This work was supported by NSF CAREER AWARD 1553023 and NIH/NIAID award R01AI103369.

1. Growth of Pseudomonas aeruginosa Colony Biofilms
<ol>
	<li>Preparation of Medium-Bilayer Plates
	<ol>
		<li>Prepare a 10 g/L tryptone, 10 g/L agar (see Table of Materials) solution in deionized water.</li>
		<li>Autoclave for 20 min. Cool to 50-60 &#176;C in a water bath.</li>
		<li>Pour 45 mL of the agar-tryptone solution into a 100 mm x 100 mm square dish (see Table of Materials) using a 50-mL conical tube. Allow the agar to solidify (~20-30 min). Pour a second, 15-mL layer on top...

<ol>
	<li>Ray, V. A., Morris, A. R., Visick, K. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+semi-quantitative+approach+to+assess+biofilm+formation+using+wrinkled+colony+development.">A semi-quantitative approach to assess biofilm formation using wrinkled colony development.</a> J. Vis. Exp. (64), e4035 (2012).</li><li>Friedman, L., Kolter, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genes+involved+in+matrix+formation+in+Pseudomonas+aeruginosa+PA14+biofilms.">Genes involved in matrix formation in Pseudomonas aeruginosa PA14 biofilms.</a> Mol. Microbiol. 51 (3), 675-690 (2004).</li><li>Okegbe, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electron-shuttling+antibiotics+structure+bacterial+communities+by+modulating+cellular+levels+of+c-di-GMP.">Electron-shuttling antibiotics structure bacterial communities by modulating cellular levels of c-di-GMP.</a> Proc. Natl. Acad. Sci. U. S. A. 114 (26), E5236-E5245 (2017).</li><li>Vlamakis, H., Aguilar, C., Losick, R., Kolter, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Control+of+cell+fate+by+the+formation+of+an+architecturally+complex+bacterial+community.">Control of cell fate by the formation of an architecturally complex bacterial community.</a> Genes Dev. 22 (7), 945-953 (2008).</li><li>Serra, D. O., Richter, A. M., Klauck, G., Mika, F., Hengge, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microanatomy+at+cellular+resolution+and+spatial+order+of+physiological+differentiation+in+a+bacterial+biofilm.">Microanatomy at cellular resolution and spatial order of physiological differentiation in a bacterial biofilm.</a> MBio. 4 (2), e00103-e00113 (2013).</li><li>Serra, D. O., Richter, A. M., Hengge, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cellulose+as+an+architectural+element+in+spatially+structured+Escherichia+coli+biofilms.">Cellulose as an architectural element in spatially structured Escherichia coli biofilms.</a> J. Bacteriol. 195 (24), 5540-5554 (2013).</li><li>McGlinn, E., Mansfield, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+gene+expression+in+mouse+embryos+and+tissue+sections.">Detection of gene expression in mouse embryos and tissue sections.</a> Methods Mol. Biol. 770, 259-292 (2011).</li><li>Choi, Y. S., Kim, Y. C., Baek, K. J., Choi, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+Situ+Detection+of+Bacteria+within+Paraffin-embedded+Tissues+Using+a+Digoxin-labeled+DNA+Probe+Targeting+16S+rRNA.">In Situ Detection of Bacteria within Paraffin-embedded Tissues Using a Digoxin-labeled DNA Probe Targeting 16S rRNA.</a> J. Vis. Exp. (99), e52836 (2015).</li><li>James, G., Hunt, A. M. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+Biofilms+in+Tissue+Specimens.">Imaging Biofilms in Tissue Specimens.</a> Antibiofilm Agents. , 31-44 (2014).</li><li>Madsen, J. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Facultative+control+of+matrix+production+optimizes+competitive+fitness+in+Pseudomonas+aeruginosa+PA14+biofilm+models.">Facultative control of matrix production optimizes competitive fitness in Pseudomonas aeruginosa PA14 biofilm models.</a> Appl. Environ. Microbiol. 81 (24), 8414-8426 (2015).</li><li>Jo, J., Cortez, K. L., Cornell, W. -. C., Price-Whelan, A., Dietrich, L. E. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+orphan+cbb3-type+cytochrome+oxidase+subunit+supports+Pseudomonas+aeruginosa+biofilm+growth+and+virulence.">An orphan cbb3-type cytochrome oxidase subunit supports Pseudomonas aeruginosa biofilm growth and virulence.</a> bioRxiv. , 171538 (2017).</li><li>Fong, J. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+dynamics+of+RbmA+governs+plasticity+of+Vibrio+cholerae+biofilms.">Structural dynamics of RbmA governs plasticity of Vibrio cholerae biofilms.</a> Elife. 6, (2017).</li><li>Bertani, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lysogeny+at+mid-twentieth+century:+P1,+P2,+and+other+experimental+systems.">Lysogeny at mid-twentieth century: P1, P2, and other experimental systems.</a> J. Bacteriol. 186 (3), 595-600 (2004).</li><li>Schindelin, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fiji:+an+open-source+platform+for+biological-image+analysis.">Fiji: an open-source platform for biological-image analysis.</a> Nat. Methods. 9 (7), 676-682 (2012).</li><li>Dietrich, L. E. P., Teal, T. K., Price-Whelan, A., Newman, D. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Redox-active+antibiotics+control+gene+expression+and+community+behavior+in+divergent+bacteria.">Redox-active antibiotics control gene expression and community behavior in divergent bacteria.</a> Science. 321 (5893), 1203-1206 (2008).</li><li>Zupan&#269;i&#269;, D., Ter&#269;elj, M., &#352;trus, B., Verani&#269;, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=How+to+obtain+good+morphology+and+antigen+detection+in+the+same+tissue+section?.">How to obtain good morphology and antigen detection in the same tissue section?.</a> Protoplasma. , (2017).</li><li>Priester, J. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enhanced+visualization+of+microbial+biofilms+by+staining+and+environmental+scanning+electron+microscopy.">Enhanced visualization of microbial biofilms by staining and environmental scanning electron microscopy.</a> J. Microbiol. Methods. 68 (3), 577-587 (2007).</li><li>Boyles, J., Anderson, L., Hutcherson, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+fixative+for+the+preservation+of+actin+filaments:+fixation+of+pure+actin+filament+pellets.">A new fixative for the preservation of actin filaments: fixation of pure actin filament pellets.</a> J. Histochem. Cytochem. 33 (11), 1116-1128 (1985).</li><li>Blackburn, M. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Examination+of+normal+and+abnormal+placentation+in+the+mouse.">Examination of normal and abnormal placentation in the mouse.</a> Methods Mol. Biol. 136, 185-193 (2000).</li><li>Hoffman, E. A., Frey, B. L., Smith, L. M., Auble, D. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Formaldehyde+crosslinking:+a+tool+for+the+study+of+chromatin+complexes.">Formaldehyde crosslinking: a tool for the study of chromatin complexes.</a> J. Biol. Chem. 290 (44), 26404-26411 (2015).</li><li>Jennings, L. K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pel+is+a+cationic+exopolysaccharide+that+cross-links+extracellular+DNA+in+the+Pseudomonas+aeruginosa+biofilm+matrix.">Pel is a cationic exopolysaccharide that cross-links extracellular DNA in the Pseudomonas aeruginosa biofilm matrix.</a> Proc. Natl. Acad. Sci. U. S. A. 112 (36), 11353-11358 (2015).</li></ol>

Paraffin-embedding and thin-sectioning tissue samples is a classic histological technique that enables imaging of micro-morphological structures and is commonly used on eukaryotic tissues, and has been applied with some success to microbial samples8,9. While cryoembedding allows for strong retention of endogenous and immunofluorescent signal, paraffin embedding is generally preferable as it provides better preservation of morphology16. In ...

Most microbes have the capacity to form biofilms, communities of cells held together by self-produced matrices. Biofilms can be grown in many types of physical setups, with various regimes of nutrient and substrate provision. Specific assays for biofilm formation tend to yield reproducible multicellular structures, and common architectures are observed for phylogenetically diverse species at the community or macroscopic level. When microbes are grown as colonies on solid medium under an atmosphere, macroscopic morphology conveys information about the capacity for matrix production and often correlates with other traits 1,2,3. The internal architecture of microbial colonies can also provide clues regarding biofilm-specific chemistry and physiology, but has been difficult to characterize. Recent applications of cryoembedding and cryosectioning techniques to bacterial colonies have enabled imaging and visualization of specific features at unprecedented resolution 4,5,6. However, studies with animal tissue have shown that paraffin embedding provides superior preservation of morphology when compared to cryoembedding 7 and has been used to visualize bacteria in tissues 8,9. We have therefore developed a protocol for fixation, paraffin embedding, and thin sectioning of microbial colony biofilms. Here, we will describe the preparation of Pseudomonas aeruginosa PA14 colony-biofilm thin sections 10,11, but we have also successfully applied this technique to biofilms formed by the bacteria Pseudomonas synxantha, Bacillus subtilis, and Vibrio cholerae12.
The process of paraffin-embedding and thin-sectioning biofilms follows a simple logic. First, the biofilms are encased in a layer of agar to preserve morphology during processing. Second, the encased-biofilms are submerged in a fixative to crosslink macromolecules and preserve micromorphology. These are then dehydrated with alcohol, cleared with a more non-polar solvent, and then infiltrated with liquid paraffin wax. Once infiltrated, the samples are embedded into wax blocks for sectioning. Sections are cut, mounted on slides, and then rehydrated in order to return them to a more native state. From this point, they can be stained or covered in mounting medium for microscopic analysis.
This protocol produces thin sections of microbial biofilms suitable for histological analysis. Colony biofilm substructures are visible when thin sections prepared using this method are imaged by light microscopy. Biofilms can also be grown on media containing fluorescent stains specific for individual features or stained at the rehydration step, immediately prior to mounting (steps 9.5-9.6). Finally, microbes can be engineered to produce fluorescent proteins in a constitutive or regulated fashion allowing in situ reporting of cell distribution or gene expression within these communities. We have used these methods to determine colony biofilm depth, cell distribution, matrix distribution, growth patterns, and spatiotemporal gene expression.

<table border="0" cellpadding="0" cellspacing="0" width="1205">
	<tbody>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">5 3/4&#34; Pasteur pipette</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">13-678-6A</td>
			<td style="width:577px;">Purchased from univeristy biostores&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Agar&#160;</td>
			<td style="width:191px;">Teknova&#160;</td>
			<td style="width:161px;">A7777</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Buchner Aspirator (Vacuum) Flask&#160;</td>
			<td style="width:191px;">Pyrex</td>
			<td style="width:161px;">5340</td>
			<td>Purchased from univeristy biostores&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Chemically-resistant Marking Pen</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">103051-182</td>
			<td>Manufacturer: Leica</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Clear Fingernail Polish&#160;</td>
			<td style="width:191px;">********</td>
			<td style="width:161px;">********</td>
			<td>Store bought</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Congo Red Indicator Grade</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">AAAB24310-14</td>
			<td>Manufacturer: Alfa Aesar</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Coomassie Blue&#160;</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">EM-3340</td>
			<td>Manufacturer: EMD Millipore</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:276px;">TRIS-buffered Mounting Medium (w/ DAPI)&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">50 247 04</td>
			<td>Manufacturer: Electron Microscopy Sciences</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Embedding Mold&#160;</td>
			<td style="width:191px;">********</td>
			<td style="width:161px;">********</td>
			<td>3D printed in-house</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:276px;">Embedding Mold (commercial)&#160;</td>
			<td style="width:191px;">Electron Microscopy Sciences</td>
			<td style="width:161px;">70182</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Ethanol 200P</td>
			<td style="width:191px;">Decon Labs, Inc.&#160;</td>
			<td style="width:161px;">2701</td>
			<td>Purchased from univeristy biostores&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Fine-tipped Brush</td>
			<td style="width:191px;">********</td>
			<td style="width:161px;">********</td>
			<td>Store bought, paint brush</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Glass Coverslips 60x22mm</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">12-519-21C</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Glass Rehydration Mailer&#160;</td>
			<td style="width:191px;">Ted Pella</td>
			<td style="width:161px;">21043</td>
			<td>20 slide mailer&#160;</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:276px;">Histoclear-II, orange oil-based clearing agent&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">50 899 90150</td>
			<td>Manufacturer: National Diagnostics&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Histosette, Embedding Casette</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">15 182 701A</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">L-lysine hydrochloride&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">BP386 100</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Low Profile Microtome Blades</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">22 210 048</td>
			<td>Manufacturer: Sturkey&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Micropipette&#160;</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">89080-004</td>
			<td>Promo-pack</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Micropipette Tips&#160;</td>
			<td style="width:191px;">See comments section</td>
			<td style="width:161px;">See comments section</td>
			<td>p10 (Fisher Scientific, 02 707 469), p200 (VWR, 89079-474), p1250 (VWR, 89079-486)</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Microtome&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">905200U/00016050</td>
			<td>Model: HM355S, Manufacturer: Microm, NON-CATALOG, Vendor Catalog # 905200U/00016050</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Formaldehyde, 37% Aqueous (Formalin)</td>
			<td style="width:191px;">Ricca Chemical</td>
			<td style="width:161px;">RSOF0010-500A</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Paraplast Xtra (paraffin wax)</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">15159-486</td>
			<td>Manufacturer: McCormick Scientific&#160;</td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:276px;">Petri Dishes Square 100x100x15mm</td>
			<td style="width:191px;">Laboratory Disposable Products&#160;</td>
			<td style="width:161px;">D210-16</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Potassium chloride&#160;</td>
			<td style="width:191px;">EMD Chemicals&#160;</td>
			<td style="width:161px;">PX1405-1</td>
			<td>Component of phosphate buffered saline, prepared in-house&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Potassium phosphate&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">P380-500</td>
			<td>Component of phosphate buffered saline, prepared in-house&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Razor Blades&#160;</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">55411-050</td>
			<td>Purchased from univeristy biostores&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Slide Warmer&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">NC0865259</td>
			<td>NON-CATALOG, Vendor Catalog # 12857D</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Sodium chloride&#160;</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">0241-1KG</td>
			<td>Component of phosphate buffered saline, prepared in-house&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Sodium phosphate&#160;</td>
			<td style="width:191px;">VWR</td>
			<td style="width:161px;">BDH9296.500</td>
			<td>,Component of phosphate buffered saline, prepared in-house&#160;</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Suprafrost Histology Slides&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">12-544-2</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Tissue Flotation Water Bath&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">NC0815797</td>
			<td>Manufacturer: Ted Pella, Vendor Catalog # 28156-B</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Automatic Tissue Processor&#160;</td>
			<td style="width:191px;">Fisher Scientific</td>
			<td style="width:161px;">813160U/Q#00009061</td>
			<td>Model: STP120 Tissue Processor</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Tryptone&#160;</td>
			<td style="width:191px;">Teknova&#160;</td>
			<td style="width:161px;">T9012</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:276px;">Yeast extract</td>
			<td style="width:191px;">Teknova&#160;</td>
			<td style="width:161px;">Y9010</td>
			<td></td>
		</tr>
	</tbody>
</table>

paraffin embedding and thin sectioning of microbial colony biofilms for microscopic analysis

Sectioning via paraffin embedding is a broadly established technique in eukaryotic systems. Here we provide a method for the fixation, embedding, and sectioning of intact microbial colony biofilms using perfused paraffin wax. To adapt this method for use on colony biofilms, we developed techniques for maintaining each sample on its growth substrate and laminating it with an agar overlayer, and added lysine to the fixative solution. These optimizations improve sample retention and preservation of micromorphological features. Samples prepared in this manner are amenable to thin sectioning and imaging by light, fluorescence, and transmission electron microscopy. We have applied this technique to colony biofilms of Pseudomonas aeruginosa, Pseudomonas synxantha, Bacillus subtilis, and Vibrio cholerae. The high level of detail visible in samples generated by this method, combined with reporter strain engineering or the use of specific dyes, can provide exciting insights into the physiology and development of microbial communities.

This method generates biofilm thin-sections wherein distinct morphological features and zones of gene expression can be imaged by DIC, fluorescence microscopy, and TEM. While DIC imaging using a 40X oil immersion objective can be sufficient to show some morphological features (Figure 2E), we have found that fluorescence microscopy of strains engineered to constitutively express fluorescent protein provides enhanced visualization of cell distribution within th...

Watch this Scientific Journal Video about Paraffin Embedding and Thin Sectioning of Microbial Colony Biofilms for Microscopic Analysis at JoVE.com

Paraffin Embedding and Thin Sectioning of Microbial Colony Biofilms for Microscopic Analysis

We describe fixation, paraffin embedding, and thin sectioning techniques for microbial colony biofilms. In prepared samples, biofilm substructure and reporter expression patterns can be visualized by microscopy.

Sectioning via paraffin embedding is a broadly established technique in eukaryotic systems. Here we provide a method for the fixation, embedding, and ...

The overall goal of this procedure is to generate paraffin embedded biofilm sections that can be used to assess the distribution of gene expression as reported by fluorescent protein production within intact native morphologies. This method can help answer key questions in the study of microbial communities such how the expression of specific genes in the production of exopolymeric substances distributed in the context of native biofilm architecture. The main advantage of this technique is that is allows for analysis of gene expression within the preserved morphology of biofilm cross-sections while also being amenable to downstream treatments such as staining of distinct features and high-resolution imaging such confocal or electron microscopy.After preparing agar tryptone solution according to the text protocol, use a 50-milliliter conical tube to pour 45 milliliters of the solution into a 100-millimeter by 100 millimeter square dish. Allow the agar to solidify for approximately 20 to 30 minutes. Pour a second 15-millimeter layer on top of the first layer, then let it solidify overnight, and if necessary, use a lint-free tissue to remove condensation from the lids.Next, to spot colony biofilms, after growing an isolated single P.Aeruginosa colony from a frozen stock according to the text protocol, pipette 2.5 to 10 microliters of cell suspension onto a medium bi-layer plate. Colonies may be incubated in the dark at 25 degrees Celsius in 80 to 100%relative humidity for up to four days. Gently pour 15 milliliters of the agar solution over the growth medium and colony and allow the agar to form a gel at room temperature for five minutes.Then, use a sharp razor blade to cut a square, three-layered chuck with the colony laminated between the top two layers. If preparing multiple samples, ensure that each chuck is cut to a comparable size. Gently remove any excess agar from the colony containing chuck.Then, wet the flat head of a spatula in PBS or water and gently insert it between the top and bottom layers of agar. Immediately transfer the laminated colony into an embedding cassette labeled with a chemical-resistant marking pen. Place the embedding cassette into a glass slide mailer containing previously prepared fixative.Process the samples. Use 1X PBS to wash them twice for one hour each. For best results, automate reagent homogenization using the low setting on the spin function of an automatic tissue processor.To embed the samples, fill a wax mold with molten paraffin wax heated to 55 degrees Celsius, then use a heated flat spatula to quickly transfer the infiltrated chuck from the embedding cassette into the wax mold ensuring that the chuck rests parallel to the base of the mold. Allow the wax to solidify overnight at four degrees Celsius. Samples molded in solid wax may be stored indefinitely at this temperature.Once the wax has solidified, excise the sample from the mold and use a razor blade to trim excess wax from around the sample. Leave some wax extending from one end of the sample that can be used to clamp it into the microtome. It is important to trim the wax-embedded sample such that its shape facilitates the collection of smooth linear ribbons.Small imperfections in trimming can produce artifacts in the ribbon and compromise the integrity of the section. Next, heat a water bath to 42 degrees Celsius. Then, clamp the sample into the microtome with the surface of the colony oriented perpendicularly to the edge of the blade.Trim the sample in 50-micrometer intervals until the desired plane of the colony has been reached from which sections will be collected using a microtome set to a sectioning velocity of 75 to 80 RPM and a clearance angle of six to 10 degrees. Cut a ribbon of the desired number of 10-micrometer-thick sections. Then, use a fine-tipped paint brush to detach the ribbon from the blade.Now, with forceps or a drop of water at the tip of a Pasteur pipette, gently transfer the ribbon to the water bath. Immediately insert a slide into the water bath and position it below the ribbon at a 45-degree angle. Touch the narrow edge of the ribbon to the slide just below the frosted label.The ribbon should adhere. Pull the slide out of the water bath and adjust the angle so it's perpendicular to the surface of the water allowing the ribbon to lay flat against the slide along its length. Avoid trapping excess water beneath the ribbon.Gently stand the slide onto an absorbent lint-free tissue wicking excess water from the section. Then, lay the slide on a paper towel and allow it to dry in the dark at room temperature overnight. Heat a leveled hot plate to 45 degrees Celsius and place the slide on the plate for 30 to 60 minutes.The wax will become semi-molten and flatten against the slide. Gently lift the slide from the hot plate and lay it flat onto a smooth level room temperature surface for approximately one minute until the wax solidifies. Ensure that the molten wax does not pull to either side of the slide.With the samples inside a glass slide mailer, de-wax the slides in four washes of clearing agent for five minutes each. Use a Buchner aspirator to remove solution between washes. Use 100%ethanol to wash the slides three times for one minute each.Then, after rehydrating the slides according to the text protocol, immediately mount the sections in a tris-buffered mounting medium and apply a coverslip. The overlay agar around the section does not react with the fixative, so it does not adhere to the chard slide. This agar can dislodge during rehydration and damage the section, so care should be taken not to agitate the solution during rehydration.Allow the mounting medium to polymerize at room temperature overnight. Once polymerized, use clear nail polish to seal the coverslip to the slide. Finally, store the sealed slides indefinitely in the dark at four degrees Celsius.While DIC imaging using a 40 times oil immersion objective can be sufficient to show some morphological features of biofilm thin sections, fluorescence microscopy of strains engineered to constitutively express fluorescent proteins provides enhanced visualization of cellular distribution within the samples. As shown in these panels, images of individual sections can stitched together to generate a cross-section of the entire colony and provides context for the localization of structural features within the overall morphology at the macroscopic level. Using a strain engineered to express fluorescent protein under the control of a specific promoter enables the visualization of the distribution of gene expression.In addition, colonies can be grown on medium containing dyes, or dyes can be added post-sectioning to stains'specific polysaccharides. Finally, samples can also be prepared and imaged at higher resolution using transmission electron microscopy as presented here. It's important when attempting this procedure to be mindful of the samples'vagility and of the potential to introduce fluorescent and structural artifacts either through fixation, sectioning or rehydration which may influence your interpretation of the data.This procedure allows for a quantitative image analysis such as correlating the expression profiles of fluorescent reporters with morphological features and the Z-axis of a biofilm. This protocol can be applied to diverse species of biofilm-forming microbes with medical and industrial significance such as Pseudomonas aeruginosa, Vibrio cholerae and Bacillus subtilis. After watching this video, you should have a good understanding of how to grow and prepare colony biofilms for sectioning via paraffin embedding.
