1. Fabrication of the transfer tool and drain chamber system
<ol>
	<li>Attached (Supplementary Files 1, 2) is the engineering drawing for the drain chamber assembly consisting of two parts: top and bottom. Model this device according to the specifications of the desired system (e.g., the outer diameter of the receiving substrate) and export as an STL file for 3D printing.</li>
	<li>For the top part, utilize a filament printer of choice and print in the lowest resolution possible, including scaffolding wherever necessary. Adhere to the recommended parameters of the printer. It is also recommended that the top part be printed using poly(lactic acid) (PLA) to minimize material shedding.</li>
	<li>For the bottom part, use an inkjet resin printer or filament printer with a build height as fine as 20 &#181;m.
	NOTE: PLA is a suitable material which minimizes material shedding.</li>
	<li>Scrub and clean both parts with deionized water, ensuring the removal of any potential shedding material from the printing process. Sonication in deionized water is also recommended. Test the threading on the two parts to ensure a good fit.</li>
	<li>Complete the drain chamber with a size 117 neoprene O-ring and tubing of the parameters specified in the supporting documents (Supplementary Files 1, 2). A schematic of the entire drain chamber assembly is shown in Figure 1.</li>
	<li>Print the transfer tool using any filament printer at medium to fine resolution. There are two parts: clamp and loading arm.
	NOTE: It is highly recommended that the transfer tool be printed using poly(lactic acid) (PLA), as other plastics can be poorly wetted and cause the wafer to become wet unexpectedly.</li>
	<li>Complete the clamp with a size 10 screw and then attach the clamp onto a laboratory jack.</li>
</ol>
2. Initial mechanized deposition and membrane lift-off from donor substrate
<ol>
	<li>Place a bare 25 mm-diameter AAO disc (or any arbitrary porous receiver substrate of choice) onto the bottom part of the drain chamber. Then, place the neoprene O-ring on top of the AAO disc and screw on the top part of the drain chamber.</li>
	<li>Rinse and/or sonicate the setup various times with deionized (DI) water. This helps to remove any dust and/or any remaining particulates from 3D printing.</li>
	<li>Place the piece of Si wafer with the transferable polymer stack (donor wafer) onto the lip of the transfer tool loading arm.</li>
	<li>Fill the drain chamber with 25 mL of DI water.</li>
	<li>Lower the laboratory jack so that the tool is dipped slowly into the entrance ramp of the drain chamber and that the donor silicon substrate is slowly submerged. Ensure that the wafer is submerged sufficiently for the membrane to completely delaminate and lift-off from the underlying donor substrate.
	NOTE: Using a piece of Si wafer with no dust contamination will ensure easy separation from the donor substrate.</li>
	<li>Slowly raise the transfer tool out of the water and move it out of the way, making sure not to disturb the floating membrane.</li>
	<li>Coax the membrane into the opening of the chamber with tweezers. Placing the tweezer in water in front of membrane will guide it due to surface tension. Touching the floating membrane itself is not necessary and should be avoided.</li>
</ol>
3. Meniscus-guided transfer to receiver substrate with the drain chamber system
<ol>
	<li>Connect tubing to the outlet of the bottom part of the drain chamber. Attach this tubing to a 20 mL Luer-lock syringe.</li>
	<li>Obtain a syringe pump with withdrawing functionality. Place the syringe onto the pump and withdraw water at a rate of 1-2.5 mL/min until all the water has been drained out.</li>
	<li>After 10 min, the water should be completely removed from the drain chamber. If there is still any residual water within the chamber, reconnect the syringe and tubing and continue to withdraw any residual water.</li>
	<li>After complete drainage of the water, the membrane will now be placed at the center of the receiver substrate. Disconnect the drain chamber from the syringe pump and disassemble the drain chamber to remove the receiver substrate containing the membrane.
	NOTE: The total process including set-up takes ~15 min. Reducing the working volume of water and increasing the drain rate can shorten this process.</li>
	<li>Allow the sample to dry completely at room temperature before further use in any application.</li>
</ol>
