All human participants provided informed consent. The protocol was part of a study approved by the Institutional Review Board of the University of Central Florida. Inclusion criteria included ages 18 -45 and physically active according to ACSM guidelines (30 min of moderate to vigorous activity 5 days per week)19. Exclusion criteria included low back pain within the past year, current hip, upper, or lower extremity pain or injury, a year history of low back surgery or lower extremity surgery, self...

<ol>
	<li>Kendall, F., McCreary, E., Provance, P., Rodgers, M., Romani, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Muscles: Testing and Function with Posture and Pain. , (2005).</li><li>Bergmark, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stability+of+the+lumbar+spine.+A+study+in+mechanical+engineering.">Stability of the lumbar spine. A study in mechanical engineering.</a> Acta Orthopaedica Scandinavica. Supplementum. 230, 1-54 (1989).</li><li>Borghuis, J., Hof, A. L., Lemmink, K. A. P. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+importance+of+sensory-motor+control+in+providing+core+stability.">The importance of sensory-motor control in providing core stability.</a> Sports Medicine. 38 (11), 893-916 (2008).</li><li>Ireland, M. L., Willson, J. D., Ballantyne, B. T., Davis, I. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hip+strength+in+females+with+and+without+patellofemoral+pain.">Hip strength in females with and without patellofemoral pain.</a> Journal of Orthopaedic &amp; Sports Physical Therapy. 33 (11), 671-676 (2003).</li><li>Zazulak, B. T., Hewett, T. E., Reeves, N. P., Goldberg, B., Cholewicki, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deficits+in+neuromuscular+control+of+the+trunk+predict+knee+injury+risk:+prospective+biomechanical-epidemiologic+study.">Deficits in neuromuscular control of the trunk predict knee injury risk: prospective biomechanical-epidemiologic study.</a> The American Journal of Sports Medicine. 35 (7), 1123-1130 (2007).</li><li>George, S. Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Interventions+for+the+management+of+acute+and+chronic+low+back+pain:+revision+2021.">Interventions for the management of acute and chronic low back pain: revision 2021.</a> Journal of Orthopaedic &amp; Sports Physical Therapy. 51 (11), (2021).</li><li>Dieterich, A. V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=M-mode+ultrasound+used+to+detect+the+onset+of+deep+muscle+activity.">M-mode ultrasound used to detect the onset of deep muscle activity.</a> Journal of Electromyography and Kinesiology. 25 (2), 224-231 (2015).</li><li>Teyhen, D. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Abdominal+and+lumbar+multifidus+muscle+size+and+symmetry+at+rest+and+during+contracted+states+normative+reference+ranges.">Abdominal and lumbar multifidus muscle size and symmetry at rest and during contracted states normative reference ranges.</a> Journal of Ultrasound in Medicine. 31 (7), 1099-1110 (2012).</li><li>Oliva-Lozano, J. M., Muyor, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Core+muscle+activity+during+physical+fitness+exercises:+A+systematic+review.">Core muscle activity during physical fitness exercises: A systematic review.</a> International Journal of Environmental Research and Public Health. 17 (12), 4306 (2020).</li><li>Dieterich, A., Petzke, F., Pickard, C., Davey, P., Falla, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Differentiation+of+gluteus+medius+and+minimus+activity+in+weight+bearing+and+non-weight+bearing+exercises+by+M-mode+ultrasound+imaging.">Differentiation of gluteus medius and minimus activity in weight bearing and non-weight bearing exercises by M-mode ultrasound imaging.</a> Manual therapy. 20 (5), 715-722 (2015).</li><li>Biscarini, A., Contemori, S., Grolla, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Activation+of+scapular+and+lumbopelvic+muscles+during+core+exercises+executed+on+a+whole-body+wobble+board.">Activation of scapular and lumbopelvic muscles during core exercises executed on a whole-body wobble board.</a> Journal of Sport Rehabilitation. 28 (6), 623-634 (2019).</li><li>Calatayud, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Progression+of+core+stability+exercises+based+on+the+extent+of+muscle+activity.">Progression of core stability exercises based on the extent of muscle activity.</a> American Journal of Physical Medicine &amp; Rehabilitation. 96 (10), 694-699 (2017).</li><li>McGill, S. M., Karpowicz, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Exercises+for+spine+stabilization:+motion/motor+patterns,+stability+progressions,+and+clinical+technique.">Exercises for spine stabilization: motion/motor patterns, stability progressions, and clinical technique.</a> Archives of Physical Medicine and Rehabilitation. 90 (1), 118-126 (2009).</li><li>Czaprowski, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Abdominal+muscle+EMG-activity+during+bridge+exercises+on+stable+and+unstable+surfaces.">Abdominal muscle EMG-activity during bridge exercises on stable and unstable surfaces.</a> Physical Therapy in Sport. 15 (3), 162-168 (2014).</li><li>Souza, G. M., Baker, L. L., Powers, C. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electromyographic+activity+of+selected+trunk+muscles+during+dynamic+spine+stabilization+exercises.">Electromyographic activity of selected trunk muscles during dynamic spine stabilization exercises.</a> Archives of Physical Medicine and Rehabilitation. 82 (11), 1551-1557 (2001).</li><li>Criswell, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Cram's Introduction to Surface Electromyography. , (2010).</li><li>Mirmohammad, R., Minoonejhad, H., Sheikhhoseini, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasonographic+comparison+of+deep+lumbopelvic+muscles+activity+in+plank+movements+on+stable+and+unstable+surface.">Ultrasonographic comparison of deep lumbopelvic muscles activity in plank movements on stable and unstable surface.</a> Physical Treatments: Specific Physical Therapy Journal. 9 (3), 147-152 (2019).</li><li>Bunce, S. M., Hough, A. D., Moore, A. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Measurement+of+abdominal+muscle+thickness+using+M-mode+ultrasound+imaging+during+functional+activities.">Measurement of abdominal muscle thickness using M-mode ultrasound imaging during functional activities.</a> Manual Therapy. 9 (1), 41-44 (2004).</li><li>Garber, C. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=American+College+of+Sports+Medicine+position+stand.+Quantity+and+quality+of+exercise+for+developing+and+maintaining+cardiorespiratory,+musculoskeletal,+and+neuromotor+fitness+in+apparently+healthy+adults:+guidance+for+prescribing+exercise.">American College of Sports Medicine position stand. Quantity and quality of exercise for developing and maintaining cardiorespiratory, musculoskeletal, and neuromotor fitness in apparently healthy adults: guidance for prescribing exercise.</a> Medicine &amp; Science in Sports &amp; Exercise. 43 (7), 1334-1359 (2011).</li><li>Vera-Garcia, F. J., Moreside, J. M., McGill, S. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=MVC+techniques+to+normalize+trunk+muscle+EMG+in+healthy+women.">MVC techniques to normalize trunk muscle EMG in healthy women.</a> Journal of Electromyography and Kinesiology. 20 (1), 10-16 (2010).</li><li>Partner, S. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Changes+in+muscle+thickness+after+exercise+and+biofeedback+in+people+with+low+back+pain.">Changes in muscle thickness after exercise and biofeedback in people with low back pain.</a> Journal of Sport Rehabilitation. 23 (4), 307-318 (2014).</li><li>Devorski, L., Bazett-Jones, D., Mangum, L. C., Glaviano, N. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Muscle+activation+in+the+shoulder+girdle+and+lumbopelvic-hip+complex+during+common+therapeutic+exercises.">Muscle activation in the shoulder girdle and lumbopelvic-hip complex during common therapeutic exercises.</a> Journal of Sport Rehabilitation. 31 (1), 31-37 (2021).</li><li>Youdas, J. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Magnitudes+of+muscle+activation+of+spine+stabilizers+in+healthy+adults+during+prone+on+elbow+planking+exercises+with+and+without+a+fitness+ball.">Magnitudes of muscle activation of spine stabilizers in healthy adults during prone on elbow planking exercises with and without a fitness ball.</a> Physiotherapy Theory and Practice. 34 (3), 212-222 (2018).</li><li>Ekstrom, R. A., Donatelli, R. A., Carp, K. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electromyographic+analysis+of+core+trunk,+hip,+and+thigh+muscles+during+9+rehabilitation+exercises.">Electromyographic analysis of core trunk, hip, and thigh muscles during 9 rehabilitation exercises.</a> The Journal of Orthopaedic and Sports Physical Therapy. 37 (12), 754-762 (2007).</li><li>Mangum, L. C., Sutherlin, M. A., Saliba, S. A., Hart, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reliability+of+ultrasound+imaging+measures+of+transverse+abdominis+and+lumbar+multifidus+in+various+positions.">Reliability of ultrasound imaging measures of transverse abdominis and lumbar multifidus in various positions.</a> PM&amp;R. 8 (4), 340-347 (2016).</li><li>Mangum, L. C., Henderson, K., Murray, K. P., Saliba, S. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasound+assessment+of+the+transverse+abdominis+during+functional+movement.">Ultrasound assessment of the transverse abdominis during functional movement.</a> Journal of Ultrasound in Medicine. 37 (5), 1225-1231 (2018).</li><li>Carovac, A., Smajlovic, F., Junuzovic, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Application+of+ultrasound+in+medicine.">Application of ultrasound in medicine.</a> Acta Informatica Medica. 19 (3), 168-171 (2011).</li><li>Chowdhury, R. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Surface+electromyography+signal+processing+and+classification+techniques.">Surface electromyography signal processing and classification techniques.</a> Sensors. 13 (9), 12431-12466 (2013).</li><li>Tweedell, A. J., Tenan, M. S., Haynes, C. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Differences+in+muscle+contraction+onset+as+determined+by+ultrasound+and+electromyography.">Differences in muscle contraction onset as determined by ultrasound and electromyography.</a> Muscle &amp; Nerve. 59 (4), 494-500 (2019).</li></ol>

The authors declare no conflicts of interest related to this manuscript.

M-mode ultrasound provides onset of muscle tissue movement and muscle thickness change during real time observation of anatomy over a selected time21. M-mode ultrasound combined with sEMG provides an overall understanding of muscle function, including electrical representation and visual observation. These instruments can be used in tandem during exercise to provide researchers with a global understanding of muscle function.
Specific training of ultrasound and sEMG tech...

The lateral abdominal wall is made up of the transverse abdominis, internal oblique, and external oblique1. The lateral abdominal wall contracts concentrically, eccentrically, and isometrically to withstand the forces placed on the body1. The co-contraction of this muscle group provides stabilization of the center of the human body2,3. These muscles are important during the prevention and rehabilitation of lower extremity injuries because poor trunk function is associated with increased hip adduction and knee valgus, which are risk factors for lower extremity injuries4,5. Focusing on strengthening and increasing muscular endurance of the core musculature not only decreases risk factors for the lower extremity but can also decrease low back pain6. Recently, it has been recommended that individuals who are suffering from acute and chronic low back pain should include trunk strengthening, endurance, and specific trunk muscle activation in their rehabilitation6. An example of specific trunk muscle activation is targeting isolated or grouped trunk muscles using co-contraction to restore control or increase coordination of the lumbopelvic-hip region6.
Two ways to objectively measure muscle function are the use of motion mode (M-mode) ultrasound and surface electromyography (sEMG). M-mode ultrasound provides a real-time visualization of muscle and fascia movement during a recorded time which can display onset and extent of the motion7. The distance between the superior inferior fascial border and inferior superior fascial border are measured at a selected time to obtain muscle thickness. Muscle thickness during a specific time point of an exercise can be divided by resting thickness to achieve an activation ratio8. sEMG provides insight into muscle activation and fatigue, as the output can be compared to the muscle&#39;s maximum contraction9. These two instruments and methods have been used previously to measure the onset of hip muscle activation during a variety of exercises in healthy and injured individuals10. Exercises that target the trunk, and specifically the lateral abdominal wall, are the side plank and dead bug11,12,13. The side plank is performed in a side lying position with the elbow directly underneath the shoulder and forearm on the ground, the hips are raised off the ground until the spine is in a neutral position. The knees are extended, and the feet are placed on top of one another9 (Supplemental Figure 1). The dead bug is performed in a supine position with both arms straight above and the hips and knees flexed in a 90&#176; angle. The exercise begins when one arm is flexed above the head and the contralateral leg extends. The opposite arm and leg remain in a neutral position and then flex and extend once the original moving arm and leg return to the neutral position13 (Supplemental Figure 2 and Supplemental Figure 3).
The activation of the external oblique has been seen to range from 37% to 62% of maximum voluntary isometric contraction (MVIC) during the side plank11,12,14. During the dead bug, the activation of the external oblique has been recorded between 20% to 30% of MVIC for only five repetitions of the exercise15. The internal oblique and transverse abdominis, the deeper abdominal muscles of the lateral abdominal wall, activate between 22% to 28% of MVIC during the side plank12,14. Due to the overlapping nature of the internal oblique and transverse abdominis, the two muscles have been combined during sEMG collection14. A limitation of sEMG is the crosstalk from adjacent muscles, where the sEMG sensor may be producing an output of a different muscle, resulting in a false understanding of activation16. Muscle thickness measurements obtained with ultrasound can be used to mitigate this limitation, and this measurement is feasible during trunk exercises, such as the isometric holds previously mentioned17.
Muscle thickness of the lateral abdominal wall has been recorded during the side plank as an absolute magnitude of difference between contracted thickness and rested thickness. At the 30 s time point of a side plank, the muscle thickness of the internal oblique and external oblique increased by 0.526 mm and 0.205 mm, respectively17. These measurements were recorded in brightness mode ultrasound at one time point during the side plank. B-mode ultrasound is commonly performed to assess before and after images; however, this method only allows for measurement at two time points18. M-mode ultrasound provides increased advantages compared to B-mode ultrasound, as it can detect onset of muscle activation as well as muscle thickness during the entirety of the exercise with any time point able to be selected for measurement18. Therefore, the overall goal of the current protocol is to provide an innovative and practical measurement of muscle function with M-mode ultrasound and sEMG during core endurance exercises. This is beneficial to researchers and clinicians to understand how muscles function throughout the duration of an exercise, especially of an endurance nature, as opposed to a measurement isolated to a single time point.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Alcohol prep pads</td>
			<td>Henry Schein</td>
			<td>HS1007</td>
			<td></td>
		</tr>
		<tr>
			<td>Amazon Basics 1/2- Inch Extra Thick Exercise Yoga Mat</td>
			<td>Amazon</td>
			<td>YM2001BK</td>
			<td></td>
		</tr>
		<tr>
			<td>Delsys Trigno Sensor Adhesive Interface, 4-Slot</td>
			<td>Delsys</td>
			<td>SC:F03</td>
			<td></td>
		</tr>
		<tr>
			<td>Delsys Trigno Wireless System</td>
			<td>Delsys</td>
			<td>T03-A16014</td>
			<td></td>
		</tr>
		<tr>
			<td>Galaxy Tablet S5e</td>
			<td>Samsung</td>
			<td>SM-TS20N</td>
			<td></td>
		</tr>
		<tr>
			<td>GE NextGen Logig e Ultrasound Unit</td>
			<td>GE Healthcare</td>
			<td>HR48382AR</td>
			<td></td>
		</tr>
		<tr>
			<td>Linear Array Probe</td>
			<td>GE Healthcare</td>
			<td>H48062AB</td>
			<td></td>
		</tr>
		<tr>
			<td>Trigno Avanti sensors</td>
			<td>Delsys</td>
			<td>T03-A16014</td>
			<td></td>
		</tr>
	</tbody>
</table>

muscle function obtained with motion mode ultrasound and surface electromyography during core endurance exercise

Motion mode (M-mode) ultrasound allows researchers and clinicians to measure the change of muscle thickness across time. Muscle thickness can be measured between fascial borders at a given time point during an exercise. This selected time point produces a one-dimensional image resulting in real-time, live observation of anatomy. Ultrasound used during functional movement can be referred to as dynamic ultrasound; this is feasible and reliable with the use of a linear transducer, elastic belt, and foam block to secure consistent transducer placement. The lateral abdominal wall is commonly investigated using ultrasound due to the overlapping nature of the muscles. Surface electromyography (sEMG) can complement M-mode ultrasound imaging because it measures the electrical representation of muscle activation. There is minimal evidence using M-mode ultrasound and sEMG simultaneously during core exercise. Exercises that challenge the core musculature involve both isometric holds (e.g., side plank), as well as oscillatory extremity movements (e.g., dead bug). In this study, both instruments will be used simultaneously to measure core muscle function during exercise. Ultrasound measurements will be obtained using a linear transducer and ultrasound unit, and sEMG measurements will be acquired from a wireless sEMG system. To make comparisons between participants and exercises, normalization methods using static, exercise starting positions for both instruments will be used. An activation ratio will be used for ultrasound and calculated by dividing the contracted thickness (thickness during a time point of exercise) by the rested (starting position) thickness. Muscle thickness will be measured in centimeters from the superior inferior fascial border to inferior superior fascial border. These methods aim to offer an innovative and practical measurement of muscle function with M-mode ultrasound and sEMG during core endurance exercises.

The measurements of both ultrasound and sEMG during the static, exercise starting position are represented in Table 2. These numbers will be used as the denominator when calculating the activation ratio. The thickness values of external oblique, internal oblique, and transverse abdominis during the first 5 s, last 5 s, and total duration (60 s) are in Table 3. These numbers are divided by the numbers in Table 2. The sEMG values normalized to static, exercise starting pos...

Watch this Scientific Journal Video about Muscle Function Obtained with Motion Mode Ultrasound and Surface Electromyography during Core Endurance Exercise at JoVE.com

Muscle Function Obtained with Motion Mode Ultrasound and Surface Electromyography during Core Endurance Exercise

This protocol uses motion mode ultrasound and surface electromyography simultaneously to measure muscle function of the core. Muscle thickness and activation of the local stabilizers (e.g., transverse abdominis, internal oblique) and global movers (e.g., external oblique) is achievable during specific time points of the side plank and dead bug exercises.

Motion mode (M-mode) ultrasound allows researchers and clinicians to measure the change of muscle thickness across time. Muscle thickness can be measured ...

This protocol provides insight into how dynamic ultrasound can be implemented in a clinical setting to assess musculature during core exercise. The main advantage of this technique is that both instruments can be used simultaneously during core exercise. To begin, turn on the ultrasound machine, press Patient, and add a new patient.Click New Patient and enter the patient identification number. Select MSK exam type then click abdominal preset and press Register. Press Exit.Turn on the tablet and click the EMG recording application. Click the menu button in the top left screen and scan for sensors. Take the sensor out of the base and hover over the activation button.Once the sensor is connected with the application, create a new folder with the participant's identification number. Determine the external oblique sensor location by palpating the right iliac crest and right inferior rib while the participant is supine hook lying. Shave, clean, and debris the area of the skin where the sensor will be placed.Add adhesive to the sensor and secure onto skin. Place the sensor three centimeters anterior from the midway point between the lower rib and the iliac crest parallel to the muscle fibers. In a standing position, place the transducer through the elastic belt and foam block.Add gel to the transducer and place the transducer 10 centimeters lateral to the umbilicus. Adjust until the lateral abdominal wall is visible on the screen. Ensure that the transducer is tightly secured to the lateral abdominal wall.Secure the belt with the Velcro straps. Adjust the depth to obtain optimal image quality in B mode. On a yoga mat, instruct the participant to lay on their right side with their elbow in 90 degrees of flexion so their trunk and upper extremity is raised off the ground.The participant's feet should be stacked on each other with the knees fully extended. The legs should be parallel, touching the yoga mat. Press Freeze then Store for each image to capture three static ultrasound images of the lateral abdominal wall.In the SEMG menu in the top left screen of the EMG recording application, select Settings and select the bicep icon. Press Click Play to begin. There will be a five second countdown.During this period, instruct the patient to assume the testing position. Record the maximum voluntary contraction, as this will be used for normalization calculation. Next, instruct the participant to complete the side plank for 60 seconds, maintaining the correct form.Press the M on the ultrasound machine to turn on M mode. Press the Play button on the EMG application. Once the five second countdown commences, press Store on the ultrasound to begin the ultrasound recording.To save the recorded M mode video, press Store once the exercise has stopped and the Stop button on the SEMG application. Click Save File As and type in a file name to save the output which will appear on the screen when the recording is stopped. On the yoga mat, instruct the participant to lay supine with their legs in a hook lying position.Press Freeze and then Store for each image to capture three static images of the lateral abdominal wall via ultrasound. Saved images will be located below the active image screen. Next, instruct the participant to complete the dead bug for 60 seconds, maintaining the correct form.Press the M on the ultrasound machine to turn on M mode. Instruct the participant to maximally extend their right shoulder while maximally extending their left hip and knee while also maintaining the starting position of the contralateral extremities. Instruct the participant to then flex their shoulder, hip, and knee to return to the starting position.The contralateral extremities will then perform the same motion. Ask the participant to perform the exercise to a metronome set to 45 beats per minute. This results in 22 repetitions of the dead bug in 60 seconds.Press the Play button on the EMG application. Once the five second countdown commences, press Store on the ultrasound to begin the ultrasound recording. Click enter when the first static image you want to measure is selected.Press Measure to open the measurement tool. Measure the maximal muscle thickness during the static positions in centimeters from the superior inferior facial border to the inferior superior facial border. Click Enter at the superior inferior border and Enter again at the inferior superior border.Repeat the ultrasound static measurement procedure for side plank and dead bug static measurements. Average the measurements of the three static images. Measure the maximal thickness of the external oblique, internal oblique, and transverse abdominal thickness during the first five seconds and the last five seconds of the exercise.Additionally, record the maximal thickness over the entire 60 seconds. Press Measure to open the measurement tool. Measure the maximal muscle thickness during the static positions in centimeters from the superior interior facial border to the inferior superior facial border.Divide each of the three thickness measurements obtained during the exercises by the averaged static position to obtain an activation ratio. Press the home icon on the EMG data recording page. Select the folder icon in the top right corner of the screen.The saved output from the static and exercise trials will be saved here. Convert each file to a XLSX file. Export the XLSX file.In a spreadsheet, obtain the maximum values during the first and last five seconds and the overall maximum value. Divide the static SEMG output obtained from static side plank SEMG and dead bug SEMG by the output during the exercises respectively. The table here represents measurements of both ultrasound and SEMG during the static exercise starting position.These numbers are used as the denominator when calculating the activation ratio. The thickness values of the external oblique, internal oblique, and transverse abdominous during the first five seconds, last five seconds, and total duration of 60 seconds show higher values of dead bug. The SEMG values normalized to static exercise starting position during the first five seconds, last five seconds, and peak activity show lower values of dead bug.The activation ratios for the external oblique, internal oblique, and transverse abdominous also show lower dead bug values. Make sure the location of the transducer is accurate with the muscles visible on the screen with and without the securing belt and foam. Additional methods include obtaining the onset of muscle activation visually through ultrasound and electrically through surface electromyography.Researchers can use both instruments and healthy and pathological individuals to observe muscle function of the core. Additionally, these instruments can be used with other muscles within the body.
