazine Cream (SSD Cream) or Neosporin ointment can help alleviate the pain or distress of the animals, and therefore it is advised to apply them before the anesthesia wears off. Observe the animals the next day for signs of pain or distress (change of gait, inactivity). Reapply analgesic cream if the signs persist. </li>
</ol>
5. Confirmation of Antigen Expression
<ol>
 <li>48 hr after the tattooing treatment (note that different pDNA constructs may require different expression times), the mouse is euthanized by CO2 narcosis. For other animals, refer to the euthanasia guidelines of your institution. </li>
 <li>Dissect the skin at the tattooing site, and fix the tissue in 4% paraformaldehyde at 4 &deg;C overnight.</li>
 <li>Rinse the tissue with 70% ethanol, and transfer it into 1X PBS for imaging. </li>
 <li>Examine the whole tissue using a confocal microscope to check for EGFP signals. Alternatively, the skin tissue can be embedded in paraffin wax and examined in sections under a fluorescent microscope. </li>
</ol>

<ol>
	<li>Bins, A. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+rapid+and+potent+DNA+vaccination+strategy+defined+by+in+vivo+monitoring+of+antigen+expression.">A rapid and potent DNA vaccination strategy defined by in vivo monitoring of antigen expression.</a> Nat Med. 11, 899-904 (2005).</li><li>Pokorna, D., Rubio, I., Muller, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA-vaccination+via+tattooing+induces+stronger+humoral+and+cellular+immune+responses+than+intramuscular+delivery+supported+by+molecular+adjuvants.">DNA-vaccination via tattooing induces stronger humoral and cellular immune responses than intramuscular delivery supported by molecular adjuvants.</a> Genet. Vaccines Ther. 6, 4 (2008).</li><li>van den Berg, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimization+of+intradermal+vaccination+by+DNA+tattooing+in+human+skin.">Optimization of intradermal vaccination by DNA tattooing in human skin.</a> Hum. Gene Ther. 20, 181-189 (2009).</li><li>Liu, M. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA+vaccines:+a+review.">DNA vaccines: a review.</a> J. Intern. Med. 253, 402-410 (2003).</li><li>Koide, Y., Nagata, T., Yoshida, A., Uchijima, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA+vaccines.">DNA vaccines.</a> Jpn. J. Pharmacol. 83, 167-174 (2000).</li><li>Peachman, K. K., Rao, M., Alving, C. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Immunization+with+DNA+through+the+skin.">Immunization with DNA through the skin.</a> Methods. 31, 232-242 (2003).</li><li>Verstrepen, B. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Improved+HIV-1+specific+T-cell+responses+by+short-interval+DNA+tattooing+as+compared+to+intramuscular+immunization+in+non-human+primates.">Improved HIV-1 specific T-cell responses by short-interval DNA tattooing as compared to intramuscular immunization in non-human primates.</a> Vaccine. 26, 3346-3351 (2008).</li><li>Potthoff, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Immunogenicity+and+efficacy+of+intradermal+tattoo+immunization+with+adenoviral+vector+vaccines.">Immunogenicity and efficacy of intradermal tattoo immunization with adenoviral vector vaccines.</a> Vaccine. 27, 2768-2774 (2009).</li><li>Quaak, S. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DNA+tattoo+vaccination:+effect+on+plasmid+purity+and+transfection+efficiency+of+different+topoisoforms.">DNA tattoo vaccination: effect on plasmid purity and transfection efficiency of different topoisoforms.</a> J. Control Release. 139, 153-159 (2009).</li><li>Pokorna, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Vaccination+with+human+papillomavirus+type+16-derived+peptides+using+a+tattoo+device.">Vaccination with human papillomavirus type 16-derived peptides using a tattoo device.</a> Vaccine. 27, 3519-3529 (2009).</li></ol>

No conflicts of interest declared.

DNA vaccination is considered safer than traditional vaccination strategies as it does not require manipulation of, or expose the vaccines to, live or attenuated pathogens4. However, the result of DNA vaccination depends heavily on the delivery route. Skin is abundant in antigen-presenting cells, such as Langerhans Cells and dendritic cells1, and thus an ideal site for immunization in terms of immunogenicity and ease of access5,6. As a result, intradermal vaccination strategy is one of th...

<table border="1">
<tbody>
 <tr>
 <td>Name of Reagent/Material</td>
 <td>Company</td>
 <td>Catalogue Number</td>
 <td>Comments</td>
 </tr>
 <tr>
 <td>pCX-EGFP plasmid DNA </td>
 <td>Clontech</td>
 <td></td>
 <td></td>
 </tr>
 <tr>
 <td>STEALTH Rotary Tattoo System </td>
 <td>Worldwide Tattoo Supply</td>
 <td>STEALTH-L</td>
 <td></td>
 </tr>
 <tr>
 <td>Tattoo needles </td>
 <td>Worldwide Tattoo Supply</td>
 <td>1207RSB</td>
 <td></td>
 </tr>
 <tr>
 <td>EndoFree Plasmid Maxi Kit </td>
 <td>Qiagen</td>
 <td>12362</td>
 <td></td>
 </tr>
 <tr>
 <td>0.22 &mu;m PVDF sterile filter </td>
 <td>Millipore</td>
 <td>SLGV013SL</td>
 <td></td>
 </tr>
 <tr>
 <td>electrical hair trimmer</td>
 <td>Commercially available </td>
 <td></td>
 <td></td>
 </tr>
 <tr>
 <td>disposable safety razors</td>
 <td>Commercially available </td>
 <td></td>
 <td></td>
 </tr>
 <tr>
 <td>Silver Sulfadiazine Cream</td>
 <td>Watson</td>
 <td>NDC 0591-0810-55</td>
 <td></td>
 </tr>
 <tr>
 <td>Ketamine HCL</td>
 <td></td>
 <td>NDC 0856-2012-01</td>
 <td></td>
 </tr>
 <tr>
 <td>Zylazine Sterile Solution</td>
 <td></td>
 <td>NADA 139-236</td>
 <td></td>
 </tr>
 </tbody>
</table>

skin tattooing as a novel approach for dna vaccine delivery

Nucleic acid-based vaccination is a topic of growing interest, especially plasmid DNA (pDNA) encoding immunologically important antigens. After the engineered pDNA is administered to the vaccines, it is transcribed and translated into immunogen proteins that can elicit responses from the immune system. Many ways of delivering DNA vaccines have been investigated; however each delivery route has its own advantages and pitfalls. Skin tattooing is a novel technique that is safe, cost-effective, and convenient. In addition, the punctures inflicted by the needle could also serve as a potent adjuvant. Here, we a) demonstrate the intradermal delivery of plasmid DNA encoding enhanced green fluorescent protein (pCX-EGFP) in a mouse model using a tattooing device and b) confirm the effective expression of EGFP in the skin cells using confocal microscopy.

The expression of EGFP with an excitation peak at 488 nm and emission peak at 509 nm can be observed in mouse skin cells. From a 1.875 &mu;g dose of DNA, containing approximately 3&times;1017copies of the plasmid, we typically observed 10-20 EGFP signals in the 1 cm2 tattooed area. This relatively low number of transfected cells is consistent with the results of a previous study3. The EGFP expression (Figure 1) provides the evidence that EGFP plasmid was delivered into th...

Watch this Scientific Journal Video about Skin Tattooing As A Novel Approach For DNA Vaccine Delivery at JoVE.com

Skin Tattooing As A Novel Approach For DNA Vaccine Delivery

Skin tattooing is a potent and safe way to delivery DNA vaccine intradermally. Here, a DNA plasmid encoding EGFP is delivered by tattooing to the skin of a laboratory mouse, and the expression of EGFP in the skin cells is then inspected by confocal microscopy.
