1. Preparation of buffers, solvent and antisolvent streams
<ol>
	<li>Dissolve all lipid components in ethanol at given mass concentrations, as shown in Table 1, to make a patisiran LNP formulation10. Prior to use, heat the solutions to 37 &#176;C with gentle sonication to re-dissolve any precipitated solids.
	NOTE: Larger stock solutions of several milliliters can be prepared and stored at 4 &#176;C.</li>
	<li>Prepare an acetate buffer stock solution at a concentration of 100 mM, pH 4, by combining 186 mg of sodium acetate and 464 mg of acetic acid in 80 mL of nuclease-free water. Adjust the pH with concentrated HCl or NaOH as needed and make up the final volume to 100 mL.</li>
	<li>Prepare a HEPES buffer stock solution at a concentration of 1 M, pH 7.5, by dissolving 23.82 g of HEPES salt in 80 mL of nuclease-free water. Adjust the pH with concentrated HCl or NaOH as needed and make up the final volume to 100 mL.</li>
	<li>Dilute the nucleic acid polymer of interest and the 100 mM acetate buffer stock with nuclease-free water to produce a 300 &#181;g/mL solution of RNA in 30 mM acetate buffer. Prepare an adequate volume of working solution for the designed experiments, and this protocol requires 1500 &#181;L total for both the CIJ and MIVM mixers.
	NOTE: RNA obtained from the supplier will already be in an appropriate buffer, typically at a concentration of 10 mg/mL (yeast RNA) or 1 mg/mL (luciferase-encoding mRNA, LucRNA, or GFP-encoding mRNA, GFP-RNA). Yeast RNA may be used as a low-cost model RNA for precipitations.</li>
</ol>
2. Formulation of LNPs using a two-jet CIJ mixer
<ol>
	<li>Preparation and cleaning of equipment
	<ol>
		<li>Clean CIJ mixers immediately before use by flushing the mixer with ethanol. Fill two 5 mL syringes with ethanol and lock each into an inlet port of the CIJ. Rapidly depress the syringes and collect the mixer effluent as waste.
		NOTE: CIJ mixers may be constructed and operated as previously described29. Various support stands may be used to hold the CIJ mixer, including a ring stand, centrifuge tube holder, or Erlenmeyer flask. The CIJ suppliers are listed in the Table of Materials and the Supplementary File 1.</li>
		<li>Remove the ethanol flush syringes from the CIJ. These syringes may be stored and reused for additional ethanol rinses of the CIJ.</li>
		<li>Dry the internal channels of CIJ by blowing a dry nitrogen stream through the inlet adapters. Use only dry, filtered air that is not contaminated with pump oil mist or aerosols if nitrogen is not available.</li>
	</ol>
	</li>
	<li>Preparation of solvent and antisolvent streams
	<ol>
		<li>Mix the lipid stock solutions and dilute with additional ethanol to produce 500 &#181;L of the 6 mg/mL lipid solution listed in Table 1 in a 1.5 mL microcentrifuge tube.
		NOTE: This formulation is the commonly used Onpattro composition containing 50 mole% MC3, 10 mole% DSPC, 38.5 mole% cholesterol, and 1.5 mole% DMG-PEG2000.</li>
		<li>Dilute the 100 mM pH 4 acetate buffer stock to 10 mM in a total volume of 4 mL as the CIJ mixer effluent quench bath.
		NOTE: A magnetic stir bar may also be added to the quench bath.</li>
		<li>Withdraw 500 &#181;L of RNA solution prepared in step 1.4 in a 1 mL syringe. Invert the syringe and expel any air from this aqueous antisolvent stream containing nucleic acid polymer.</li>
		<li>Withdraw 500 &#181;L of the lipid solution prepared in step 2.2.1 in a 1 mL syringe. Invert the syringe and expel any air from this ethanolic solvent stream containing lipids.</li>
	</ol>
	</li>
	<li>LNP production in a CIJ mixer
	<ol>
		<li>Position the clean CIJ mixer over the quench bath vial.
		NOTE: A ring stand clamp or tube rack makes a convenient support for the CIJ mixer. See Figure 1A for a typical CIJ setup.</li>
		<li>Mate the two syringes filled in step 2.2.3 and step 2.2.4 to the CIJ mixer inlet ports.</li>
		<li>Depress both syringes rapidly to mix the solvent and antisolvent streams and collect lipid NPs in the quench bath.
		NOTE: the syringes must be advanced quickly (in under 1 s) but smoothly and uniformly. Asymmetric flow or slow flow will produce polydisperse, large LNPs.</li>
		<li>Remove the CIJ mixer from over the quench bath with the syringes still attached.
		NOTE: Do not remove the syringes or allow the hold-up volume to flow into the quench bath, as this material is poorly mixed and will adversely impact the production dispersion properties if mixed into the quench bath.</li>
		<li>Hold the CIJ over a waste container and remove the syringes, allowing the residual hold-up volume to flow into the waste container. Dispose these syringes and repeat the cleaning process as described in section 2.1.</li>
		<li>Analyze LNPs produced with the CIJ as described in section 5 below.</li>
	</ol>
	</li>
</ol>
3. Formulation of LNPs using a four-jet MIVM mixer
<ol>
	<li>Assembly of a MIVM mixer, referred to as a micro-size MIVM (&#181;MIVM) to distinguish it from larger models used for scaled-up production
	<ol>
		<li>Gather all the individual components required to assemble a MIVM mixer: the bottom receiver, the mixing geometry disk, the top disk, the O-ring, and the spanner wrench.
		NOTE: MIVM construction, assembly, and operation have been previously demonstrated for the encapsulation of hydrophobic species, and the suppliers are listed in Supplementary File 1 and the Table of Materials29. See Figure 2 for a schematic of components and mixer stand terminology.</li>
		<li>Seat the O-ring into the groove in the mixing disk.</li>
		<li>Align the mixing disk holes with the pegs on the top disk and push them together without dislodging the O-ring.</li>
		<li>Screw the mated mixing disk, O-ring, and top disk assembly into the bottom receiver loosely.
		NOTE: Remove the outlet tubing from the bottom receiver before this step.</li>
		<li>Tighten the top disk into the bottom receiver using the spanner wrench.
		NOTE: A food or pharmaceutical-grade anti-seize compound may be applied to the top disk threads if thread galling is observed.</li>
		<li>Insert and tighten the outlet tubing fitting into the bottom receiver to complete the MIVM.</li>
		<li>Mount the assembled MIVM into the mixer stand so the outlet tubing exits through the support plate.
		&#8203;NOTE: The procedure for adjusting the MIVM mixer stand should be periodically performed to make sure the mechanical stops on the mixer stand are correctly configured29.</li>
	</ol>
	</li>
	<li>Preparation of solvent and antisolvent streams
	<ol>
		<li>Mix the two ethanolic lipid solvent stream solutions in a 1.5 mL microcentrifuge tube, as given in Table 2, by diluting the lipid stock solutions and adding additional ethanol as needed to reach a final lipid concentration of 6 mg/mL.
		NOTE: This is the same lipid solution composition as in 2.2.1 but with a total volume of 1000 &#181;L.</li>
		<li>Dilute the 100 mM pH 4 acetate buffer stock to 10 mM in a total volume of 8 mL as the MIVM effluent quench bath.
		NOTE: A magnetic stir bar may also be added to the quench bath.</li>
	</ol>
	</li>
	<li>Formulation of LNPs using a MIVM mixer
	<ol>
		<li>Place the 8 mL quench bath underneath the mixer stand so that the outflow tubing is emptying into the quench bath.</li>
		<li>Draw up the solvent and antisolvent streams into 1 mL gas-tight syringes using a blunt tip needle. Remove all air bubbles and dispose of the needle. Prime each syringe by inverting and expelling any air from the syringe.</li>
		<li>Assemble the four syringes onto the mixer in a clockwise fashion (Syringes 1-4, Table 2) with the same streams on the opposite sides. See Figure 1B for the final appearance schematic.</li>
		<li>Hold the bearing housing on both sides of the mobile plate. Avoid placing the fingers on the bottom face of the housing, as this poses a pinch hazard due to the mechanical stops. Carefully lower the mobile plate until it evenly rests on the syringes.
		NOTE: The syringe plungers must all be at an equal height before operation.</li>
		<li>Steadily and smoothly depress the plate, aiming to complete the operation in about 0.5 s to 1 s for these stream volumes.</li>
		<li>Cap the quench bath, which contains the LNP dispersion.</li>
		<li>Perform the cleaning of the MIVM after use, following the instructions in step 3.5 below.</li>
	</ol>
	</li>
	<li>Formulation of LNPs using a MIVM mixer driven by a syringe pump
	<ol>
		<li>Assemble the MIVM as described in step 3.1.</li>
		<li>Prepare the solvent and antisolvent solutions in the desired composition and at a sufficient volume for the required formulation size (Table 3).
		NOTE: These are the same compositions as the aqueous antisolvent (step 1.4) and ethanolic solvent (step 3.2.1) streams but are scaled up for use with the larger syringe volumes in Table 3.</li>
		<li>Load the solutions into gas-tight syringes with 20 mL volumes and attach PTFE tubing with a luer adapter fitted on the end. Prime the syringes and tubing by inverting the syringe and tubing and then expelling any air.</li>
		<li>Mount the syringes into a syringe pump and attach the syringes to the mixer inlets on the MIVM, as shown in Figure 3A.
		NOTE: The CIJ may also be operated via pumps in the same way but with only one antisolvent and solvent stream syringe.</li>
		<li>Dilute the 100 mM pH 4 acetate buffer stock to 10 mM in a total volume of 320 mL as the MIVM effluent quench bath.</li>
		<li>Place the quench bath underneath the MIVM outlet.</li>
		<li>Set the volumetric flow rate on the syringe pump to 20 mL/min.
		NOTE: The volumetric flow rates may be varied from 2 mL/min to 40 mL/min by manually setting the values on the syringe pump to form LNPs with different micromixing conditions.</li>
		<li>Start the syringe pump, but allow the first 10 s of effluent to flow into a waste beaker. Collect the MIVM effluent in the quench bath after this 10 s start-up flow period.</li>
		<li>Remove and cap the quench bath containing LNP dispersion made at the selected (20 mL/min) volumetric flow rate.
		NOTE: This procedure may be repeated to synthesize LNPs at different flow rates by selecting appropriate quench bath volumes.</li>
		<li>Clean the MIVM between each experiment (when changing the flow rate) by flushing out at least twice the volume of outlet tubing to prevent collection of LNPs made at the previous flow rate condition before beginning the next LNP synthesis.</li>
	</ol>
	</li>
	<li>Equipment cleaning after use
	<ol>
		<li>Detach the mixer from the stand while keeping the syringes attached, and hold it over a waste container. Remove the syringes, letting the hold-up volume drain into the container. Then, hold the mixer assembly upside down and use the spanner wrench to disassemble the mixer.</li>
		<li>Rinse the outlet tubing with solvent (e.g., ethanol) and dry with air or nitrogen.</li>
		<li>Rinse the mixing geometry with a suitable solvent, such as deionized water or ethanol, followed by a rinse with ethanol. Dry the components using a stream of air or nitrogen.</li>
		<li>Rinse the O-ring with deionized water and blot dry.
		NOTE: If the O-ring looks stretched or deformed, let it air dry overnight before using it. Maintain a large stock of O-rings since they are consumable parts. If the shape does not recover by the next day, dispose of the O-ring.</li>
		<li>Rinse the top disk thoroughly with solvent, using an air or nitrogen stream to dry the surface and the syringe fittings.</li>
		<li>Rinse each syringe with a good solvent (e.g., deionized water or ethanol). Apply a final rinse with ethanol and air dry before the next use.</li>
	</ol>
	</li>
</ol>
4. Post-processing of LNPs
<ol>
	<li>Buffer exchange and ethanol removal
	<ol>
		<li>Dialyze the LNP dispersion against a 10 mM HEPES buffer at pH 7.4 utilizing an appropriately sized dialysis cassette with a 20 kDa molecular weight cutoff dialysis cartridge.
		NOTE: This step both removes the residual 10% ethanol and increases the dispersion pH by replacing the acetate buffer with HEPES.</li>
		<li>Dilute the stock 1 M HEPES buffer to 10 mM in a total volume of 1 L.</li>
		<li>Load the LNP dispersion into a 12 mL dialysis cassette using a syringe and needle.</li>
		<li>Immerse the dialysis cartridge in the 1 L of HEPES buffer and magnetically stir the external buffer. Change the external HEPES buffer after 3 h, and remove the dialysis cartridge after an additional 3 h for a total dialysis time of 6 h.</li>
		<li>Withdraw the dialyzed LNP dispersion from the dialysis cartridge and discard the spent cartridge.</li>
	</ol>
	</li>
	<li>LNP suspension concentration via ultracentrifugation
	<ol>
		<li>Pipette the suspension into an appropriately sized centrifugal filter with a MWCO of 100kDa30.
		NOTE: Centrifugal filters are available in a range of sizes, commonly from 0.5 mL to 12 mL.</li>
		<li>Centrifuge the dispersion at 2000 x g for 10-20 min (at room temperature) to increase the concentration by a factor of approximately 5-20x.
		NOTE: During centrifugation, check on the sample every 5 min to ensure that an appropriate amount of liquid remains.</li>
	</ol>
	</li>
</ol>
5. Characterization of LNPs
<ol>
	<li>Hydrodynamic diameter measurements with dynamic light scattering (DLS)
	<ol>
		<li>Dispense 750 &#181;L or 900 &#181;L of the prepared LNP dispersion (without any dilutions) into a plastic micro or square cuvette, respectively.
		NOTE: Smaller volumes can also be used in appropriate cuvettes.</li>
		<li>Set the appropriate viscosity for the solvent in which the LNPs are dispersed (i.e., 1.26 cP for 10 vol% ethanol mixture).</li>
		<li>Collect backscattered light at a 173&#176; angle at 25 &#176;C, followed by the size determination of LNP using the Stokes-Einstein model and the first cumulant of the light scattering correlation function series expansion as defined in the ISO standard document 13321:1996 E.</li>
		<li>Repeat the measurements at least three times.</li>
	</ol>
	</li>
	<li>Zeta potential measurements
	<ol>
		<li>Add ~800 &#181;L of as-prepared LNP dispersion into folded capillary zeta-sizer cells.
		NOTE: To avoid bubble entrapment within the capillary channel, half of the liquid is dispensed into the cells, held upside down, and then rotated.</li>
		<li>Repeat the measurements at least three times.
		NOTE: Buffer conductivity should be between 0.2-2 milliSiemens/cm for best results.</li>
	</ol>
	</li>
	<li>Encapsulation efficiency (EE) measurements by commercially available RNA quantification kit
	<ol>
		<li>Dilute the appropriate amount of the 20x Tris-EDTA (TE) buffer at pH 7.5 provided in the assay kit to 1x concentration using nuclease-free water.</li>
		<li>Prepare a Triton X-100 solution at 2 wt%.</li>
		<li>Dilute the appropriate amount of LNP dispersions in the 1x TE buffer to yield a total mass concentration of approximately 0.6 &#181;g/mL for RNA, with ethanol content below 0.2 vol%.</li>
		<li>Prepare similar samples as in the previous step but containing 0.5 wt.% Triton X-100, which effectively dissolves the LNPs, facilitating the differentiation between &#34;free&#34; and total RNA concentrations in the absence and presence of Triton X-100, respectively.</li>
		<li>Prepare appropriate amounts of control RNA solutions at the concentrations of 0 &#181;g/mL, 0.1 &#181;g/mL, 0.2 &#181;g/mL, 0.4 &#181;g/mL, 0.6 &#181;g/mL, 0.8 &#181;g/mL and 1.0 &#181;g/mL in the 1x TE buffer.
		NOTE: The RNA kit may initially need to be diluted.</li>
		<li>Repeat the previous step but at 0.5 wt.% Triton X-100.</li>
		<li>Dilute the Ribogreen dye (provided in the kit) 200 times in the 1x TE buffer.</li>
		<li>Add appropriate volumes of the diluted Ribogreen dye to all prepared control RNA and sample solutions, whether with or without Triton X-100. The dye should be diluted equally across both control RNA and sample solutions at a factor of two. Consequently, the total dilution of the dye is 400 times that of its original concentration in the assay kit.</li>
		<li>Vortex mix the containers.</li>
		<li>Prepare a 96-well, non-treated, flat-bottom, opaque plate for analysis in a plate reader.</li>
		<li>Dispense 100 &#181;L volumes of samples and RNA controls into separate cells of the plate.
		NOTE: Watch for bubble formation in solutions containing Triton X-100. At least three replicates are conducted for each sample, requiring at least 350 &#181;L of samples.</li>
		<li>Record fluorescence intensity using the plate reader at an excitation wavelength of 485 nm and an emission wavelength of 528 nm, with an illumination duration of approximately 10 s per reading. No shaking is needed.
		NOTE: The EE is determined from <img alt="Equation 1" src="/files/ftp_upload/67047/67047eq01.jpg" style="margin: auto;" />, where Iwith Triton and Iwithout Triton represent the averaged fluorescence intensity of three replicates of samples with and without Triton X-100, respectively, and awith Triton and awithout Triton denote the slope of linear fits to the two averaged calibration curves with and without Triton X-100, respectively31.</li>
	</ol>
	</li>
</ol>

Synthesizing Lipid Nanoparticles Using CIJ and &#181;MIVM Mixer Technologies

<ol>
	<li>Hou, X., Zaks, T., Langer, R., Dong, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+nanoparticles+for+mRNA+delivery.">Lipid nanoparticles for mRNA delivery.</a> Nat Rev Mater. 6 (12), 1078-1094 (2021).</li><li>Dowdy, S. F., Setten, R. L., Cui, X. -. S., Jadhav, S. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Delivery+of+RNA+therapeutics:+The+great+endosomal+escape.">Delivery of RNA therapeutics: The great endosomal escape.</a> Nucleic Acid Ther. 32 (5), 361-368 (2022).</li><li>Eygeris, Y., Patel, S., Jozic, A., Sahay, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deconvoluting+lipid+nanoparticle+structure+for+messenger+RNA+delivery.">Deconvoluting lipid nanoparticle structure for messenger RNA delivery.</a> Nano Lett. 20 (6), 4543-4549 (2020).</li><li>Tenchov, R., Bird, R., Curtze, A. E., Zhou, Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+nanoparticles&#9472;from+liposomes+to+mRNA+vaccine+delivery,+a+landscape+of+research+diversity+and+advancement.">Lipid nanoparticles&#9472;from liposomes to mRNA vaccine delivery, a landscape of research diversity and advancement.</a> ACS Nano. 15 (11), 16982-17015 (2021).</li><li>Buck, J., Grossen, P., Cullis, P. R., Huwyler, J., Witzigmann, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid-based+DNA+therapeutics:+Hallmarks+of+non-viral+gene+delivery.">Lipid-based DNA therapeutics: Hallmarks of non-viral gene delivery.</a> ACS Nano. 13 (4), 3754-3782 (2019).</li><li>Semple, S. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rational+design+of+cationic+lipids+for+siRNA+delivery.">Rational design of cationic lipids for siRNA delivery.</a> Nat Biotechnol. 28 (2), 172-176 (2010).</li><li>Lam, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=trialkyl+ionizable+lipids+are+versatile+lipid-nanoparticle+components+for+therapeutic+and+vaccine+applications.">trialkyl ionizable lipids are versatile lipid-nanoparticle components for therapeutic and vaccine applications.</a> Adv Mater. 35 (15), 2209624 (2023).</li><li>Gilleron, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Image-based+analysis+of+lipid+nanoparticle-mediated+siRNA+delivery,+intracellular+trafficking+and+endosomal+escape.">Image-based analysis of lipid nanoparticle-mediated siRNA delivery, intracellular trafficking and endosomal escape.</a> Nat Biotechnol. 31 (7), 638-646 (2013).</li><li>Evers, M. J. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=State-of-the-art+design+and+rapid-mixing+production+techniques+of+lipid+nanoparticles+for+nucleic+acid+delivery.">State-of-the-art design and rapid-mixing production techniques of lipid nanoparticles for nucleic acid delivery.</a> Small Methods. 2 (9), 1700375 (2018).</li><li>Kulkarni, J. A., Cullis, P. R., Van Der Meel, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+nanoparticles+enabling+gene+therapies:+From+concepts+to+clinical+utility.">Lipid nanoparticles enabling gene therapies: From concepts to clinical utility.</a> Nucleic Acid Ther. 28 (3), 146-157 (2018).</li><li>J&#252;rgens, D. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lab-scale+siRNA+and+mRNA+LNP+manufacturing+by+various+microfluidic+mixing+techniques+-+an+evaluation+of+particle+properties+and+efficiency.">Lab-scale siRNA and mRNA LNP manufacturing by various microfluidic mixing techniques - an evaluation of particle properties and efficiency.</a> OpenNano. 12, 100161 (2023).</li><li>Wang, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+of+selective+organ-targeting+(sort)+lipid+nanoparticles+(LNPs)+using+multiple+technical+methods+for+tissue-specific+mRNA+delivery.">Preparation of selective organ-targeting (sort) lipid nanoparticles (LNPs) using multiple technical methods for tissue-specific mRNA delivery.</a> Nat Protoc. 18 (1), 265-291 (2023).</li><li>Yanez Arteta, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Successful+reprogramming+of+cellular+protein+production+through+mRNA+delivered+by+functionalized+lipid+nanoparticles.">Successful reprogramming of cellular protein production through mRNA delivered by functionalized lipid nanoparticles.</a> Proc Natl Acad Sci. 115 (15), E3351-E3360 (2018).</li><li>Eygeris, Y., Gupta, M., Kim, J., Sahay, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemistry+of+lipid+nanoparticles+for+RNA+delivery.">Chemistry of lipid nanoparticles for RNA delivery.</a> Acc Chem Res. 55 (1), 2-12 (2022).</li><li>Shepherd, S. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Scalable+mRNA+and+siRNA+lipid+nanoparticle+production+using+a+parallelized+microfluidic+device.">Scalable mRNA and siRNA lipid nanoparticle production using a parallelized microfluidic device.</a> Nano Lett. 21 (13), 5671-5680 (2021).</li><li>Leung, A. K. K., Tam, Y. Y. C., Chen, S., Hafez, I. M., Cullis, P. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microfluidic+mixing:+A+general+method+for+encapsulating+macromolecules+in+lipid+nanoparticle+systems.">Microfluidic mixing: A general method for encapsulating macromolecules in lipid nanoparticle systems.</a> J Phys Chem B. 119 (28), 8698-8706 (2015).</li><li>Prakash, G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microfluidic+fabrication+of+lipid+nanoparticles+for+the+delivery+of+nucleic+acids.">Microfluidic fabrication of lipid nanoparticles for the delivery of nucleic acids.</a> Adv Drug Deliv Rev. 184, 114197 (2022).</li><li>Carvalho, B. G., Ceccato, B. T., Michelon, M., Han, S. W., De La Torre, L. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advanced+microfluidic+technologies+for+lipid+nano-microsystems+from+synthesis+to+biological+application.">Advanced microfluidic technologies for lipid nano-microsystems from synthesis to biological application.</a> Pharmaceutics. 14 (1), 141 (2022).</li><li>Webb, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Using+microfluidics+for+scalable+manufacturing+of+nanomedicines+from+bench+to+GMP:+A+case+study+using+protein-loaded+liposomes.">Using microfluidics for scalable manufacturing of nanomedicines from bench to GMP: A case study using protein-loaded liposomes.</a> Int J Pharm. 582, 119266 (2020).</li><li>Warne, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Delivering+3+billion+doses+of+comirnaty+in+2021.">Delivering 3 billion doses of comirnaty in 2021.</a> Nat Biotechnol. 41 (2), 183-188 (2023).</li><li>Johnson, B. K., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Flash+nanoprecipitation+of+organic+actives+and+block+copolymers+using+a+confined+impinging+jets+mixer.">Flash nanoprecipitation of organic actives and block copolymers using a confined impinging jets mixer.</a> Aust J Chem. 56 (10), 1021-1024 (2003).</li><li>Hogarth, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaluating+the+impact+of+systematic+hydrophobic+modification+of+model+drugs+on+the+control,+stability+and+loading+of+lipid-based+nanoparticles.">Evaluating the impact of systematic hydrophobic modification of model drugs on the control, stability and loading of lipid-based nanoparticles.</a> J Mater Chem B. 9 (48), 9874-9884 (2021).</li><li>Belliveau, N. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microfluidic+synthesis+of+highly+potent+limit-size+lipid+nanoparticles+for+in+vivo+delivery+of+siRNA.">Microfluidic synthesis of highly potent limit-size lipid nanoparticles for in vivo delivery of siRNA.</a> Mol Ther Nucleic Acids. 1, e37 (2012).</li><li>D'addio, S. M., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Controlling+drug+nanoparticle+formation+by+rapid+precipitation.">Controlling drug nanoparticle formation by rapid precipitation.</a> Adv Drug Deliv Rev. 63 (6), 417-426 (2011).</li><li>Johnson, B. K., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanism+for+rapid+self-assembly+of+block+copolymer+nanoparticles.">Mechanism for rapid self-assembly of block copolymer nanoparticles.</a> Phys Rev Lett. 91 (11), 118302 (2003).</li><li>Han, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+simple+confined+impingement+jets+mixer+for+flash+nanoprecipitation.">A simple confined impingement jets mixer for flash nanoprecipitation.</a> J Pharm Sci. 101 (10), 4018-4023 (2012).</li><li>Markwalter, C. E., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Design+of+a+small-scale+multi-inlet+vortex+mixer+for+scalable+nanoparticle+production+and+application+to+the+encapsulation+of+biologics+by+inverse+flash+nanoprecipitation.">Design of a small-scale multi-inlet vortex mixer for scalable nanoparticle production and application to the encapsulation of biologics by inverse flash nanoprecipitation.</a> J Pharm Sci. 107 (9), 2465-2471 (2018).</li><li>Johnson, B. K., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemical+processing+and+micromixing+in+confined+impinging+jets.">Chemical processing and micromixing in confined impinging jets.</a> AIChE. 49, 2264-2282 (2003).</li><li>Markwalter, C. E., Pagels, R. F., Wilson, B. K., Ristroph, K. D., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Flash+nanoprecipitation+for+the+encapsulation+of+hydrophobic+and+hydrophilic+compounds+in+polymeric+nanoparticles.">Flash nanoprecipitation for the encapsulation of hydrophobic and hydrophilic compounds in polymeric nanoparticles.</a> J Vis Exp. (143), e58757 (2019).</li><li>Bailey-Hytholt, C. M., Ghosh, P., Dugas, J., Zarraga, I. E., Bandekar, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Formulating+and+characterizing+lipid+nanoparticles+for+gene+delivery+using+a+microfluidic+mixing+platform.">Formulating and characterizing lipid nanoparticles for gene delivery using a microfluidic mixing platform.</a> J Vis Exp. (168), e62226 (2021).</li><li>Bizmark, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ribogreen+fluorescent+assay+kinetics+to+measure+ribonucleic+acid+loading+into+lipid+nanoparticle+carriers.">Ribogreen fluorescent assay kinetics to measure ribonucleic acid loading into lipid nanoparticle carriers.</a> Adv Mater Interfaces. 11 (17), 2301083 (2024).</li><li>Zhang, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Modification+of+lipid-based+nanoparticles:+An+efficient+delivery+system+for+nucleic+acid-based+immunotherapy.">Modification of lipid-based nanoparticles: An efficient delivery system for nucleic acid-based immunotherapy.</a> Molecules. 27 (6), 1943 (2022).</li><li>Kulkarni, J. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fusion-dependent+formation+of+lipid+nanoparticles+containing+macromolecular+payloads.">Fusion-dependent formation of lipid nanoparticles containing macromolecular payloads.</a> Nanoscale. 11 (18), 9023-9031 (2019).</li><li>El-Mayta, R., Padilla, M. S., Billingsley, M. M., Han, X., Mitchell, M. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Testing+the+in+vitro+and+in+vivo+efficiency+of+mRNA-lipid+nanoparticles+formulated+by+microfluidic+mixing.">Testing the in vitro and in vivo efficiency of mRNA-lipid nanoparticles formulated by microfluidic mixing.</a> J Vis Exp. (191), e64810 (2023).</li><li>Scalzo, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ionizable+lipid+nanoparticle-mediated+delivery+of+plasmid+DNA+in+cardiomyocytes.">Ionizable lipid nanoparticle-mediated delivery of plasmid DNA in cardiomyocytes.</a> Int J Nanomed. 17, 2865-2881 (2022).</li><li>Feng, J., Markwalter, C. E., Tian, C., Armstrong, M., Prud'homme, R. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Translational+formulation+of+nanoparticle+therapeutics+from+laboratory+discovery+to+clinical+scale.">Translational formulation of nanoparticle therapeutics from laboratory discovery to clinical scale.</a> J Transl Med. 17 (1), 200 (2019).</li><li>Kazemian, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid-nanoparticle-based+delivery+of+CRISPR/cas9+genome-editing+components.">Lipid-nanoparticle-based delivery of CRISPR/cas9 genome-editing components.</a> Mol Pharm. 19 (6), 1669-1686 (2022).</li><li>Pinkerton, N. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Polymeric+drug+delivery+vehicles+and+imaging+agents.">Polymeric drug delivery vehicles and imaging agents.</a> Princeton University. , (2014).</li></ol>

The authors have no conflicts of interest to disclose.

Synthesis of LNPs containing nucleic acid polymers using two confined impinging jet turbulent mixers has been presented. When conducted at appropriate velocities, CIJ turbulent mixers ensure the time scale of mixing is shorter than the LNP assembly time, producing homogenous supersaturation conditions for forming small LNPs with narrow size distributions21. Consequently, LNPs made with the same chemistry using different turbulent mixer geometries (the 2-jet CIJ and the 4-jet MIVM mixer) exhibit similar physicochemical properties and show good transfection efficiencies (Figure 5 and Figure 6). In contrast, LNPs made using pipetting that produces poorer mixing results in larger and more polydisperse LNPs (Figure 5A) with lower transfection efficiencies. It has long been understood that mixing and assembly kinetics play a significant role in LNP processing; Cullis et al. noted that rapid convective-diffusive mixing of ethanol and buffer leads to the formation of small particles with a narrow size distribution, whereas slow diffusive mixing leads to larger particles with broad size distributions9. The time scale of mixing in CIJ turbulent mixers decreases proportionately to the inlet flow rates of the streams to the mixer27. This is quantified by the dimensionless Reynolds number (Re), which measures the ratio between the inertial and viscous forces. The turbulence inside the mixing chambers of the CIJ and MIVM occurs at sufficiently high Re, such that the turbulent vortex stretching results in small scales of length that produce rapid solvent/antisolvent mixing by diffusion. The turbulent length scale depends on the Re and not the specific geometry of the mixing device. That is why either the CIJ or the MIVM makes the same LNP particles, and why various sizes of MIVM mixers make the same NP sizes27. At high Re, corresponding to high inlet velocities, LNPs can be made reproducibly without batch-to-batch variations (Figure 3B).
This protocol enables the formulation of a variety of mRNA, DNA, or siRNA LNPs with different physicochemical properties using turbulent CIJ mixers. In addition to allowing versatility in composition and concentrations, this technique provides a clear path to rapidly screen formulations at bench sale (a few milligrams) and scale up the lead formulations to larger industrial batch sizes at production rates of 5 L/min36. This has been a major hurdle for several other techniques, including bulk-mixing and microfluidics. For instance, bulk-processing techniques fail to consistently manufacture LNPs reproducibly, even at a few milliliter scales. Microfluidic techniques provide a significant improvement over bulk-mixing techniques to enable the production of uniform and reproducible LNPs; however, they are only in the milligram range29. As detailed in the introduction, parallelization of microfluidic devices provides an attempt at scaling to production scales but does not eliminate the issue of fouling, and it cannot be scaled as successfully as mixers based on confined impinging jet technology.
Apart from these advantages, CIJ mixers will be instrumental in manufacturing next-generation LNPs that exhibit targeting capabilities or perform gene editing. The current LNP formulations have lipids and nucleic acids that have similar diffusivities, and therefore, they can be made even with slightly poor mixing at bench-scale. However, gene-editing approaches may require the encapsulation of nucleic acid species with widely different molecular weights, such as small guide RNA molecules and large mRNA transcripts, to code a CAS9 protein37. The very different diffusion time scales of these different species make uniform encapsulation at stoichiometric ratios challenging. This problem of uniform encapsulation becomes more pronounced as the mixing efficiency becomes poorer. Likewise, targeting non-hepatic cells might need the incorporation of strongly bound slow-diffusing stabilizers (such as large molecular weight block copolymers with targeting ligands). Targeting ligands as large as 14 kDa can be conjugated to block copolymers prior to nanoparticle assembly, which enables their uniform incorporation into NPs using CIJ mixing38. CIJ turbulent mixers are useful tools for manufacturing LNPs made with components having different diffusivities.
While CIJ turbulent mixers demonstrate several advantages over other mixers for formulating LNPs, it is important to note the limitations associated with each geometry. The 2-jet CIJ mixer requires that both the inlet streams (ethanol and water) have equal momenta (within 10%-30%) to achieve uniform turbulent micromixing in the chamber. The fact that the exit stream comprises 50:50 solvent/antisolvent limits the level of supersaturation in the mixing cavity where precipitation occurs29. This drawback is addressed by the 4-jet MIVM mixer, as it can utilize four jets with unequal momenta to accomplish high supersaturation conditions in the mixing chamber. Additionally, both the mixers are required to be in the order of milligrams of total mass, making them a non-ideal choice for high-throughput screening of many different LNP formulations. For simple LNP formulations, screening may best be done with microfluidics or pipetting strategies at microgram scales and then transferred to the confined impinging jet technology when a few lead formulations have been identified. It is also crucial to consider the dead volumes in the mixers. In the CIJ, two jet mixers, the hold-up volumes are 50-100 microliters. This amount of material must be subtracted from the amount captured in the quench bath when calculating the recovery from the process. These losses are insignificant when operating on large scales but would account for 10% losses when total volumes of 5 mL are produced, as shown here. The impinging jet turbulent mixers are a valuable tool for producing LNPs at the GMP scale, as evidenced by the two FDA-approved COVID-19 vaccines.

mRNA-based therapeutics hold great potential for the treatment and prevention of a wide range of diseases, including infectious diseases, genetic disorders, and cancers1. Unlike small-molecule therapeutics, which can passively diffuse across the cell membrane, nucleic acids must be encapsulated for intracellular delivery2. Encapsulation provides both structure and stability to mRNA, facilitating their intracellular delivery via endocytic pathways as well as preventing degradation from intra- and extra-cellular components such as nucleases3. A host of materials and nanocarriers have been developed for the encapsulation and delivery of mRNA, including inorganic nanoparticles, polymers, lipids, and lipid-like materials1. Among these, LNPs have emerged as the most prominent delivery platform for mRNA-based therapeutics4.
LNPs are composed of four lipid components: ionizable lipid, cholesterol, zwitterionic lipid, and PEG-lipid stabilizer5. Ionizable lipids suitable for mRNA delivery exhibit a careful balance between the lipid hydrophobicity and the dissociation constant (pKa) of a ternary amine group6. The ionizable lipid pKa typically has a pH between 6.0 and 6.7, such as KC-2 (DLin-KC2-DMA), MC-3 (DLin-MC3-DMA), and ALC-03157. This pKa restriction on the ionizable lipid enables both the encapsulation of nucleic acid polymers as hydrophobic lipid salts and the intracellular delivery through an &#34;endosome escape&#34; process. LNPs enter a target cell through (various) endocytosis pathways that all involve acidification of the endosome from pH 7.4 to pH ~58. The ionizable lipid pKa ensures that LNPs have nearly neutral surfaces under physiological conditions but become cationic in an acidifying endosome9. This pH response enables selective disruption of only the endosomal membrane, the release of the encapsulated nucleic acid polymer, and preserves cell viability, unlike permanently cationic lipids used in transfection systems such as Lipofectamine. Cholesterol is a hydrophobic, interstitial molecule in the LNP structure that improves lipid fluidity. The zwitterionic lipid plays a structural role and forms a bilayer on the LNP surface. The poly(ethylene glycol)-lipid (PEG-lipid) is a colloidal stabilizer that enhances the LNP stability by imparting a polymeric steric stabilizer onto the LNP surface, which resists aggregation of LNPs. This stabilizes the LNP, particularly during changes in pH that regenerate the free base form of the ionizable lipid which behaves like a hydrophobic oil. The Onpattro (patisiran) recipe (hereafter, referred to as LNP formulation) is often used as a starting point for LNP formulation with ionizable lipid MC3, cholesterol, distearoylphosphatidylcholine (DSPC), and PEG2000-DMG dissolved in ethanol mixed against an aqueous solution of RNA10.
Several techniques can be used to manufacture LNPs encapsulating nucleic acid polymers, with most of them relying on a common theme of rapidly mixing an ethanol stream containing lipids with an aqueous stream incorporating the nucleic acid of interest (siRNA, mRNA, or DNA)9,11,12,13,14. In this regard, bulk mixing processes such as pipette mixing and vortex mixing offer a simple strategy to form LNPs that eliminates the need for using sophisticated instruments12. However, bulk mixing does not provide a homogeneous distribution of components, leading to a sub-optimal LNP size distribution along with significant batch-to-batch variability15.
Laboratories routinely use microfluidic mixing techniques to obtain reproducible LNPs by achieving more precise control over mixing conditions12,13,16. Yet, the laminar flow conditions in microfluidic devices, which are inherent due to the small length scales and low velocities in a microfluidics chamber, result in comparatively slow solvent/antisolvent mixing17. The small chamber dimensions severely limit the throughput and scalability needed for GMP production of LNPs, but researchers have parallelized microfluidic chambers to attempt to scale production volumes15. A parallelized microfluidics geometry does not eliminate the problem of lipid adsorption to surfaces during large volume processing, a problem commonly referred to as &#34;fouling&#34; of the mixing device, and there are problems with uniformity and stability of flows that make microfluidics scaleup challenging for industrial-scale production18,19. It is not surprising that pharmaceutical companies used turbulent impinging jet mixers to manufacture COVID-19 vaccination mRNA-LNPs20.
The production process of RNA-loaded LNPs entails the blending of an aqueous buffer stream containing the RNA payload with an ethanol stream containing the four distinct lipid components. These formulations utilize an acidic buffer with a pH of 4.0 or less, which charges the ionizable lipid as the aqueous and ethanolic streams mix. The positively charged ionizable lipids interact electrostatically with the negatively charged RNAs, forming a hydrophobic RNA-lipid salt. Hydrophobic lipid species, including the RNA-lipid salt, precipitate in the mixed solvents and form hydrophobic nuclei. These nuclei grow through the precipitation of zwitterionic lipid and cholesterol until reaching a critical point where sufficient pegylated lipid adsorbs on the surface of the LNPs, halting further growth -nucleation and growth mechanism21,22,23. The addition of aqueous buffer to the lipid solution, to the extent where lipids precipitate and LNPs form, hinges on two distinct time scales: the solvent-antisolvent mixing period, &#964;mix, and the nuclei growth period, &#964;agg. The dimensionless Damk&#246;hler number, defined as Da = &#964;mix/&#964;agg, captures the interplay between these time scales24. In instances of slow mixing (Da &#62; 1), the final size of LNPs is transport-controlled and varies with mixing time. Conversely, during fast mixing (Da &#60; 1), the fluid is fragmented into Kolmogrov-length striations or layers, whereby LNP formation is solely governed by the molecular diffusion of each constituent, resulting in homogeneous kinetics of LNP formation. Achieving the latter scenario demands that the lipid concentration exceeds a critical threshold, establishing a state of supersaturation conducive to uniform homogeneous nucleation.
It is estimated that &#964;agg ranges from a few tens to a few hundreds of milliseconds25. In its most basic configuration, the two streams, one containing ethanol with lipids and the other containing an aqueous buffer with RNA cargo, are injected into a chamber known as a &#34;confined impinging jet&#34; (CIJ) mixer. Turbulent vortices produce solvent/antisolvent striation length scales of 1 &#181;m within 1.5 ms when operated at appropriate velocities. The stream velocities and mixing geometry determine the conversion of linear momentum into turbulent vortices that mix the streams. This is parameterized by the dimensionless number, the Reynolds number (Re), that is linearly proportional to the flow velocities. Re is computed from Re = &#931; (ViDi/vi), where Vi is the flow velocity in each steam, vi is the kinematic viscosity of each stream, and Di is the stream inlet diameter in 2-jet CIJ devices26 or the chamber diameter in 4-jet MIVMs27. Note: Some references for the CIJ use only a single jet diameter and velocity to define Re28. Re is in the range of 1-100 in a microfluidics device, whereas in the CIJ devices, Re of 125,000 can be achieved. In a CIJ mixer, streams with equal momentum collide, dissipating their momentum upon impact as turbulent mixing, which leads to efficient micromixing due to the small Kolmogorov microscales and small Damk&#246;hler number. Another type of mixer is the &#34;multiple inlet vortex mixer&#34; (MIVM), where four streams are directed into a central chamber. In this setup, continuous flows into the confined mixing chamber ensure a well-defined mixing time scale. All fluid elements pass through the high-energy mixing zone in both types of mixers. In contrast, simple mixing devices like T-junctions do not contain a chamber that provides a mixing zone, resulting in less mixing of the two streams due to the incoming stream momentum being largely deflected into the outlet direction rather than into turbulent vortex generation. Both CIJ and MIVM mixers can be operated in batch or continuous modes, offering flexibility for LNP production at various scales.
This protocol describes how optimal LNP formulations are made by employing two confined impinging jet technologies: 2-jet CIJ and the 4-jet MIVM mixers. The operation of CIJ and MIVM mixers has been previously demonstrated for the preparation of NPs with hydrophobic core materials29. That article and video should be consulted as an additional resource on the formation of NPs with these mixers. This update focuses on lipid-based NP formation. The ability to tune the size of LNPs by varying the micro-mixing conditions is demonstrated. Additionally, the utility of CIJ technologies in forming stable, monodisperse LNPs with improved in vitro transfection efficiencies in HeLa cells when compared to LNPs made using poor pipette mixing is shown. Furthermore, the advantages and disadvantages of each CIJ mixing geometry, along with appropriate conditions needed for the scaleup of these mixers, are discussed.
