We express our gratitude to Dr. Caroline Burns at Boston Children&#39;s Hospital for generously sharing the transgenic zebrafish. We thank Ms. Elizabeth Ibanez for her help in husbanding zebrafish at UT Dallas. We also appreciate all the constructive comments provided by D-incubator members at UT Dallas. This work was supported by NIH R00HL148493 (Y.D.), R01HL162635 (Y.D.), and UT Dallas STARS program (Y.D.).

Approval for this study was granted by the Institutional Animal Care and Use Committee (IACUC) of the University of Texas at Dallas, under protocol number #20-07. Tg(myl7:nucGFP) transgenic zebrafish larvae12 were used for the present study. All data acquisition and image post-processing were carried out using open-source software or platforms with research or educational licenses. The resources are available from the authors upon reasonable request.
1. Zebrafish breeding and embryo microinjection
Timing: 2 days
<ol>
	<li>Maintain and breed adult zebrafish through standard care and breed procedures. For detailed methods, refer to previous report13.</li>
	<li>Perform microinjection following established protocol14. For the present study, microinjection was performed at the 1-2 cell (zygote) stage.
	&#8203;NOTE: It is crucial to accurately identify this stage for effective microinjection and to ensure developmental consistency. During the one-cell stage, a small dome forms atop the yolk, and this stage typically lasts approximately 12 min. Upon progressing to the two-cell stage, two adjacent domes become visible, and this stage endures for about 45 min post-fertilization15. More detailed information of system construction can be found in other reports or protocols12,16,17.&#160;</li>
</ol>
2. Zebrafish embryos/larvae preparation and mounting
Timing: 7 days
<ol>
	<li>Transfer embryos at 1 day post fertilization (dpf) to E3 water with 0.2 mM 1-Phenyl-2-thiourea (PTU) (see Table of Materials) to prevent pigment formation.</li>
	<li>Replace the medium with fresh E3 water with PTU every day until LSM imaging.</li>
	<li>Image embryos or larvae with the stereo microscope to record their development at the desired timepoints between 0 and 7 dpf.</li>
	<li>Prepare segmented fluorinated ethylene propylene (FEP) tubes with 2 mm inner diameter for embedding zebrafish larvae under the LSM system12.
	NOTE: The FEP tube is utilized to secure the sample with refractive index matching materials that closely resemble the surrounding medium, such as water.</li>
	<li>Starting from 3 dpf, transfer fish to a 150 mg/L tricaine (MS-222) solution (see Table of Materials) to immobilize fish before imaging.</li>
	<li>Prepare 0.8 % low-melting agarose with 150 mg/L tricaine and use a transfer pipette to move anesthetized fish to the agarose once it has cooled to room temperature18.</li>
	<li>Use another transfer pipette to mount the fish with agarose in FEP tubes (Figure 1).
	NOTE: To ascertain the minimal stress in the developing embryos, pre- and post-fixation examinations of cardiac activity, such as heart rate, were conducted under microscopic observation. These assessments aimed to identify any significant differences before and after tricaine anesthesia. An additional examination of the skin and musculature for irregularities in cardiac structure, such as edema, could also be conducted post-fixation. The concentration of tricaine also plays a crucial role in cardiac imaging19, and therefore the 150 mg/L concentration tricaine solution was utilized for the imaging of contraction in zebrafish larvae in this project. While the present retrospective synchronization allows us to address the irregular heartbeats20, a comprehensive solution for the 4D imaging of cardiac arrhythmias and long-term imaging in zebrafish is still under development.</li>
</ol>
3. Light-sheet imaging system setup and configuration
Timing: 3-14 days
<ol>
	<li>Construct an in-house LSM system based on a cylindrical lens using continuous-wave diode-pumped solid-state (DPSS) laser systems at specific wavelengths such as 473 nm and 532 nm as illumination sources (Figure 2A).</li>
	<li>Customize LabVIEW (see Table of Materials) control codes for the synchronization of translational sample stage, light-sheet illumination, and exposure of sCMOS camera to capture image sequences.
	&#8203;NOTE: More detailed information of system construction can be found in other reports or protocols12,16,17. We encourage research groups to seek collaborative opportunities with laboratories that possess established expertise in optical imaging during system construction.</li>
</ol>
4. Zebrafish imaging preparation and data collection
Timing: 1 day
<ol>
	<li>Calibrate LSM system spatial resolution and minimize opacity variation at varying depths by measuring fluorescence beads.
	<ol>
		<li>First, dilute fluorescent beads (see Table of Materials) having the diameter of 0.53 &#181;m to a concentration of 1: 1.5 x 105 using 0.8 % low-melting agarose and transfer the solution to the segmented FEP tube.</li>
		<li>Second, use the LSM system to image the beads and measure the point spread function (PSF) across the entire sample, validating the spatial resolution and system alignment12.
		NOTE: In this system, the analysis of representative results for the full width at half maximum (FWHM) indicates lateral and axial resolutions of 1.26 &#177; 0.15 and 2.48 &#177; 0.15 &#181;m (n = 60 beads), respectively. This suggests a consistent spatial resolution throughout the imaging depth.</li>
	</ol>
	</li>
	<li>Attach the FEP tube with mounted zebrafish larva securely to the 6-axis (x, y, z, pitch, yaw, and roll) motorized sample stage, and submerge the tubes into the sample chamber filled with E3 water. To avoid the light scattering by the yolk sac and better locate the position of the heart, rotate the zebrafish larva to take image from the ventral side (Figure 2B). In this case, most captured images would include both the ventricle and atrium (Figure 2C).
	NOTE: Given that the current imaging procedures typically lasted less than one hour per fish and were conducted in a controlled room temperature environment, the chamber temperature control and oxygen level regulation are deemed optional for this project. However, for longer-term time-lapse imaging studies, particularly those focused on developmental processes, continuous temperature monitoring and regulation at 27 &#176;C within the sample chamber is suggested to ensure the physiological environment of the zebrafish and to prevent any potential developmental abnormalities.</li>
	<li>Connect the motorized sample stage to the workstation and configure all necessary parameters, including the desired moving mode.</li>
	<li>Establish a connection between the sCMOS camera and the workstation. Adjust all essential settings, such as an exposure time of 5 ms and the desired region of interest.</li>
	<li>Configure the number of image sequences and frames within the customized LabVIEW control program.</li>
	<li>Power on the laser and initiate LSM imaging of the sample. Maintain the process until all image sequences have been successfully recorded.</li>
	<li>Record 300 frames as a 2D image sequence to cover 3-5 cardiac cycles of the larva with a framerate of 200 frames/second. The recording captures cardiac contractility at the selective plane illuminated by the light-sheet.</li>
	<li>Move the larva at the step size of 1 &#181;m across the light-sheet illumination to virtually slice the sample.
	NOTE: The step size of the sample stage should be set based on the axial resolution of the light-sheet system, following the Nyquist-Shannon sampling theorem12.</li>
	<li>Repeat step 7 to record another image sequence of the new sample slice until the whole heart is covered. Generally, 100-200 image sequences with the step size of 1 &#181;m ensure the coverage of the entire heart of a zebrafish larva (Figure 2D).
	&#8203;NOTE: Step 4.7-4.9 are controlled by the LabVIEW program and automatically performed by the LSM system (Figure 3). Given the extensive volume of image data generated, a standardized naming convention is recommended for image sequences. For example, designate folders with names such as &#34;z-1&#34;, &#34;z-2&#34;, etc., to categorize data across various image sequences. Within each sequence, the images should be named sequentially (e.g., &#34;1&#34;, &#34;2&#34;, ...) to denote distinct time points. The total time for mounting fish, adjusting the imaging&#160;angle, and collecting all the data for one zebrafish larva is around 1 h.</li>
</ol>
5. 4D image&#160;reconstruction with parallel computation
Timing: 1 day
NOTE: The 4D reconstruction algorithm developed by our group and sample data are publicly accessible21. This method allows one to reconstruct the 4D heart image from the image sequences collected in previous steps (Table 1).
<ol>
	<li>Open the file test_Parallel.m in MATLAB (see Table of Materials). Specify the folder location where the raw image sequences are stored in the variable &#34;baseDir&#34;.</li>
	<li>Assign the variable &#34;numOfSlice&#34; with the total number of image sequences (typically 100-150) and the variable &#34;numOfImage&#34; with the number of images (typically 300-500) in each sequence.</li>
	<li>Inspect the image sequence that shows the middle plane of the zebrafish heart (for example, the 51st sequence out of 101 total sequences). Identify the frame numbers of the first and fourth systoles in this sequence and assign them to the variables systolicPoint_1st and systolicPoint_4th.</li>
	<li>Click on Run to start the process.
	NOTE: The length of the cardiac cycle in each image sequence will first be identified by the MATLAB program through a comparison of the similarity (sum of squared differences) between images at different time points. Subsequently, the cardiac cycle will be estimated using the average of the cycle lengths from all image sequences. Next, the starting points of image sequences at different axial locations will be aligned by the program through an iterative comparison of the image similarity from the first image sequence to the last image sequence.</li>
	<li>Check the results in the output folder. The program will save the images as &#34;.tif&#34; files with time stamps. Each &#34;.tif&#34; file is a 3D heart image at a specific time point. The time interval between two 3D images is equal to the exposure time that is set.
	&#8203;NOTE: Reconstruct the acquired images from the previous steps to depict the 4D (3D spatial + 1D temporal) cardiac contractions. To enhance proficiency in high-throughput investigations during the retrospective synchronization, this approach enables simultaneous computational operations on a GPU by leveraging multiple CPU cores through the MATLAB parallel computing toolbox and transforming images into the gpuArray format.</li>
</ol>
6. 3D cell segmentation and cell tracking
Timing: 1 day
<ol>
	<li>Download 3DeeCellTracker package (see Table of Materials) and set up the Python environment22.</li>
	<li>Download ITK-SNAP annotation software23 (see Table of Materials) and use it to manually label the 3D heart image in two selected timepoints, one at the ventricular diastole and the other at the ventricular systole, to create the training and validation datasets.
	NOTE: Other labeling software may also be applicable.</li>
	<li>In Python, run the 3DeeCellTracker training program and initialize the noise_level(100 in this case), folder_path and model parameters in TrainingUNet3D function to set the predefined 3D U-Net model.</li>
	<li>In MATLAB, use imageDimConverter.m program to convert and rename the training and validation dataset to the proper format for loading.</li>
	<li>In Python, load the training and validation datasets by using trainer.load_dataset() and trainer.draw_dataset() functions.</li>
	<li>In Python, run the first part of 3DeeCellTracker tracking program and initialize the parameters.
	NOTE: This includes defining image parameters to characterize image dimensions, segmentation parameters to select the machine learning model applied for cell segmentation, and tracking parameters to select the pre-trained deep neural network models employed for cell registration. For the first time use, employing the U-Net model for cell segmentation and FFN+ PR-GLS for cell registration is recommended. It is needed to store data, model, and results in folders that will be automatically created in this step.</li>
	<li>In MATLAB, use imageDimConverter.m program to convert and rename all the 3D heart images to the proper format and transfer them to the data folder created in the last step.</li>
	<li>In Python, run the second part of 3DeeCellTracker program to start segmentation.</li>
	<li>Once the first 3D image is segmented, compare the segmentation result with the raw image, and perform manual correction if any incorrect segmentation is found. Move the corrected segmentation to the created &#34;/manual_vol1&#34; folder.</li>
	<li>In Python, run the third part of 3DeeCellTracker program to segment all the images.</li>
	<li>Use Amira (see Table of Materials) to perform a visual assessment of tracking outcomes by comparing the positions of tracked cells with their corresponding raw images. If test results are not satisfying, recommence the procedure from step 6.6, employ an alternative machine learning model for segmentation or cell registration, and then re-initiate the tracking process.
	&#8203;NOTE: After the segmentation, the data of cell labels is stored as an 8-bit image (0 to 255) by default, which means only 256 scales are provided as labels for cell classification. There are two solutions for addressing this issue when additional classes are needed. One solution is to set the format of data of cell labels as a 16-bit image in the tracking program, which will cause an exponential increase in the processing time, more than two days in the present case. The other solution is to use the &#34;separateTrackingResults.py&#34; program to post-process the cell labels, which will separate cells with the same labels based on their physical location and assign each cell a different label. This process takes around 10 min in this case.</li>
</ol>
7. Cardiac contractility analysis in the virtual reality mode
Timing: 1 day
<ol>
	<li>Acquire the cell tracking outcome from previous steps.</li>
	<li>Manually validate the data and select cells with consistent image intensity across all volumes (about 500 cells out of approximately 600).</li>
	<li>Use cellLabelsToObj.ipynb script21 to generate a surface mesh for each individual cell through 3D Slicer software24 (see Table of Materials) and assign a unique color code to each cell.</li>
	<li>Export each 3D model, consisting of all cells in a single time point, as a single .obj file consisting of multiple sub-objects accompanied by a .mtl file to describe the cell label.</li>
	<li>Import the models into Unity using the educational license, a development engine used for extended reality.</li>
	<li>Apply the customized scripts consisting of functions written in C# to the models and user-interface elements to allow for 4D visualization and interactive analysis. Perform VR interaction following step 7.7.</li>
	<li>Interact with the models in virtual reality (VR) using the following functions (Figure 4):
	<ol>
		<li>Cell selection: Select up to two cells at a time and view their trajectories, velocities, volumes, surface areas, and relative distances.</li>
		<li>Time point selection: Choose a specific time point in the data to analyze the outputs of the selected cells, such as at t = 0 ms during diastole, or at t = 200 ms during systole.</li>
		<li>Time pause: Freeze the dynamic model to focus on the selected cells and their outputs.</li>
		<li>Contrast: Modulate the contrast between the selected cells and surrounding cells in the model.</li>
	</ol>
	</li>
</ol>

Analysis of Zebrafish Cardiac Contraction with Virtual Reality Interaction

<ol>
	<li>Power, R. M., Huisken, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+guide+to+light-sheet+fluorescence+microscopy+for+multiscale+imaging.">A guide to light-sheet fluorescence microscopy for multiscale imaging.</a> Nat. Methods. 14 (4), 360-373 (2017).</li><li>Liu, J., Stainier, D. Y. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Zebrafish+in+the+study+of+early+cardiac+development.">Zebrafish in the study of early cardiac development.</a> Circ. Res. 110 (6), 870 (2012).</li><li>Ding, Y., Bu, H., Xu, X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Modeling+inherited+cardiomyopathies+in+adult+zebrafish+for+precision+medicine.">Modeling inherited cardiomyopathies in adult zebrafish for precision medicine.</a> Front. Physiol. 11, 599244 (2020).</li><li>Giardoglou, P., Beis, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=On+zebrafish+disease+models+and+matters+of+the+heart.">On zebrafish disease models and matters of the heart.</a> Biomedicines. 7 (1), 15 (2019).</li><li>Zhang, X., Alexander, R. V., Yuan, J., Ding, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Computational+analysis+of+cardiac+contractile+function.">Computational analysis of cardiac contractile function.</a> Curr. Cardiol. Rep. 24 (12), 1983-1994 (2022).</li><li>Weber, M., Huisken, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+imaging+of+cardiac+development+and+function+in+zebrafish+using+light+sheet+microscopy.">In vivo imaging of cardiac development and function in zebrafish using light sheet microscopy.</a> Swiss Med. Wkly. 145 (51), w14227 (2015).</li><li>Vedula, V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+method+to+quantify+mechanobiologic+forces+during+zebrafish+cardiac+development+using+4-D+light+sheet+imaging+and+computational+modeling.">A method to quantify mechanobiologic forces during zebrafish cardiac development using 4-D light sheet imaging and computational modeling.</a> PLOS Comput. Biol. 13 (10), e1005828 (2017).</li><li>Yalcin, H. C., Amindari, A., Butcher, J. T., Althani, A., Yacoub, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Heart+function+and+hemodynamic+analysis+for+zebrafish+embryos.">Heart function and hemodynamic analysis for zebrafish embryos.</a> Dev. Dyn. 246 (11), 868-880 (2017).</li><li>Baek, K. I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advanced+microscopy+to+elucidate+cardiovascular+injury+and+regeneration:+4D+light-sheet+imaging.">Advanced microscopy to elucidate cardiovascular injury and regeneration: 4D light-sheet imaging.</a> Prog. Biophys. Mol. Biol. 138, 105-115 (2018).</li><li>Salman, H. E., Yalcin, H. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advanced+blood+flow+assessment+in+Zebrafish+via+experimental+digital+particle+image+velocimetry+and+computational+fluid+dynamics+modeling.">Advanced blood flow assessment in Zebrafish via experimental digital particle image velocimetry and computational fluid dynamics modeling.</a> Micron. 130, 102801 (2020).</li><li>Sodimu, O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light+sheet+imaging+and+interactive+analysis+of+the+cardiac+structure+in+neonatal+mice.">Light sheet imaging and interactive analysis of the cardiac structure in neonatal mice.</a> J. Biophotonics. 16 (5), e202200278 (2023).</li><li>Zhang, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=4D+light-sheet+imaging+and+interactive+analysis+of+cardiac+contractility+in+zebrafish+larvae.">4D light-sheet imaging and interactive analysis of cardiac contractility in zebrafish larvae.</a> APL Bioeng. 7 (2), 026112 (2023).</li><li>Westerfield, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Zebrafish+Book.">The Zebrafish Book.</a> Eugene. , (2000).</li><li>Rosen, J. N., Sweeney, M. F., Mably, J. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microinjection+of+zebrafish+embryos+to+analyze+gene+function.">Microinjection of zebrafish embryos to analyze gene function.</a> J Vis Exp. 25, e1115 (2009).</li><li>Kimmel, C. B., Ballard, W. W., Kimmel, S. R., Ullmann, B., Schilling, T. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stages+of+embryonic+development+of+the+zebrafish.">Stages of embryonic development of the zebrafish.</a> Dev Dyn. 203 (3), 253-310 (1995).</li><li>Girkin, J. M., Carvalho, M. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+light-sheet+microscopy+revolution.">The light-sheet microscopy revolution.</a> J. Opt. 20 (5), 053002 (2018).</li><li>Gualda, E. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=OpenSpinMicroscopy:+an+open-source+integrated+microscopy+platform.">OpenSpinMicroscopy: an open-source integrated microscopy platform.</a> Nat. Methods. 10 (7), 599-600 (2013).</li><li>Messerschmidt, V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Light-sheet+fluorescence+microscopy+to+capture+4-dimensional+images+of+the+effects+of+modulating+shear+stress+on+the+developing+zebrafish+heart.">Light-sheet fluorescence microscopy to capture 4-dimensional images of the effects of modulating shear stress on the developing zebrafish heart.</a> J Vis Exp. 138, e57763 (2018).</li><li>Kaufmann, A., Mickoleit, M., Weber, M., Huisken, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multilayer+mounting+enables+long-term+imaging+of+zebrafish+development+in+a+light+sheet+microscope.">Multilayer mounting enables long-term imaging of zebrafish development in a light sheet microscope.</a> Development. 139 (17), 3242-3247 (2012).</li><li>Lee, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=4-Dimensional+light-sheet+microscopy+to+elucidate+shear+stress+modulation+of+cardiac+trabeculation.">4-Dimensional light-sheet microscopy to elucidate shear stress modulation of cardiac trabeculation.</a> J Clin Invest. 126 (5), 1679-1690 (2016).</li><li>Zhang, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=4D+light-sheet+imaging+and+interactive+analysis+of+cardiac+contractility+in+Zebrafish+larvae.">4D light-sheet imaging and interactive analysis of cardiac contractility in Zebrafish larvae.</a> Zenodo. , (2023).</li><li>Wen, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=3deecelltracker,+a+deep+learning-based+pipeline+for+segmenting+and+tracking+cells+in+3d+time+lapse+images.">3deecelltracker, a deep learning-based pipeline for segmenting and tracking cells in 3d time lapse images.</a> Elife. 10, e59187 (2021).</li><li>Yushkevich, P. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=User-guided+3D+active+contour+segmentation+of+anatomical+structures:+significantly+improved+efficiency+and+reliability.">User-guided 3D active contour segmentation of anatomical structures: significantly improved efficiency and reliability.</a> Neuroimage. 31 (3), 1116-1128 (2006).</li><li>Fedorov, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=3D+Slicer+as+an+image+computing+platform+for+the+quantitative+imaging+network.">3D Slicer as an image computing platform for the quantitative imaging network.</a> Magn. Reson. Imaging. 30 (9), 1323-1341 (2012).</li><li>Naderi, A. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deep+learning-based+framework+for+cardiac+function+assessment+in+embryonic+zebrafish+from+heart+beating+videos.">Deep learning-based framework for cardiac function assessment in embryonic zebrafish from heart beating videos.</a> Comput. Biol. Med. 135, 104565 (2021).</li><li>Mickoleit, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-resolution+reconstruction+of+the+beating+zebrafish+heart.">High-resolution reconstruction of the beating zebrafish heart.</a> Nat. Methods. 11 (9), 919-922 (2014).</li><li>Lee, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=4-Dimensional+light-sheet+microscopy+to+elucidate+shear+stress+modulation+of+cardiac+trabeculation.">4-Dimensional light-sheet microscopy to elucidate shear stress modulation of cardiac trabeculation.</a> J. Clin. Invest. 126 (5), 1679-1690 (2016).</li><li>Ding, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiscale+light-sheet+for+rapid+imaging+of+cardiopulmonary+system.">Multiscale light-sheet for rapid imaging of cardiopulmonary system.</a> JCI Insight. 3 (16), e121396 (2018).</li><li>Choe, C. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgenic+fluorescent+zebrafish+lines+that+have+revolutionized+biomedical+research.">Transgenic fluorescent zebrafish lines that have revolutionized biomedical research.</a> Lab. Anim. Res. 37 (1), 1-29 (2021).</li><li>Coelho-Filho, O. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Quantification+of+cardiomyocyte+hypertrophy+by+cardiac+magnetic+resonance:+implications+on+early+cardiac+remodeling.">Quantification of cardiomyocyte hypertrophy by cardiac magnetic resonance: implications on early cardiac remodeling.</a> Circulation. 128 (11), 1225 (2013).</li><li>Zhang, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Automatic+segmentation+and+cardiac+mechanics+analysis+of+evolving+zebrafish+using+deep+learning.">Automatic segmentation and cardiac mechanics analysis of evolving zebrafish using deep learning.</a> Front. Cardiovasc. Med. 8, 675291 (2021).</li><li>Ding, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Integrating+light-sheet+imaging+with+virtual+reality+to+recapitulate+developmental+cardiac+mechanics.">Integrating light-sheet imaging with virtual reality to recapitulate developmental cardiac mechanics.</a> JCI Insight. 2 (22), e97180 (2017).</li><li>Koger, C. R., Hassan, S. S., Yuan, J., Ding, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Virtual+reality+for+interactive+medical+analysis.">Virtual reality for interactive medical analysis.</a> Front. Virtual Real. 3, 782854 (2022).</li><li>Yuan, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Extended+reality+for+biomedicine.">Extended reality for biomedicine.</a> Nat. Rev. Methods Prim. 3 (1), 1-1 (2023).</li></ol>

The authors have no conflict of interest to disclose.

The integration of the zebrafish model with engineering methods holds immense potential for the in vivo exploration of myocardial infarction, arrhythmias, and congenital heart defects. Leveraging its optical transparency, regenerative capacity, and genetic and physiological similarities to humans, zebrafish embryos and larvae have become extensively utilized in research1,2,4. The superior spatiotemporal resolution, mini...

The zebrafish (Danio rerio) is a widely used model organism for studying cardiac development, physiology, and repair due to its optical transparency, genetic tractability, and regenerative capacity1,2,3,4. Upon myocardial infarction, while structural and functional changes impact the cardiac ejection and hemodynamics, technical limitations continue to hinder the ability to investigate the dynamic process during cardiac regeneration with the high spatiotemporal resolution. For example, conventional imaging methods, such as confocal microscopy, have limitations in terms of imaging depth, temporal resolution, or phototoxicity for capturing the dynamic changes and assessing cardiac contractile function during multiple cardiac cycles5.
Light-sheet microscopy represents a state-of-the-art imaging method that successfully addresses these issues by quickly sweeping the laser across the heart&#39;s ventricle and atrium, achieving detailed images with enhanced spatiotemporal resolution and negligible photo-bleaching and photo-toxic effects6,7,8,9,10,11.
This protocol introduces a comprehensive imaging strategy that includes LSM system construction, 4D image reconstruction, 3D cell tracking, and interactive analysis to capture and analyze the dynamics of cardiomyocytes across the entire heart during multiple cardiac cycles12. The customized imaging system and computational methodology allow&#160;one to track the myocardial microstructure and contractile function at the single-cell level in transgenic Tg(myl7:nucGFP) zebrafish larvae. Furthermore, small molecule compounds were delivered into the embryos using microinjection to assess drug-induced cardiac injury and subsequent regeneration. This holistic strategy provides an entry point to in vivo investigate structural, functional, and mechanical properties of myocardium at the single-cell level during cardiac development and regeneration.

<table>
	<tbody>
		<tr>
			<td>RESOURCE</td>
			<td>SOURCE/Reference</td>
			<td>IDENTIFIER</td>
		</tr>
		<tr>
			<td>Animal models</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Tg(myl7:nucGFP) transgenic zebrafish</td>
			<td>Burns Lab in Boston Children&#39;s Hospital</td>
			<td>ZDB-TGCONSTRCT-070117-49</td>
		</tr>
		<tr>
			<td>Software and algorithms</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>MATLAB</td>
			<td>The MathWorks Inc.</td>
			<td>R2023a</td>
		</tr>
		<tr>
			<td>LabVIEW</td>
			<td>National Instruments Corporation</td>
			<td>2017 SP1</td>
		</tr>
		<tr>
			<td>HCImage Live</td>
			<td>Hamamatsu Photonics</td>
			<td>4.6.1.2</td>
		</tr>
		<tr>
			<td>Python</td>
			<td>The Python Software Foundation</td>
			<td>3.9.0</td>
		</tr>
		<tr>
			<td>Fiji-ImageJ</td>
			<td>Schneider et al.18</td>
			<td>1.54f</td>
		</tr>
		<tr>
			<td>3DeeCellTracker</td>
			<td>Chentao Wen et al.15</td>
			<td>v0.5.2</td>
		</tr>
		<tr>
			<td>Unity</td>
			<td>Unity Software Inc.</td>
			<td>2020.3.2f1</td>
		</tr>
		<tr>
			<td>Amira</td>
			<td>Thermo Fisher Scientific</td>
			<td>2021.2</td>
		</tr>
		<tr>
			<td>3D Slicer</td>
			<td>Andriy Fedorov et al.17</td>
			<td>5.2.1</td>
		</tr>
		<tr>
			<td>ITK SNAP</td>
			<td>Paul A Yushkevich et al.16</td>
			<td>4</td>
		</tr>
		<tr>
			<td>Light-sheet system</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Cylindrical lens</td>
			<td>Thorlabs</td>
			<td>ACY254-050-A</td>
		</tr>
		<tr>
			<td>4X Illumination objective</td>
			<td>Nikon</td>
			<td>MRH00045</td>
		</tr>
		<tr>
			<td>20X Detection objective</td>
			<td>Olympus</td>
			<td>1-U2M585</td>
		</tr>
		<tr>
			<td>sCMOS camera</td>
			<td>Hamamatsu</td>
			<td>C13440-20CU</td>
		</tr>
		<tr>
			<td>Motorized XYZ stage</td>
			<td>Thorlabs</td>
			<td>PT3/M-Z8</td>
		</tr>
		<tr>
			<td>Two-axis tilt stage</td>
			<td>Thorlabs</td>
			<td>GN2/M</td>
		</tr>
		<tr>
			<td>Rotation stepper motor</td>
			<td>Pololu</td>
			<td>1474</td>
		</tr>
		<tr>
			<td>Fluorescent beads</td>
			<td>Spherotech</td>
			<td>FP-0556-2</td>
		</tr>
		<tr>
			<td>473nm DPSS Laser</td>
			<td>Laserglow</td>
			<td>R471003GX</td>
		</tr>
		<tr>
			<td>532nm DPSS laser</td>
			<td>Laserglow</td>
			<td>R531003FX</td>
		</tr>
		<tr>
			<td>Microinjector and vacuum pump</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Microinjector</td>
			<td>WPI</td>
			<td>PV850</td>
		</tr>
		<tr>
			<td>Vacuum pump</td>
			<td>Welch</td>
			<td>2522B-01</td>
		</tr>
		<tr>
			<td>Pre-Pulled Glass Pipettes</td>
			<td>WPI</td>
			<td>TIP10LT</td>
		</tr>
		<tr>
			<td>Capillary tip for gel loading</td>
			<td>Bio-Rad</td>
			<td>2239912</td>
		</tr>
		<tr>
			<td>Virtual reality hardware</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>VR headset</td>
			<td>Meta</td>
			<td>Quest 2</td>
		</tr>
		<tr>
			<td>30mg/L PTU solution</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>PTU</td>
			<td>Sigma-Aldrich</td>
			<td>P7629</td>
		</tr>
		<tr>
			<td>1X E3 working solution</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>1% Agarose</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Low-melt agarose</td>
			<td>Thermo Fisher</td>
			<td>16520050</td>
		</tr>
		<tr>
			<td>Deionized water</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>10g/L Tricaine stock solution</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Tricaine</td>
			<td>Syndel</td>
			<td>SYNC-M-GR-US02</td>
		</tr>
		<tr>
			<td>Deionized water</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Sodium bicarbonate</td>
			<td>Sigma-Aldrich</td>
			<td>S6014</td>
		</tr>
		<tr>
			<td>150mg/L Tricaine working solution</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>10g/L Tricaine stock solution</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Deionized water</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>60X E3 stock solution</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Sodium Chloride</td>
			<td>Lab Animal Resource Center (LARC), The University of Texas at Dallas</td>
			<td>NaCl</td>
		</tr>
		<tr>
			<td>Potassium Chloride</td>
			<td>-</td>
			<td>KCL</td>
		</tr>
		<tr>
			<td>Calcium Chloride Dihydrate</td>
			<td>-</td>
			<td>CaCL2 x 2H2O</td>
		</tr>
		<tr>
			<td>Magnesium Sulfate Heptahydrate</td>
			<td>-</td>
			<td>MgSO4 x 7H2O</td>
		</tr>
		<tr>
			<td>RO Water</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
		</tr>
		<tr>
			<td>1X E3 working solution</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>60X E3 stock solution</td>
			<td>Lab Animal Resource Center (LARC), The University of Texas at Dallas</td>
			<td>-</td>
		</tr>
		<tr>
			<td>RO Water</td>
			<td>-</td>
			<td>-</td>
		</tr>
		<tr>
			<td>1% Methylene Blue (optional)&#160;</td>
			<td>-</td>
			<td>C16H18ClN3S</td>
		</tr>
	</tbody>
</table>

4d light-sheet imaging of zebrafish cardiac contraction

Zebrafish is an intriguing model organism known for its remarkable cardiac regeneration capacity. Studying the contracting heart in vivo is essential for gaining insights into structural and functional changes in response to injuries. However, obtaining high-resolution and high-speed 4-dimensional (4D, 3D spatial + 1D temporal) images of the zebrafish heart to assess cardiac architecture and contractility remains challenging. In this context, an in-house light-sheet microscope (LSM) and customized computational analysis are&#160;used to overcome these technical limitations. This strategy, involving LSM system construction, retrospective synchronization, single cell tracking, and user-directed analysis, enables one to investigate the micro-structure and contractile function across the entire heart at the single-cell resolution in the transgenic Tg(myl7:nucGFP) zebrafish larvae. Additionally, we are able to further incorporate microinjection of small molecule compounds to induce cardiac injury in a precise and controlled manner. Overall, this framework allows one to track physiological and pathophysiological changes, as well as the regional mechanics at the single-cell level during cardiac morphogenesis and regeneration.

Author Spotlight: High-Resolution 4D Light-Sheet Imaging and Virtual Reality in Zebrafish for Single-Cell Analysis of Heart Function

4D Light-sheet Imaging of Zebrafish Cardiac Contraction

Our research uses 4D light-sheet imaging to explore cardiac contractile function in zebrafish, aiming to understand the dynamics of cardiac contraction at the single-cell level. One of the foremost experimental challenges is achieving high spatial terminal resolution, dynamic imaging of cardiac function while observing natural heart rhythms. Our study fills the gap in analyzing intricate 4D cardiac dynamic at single-cell resolution.We utilize GPU-based parallel computation, virtual reality, and advance cell tracking to interpret light-sheet imaging data. Our novel virtual reality platform offers an interactive approach to assess regional cardiac contractions, providing manipulative functionalities for more in-depth analysis. By facilitating user-directed analysis of cardiac contraction, our protocol could lead to an enhanced understanding of cardiac development and disease.

The current protocol consists of three main steps: zebrafish preparation and microinjection, light-sheet imaging and 4D image reconstruction, and cell tracking and VR interaction. Adult zebrafish were allowed to mate, the fertilized eggs were collected, and performed microinjection as needed for the proposed experiments (Figure 1). This step provides an entry point to explore zebrafish applications in the investigation of cardiac development and regeneration, and it also plays a crucial role...

Watch this Scientific Journal Video about 4D Light-sheet Imaging of Zebrafish Cardiac Contraction at JoVE.com

This protocol utilizes light-sheet imaging to investigate cardiac contractile function in zebrafish larvae and gain insights into cardiac mechanics through cell tracking and interactive analysis.

Zebrafish is an intriguing model organism known for its remarkable cardiac regeneration capacity. Studying the contracting heart in vivo is essential for ...
