Description: Watch this Scientific Journal Video about Synthesis and Characterization of mRNA-Loaded PolyBeta Aminoesters Nanoparticles for Vaccination Purposes at JoVE.com

Financial support from MINECO/FEDER (grants SAF2015-64927-C2-2-R, RTI2018-094734-B-C22, and COV20/01100) is acknowledged. CGF acknowledged her IQS PhD Fellowship.

1. Synthesis of pBAE polymer with end oligopeptides (OM-pBAE)
<ol>
	<li>Polymerization of C6-pBAE
	<ol>
		<li>Add 5-amino-1-pentanol (38 mmol; MW = 103.16 Da) 1-hexylamine (38 mmol; MW = 101.19 Da) into a round-bottom glass flask (100 mL). Then, add 1,4-butanediol diacrylate (82 mmol; MW = 198.22 Da).</li>
		<li>Pre-heat the silicone oil bath at 90 &#176;C, place the round-bottom flask into the oil bath and stir the mixture with the aid of a magnetic stir bar overnight (~18 h). Then, take the product from the round-bot...

<ol>
	<li>Chumakov, K., Benn, C. S., Aaby, P., Kottilil, S., Gallo, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Can+existing+live+vaccines+prevent+COVID-19.">Can existing live vaccines prevent COVID-19.</a> Science. 368 (6496), 1187-1188 (2020).</li><li>Zhang, C., Maruggi, G., Shan, H., Li, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advances+in+mRNA+vaccines+for+infectious+diseases.">Advances in mRNA vaccines for infectious diseases.</a> Frontiers in Immunology. 10, 1-13 (2019).</li><li>Wherry, E. J., Jaffee, E. M., Warren, N., D'Souza, G., Ribas, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=How+did+we+get+a+COVID-19+vaccine+in+less+than+1+year.">How did we get a COVID-19 vaccine in less than 1 year.</a> Clinical Cancer Research. 27 (8), 2136-2138 (2021).</li><li>Folegatti, P. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Safety+and+immunogenicity+of+the+ChAdOx1+nCoV-19+vaccine+against+SARS-CoV-2:+a+preliminary+report+of+a+phase+1/2,+single-blind,+randomised+controlled+trial.">Safety and immunogenicity of the ChAdOx1 nCoV-19 vaccine against SARS-CoV-2: a preliminary report of a phase 1/2, single-blind, randomised controlled trial.</a> The Lancet. 396 (10249), 467-478 (2020).</li><li>Geall, A. J., Mandl, C. W., Ulmer, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RNA:+The+new+revolution+in+nucleic+acid+vaccines.">RNA: The new revolution in nucleic acid vaccines.</a> Seminars in Immunology. 25 (2), 152-159 (2013).</li><li>Ulmer, J. B., Geall, A. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recent+innovations+in+mRNA+vaccines.">Recent innovations in mRNA vaccines.</a> Current Opinion in Immunology. 41, 18-22 (2016).</li><li>Kranz, L. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Systemic+RNA+delivery+to+dendritic+cells+exploits+antiviral+defence+for+cancer+immunotherapy.">Systemic RNA delivery to dendritic cells exploits antiviral defence for cancer immunotherapy.</a> Nature. 534 (7607), 396-401 (2016).</li><li>Milane, L., Amiji, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Clinical+approval+of+nanotechnology-based+SARS-CoV-2+mRNA+vaccines:+impact+on+translational+nanomedicine.">Clinical approval of nanotechnology-based SARS-CoV-2 mRNA vaccines: impact on translational nanomedicine.</a> Drug Delivery and Translational Research. 1 (4), 3 (2020).</li><li>Green, J. J., Langer, R., Anderson, D. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+combinatorial+polymer+library+approach+yields+insight+into+nonviral+gene+delivery.">A combinatorial polymer library approach yields insight into nonviral gene delivery.</a> Accounts of Chemical Research. 41 (6), 749-759 (2008).</li><li>Guerrero-C&#225;zares, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biodegradable+polymeric+nanoparticles+show+high+efficacy+and+specificity+at+DNA+delivery+to+human+glioblastoma+in+vitro+and+in+vivo.">Biodegradable polymeric nanoparticles show high efficacy and specificity at DNA delivery to human glioblastoma in vitro and in vivo.</a> ACS Nano. 8 (5), 5141-5153 (2014).</li><li>Kozielski, K. L., Tzeng, S. Y., Hurtado De Mendoza, B. A., Green, J. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioreducible+cationic+polymer-based+nanoparticles+for+efficient+and+environmentally+triggered+cytoplasmic+siRNA+delivery+to+primary+human+brain+cancer+cells.">Bioreducible cationic polymer-based nanoparticles for efficient and environmentally triggered cytoplasmic siRNA delivery to primary human brain cancer cells.</a> ACS Nano. 8 (4), 3232-3241 (2014).</li><li>Segovia, N., Dosta, P., Cascante, A., Ramos, V., Borr&#243;s, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oligopeptide-terminated+poly(&#946;-amino+ester)s+for+highly+efficient+gene+delivery+and+intracellular+localization.">Oligopeptide-terminated poly(&#946;-amino ester)s for highly efficient gene delivery and intracellular localization.</a> Acta Biomaterialia. 10 (5), 2147-2158 (2014).</li><li>Dosta, P., Segovia, N., Cascante, A., Ramos, V., Borr&#243;s, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Surface+charge+tunability+as+a+powerful+strategy+to+control+electrostatic+interaction+for+high+efficiency+silencing,+using+tailored+oligopeptide-+modified+poly+(beta-amino+ester)s+(PBAEs).">Surface charge tunability as a powerful strategy to control electrostatic interaction for high efficiency silencing, using tailored oligopeptide- modified poly (beta-amino ester)s (PBAEs).</a> Acta Biomaterialia. 20, 82-93 (2015).</li><li>Fornaguera, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=mRNA+delivery+system+for+targeting+antigen-presenting+cells+in+vivo.">mRNA delivery system for targeting antigen-presenting cells in vivo.</a> Advanced Healthcare Materials. 7 (17), 180033 (2018).</li><li>Fornaguera, C., Castells-Sala, C., L&#225;zaro, M. &. #. 1. 9. 3. ;., Cascante, A., Borr&#243;s, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+an+optimized+freeze-drying+protocol+for+OM-PBAE+nucleic+acid+polyplexes.">Development of an optimized freeze-drying protocol for OM-PBAE nucleic acid polyplexes.</a> International Journal Pharmaceutics. 569, (2019).</li><li>Fornaguera, C., Solans, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analytical+methods+to+characterize+and+purify+polymeric+nanoparticles.">Analytical methods to characterize and purify polymeric nanoparticles.</a> International Journal of Polymer Science. , (2018).</li><li>Fornaguera, C., Solans, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Characterization+of+polymeric+nanoparticle+dispersions+for+biomedical+applications:+size,+surface+charge+and+stability.">Characterization of polymeric nanoparticle dispersions for biomedical applications: size, surface charge and stability.</a> Pharmaceutical Nanotechnology. 6 (3), 147-164 (2018).</li><li>Sahin, U., Karik&#243;, K., T&#252;reci, &. #. 2. 1. 4. ;. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=MRNA-based+therapeutics-developing+a+new+class+of+drugs.">MRNA-based therapeutics-developing a new class of drugs.</a> Nature Reviews Drug Discovery. 13 (10), 759-780 (2014).</li><li>Fan, Y. N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cationic+lipid-assisted+nanoparticles+for+delivery+of+mRNA+cancer+vaccine.">Cationic lipid-assisted nanoparticles for delivery of mRNA cancer vaccine.</a> Biomaterials Science. 6 (11), 3009-3018 (2018).</li><li>Le Moignic, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preclinical+evaluation+of+mRNA+trimannosylated+lipopolyplexes+as+therapeutic+cancer+vaccines+targeting+dendritic+cells.">Preclinical evaluation of mRNA trimannosylated lipopolyplexes as therapeutic cancer vaccines targeting dendritic cells.</a> Journal of Controlled Release. 278, 110-121 (2018).</li><li>Banerji, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=mRNA+vaccines+to+prevent+COVID-19+disease+and+reported+allergic+reactions:+Current+evidence+and+approach.">mRNA vaccines to prevent COVID-19 disease and reported allergic reactions: Current evidence and approach.</a> Journal of Allergy and Clinical Immunology: In Practice. 9 (4), 1423-1437 (2021).</li><li>Kaczmarek, J. C., Kowalski, P. S., Anderson, D. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advances+in+the+delivery+of+RNA+therapeutics:+from+concept+to+clinical+reality.">Advances in the delivery of RNA therapeutics: from concept to clinical reality.</a> Genome Medicine. 9 (1), 1-16 (2017).</li><li>Dosta, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Delivery+of+anti-microRNA-712+to+inflamed+endothelial+cells+using+poly(&#946;-amino+ester)+nanoparticles+conjugated+with+VCAM-1+targeting+peptide.">Delivery of anti-microRNA-712 to inflamed endothelial cells using poly(&#946;-amino ester) nanoparticles conjugated with VCAM-1 targeting peptide.</a> Advanced Healthcare Materials. , 1-11 (2021).</li><li>Segovia, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hydrogel+doped+with+nanoparticles+for+local+sustained+release+of+siRNA+in+breast+cancer.">Hydrogel doped with nanoparticles for local sustained release of siRNA in breast cancer.</a> Advanced Healthcare Materials. 4 (2), 271-280 (2015).</li></ol>

After the outbreak of the Covid-19 pandemic last year, the importance of vaccines in terms of infectious disease control has manifested as a critical component8. Efforts from scientists worldwide have enabled the release to the market of many vaccines. For the first time in history, mRNA vaccines have demonstrated their previously hypothesized success, thanks to their rapid design because of their capacity to adapt to any novel antigen within some months5,<sup cl...

Infectious diseases have represented a severe threat to millions of human beings around the globe and are still one of the leading causes of death in some developing countries. Prophylactic vaccination has been one of the most effective interventions of modern society to prevent and control infectious diseases1,2. These critical milestones of science in 20th-century relevance have been remarked by the recent worldwide Covid-19 pandemic caused by the SARS-CoV-2 virus3. Recognizing the importance of having efficient vaccines to curtail the dissemination of the disease, cooperative efforts from all biomedical communities have successfully resulted in many prophylactic vaccines in the market in less than a year4.
Traditionally, vaccines were composed of attenuate (live, reduced virulence) or inactivated (death particles) viruses. However, for some diseases with no margin for safety errors, viral particles are not possible, and protein subunits are used instead. Nevertheless, subunits usually do not enable the combination of more than one epitope/antigen, and adjuvants are required to enhance vaccination potency5,6. Therefore, the need for novel vaccine types stands clear.
As demonstrated during the current pandemic, novel vaccine candidates based on nucleic acids can be advantageous in terms of avoiding long development processes and providing high versatility while producing, at the same time, a vital patient immunization. This is the case of mRNA vaccines, which were initially designed as experimental cancer vaccines. Thanks to their natural capacity to produce antigen-specific T-cell responses3,5,6,7. Being mRNA the molecule that encodes the antigenic protein, only changing the same, the vaccine can be rapidly tailored to immunize other variants of the same microorganism, different strains, other infectious microorganisms, or even become a cancer immunotherapeutic treatment. In addition, they are advantageous in terms of large-scale production costs. However, mRNA has a significant hurdle that hampers their naked administration: its stability and integrity are compromised in physiological media, full of nucleases. For this reason, the use of a nanometric carrier that protects it and vectorizes mRNA to the antigen-presenting cells is required2,8.
In this context, poly(beta aminoesters) (pBAE) are a class of biocompatible and biodegradable polymers that demonstrated a remarkable ability to complex mRNA in nanometric particles, thanks to their cationic charges9,10,11. These polymers are composed of ester bonds, which makes their degradation easy by esterases in physiological conditions. Among the pBAE library candidates, those functionalized with end cationic oligopeptides showed a higher capacity to form small nanoparticles to efficiently penetrate cells through endocytosis and transfect the encapsulated gene material. Furthermore, thanks to their buffering capacity, the acidification of the endosome compartment allows endosomal escape12,13. Namely, a specific kind of pBAE, including hydrophobic moieties on their backbone (the so-named C6 pBAE) to enhance their stability and end-oligopeptide combination (60% of polymer modified with a tri-lysine and 40% of the polymer with a tri-histidine) that selectively transfects antigen-presenting cells after parenteral administration and produce the mRNA encoded antigen presentation followed by mice immunization has been recently published14. In addition, it has also been demonstrated that these formulations could circumvent one of the main bottleneck steps of nanomedicine formulations: the possibility to freeze-dry them without losing their functionality, which enables long-term stability in soft dry environments15.
In this context, the objective of the current protocol is to make the procedure for the formation of the mRNA nanoparticles available to the scientific community by giving a description of the critical steps in the protocol and enabling the production of efficient vaccines for infectious diseases prevention and tumor treatment applications.
The following protocol describes the complete workout to synthesize oligopeptide end-modified poly(beta aminoesters) - OM-pBAE polymers that will further be used for nanoparticle synthesis. In the protocol, nanoparticles formulation is also included. In addition, critical steps for the success of the procedure and representative results are also provided to ensure that the resulting formulations accomplish the required quality control characterization features to define a positive or negative result. This protocol is summarized in Figure 1.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>1,4-butanediol diacrylate</td>
			<td>Sigma Aldrich</td>
			<td>123048</td>
			<td></td>
		</tr>
		<tr>
			<td>1-hexylamine</td>
			<td>Sigma Aldrich</td>
			<td>219703</td>
			<td></td>
		</tr>
		<tr>
			<td>5-amino-1-pentanol</td>
			<td>Sigma Aldrich</td>
			<td>411744</td>
			<td></td>
		</tr>
		<tr>
			<td>Acetone</td>
			<td>Panreac</td>
			<td>141007</td>
			<td></td>
		</tr>
		<tr>
			<td>CD11b antibody</td>
			<td>BD</td>
			<td>550993</td>
			<td></td>
		</tr>
		<tr>
			<td>CD86 antibody</td>
			<td>Bioligend</td>
			<td>105007</td>
			<td></td>
		</tr>
		<tr>
			<td>Chlor hydroxhyde</td>
			<td>Panreac</td>
			<td>181023</td>
			<td></td>
		</tr>
		<tr>
			<td>Chloroform-d</td>
			<td>Sigma Aldrich</td>
			<td>151823</td>
			<td></td>
		</tr>
		<tr>
			<td>Cys-His-His-His peptide</td>
			<td>Ontores</td>
			<td>Custom</td>
			<td></td>
		</tr>
		<tr>
			<td>Cys-Lys-Lys-Lys peptide</td>
			<td>Ontores</td>
			<td>Custom</td>
			<td></td>
		</tr>
		<tr>
			<td>D2O</td>
			<td>Sigma Aldrich</td>
			<td>151882</td>
			<td></td>
		</tr>
		<tr>
			<td>DEPC reagent for Rnase free water</td>
			<td>Sigma Aldrich</td>
			<td>D5758</td>
			<td>This reagent is important to treat MilliQ water to remove any RNases of the buffers</td>
		</tr>
		<tr>
			<td>Diethyl eter</td>
			<td>Panreac</td>
			<td>212770</td>
			<td></td>
		</tr>
		<tr>
			<td>dimethyl sulfoxide</td>
			<td>Sigma Aldrich</td>
			<td>276855</td>
			<td></td>
		</tr>
		<tr>
			<td>HEPES</td>
			<td>Sigma Aldrich</td>
			<td>H3375</td>
			<td></td>
		</tr>
		<tr>
			<td>mRNA EGFP</td>
			<td>TriLink Technologies</td>
			<td>L-7601</td>
			<td></td>
		</tr>
		<tr>
			<td>mRNA OVA</td>
			<td>TriLink Technologies</td>
			<td>L-7610</td>
			<td></td>
		</tr>
		<tr>
			<td>RiboGreen kit</td>
			<td>ThermoFisher</td>
			<td>R11490</td>
			<td></td>
		</tr>
		<tr>
			<td>sodium acetate</td>
			<td>Sigma Aldrich</td>
			<td>71196</td>
			<td></td>
		</tr>
		<tr>
			<td>sucrose</td>
			<td>Sigma Aldrich</td>
			<td>S0389</td>
			<td></td>
		</tr>
		<tr>
			<td>Trifluoroacetic acid</td>
			<td>Sigma Aldrich</td>
			<td>302031</td>
			<td></td>
		</tr>
		<tr>
			<td>Trypsin-EDTA</td>
			<td>Fisher Scientific</td>
			<td>11570626</td>
			<td></td>
		</tr>
		<tr>
			<td>&#945;-mouse AlexaFluor488 antibody</td>
			<td>Abcam</td>
			<td>Ab450105</td>
			<td></td>
		</tr>
		<tr>
			<td>Equipment</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Nanoparticle Tracking Analyzer</td>
			<td>Malvern Panalytical</td>
			<td>NanoSight NS300</td>
			<td></td>
		</tr>
		<tr>
			<td>Nuclear Magnetic Ressonance Spectrometer</td>
			<td>Varian</td>
			<td>400 MHz</td>
			<td></td>
		</tr>
		<tr>
			<td>ZetaSizer</td>
			<td>Malvern Panalytical</td>
			<td>Nano ZS</td>
			<td>For zeta potential and hydrodynamic size determination</td>
		</tr>
		<tr>
			<td>Software</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>NanoSight NTA software</td>
			<td>Malvern Panalytical</td>
			<td>MAN0515-02-EN-00</td>
			<td></td>
		</tr>
		<tr>
			<td>NovoExpress Software</td>
			<td>Agilent</td>
			<td>Not specified</td>
			<td></td>
		</tr>
		<tr>
			<td>ZetaSizer software</td>
			<td>Malvern Panalytical</td>
			<td>DTS Application</td>
			<td>To analyze surface charge and hydrodynamic sizes</td>
		</tr>
	</tbody>
</table>

synthesis and characterization of mrna-loaded poly(beta aminoesters) nanoparticles for vaccination purposes

Vaccination has been one of the major successes of modern society and is indispensable in controlling and preventing disease. Traditional vaccines were composed of entire or fractions of the infectious agent. However, challenges remain, and new vaccine technologies are mandatory. In this context, the use of mRNA for immunizing purposes has shown an enhanced performance, as demonstrated by the speedy approval of two mRNA vaccines preventing SARS-CoV-2 infection. Beyond success in preventing viral infections, mRNA vaccines can also be used for therapeutic cancer applications.
Nevertheless, the instability of mRNA and its fast clearance from the body due to the presence of nucleases makes its naked delivery not possible. In this context, nanomedicines, and specifically polymeric nanoparticles, are critical mRNA delivery systems. Thus, the aim of this article is to describe the protocol for the formulation and test of an mRNA vaccine candidate based on the proprietary polymeric nanoparticles. The synthesis and chemical characterization of the poly(beta aminoesters) polymers used, their complexation with mRNA to form nanoparticles, and their lyophilization methodology will be discussed here. This is a crucial step for decreasing storage and distribution costs. Finally, the required tests to demonstrate their capacity to in vitro transfect and mature model dendritic cells will be indicated. This protocol will benefit the scientific community working on vaccination because of its high versatility that enables these vaccines to prevent or cure a wide variety of diseases.

Polymer synthesis and characterization
The OM-pBAE synthesis procedure&#160;is given in Figure 2. As Figure 2A shows, the first step to obtain the OM-pBAE is to synthesize the C6-pBAE by adding the amines (1-hexylamine and 5-amino-1-pentanol, ratio 1:1) to the diacrylate (1,4-butanediol diacrylate). This reaction is carried out at 90 &#176;C for 20 h and with constant stirring. Afterward, a solution of oligopeptides is added to a solution ...

Watch this Scientific Journal Video about Synthesis and Characterization of mRNA-Loaded PolyBeta Aminoesters Nanoparticles for Vaccination Purposes at JoVE.com

Synthesis and Characterization of mRNA-Loaded PolyBeta Aminoesters Nanoparticles for Vaccination Purposes

Here, a simple protocol is presented for producing mRNA nanoparticles based on poly(beta aminoester) polymers, easy to be tailored by changing the encapsulated mRNA. The workflow for synthesizing the polymers, the nanoparticles, and their in vitro essential characterization are also described. A proof-of-concept regarding immunization is also added.

Synthesis and Characterization of mRNA-Loaded Poly(Beta Aminoesters) Nanoparticles for Vaccination Purposes

Vaccination has been one of the major successes of modern society and is indispensable in controlling and preventing disease. Traditional vaccines were ...

This protocol is significant because it demonstrates, how to prepare Polymeric nanoparticles, encapsulated nucleic acids in one simple step. The main advantages of this technique, are versatility, as it can be applied to different nucleic acids and cell types. The use of simple procedures for particle preparation, such as pipetting up and down, and the possibility to extend the stability of the nanoparticles and drum conditions by lyophilization.Demonstrating the procedure will be Laura Olmo, Coral Garcia-Fernandez, Maria Stampa Lopez-Pinto and Maria Navalon-Lopez, phd student of our laboratory and Marta Diaz-Caballero, a post doc for our laboratory. For polyplexes formation, thaw the previously prepared polymers, C6 peptide, poly beta amino esters, and vortex the solution. After pipetting the polymer mix up and down, prepare a 12.5 millimolar solution in sodium acetate.Vortex the solution and wait for 10 minutes. Next, prepare mRNA at 0.5 milligrams per milliliter and mixed by pipetting. Vortex the polymer solution again, then mix the genetic material solution in the polymer solution in a one-to-one ratio in a micro centrifuge tube and incubate the tube at 25 degrees Celsius for 30 minutes in a Thermoblock.After incubation precipitate the mixture with one to two RNase free water by adding the sample to a micro centrifuge tube containing the water, then to include the excipients, add a 20 millimolar heaps and 4%sucrose solution in the same volume as the mixture of mRNA and poly beta amino esters, and mixed by pipetting. For Lyophilization after freezing the polyplex solution at minus 80 degrees Celsius for one hour, perform the primary drying, then immediately store the polyplexes at minus 20 degrees Celsius to avoid rehydration. For polyplex resuspension, remove the lyophilized nano-particles from the minus 20 degrees Celsius freezer and rapidly add the corresponding amount of deep hydrogenated water to re-disperse the solid and achieved the desired concentration.Pipette gently until total resuspension and once dissolved, pipette up and down vigorously avoiding bubbles. After 24 hours of transfection for qualitative assessment by fluorescence microscopy, place the 96 well plate containing the transfected Hela cells onto the microscope and start visualizing using the 10 times objective. First, apply a white balance to create a background reference for the software, then acquire an image to overlay it with the fluorescence image during the analysis.Change the microscope mode to reflection mode and move the filter wheel to the blue laser to visualize EGFP. Then acquire images for all the conditions or wells employing the same exposure time. For quantitative assessment by flow cytometry, wash the Hela cells transfected in a 96 well plate using 100 microliters of PBS per well.After aspirating the PBS at 25 microliters of trypsin per well and incubate at 37 degrees Celsius for five minutes. Once the cells are detached, add the previously recovered media to inactivate the trypsin, then fix the cells by adding 31.25 microliters of 10%formalin per well and incubating for 20 minutes. Next turn on the flow cytometer and the software, then set up the proper conditions for the experiment, including the type of plate sample volume and other parameters such as shaking and rinsing between samples.Set up the appropriate parameters to quantify the percentage of positively transfected cells by first viewing the flow data on forward scattered light versus side scattered light to distinguish the cells from the debris. And then plotting another scatterplot, comparing the amplitude versus height to gate and discriminate individual cells. One day before transfection, plate 10, 000 JAWS II cells per well in a 96 well plate for overnight incubation.The following day transfect the cells with 0.6 micrograms mRNA per well and incubate the plate for 24 hours in a dry air incubator at 37 degrees Celsius and 5%carbon dioxide. The next day, wash the cells remaining in the well with 25 microliters of PBS. After aspirating the PBS at 25 microliters of trypsin and incubate the plate for five minutes at 37 degrees Celsius to detach the cells.Stop the trypsin reaction by adding the previously recovered media onto the correspondent well. Then centrifuge the plate, aspirate the media, and fix the cells by adding 50 microliters of PBS and 2.5%formalin per well followed by incubating the plate at four degrees Celsius for 20 minutes, centrifuge the plate. Then add 50 microliters of PBS and 3%BSA per well and incubator for 30 minutes at four degrees Celsius.After incubation centrifuge the plate again, then add 50 microliters of the mouse ovalbumin antibody in PBS and 3%BSA and incubator for 30 minutes at four degrees Celsius. Repeat centrifugation step, then wash the cells with 50 microliters of PBS. After aspirating the PBS, add the secondary antibodies and incubate for one hour at four degrees Celsius.After incubation, repeat the centrifugation and washing steps. Then resuspend the cells and 100 microliters of PBS and 2.5%formalin for flow cytometry analysis. Physiochemical characterization of fresh and lyophilized GFP mRNA encapsulating nanoparticles show no significant differences in size and poly dispersity index.Transmission electron microscopy of the polyplexes confirms the formation of spherical and mono dispersed nanoparticles of approximately 50 nanometers in diameter. Encapsulation efficiency data of a Lego peptide and modified poly beta amino ester polyplexes encapsulating GFP, or ovalbumin show no significant differences depending on the type of mRNA. A qualitative analysis of EGFP expression, 24 hours post-transaction in the JAWS II cell line is shown here.Quantitatively compared to the negative control. The percent GFP positive cells is significantly higher and comparable to a positive control performed with a classical transfection reagent. The ovalbumin mRNA loaded oligopeptide and modified poly beta amino ester nanoparticles can activate dendritic cells as seen by the significantly higher expression of CD11b and CD86 membrane markers in transfected cells compared to non-transfected cells.Our vaccination platform based on the use of mRNA as the active principle, as well as our proprietary polymers can be adapted to be used in prophylaxis as well as for cancer therapeutics. We can use our technology to make a highlight that contribution in cancer immunotherapeutics. since we can encapsulate tumor-associated antigens in our nanoparticles and make a shift in cancer treatments.
