1. Photolithography on Stainless Steel
<ol>
	<li>Design the photomask using a mechanical drawing software and fabricate the design by submitting it to a photomask printer4.</li>
	<li>Wash the stainless steel (316 SS; lengthx width: 4 cm x 4 cm, thickness: 1 mm) by rinsing it in alkaline solutions (50 g/L NaOH and 40 g/L Na2CO3) at room temperature for 15 min to remove oil contaminants.</li>
	<li>Thoroughly clean the stainless steel by performing ultrasonic cleaning in an ultrasonic cleaning machine (working frequency: 40 KHz, ultrasonic power: 500 W). Rinse it sequentially with deionized water, n-hexane, acetone, and ethanol for 10 min each.</li>
	<li>Dry the stainless steel by placing it on a hot plate at 150 &#176;C for 30 min. Protect the stainless steel by covering it with a sheet of aluminum (Al) foil.</li>
	<li>Place the stainless steel on the center of a spin coater. Use a dropper to deposit positive photoresist (about 1 mL) onto the stainless steel, from the center to the edge, until the photoresist completely covers the stainless steel. Avoid bubble formation in the photoresist.
	<ol>
		<li>Perform spin-coating, first with a speed of 700 rpm/min for 6 s, to start the spin cycle, and then with a speed of 1,500 rpm/min for 15 s, to evenly spread the photoresist.</li>
	</ol>
	</li>
	<li>Release the vacuum valve and retrieve the stainless steel using a pair of tweezers. Place the stainless steel on a hot plate at 120 &#176;C for 2 min to bake the photoresist.</li>
	<li>Place the stainless steel on the vacuum valve of a photolithography machine. Set the exposure time of the photolithography machine to 25 s.
	NOTE: Here, the photolithography machine is a contact aligner with an ultraviolet (UV) light wavelength of 254 nm and a light intensity of 13 mW/cm2.</li>
	<li>Release the stainless steel and place it in the developer solution for 1 min to remove the photoresist without exposing it to the UV light. Remove the stainless steel from the developer solution, wash it with deionized water, and dry it under N2 gas.</li>
	<li>Place the stainless steel on a hot plate to bake at 120 &#176;C for 2 min.</li>
	<li>Use an upright microscope with a magnification of 100x to observe the surface of the stainless steel to inspect the obtained photoresist texture.</li>
</ol>
2. Chemical Etching of Stainless Steel
<ol>
	<li>Prepare a chemical etching solution with a volume of 200 mL (400 g/L FeCl3, 20 g/L phosphoric acid, and 100 g/L hydrochloric acid) in a 500-mL beaker.</li>
	<li>Place the stainless steel with photoresist texture in the chemical solution for 10 min. Do not allow the stainless-steel pieces to contact each other. Place a maximum of four stainless steel pieces at one time.</li>
	<li>Take out of the chemically etched stainless steel using tweezers, wash the pieces with deionized water for 1 min, and dry them with N2 gas.</li>
	<li>Remove the photoresist texture by submerging the stainless steel in acetone for ultrasonic cleaning for 5 min. Then, dry the chemically etched stainless steel with N2 gas.</li>
</ol>
3. OTS Self-assembly on Chemically Etched Stainless Steel
<ol>
	<li>Clean the chemically etched stainless steel with a steady stream of deionized water, dry it with N2 gas, and place it on a hot plate at 100 &#176;C for 30 min to completely dry the surface.</li>
	<li>Hydroxylate the chemically etched stainless steel with an O2 plasma treatment in an RF plasma machine, with an RF power of 100 W for 10 min, a system pressure of 100 mbar, and a flow rate of 20 sccm.</li>
	<li>Prepare 1 mM OTS solution in anhydrous toluene in a beaker. Dry the beaker thoroughly before solution preparation.</li>
	<li>Rinse the chemically etched stainless steel with the OTS solution for 4 h at room temperature. Place the beaker in a sealed bag. Do not allow the stainless steel pieces to contact each other.</li>
	<li>Remove the stainless steel, clean it with anhydrous toluene by performing ultrasonic cleaning for 10 min, and dry it with N2 gas.</li>
</ol>
4. Slippery Surface Preparation
<ol>
	<li>Deposit approximately 10 mL/cm2 silicone oil (viscosity: 350 cst; surface tension: 21.1 mN/m) onto the OTS-coated, chemically etched stainless steel using a dropper.</li>
	<li>Use an optical stereomicroscope to observe the wetting process of the silicone oil on the stainless-steel surface (magnification of 10x).</li>
	<li>Remove the excess silicone oil by placing the stainless steel in a vertical position for 1 h.</li>
</ol>
5. Investigation of Water Sliding Behavior on Slippery Surfaces
<ol>
	<li>Deposit a 4-&#181;L water droplet on the slippery surface. Place the stainless steel under an optical microscope and tilt the substrate by ~2&#176;.</li>
	<li>Visualize the water droplet sliding on the slippery surface at a low magnification (50x) to check that the slippery surface has the easy sliding property.</li>
</ol>
6. Analysis of Anti-wetting on the Slippery Surface at High Temperatures
<ol>
	<li>Place the stainless steel with a slippery surface on a hot plate using tweezers. Set the hot plate at different high temperatures (i.e., 200 &#176;C, 250 &#176;C, and 300 &#176;C) to analyze the anti-wetting behaviors at different temperatures.
	NOTE: Do not directly touch the high-temperature stainless steel with hands.</li>
	<li>Use a micro-syringe to deposit a 10-&#181;L water droplet on the slippery surface.
	NOTE: Before dropping the water droplet, the temperature of the slippery surface should reach equilibrium.</li>
	<li>Use a high-speed camera to record the water droplet movement at a frame rate of 500 Hz.
	<ol>
		<li>Fix the camera to a tripod and direct the lens of the camera toward the stainless steel. Adjust the focus of the camera to obtain a clear water droplet image. Record the movement of the water droplet on the stainless-steel surface by pushing the start button of the camera. Push the end button of the camera when the water droplet slides off the stainless steel to complete the recording.</li>
	</ol>
	</li>
</ol>
7. Analysis of the Anti-adhesion Effects of the Slippery Surface on Soft Tissue
<ol>
	<li>Use a manipulator, a dynamometer, a hot plate, and a stationary fixture to set up an adhesion force measurement platform4, as shown in Figure 3a.</li>
	<li>Place the test surface on the hot plate. Use a clamp to fix the stainless steel on the plate. Heat the test surface to a certain high temperature (e.g., 300 &#176;C).
	NOTE: The test surface should closely contact the hot plate to ensure efficient heat transport to the slippery surface.</li>
	<li>Fix the dynamometer to the manipulator. Connect a cylinder table (diameter: 2 cm) with a force head to act as a soft tissue fixed platform.</li>
	<li>Fix the soft tissue (e.g., chicken breast; length: 5 cm, width: 2 cm, thickness: 3 mm) onto the cylinder table using a thin wire. Ensure that the soft tissue surface is approximately even.</li>
	<li>Load the soft tissue onto the test surface at a speed of 1 mm/s until the dynamometer reaches a certain maximum force (e.g., 4.5 N) by rotating the motion button of the manipulator. Then, unload the soft tissue at the same speed.</li>
	<li>Connect a computer to the dynamometer using a data transmission line and record the real-time force between the soft tissue and the test surface.</li>
</ol>

<ol>
	<li>Liu, Y., Chen, X., Xin, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Can+superhydrophobic+surfaces+repel+hot+water?.">Can superhydrophobic surfaces repel hot water?.</a> J Mater Chem. 19 (31), 5602-5611 (2009).</li><li>Urata, C., Masheder, B., Cheng, D. F., Hozumi, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+thermally+stable,+durable+and+temperature-dependent+oleophobic+surface+of+a+polymethylsilsesquioxane+film.">A thermally stable, durable and temperature-dependent oleophobic surface of a polymethylsilsesquioxane film.</a> Chem Commun. 49, 3318-3320 (2013).</li><li>Daniel, D., Mankin, M. N., Belisle, R. A., Wong, T. -. S., Aizenberg, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lubricant-infused+micro/nano-structured+surfaces+with+tunable+dynamic+omniphobicity+at+high+temperatures.">Lubricant-infused micro/nano-structured surfaces with tunable dynamic omniphobicity at high temperatures.</a> Appl Phys. Lett. 102 (23), 231603 (2013).</li><li>Zhang, P., Chen, H., Zhang, L., Zhang, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Anti-adhesion+effects+of+liquid-infused+textured+surfaces+on+high-temperature+stainless+steel+for+soft+tissue.">Anti-adhesion effects of liquid-infused textured surfaces on high-temperature stainless steel for soft tissue.</a> Appl Surf Sci. 385, 249-256 (2016).</li><li>Barthlott, W., Neinhuis, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Purity+of+the+sacred+lotus,or+escape+from+contamination+in+biological+surfaces.">Purity of the sacred lotus,or escape from contamination in biological surfaces.</a> Planata. 202 (1), 1-8 (1997).</li><li>Feng, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Super-hydrophobic+surfaces:+from+natural+to+artificial.">Super-hydrophobic surfaces: from natural to artificial.</a> Adv Mater. 14 (24), 1857-1860 (2002).</li><li>Li, X. M., Reinhoudt, D., Crego-Calama, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=What+do+we+need+for+a+superhydrophobic+surface?+A+review+on+the+recent+progress+in+the+preparation+of+superhydrophobic+surfaces.">What do we need for a superhydrophobic surface? A review on the recent progress in the preparation of superhydrophobic surfaces.</a> Chem Soc Rev. 36 (8), 1350-1368 (2007).</li><li>Roach, P., Shirtcliffe, N. J., Newton, M. I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Progess+in+superhydrophobic+surface+development.">Progess in superhydrophobic surface development.</a> Soft Matter. 4, 224-240 (2008).</li><li>Park, K. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Condensation+on+slippery+asymmetric+bumps.">Condensation on slippery asymmetric bumps.</a> Nature. 531 (7592), 78-82 (2016).</li><li>Wong, T. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioinspired+self-repairing+slippery+surfaces+with+pressure-stable+omniphobicity.">Bioinspired self-repairing slippery surfaces with pressure-stable omniphobicity.</a> Nature. 477 (7365), 443-447 (2011).</li><li>Chen, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Continuous+directional+water+transport+on+the+peristome+surface+of+Nepenthes+alata.">Continuous directional water transport on the peristome surface of Nepenthes alata.</a> Nature. 532 (7597), 85-89 (2016).</li><li>Zhang, P., Chen, H., Zhang, L., Ran, T., Zhang, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transparent+self-cleaning+lubricant-infused+surfaces+made+with+large-area+breath+figure+patterns.">Transparent self-cleaning lubricant-infused surfaces made with large-area breath figure patterns.</a> Appl Surf Sci. 355, 1083-1090 (2015).</li><li>Lafuma, A., Qu&#233;r&#233;, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Slippery+pre-suffused+surfaces.">Slippery pre-suffused surfaces.</a> EPL. 96, 56001 (2011).</li><li>Epstein, A. K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liquid-infused+structured+surfaces+with+exceptional+anti-biofouling+performance.">Liquid-infused structured surfaces with exceptional anti-biofouling performance.</a> P Natl Acad Sci USA. 109 (33), 13182-13187 (2012).</li><li>MacCallum, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liquid-infused+silicone+as+a+biofouling-free+medical+material.">Liquid-infused silicone as a biofouling-free medical material.</a> ACS Biomater Sci Eng. 1, 43-51 (2015).</li><li>Zhang, J., Wu, L., Li, B., Li, L., Seeger, S., Wang, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaporation-induced+transition+from+Nepenthes+pitcher-inspired+slippery+surfaces+to+lotus+leaf-inspired+superoleophobic+surfaces.">Evaporation-induced transition from Nepenthes pitcher-inspired slippery surfaces to lotus leaf-inspired superoleophobic surfaces.</a> Langmuir. 30 (47), 14292-14299 (2014).</li><li>Sutton, P. A., Awad, S., Perkins, A. C., Lobo, D. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparison+of+lateral+thermal+spread+using+monopolar+and+bipolar+diathermy+the+Harmonic+Scalpel&#8482;+and+the+Ligasure&#8482;.">Comparison of lateral thermal spread using monopolar and bipolar diathermy the Harmonic Scalpel&#8482; and the Ligasure&#8482;.</a> Brit J Surg. 97 (3), 428-433 (2010).</li><li>Koch, C., Friedrich, T., Metternich, F., Tannapfel, A., Reimann, H. P., Eichfeld, U. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Determination+of+temperature+elevation+in+tissue+during+the+application+of+the+harmonic+scalpel.">Determination of temperature elevation in tissue during the application of the harmonic scalpel.</a> Ultrasound Med Biol. 29 (2), 301-309 (2003).</li><li>Sinha, U. K., Gallagher, L. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+steel+scalpel,+ultrasonic+scalpel,+CO2+laser,+and+monopolar+and+bipolar+electrosurgery+on+wound+healing+in+guinea+pig+oral+mucosa.">Effects of steel scalpel, ultrasonic scalpel, CO2 laser, and monopolar and bipolar electrosurgery on wound healing in guinea pig oral mucosa.</a> Laryngoscope. 113 (2), 228-236 (2003).</li><li>Lee, J. H., Go, A. K., Oh, S. H., Lee, K. E., Yuk, S. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tissue+anti-adhesion+potential+of+ibuprofen-loaded+PLLA-PEG+diblock+copolymer+films.">Tissue anti-adhesion potential of ibuprofen-loaded PLLA-PEG diblock copolymer films.</a> Biomaterials. 26 (6), 671-678 (2005).</li><li>Ding, J. N., Wong, P. L., Yang, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Friction+and+fracture+properties+of+polysilicon+coated+with+self-assembled+monolayers.">Friction and fracture properties of polysilicon coated with self-assembled monolayers.</a> Wear. 260 (1-2), 209-214 (2006).</li><li>Kulkarni, S. A., Mirji, S. A., Mandale, A. B., Vijayamohanan, K. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vitro+stability+study+of+organosilane+self-assemble+monolayers+and+multilayers.">In vitro stability study of organosilane self-assemble monolayers and multilayers.</a> Thin Solid Films. 496, 420-425 (2006).</li><li>Meth, S., Savchenko, N., Viva, F. A., Starosvetsky, D., Groysman, A., Sukenik, C. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Siloxane-based+thin+films+for+corrosion+protection+of+stainless+steel+in+chloride+media.">Siloxane-based thin films for corrosion protection of stainless steel in chloride media.</a> J Appl Electrochem. 41 (8), 885-890 (2011).</li><li>Zhang, P., Chen, H., Zhang, L., Zhang, Y., Zhang, D., Jiang, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stable+slippery+liquid-infused+anti-wetting+surface+at+high+temperatures.">Stable slippery liquid-infused anti-wetting surface at high temperatures.</a> J Mater Chem A. 4 (31), 12212-12220 (2016).</li><li>Smith, J. D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Droplet+mobility+on+lubricant-impregnated+surfaces.">Droplet mobility on lubricant-impregnated surfaces.</a> Soft Matter. 9 (6), 1772-1780 (2013).</li><li>Tran, T., Staat, H. J. J., Prosperetti, A., Sun, C., Lohse, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Drop+impact+on+superheated+surfaces.">Drop impact on superheated surfaces.</a> Phys Rev Lett. 108 (3), 036101 (2012).</li><li>Donzelli, J., Leonetti, J. P., Wurster, R. D., Lee, J. M., Young, M. R. I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neuroprotection+due+to+irrigation+during+bipolar+cautery.">Neuroprotection due to irrigation during bipolar cautery.</a> Arch Otolaryngol. 126 (2), 149-153 (2000).</li></ol>

The authors have nothing to disclose.

This manuscript details protocols for fabricating a slippery surface with high-temperature resistance. The slippery property of our prepared surface was demonstrated by observing the easy-sliding behavior of a water droplet. Then, the anti-wetting of the prepared slippery surface at different high temperatures was investigated by depositing a water droplet on the hot surface. The results show that the prepared slippery surface maintained its slippery property even when it was heated to above 300 &#176;C. We also determin...

Anti-adhesion surfaces at high temperatures for use with liquids and soft tissues have received considerable interest because of their extensive application potential in electrosurgical instruments, engines, pipelines etc.1,2,3,4. Bioinspired surfaces, particularly superhydrophobic surfaces, are considered the ideal choice because of their excellent anti-wetting abilities and self-cleaning properties5. In superhydrophobic surfaces, the anti-wetting ability should be ascribed to the locked air in the surface structure. However, the superhydrophobic state is unstable because it is in the Cassie-Baxter state6,7. Also, at high temperatures, the anti-wetting for liquid droplets can fail because of the wetting state transition from the Cassie-Baxter to the Wenzel state8. This wetting transition is induced by small liquid droplet wetting in the structures, which results in the failure to lock the air in place.
Recently, inspired by the slippery properties of the peritome of the pitcher plant, Nepenthes, Wong et al. reported a concept to construct slippery surfaces by infusing a lubricant into the surface structures9,10,11. Due to capillary force, the structures can firmly hold the lubricant in place, just as in the locked air pocket on superhydrophobic surfaces. Thus, the lubricant and surface structures can form a stable solid/liquid surface. When the lubricant has a preferential affinity for the surface structure, the liquid droplet on the composite surface can slide easily, with only a very low contact angle hysteresis (e.g., ~2&#176;)12. This lubricant layer also enables the surface to have remarkable anti-wetting capabilities13, demonstrating great potential for medical devices14,15. However, previous studies on slippery surfaces mainly focused on the preparation for application at room temperature or low temperatures. There are very few studies on the preparation of slippery surfaces with high-temperature resistance. For example, Zhang et al. showed that the rapid evaporation of lubricant rapidly causes the failure of the slippery property at even slightly high temperatures16.
Slippery surfaces with high-temperature resistance can widen the application potential; for example, they can be used as liquid barriers to decrease soft tissue adhesion to electrosurgical instrument tips. During the surgical operation, severe soft tissue adhesion occurs because of the high temperature of the electrosurgical instrument tips. The soft tissue can be charred, causing it to adhere to the instrument tip, which then tears the soft tissue around the tip17,18,19. The adhered soft tissue on the electrosurgical instrument tip negatively influences the operation and also may induce the failure of hemostasis19,20. These effects significantly harm people&#39;s health and economic interest. Therefore, solving the issue of soft tissue adhesion to electrosurgical instruments is very urgent. In fact, slippery surfaces offer an opportunity to solve this problem.
Here, we present a protocol to fabricate slippery surfaces available at high temperatures. Stainless steel was selected as the surface material because of its high-temperature resistance. The stainless steel was roughened by photolithography-assisted chemical etching. Then, the surface was functionalized with a biocompatible material, saline octadecyltrichlorosilane (OTS)21,22,23,24. A slippery surface was prepared by adding silicone oil. These materials enabled the slippery surface to achieve high-temperature resistance. The anti-wetting property at high temperatures and the anti-adhesion effects on soft tissue were investigated. The results show the potential of using slippery surfaces to solve the anti-adhesion problem at high temperatures.

<table><tbody><tr><td>Stainless steel</td><td>Hongtu Corporation</td><td>316</td><td>Use as received</td></tr><tr><td>Octadecyltrichlorosilane</td><td>Huaxia Reagent</td><td>112-04-9</td><td>Use as received</td></tr><tr><td>Photoresist</td><td>Kempur Microelectronic Corporation</td><td>317S</td><td>Use as received</td></tr><tr><td>Silicone oil</td><td>Beijing Chemical Works</td><td>350 cst</td><td>Use as received</td></tr><tr><td>Anhydrous toluene</td><td>Beijing Chemical Works</td><td>108-88-3</td><td>Use as received</td></tr><tr><td>Phosphoric acid (H&lt;span class=&quot;font7&quot;&gt;&lt;sub&gt;3&lt;/sub&gt;&lt;/span&gt;&lt;span class=&quot;font0&quot;&gt;PO&lt;/span&gt;&lt;span class=&quot;font7&quot;&gt;&lt;sub&gt;4&lt;/sub&gt;&lt;/span&gt;&lt;span class=&quot;font0&quot;&gt;)&lt;/span&gt;</td><td>Tianjin Chemical Corporation</td><td>7664-38-2</td><td>Use as received</td></tr><tr><td>Hydrochloric acid (HCl)</td><td>Tianjin Chemical Corporation</td><td>7647-01-0</td><td>Use as received</td></tr><tr><td>&lt;span class=&quot;font0&quot;&gt;F&lt;/span&gt;&lt;span class=&quot;font8&quot;&gt;erric chloride (&lt;/span&gt;&lt;span class=&quot;font0&quot;&gt;FeCl&lt;/span&gt;&lt;span class=&quot;font7&quot;&gt;&lt;sub&gt;3&lt;/sub&gt;&lt;/span&gt;&lt;span class=&quot;font8&quot;&gt;)&lt;/span&gt;</td><td>Tianjin Chemical Corporation</td><td>7705-08-0</td><td>Use as received</td></tr><tr><td>Optical upright microscope</td><td>Olympus</td><td>BX51</td><td></td></tr><tr><td>Optical stereo microscope</td><td>Olympus</td><td>SZX16</td><td></td></tr><tr><td>High speed camera</td><td>Olympus</td><td>i-SPEED LT</td><td></td></tr><tr><td>Ultrasonic cleaner</td><td>KUNSHAN ULTRASONIC INSTRUMENTS CO. LTD</td><td>KQ-500E</td><td></td></tr><tr><td>Dynamometer</td><td>Yueqing Handapi Instruments Co. Ltd</td><td>HP-5</td><td></td></tr><tr><td>Manipulator</td><td>Yueqing Handapi Instruments Co. Ltd</td><td>HLD</td><td></td></tr><tr><td>Hot plate</td><td>Shenzhen Jingyihuang Corporation</td><td>DRB-1</td><td></td></tr></tbody></table>

preparation and high-temperature anti-adhesion behavior of a slippery surface on stainless steel

Anti-adhesion surfaces with high-temperature resistance have a wide application potential in electrosurgical instruments, engines, and pipelines. A typical anti-wetting superhydrophobic surface easily fails when exposed to a high-temperature liquid. Recently, Nepenthes-inspired slippery surfaces demonstrated a new way to solve the adhesion problem. A lubricant layer on the slippery surface can act as a barrier between the repelled materials and the surface structure. However, the slippery surfaces in previous studies rarely showed high-temperature resistance. Here, we describe a protocol for the preparation of slippery surfaces with high-temperature resistance. A photolithography-assisted method was used to fabricate pillar structures on stainless steel. By functionalizing the surface with saline, a slippery surface was prepared by adding silicone oil. The prepared slippery surface maintained the anti-wetting property for water, even when the surface was heated to 300 &#176;C. Also, the slippery surface exhibited great anti-adhesion effects on soft tissues at high temperatures. This type of slippery surface on stainless steel has applications in medical devices, mechanical equipment, etc.

The slippery surface was prepared by adding silicone oil to OTS-coated, chemically etched stainless steel. Due to their similar chemical properties, the surface was completely wetted by silicone oil. The wetting process is shown in Figure 1a. The red dotted line marks the wetting line. After the wetting, a visible oil layer could be distinguished from the dry surface. The slippery property of the prepared slippery surface was investigated by depositing a wate...

Watch this Scientific Journal Video about Preparation and High-temperature Anti-adhesion Behavior of a Slippery Surface on Stainless Steel at JoVE.com

Preparation and High-temperature Anti-adhesion Behavior of a Slippery Surface on Stainless Steel

Slippery surfaces provide a new way to solve the adhesion problem. This protocol describes how to fabricate slippery surfaces at high temperatures. The results demonstrate that the slippery surfaces showed anti-wetting for liquids and a remarkable anti-adhesion effect on soft tissues at high temperatures.

Anti-adhesion surfaces with high-temperature resistance have a wide application potential in electrosurgical instruments, engines, and pipelines. A ...
