This research was supported by the Department of Veterans Affairs Career Development Award 1IK2BX001701, CTSA award UL1TR000445 from the National Center for Advancing Translational Sciences, the National Science Foundation Award Numbers 1547757 and 1400969, and NIH grant GM05551. Its contents are solely the responsibility of the authors and do not necessarily represent official views of the National Center for Advancing Translational Sciences or the National Institutes of Health.

1. Expression of S100A12
<ol>
	<li>Transform competent BL21 DE3 cells with a pGEMEX-S100a12 plasmid using a standard heat shock protocol18. Add 1 to 5 &#181;L of plasmid to 50 &#181;L of bacteria in a microcentrifuge tube on ice. Incubate for 20 min.</li>
	<li>Heat shock the cells at 42 &#176;C for 30 s.</li>
	<li>Incubate the cells on ice for 2 min.</li>
	<li>Add 500 &#181;L of SOC media to the cells. Incubate at 37 &#176;C with shaking at 250 rpm on an orbital shaker for 1 h.</li>
	<li>Plate 150 &#181;L of the transformation reaction on LB-agar medium (supplemented with 100 &#181;g/mL ampicillin). Incubate for 12-16 h at 37 &#176;C.</li>
	<li>Pick one colony. Inoculate 2 mL of LB (supplemented with 100 &#181;g/mL ampicillin).</li>
	<li>Incubate for 4-6 h at 37 &#176;C on an orbital shaker (300 rpm). The OD600 should read between 1-3 absorbance units.</li>
	<li>Add 500 &#181;L of starter culture to 50 mL of ZYM-5052 autoinduction media26 supplemented with 100 &#181;g/mL of ampicillin. For best aeration and maximum expression, use a 250 mL baffled Erlenmeyer flask. Shake (300 rpm) for 24 h, at 37 &#176;C.</li>
	<li>Transfer bacterial suspension to a centrifuge tube. Pellet the cells by centrifugation (4,000 x g, 10 min) at 4 &#176;C.</li>
	<li>Decant the media, log sample, and store cell paste at -80 &#176;C. Sample is stable for years.</li>
</ol>
2. Purification of S100A12 Using Low Pressure Chromatography
<ol>
	<li>Resuspend cells in 30 mL of 20 mM Tris, pH 8.0.</li>
	<li>Sonicate the suspension on ice to lyse cells. Use ~20 W output, 5 s on and 5 s off cycle for 5 min.</li>
	<li>Transfer the solution to high-speed centrifuge tubes. Clarify the cell lysate by centrifugation, 20,000 x g for 30 min at 4 &#176;C.</li>
	<li>Decant the supernatant and transfer to a clean 100 mL polypropylene beaker. Cool the solution by placing the beaker on ice. Add a stir bar and slowly add 11.20 g of ammonium sulfate. Allow the solution to stir on ice for an additional 1 h. This will create a 60% solution of ammonium sulfate and precipitate most of the E. coli endogenous proteins. S100A12 will remain soluble.</li>
	<li>Centrifuge the solution at 4 &#176;C, 20,000 x g for 20 min to pellet the precipitated protein.</li>
	<li>Decant the supernatant and transfer to dialysis tubing (MWCO 3,500 kDa). Dialyze against 1 L of 20 mM Tris, pH 8.0 at 4 &#176;C. Change the dialysis buffer twice. Allow 4 h in between changes.</li>
	<li>Anion exchange chromatography
	<ol>
		<li>Perform chromatography on a low pressure system. Typical flow rate is 1 mL/min.</li>
		<li>Equilibrate a 5 mL Sepharose column with 10 mL of 20 mM Tris, pH 8.0.</li>
		<li>Load the ~40 mL of S100A12 solution using the sample pump (collect the flow through).</li>
		<li>Wash the column with 10 mL of 20 mM Tris, pH 8.</li>
		<li>Develop the column with a 0-30% gradient (Buffer B is 20 mM Tris, pH 8.0, 1 M NaCl) over 19 column volumes (CV, 95 mL). Collect 5 mL fractions.</li>
		<li>Take a 10 &#181;L aliquot of each fraction and analyze using MES SDS PAGE with Coomassie staining. Run gel using constant voltage (20 V/cm) for 30 min.</li>
		<li>Pool fractions containing S100A12. S100A12 runs at ~10 kDa protein on a denaturing gel.</li>
		<li>Concentrate fractions to 5 mL using an ultrafiltration device (MWCO 10 kDa). Centrifuge at 3,000 x g for ~8 min. Take the top fraction.</li>
	</ol>
	</li>
	<li>Size-exclusion chromatography
	<ol>
		<li>Equilibrate S75 column with 1 CV (120 mL) of 20 mM Tris pH 8, 100 mM NaCl.</li>
		<li>Inject &#60; 5 mL of concentrated S100A12 fractions (from the ion exchange chromatography).</li>
		<li>Develop the column at a flow rate of 1 mL/m over 120 mL. Collect 5 mL fractions.</li>
		<li>Take a 10 &#181;L aliquot of each fraction and analyze using SDS PAGE with Coomassie staining. Validate protein identity using western blot or mass spectrometry (calculated molecular mass of monomeric subunit 10,575.0 Da, measured 10575.4 Da).</li>
	</ol>
	</li>
	<li>Pool fractions
	<ol>
		<li>Measure the absorbance of the protein A280 using a spectrophotometer. Use the SEC buffer as a blank. The calculated extinction coefficient for S100A12 homodimer is 5960 M-1 cm-1.
		NOTE: Typical yields are 35-45 mg of S100A12 per 50 mL of culture.</li>
		<li>Aliquot S100A12 into 1.5 mL microcentrifuge tubes (1 mg/tube), flash freeze in liquid nitrogen and store at -80 &#176;C.</li>
	</ol>
	</li>
</ol>
3. Antimicrobial Activity Assays
<ol>
	<li>Streak H. pylori strain G27 onto tryptic soy agar plates supplemented with 5% sheep blood (blood agar plates). Grow 2-3 days at 37 &#176;C in room air supplemented with 5% carbon dioxide.</li>
	<li>Inoculate H. pylori into Brucella broth supplemented with 1x cholesterol. Culture overnight shaking (250 rpm) at 37 &#176;C in room air supplemented with 5% carbon dioxide.</li>
	<li>Dilute H. pylori 1:10 into 50% Brucella broth, 50% calprotectin buffer plus 1x cholesterol and culture in medium alone or supplemented with 100 &#181;M zinc chloride plus 0, 100 or 1,000 &#181;g/mL of purified S100A12. Culture overnight shaking (250 rpm) at 37 &#176;C in room air supplemented with 5% carbon dioxide.</li>
	<li>The following day, perform serial dilutions and plate onto blood agar plates. Allow bacterial colonies to grow for 2-3 days at 37 &#176;C in room air supplemented with 5% carbon dioxide. Enumerate the colony forming units to calculate bacterial growth in the presence or absence of S100A12 and/or exogenous zinc.</li>
</ol>

<ol>
	<li>Schiopu, A., Cotoi, O. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100A8+and+S100A9:+DAMPs+at+the+crossroads+between+innate+immunity,+traditional+risk+factors,+and+cardiovascular+disease.">S100A8 and S100A9: DAMPs at the crossroads between innate immunity, traditional risk factors, and cardiovascular disease.</a> Mediators Inflamm. 2013, 828354 (2013).</li><li>Chen, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100A9+induced+inflammatory+responses+are+mediated+by+distinct+damage+associated+molecular+patterns+(DAMP)+receptors+in+vitro+and+in+vivo.">S100A9 induced inflammatory responses are mediated by distinct damage associated molecular patterns (DAMP) receptors in vitro and in vivo.</a> PLoS One. 10 (2), e0115828 (2015).</li><li>Chernov, A. V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+calcium-binding+proteins+S100A8+and+S100A9+initiate+the+early+inflammatory+program+in+injured+peripheral+nerves.">The calcium-binding proteins S100A8 and S100A9 initiate the early inflammatory program in injured peripheral nerves.</a> J Biol Chem. 290 (18), 11771-11784 (2015).</li><li>Fanjul, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Presence+of+MRP8+and+MRP14+in+pancreatic+cell+lines:+differential+expression+and+localization+in+CFPAC-1+cells.">Presence of MRP8 and MRP14 in pancreatic cell lines: differential expression and localization in CFPAC-1 cells.</a> Am J Physiol. 268 (5 Pt 1), C1241-C1251 (1995).</li><li>Vogl, T., Gharibyan, A. L., Morozova-Roche, L. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pro-inflammatory+S100A8+and+S100A9+proteins:+self-assembly+into+multifunctional+native+and+amyloid+complexes.">Pro-inflammatory S100A8 and S100A9 proteins: self-assembly into multifunctional native and amyloid complexes.</a> Int J Mol Sci. 13 (3), 2893-2917 (2012).</li><li>Smith, S. P., Shaw, G. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+change-in-hand+mechanism+for+S100+signalling.">A change-in-hand mechanism for S100 signalling.</a> Biochem Cell Biol. 76 (2-3), 324-333 (1998).</li><li>Bresnick, A. R., Weber, D. J., Zimmer, D. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100+proteins+in+cancer.">S100 proteins in cancer.</a> Nat Rev Cancer. 15 (2), 96-109 (2015).</li><li>Leclerc, E., Heizmann, C. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+importance+of+Ca2+/Zn2++signaling+S100+proteins+and+RAGE+in+translational+medicine.">The importance of Ca2+/Zn2+ signaling S100 proteins and RAGE in translational medicine.</a> Front Biosci (Schol Ed). 3, 1232-1262 (2011).</li><li>Goyette, J., Geczy, C. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inflammation-associated+S100+proteins:+new+mechanisms+that+regulate+function.">Inflammation-associated S100 proteins: new mechanisms that regulate function.</a> Amino Acids. 41 (4), 821-842 (2011).</li><li>Kehl-Fie, T. E., Skaar, E. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nutritional+immunity+beyond+iron:+a+role+for+manganese+and+zinc.">Nutritional immunity beyond iron: a role for manganese and zinc.</a> Curr Opin Chem Biol. 14 (2), 218-224 (2010).</li><li>Zackular, J. P., Chazin, W. J., Skaar, E. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nutritional+Immunity:+S100+Proteins+at+the+Host-Pathogen+Interface.">Nutritional Immunity: S100 Proteins at the Host-Pathogen Interface.</a> J Biol Chem. 290 (31), 18991-18998 (2015).</li><li>Realegeno, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100A12+Is+Part+of+the+Antimicrobial+Network+against+Mycobacterium+leprae+in+Human+Macrophages.">S100A12 Is Part of the Antimicrobial Network against Mycobacterium leprae in Human Macrophages.</a> PLoS Pathog. 12 (6), e1005705 (2016).</li><li>Perera, C., McNeil, H. P., Geczy, C. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100+Calgranulins+in+inflammatory+arthritis.">S100 Calgranulins in inflammatory arthritis.</a> Immunol Cell Biol. 88 (1), 41-49 (2010).</li><li>Moroz, O. V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structure+of+the+human+S100A12-copper+complex:+implications+for+host-parasite+defence.">Structure of the human S100A12-copper complex: implications for host-parasite defence.</a> Acta Crystallogr D Biol Crystallogr. 59 (Pt 5), 859-867 (2003).</li><li>Moroz, O. V., Blagova, E. V., Wilkinson, A. J., Wilson, K. S., Bronstein, I. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+crystal+structures+of+human+S100A12+in+apo+form+and+in+complex+with+zinc:+new+insights+into+S100A12+oligomerisation.">The crystal structures of human S100A12 in apo form and in complex with zinc: new insights into S100A12 oligomerisation.</a> J Mol Biol. 391 (3), 536-551 (2009).</li><li>Moroz, O. V., Dodson, G. G., Wilson, K. S., Lukanidin, E., Bronstein, I. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiple+structural+states+of+S100A12:+A+key+to+its+functional+diversity.">Multiple structural states of S100A12: A key to its functional diversity.</a> Microsc Res Tech. 60 (6), 581-592 (2003).</li><li>Cunden, L. S., Gaillard, A., Nolan, E. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Calcium+Ions+Tune+the+Zinc-Sequestering+Properties+and+Antimicrobial+Activity+of+Human+S100A12.">Calcium Ions Tune the Zinc-Sequestering Properties and Antimicrobial Activity of Human S100A12.</a> Chem Sci. 7 (2), 1338-1348 (2016).</li><li>Haley, K. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Human+Antimicrobial+Protein+Calgranulin+C+Participates+in+Control+of+Helicobacter+pylori+Growth+and+Regulation+of+Virulence.">The Human Antimicrobial Protein Calgranulin C Participates in Control of Helicobacter pylori Growth and Regulation of Virulence.</a> Infect Immun. 83 (7), 2944-2956 (2015).</li><li>Cover, T. L., Blaser, M. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Helicobacter+pylori+in+health+and+disease.">Helicobacter pylori in health and disease.</a> Gastroenterology. 136 (6), 1863-1873 (2009).</li><li>Tham, K. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Helicobacter+pylori+genotypes,+host+factors,+and+gastric+mucosal+histopathology+in+peptic+ulcer+disease.">Helicobacter pylori genotypes, host factors, and gastric mucosal histopathology in peptic ulcer disease.</a> Hum Pathol. 32 (3), 264-273 (2001).</li><li>Wotherspoon, A. C., Ortiz-Hidalgo, C., Falzon, M. R., Isaacson, P. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Helicobacter+pylori-associated+gastritis+and+primary+B-cell+gastric+lymphoma.">Helicobacter pylori-associated gastritis and primary B-cell gastric lymphoma.</a> Lancet. 338 (8776), 1175-1176 (1991).</li><li>Correa, P., Piazuelo, M. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+gastric+precancerous+cascade.">The gastric precancerous cascade.</a> J Dig Dis. 13 (1), 2-9 (2012).</li><li>de Martel, C., Forman, D., Plummer, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Gastric+cancer:+epidemiology+and+risk+factors.">Gastric cancer: epidemiology and risk factors.</a> Gastroenterol Clin North Am. 42 (2), 219-240 (2013).</li><li>Algood, H. M., Gallo-Romero, J., Wilson, K. T., Peek, R. M., Cover, T. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Host+response+to+Helicobacter+pylori+infection+before+initiation+of+the+adaptive+immune+response.">Host response to Helicobacter pylori infection before initiation of the adaptive immune response.</a> FEMS Immunol Med Microbiol. 51 (3), 577-586 (2007).</li><li>Gaddy, J. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+host+protein+calprotectin+modulates+the+Helicobacter+pylori+cag+type+IV+secretion+system+via+zinc+sequestration.">The host protein calprotectin modulates the Helicobacter pylori cag type IV secretion system via zinc sequestration.</a> PLoS Pathog. 10 (10), e1004450 (2014).</li><li>Studier, F. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stable+expression+clones+and+auto-induction+for+protein+production+in+E.+coli.">Stable expression clones and auto-induction for protein production in E. coli.</a> Methods Mol Biol. 1091, 17-32 (2014).</li><li>Gilston, B. A., Skaar, E. P., Chazin, W. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Binding+of+transition+metals+to+S100+proteins.">Binding of transition metals to S100 proteins.</a> Sci China Life Sci. 59 (8), 792-801 (2016).</li><li>Corbin, B. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Metal+chelation+and+inhibition+of+bacterial+growth+in+tissue+abscesses.">Metal chelation and inhibition of bacterial growth in tissue abscesses.</a> Science. 319 (5865), 962-965 (2008).</li><li>Kehl-Fie, T. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nutrient+metal+sequestration+by+calprotectin+inhibits+bacterial+superoxide+defense,+enhancing+neutrophil+killing+of+Staphylococcus+aureus.">Nutrient metal sequestration by calprotectin inhibits bacterial superoxide defense, enhancing neutrophil killing of Staphylococcus aureus.</a> Cell Host Microbe. 10 (2), 158-164 (2011).</li><li>Liu, J. Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Zinc+sequestration+by+the+neutrophil+protein+calprotectin+enhances+Salmonella+growth+in+the+inflamed+gut.">Zinc sequestration by the neutrophil protein calprotectin enhances Salmonella growth in the inflamed gut.</a> Cell Host Microbe. 11 (3), 227-239 (2012).</li><li>Damo, S. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+basis+for+manganese+sequestration+by+calprotectin+and+roles+in+the+innate+immune+response+to+invading+bacterial+pathogens.">Molecular basis for manganese sequestration by calprotectin and roles in the innate immune response to invading bacterial pathogens.</a> Proc Natl Acad Sci U S A. 110 (10), 3841-3846 (2013).</li><li>Nakashige, T. G., Zhang, B., Krebs, C., Nolan, E. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+calprotectin+is+an+iron-sequestering+host-defense+protein.">Human calprotectin is an iron-sequestering host-defense protein.</a> Nat Chem Biol. 11 (10), 765-771 (2015).</li><li>Gaddy, J. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Helicobacter+pylori+Resists+the+Antimicrobial+Activity+of+Calprotectin+via+Lipid+A+Modification+and+Associated+Biofilm+Formation.">Helicobacter pylori Resists the Antimicrobial Activity of Calprotectin via Lipid A Modification and Associated Biofilm Formation.</a> MBio. 6 (6), e01349-e01315 (2015).</li><li>Testerman, T. L., Conn, P. B., Mobley, H. L., McGee, D. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nutritional+requirements+and+antibiotic+resistance+patterns+of+Helicobacter+species+in+chemically+defined+media.">Nutritional requirements and antibiotic resistance patterns of Helicobacter species in chemically defined media.</a> J Clin Microbiol. 44 (5), 1650-1658 (2006).</li><li>Leach, S. T., Mitchell, H. M., Geczy, C. L., Sherman, P. M., Day, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=S100+calgranulin+proteins+S100A8,+S100A9+and+S100A12+are+expressed+in+the+inflamed+gastric+mucosa+of+Helicobacter+pylori-infected+children.">S100 calgranulin proteins S100A8, S100A9 and S100A12 are expressed in the inflamed gastric mucosa of Helicobacter pylori-infected children.</a> Can J Gastroenterol. 22 (5), 461-464 (2008).</li><li>Wilkie-Grantham, R. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Myeloperoxidase-dependent+lipid+peroxidation+promotes+the+oxidative+modification+of+cytosolic+proteins+in+phagocytic+neutrophils.">Myeloperoxidase-dependent lipid peroxidation promotes the oxidative modification of cytosolic proteins in phagocytic neutrophils.</a> J Biol Chem. 290 (15), 9896-9905 (2015).</li></ol>

The authors declare that they have no competing financial interests.

An efficient protocol for both expression and purification of human S100A12 is presented. The E. coli expression system is the most common tool used for the production of recombinant proteins, particularly when mg quantities are required for biochemical and biophysical studies. A key enhancement of the procedure described here is the use of auto-induction media26 which increases the yield of purified protein by a factor of almost thirty as compared to expression with standard Luria-broth ...

S100 proteins are a class of the EF-hand family of calcium binding proteins with a diverse array of functions1. They are expressed in a tissue and cell specific manner, and regulate a broad spectrum of cellular functions2,3. Unique to calcium binding proteins, S100 proteins exhibit both intracellular and extracellular functions4,5. Within the cell, Ca2+ binding induces a conformational change that exposes a hydrophobic surface that specifically targets protein binding partners6. This intracellular mechanism regulates important processes such as cell proliferation, differentiation and energy metabolism. In the extracellular milieu, S100 proteins exhibit two functions7. In one, they act as damage associated molecular pattern (DAMP) proteins and initiate a pro-inflammatory immune response through interaction with pattern recognition receptors8,9. Additionally, several members of the S100 protein class sequester transition metals, a function that serves to starve microbial pathogens in a process termed nutritional immunity10,11.
S100A12 (also known as calgranulin C and EN-RAGE) is highly expressed in macrophages and neutrophils and has been identified as a potential biomarker for inflammatory diseases12,13. In addition to binding calcium at its EF-Hand sites, S100A12 has two high affinity transition metal binding sites located at opposite ends of the dimer interface14,15. Each binding site is comprised of three histidine residues and one aspartic acid residue and can chelate zinc or copper16,17. Recently, we reported that S100A12-dependent zinc starvation is important in regulating Helicobacter pylori growth and the activity of pro-inflammatory virulence factors18.
H. pylori infects the stomach of about half of the world&#39;s human population; making it arguably one of the most successful bacterial pathogens19. Infection with H. pylori can lead to significant gastric disease outcomes including gastritis, peptic and duodenal ulcer, mucosa associated lymphoid tissue (MALT) lymphoma, and invasive gastric adenocarcinoma (stomach cancer). Stomach cancer is the leading cause of non-cardia cancer-associated death in the world, and the single biggest associated risk factor for stomach cancer is infection with H. pylori.
H. pylori persists in the gastric niche despite a robust immune response to the pathogen, underscoring the need for a better understanding of immune mechanisms of controlling this bacterial infection20,21,22,23. H. pylori-associated inflammation is characterized by a profound infiltration of polymorphonuclear cells, or neutrophils, which deposit a repertoire of antimicrobial proteins, including S100A12, at the site of infection18,24,25. In an effort to understand the complex dialogue between host and pathogen, we sought to refine the technique to purify S100A12 and use it to study the antimicrobial affect it exerts upon this medically relevant pathogen. The protocol below outlines an improved technique for S100A12 purification in its biologically active state; capable of binding nutrient metals with high affinity and chelating them away from invading microorganisms. Furthermore, the methods below highlight the utility of this protein as a critical reagent to study the mechanism by which innate antimicrobial molecules restrict the growth of bacterial pathogens.
S100A-family proteins have gained appreciation as an important group of innate immune system molecules which participate in immune signaling as well as host defense27. The most well-studied of these is calprotectin (MRP-8/14, calgranulin A/B, S100A8/A9)28,29,30. Calprotectin is a neutrophil-associated protein which forms a heterodimer of the S100A8 and S100A9 subunits which binds transition metals at the dimer interface31. Calprotectin has been shown to possess two metal binding sites: Site 1 can bind Zn2+, Mn2+, or Fe2+, and Site 2 can bind Zn2+ 31,32. Numerous reports have demonstrated that calprotectin has antimicrobial activities against diverse pathogens including Staphylococcus aureus, Candida albicans, Acinetobacter baumannii, Klebsiella pneumoniae, Escherichia coli, and H. pylori, and that the inhibitory effects are due to the metal chelation activity of calprotectin25,28,29.
Previous work demonstrated calprotectin exerts numerous activities on H. pylori including altering the lipid A structure in the outer membrane, repressing the cag-Type IV secretion system (which is a major proinflammatory virulence factor within H. pylori), inducing biofilm formation, and repressing H. pylori growth and viability in a dose-dependent manner25,33. Furthermore, genetic and biochemical assays revealed the antibacterial activity of calprotectin against H. pylori was largely derived from its ability to bind nutrient zinc25. H. pylori requires zinc, as was determined by previous research which utilized a chemically defined medium to ascertain the micronutrient requirements for this pathogen to grow and proliferate34. Additionally, calprotectin was highly abundant within H. pylori-infected tissues, and associated with neutrophilic infiltrates, indicating the host may be employing calprotectin as an antimicrobial strategy during infection and subsequent inflammation25,35.
Recent evidence from unbiased proteomics screening techniques suggests that under conditions where reactive oxygen species are plentiful, calprotectin undergoes post-translational modifications which alter the hexa-histidine binding site, thereby inhibiting the metal-binding activity of the protein36. As such, we hypothesized that other S100A-family proteins among the wide repertoire of these molecules could potentially act as auxiliary metal-chelators. We selected S100A12 for further study because it was not identified in the aforementioned screen for post-translational modification, it has the capacity to bind zinc, and it is highly abundant in human tissues derived from H. pylori-infected individuals.
Our work indicates that S100A12 can inhibit H. pylori growth and viability in a dose-dependent manner in the G27 strain of H. pylori, and that the antimicrobial activity of this protein can be reversed by the addition of excess nutrient zinc. This work complements our previous work indicating S100A12 exerted antimicrobial activity against PMSS1 and 7.13 strains of H. pylori, demonstrating its broad antibacterial activity against numerous clinical isolates and laboratory-adapted strains of H. pylori18. Together, these results confirm the importance of S100A12 as a mechanism to control bacterial growth and proliferation via nutritional immunity. Future studies of this important host-bacterial interaction could include exploiting the activity of S100A12 to reduce bacterial burden within host tissues, or determining the contribution of this protein to immune signaling in the context of H. pylori infection.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>S100A12 Expression</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Expression cells</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>BL 21 (DE3) competent cells</td>
			<td>New England Biolabs</td>
			<td>C25271</td>
		</tr>
		<tr>
			<td>Autoinduction medium components</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Yeast Extract</td>
			<td>Research Products International</td>
			<td>Y20020-250.0</td>
		</tr>
		<tr>
			<td>NaCl</td>
			<td>Research Products International</td>
			<td>S23020-500.0</td>
		</tr>
		<tr>
			<td>Tryptone</td>
			<td>Research Products International</td>
			<td>T60060-250.0</td>
		</tr>
		<tr>
			<td>FeCl3</td>
			<td>Sigma-Aldrich</td>
			<td>F2877</td>
		</tr>
		<tr>
			<td>MgSO4</td>
			<td>Research Products International</td>
			<td>M65240-100.0</td>
		</tr>
		<tr>
			<td>Na2HPO4</td>
			<td>Research Products International</td>
			<td>S23100-500.0</td>
		</tr>
		<tr>
			<td>KH2PO4</td>
			<td>Research Products International</td>
			<td>P41200-500.0</td>
		</tr>
		<tr>
			<td>NH4Cl</td>
			<td>Research Products International</td>
			<td>A20424-500.0</td>
		</tr>
		<tr>
			<td>Na2SO4</td>
			<td>Research Products International</td>
			<td>S25150-500.0</td>
		</tr>
		<tr>
			<td>Glycerol</td>
			<td>Research Products International</td>
			<td>G22020-1.0</td>
		</tr>
		<tr>
			<td>D-glucose</td>
			<td>Research Products International</td>
			<td>G32040-500.0</td>
		</tr>
		<tr>
			<td>lactose</td>
			<td>Sigma-Aldrich</td>
			<td>L2643</td>
		</tr>
		<tr>
			<td>Selection agent</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>ampicillin</td>
			<td>Research Products International</td>
			<td>A40040-5.0</td>
		</tr>
		<tr>
			<td>S100A12 Purification</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>AKTA Start Chromatography System</td>
			<td>GE</td>
			<td>29-220-94</td>
		</tr>
		<tr>
			<td>HiTrap Q Sepharaose Fast Flow</td>
			<td>GE</td>
			<td>17-5156-01</td>
		</tr>
		<tr>
			<td>HiPrep 16/60 S-200 HR</td>
			<td>GE</td>
			<td>17-1166-01</td>
		</tr>
		<tr>
			<td>Nanodrop lite spectrophotometer</td>
			<td>Thermo Fisher Scientific</td>
			<td>ND-LITE</td>
		</tr>
		<tr>
			<td>Tris Base</td>
			<td>Research Products International</td>
			<td>T60040-1000.0</td>
		</tr>
		<tr>
			<td>H. pylori Culture</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Blood agar plates</td>
			<td>Lab Supply Company</td>
			<td>BBL221261</td>
		</tr>
		<tr>
			<td>Brucella broth</td>
			<td>Sigma-Aldrich</td>
			<td>B3051</td>
		</tr>
		<tr>
			<td>Cholesterol (250X)</td>
			<td>Thermo Fisher Scientific</td>
			<td>12531018</td>
		</tr>
		<tr>
			<td>NaCl</td>
			<td>Sigma-Aldrich</td>
			<td>793566</td>
		</tr>
		<tr>
			<td>CaCl2</td>
			<td>Sigma-Aldrich</td>
			<td>C4901</td>
		</tr>
		<tr>
			<td>&#946;-mercaptoethanol</td>
			<td>Sigma-Aldrich</td>
			<td>M6250</td>
		</tr>
		<tr>
			<td>Tris Base</td>
			<td>Sigma-Aldrich</td>
			<td>T1503</td>
		</tr>
		<tr>
			<td>Zinc Chloride</td>
			<td>Sigma-Aldrich</td>
			<td>229997</td>
		</tr>
	</tbody>
</table>

expression, purification, and antimicrobial activity of s100a12

Calgranulin proteins are important mediators of innate immunity and are members of the S100 class of the EF-hand family of calcium binding proteins. Some S100 proteins have the capacity to bind transition metals with high affinity and effectively sequester them away from invading microbial pathogens in a process that is termed "nutritional immunity". S100A12 (EN-RAGE) binds both zinc and copper and is highly abundant in innate immune cells such as macrophages and neutrophils. We report a refined method for the expression, enrichment and purification of S100A12 in its active, metal-binding configuration. Utilization of this protein in bacterial growth and viability analyses reveals that S100A12 has antimicrobial activity against the bacterial pathogen, Helicobacter pylori. The antimicrobial activity is predicated on the zinc-binding activity of S100A12, which chelates nutrient zinc, thereby starving H. pylori which requires zinc for growth and proliferation.

S100A12 expression and purification
A three-step purification produced ~40 mg of recombinant S100A12 from 50 mL of bacterial culture. The first step was an ammonium sulfate precipitation of endogenous E. coli proteins. This step was followed by anion-exchange chromatography (Figure1A). The protein is tracked by a SDS-PAGE stained with Coomassie Brilliant Blue (Figure 1B). ...

Watch this Scientific Journal Video about Expression, Purification, and Antimicrobial Activity of S100A12 at JoVE.com

Expression, Purification, and Antimicrobial Activity of S100A12

Here, we present a method to express and purify S100A12 (calgranulin C). We describe a protocol to measure its antimicrobial activity against the human pathogen H. pylori.
