Funding for this work was supported primarily by start-up funds from Reed College to KLC, Helen Stafford Research Fellowship funds to OLH, and a Reed College Science Research Fellowship to YK. This project began in Steve Wilson&#39;s lab as a collaboration with HR, who was supported by a Wellcome Trust Studentship (2009-2014). We thank M&#225;t&#233; Varga, Steve Wilson, and other members of the Wilson lab for initial discussions about this project, and we especially thank Florencia Cavodeassi and Kate Edwards, who were the first to teach KLC how to mount embryos in agarose and perform zebrafish brain dissections. We also thank Greta Glover and Jay Ewing for help with assembling our tungsten needle-sharpening device.

The methods in this paper were conducted in accordance with guidelines and approval of the Institutional Animal Care and Use Committees of Reed College and University College London. See the Table of Materials for details about zebrafish strains used in this study.
1. Prepare materials and tools
<ol>
	<li>Make solutions.
	<ol>
		<li>Make embryo medium (E314) by diluting a 60x stock (300 mM NaCl, 10.2 mM KCl, 20 mM CaCl2-dih...

<ol>
	<li>Butler, A. B., Hodos, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optic+tectum.">Optic tectum.</a> Comparative Vertebrate Neuroanatomy: Evolution and Adaptation. , 311-340 (2005).</li><li>Cang, J., Feldheim, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Developmental+mechanisms+of+topographic+map+formation+and+alignment.">Developmental mechanisms of topographic map formation and alignment.</a> Annual Review of Neuroscience. 36 (1), 51-77 (2013).</li><li>Basso, M. A., Bickford, M. E., Cang, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Unraveling+circuits+of+visual+perception+and+cognition+through+the+superior+colliculus.">Unraveling circuits of visual perception and cognition through the superior colliculus.</a> Neuron. 109 (6), 918-937 (2021).</li><li>Burrill, J. D., Easter, S. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+the+retinofugal+projections+in+the+embryonic+and+larval+zebrafish+(Brachydanio+rerio).">Development of the retinofugal projections in the embryonic and larval zebrafish (Brachydanio rerio).</a> The Journal of Comparative Neurology. 346 (4), 583-600 (1994).</li><li>Regeneration in the goldfish visual system. Webvision: The Organization of the Retina and Visual System Available from: <a target="_blank" href="https://webvision.med.utah.edu/book/part-x-repair-and-regeneration-in-the-visual-system/regeneration-in-the-goldfish-visual-system/">https://webvision.med.utah.edu/book/part-x-repair-and-regeneration-in-the-visual-system/regeneration-in-the-goldfish-visual-system/</a> (2021)</li><li>Regeneration in the visual system of adult mammals. Webvision: The Organization of the Retina and Visual System Available from: <a target="_blank" href="https://webvision.med.utah.edu/book/part-x-repair-and-regeneration-in-the-visual-system/regeneration-in-the-visual-system-of-adult-mammals/">https://webvision.med.utah.edu/book/part-x-repair-and-regeneration-in-the-visual-system/regeneration-in-the-visual-system-of-adult-mammals/</a> (2021)</li><li>Cerveny, K. L., Varga, M., Wilson, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Continued+growth+and+circuit+building+in+the+anamniote+visual+system.">Continued growth and circuit building in the anamniote visual system.</a> Developmental Neurobiology. 72 (3), 328-345 (2012).</li><li>Lindsey, B. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Midbrain+tectal+stem+cells+display+diverse+regenerative+capacities+in+zebrafish.">Midbrain tectal stem cells display diverse regenerative capacities in zebrafish.</a> Scientific Reports. 9 (1), 4420 (2019).</li><li>Soares, D., Yamamoto, Y., Strickler, A. G., Jeffery, W. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+lens+has+a+specific+influence+on+optic+nerve+and+tectum+development+in+the+blind+cavefish+Astyanax.">The lens has a specific influence on optic nerve and tectum development in the blind cavefish Astyanax.</a> Developmental Neuroscience. 26 (5-6), 308-317 (2004).</li><li>White, E. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+experimental+study+of+the+relationship+between+the+size+of+the+eye+and+the+size+of+the+optic+tectum+in+the+brain+of+the+developing+teleost,+Fundulus+heteroclitus.">An experimental study of the relationship between the size of the eye and the size of the optic tectum in the brain of the developing teleost, Fundulus heteroclitus.</a> Journal of Experimental Zoology. 108 (3), 439-469 (1948).</li><li>Raymond, P., Easter, S., Burnham, J., Powers, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Postembryonic+growth+of+the+optic+tectum+in+goldfish.+II.+Modulation+of+cell+proliferation+by+retinal+fiber+input.">Postembryonic growth of the optic tectum in goldfish. II. Modulation of cell proliferation by retinal fiber input.</a> The Journal of Neuroscience. 3 (5), 1092-1099 (1983).</li><li>Sato, Y., Yano, H., Shimizu, Y., Tanaka, H., Ohshima, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optic+nerve+input-dependent+regulation+of+neural+stem+cell+proliferation+in+the+optic+tectum+of+adult+zebrafish.">Optic nerve input-dependent regulation of neural stem cell proliferation in the optic tectum of adult zebrafish.</a> Developmental Neurobiology. 77 (4), 474-482 (2017).</li><li>Hall, Z. J., Tropepe, V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Visual+experience+facilitates+BDNF-dependent+adaptive+recruitment+of+new+neurons+in+the+postembryonic+optic+tectum.">Visual experience facilitates BDNF-dependent adaptive recruitment of new neurons in the postembryonic optic tectum.</a> The Journal of Neuroscience. 38 (8), 2000-2014 (2018).</li><li>Nusslein-Volhard, C., Dahm, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Zebrafish. , (2002).</li><li>Cold Spring Harbor Protocols. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Marc's+modified+Ringer's+(MMR)+(10X,+pH+7.4).">Marc's modified Ringer's (MMR) (10X, pH 7.4).</a> Cold Spring Harbor Protocols. , (2009).</li><li>Turner, K. J., Bracewell, T. G., Hawkins, T. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Anatomical+dissection+of+zebrafish+brain+development.">Anatomical dissection of zebrafish brain development.</a> Brain Development. 1082, 197-214 (2014).</li><li>Brady, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+simple+technique+for+making+very+fine,+durable+dissecting+needles+by+sharpening+tungsten+wire+electrolytically.">A simple technique for making very fine, durable dissecting needles by sharpening tungsten wire electrolytically.</a> Bulletin of the World Health Organization. 32 (1), 143-144 (1965).</li><li>. ZFIN Tricaine recipe Available from: <a target="_blank" href="https://zfin.atlassian.net/wiki/spaces/prot/pages/362220023/TRICAINE">https://zfin.atlassian.net/wiki/spaces/prot/pages/362220023/TRICAINE</a> (2018)</li><li>Zhang, L., Leung, Y. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microdissection+of+zebrafish+embryonic+eye+tissues.">Microdissection of zebrafish embryonic eye tissues.</a> Journal of Visualized Experiments: JoVE. (40), e2028 (2010).</li><li>. ZFIN protocols Available from: <a target="_blank" href="https://zfin.atlassian.net/wiki/spaces/prot/overview">https://zfin.atlassian.net/wiki/spaces/prot/overview</a> (2021)</li><li>Engerer, P., Plucinska, G., Thong, R., Trov&#242;, L., Paquet, D., Godinho, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+subcellular+structures+in+the+living+zebrafish+embryo.">Imaging subcellular structures in the living zebrafish embryo.</a> Journal of Visualized Experiments: JoVE. (110), e53456 (2016).</li><li>ImageJ with batteries included. Fiji Available from: <a target="_blank" href="https://figi.sc/">https://figi.sc/</a> (2021)</li><li>O'Brien, J., Hayder, H., Peng, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Automated+quantification+and+analysis+of+cell+counting+procedures+using+ImageJ+plugins.">Automated quantification and analysis of cell counting procedures using ImageJ plugins.</a> Journal of Visualized Experiments: JoVE. (117), e54719 (2016).</li><li>Poggi, L., Vitorino, M., Masai, I., Harris, W. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Influences+on+neural+lineage+and+mode+of+division+in+the+zebrafish+retina+in+vivo.">Influences on neural lineage and mode of division in the zebrafish retina in vivo.</a> The Journal of Cell Biology. 171 (6), 991-999 (2005).</li><li>Karlstrom, R. O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Zebrafish+mutations+affecting+retinotectal+axon+pathfinding.">Zebrafish mutations affecting retinotectal axon pathfinding.</a> Development. 123 (1), 427-438 (1996).</li><li>Harvey, B. M., Baxter, M., Granato, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optic+nerve+regeneration+in+larval+zebrafish+exhibits+spontaneous+capacity+for+retinotopic+but+not+tectum+specific+axon+targeting.">Optic nerve regeneration in larval zebrafish exhibits spontaneous capacity for retinotopic but not tectum specific axon targeting.</a> PLOS ONE. 14 (6), 0218667 (2019).</li><li>Robles, E., Filosa, A., Baier, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Precise+lamination+of+retinal+axons+generates+multiple+parallel+input+pathways+in+the+tectum.">Precise lamination of retinal axons generates multiple parallel input pathways in the tectum.</a> Journal of Neuroscience. 33 (11), 5027-5039 (2013).</li><li>Vargas, M. E., Barres, B. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Why+Is+Wallerian+degeneration+in+the+CNS+so+slow.">Why Is Wallerian degeneration in the CNS so slow.</a> Annual Review of Neuroscience. 30 (1), 153-179 (2007).</li><li>Hughes, A. N., Appel, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microglia+phagocytose+myelin+sheaths+to+modify+developmental+myelination.">Microglia phagocytose myelin sheaths to modify developmental myelination.</a> Nature Neuroscience. 23 (9), 1055-1066 (2020).</li><li>de Calbiac, H., Dabacan, A., Muresan, R., Kabashi, E., Ciura, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Behavioral+and+physiological+analysis+in+a+zebrafish+model+of+epilepsy.">Behavioral and physiological analysis in a zebrafish model of epilepsy.</a> Journal of Visualized Experiments: JoVE. (176), e58837 (2021).</li><li>Adams, S. L., Zhang, T., Rawson, D. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+external+medium+composition+on+membrane+water+permeability+of+zebrafish+(Danio+rerio)+embryos.">The effect of external medium composition on membrane water permeability of zebrafish (Danio rerio) embryos.</a> Theriogenology. 64 (7), 1591-1602 (2005).</li><li>Fredj, N. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Synaptic+activity+and+activity-dependent+competition+regulates+axon+arbor+maturation,+growth+arrest,+and+territory+in+the+retinotectal+projection.">Synaptic activity and activity-dependent competition regulates axon arbor maturation, growth arrest, and territory in the retinotectal projection.</a> Journal of Neuroscience. 30 (32), 10939-10951 (2010).</li><li>Alberio, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+light-gated+potassium+channel+for+sustained+neuronal+inhibition.">A light-gated potassium channel for sustained neuronal inhibition.</a> Nature Methods. 15 (11), 969-976 (2018).</li><li>Kay, J. N., Finger-Baier, K. C., Roeser, T., Staub, W., Baier, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Retinal+ganglion+cell+genesis+requires+lakritz,+a+zebrafish+atonal+homolog.">Retinal ganglion cell genesis requires lakritz, a zebrafish atonal homolog.</a> Neuron. 30 (3), 725-736 (2001).</li><li>Gnuegge, L., Schmid, S., Neuhauss, S. C. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+the+activity-deprived+zebrafish+mutant+macho+reveals+an+essential+requirement+of+neuronal+activity+for+the+development+of+a+fine-grained+visuotopic+map.">Analysis of the activity-deprived zebrafish mutant macho reveals an essential requirement of neuronal activity for the development of a fine-grained visuotopic map.</a> The Journal of Neuroscience. 21 (10), 3542-3548 (2001).</li><li>Jeffery, W. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Astyanax+surface+and+cave+fish+morphs.">Astyanax surface and cave fish morphs.</a> EvoDevo. 11 (1), 14 (2020).</li><li>Sieger, D., Peri, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Animal+models+for+studying+microglia:+The+first,+the+popular,+and+the+new.">Animal models for studying microglia: The first, the popular, and the new.</a> Glia. 61 (1), 3-9 (2013).</li><li>Svahn, A. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+ramified+microglia+from+early+macrophages+in+the+zebrafish+optic+tectum.">Development of ramified microglia from early macrophages in the zebrafish optic tectum.</a> Developmental Neurobiology. 73 (1), 60-71 (2013).</li><li>Herzog, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+clearance+of+cellular+debris+by+microglia+limits+secondary+neuronal+cell+death+after+brain+injury+in+vivo.">Rapid clearance of cellular debris by microglia limits secondary neuronal cell death after brain injury in vivo.</a> Development. 146 (9), (2019).</li><li>Chen, J., Poskanzer, K. E., Freeman, M. R., Monk, K. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Live-imaging+of+astrocyte+morphogenesis+and+function+in+zebrafish+neural+circuits.">Live-imaging of astrocyte morphogenesis and function in zebrafish neural circuits.</a> Nature Neuroscience. 23 (10), 1297-1306 (2020).</li></ol>

The techniques described in this paper illustrate one of many approaches for studying vertebrate visual system development in zebrafish. Other researchers have published methods to dissect the embryonic retina and perform gene expression analyses19 or visualize neuronal activity in the optic tectum30. This paper provides an approach for exploring how differential retinal input may influence cell behaviors in the optic tectum.
To ensure successful...

The goal of this method is to investigate how retinal input influences the growth and development of the optic tectum, the visual processing center in the zebrafish brain. By removing one eye and then comparing the two sides of the optic tectum, tectal changes within the same specimen can be observed and normalized, enabling comparison across multiple specimens. Modern molecular approaches combined with this technique will yield insights into the mechanisms underlying visual system growth and development, as well as axonal degeneration and regeneration.
Sensory systems - visual, auditory, and somatosensory - gather information from external organs and relay that information to the central nervous system, generating &#34;maps&#34; of the external world across the midbrain1,2. Vision is the dominant sensory modality for nearly all vertebrates, including many fishes. The retina, the neural tissue in the eye, gathers information with a neuronal circuit consisting primarily of photoreceptors, bipolar cells, and retinal ganglion cells (RGCs), the projection neurons of the retina. RGCs have long axons that find their way across the inner surface of the retina to the optic nerve head, where they fasciculate and travel together through the brain, ultimately terminating in the visual processing center in the dorsal midbrain. This structure is called the optic tectum in fish and other non-mammalian vertebrates and is homologous to the superior colliculus in mammals3.
The optic tectum is a bilaterally symmetric multilayered structure in the dorsal midbrain. In zebrafish and most other fishes, each lobe of the optic tectum receives visual input solely from the contralateral eye, such that the left optic nerve terminates in the right tectal lobe and the right optic nerve terminates in the left tectal lobe4 (Figure 1). Like its mammalian counterpart, the superior colliculus, the optic tectum integrates visual information with other sensory inputs, including audition and somatosensation, controlling shifts in visual attention and eye movements such as saccades1,5,6. However, unlike the mammalian superior colliculus, the optic tectum continuously generates new neurons and glia from a specialized stem cell niche near the medial and caudal edges of the tectal lobes called the tectal proliferation zone7. Maintenance of proliferative progenitors in the optic tectum and other regions of the central nervous system contributes, in part, to the remarkable regenerative capacity documented in zebrafish8.
Previous work examining the brains of blind or one-eyed fishes revealed that optic tectum size is directly proportional to the amount of retinal innervation it receives9,10,11. In adult cave fish, whose eyes degenerate in early embryogenesis, the optic tectum is noticeably smaller than that of closely related, sighted surface fish9. Cave fish eye degeneration can be blocked by replacing the endogenous lens with a lens from a surface fish during embryogenesis. When these one-eyed cave fish are reared to adulthood, the innervated tectal lobe contains approximately 10% more cells than the non-innervated tectal lobe9. Similarly, in larval killifish that were incubated with chemical treatments to generate eyes of different sizes within the same individual, the side of the tectum with more innervation was larger and contained more neurons10. Evidence from optic nerve crush experiments in adult goldfish indicates that innervation promotes proliferation, with tectal cell proliferation decreasing when innervation was disrupted11.
Confirming and extending these classical studies, several recent reports provide data suggesting that proliferation in response to innervation is modulated, at least in part, by the BDNF-TrkB pathway12,13. Many open questions about optic tectum growth and development remain, including how a developing sensory system copes with injury and axon degeneration, which cellular and molecular signals enable retinal input to regulate optic tectum growth, when these mechanisms become active, and whether innervation-linked proliferation and differentiation enable the retina and its target tissue to coordinate growth rates and ensure accurate retinotopic mapping. In addition, there are much larger questions about activity-dependent development that can be addressed by interrogating the zebrafish visual system with surgical approaches such as the one described below.
To investigate the cellular and molecular mechanisms by which neural activity, specifically from visual input, alters cell survival and proliferation, the described approach directly compares innervated and denervated tectal lobes (Figure 1) within individual zebrafish larvae. This method allows for the documentation of RGC axon degeneration in the optic tectum and confirmation that the number of mitotic cells correlates with innervation.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/63509/63509fig01.jpg" />
Figure 1: Sketches of zebrafish larvae before and after unilateral eye removal. (A) Drawing of 5 dpf larvae as viewed under a dissecting microscope. Each larva is embedded in low-melting-point agarose and oriented laterally before a tungsten needle with a sharp, hooked tip is used to scoop out the eye facing up (left eye in this example). (B) Drawing of the dorsal view of a 9 dpf larva resulting from the surgery depicted in A. Only three highly schematized RGC axons from the right eye are shown defasciculating and connecting with neurons in the left tectal lobe. Abbreviations: dpf = days post fertilization; dps = days post surgery; RGC = retinal ganglion cells. <a href="https://www.jove.com/files/ftp_upload/63509/63509fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Equipment and supplies:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Breeding boxes</td>
			<td>Aquaneering</td>
			<td>ZHCT100</td>
			<td></td>
		</tr>
		<tr>
			<td>Dow Corning high vacuum grease</td>
			<td>Sigma or equivalent supplier</td>
			<td>Z273554</td>
			<td></td>
		</tr>
		<tr>
			<td>Erlenmeyer flasks (125 mL)</td>
			<td></td>
			<td></td>
			<td>For making Marc&#39;s Modified Ringers (MMR) with antibiotics for post-surgery incubation</td>
		</tr>
		<tr>
			<td>Fine forceps - Dumont #5</td>
			<td>Fine Science Tools (FST)</td>
			<td>11252-20</td>
			<td></td>
		</tr>
		<tr>
			<td>Glass Pasteur pipettes</td>
			<td>DWK Lifescience</td>
			<td>63A53 &#38; 63A53WT</td>
			<td>For pipetting embryos and larvae</td>
		</tr>
		<tr>
			<td>Glass slides for microscopy</td>
			<td>VWR or equivalent supplier</td>
			<td>48311-703</td>
			<td>Standard glass microscope slides can be ordered from many different laboratory suppliers.</td>
		</tr>
		<tr>
			<td>Glassware including graduated bottles and graduated cylinders</td>
			<td></td>
			<td></td>
			<td>For making and storing solutions</td>
		</tr>
		<tr>
			<td>2-part epoxy resin</td>
			<td>ACE Hardware or other equivalent supplier of Gorilla Glue or equivalent</td>
			<td>0.85 oz syringe</td>
			<td>https://www.acehardware.com/departments/paint-and-supplies/tape-glues-and-adhesives/glues-and-epoxy/1590793</td>
		</tr>
		<tr>
			<td>Microcentrifuge tube (1.7 mL)</td>
			<td>VWR or equivalent supplier</td>
			<td>22234-046</td>
			<td></td>
		</tr>
		<tr>
			<td>Nickel plated pin holder (17 cm length)</td>
			<td>Fine Science Tools (FST)</td>
			<td>26018-17</td>
			<td>To hold tungsten wire while sharpening and performing surgeries/dissections.</td>
		</tr>
		<tr>
			<td>Nylon mesh tea strainer or equivalent</td>
			<td>Ali Express or equivalent</td>
			<td></td>
			<td>For harvesting zebrafish eggs after spawning; https://www.aliexpress.com/item/1005002219569756.html</td>
		</tr>
		<tr>
			<td>Paper clip</td>
			<td></td>
			<td></td>
			<td>For Tungsten needle sharpening device.</td>
		</tr>
		<tr>
			<td>Petri dishes 100 mm</td>
			<td>Fischer Scientific or equivalent supplier</td>
			<td>50-190-0267</td>
			<td></td>
		</tr>
		<tr>
			<td>Petri dishes 35 mm</td>
			<td>Fischer Scientific or equivalent supplier</td>
			<td>08-757-100A</td>
			<td></td>
		</tr>
		<tr>
			<td>Pipette pump</td>
			<td>SP Bel-Art or equivalent</td>
			<td>F37898-0000</td>
			<td></td>
		</tr>
		<tr>
			<td>Potassium hydroxide (KOH)</td>
			<td>Sigma</td>
			<td>909122</td>
			<td>For Tungsten needle sharpening device. Make a 10% w/v solution of KOH in the hood by adding pellets to deionized water.</td>
		</tr>
		<tr>
			<td>Power supply (variable voltage)</td>
			<td></td>
			<td></td>
			<td>For Tungsten needle sharpening device. Any power supply with variable voltage will work (even one used for gel electrophoresis).</td>
		</tr>
		<tr>
			<td>Sylgard 184 Elastomer kit</td>
			<td>Dow Corning</td>
			<td>3097358</td>
			<td></td>
		</tr>
		<tr>
			<td>Tungsten wire (0.125 mm diameter)</td>
			<td>World Precision Instruments (WPI)</td>
			<td>TGW0515</td>
			<td>Sharpen to remove eye and dissect larvae.</td>
		</tr>
		<tr>
			<td>Variable temperature heat block</td>
			<td>The Lab Depot or equivalent supplier</td>
			<td>BSH1001 or BSH1002</td>
			<td>Set to 40-42 &#176;C ahead of experiments.</td>
		</tr>
		<tr>
			<td>Wide-mouth glass jar with lid (e.g., clean jam or salsa jar)</td>
			<td></td>
			<td></td>
			<td>For Tungsten needle sharpening device.</td>
		</tr>
		<tr>
			<td>Wires with alligator clip leads</td>
			<td></td>
			<td></td>
			<td>For Tungsten needle sharpening device.</td>
		</tr>
		<tr>
			<td>Microscopes:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Dissecting microscope</td>
			<td></td>
			<td></td>
			<td>Any type will work but having adjustable transmitted light on a mirrored base is preferred.</td>
		</tr>
		<tr>
			<td>Laser scanning confocal microscope</td>
			<td></td>
			<td></td>
			<td>High NA, 20-25x water dipping objective lens is recommended.
			Microscope control and image capture software (Elements) is used here but any confocal microscope will work.</td>
		</tr>
		<tr>
			<td>Reagents for surgeries and dissections:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Calcium chloride dihydrate</td>
			<td>Sigma</td>
			<td>C7902</td>
			<td>For Marc&#39;s Modified Ringers (MMR) and embryo medium (E3).</td>
		</tr>
		<tr>
			<td>HEPES</td>
			<td>Sigma</td>
			<td>H7006</td>
			<td>For Marc&#39;s Modified Ringers (MMR).</td>
		</tr>
		<tr>
			<td>Low melting point agarose</td>
			<td>Invitrogen</td>
			<td>16520-050</td>
			<td>Make 1% in embryo medium (E3) or Marc&#39;s Modified Ringers (MMR).</td>
		</tr>
		<tr>
			<td>Magnesium chloride hexahydrate</td>
			<td>Sigma</td>
			<td>1374248</td>
			<td>For embryo medium (E3).</td>
		</tr>
		<tr>
			<td>Magnesium sulfate</td>
			<td>Sigma</td>
			<td>M7506</td>
			<td>For Marc&#39;s Modified Ringers (MMR).</td>
		</tr>
		<tr>
			<td>Paraformaldehyde</td>
			<td>Electron Microscopy Sciences</td>
			<td>19210</td>
			<td>Dilute 8% (w/v) stock with 2x concentrated PBS (diluted from 10x PBS stock).</td>
		</tr>
		<tr>
			<td>Penicillin/Streptomycin</td>
			<td>Sigma</td>
			<td>P4333-20ML</td>
			<td>Dilute 1:100 in Marc&#39;s Modified Ringers.</td>
		</tr>
		<tr>
			<td>Phosphate buffered saline (PBS) tablets</td>
			<td>Diagnostic BioSystems</td>
			<td>DMR E404-01</td>
			<td>Make 10x stock in deionized water, autoclave and store at room temperature. Dilute to 1x working concentration.</td>
		</tr>
		<tr>
			<td>Potassium chloride</td>
			<td>Sigma</td>
			<td>P3911</td>
			<td>For Marc&#39;s Modified Ringers (MMR) and embryo medium (E3).</td>
		</tr>
		<tr>
			<td>Sodium chloride</td>
			<td>Sigma</td>
			<td>S9888</td>
			<td>For Marc&#39;s Modified Ringers (MMR) and embryo medium (E3).</td>
		</tr>
		<tr>
			<td>Sodium hydroxide</td>
			<td>Sigma</td>
			<td>S5881</td>
			<td>Make 10 M and use to adjust pH of MMR to 7.4.</td>
		</tr>
		<tr>
			<td>Sucrose</td>
			<td>Sigma</td>
			<td>S9378</td>
			<td></td>
		</tr>
		<tr>
			<td>Tricaine-S</td>
			<td>Pentair</td>
			<td>100G #TRS1</td>
			<td>Recipe: https://zfin.atlassian.net/wiki/spaces/prot/pages/362220023/TRICAINE</td>
		</tr>
		<tr>
			<td>Reagents for immunohistochemistry:</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Alexafluor 568 tagged Secondary antibody to detect rabbit IgG</td>
			<td>Invitrogen</td>
			<td>A-11011</td>
			<td>Use at 1:500 dilution for wholemount immunohistochemistry.</td>
		</tr>
		<tr>
			<td>DAPI or ToPro3</td>
			<td>Invitrogen</td>
			<td>1306 or T3605</td>
			<td>Make up 1 mg/mL solutions in DMSO; 1:5,000 dilution for counterstaining.</td>
		</tr>
		<tr>
			<td>Dimethyl sulfoxide (DMSO)</td>
			<td>Sigma</td>
			<td>D8418</td>
			<td>A component of immunoblock buffer.</td>
		</tr>
		<tr>
			<td>Methanol (MeOH)</td>
			<td>Sigma</td>
			<td>34860</td>
			<td>Mixing MeOH with aqueous solutions like PBST is exothermic. Make the MeOH/PBST solutions at least several hours ahead of time or cool them on ice before using.</td>
		</tr>
		<tr>
			<td>Normal goat serum</td>
			<td>ThermoFisher Scientific</td>
			<td>50-062Z</td>
			<td>A component of immunoblock buffer. Can be aliquoted in 1-10 mL volumes and stored at -20 &#176;C.</td>
		</tr>
		<tr>
			<td>Primary antibody to detect phosphohistone H3</td>
			<td>Millipore</td>
			<td>06-570</td>
			<td>Use at 1:300 dilution for wholemount immunohistochemistry.</td>
		</tr>
		<tr>
			<td>Primary antibody to detect Red Fluorescent Protein (RFP; detects dsRed derivatives)</td>
			<td>MBL International</td>
			<td>PM005</td>
			<td>Use at 1:500 dilution for wholemount immunohistochemistry.</td>
		</tr>
		<tr>
			<td>Proteinase K (PK)</td>
			<td>Sigma</td>
			<td>P2308-10MG</td>
			<td>Make up 10 mg/mL stock solutions in PBS and use at 10 &#181;g/mL.</td>
		</tr>
		<tr>
			<td>Triton X-100</td>
			<td>Sigma</td>
			<td>T8787</td>
			<td>Useful to make a 20% (v/v) stock solution in PBS.</td>
		</tr>
		<tr>
			<td>Software for data analysis</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>ImageJ (Fiji)</td>
			<td></td>
			<td></td>
			<td>freeware for image analysis; https://imagej.net/software/fiji/</td>
		</tr>
		<tr>
			<td>Rstudio</td>
			<td></td>
			<td></td>
			<td>freeware for statistical analysis and data visualization; https://www.rstudio.com/products/rstudio/download/</td>
		</tr>
		<tr>
			<td>Adobe Photoshop or GIMP</td>
			<td></td>
			<td></td>
			<td>Proprietary image processing software (Adobe Photoshop and Illustrator) are often used to compose figures). A freeware alternative is Gnu Image Manipulation Program (GIMP; https://www.gimp.org/)</td>
		</tr>
		<tr>
			<td>Zebrafish strains</td>
			<td></td>
			<td></td>
			<td>available from the&#160; Zebrafish International Resource Centers in the US (https://zebrafish.org/home/guide.php) or in Europe (https://www.ezrc.kit.edu/). Specialized transgenic strains that have not yet been deposited in either resource center can be requested from individual labs after publication.</td>
		</tr>
	</tbody>
</table>

eye removal in living zebrafish larvae to examine innervation-dependent growth and development of the visual system

Zebrafish exhibit remarkable life-long growth and regenerative abilities. For example, specialized stem cell niches established during embryogenesis support continuous growth of the entire visual system, both in the eye and the brain. Coordinated growth between the retinae and the optic tectum ensures accurate retinotopic mapping as new neurons are added in the eyes and brain. To address whether retinal axons provide crucial information for regulating tectal stem and progenitor cell behaviors such as survival, proliferation, and/or differentiation, it is necessary to be able to compare innervated and denervated tectal lobes within the same animal and across animals.
Surgical removal of one eye from living larval zebrafish followed by observation of the optic tectum achieves this goal. The accompanying video demonstrates how to anesthetize larvae, electrolytically sharpen tungsten needles, and use them to remove one eye. It next shows how to dissect brains from fixed zebrafish larvae. Finally, the video provides an overview of the protocol for immunohistochemistry and a demonstration of how to mount stained embryos in low-melting-point agarose for microscopy.

To confirm whether eye removal was complete and assess how the optic tectum changes, surgeries were performed in the Tg[atoh7:RFP] strain, which labels all RGCs with a membrane-targeted RFP and, thus, all axons that project from the retina and form the optic nerve24. Although using this strain is not absolutely necessary, it enables straightforward observation and visualization of the optic nerve termini in the optic tectum neuropil. Other approaches for labeling the optic nerve, such as ...
