Many thanks to Silke Kipper, Sarah Kiefer, Michael Wei&#223;, Conny Bartsch and Silke Voigt-Heucke for enthusiastic sample collection in the field, to Janett Birkenfeld for continued assistance, to Ulla Kobalz for the beautiful gels and to Tobias Krause for moral support.

All procedures were performed in compliance with the German law for animal protection (TierSchG).
1. Preparation of Reagents and Consumables
<ol>
	<li>Prepare a 5% (w/w) Chelex-100 solution in molecular grade water. Prepare aliquots of 200 &#181;l in standard 1.5 ml reaction tubes. As the Chelex resin precipitates fast from the suspension it is necessary to re-homogenize the suspension constantly during the preparation of the aliquots. It's advisable to prepare 50 ml or more in one batch and keep the suspension homogenized using a magnetic stirrer. The Chelex solution can be stored for years at ambient conditions.</li>
	<li>Cut pieces of Whatman paper with a width smaller than the beak width of the bird to be tested. The length of the paper depends on the method to take the sample:
	<ol>
		<li>Using forceps, the piece should be long enough to enable sample collection without the forceps being inserted into the beak of the bird. As a rough estimate, for a beak length of 0.5 cm a piece of paper with the length of 1 cm should be fine.</li>
		<li>If not using forceps, the piece must be longer, but the stiffness of the piece should still allow sampling of epithelial cells.</li>
	</ol>
	</li>
	<li>Prepare one aliquot of PCR premix for each sample to be analyzed. For a PCR in a total volume of 25 &#181;l the mix contains 0.18 mM dNTPs, 2 mM MgCl2, 70 mM Tris-HCl, 17.25 mM ammonium sulfate , 0.1% Tween-20, 0.32 &#956;M P2 primer (TCTGCATCGCTAAATCCTTT), 0.32 &#956;M P8 primer (CTCCCAAGGATGAGRAAYTG)16 and 2 units Taq polymerase. Homemade Taq polymerase17 can be used. To allow addition of the maximum amount of DNA-solution, a 6 &#181;l premix can be prepared and stored at -20 &#176;C for several weeks.</li>
</ol>
2. Sample Collection
Wearing gloves is not essential for avian sex determination as the PCR primers cannot anneal to human DNA. For other genotyping purposes it might be advisable.
<ol>
	<li>Capture the bird of interest and gently hold it in one hand e.g. with the 'ringer's grip'18. Make sure not to squeeze the bird.</li>
	<li>Hold a piece of Whatman paper with a forceps and swipe it several times across the inside of the cheeks, the tongue and the choana. Usually samples are obtained within less than 30 seconds.
	<ol>
		<li>Adult animals: depending on the species it might be difficult to get the bird to open its beak. Usually touching the side of the beak and applying gentle pressure will work.</li>
		<li>Nestlings: Sampling from hatchlings or nestlings is especially easy using this technique, as their begging behavior provides easy access to the inside of the beak. It might even be possible to obtain the sample without handling them at all, as they readily beg e.g. when their nestbox is opened.</li>
	</ol>
	</li>
	<li>Immediately store the paper in a prepared reaction tube containing 200 &#181;l of the 5% (w/w) Chelex-100 solution.</li>
</ol>
If you also intend/need to mark the chicks, do so now as described in section 6.
3. Storage of Samples Before DNA Extraction
<ol>
	<li>If working in the lab, store samples at -20 &#176;C. If this is not possible or difficult (e.g. in the field) store samples at ambient temperatures.</li>
	<li>Samples can be stored for more than 3 years at temperatures ranging from room temperature to -20 &#176;C.</li>
</ol>
4. DNA Extraction
<ol>
	<li>If the sample is frozen, thaw it at room temperature.</li>
	<li>Ensure that the piece of paper is on the bottom of the tube submerged in the Chelex-100 solution.</li>
	<li>Incubate samples for 15 min at 56 &#176;C.</li>
	<li>Vortex briefly and spin down the content of the tube.</li>
	<li>Incubate the samples for 8 min at 100 &#176;C.</li>
	<li>Spin the samples at 15,000 x g for 3 min.</li>
	<li>Use the supernatant for subsequent genotyping.</li>
</ol>
5. Molecular Sex Determination
<ol>
	<li>Prepare one PCR tube with 6 &#181;l premix per sample plus two additional tubes for the negative (mandatory) and positive control (optional). For routine sex determination include a sample from the last successful sexing as a positive control.</li>
	<li>Add 19 &#181;l of the supernatant from the DNA extraction to the PCR premix. Make sure to pipette from the surface of the solution to avoid carryover of Chelex beads. This is crucial, as Chelex is a cation exchanger and thus severely inhibits all enzymatic reactions.</li>
	<li>Run the following PCR program: Incubation at 94 &#176;C for 3 min, 45 cycles each with a 30 sec melting step 94 &#176;C, followed by a 30 sec annealing step at 55 &#176;C, followed by a 45 sec elongation step at 72 &#176;C. In a final chase off step, the reactions are incubated for 5 min at 72 &#176;C.</li>
	<li>Prepare a 2% standard TBE or TAE agarose gel to separate the PCR products.</li>
	<li>Run the agarose gel with appropriate voltage settings.</li>
	<li>Visualize the bands under UV light and take a picture. Make sure the two bands in the samples originating from females are well separated.</li>
	<li>Distinguish male from female samples by the presence of one (male) or two (female) bands.</li>
</ol>
6. Marking Nestlings
<ol>
	<li>Check nests for newly hatched chicks on a schedule appropriate for the species/study (e.g. daily checks in the mornings are advised as most chicks hatch then).</li>
	<li>Cut the down feathers of each chick within a nest at a different characteristic location. In zebra finches tufts of downs grow at four characteristic and distinct areas across the nestling's body (Figure 4A). For each chick cut one area (Figure 4B). If there are more than four chicks within one nest, the unique four 'haircuts' can be combined.</li>
</ol>
For zebra finches: Apply leg bands at ten days post hatching when down feathers become hard to detect and nestling size allows ringing.

<ol>
	<li>Russell, W. M. S., Burch, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+principles+of+humane+experimental+technique.">The principles of humane experimental technique.</a> , (1959).</li><li>Robertson, B. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+sexing+of+individual+kakapo,+Strigops+habroptilus+Aves,+from+feces.">Molecular sexing of individual kakapo, Strigops habroptilus Aves, from feces.</a> Mol. Ecol. 8, 1349-1350 (1999).</li><li>Yannic, G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Description+of+microsatellite+markers+and+genotyping+performances+using+feathers+and+buccal+swabs+for+the+Ivory+gull+(Pagophila+eburnea).">Description of microsatellite markers and genotyping performances using feathers and buccal swabs for the Ivory gull (Pagophila eburnea).</a> Mol. Ecol. Resour. 11, 877-889 (2011).</li><li>Bello, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isolation+of+genomic+DNA+from+feathers.">Isolation of genomic DNA from feathers.</a> J. Vet. Diagn. Invest. 13, 162-164 (2001).</li><li>Handel, C. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Use+of+buccal+swabs+for+sampling+DNA+from+nestling+and+adult+birds.">Use of buccal swabs for sampling DNA from nestling and adult birds.</a> Wildl. Soc. Bull. 34, 1094-1100 (2006).</li><li>Brubaker, J. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+noninvasive,+direct+real-time+PCR+method+for+sex+determination+in+multiple+avian+species.">A noninvasive, direct real-time PCR method for sex determination in multiple avian species.</a> Mol. Ecol. Resour. 11, 415-417 (2011).</li><li>Arima, H., Ohnishi, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Usefulness+of+avian+buccal+cells+for+molecular+sexing.">Usefulness of avian buccal cells for molecular sexing.</a> Ornithological Science. 5, 139-143 (2006).</li><li>Seki, S. -. I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+sexing+of+individual+Ryukyu+Robins+Erithacus+komadori+using+buccal+cells+as+a+non-invasive+source+of+DNA.">Molecular sexing of individual Ryukyu Robins Erithacus komadori using buccal cells as a non-invasive source of DNA.</a> Ornithological Science. 2, 135-137 (2003).</li><li>Wellbrock, A. H. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Buccal+swabs+as+a+reliable+source+of+DNA+for+sexing+young+and+adult+Common+Swifts+(Apus+apus).">Buccal swabs as a reliable source of DNA for sexing young and adult Common Swifts (Apus apus).</a> J. Ornithol. 153, 991-994 (2012).</li><li>Marion, W. R., Shamis, J. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Annotated-Bibliography+of+Bird+Marking+Techniques.">Annotated-Bibliography of Bird Marking Techniques.</a> Bird Banding. 48, 42-61 (1977).</li><li>Scharff, C., Adam, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neurogenetics+of+birdsong.">Neurogenetics of birdsong.</a> Curr. Opin. Neurobiol. , (2012).</li><li>Griffith, S. C., Buchanan, K. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Zebra+Finch:+the+ultimate+Australian+supermodel.">The Zebra Finch: the ultimate Australian supermodel.</a> Emu. 110, 5-12 (2010).</li><li>Fee, M. S., Scharff, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+songbird+as+a+model+for+the+generation+and+learning+of+complex+sequential+behaviors.">The songbird as a model for the generation and learning of complex sequential behaviors.</a> Ilar J. 51, 362-377 (2010).</li><li>Honarmand, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stressful+dieting:+nutritional+conditions+but+not+compensatory+growth+elevate+corticosterone+levels+in+zebra+finch+nestlings+and+fledglings.">Stressful dieting: nutritional conditions but not compensatory growth elevate corticosterone levels in zebra finch nestlings and fledglings.</a> PLoS On. 5, (1371).</li><li>Krause, E. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Zebra+finch+nestlings+beg+more+under+better+nutritional+conditions.">Zebra finch nestlings beg more under better nutritional conditions.</a> Behaviour. 148, 1239-1255 (2011).</li><li>Griffiths, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+DNA+test+to+sex+most+birds.">A DNA test to sex most birds.</a> Mol. Ecol. 7, 1071-1075 (1998).</li><li>Pluthero, F. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+purification+of+high-activity+Taq+DNA+polymerase.">Rapid purification of high-activity Taq DNA polymerase.</a> Nucleic Acids Res. 21, 4850-4851 (1993).</li><li>. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Joint+Working+Group+on+Refinement.+Laboratory+birds:+refinements+in+husbandry+and+procedures.+Fifth+report+of+BVAAWF/FRAME/RSPCA/UFAW+Joint+Working+Group+on+Refinement.">Joint Working Group on Refinement. Laboratory birds: refinements in husbandry and procedures. Fifth report of BVAAWF/FRAME/RSPCA/UFAW Joint Working Group on Refinement.</a> Lab Anim. 35, 1-163 (2001).</li></ol>

The authors have nothing to disclose.

Sexing from buccal swabs using Chelex showed an extremely high success rate. Cutting hatchling's down feathers enabled differentiation between nestlings until leg banding was possible.
Chelex-DNA extraction from buccal swabs yielded enough DNA to successfully perform molecular sexing. Sex determination was 100% correct as validated by sexually dimorphic plumage. The success rate reported here is markedly higher than the rate reported by two previous studies7,9. The DNA extraction wi...

Individual recognition, sexing and genotyping are fundamental prerequisites in a variety of experimental studies. Obtaining DNA bearing material and marking subjects unambiguously (even at an early age) should have minimal impact on physiology, behavior, and survival. Whenever possible, invasive procedures should be avoided according to the RRR principle1.
Non-invasive methods are not only beneficial for the animal but also might improve the obtained data as animals are less affected by the treatments.
In birds, DNA sexing can be performed on a number of non-invasively obtainable materials as droppings2, feathers3,4 or buccal swabs3,5,9. Regardless of subject&#180;s condition and age buccal swabs are the method of choice for avian sexing, because they are easy to perform, rarely fail and handling is short.
So far, DNA from buccal swabs was either extracted with commercially available kits3,6 or time consuming standard DNA extraction protocols3,6-8. Kits are not only rather expensive, but their protocols can impose challenges for field work. Some procedural details, e.g. drying and incubation of samples, are not practical in the field. Especially in a setting where experimental protocols require sex dependent treatment from as early as a few minutes post hatching, there is urge for a quick, non-invasive, reliable and easy method to obtain results.
Across the avian taxa a considerable toolbox for marking individuals has been developed10. The wide array of available techniques accounts for the variety of research objectives, species and budgets. However, marking small nestlings has confronted researchers with additional challenges. In some species (e.g. passerines) chicks are too small to apply leg bands and require alternative methods, which do not alter parent-offspring behavior. As awareness and interest in improving animal welfare and techniques in field and laboratory studies is growing, the use of non-invasive techniques is strongly encouraged and preferred.
This protocol provides a non-invasive, quick, easily recognizable and persistent method to individually mark very young nestlings before applying leg bands is feasible. This marking method is introduced on one of the most important avian laboratory model species, the Zebra Finch (Taeniopygia guttata)11-13. The protocol complies with all of the previously published objectives for individual marking techniques10 and has been already successfully applied14,15.

<table border="0" cellpadding="0" cellspacing="0" width="702">
	<tbody>
		<tr height="75">
			<td height="75" style="height:75px;width:191px;">Whatman 3MM Chromatography paper</td>
			<td style="width:163px;">e.g. Fisher Scientific</td>
			<td style="width:269px;">No.:3030-153</td>
			<td style="width:80px;"></td>
		</tr>
		<tr height="25">
			<td height="25" style="height:25px;width:191px;">Chelex 100 Resin</td>
			<td style="width:163px;">Biorad</td>
			<td style="width:269px;">#143-2832</td>
			<td></td>
		</tr>
		<tr height="50">
			<td height="50" style="height:50px;width:191px;">Taq polymerase</td>
			<td style="width:163px;">addgene</td>
			<td style="width:269px;">http://www.addgene.org/25712/</td>
			<td></td>
		</tr>
		<tr height="75">
			<td height="75" style="height:75px;width:191px;">leg band (Flexi number rings for birds, diameter 2,5 mm)</td>
			<td style="width:163px;">Horst Stengel &#38; Sohn</td>
			<td style="width:269px;"></td>
			<td></td>
		</tr>
	</tbody>
</table>

who is who? non-invasive methods to individually sex and mark altricial chicks

Many experiments require early determination of offspring's sex as well as early marking of newborns for individual recognition. According to animal welfare guidelines, non-invasive techniques should be preferred whenever applicable. In our group, we work on different species of song birds in the lab and in the field, and we successfully apply non-invasive methods to sex and individually mark chicks. This paper presents a comprehensive non-invasive tool-box. Sexing birds prior to the expression of secondary sexual traits requires the collection of DNA-bearing material for PCR. We established a quick and easy method to sex birds of any age (post hatching) by extracting DNA from buccal swabs. Results can be obtained within 3 hours. For individual marking chick's down feathers are trimmed in specific patterns allowing fast identification within the hatching order. This set of methods is easily applicable in a standard equipped lab and especially suitable for working in the field as no special equipment is required for sampling and storage. Handling of chicks is minimized and marking and sexing techniques are non-invasive thereby supporting the RRR-principle of animal welfare guidelines.

Buccal swabs can be used to obtain DNA for sex determination in a variety of small birds
Samples were collected from Zebra Finches (Taeniopygia guttata, 99 individuals, age 0 days - 5 years), Canaries (Serinus canaria), Bengalese Finches (Lonchura striata), Nightingales (Luscinia megarhynchos), Great Tits (Parus major) and Blackbirds (Turdus merula) (for all other species: sample size 1-3, age unknown) (Figure 1).
<p class...

Watch this Scientific Journal Video about Who is Who? Non-invasive Methods to Individually Sex and Mark Altricial Chicks at JoVE.com

Who is Who? Non-invasive Methods to Individually Sex and Mark Altricial Chicks

This protocol provides a convenient set of methods, which enables extremely fast, easy, non-invasive, reliable and low-cost, molecular sex determination of birds and their non-invasive, quick, safe and easily recognizable marking shortly after hatching. Only limited handling of chicks is required. This convenient toolbox of methods complies entirely with the RRR-guidelines.

Many experiments require early determination of offspring's sex as well as early marking of newborns for individual recognition. According to animal ...
