1. Construction and Preparation of Porous Media Soil Tank
<ol>
	<li>Cut a large piece of 1.2 cm thick acrylic glass into five individual panes. Assemble these panes into an open-topped soil tank with internal length, width and height of 25, 9.1 and 55 cm, respectively. Acrylic glass allows processes in the subsurface to be visually observed.</li>
	<li>Draw a 5 x 5 grid that is 25 cm by 25 cm on each of the two large glass panes (length 25 cm and height 55 cm) as shown in Figure 1. Ensure that each square within the grid has an area of 25 cm2 (Figure 1). The grid will be used to properly space the sensors within the soil tank.</li>
</ol>
<img alt="Figure 1" src="/files/ftp_upload/52704/52704fig1highres.jpg" width="700" />
Figure 1: Schematic front and side views of the soil tank used for the experimental set-up (dimensions are in centimeters). (a) The front view of the soil tank displaying the grid system consisting of twenty-five 5 cm x 5 cm squares. (b) The side view of the soil tank, showing the installed temperature, relative humidity and soil moisture sensor network as a function of depth. Note that the schematics are not drawn to scale.
<ol start="3">
	<li>On one of the large glass planes, drill a total of twenty-five 1.9 cm (&#190; inch) diameter holes for the soil moisture sensors.
	<ol>
		<li>Drill each hole in the center of every square in the grid established in Step 1.2 so that the centers of the holes of two abutting squares are 5 cm apart; the first set of holes is 2.5 cm below the top of the tank. Use appropriately sized taps to cut threads into each of the newly created holes. The 5 cm spacing between sensors ensures that each sensor is outside of the sampling volume of the next closest sensor.</li>
	</ol>
	</li>
	<li>Similarly, drill and tap a total of twenty-five 0.635 cm (&#188; inch) diameter holes in the center of each grid box created during Step 1.2. Make sure that the center of each hole is spaced 5 cm apart with the first row of holes located 2.5 cm below the top of the soil tank. The 5 cm spacing between sensors ensures that each sensor is outside of the sampling volume of the next closest sensor.</li>
	<li>On the acrylic pane used as the bottom of the tank, drill and tap a single &#189; inch diameter hole in the middle of the pane. Glue a mesh screen (finer than the test soils to be used) over the hole on the internal side of the glass. On the external side of the bottom plane, install a 90&#176; elbow that is attached to flexible tubing with an adjustable valve. This valve and tubing is used to drain water from the tank at the termination of an experiment or as a way to install constant head devices for maintaining constant water table depths.</li>
	<li>Use marine grade glue or similar water resistant polymer adhesive to attach and seal the tank together as shown in Figure 1. Allow the adhesive to cure for one day.</li>
	<li>To raise the tank off of the ground and make room for the 90&#176; elbow (Figure 1), attach two additional pieces of 1.2 cm thick acrylic glass with length 12 cm and height 5 cm to the bottom of the tank.</li>
</ol>
2. Construction and Preparation of Climate Controlled Wind Tunnel
<ol>
	<li>Construct the 215 cm long upstream portion of the wind tunnel out of rectangular galvanized steel ducting material that has a width of 8.5 cm and a height of 26 cm. Surround the outside of the duct with polystyrene insulation.</li>
	<li>Drill a small hole in the side of the duct work near the downstream exit of the upstream portion of the wind tunnel for the insertion of a relative humidity-temperature sensor (Figure 2).</li>
</ol>
<img alt="Figure 2" src="/files/ftp_upload/52704/52704fig2highres.jpg" width="700" />
Figure 2: Complete experimental set-up, including tank, ductwork, sensors grid (dimensions are in centimeters). Complete experimental set up of the combined wind tunnel and soil-tank apparatus. The wind tunnel is elevated and sits flush with the surface of the soil tank. The soil tank is instrumented with a network of sensors used to measure a variety of subsurface and atmospheric variables. The grid circles represent the locations for inserting these sensors. A heating control system and an in-line duct fan are used to control temperature and wind speed, respectively. The pitot-static tube is used to measure wind speed. The entire apparatus sits on a weighting scale to obtain a mass balance during experimentation. Note that the schematic is not drawn to scale.
<ol start="3">
	<li>Install five ceramic infrared heating elements positioned in parallel within a reflector along the length of the upstream portion of the wind tunnel. Connect the infrared heating elements to a temperature control system regulated by an infrared temperature sensor.</li>
	<li>Construct the mid-section of the wind tunnel out of two 1.2 cm thick acrylic panels with a length and height of 25 cm and 26 cm respectively. Drill two 0.635 cm (&#188; inch) diameter holes in one of the mid-section panels to insert temperature and/or relative humidity-temperature sensors at the locations shown in Figure 2.
	<ol>
		<li>Secure the acrylic panels to the top of the soil tank side walls (i.e., panels with dimensions 25 cm x 55 cm) using a strong adhesive tape, ensuring that the wind tunnel and soil tank panels sit flush with one another.</li>
	</ol>
	</li>
	<li>Construct the first 50 cm of the downstream portion of the wind tunnel out of the same size rectangular ducting material described in Step 2.1. On the terminating side, reduce the rectangular ducting material to a 15.3 cm diameter round duct with length of 170 cm. Install a galvanized steel damper, used to adjust wind speeds, at the far downstream end of the round duct for aid in wind speed control.</li>
	<li>As in Step 2.2, drill one 0.635 cm diameter hole in the side of the downstream rectangular duct near the entrance for the insertion of a relative humidity-temperature sensor. Drill a second 0.635 cm diameter hole from the top of the rectangular duct along the centerline of the wind tunnel.</li>
	<li>Install an in-line duct fan in the middle of the round duct (i.e., 85 cm downstream from reduction described in Step 2.4) oriented to expel air from the downstream portion of the wind tunnel. Interface the fan with a variable speed controller for more precise control of rotational frequency and as a result wind speed.</li>
	<li>Use weldment material and adjustable shelving units to elevate and secure the wind tunnel apparatus. Ensure that the bottom of the upstream and downstream ductwork are flush with the top of the soil tank (Figure 2).</li>
</ol>
3. Installation of Sensors
<ol>
	<li>Prior to installation within the soil tank, secure each soil moisture and temperature sensor within a threaded NPT housing (1.9 cm and 0.635 cm housings, respectively) and seal with flashing sealant to prevent moisture intrusion. Do not use silicone-based sealant products as they can interfere with the electronics within some sensors. Cure the sensors for approximately one week.</li>
	<li>Prior to installation in the soil tank, calibrate the soil moisture sensors in accordance with the two point &#945;-mixing method developed by Sakaki et al.12.</li>
	<li>Wrap the threads of each NPT housing with plumbers tape prior to installation in the tank to help provide a better seal between the NPT threading and acrylic glass.</li>
	<li>Install a total of 25 soil moisture and temperature sensors each horizontally through the walls of the tank at the locations discussed in Step 1.2. Twist the sensor cables in sync with the NPT fitting/housing so as not damage the internal wiring within the cables. Do not over-torque the NPTs so as to prevent the glass from cracking. Connect the soil moisture sensors and temperature sensors to their designated data loggers.</li>
	<li>Install 3 relative humidity-temperature sensors on the soil surface at distances of 2.5, 12.5 and 21.5 cm from the leading edge of the tank. Place the sensors in good contact with the soil surface so that the relative humidity readings reflect the conditions at the soil surface rather than the surrounding air. Connect the sensors to data loggers.</li>
	<li>To obtain the requisite air temperature and relative humidity measurements in the atmosphere, install relative humidity-temperature sensors in the free flow section of the wind tunnel, using the holes drilled through the upstream and downstream sections of the wind tunnel as well as the panels.</li>
	<li>Install a pitot-static tube directly downstream of the soil tank through the 0.635 cm hole drilled in the top of the downstream wind tunnel section. Hold the pitot-static tube at a height of 13 cm from the floor of the section. Connect the pitot-static tube to a differential pressure transducer.</li>
	<li>Calibrate the differential pressure transducer. The pitot-static tube measures dynamic pressure which is defined as the difference of the stagnation and static pressures. The pressure differential is interpreted by the pressure transducer as a voltage differential.
	<ol>
		<li>Measure the voltage under no flow conditions (voltage should be approximately equal to 0) and for flow of a known dynamic pressure; this allows a linear relationship to be established between dynamic pressure and voltage. Determine wind speed by applying Bernoulli&#8217;s equation:
		<img alt="Equation 1" fo:content-width="0.8in" src="/files/ftp_upload/52704/52704eq1.jpg" width="100" /> (1)
		where V (m/sec) is wind speed, Pdynamic (Pa) is dynamic pressure, and &#961; (kg/m3) is the density of air.</li>
		<li>Compare the velocity calculated using Equation (1) with another measurement device. Here, compare the pitot-static tube differential pressure transducer with Laser Doppler Velocimetry (LDV) measurements which has an accuracy of &#177; 0.01 m/sec.
		Note: A summary of sensors employed and their associated sampling frequencies can be found in Table 1. For sensor specifications and other information, refer to the enclosed materials/equipment list.</li>
	</ol>
	</li>
</ol>
<table border="0" cellpadding="0" cellspacing="0">
	<tbody>
		<tr>
			<td>Sensor</td>
			<td>Sensor Measurements</td>
			<td>Number of Sensors Employed in Experimental Apparatus</td>
			<td>Sensor Sampling Frequency (min)</td>
		</tr>
		<tr>
			<td>EC-5</td>
			<td>Soil moisture</td>
			<td>25</td>
			<td>10</td>
		</tr>
		<tr>
			<td>ECT</td>
			<td>Soil/air temperature</td>
			<td>25</td>
			<td>10</td>
		</tr>
		<tr>
			<td>SH-1</td>
			<td>Thermal properties</td>
			<td>1</td>
			<td>10</td>
		</tr>
		<tr>
			<td>EHT</td>
			<td>Relative humidity/temperature</td>
			<td>5</td>
			<td>10</td>
		</tr>
		<tr>
			<td>Infrared camera</td>
			<td>Surface temperature/evaporation</td>
			<td>1</td>
			<td>1</td>
		</tr>
		<tr>
			<td>Digital camera</td>
			<td>Visualization of drying front</td>
			<td>1</td>
			<td>60</td>
		</tr>
		<tr>
			<td>Pitot static tube</td>
			<td>Wind velocity</td>
			<td>1</td>
			<td>10</td>
		</tr>
		<tr>
			<td>Weighting scale</td>
			<td>Cumulative evaporation/evaporation rate</td>
			<td>1</td>
			<td>10</td>
		</tr>
	</tbody>
</table>
Table 1: Summary of sensors used in experimental portion of present study.
4. Pack the Soil Tank and Prepare for the Start of the Experiment
<ol>
	<li>Prior to packing the tank with soil, test its integrity by performing a leak test. Fill the tank with water and wait for 4-6 hr to ensure that no leaks in the structure or sensors have developed.
	<ol>
		<li>If leaks develop, drain the tank, let it dry overnight and fix the leaks using the same marine adhesive used during original construction. If no leaks develop, drain the soil tank and prepare for the steps below.</li>
	</ol>
	</li>
	<li>Determine the total volume of the tank with sensors in place. Carefully fill the tank with water using a graduated cylinder, making sure to record the amount of water added. Convert the recorded total volume to cubic centimeters for use in Step 4.5.</li>
	<li>Obtain dry soil to pack the soil tank. Characterize the hydraulic and thermal properties of the selected soil separately in accordance with the methods discussed in Smits et al.11</li>
	<li>Carefully wet-pack the soil tank using soil and deionized water.
	<ol>
		<li>To wet-pack the soil tank, first pour approximately 5 cm of water into the tank. Slowly add dry soil to the water in the tank, using a scoop, in 2.5 cm depth increments. Record the weight of the sand added during each lift so the porosity of the soil packing can be calculated.</li>
		<li>Upon completion of each layer, repeatedly tap the tank walls using a rubber mallet, 100-200 times, to obtain a uniform bulk density throughout. While tapping, avoid contact with the sensors and sensor wires. The use of vibratory devices should be avoided so as not to damage the network of sensitive sensors.</li>
	</ol>
	</li>
	<li>Upon completion of packing the tank, sum together the weights of each soil layer (see Step 4.4) to get the total mass of soil. Divide the total mass by the bulk density of soil (e.g. the bulk density of quartz sand is 2.65 g/cm3) to determine the volume of the sand (Vs, cm3). Calculate the porosity (&#951;, m3/m3) of the soil in the tank according to:
	<img alt="Equation 2" fo:content-width="0.8in" src="/files/ftp_upload/52704/52704eq2.jpg" width="100" /> (2)
	where (VT, m3) is the total volume of the empty tank determined in Step 4.2.</li>
	<li>Once the tank is fully packed, place a plastic cover such as saran wrap over the tank until the experiment is ready to start to prevent the onset of evaporation.</li>
	<li>Place the tank on a weighting scale to monitor cumulative water loss which can in turn be used to calculate evaporation rate.</li>
	<li>Calculate the hourly evaporation rate by dividing the hourly weight loss by the product of the density of water and the cross sectional area of the evaporating surface.</li>
</ol>
5. Start the Experiment and Begin Data Collection
<ol>
	<li>Once the set-up is complete, determine the desired atmospheric conditions (i.e. temperature, wind speed). Ensure that the data loggers and other data acquisition systems are turned on and set to the correct sampling intervals (e.g., every 10 min).</li>
	<li>Start the fan and temperature control system. Allow the climate conditions to equilibrate before removing the plastic cover on the surface of the soil tank. Run the experiment for the desired length of time (e.g., 15 days).</li>
</ol>

<ol>
	<li>Verstraete, M. M., Schwartz, S. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Desertification+and+global+change.">Desertification and global change.</a> Vegetatio. 91, 3-13 (1991).</li><li>Warren, A., Adams, W. M., Goudie, A. S., Orme, A. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Desertification.">Desertification.</a> The Physical Geography of Africa. , 342-355 (1996).</li><li>Katata, G., Nagai, H., Ueda, H., Agam, N., Berliner, P. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+a+land+surface+model+including+evaporation+and+adsorption+processes+in+the+soil+for+the+land-air+exchange+in+arid+regions.">Development of a land surface model including evaporation and adsorption processes in the soil for the land-air exchange in arid regions.</a> J. Hydrometeorol. 8, 1307-1324 (2007).</li><li>Davarzani, H., Smits, K. M., Tolene, R., Illangasekare, T. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Study+of+the+effect+of+wind+speed+on+evaporation+from+soil+through+integrated+modeling+of+atmospheric+boundary+layer+and+shallow+subsurface.">Study of the effect of wind speed on evaporation from soil through integrated modeling of atmospheric boundary layer and shallow subsurface.</a> Water Resour. Res. 50, (2014).</li><li>Heitman, J. L., Horton, R., Ren, T., Nassar, I. N., Davis, D. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+test+of+coupled+soil+heat+and+water+transfer+prediction+under+transient+boundary+temperatures.">A test of coupled soil heat and water transfer prediction under transient boundary temperatures.</a> Soil Sci. Soc. Am. J. 72 (5), 1197-1207 (2008).</li><li>Gurr, C. G., Marshall, T. J., Hutton, J. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Movement+of+water+in+soil+due+to+a+temperature+gradient.">Movement of water in soil due to a temperature gradient.</a> Soil Sci. 74, 335-345 (1952).</li><li>Nassar, I. N., Horton, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Water+transport+in+unsaturated+non-isothermal+salty+soil:+experimental+results.">Water transport in unsaturated non-isothermal salty soil: experimental results.</a> Soil Sci. Soc. Am. J. 53, 1323-1363 (1989).</li><li>Prunty, L., Horton, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Steady-state+Temperature+Distribution+in+Nonisothermal+unsaturated+closed+soil+cells.">Steady-state Temperature Distribution in Nonisothermal unsaturated closed soil cells.</a> Soil Sci. Soc. Am. J. 58, 1358-1363 (1994).</li><li>Bachmann, J., Horton, R., Ren, T., van der Ploeg, R. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparison+of+the+thermal+properties+of+four+wettable+and+four+water-repellent+soils.">Comparison of the thermal properties of four wettable and four water-repellent soils.</a> Soil Sci. Soc. Am. J. 65 (6), 1675-1679 (2001).</li><li>Smits, K. M., Sakaki, T., Limsuwat, A., Illangasekare, T. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Thermal+conductivity+of+sands+under+varying+moisture+and+porosity+in+drainage-wetting+cycles.">Thermal conductivity of sands under varying moisture and porosity in drainage-wetting cycles.</a> Vadose Zone J. 9, 1-9 (2010).</li><li>Sakaki, T., Limsuwat, A., Smits, K. M., Illangasekare, T. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Empirical+two-point+&#945;-mixing+Model+for+calibrating+the+ECH2O+EC-5+soil+sensor+in+sands.">Empirical two-point &#945;-mixing Model for calibrating the ECH2O EC-5 soil sensor in sands.</a> Water Resources Research. 44, W00D08 (2008).</li><li>Shokri, N., Lehmann, P., Or, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaporation+from+layered+porous+media.">Evaporation from layered porous media.</a> J. Geophys. Res. 115, B06204 (2010).</li><li>Van Brakel, J., Mujumdar, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mass+transfer+in+convective+drying.">Mass transfer in convective drying.</a> Advances in Drying. 1, 217-267 (1980).</li><li>Yiotis, A. G., Subos, A. G. B. o. u. d. o. u. v. i. s. A. K., Tsimpanogiannis, I. N., Yortsos, Y. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+liquid+films+on+the+drying+of+porous+media.">The effect of liquid films on the drying of porous media.</a> AIChE J. 50, 2721-2737 (2004).</li><li>Ishihara, Y., Shimojima, E., Harada, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Water+vapor+transfer+beneath+bare+soil+where+evaporation+is+influenced+by+a+turbulent+surface+wind.">Water vapor transfer beneath bare soil where evaporation is influenced by a turbulent surface wind.</a> J. Hydrol. 131 (1-4), 63-104 (1992).</li><li>Lehmann, P., Assouline, S., Or, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characteristic+lengths+affecting+evaporative+drying+of+porous+media.">Characteristic lengths affecting evaporative drying of porous media.</a> Phys. Rev. E. 77 (5 Pt 2), 056309 (2008).</li><li>Trautz, A. C., Smits, K. M., Schulte, P., Illangasekare, T. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sensible+heat+balance+and+heat-pulse+method+applicability+to+in+situ+soil-water+evaporation.">Sensible heat balance and heat-pulse method applicability to in situ soil-water evaporation.</a> Vadose Zone J. 13, (2014).</li></ol>

The authors declare that they have no competing financial interests.

The purpose of this protocol was to develop an experimental apparatus and associated procedures for the generation of high spatial and temporal resolution data required for studying land-atmospheric interactions with respect to heat and mass transfer processes. The experimental apparatus described consisted of a soil tank and a small wind tunnel, both of which were outfitted with an array of sensors for the measurement of pertinent soil and atmospheric variables (e.g., wind speed, relative humidity, soil and air...
