Name: saturated fatty acids induce ceramide-associated macrophage cell death
Uploaded: 2017-10-31T15:00:00.000+00:00
Duration: 8 min 26 s
Description: Watch this Scientific Journal Video about Saturated Fatty Acids Induce Ceramide-associated Macrophage Cell Death at JoVE.com

This work was supported partially by the University of Louisville start-up funds and National Cancer Institute (Bethesda, MD) grants R01CA177679, R01CA180986.

The protocol was approved by the Institutional Animal Care and Use Committee (IACUC) of University of Louisville.
1. Mouse Bone Marrow Derived Macrophages (BMDMs)
<ol>
	<li>Euthanize a 6- to 8-week-old, healthy wild type mouse using CO2. Pin it down to a foam board and spray it with 70% ethanol until it is soaked. Remove the tibia/femur bones with forceps and scissors. Put them in a petri dish with 5 mL 1x phosphate-buffered saline (PBS). Perform all procedures under sterile conditions.</li>
	<li>Cut open both ends of the tibia/femur bone with a scissor in a sterile tissue culture hood. Flush the bone with a 25 G needle with PBS + 2% fetal bovine serum (FBS) into a 15 mL tube.</li>
	<li>Centrifuge the bone marrow cells at 500 x g, 4 &#176;C for 5 min.</li>
	<li>Resuspend the cell pellet in 1 mL red blood cell lysis buffer to lyse red blood cells (RBC) for less than 1 min. Dilute immediately with 9 mL 1x PBS. Centrifuge again as in step 1.3. Decant the supernatants.</li>
	<li>Resuspend the cell pellet in 10 mL 1x PBS, filter the cell suspension through a sterile 40 &#956;m&#160;nylon mesh into another 15 mL tube to remove cell debris/clumps. Centrifuge again as in 1.3. Decant the supernatants.</li>
	<li>Resuspend the cell pellet in 15 mL Roswell Park Memorial Institute medium (RPMI) 1640 with 5% FBS and 10 &#956;g/mL gentamicin, plate the cells in a 100-mm tissue culture dish at 37 oC incubator for 60 min. Gently swirl the dish, take out the floating cells, and count them.</li>
	<li>Plate 6x106 cells in a 100-mm dish with 12 mL macrophage differentiating media (RPMI 1640 with 5% FBS and 10 &#956;g/mL gentamicin, mixed with 30% L929 conditioned media10) with 10 ng/mL recombinant mouse macrophage colony-stimulating factor (M-CSF) for 2 days.</li>
	<li>After culturing for 2 days in a 37 &#176;C incubator with 5% CO2, feed each dish with 6 mL fresh macrophage differentiating media with 10 ng/mL M-CSF.</li>
	<li>On day 5, take 8 mL of the old media out without disturbing the cells and add 10 mL fresh macrophage differentiating media with 10 ng/mL M-CSF.</li>
	<li>On day 7, harvest the bone marrow-derived macrophages (BMDMs) using a cell lifter.
	NOTE: Attached macrophages can also be dissociated with 5 mL 1 mM EDTA in 1x PBS for 5 to 10 min after removing the float cells and washing plate twice with 5 mL 1x PBS. Centrifuge the cells as in step 1.3., resuspend them in fresh macrophage differentiating media, and count them with a hemocytometer.
	<ol>
		<li>Confirm the BMDMs&#39; phenotype by flow cytometry as described5. Prepare the derived mouse macrophages in a certain concentration for the following studies.</li>
	</ol>
	</li>
</ol>
2. BSA-fatty Acid Conjugate Preparation
<ol>
	<li>Prepare 2 mM BSA in sterile PBS. For example, weigh 6.65 g BSA, add 30 mL 1x PBS to dissolve, then add more PBS until 50 mL, scaling components to make 2 mM BSA in 1x PBS.</li>
	<li>Prepare 5 mM individual sodium salt of fatty acids in 2 mM BSA. Heat to 37 &#176;C or higher, if necessary, and sonicate the mixture of 2 mM BSA and sodium salt of fatty acids until a clear solution is obtained.
	NOTE: Compared to unsaturated fatty acids, saturated fatty acids need a higher temperature and more sonication time for dissolving.</li>
	<li>Filter the fatty-acid-BSA solution through a 0.22 &#956;m filter, aliquot it into 1.5 mL sterile microcentrifuge tubes, and store them at 4 &#176;C for short term use or at -20 &#176;C for long term storage. No precipitation should be observed after storage at 4 &#176;C in the refrigerator.</li>
</ol>
3. Saturated Fatty Acids Induce Cell Death of Mouse Bone Marrow Derived Macrophages
<ol>
	<li>Plate the BMDMs in a 24-well tissue culture plate with 0.4 x 106/mL in macrophage differentiating media.</li>
	<li>Treat the cells with the 0.4 mM palmitic acid and stearic acid for 16 to 24 h at a 37 &#176;C incubator with 5% CO2. Use BSA as the negative control.</li>
	<li>Harvest the cells with a cell lifter after treatment and spin down the cells at 500 x g, 4 &#176;C for 5 min.</li>
	<li>Stain the cells with Annexin V-Alexa 488 and 7-aminoactinomycin D (7-AAD) in 100 &#956;L annexin V binding buffer for 15 min at room temperature.</li>
	<li>Dilute the sample with 200 &#181;L of annexin-binding buffer, mix gently, then keep the samples on ice after the incubation period.</li>
	<li>Analyze the stained cells as soon as possible by flow cytometry5. Annexin V-Alexa 488 is detected in FITC channel and 7-AAD is detected in PerCP/PerCP-Cy5.5 channel.</li>
</ol>
4. Intracellular Ceramide Staining
<ol>
	<li>After fatty acid treatment, harvest the cells as in step 3.3. Then fix the cells in 4% paraformaldehyde for 30 min.</li>
	<li>Wash the sample with 1 mL 1x PBS, spin down as step in 3.3, and decant the supernatant.</li>
	<li>Stain the cells with anti-ceramide primary antibody (1:200 dilution) in 100 &#956;L 1x permeabilization buffer for 30 min.</li>
	<li>Wash and spin down the cells again as in step 4.2.</li>
	<li>Stain the cells with anti-mouse IgM secondary antibody (1:500 dilution) in 100 &#956;L 1x permeabilization buffer for 30 min.</li>
	<li>Wash and spin down the cells again as in step 4.2. Add 250 &#956;L 1x PBS and analyze the stained cells by flow cytometry5.
	NOTE: See the detailed reagent list in the Table of equipment and reagents.</li>
</ol>

<ol>
	<li>Martins de Lima, T., Cury-Boaventura, M. F., Giannocco, G., Nunes, M. T., Curi, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparative+toxicity+of+fatty+acids+on+a+macrophage+cell+line+(J774).">Comparative toxicity of fatty acids on a macrophage cell line (J774).</a> Clin Sci (Lond). 111 (5), 307-317 (2006).</li><li>Simard, J. R., Zunszain, P. A., Hamilton, J. A., Curry, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Location+of+high+and+low+affinity+fatty+acid+binding+sites+on+human+serum+albumin+revealed+by+NMR+drug-competition+analysis.">Location of high and low affinity fatty acid binding sites on human serum albumin revealed by NMR drug-competition analysis.</a> J Mol Biol. 361 (2), 336-351 (2006).</li><li>Penn, A. H., Dubick, M. A., Torres Filho, I. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fatty+Acid+Saturation+of+Albumin+Used+in+Resuscitation+Fluids+Modulates+Cell+Damage+in+Shock:+In+Vitro+Results+Using+a+Novel+Technique+to+Measure+Fatty+Acid+Binding+Capacity.">Fatty Acid Saturation of Albumin Used in Resuscitation Fluids Modulates Cell Damage in Shock: In Vitro Results Using a Novel Technique to Measure Fatty Acid Binding Capacity.</a> Shock. , (2017).</li><li>Vusse, G. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Albumin+as+fatty+acid+transporter.">Albumin as fatty acid transporter.</a> Drug Metab Pharmacokinet. 24 (4), 300-307 (2009).</li><li>Zhang, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Adipose+Fatty+Acid+Binding+Protein+Promotes+Saturated+Fatty+Acid-Induced+Macrophage+Cell+Death+through+Enhancing+Ceramide+Production.">Adipose Fatty Acid Binding Protein Promotes Saturated Fatty Acid-Induced Macrophage Cell Death through Enhancing Ceramide Production.</a> J Immunol. 198 (2), 798-807 (2017).</li><li>Zhang, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Epidermal+Fatty+Acid+binding+protein+promotes+skin+inflammation+induced+by+high-fat+diet.">Epidermal Fatty Acid binding protein promotes skin inflammation induced by high-fat diet.</a> Immunity. 42 (5), 953-964 (2015).</li><li>Wen, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fatty+acid-induced+NLRP3-ASC+inflammasome+activation+interferes+with+insulin+signaling.">Fatty acid-induced NLRP3-ASC inflammasome activation interferes with insulin signaling.</a> Nat Immunol. 12 (5), 408-415 (2011).</li><li>Zhang, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fatty+acid-binding+protein+E-FABP+restricts+tumor+growth+by+promoting+IFN-beta+responses+in+tumor-associated+macrophages.">Fatty acid-binding protein E-FABP restricts tumor growth by promoting IFN-beta responses in tumor-associated macrophages.</a> Cancer Res. 74 (11), 2986-2998 (2014).</li><li>Ulloth, J. E., Casiano, C. A., De Leon, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Palmitic+and+stearic+fatty+acids+induce+caspase-dependent+and+-independent+cell+death+in+nerve+growth+factor+differentiated+PC12+cells.">Palmitic and stearic fatty acids induce caspase-dependent and -independent cell death in nerve growth factor differentiated PC12 cells.</a> J Neurochem. 84 (4), 655-668 (2003).</li><li>Weischenfeldt, J., Porse, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bone+Marrow-Derived+Macrophages+(BMM):+Isolation+and+Applications.">Bone Marrow-Derived Macrophages (BMM): Isolation and Applications.</a> CSH Protoc. , (2008).</li><li>Dansen, T. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-affinity+binding+of+very-long-chain+fatty+acyl-CoA+esters+to+the+peroxisomal+non-specific+lipid-transfer+protein+(sterol+carrier+protein-2).">High-affinity binding of very-long-chain fatty acyl-CoA esters to the peroxisomal non-specific lipid-transfer protein (sterol carrier protein-2).</a> Biochem J. 339 (Pt 1), 193-199 (1999).</li><li>Ulloth, J. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+methyl-beta-cyclodextrin+toxicity+in+NGF-differentiated+PC12+cell+death.">Characterization of methyl-beta-cyclodextrin toxicity in NGF-differentiated PC12 cell death.</a> Neurotoxicology. 28 (3), 613-621 (2007).</li></ol>

The authors declare no financial conflicts of interest.

The proper preparation of fatty acid solution is of critical importance to study the biological function of fatty acids. The neutralization of fatty acid increases its solubility in aqueous solution. However, sodium salts of fatty acids, especially saturated fatty acids, are still of low solubility in water or PBS as we observed. One method is to use 95 - 100% ethanol to help dissolve fatty acid1. Using this method, higher toxicity to cells may be observed even at lower concentrations for less tox...

Fatty acids play a critical role in energy metabolism and in the synthesis of membrane phospholipids in different kinds of cells. Fatty acids have a low aqueous solubility. Appropriate preparation of fatty acid is of critical importance for studying the biological functions of fatty acids in mammalian cells. When fatty acids are prepared with ethanol, many fatty acids may show their toxic soap (detergent) effect on the cell membrane, even at relatively low concentrations1. As a natural, major transporter for free fatty acids in the serum, serum albumin is considered a good carrier for fatty acid delivery in vitro for fatty acid function assays2,3,4. However, the details of the preparation of fatty acid and serum albumin conjugate are usually not available even though many research papers using fatty acids have been published.
Macrophages highly express epidermal fatty acid-binding protein and adipose fatty acid-binding protein5,6,7,8. They actively uptake saturated and unsaturated fatty acids which may regulate their immune functions. To study the impact of fatty acids on macrophages and other cells, different methods of fatty acid preparation were applied1,7,9. Using appropriately prepared fatty acid/serum albumin conjugates to investigate the impact of fatty acids on macrophage function is of critical importance in obtaining biologically meaningful data. Studies on the impact of fatty acids on macrophage function can provide basic knowledge and potential therapeutic targets relating to fatty acid metabolism in macrophage-involved diseases.

<table><tbody><tr><td>CPX Ultrasonic Bath&amp;nbsp;</td><td>Bransonic</td><td>Model 2800</td><td></td></tr><tr><td>Sodium palmitate (PA)</td><td>Nu-Chek Prep, Inc.</td><td>S-1109</td><td>M.W. 278</td></tr><tr><td>Sodium stearate (SA)</td><td>Nu-Chek Prep, Inc.</td><td>S-1111</td><td>M.W. 306</td></tr><tr><td>Bovine serum albumin (BSA), fatty acid-free</td><td>Fisher Scientific</td><td>9048-46-8</td><td></td></tr><tr><td>Mouse macrophage colony stimulating factor (mM-CSF)&amp;nbsp;</td><td>Cell Signaling Technology,&amp;nbsp; Inc.</td><td>5228</td><td></td></tr><tr><td>RPMI 1640</td><td>VWR International</td><td>71002-878</td><td></td></tr><tr><td>Annexin V, Alexa Fluor 488 conjugate</td><td>Fisher Scientific</td><td>A13201</td><td></td></tr><tr><td>7-AAD</td><td>BD Biosciences</td><td>559925</td><td></td></tr><tr><td>Monoclonal anti-ceramide antibody (mouse IgM)</td><td>Sigma</td><td>C8104-50TST</td><td>Clone: MID 15B4</td></tr><tr><td>Goat Anti-Mouse IgM Antibody, &amp;micro; chain, FITC conjugate</td><td>Sigma</td><td>AP128F</td><td></td></tr><tr><td>Fixation buffer</td><td>Biolegend</td><td>420801</td><td></td></tr><tr><td>Permeabilization buffer</td><td>Ebioscience</td><td>4307693</td><td></td></tr><tr><td>Red Blood Cell Lysis Buffer&amp;nbsp;</td><td>Sigma</td><td>11814389001</td><td></td></tr><tr><td>Annexin V Binding Buffer</td><td>BD Biosciences</td><td>556454</td><td></td></tr><tr><td>L929 cells</td><td>ATCC</td><td>CCL-1</td><td></td></tr><tr><td>Corning&amp;nbsp;Cell Lifter&amp;nbsp;</td><td>Fisher Scientific</td><td>07-200-364</td><td></td></tr><tr><td>Note: M.W. is for molecular weight.</td><td></td><td></td><td></td></tr></tbody></table>
