1. Pre-processing of materials
NOTE: Ni-foam (commercially available, see Table of Materials) with 25 mm x 25 mm x 1.5 mm is used for the H2O2 FC&#39;s anode.
<ol>
	<li>Immerse the Ni-foam sample into alcohol and deionized (DI) water, sonicate for three times, 5 min in solvent and water. Subsequently, place the Ni-foam on a clean glass substrate.</li>
	<li>Utilize the carbon fiber cloth (see Table of Materials) as the cathode substrate. Cut the carbon cloth into 25 mm x 25 mm square pieces using scissors.</li>
	<li>Immerse the carbon cloth sample into acetone, 75% alcohol, DI water, and sonicate three times for 5 min, respectively. Then, flush the carbon cloth with DI water to remove residues of alcohol. Place the carbon cloth on a glass substrate.
	&#8203;NOTE: Based on the discussed research results15,16, Au as the cathode and Ni as the anode have been chosen as catalysts for H2O2 FCs. Metals like Pt, Pd, Ni, Au, and Ag have specific catalytical selectivity towards H2O2 oxidation or reduction reaction, making them suitable electrode materials. The Au@carbon fiber electrode offers a combination of electrocatalytic activity, stability, and enhanced conductivity, making it a suitable choice for membraneless hydrogen peroxide fuel cells.</li>
</ol>
2. Electroplating of Au on a carbon cloth
<ol>
	<li>Prepare reagents for electroplating as given by the following: chloroauric acid (HAuCl4), potassium chloride (KCl), hydrochloric acid (HCl), and DI water (see Table of Materials).</li>
	<li>Prepare 80 mL solutions (based on the volume of the beaker) in a clean beaker with 0.005 M HAuCl4, 0.1 M KCl, and 0.01 M HCl. Seal the opening and stir the solution for 15 min.</li>
	<li>Prepare the electroplating material carbon cloth, and the plating solution. The electroplating process is run by Electrochemical Station (ES) (see Table of Materials).
	NOTE: Three electrode method is selected here for plating: carbon cloth as the Working Electrode (WE), graphite rod as the Counter Electrode (CE), and Ag/AgCl (saturated 1 M KCl solution) as the Reference Electrode (RE).</li>
	<li>Ensure each electrode is clamping the correct object. Immerse electrodes into the plating solution.</li>
	<li>Start the ES. Set the program to the Chronoamperometry Method, as shown in Figure 1C. Ensure a single depositing circle is as follows: working potential 0.1 V for 0.1 s and resting potential 0.2 V for 0.2 s. As the result, the AuCl4- ion diffuses uniformly around the WE.
	<ol>
		<li>Set Electroplating Circles at 800, 1600, 2400, and 3200 circles. Run the program.
		NOTE: Typically, the Chronoamperometry method program in ES cannot achieve 1600 cycles. Alternatively, Multi-Potential Steps program of ES can also be used for the electroplating method, the same selections as the Chronoamperometry method (see manufacturer&#39;s instructions).</li>
	</ol>
	</li>
	<li>After electroplating, close the ES, pack the reagents, and collect Au electroplated carbon fiber cloth (Au@CF).</li>
	<li>Immerse the Au@CF into the DI water three times to remove the solution residues. Place it on a glass substrate for drying in the air.</li>
	<li>Cut the un-plated part of the Au@CF caused by the clamps to prevent part of CF from contacting solutions.</li>
	<li>Measure the size of Au@CF (a: length, b: width) with a ruler for calculating current/power densities.</li>
</ol>
3. Performance characterization of an FC
<ol>
	<li>Prepare solutions with two concentrations, one solution for pH gradient (1 mol H2O2, pH = 1, 3, 5, 7, 9, 11, 13), while the other one for H2O2 (CHP) gradient (pH = 1, CHP = 0.25 mol, 0.5 mol, 1 mol, 2 mol).</li>
	<li>Characterize the FC performance by ES with two electrodes for OCP and three electrodes for the polarization and power output curves (steps 3.3-3.6).</li>
	<li>Re-wash Ni-foam and Au@CF again with DI water two times. Place them aside for standby.</li>
	<li>Obtain OCP data during the testing of an FC: OCP is an essential parameter in the FC performance.
	<ol>
		<li>Use Ni-foam as both RE and CE, and Au@CF as WE. Add the solution to the test beaker. Connect electrodes to the ES. Turn on the ES.</li>
		<li>Set the program to Open Circuit Potential - Time Method; Run Time: 400 s, Sample Interval: 0.1 s, High E Limit: 1 V, Low E Limit: -1 V. Run the program.
		NOTE: It often takes time for the FC output to stabilize. Run measurements until stable FC results are obtained.</li>
		<li>Measure the data. Close the program. Wash the beaker and electrodes. Add other solutions for specific tests.</li>
	</ol>
	</li>
	<li>Test output performance of FC based on OCP data. Here, only original Linear Sweep Voltammetry (LSV) curve data is required. Further output data can be calculated from the LSV curve.
	<ol>
		<li>Re-wash Ni-foam and Au@CF with DI water (repeat two times). Use Ni-foam as RE and CE, Au@CF as WE. Add the solution to the test beaker.</li>
		<li>Set the program to LSV, OCP as Initial E, 0 V as Final E, scan rate as 0.01 V/s, corresponding to the conditions of open circuit (OCP) and short circuit (0 V). Run the program.</li>
		<li>Collect the data, close the program, wash the beaker and electrodes, and add other required solutions for specific tests.</li>
	</ol>
	</li>
	<li>Wash the electrodes after experiments and store them on a glass.
	&#8203;NOTE: Experiment data can be stored in EXCEL format.</li>
</ol>
4. Structural characterization of electrodes
NOTE: XRD is a facile and reliable method to analyze samples. XRD is taken to detect elements of the electrodes, such as electroplated Au on the carbon cloth. XRD tests are done before and after FC characterization to analyze potential corrosion and degradation of electrodes. For example, Au particles&#39; can detach from CF, and nickel corrosion may occur in acidic solutions5.
<ol>
	<li>Wash the electrodes with DI water (two times) and dry them in the air at room temperature.</li>
	<li>Scrape off metals on the electrodes with tweezers. Collect the metal powder and place it in a container.</li>
	<li>Perform XRD tests17on the metal powder samples.</li>
	<li>Take SEM to characterize the morphology of the electrodes and investigate infiltration and electroplating between the gold and carbon fiber cloth. In addition, characterize the corrosion of nickel by SEM.</li>
</ol>
5. Data processing and power output calculation
<ol>
	<li>All data can be analyzed in EXCEL. Use Excel or Origin to analyze data and plot experimental graphs.</li>
	<li>Use the OCP data to characterize the selectivity of electrodes, e.g., using a table or a line figure. Use average potential for table legends. Typically, a line figure is used to demonstrate the stability of the FC.</li>
	<li>Use the LSV data to characterize the output performance of FC. There are two columns of data in the EXCEL file. Typically, one data set shows potential (U), and the other is recorded current (I). Calculate the power output using the following equation: P = U&#160;&#215;&#160;I
	NOTE: A high current (I) value shows a satisfactory performance of the FC. For example, a large electrode surface area results in higher currents. A normalized parameter referred to FCs&#39; performance is current density (ID), which is equal to the current divided by the surface area (A) of the electrodes: ID = I/A</li>
	<li>Subsequently, calculate the power density (PD) as: PD = U&#160;&#215; ID
	NOTE:It is essential to take the absolute value, as preliminary data values may be negative due to the direction of the current, which is not desirable during measurements.</li>
	<li>Comparing parameters using U, ID, and PD within a single figure is straightforward. Assign ID to the x-axis, U to the left y-axis, and PD to the right y-axis.</li>
</ol>

Exploring Innovative 3D Electrodes for Hydrogen Peroxide Fuel Cells

<ol>
	<li>Sazali, N., Wan Salleh, W. N., Jamaludin, A. S., Mhd Razali, M. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=New+perspectives+on+fuel+cell+technology:+A+brief+review.">New perspectives on fuel cell technology: A brief review.</a> Membranes. 10 (5), 99 (2020).</li><li>Singla, M. K., Nijhawan, P., Oberoi, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hydrogen+fuel+and+fuel+cell+technology+for+cleaner+future:+a+review.">Hydrogen fuel and fuel cell technology for cleaner future: a review.</a> Environmental Science and Pollution Research International. 28 (13), 15607-15626 (2021).</li><li>Cao, D., Chen, D., Lan, J., Wang, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+alkaline+direct+NaBH4-H2O2+fuel+cell+with+high+power+density.">An alkaline direct NaBH4-H2O2 fuel cell with high power density.</a> Journal of Power Sources. 190 (2), 346-350 (2009).</li><li>Lan, R., Tao, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ammonia+as+a+suitable+fuel+for+fuel+cells.">Ammonia as a suitable fuel for fuel cells.</a> Frontiers in Energy Research. 2, 2014 (2014).</li><li>Alias, M. S., Kamarudin, S. K., Zainoodin, A. M., Masdar, M. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Active+direct+methanol+fuel+cell:+An+overview.">Active direct methanol fuel cell: An overview.</a> International Journal of Hydrogen Energy. 45 (38), 19620-19641 (2020).</li><li>Ferrigno, R., Stroock, A. D., Clark, T. D., Mayer, M., Whitesides, G. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membraneless+vanadium+redox+fuel+cell+using+laminar+flow.">Membraneless vanadium redox fuel cell using laminar flow.</a> Journal of the American Chemical Society. 124 (44), 12930-12931 (2002).</li><li>Yan, X., Xu, A., Zeng, L., Gao, P., Zhao, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+paper-based+microfluidic+fuel+cell+with+hydrogen+peroxide+as+fuel+and+oxidant.">A paper-based microfluidic fuel cell with hydrogen peroxide as fuel and oxidant.</a> Energy Technology. 6 (1), 140-143 (2018).</li><li>Ha, S. M., Ahn, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Laminar+flow-based+micro+fuel+cell+utilizing+grooved+electrode+surface.">Laminar flow-based micro fuel cell utilizing grooved electrode surface.</a> Journal of Power Sources. 267, 731-738 (2014).</li><li>Liu, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+woven+thread-based+microfluidic+fuel+cell+with+graphite+rod+electrodes.">A woven thread-based microfluidic fuel cell with graphite rod electrodes.</a> International Journal of Hydrogen Energy. 43 (49), 22467-22473 (2018).</li><li>Peng, J., Zhang, Z. Y., Niu, H. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Three-dimensional+two-phase+model+for+a+membraneless+fuel+cell+using+decomposition+of+hydrogen+peroxide+with+y-shaped+microchannel.">A Three-dimensional two-phase model for a membraneless fuel cell using decomposition of hydrogen peroxide with y-shaped microchannel.</a> Fuel Cells. 12 (6), 1009-1018 (2012).</li><li>Wu, K. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly+selective+hydrogen+peroxide+electrosynthesis+on+carbon:+in+situ+interface+engineering+with+surfactants.">Highly selective hydrogen peroxide electrosynthesis on carbon: in situ interface engineering with surfactants.</a> Chem. 6 (6), 1443-1458 (2020).</li><li>Yang, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+facile+microfluidic+hydrogen+peroxide+fuel+cell+with+high+performance:+electrode+interface+and+power-generation+properties.">A facile microfluidic hydrogen peroxide fuel cell with high performance: electrode interface and power-generation properties.</a> ACS Applied Energy Materials. 1 (10), 5328-5335 (2018).</li><li>An, L., Zhao, T., Yan, X., Zhou, X., Tan, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+dual+role+of+hydrogen+peroxide+in+fuel+cells.">The dual role of hydrogen peroxide in fuel cells.</a> Science Bulletin. 60 (1), 55-64 (2015).</li><li>Yamazaki, S. I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+fuel+cell+with+selective+electrocatalysts+using+hydrogen+peroxide+as+both+an+electron+acceptor+and+a+fuel.">A fuel cell with selective electrocatalysts using hydrogen peroxide as both an electron acceptor and a fuel.</a> Journal of Power Sources. 178 (1), 20-25 (2008).</li><li>Sanli, A. E., Ayta&#231;, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Response+to+Disselkamp:+Direct+peroxide/peroxide+fuel+cell+as+a+novel+type+fuel+cell.">Response to Disselkamp: Direct peroxide/peroxide fuel cell as a novel type fuel cell.</a> International Journal of Hydrogen Energy. 36 (1), 869-875 (2011).</li><li>Gu, L., Nie, L., George H, M. i. l. e. y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cathode+electrocatalyst+selection+and+deposition+for+a+direct+borohydride/hydrogen+peroxide+fuel+cell.">Cathode electrocatalyst selection and deposition for a direct borohydride/hydrogen peroxide fuel cell.</a> Journal of Power Sources. 173 (1), 77-85 (2007).</li><li>Yang, F., Cheng, K., Wu, T., Zhang, Y., Yin, J., Wang, G., Cao, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+of+Au+nanodendrites+supported+on+carbon+fiber+cloth+and+its+catalytic+performance+to+H2O2+electroreduction+and+electrooxidation.">Preparation of Au nanodendrites supported on carbon fiber cloth and its catalytic performance to H2O2 electroreduction and electrooxidation.</a> RSC Advances. 3 (16), 5483-5490 (2013).</li><li>Vidal-Iglesias, F. J., Solla-Gull&#243;n, J., Herrero, E., Rodes, A., Aldaz, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Do+you+really+understand+the+electrochemical+Nernst+equation.">Do you really understand the electrochemical Nernst equation.</a> Electrocatalysis. 4, 1-9 (2013).</li><li>Jing, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+open+circuit+potential+of+hydrogen+peroxide+at+noble+and+glassy+carbon+electrodes+in+acidic+and+basic+electrolytes.">The open circuit potential of hydrogen peroxide at noble and glassy carbon electrodes in acidic and basic electrolytes.</a> Journal of Electroanalytical Chemistry. 658 (1-2), 46-51 (2011).</li><li>Eaves, S., Eaves, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+cost+comparison+of+fuel-cell+and+battery+electric+vehicles.">A cost comparison of fuel-cell and battery electric vehicles.</a> Journal of Power Sources. 130 (1-2), 208-212 (2004).</li><li>Wee, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Which+type+of+fuel+cell+is+more+competitive+for+portable+application:+Direct+methanol+fuel+cells+or+direct+borohydride+fuel+cells.">Which type of fuel cell is more competitive for portable application: Direct methanol fuel cells or direct borohydride fuel cells.</a> Journal of Power Sources. 161 (1), 1-10 (2006).</li><li>Muthukumar, P., Groll, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Erratum+to+&amp;#34;Metal+hydride+based+heating+and+cooling+systems:+a+review&amp;#34.">Erratum to &amp;#34;Metal hydride based heating and cooling systems: a review&amp;#34.</a> International Journal of Hydrogen Energy. 35 (16), 8816-8829 (2010).</li></ol>

Authors have no conflicts to declare.

Several parameters significantly influence the performance of a membraneless hydrogen peroxide fuel cell beyond solution pH and H2O2 concentration. The choice of electrode material dictates electrocatalytic activity and stability, while the electrode&#39;s surface area can enhance reaction sites. Operating temperature affects reaction kinetics, and the flow rate of reactants can determine the mixing efficiency of fuel and oxidant. The concentration of any catalyst used is pivotal for reaction rates,...

A fuel cell is an electrochemical device that utilizes fuel and oxidant to convert chemicals into electrical energy. FCs have higher energy conversion efficiency than traditional combustion engines since they are not bound by the Carnot Cycle1. By utilizing fuels such as hydrogen (H2)2, borohydride-hydrogen (NaBH4)3, and ammonia (NH3)4, FCs have become a promising energy source that is environmentally clean and can achieve high performance, offering significant potential to reduce human dependence on fossil fuels. However, FC technology faces specific challenges. One prevalent issue is the internal role of a proton exchange membrane (PEM) in the FC system, which acts as a safeguard against internal short circuits. The integration of an electrolytic membrane contributes to increased fabrication costs, internal circuit resistance, and architectural complexity5. Moreover, transforming single-compartment FCs into multi-stack arrays introduces additional complications due to the intricate process of integrating flow channels, electrodes, and plates to enhance power and current outputs5.
Over the past decades, concerted efforts have been made to address these membrane-related challenges and streamline the FC system. Notably, the emergence of membraneless FC configurations using laminar co-flows at low Reynold numbers has offered an innovative solution. In such setups, the interface between two flows functions as a &#34;virtual&#34; proton-conducting membrane6. Laminar flow-based FCs (LFFCs) have been widely studied, leveraging the benefits of microfluidics7,8,9,10. However, LFFCs require stringent conditions, including high energy input for pumping laminar fuels/oxidants, mitigation of reactant crossover in fluidic streams, and optimization of hydrodynamic parameters.
Recently, H2O2 has gained interest as a potential fuel and oxidant due to its carbon-neutral nature, yielding water (H2O) and oxygen (O2) during electrooxidation and electroreduction processes at electrodes11,12. H2O2 can be mass-produced using a two-electron reduction process or by a two-electron oxidation process from water12. Subsequently, in contrast to other gaseous fuels, liquid H2O2 fuel can be integrated into existing gasoline infrastructure 5. Besides, the H2O2 disproportionation reaction makes it possible to serve H2O2 as both fuel and oxidant. Figure 1A shows a schematic structure of a facile H2O2 FC&#39;s architecture. In comparison to traditional FCs2,3,4, the H2O2 FC utilizes the advantages of device &#34;simplicity.&#34; Yamasaki et al. demonstrated membraneless H2O2 FCs, playing the role of both fuel and oxidant. The described mechanism of electrical energy generation has inspired research communities to continue this research direction6. Subsequently, electrooxidation and electroreduction mechanisms using H2O2 as a fuel and oxidant have been represented by the following reactions13,14
In the acidic media:
Anode: H2O2 &#8594; O2 + 2H+ + 2e-; Ea1 = 0.68 V vs. SHE
Cathode: H2O2 + 2H+ + 2e- &#8594; 2H2O; Ea2 = 1.77 V vs. SHE
Total: 2 H2O2 &#8594; 2H2O + O2
In the basic media:
H2O2 + OH- &#8594; HO2- + H2O
Anode: HO2- + OH- &#8594; O2 + H2O + 2e-; Eb1 = 0.15 V vs. SHE
Cathode: HO2- + H2O + 2e- &#8594; 3OH-; Eb2 = 0.87 V vs. SHE
Total: 2 H2O2 &#8594; 2H2O + O2
Figure 1B illustrates the working principle of H2O2 FCs. H2O2 donates electrons at the anode and accepts electrons at the cathode. Electron transfer between the anode and cathode occurs through an external circuit, resulting in the generation of electricity. The theoretical open circuit potential (OCP) of H2O2 FC is 1.09 V in acidic media and 0.62 V in basic media13. However, numerous experimental results have shown lower values, reaching up to 0.75 V in acidic media and 0.35 V in basic media, compared to the theoretical OCP. This observation can be attributed to the presence of a mixed potential13. Additionally, the power and current output of H2O2 FCs cannot compete with the mentioned FCs2,3,4due to the limited catalytic selectivity of the electrodes. Nevertheless, it is noteworthy that current H2O2 FC technology can outperform H2, NaBH4, and NH3 FCs in terms of overall cost, as shown in Table 1. Thus, the enhanced catalytic selectivity of electrodes for H2O2 electrooxidation and electroreduction remains a significant challenge for these devices.
In this study, we introduce a three-dimensional porous structure electrode to improve the interaction between the electrode and H2O2 fuel, aiming to increase the reaction rate and enhance power and current output. We also investigate the impact of solution pH and H2O2 concentration on the FC&#39;s performance. The electrode pair used in this study comprises a gold-electroplated carbon fiber cloth and nickel foam. Structural characterization is conducted using X-ray Diffraction (XRD) and Scanning Electron Microscopy (SEM), with Open Circuit Potential (OCP), polarization, and power output curves serving as the primary parameters for FC testing.
