eoe sub articles

EoE Sub Articles

1. Biotinylation of BCG Cell Surface
<ol>
	<li>Grow BCG in Middlebrook 7H9 broth with 10% OADC (oleic acid, albumin and dextrose solution) and 0.05% Tween 80 at 37 &#176;C on a shaker platform at 50 rpm until OD = 0.5-1.
	NOTE: BCG is a biosafety level 2 pathogen and all experiments concerning BCG should be done in a biosafety cabinet with proper personal protective equipment.</li>
	<li>Wash 109 BCG 3 times with 500 &#181;L of ice-cold endotoxin free PBS plus 0.1% Tween80 (PBST) (pH 8.0). Suspend BCG pellet in sterile endotoxin free PBS.</li>
	<li>Immediately before use, prepare 1 mL of 10 mM Sulfo-NHS SS biotin in sterile filtered water.&#8203;
	<ol>
		<li>Incubate bacteria with 1 mL of 0.5 mM of Sulfo-NHS SS biotin at room temperature for 30 min.</li>
	</ol>
	</li>
	<li>Wash labeled bacteria 3 times with 500 &#181;L of iced cold PBST to remove non-reacted biotinylation reagent.
	<ol>
		<li>Re-suspend pellet in 1 mL of PBST.</li>
	</ol>
	</li>
</ol>
2. Binding of Monomeric Avidin-Fusion Protein to Biotinylated BCG Surface
<ol>
	<li>Mix 5 x 108 biotinylated BCG with Avi-protein (10 &#956;g/mL final in PBS-T) for 1 h at room temperature on shaker platform.</li>
	<li>Wash bacteria 3 times with 500 &#181;L of iced cold PBST.</li>
</ol>

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Endotoxin-free RPMI 1640</td>
			<td>StemCell Technologies</td>
			<td>36750</td>
			<td></td>
		</tr>
		<tr>
			<td>Sulfo-NHS SS biotin</td>
			<td>Thermo Fisher</td>
			<td>21328</td>
			<td></td>
		</tr>
		<tr>
			<td>Middlebrook 7H9 broth</td>
			<td>BD Diagnostic Systems</td>
			<td>271310</td>
			<td></td>
		</tr>
		<tr>
			<td>OADC</td>
			<td>BD Diagnostic Systems</td>
			<td>B11886</td>
			<td></td>
		</tr>
		<tr>
			<td>Tween 80</td>
			<td>Sigma-Aldrich</td>
			<td>P1379</td>
			<td></td>
		</tr>
	</tbody>
</table>

an avidin-biotin conjugation technique for presenting target antigens on mycobacterium bovis bcg

Source: Liao, T. A., et al., <a href="https://app.jove.com/v/56421">Expression of Exogenous Antigens in the Mycobacterium bovis BCG Vaccine via Non-genetic Surface Decoration with the Avidin-biotin System.</a> J. Vis. Exp. (2018).
The video demonstrates a technique for loading antigens on Mycobacterium bovis BCG to improve its immunogenic properties. The method uses the avidin-biotin system to coat the bacterial surface with exogenous antigens.

An Avidin-Biotin Conjugation Technique for Presenting Target Antigens on Mycobacterium bovis BCG

1. Biotinylation of BCG Cell Surface

	Grow BCG in Middlebrook 7H9 broth with 10% OADC (oleic acid, albumin and dextrose solution) and 0.05% Tween 80 at ...

Begin with a suspension of Mycobacterium bovis BCG, treated with a non-ionic surfactant, to prevent bacterial clumping.
Next, add a biotinylation reagent and incubate.
This biotinylation reagent, a complex of biotin complexed to a functional linker, facilitates binding biotin molecules to bacterial surface proteins, labeling bacteria.
Post-incubation, centrifuge the biotin-labeled bacterial suspension to remove unreacted biotinylation reagent.
Resuspend the bacteria in a buffer. Add a solution of avidin-fusion protein, a recombinant protein comprising a target antigen domain fused to monomeric avidin.
During incubation, avidin binds to biotin, facilitating bacterial surface modification with target antigens.
Centrifuge the suspension to remove unbound fusion proteins.
Resuspend the antigen-coated bacteria in a buffer containing a non-ionic surfactant. The antigen coating on the bacteria can enhance its property to trigger immune responses.
