이 작품은 NSFC 프로젝트 (81522023, 81530059, 91639113, 81772000, 81371699, 및 81401534)에 의해 재정적으로 지원 되었다.

실험 동물의 사용은 동물 실험 윤리 위원회의 난카이 대학에 의해 승인 하 고 관리 및 실험 동물의 사용에 대 한 가이드에 따라 실시.
1입니다. Electrospun PCL 이식의 제조
참고: 여기, 전기 기술 혈관 이식 조작에 이용 되었다.
<ol><li>각각, 메탄올과 클로 프롬의 혼합물에서 PCL을 용 해 하 여 25 wt %와 10 wt %의 PCL 솔루션을 준비 (1:5 볼륨 비율), 실 온 (RT) 12 시간에서.</li>
	<li>10 mL 유리 주사기를 PCL 솔루션을 로드 합니다.</li>
	<li>21-G 바늘 주사기를 놓습니다.</li>
	<li>컬렉션 악기에 스테인리스 스틸 맨 드릴 (2 mm 직경, 길이 25 c m)를 놓습니다.</li>
	<li>두꺼운 섬유 이식에 대 한 사용 하 여 25 wt %의 PCL 솔루션, 수집기 바늘 끝에서 17 cm의 거리, 8 mL/h의 유량 및 11의 전압 전기 매개 변수로 kV. 얇은 섬유 이식 10 wt %, 수집기에 바늘 끝에서 20 cm의 거리, 2 mL/h의 유량 및 18의 전압의 PCL 솔루션 사용 전기 매개 변수로 kV.</li>
	<li>얻은 이식 하룻밤 잔여 용 매를 제거 하는 진공 상태에서 배치 됩니다 확인 하십시오. 소독 절차 전에 모든 악기 고 무 균 기술을 통해 유지 합니다.</li>
	<li>주입 전에 이식 30 분 75% 에탄올 10 ml에서 그들을 immersing 및 다음 하룻밤 UV 빛에 노출에 의해 소독.</li>
	<li>섬유 및 기 공 크기 측정: 스캐닝 전자 현미경 (SEM) 이미지에 따라 ImageJ 소프트웨어를 사용 하 여 평균 섬유 직경을 계산.</li>
	<li>기계 장비의 테스트:<ol>
<li>면도날을 사용 하 여 길이 3 m m 섹션으로 관 건설 기계를 절단. 건설 기계는 마이크로미터를 사용 하 여 두께 측정 합니다.</li>
		<li>100 북 아의 부하 용량 인장 테스트 기계에 관 건설 기계를 배치</li>
		<li>파열까지 1mm 간 클램프 거리와 풀 10 m m/min의 속도로 경도 건설 기계 클램프. 인장 강도 및 파단 궁극적인 측정 합니다. 초기 선형 영역에서 탄성 계수를 계산 (최대 5% 변형) 응력-변형 곡선의.</li>
	</ol>
</li>
</ol>2. 쥐 복 부 대동맥 이식 모델
참고: 모든 재료와 수술에 사용 되는 계기는 살 균. 수술 동안 거 즈 마스크와 감염을 피하기 위해 멸 균 장갑을 착용 하는 연산자 확인 하십시오. 실내 온도 동물 체온을 유지 하기 위해 27-30 ° C에서 유지 됩니다 확인 하십시오. 진통에 관한 현지 IACUC 지침을 따르십시오.
<ol><li>남성 Sprague Dawley 쥐 혈관 이식의 수신자로 240-270 g의 무게를 사용 합니다. 쥐 수술 하기 전에 24 시간 금식은 확인 합니다. 24 시간 단식 쥐의 목표는 빈 창 자에서 대변 충분히, 그로 인하여 확장 연산자의 수평선.</li>
	<li>쥐의 백 목 잡고 아래쪽으로 머리를 유지, 낮은 복 부의 복 부 구멍으로 springe 바늘을 삽입. 복 주사에 의해 chloral 하이드 레이트 (330 mg/kg)과 마 취에 대 한 쥐를 유도.</li>
	<li>쥐는 근육과 꾸준히 호흡을 완화 했다 함으로써 적절 한 anesthetization를 확인 합니다. 운영 현미경 쥐 부정사 위치에 놓습니다.</li>
	<li>바 셀 린 안과 수 의사 연 고 마 취에서 건조를 방지 하기 위해 눈에 적용 됩니다. 수술 전에 꼬리 정 맥 주입에 의해 heparinized 생리 염 분 해결책 (50 UI/mL)와 anticoagulation (UI/100kg)을 관리 합니다.</li>
	<li>면도칼 블레이드를 사용 하 여 전방 복 벽에 털을 면도 하십시오 그리고 요오드 솔루션 및 의료 알코올 솔루션을 사용 하 여 피부를 청소.</li>
	<li>수술가 위로 중간 개복 술 절 개를 수행 하 고 절 개 길이, 약 4-5 m 인지 확인 다음 복 부 구멍을 노출.</li>
	<li>철회 하 고 우선적으로 생리 식 염 수를 적신 거 즈로 내장을 포장.</li>
	<li>신중 하 게 복 부 대동맥 해 부.</li>
	<li>식별 하 고 9-0 monofilament 나일론 봉합을 사용 하 여 모든 작은 가지를 선.</li>
	<li>격리 된 섹션을 클램프 (길이 최대 1 c m) 2 개의 혈관 클램프를 사용 하 여 대동맥의. 대동맥 20-30 분 채워 남아 있을 수 있습니다.</li>
	<li>Anastomotic 사이트를 만들 마이크로-가 위를 사용 하 여 두 개의 클램프 사이의 복 부 대동맥 transect</li>
	<li>잔여 혈액을 제거 하 heparinized 염 (UI/50ml) 솔루션을 사용 하 여 대동맥의 두 끝을 플러시.</li>
	<li>마이크로-가 위를 사용 하 여 adventitia 벗기다.</li>
	<li>9-0 monofilament 나일론 봉합을 사용 하 여 숫자의 8 봉합 패턴 2 m m 내경 및 쥐의 복 부 대동맥에 길이 1 cm 이식 anastomose.</li>
	<li>첫째, 9, 3, 12, 및 근 위 측에 6 시 위치 순서 대로 4 개의 anastomoses을 구성 다음 두 봉합 사이 4 바늘 컷된 가장자리 anastomose. 근 위 봉합을 마치고 같은 방법으로 원심 측을 봉합. 참고: 모든 스티치는 네이티브 쪽은 약간은 이식에 포함 된 보장 합니다.</li>
	<li>이식, 흘러 혈액을 있도록 원심 클램프 다음 인접 클램프를 제거.</li>
	<li>멸 균 면봉 또는 스폰지 작은 거 즈를 사용 하 여 출혈을 막으려고 봉합 끝을 누릅니다. 약 3 분, hemostasis 때까지 누릅니다.</li>
	<li>복 부 구멍으로 내장을 반환 합니다.</li>
	<li>플러시 gentamicin (320 U/mL)와 따뜻한 생리 식 염 수 솔루션을 사용 하 여 복 부 구멍.</li>
	<li>각각 근육과 피부 층에 3-0 나일론 봉합 사를 사용 하 여 복 벽을 바느질.</li>
	<li>깨끗 하 고 건조 감 금 소에 쥐를 놓고 동물 체온; 유지 케이지 난방 패드를 넣어 마 취에서 회복 하기 위해 쥐를 기다립니다. Sternal recumbency를 유지 하기 위해 충분 한 의식 회복 될 때까지 동물에 참석.</li>
	<li>후 의식 회복, 음식과 물을 함께 단일 케이지에 쥐를 넣어. 수술 후 감염을 방지 하기 위해 상처에 요오드를 적용 합니다. 그것은 완벽 하 게 복구 될 때까지 다른 동물의 회사에는 쥐를 반환 합니다.</li>
	<li>미리 정해진된 시간 지점에서 기관 지침에 따라 쥐 안락사</li>
</ol>

<ol>
	<li>Coombs, K. E., Leonard, A. T., Rush, M. N., Santistevan, D. A., Hedberg-Dirk, E. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isolated+effect+of+material+stiffness+on+valvular+interstitial+cell+differentiation.">Isolated effect of material stiffness on valvular interstitial cell differentiation.</a> J Biomed Mater Res A. 105 (1), 51-61 (2017).</li><li>Zhang, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+sandwich+tubular+scaffold+derived+from+chitosan+for+blood+vessel+tissue+engineering.">A sandwich tubular scaffold derived from chitosan for blood vessel tissue engineering.</a> J Biomed Mater Res A. 77 (2), 277-284 (2006).</li><li>Thottappillil, N., Nair, P. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Scaffolds+in+vascular+regeneration:+current+status.">Scaffolds in vascular regeneration: current status.</a> Vasc Health Risk Manag. 11, 79-91 (2015).</li><li>Pektok, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Degradation+and+healing+characteristics+of+small-diameter+poly+(e-caprolactone)+vascular+grafts+in+the+rat+systemic+arterial+circulation.">Degradation and healing characteristics of small-diameter poly (e-caprolactone) vascular grafts in the rat systemic arterial circulation.</a> Circulation. 118 (24), 2563-2570 (2008).</li><li>Innocente, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Paclitaxel-eluting+biodegradable+synthetic+vascular+prostheses:+a+step+towards+reduction+of+neointima+formation?.">Paclitaxel-eluting biodegradable synthetic vascular prostheses: a step towards reduction of neointima formation?.</a> Circulation. 120 (11 Suppl), S37-S45 (2009).</li><li>de Valence, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advantages+of+bilayered+vascular+grafts+for+surgical+applicability+and+tissue+regeneration.">Advantages of bilayered vascular grafts for surgical applicability and tissue regeneration.</a> Acta Biomater. 8 (11), 3914-3920 (2012).</li><li>Assmann, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Acceleration+of+autologous+in+vivo+recellularization+of+decellularized+aortic+conduits+by+fibronectin+surface+coating.">Acceleration of autologous in vivo recellularization of decellularized aortic conduits by fibronectin surface coating.</a> Biomaterials. 34 (25), 6015-6026 (2013).</li><li>Hasan, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electrospun+scaffolds+for+tissue+engineering+of+vascular+grafts.">Electrospun scaffolds for tissue engineering of vascular grafts.</a> Acta Biomater. 10 (1), 11-25 (2014).</li><li>Baker, B. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+potential+to+improve+cell+infiltration+in+composite+fiber-aligned+electrospun+scaffolds+by+the+selective+removal+of+sacrificial+fibers.">The potential to improve cell infiltration in composite fiber-aligned electrospun scaffolds by the selective removal of sacrificial fibers.</a> Biomaterials. 29 (15), 2348-2358 (2008).</li><li>Wang, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Creation+of+macropores+in+electrospun+silk+fibroin+scaffolds+using+sacrificial+PEO-microparticles+to+enhance+cellular+infiltration.">Creation of macropores in electrospun silk fibroin scaffolds using sacrificial PEO-microparticles to enhance cellular infiltration.</a> Journal of Biomedical Materials Research Part A. 101 (12), 3474-3481 (2013).</li><li>Lee, B. L. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Femtosecond+laser+ablation+enhances+cell+infiltration+into+three-dimensional+electrospun+scaffolds.">Femtosecond laser ablation enhances cell infiltration into three-dimensional electrospun scaffolds.</a> Acta Biomaterialia. 8 (7), 2648-2658 (2012).</li><li>Rnjak-Kovacina, J., Weiss, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Increasing+the+pore+size+of+electrospun+scaffolds.">Increasing the pore size of electrospun scaffolds.</a> Tissue Eng Part B Rev. 17 (5), 365-372 (2011).</li><li>Zhong, S., Zhang, Y., Lim, C. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fabrication+of+large+pores+in+electrospun+nanofibrous+scaffolds+for+cellular+infiltration:+a+review.">Fabrication of large pores in electrospun nanofibrous scaffolds for cellular infiltration: a review.</a> Tissue Eng Part B Rev. 18 (2), 77-87 (2012).</li><li>Pham, Q. P., Sharma, U., Mikos, A. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Electrospun+poly(epsilon-caprolactone)+microfiber+and+multilayer+nanofiber/microfiber+scaffolds:+characterization+of+scaffolds+and+measurement+of+cellular+infiltration.">Electrospun poly(epsilon-caprolactone) microfiber and multilayer nanofiber/microfiber scaffolds: characterization of scaffolds and measurement of cellular infiltration.</a> Biomacromolecules. 7 (10), 2796-2805 (2006).</li><li>Rnjak-Kovacina, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tailoring+the+porosity+and+pore+size+of+electrospun+synthetic+human+elastin+scaffolds+for+dermal+tissue+engineering.">Tailoring the porosity and pore size of electrospun synthetic human elastin scaffolds for dermal tissue engineering.</a> Biomaterials. 32 (28), 6729-6736 (2011).</li><li>Wang, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+thick+fibers+and+large+pores+of+electrospun+poly(epsilon-caprolactone)+vascular+grafts+on+macrophage+polarization+and+arterial+regeneration.">The effect of thick fibers and large pores of electrospun poly(epsilon-caprolactone) vascular grafts on macrophage polarization and arterial regeneration.</a> Biomaterials. 35 (22), 5700-5710 (2014).</li><li>Hutcheson, J. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genesis+and+growth+of+extracellular-vesicle-derived+microcalcification+in+atherosclerotic+plaques.">Genesis and growth of extracellular-vesicle-derived microcalcification in atherosclerotic plaques.</a> Nat Mater. 15 (3), 335-343 (2016).</li><li>Tara, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Well-organized+neointima+of+large-pore+poly(L-lactic+acid)+vascular+graft+coated+with+poly(L-lactic-co-epsilon-caprolactone)+prevents+calcific+deposition+compared+to+small-pore+electrospun+poly(L-lactic+acid)+graft+in+a+mouse+aortic+implantation+model.">Well-organized neointima of large-pore poly(L-lactic acid) vascular graft coated with poly(L-lactic-co-epsilon-caprolactone) prevents calcific deposition compared to small-pore electrospun poly(L-lactic acid) graft in a mouse aortic implantation model.</a> Atherosclerosis. 237 (2), 684-691 (2014).</li></ol>

저자 아무 충돌 금융 관심 있다.

셀 침투는 중생에 대 한 중요 하 고16 vivo에서혈관 이식의 개장 이다. 제한 된 셀 침투는 종종 이식 벽으로 세포의 이동 방해는 이식의 상대적으로 작은 구멍 관련이 있습니다. 이 문제를 해결 하려면 우리는 큰 기 공 구조 electrospun PCL 혈관 이식 준비 하 수정된 방법을 개발. 세부 사항에, 기 공 크기는 쉽게 처리 매개 변수에 의해 제어 될 수 있는 섬유 두께의 증가 함께 증가...

합성 중합체에서 만든 혈관 이식 심장 혈관 질병 (CVDs)의 치료를 위한 병원에 널리 활용 됩니다. 불행히도, 작은 직경의 혈관 이식의 경우 (D < 6 m m) 사용할 수 없습니다 종종 이르게 혈전 증, 내 증식, 그리고 다른 감소 된 혈액 흐름 속도 의해 발생 하는 낮은 patency 성공적인 제품 있다 합병증1.
조직 공학 장기 patency 및 항상성 비 계 기반 혈관 재생 및 재건에 따라 실현 하는 대체 전략을 제공 합니다. 자세히, 혈관 이식, 3 차원 서식 파일로 제공할 수 있는 기계적인 지원 및 혈관 조직 및 기능의 영향 세포, 세포 접착, 이동, 확산를 포함 하 여 재생 하는 동안 구조 지도 기질2분 지금까지, 다양 한 합성 폴리머 혈관 조직 공학에서 응용 프로그램에 대 한 평가. 이러한 고분자 중 poly(ε-caprolactone) (PCL)가 집중적으로 조사 좋은 셀 호환성 및 느린 저하 몇 개월에서 2 년3에 이르기까지. 쥐 대동맥 모델4,,56, PCL 혈관 이식 전기 처리 우수한 구조적 무결성 및 patency, 뿐만 아니라 지속적으로 증가 세포 침입과에서 neovascularization 전시는 최대 6 개월까지 이식 벽입니다. 그러나, 불리 한 조직 세포와 모세 혈관의 석 회화, 회귀를 포함 하 여 리 모델링 또한 관찰 되었다 더 긴 timepoints에서 최대 18 개월.
Cellularization 혈관 이식의 조직 재생을 결정 하 고7을 remolding 핵심 요소입니다. 전기, 다양 한 기법으로는 널리 고용 나노 섬유 구조8혈관 이식의 준비에 대 한. 불행히도, 상대적으로 작은 기 공 구조는 종종 후속 조직 재생을 제한 하는 electrospun 혈관 이식에 부족 한 세포 침투를 끈다. 이 문제를 해결 하려면 다양 한 기술은 시도 기 공 크기와 전반적인 다공성,9,10, 수집 장치, 레이저 방사선11에 의해 치료 후의 수정 leaching 소금/폴리머를 포함 하 여 증가 , 등등. 사실, electrospun 이식 (를 포함 하 여 섬유 직경, 기 공 크기 및 다공성)의 구조는 밀접 하 게 관련이 처리 조건12,13. 중 전기, 섬유 직경 폴리머 솔루션, 흐름 속도, 전압 등의 농도 같은 매개 변수를 변경 하 여 쉽게 제어할 수 있습니다. 14 , 15, 그러므로, 숨 구멍 크기와 다공성 향상 되었습니다 따라와.
우리는 최근 macroporous 구조 (5-7 µ m의 직경 및 30-40 µ m의 모 섬유) 수정된 PCL electrospun 이식을 했다. Vivo에서 쥐 복 부 대동맥을 대체 하 여 이식 3 개월 후 수술16patency, 좋은 endothelialization, 부드러운 근육 중생의 높은 비율을 보였다. 더 중요 한 것은, 아니 불리 한 조직의 석 회화 및 셀 회귀를 포함 하 여 개장 이식의 1 년 후에 관찰 될 수 있었다.

<table>
	<tbody>
		<tr>
			<td>Poly(&#949;-caprolactone) (PCL) pellets (Mn=80,000)</td>
			<td>Sigma</td>
			<td>704067</td>
			<td></td>
		</tr>
		<tr>
			<td>Methanol</td>
			<td>Tianjin Chemical Reagent Company</td>
			<td>1060</td>
			<td></td>
		</tr>
		<tr>
			<td>Alcohol</td>
			<td>Tianjin Chemical Reagent Company</td>
			<td>1083</td>
			<td></td>
		</tr>
		<tr>
			<td>Chloroform</td>
			<td>Tianjin Chemical Reagent Company</td>
			<td>A1007</td>
			<td></td>
		</tr>
		<tr>
			<td>Sucrose</td>
			<td>Tianjin Fengchuan Company</td>
			<td>2296</td>
			<td></td>
		</tr>
		<tr>
			<td>Triton X-100</td>
			<td>Alfa Aesar</td>
			<td>A16046</td>
			<td></td>
		</tr>
		<tr>
			<td>Sprague Dawley rats</td>
			<td>Laboratory Animal Center of the Academy of Military Medical Sciences</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Normal saline</td>
			<td>Hebei Tiancheng Pharmaceutical company</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Chloral hydrate</td>
			<td>Tianjin Ruijinte chemical company</td>
			<td>2223</td>
			<td></td>
		</tr>
		<tr>
			<td>Heparin sodium Injection</td>
			<td>Tianjin Biochem Pharmaceutical company</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Gentamycin Sulfate Injection</td>
			<td>Jiangsu Lianshui Pharmaceutical company</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Mouse anti-&#945;-SMA primary antibody</td>
			<td>Abcam</td>
			<td>ab7817</td>
			<td></td>
		</tr>
		<tr>
			<td>Mouse anti-smooth MYH primary antibody</td>
			<td>Abcam</td>
			<td>ab683</td>
			<td></td>
		</tr>
		<tr>
			<td>Rabbit polyclonal anti-rat elastin antibody</td>
			<td>Abcam</td>
			<td>ab23748</td>
			<td></td>
		</tr>
		<tr>
			<td>Rabbit anti-von Willebrand factor primary antibody</td>
			<td>Abcam</td>
			<td>ab6994</td>
			<td></td>
		</tr>
		<tr>
			<td>Goat anti-mouse IgG (Alexa Fluor 488)</td>
			<td>Invitrogen</td>
			<td>ab150117</td>
			<td></td>
		</tr>
		<tr>
			<td>Goat anti-rabbit IgG (Alexa Fluor 488)</td>
			<td>Invitrogen</td>
			<td>ab150077</td>
			<td></td>
		</tr>
		<tr>
			<td>5% normal goat serum</td>
			<td>Zhongshan Golden bridge</td>
			<td>ZLI9022</td>
			<td></td>
		</tr>
		<tr>
			<td>Hematoxylin and eosin (H&#38;E)</td>
			<td>Beijing leagene biotech</td>
			<td>DH0006</td>
			<td></td>
		</tr>
		<tr>
			<td>Masson&#39;s trichrome</td>
			<td>Beijing leagene biotech</td>
			<td>DC0032</td>
			<td></td>
		</tr>
		<tr>
			<td>Verhoeff-van Gieson (VVG)</td>
			<td>Beijing leagene biotech</td>
			<td>DC0059</td>
			<td></td>
		</tr>
		<tr>
			<td>Von Kossa</td>
			<td>Beijing leagene biotech</td>
			<td>DS0003</td>
			<td></td>
		</tr>
		<tr>
			<td>Surgical sutures needles with thread,3-0 silk</td>
			<td>Shanghai Jinhuan medical supplies company</td>
			<td>G3002b</td>
			<td></td>
		</tr>
		<tr>
			<td>Surgical sutures needles with thread,9-0 silk</td>
			<td>Shanghai Jinhuan medical supplies company</td>
			<td>H901</td>
			<td></td>
		</tr>
	</tbody>
</table>

implantation of electrospun vascular grafts with optimized structure in a rat model

여기, 우리는 macroporous PCL 혈관 이식 조작 및 복 부 대동맥 교체의 쥐 모델을 사용 하 여 평가 프로토콜을 설명 하는 프로토콜을 제시. Electrospun 혈관 이식 자주는 이식으로 세포 침투를 제한 하 고 재생성 하 고 개장 하는 신 동맥의 방해는 상대적으로 작은 구멍을가지고 있다. 이 연구에서는 두꺼운 섬유 (5-6 µ m)와 더 큰 모 (~ 30 µ m) PCL 혈관 이식 수정된 처리 기술을 사용 하 여 조작 했다. 이식의 장기 성능 쥐 복 부 대동맥 모델에 주입에 의해 평가 되었다. 초음파 분석은 이식 남아 동맥 또는 이식의 12 개월 후에 발생 하는 협 착 증 없이 특허를 보여주었다. Macroporous 구조는 셀 ingrowth를 개선 하 고 따라서 3 개월에서 재생성 조직 승진. 더 중요 한 것은, 12 개월 후 이식 벽 내 석 회화 등 불리 한 개장의 아무 표시도 없었다. 따라서, 처리 하는 수정 된 macroporous와 electrospun PCL 혈관 이식 장기 이식에 대 한 동맥 대체 될 잠재적인 개최.

PCL 이식 했다 explanted 3 개월 및 12 개월에서 post-operatively 및 hematoxylin에 오신 (H & E), 표준 조직학 기술에 의해 trichrome Masson, 분석 Verhoeff 반 Gieson (VVG), 폰 Kossa, 면역 형광 α-SMA를 위한 얼룩 MYH, vWF, 그리고 엘라 스 틴입니다. 조직학 이미지 똑바로 현미경을 사용 하 여 찍은 그리고 면역 형광 이미지 ﬂuorescence 현미경을 사용 하 여 찍은.
<p class="jove_content" fo:keep-together.within-pag...

Watch this Scientific Journal Video about Implantation of Electrospun Vascular Grafts with Optimized Structure in a Rat Model at JoVE.com

Implantation of Electrospun Vascular Grafts with Optimized Structure in a Rat Model

쥐 모델에 최적화 된 구조를 가진 Electrospun 혈관 이식 술의 이식

여기, 우리는 PCL 두꺼운 섬유와 큰 모 공, 혈관 이식 조작 및 복 부 대동맥 교체의 쥐 모델에서 vivo에서 성능을 평가 하기 위해 프로토콜을 설명 하는 수정 된 전기 방법을 제시.

Here, we present a protocol to fabricate macroporous PCL vascular graft and describe an evaluation protocol by using a rat model of abdominal aorta ...
