This work was supported by a grant from the German Research Foundation (DFG; LU1455/1-1).

1. Ex ovo Culture
<ol>
 <li>Fresh fertilized eggs are laid onto their long side in a forced-draft incubator (BSS160, Ehret, Germany) at 37.5 &deg;C with 60% humidity for incubation. Eggs stored at 12 &deg;C for longer than one week should not be used. </li>
 <li>After incubation for 2.5 days (about stage HH17), take out the eggs and label the top with a pencil to indicate direction for cracking. </li>
 <li>Before cracking, pour about 20 ml sterile distilled water into a clean large Petri dish (diameter of 145 mm; Greiner Bio-One GmbH, Germany).</li>
 <li>Place another small sterile Petri dish (diameter of 94 mm; Greiner Bio-One GmbH) into the large Petri dish.</li>
 <li>Crack the eggs on the bottom against a sharp metal edge, carefully open the eggs and transfer the entire content of each egg into the small Petri dish.</li>
 <li>Cover the large Petri dish with a lid and put it into another incubator (BINDER GmbH, Tuttlinge, Germany) for further culture at 37.5 &deg;C with about 60% humidity. After incubation for the desired number of days, the embryos can be used for electroporation. </li>
</ol>
2. Preparation for ex ovo Electroporation
<ol>
 <li>Pull glass capillaries with a microelectrode puller (PUL-100 Micropipette Puller; World Precision Instruments, Berlin, Germany) using glass tubes of 1.0-mm diameter (TW100F-4; World Precision Instruments) and break the tip of the glass capillaries into an appropriate diameter.</li>
 <li>Set up appropriate parameters (i.e., different voltages for the distinct tissues and size of embryos) for electroporation and connect electrodes to an electroporator (CUY21-Edit; Nepa Gene, Chiba, Japan) according to the target tissues and size of embryos. </li>
 <li>Prepare a plasmid solution containing plasmids in pCAGGS vector encoding a target gene, e.g., cadherin7 (Cad7; pCAGGS-Cad7 with a concentration of 2.0 &mu;g/&mu;l) and a marker gene, e.g., green fluorescent protein (GFP; pCAGGS-GFP with a concentration of 0.25 &mu;g/&mu;l). Then add Fast Green with a final concentration of 0.1% (Sigma) to label the plasmid solution with the green color. </li>
 <li>Load the glass capillary with the plasmid solution using a mouth pipette. </li>
</ol>
3. Gene Transfer into Chicken Optic Tectum by ex ovo Electroporation
<ol>
 <li>After ex ovo culture, e.g., by incubation day (E) 6, the chicken embryos are used for ex ovo electroporation.</li>
 <li>Carefully tear the vitelline and amnion membranes over the optic tectum with fine forceps and add 3 drops of sterile 0.9% Sodium Chloride solution on the surface of the tectum.</li>
 <li>Inject the plasmid solution into the cavity of the tectum by glass capillary using the mouth pipette.</li>
 <li>Place the electrodes with a tungsten needle cathode and a rectangle plate anode (CUY 661-3x7, Nepa Gene) beside the tectum, and immediately apply electric pulses (six pulses, 25 V, 60 ms pulse length, 100 ms intervals in each case) produced by the electroporator to the tectum.</li>
 <li>Cover the large Petri dish with the lid and return it into the incubator. After incubation for appropriate days (e.g., 2 or 3 days after electroporation), the tectum are collected and fixed for immunostaining (Figure 1) and biological detection.</li>
</ol>
4. Representative Results
Successful overexpression of the exogenous proteins of Cad7 and GFP by ex ovo electroporation is shown in Figure 1 as an example. When Cad7 plasmid together with GFP plasmid was electroporated into the tectum at E6, two or three days after electroporation the embryos were collected and fixed. At E8, the GFP protein is strongly expressed in the tectum in whole mount images (Figure 1A-C). Furthermore, in the sections of the tectum at E9, GFP protein (green in Figure 1D) and Cad7 protein (red in Figure 1E) are coexpressed (yellow in Figure 1F), suggesting that ex ovo electroporation is a successful method for gene transfer into the older chicken embryos in vivo.
<img src="/files/ftp_upload/4078/4078fig1.jpg" alt="Figure 1"/>
Figure 1. When the plasmids encoding GFP and Cad7 are cotransfected into the chicken tectum at E6, two or three days after ex ovo electroporation, GFP protein (green) is strongly expressed as shown in wholemount images (A-C) at E8. In sections of the tectum at E9, GFP protein (green in D) and Cad7 protein (red in E) are coexpressed (yellow in F). BF, bright field image. Scale bar: 200 &mu;m in A for A-C; 100 &mu;m in D for D-F.

<ol>
	<li>Momose, T., Tonegawa, A., Takeuchi, J., Ogawa, H., Umesono, K., Yasuda, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+targeting+of+gene+expression+in+chick+embryos+by+microelectroporation.">Efficient targeting of gene expression in chick embryos by microelectroporation.</a> Dev. Growth Differ. 41, 335-344 (1999).</li><li>Luo, J., Ju, M. J., Lin, J., Yan, X., Markus, A., Mix, E., Rolfs, A., Redies, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cadherin-20+expression+by+motor+neurons+is+regulated+by+Sonic+hedgehog+during+spinal+cord+development.">Cadherin-20 expression by motor neurons is regulated by Sonic hedgehog during spinal cord development.</a> NeuroReport. 20, 365-370 (2009).</li><li>Luo, J., Ju, M. J., Redies, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Regionalized+cadherin-7+expression+by+radial+glia+is+regulated+by+Shh+and+Pax7+during+chicken+spinal+cord+development.">Regionalized cadherin-7 expression by radial glia is regulated by Shh and Pax7 during chicken spinal cord development.</a> Neuroscience. 142, 1133-1143 (2006).</li><li>Nakamura, H., Katahira, T., Sato, T., Watanabe, Y., Funahashi, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Gain-+and+loss-of-function+in+chick+embryos+by+electroporation.">Gain- and loss-of-function in chick embryos by electroporation.</a> Mech. Dev. 121, 1137-1143 (2004).</li><li>Dai, F., Yusuf, F., Farjah, G. H., Brand-Saberi, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RNAi-induced+targeted+silencing+of+developmental+control+genes+during+chicken+embryogenesis.">RNAi-induced targeted silencing of developmental control genes during chicken embryogenesis.</a> Dev. Biol. 258, 80-90 (2005).</li><li>Rao, M., Baraban, J. H., Rajaii, F., Sockanathan, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+comparative+study+of+RNAi+methodologies+by+in+ovo+electroporation+in+the+chick+embryo.">In vivo comparative study of RNAi methodologies by in ovo electroporation in the chick embryo.</a> Dev. Dyn. 231, 592-600 (2004).</li><li>Kos, R., Tucker, R. P., Hall, R., Duong, T. D., Erickson, C. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Methods+for+introducing+morpholinos+into+the+chicken+embryo.">Methods for introducing morpholinos into the chicken embryo.</a> Dev. Dyn. 226, 470-477 (2003).</li><li>Hamburger, V., Hamilton, H. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+series+of+normal+stages+in+the+development+of+the+chick+embryo.">A series of normal stages in the development of the chick embryo.</a> J. Morphol. 88, 49-92 (1951).</li><li>Auerbach, R., Kubai, L., Knighton, D., Folkman, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+simple+procedure+for+the+long-term+cultivation+of+chicken+embryos.">A simple procedure for the long-term cultivation of chicken embryos.</a> Dev. Biol. 10, 391-394 (1974).</li><li>Luo, J., Treubert-Zimmermann, U., Redies, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cadherins+guide+migrating+Purkinje+cells+to+specific+parasagittal+domains+during+cerebellar+development.">Cadherins guide migrating Purkinje cells to specific parasagittal domains during cerebellar development.</a> Mol. Cell. Neurosci. 25, 138-152 (2004).</li><li>Luo, J., Redies, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ex+ovo+electroporation+for+gene+transfer+into+older+chicken+embryos.">Ex ovo electroporation for gene transfer into older chicken embryos.</a> Dev. Dyn. 233, 1470-1477 (2005).</li><li>Treubert-Zimmermann, U., Heyers, D., Redies, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Targeting+axons+to+specific+fiber+tracts+in+vivo+by+altering+cadherin+expression.">Targeting axons to specific fiber tracts in vivo by altering cadherin expression.</a> J. Neurosci. 22, 7617-7626 (2002).</li></ol>

No conflicts of interest declared.

This protocol provides a guide for gene transfer into older chicken embryos (e.g, into the optic tectum at E6) by ex ovo electroporation. This method extends the use of electroporation to older chicken embryos and can be easily applied to many laboratories for studying gene function in vivo at later stages. Embryos from E4 to at least E7 can be successfully electroporated by this method and the electroporated embryos can be survival until E1511. Besides the brain, this method can be also used...

<table border="1">
<tbody>
 <tr>
 <td>Name</td>
 <td>Company</td>
 <td>Catalog 			Number</td>
 </tr>
 <tr>
 <td>Electroporator</td>
 <td>Nepa Gene, Japan</td>
 <td>CUY21-Edit</td>
 </tr>
 <tr>
 <td>Electrodes</td>
 <td>Nepa Gene, Japan</td>
 <td>CUY661-3x7</td>
 </tr>
 <tr>
 <td>Egg incubator</td>
 <td>Ehret, Germany</td>
 <td>BSS160</td>
 </tr>
 <tr>
 <td>Embryo incubator</td>
 <td>BINDER GmbH, Germany</td>
 <td>&nbsp;</td>
 </tr>
 <tr>
 <td>Fluorescent microscope</td>
 <td>Keyence, 			Deutschland GmbH</td>
 <td>BZ-8000</td>
 </tr>
 <tr>
 <td>Petri dish</td>
 <td>Greiner Bio-One GmbH, 			Germany</td>
 <td>&nbsp;</td>
 </tr>
 <tr>
 <td>Microelectrode puller</td>
 <td>World Precision 			Instruments, Germany</td>
 <td>PUL-100 </td>
 </tr>
 </tbody>
</table>

gene transfer into older chicken embryos by ex ovo electroporation

The chicken embryo provides an excellent model system for studying gene function and regulation during embryonic development. In ovo electroporation is a powerful method to over-express exogenous genes or down-regulate endogenous genes in vivo in chicken embryos1. Different structures such as DNA plasmids encoding genes2-4, small interfering RNA (siRNA) plasmids5, small synthetic RNA oligos6, and morpholino antisense oligonucleotides7 can be easily transfected into chicken embryos by electroporation. However, the application of in ovo electroporation is limited to embryos at early incubation stages (younger than stage HH20 - according to Hamburg and Hamilton)8 and there are some disadvantages for its application in embryos at later stages (older than stage HH22 - approximately 3.5 days of development). For example, the vitelline membrane at later stages is usually stuck to the shall membrane and opening a window in the shell causes rupture of the vessels, resulting in death of the embryos; older embryos are covered by vitelline and allantoic vessels, where it is difficult to access and manipulate the embryos; older embryos move vigorously and is difficult to control the orientation through a relatively small window in the shell.
In this protocol we demonstrate an ex ovo electroporation method for gene transfer into chicken embryos at late stages (older than stage HH22). For ex ovo electroporation, embryos are cultured in Petri dishes9 and the vitelline and allantoic vessels are widely spread. Under these conditions, the older chicken embryos are easily accessed and manipulated. Therefore, this method overcomes the disadvantages of in ovo electroporation applied to the older chicken embryos. Using this method, plasmids can be easily transfected into different parts of the older chicken embryos10-12.

Watch this Scientific Journal Video about Gene Transfer into Older Chicken Embryos by ex ovo Electroporation at JoVE.com

Gene Transfer into Older Chicken Embryos by ex ovo Electroporation

A method of gene transfer into chicken embryos at later incubation stages (older than Hamburger and Hamilton stage (HH) 22) is described. This method overcomes disadvantages of in ovo electroporation applied to older chicken embryos and is a useful technique to study gene function and regulation at older developmental stages.
