저자 생물 물리학 그룹 및 Jacob Piehler Wladislaw 콜 기술 지원 및 자료의 준비에 대 한 지속적인 지원과 사용 하기 위해 현미경을 제공 하기 위한 CellNanOs 보드 나 브루 크의 대학에 감사 하 고 싶습니다. 프로젝트는 SFB 944에 의해 투자 되었다.

<ol>
	<li>Appelhans, T., Richter, C., Wilkens, V., Hess, S., Piehler, J., Busch, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nanoscale+organization+of+mitochondrial+microcompartments+revealed+by+combining+tracking+and+localization+microscopy.">Nanoscale organization of mitochondrial microcompartments revealed by combining tracking and localization microscopy.</a> Nano Letters. 12 (2), 610-616 (2012).</li><li>Appelhans, T., Busch, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single+Molecule+Tracking+and+Localization+of+Mitochondrial+Protein+Complexes+in+Live+Cells.">Single Molecule Tracking and Localization of Mitochondrial Protein Complexes in Live Cells.</a> Methods Mol Biol. 1567, 273-291 (2017).</li><li>Rust, M. J., Bates, M., Zhuang, X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sub-diffraction-limit+imaging+by+stochastic+optical+reconstruction+microscopy+(STORM).">Sub-diffraction-limit imaging by stochastic optical reconstruction microscopy (STORM).</a> Nat Methods. 3 (10), 793-795 (2006).</li><li>Gould, T. J., Verkhusha, V. V., Hess, S. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+biological+structures+with+fluorescence+photoactivation+localization+microscopy.">Imaging biological structures with fluorescence photoactivation localization microscopy.</a> Nat Protoc. 4 (3), 291-308 (2009).</li><li>Pennacchietti, F., Gould, T. J., Hess, S. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Role+of+Probe+Photophysics+in+Localization-Based+Superresolution+Microscopy.">The Role of Probe Photophysics in Localization-Based Superresolution Microscopy.</a> Biophys J. 113 (9), 2037-2054 (2017).</li><li>Wegel, E., G&#246;hler, A., Lagerholm, B. C., Wainman, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+cellular+structures+in+super-resolution+with+SIM,+STED+and+Localisation+Microscopy:+A+practical+comparison.">Imaging cellular structures in super-resolution with SIM, STED and Localisation Microscopy: A practical comparison.</a> Scientific reports. , (2016).</li><li>Pellett, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Two-color+STED+microscopy+in+living+cells.">Two-color STED microscopy in living cells.</a> Biomedical Optics Express. 2 (8), (2011).</li><li>Ishigaki, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=STED+super-resolution+imaging+of+mitochondria+labeled+with+TMRM+in+living+cells.">STED super-resolution imaging of mitochondria labeled with TMRM in living cells.</a> Mitochondrion. 28, 79 (2016).</li><li>Liss, V., Barlag, B., Nietschke, M., Hensel, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Self-labelling+enzymes+as+universal+tags+for+fluorescence+microscopy,+super-resolution+microscopy+and+electron+microscopy.">Self-labelling enzymes as universal tags for fluorescence microscopy, super-resolution microscopy and electron microscopy.</a> Scientific Reports. 5, 17740 (2015).</li><li>Serg&#233;, A., Bertaux, N., Rigneault, H., Marguet, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+multiple-target+tracing+to+probe+spatiotemporal+cartography+of+cell+membranes.">Dynamic multiple-target tracing to probe spatiotemporal cartography of cell membranes.</a> Nat Methods. 5 (8), (2008).</li><li>Appelhans, T., Busch, K. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+imaging+of+mitochondrial+membrane+proteins+in+specific+sub-organelle+membrane+locations.">Dynamic imaging of mitochondrial membrane proteins in specific sub-organelle membrane locations.</a> Biophysical reviews. 9 (4), 345-352 (2017).</li><li>Wilmes, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Triple-color+super-resolution+imaging+of+live+cells:+resolving+submicroscopic+receptor+organization+in+the+plasma+membrane.">Triple-color super-resolution imaging of live cells: resolving submicroscopic receptor organization in the plasma membrane.</a> Angewandte Chemie. 51 (20), 4868-4871 (2012).</li><li>Niewidok, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single-molecule+imaging+reveals+dynamic+biphasic+partition+of+RNA-binding+proteins+in+stress+granules.">Single-molecule imaging reveals dynamic biphasic partition of RNA-binding proteins in stress granules.</a> J Cell Biol. , (2018).</li><li>Wurm, C. A., Jakobs, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Differential+protein+distributions+define+two+sub-compartments+of+the+mitochondrial+inner+membrane+in+yeast.">Differential protein distributions define two sub-compartments of the mitochondrial inner membrane in yeast.</a> FEBS Lett. 580 (24), 5628-5634 (2006).</li><li>Schmidt, R., Wurm, C. A., Punge, A., Egner, A., Jakobs, S., Hell, S. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mitochondrial+cristae+revealed+with+focused+light.">Mitochondrial cristae revealed with focused light.</a> Nano Lett. 9 (6), 2508-2510 (2009).</li><li>Kukat, C., Wurm, C. A., Spahr, H., Falkenberg, M., Larsson, N. G., Jakobs, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Super-resolution+microscopy+reveals+that+mammalian+mitochondrial+nucleoids+have+a+uniform+size+and+frequently+contain+a+single+copy+of+mtDNA.">Super-resolution microscopy reveals that mammalian mitochondrial nucleoids have a uniform size and frequently contain a single copy of mtDNA.</a> Proceedings of the National Academy of Sciences of the United States of America. 108 (33), 13534-13539 (2011).</li><li>Beinlich, F., Drees, C., Piehler, J., Busch, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Shuttling+of+PINK1+between+Mitochondrial+Microcompartments+Resolved+by+Triple-Color+Superresolution+Microscopy.">Shuttling of PINK1 between Mitochondrial Microcompartments Resolved by Triple-Color Superresolution Microscopy.</a> ACS chemical biology. 10 (9), 1970-1976 (2015).</li><li>Shim, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Super-resolution+fluorescence+imaging+of+organelles+in+live+cells+with+photoswitchable+membrane+probes.">Super-resolution fluorescence imaging of organelles in live cells with photoswitchable membrane probes.</a> Proceedings of the National Academy of Sciences. 109 (35), 13978-13983 (2012).</li><li>Sbalzarini, I., Mezzacasa, A., Helenius, A., Koumoutsakos, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+Organelle+Shape+on+Fluorescence+Recovery+after+Photobleaching.">Effects of Organelle Shape on Fluorescence Recovery after Photobleaching.</a> Biophysical Journal. 89 (3), 1482-1492 (2005).</li><li>Reits, E., Neefjes, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=From+fixed+to+FRAP:+measuring+protein+mobility+and+activity+in+living+cells.">From fixed to FRAP: measuring protein mobility and activity in living cells.</a> Nature Cell Biology. 3 (6), E145-E147 (2001).</li><li>Goehring, N., Chowdhury, D., Hyman, A., Grill, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=FRAP+Analysis+of+Membrane-Associated+Proteins:+Lateral+Diffusion+and+Membrane-Cytoplasmic+Exchange.">FRAP Analysis of Membrane-Associated Proteins: Lateral Diffusion and Membrane-Cytoplasmic Exchange.</a> Biophysical Journal. 99 (8), 2443-2452 (2010).</li><li>Bacia, K., Haustein, E., Schwille, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fluorescence+correlation+spectroscopy:+principles+and+applications.">Fluorescence correlation spectroscopy: principles and applications.</a> Cold Spring Harbor protocols. 2014 (7), 709-725 (2014).</li><li>Sukhorukov, V., Dikov, D., Busch, K., Strecker, V., Wittig, I., Bereiter-Hahn, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Determination+of+protein+mobility+in+mitochondrial+membranes+of+living+cells.">Determination of protein mobility in mitochondrial membranes of living cells.</a> Biochimica et biophysica acta. 1798 (11), 2022-2032 (2010).</li><li>Kim, T. K., Eberwine, J. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mammalian+cell+transfection:+the+present+and+the+future.">Mammalian cell transfection: the present and the future.</a> Anal Bioanal Chem. 397 (8), 3173-3178 (2010).</li><li>Graham, F. L., van der Eb, A. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+technique+for+the+assay+of+infectivity+of+human+adenovirus+5+DNA.">A new technique for the assay of infectivity of human adenovirus 5 DNA.</a> Virology. 52 (2), 456-467 (1973).</li><li>Wedeking, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Spatiotemporally+Controlled+Reorganization+of+Signaling+Complexes+in+the+Plasma+Membrane+of+Living+Cells.">Spatiotemporally Controlled Reorganization of Signaling Complexes in the Plasma Membrane of Living Cells.</a> Small. 11 (44), 5912-5918 (2015).</li><li>Mironov, S. L., Ivannikov, M. V., Johansson, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=[Ca2+]i+signaling+between+mitochondria+and+endoplasmic+reticulum+in+neurons+is+regulated+by+microtubules.+From+mitochondrial+permeability+transition+pore+to+Ca2+-induced+Ca2++release.">[Ca2+]i signaling between mitochondria and endoplasmic reticulum in neurons is regulated by microtubules. From mitochondrial permeability transition pore to Ca2+-induced Ca2+ release.</a> J Biol Chem. 280 (1), 715-721 (2005).</li><li>Poot, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+mitochondrial+morphology+and+function+with+novel+fixable+fluorescent+stains.">Analysis of mitochondrial morphology and function with novel fixable fluorescent stains.</a> J Histochem Cytochem. 44 (12), 1363-1372 (1996).</li><li>Tokunaga, M., Imamoto, N., Sakata-Sogawa, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly+inclined+thin+illumination+enables+clear+single-molecule+imaging+in+cells+(vol+5,+pg+159).">Highly inclined thin illumination enables clear single-molecule imaging in cells (vol 5, pg 159).</a> Nature Methods. 5 (5), 455 (2008).</li><li>Elmokadem, A., Yu, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimal+Drift+Correction+for+Superresolution+Localization+Microscopy+with+Bayesian+Inference.">Optimal Drift Correction for Superresolution Localization Microscopy with Bayesian Inference.</a> Biophys J. 109 (9), 1772-1780 (2015).</li><li>Barlag, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single+molecule+super-resolution+imaging+of+proteins+in+living+Salmonella+enterica+using+self-labelling+enzymes.">Single molecule super-resolution imaging of proteins in living Salmonella enterica using self-labelling enzymes.</a> Sci Rep. 6, 31601 (2016).</li><li>Tokunaga, M., Imamoto, N., Sakata-Sogawa, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly+inclined+thin+illumination+enables+clear+single-molecule+imaging+in+cells.">Highly inclined thin illumination enables clear single-molecule imaging in cells.</a> Nature Methods. 5 (2), 159-161 (2008).</li><li>Mortensen, K. I., Churchman, L. S., Spudich, J. A., Flyvbjerg, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimized+localization+analysis+for+single-molecule+tracking+and+super-resolution+microscopy.">Optimized localization analysis for single-molecule tracking and super-resolution microscopy.</a> Nat Methods. 7 (5), 377-381 (2010).</li><li>Jin, S., Youle, R. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=PINK1-+and+Parkin-Mediated+Mitophagy+at+a+Glance.">PINK1- and Parkin-Mediated Mitophagy at a Glance.</a> Journal of Cell Science. 125, 795-799 (2013).</li><li>Yamano, K., Youle, R. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=PINK1+is+degraded+through+the+N-end+rule+pathway.">PINK1 is degraded through the N-end rule pathway.</a> Autophagy. 9 (11), 1758-1758 (2013).</li><li>Wiedemann, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Machinery+for+protein+sorting+and+assembly+in+the+mitochondrial+outer+membrane.">Machinery for protein sorting and assembly in the mitochondrial outer membrane.</a> Nature. 424 (6948), 565-571 (2003).</li><li>Thompson, R., Larson, D., Webb, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Precise+Nanometer+Localization+Analysis+for+Individual+Fluorescent+Probes.">Precise Nanometer Localization Analysis for Individual Fluorescent Probes.</a> Biophysical Journal. 82 (5), 2775-2783 (2002).</li></ol>

저자는 공개 없다.

여기, 듀얼 컬러 단일 분자 지역화 모바일 막 단백질의 기술을 제시 했다. 다음 프로토콜, 막 단백질 자체 라벨 TMR 및 그들의 각각 기판에 활용 된 선생님 rhodamine 염료와 반응 하는 단백질에 융합 된다. Rhodamine 밝은 photostable 염색 하 고 반복적인 이미징1따라서 허용 합니다. 성공적인 성능에 대 한 여러 조건 및 중요 한 주제 마음에 보관 해야 합니다.
첫째, 그?...

이 프로토콜의 목표는 지역화 하 고 단일 막 단백질 라이브 셀 내부를 추적 하는 이미징 방법 제공. 추적 및 지 방화 현미경 검사 법 (TALM)1,2이 메서드를 호출 하 고. 확률적 광학 재건 현미경 (폭풍)3 와 같이 형광 Photoactivation 지역화 현미경 검사 법 ((F) 팜)4,5, TALM 단일 분자 기반 형광 지역화 기술 이다. 그러나, 그것은 동일의 반복적인 이미지와 함께 조합에 있는 막 단백질의 이동성 표시 계시 한다 다른 위치에 분자 microcompartment 모바일 단백질에 대 한 액세스할 수 있는 방식으로 구분 됩니다. 즉, 단백질의 가능한 국부 세포 기관이의 건축 및 단백질1의 이동성에 의해 설정 됩니다. 메서드는 지역화 및 탄도 이미징 모바일 단백질에 의해 지도 계시 한다 때문에 다양 한 다른 슈퍼 해상도 기법6,,78 보완. 라벨은 se 당 비 형광은 유전자 조작된 융해 단백질을 사용 하 여 기반으로 합니다. 이 융해 단백질은 자체 효소 반응 covalently 염료에 활용 된 기판 레이블이 지정 됩니다. 이 절차는 라벨도 될 수 있는 이점이 있다 추가 된 기판의 크기에 의해 제어. 또한, 그것은 선택한 활용된 염료에 따라 형광의 색상을 다양 하 게 있습니다. 여러 자체 라벨 효소-태그는 사용할 수9. 또 다른 장점은, 사용 하는 자체 효소 태그 라벨 활용된 염료를 일반적으로 더 안정적이 고 밝은 형광 단백질1 와 개별 단백질 따라서 기록 될 수 있습니다 더 이상 보다는 더 정확 하 게 때까지 그들은 표백. 모바일 단백질의 궤적의 녹음 및 확산 계수10,11의 추출에 대 한 수 있습니다.
여기, 우리는 미토 콘 드 리아 멤브레인 단백질, TALM의 타당성 입증 하지만 그것은 또한 다른 세포 유형12,13를 포함 하 여 다른 내부 및 여분 cellular 막 단백질에 적용할 수 있습니다. 우리 다 색 TALM 추가 기존 슈퍼 해상도 형광 현미경 검사 법 기술14,15, 보완성에 다른 subcompartments에 있는 단백질의 동시 구별에 대 한 허용 표시 16. TALM 라이브 셀 이미징17와 호환 됩니다. 사진-물리학 선택한 rhodamines Tetramethylrhodamine (TMR)와 실리콘-Rhodamien (선생님)의 특히 그들의 밝기와 안정성, 수 있게 기록 단일 막 단백질 지역화 (및 궤적) 지도 제공 하는 여러 프레임에 걸쳐. 그러나 모션 블러는 너무 높은 때문에 프레임 마다 수집 된 광자는 적절 한 지역화를 위해 너무 낮은, TALM 높은 확산 계수와 수용 성 단백질의 지역화에 대 한 제한 됩니다. 게다가, TALM phototoxic 효과 감소 예 폭풍 또는 자극 방출 소모 (호텔 위치) 현미경6,7, 보다 전원을 적게 필요 합니다. 이것은 phototoxic 스트레스는 종종 organellar 형태학18 및 따라서 이동성 분석19영향을 때문에 중요 한. 합계에서는, 선물이 살아있는 세포에 다 색 TALM 지역화 현미경 방법 폭풍/호텔 위치 사이의 간격을 채우는 기술 (F) 팜 및 photobleaching 후 단백질 이동성 형광 복구 등을 분석 하는 기법 (졸라)20 / ,21, 형광 상관 분광학 (FCS)22, 그리고 형광 상관 분광학 (FCCS)11,23크로스.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr >
			<td >(2-(4-(2-hydroxyethyl)-1-piperazinyl)-ethanesulfonic acid, 1 M) (HEPES)</td>
			<td >Biochrom</td>
			<td >#1104E</td>
			<td ></td>
		</tr>
		<tr >
			<td >DC1: Dichroid beam splitter&#160;</td>
			<td>Chroma</td>
			<td>640 dcxr</td>
			<td>NC506031</td>
		</tr>
		<tr >
			<td >DC2: Polychroic Mirror, beamsplitter</td>
			<td >Chroma</td>
			<td>zt405/488/561/640rpc</td>
			<td>discontinued</td>
		</tr>
		<tr >
			<td >Dulbecco&#180;s Phosphate-Buffered Saline (PBS) 1x (w/o Ca &#38; Mg)</td>
			<td >Sigma-Aldrich &#38; Co.</td>
			<td >#RNBF8311</td>
			<td></td>
		</tr>
		<tr >
			<td >Earle&#180;s MEM without phenol red, without L-Glutamine and without NaHCO3 containing 1% FBS, 0.1% HEPES, 0.1% NEAA, 0.1% Alanyl-L-Glutamine and 34.78% sodium hydrogen carbonate (NaHCO3 0.75g/l)</td>
			<td ></td>
			<td ></td>
			<td>Imaging medium</td>
		</tr>
		<tr >
			<td >Earle&#180;s minimum essential medium (MEM) with phenol red, containing 1% Fetal Bovine Serum Superior (FBS), 0.1% HEPES (2-(4-(2-hydroxyethyl)-1-piperazinyl)-ethanesulfonic acid, 1 M), and 0.1% non-essential amino acids (NEAA)</td>
			<td ></td>
			<td ></td>
			<td>Growth medium</td>
		</tr>
		<tr >
			<td >EF: Emission filter quadbandpass</td>
			<td>AHF analysentechnik</td>
			<td>F72-866</td>
			<td>Brightline HC 446 nm/523 nm/600 nm/677 nm</td>
		</tr>
		<tr >
			<td >EMCCD camera</td>
			<td >Andor</td>
			<td>Andor iXON 897</td>
			<td>EMCCD camera</td>
		</tr>
		<tr >
			<td >Emission filter QuadView filter cubes, orange</td>
			<td>AHF analysentechnik</td>
			<td>F39-637</td>
			<td>bandpass 582 - 619 nm</td>
		</tr>
		<tr >
			<td >Emission filter QuadView filter cubes, red</td>
			<td>Chroma</td>
			<td></td>
			<td>bandpass 655 - 725 nm (HQ 690/70)</td>
		</tr>
		<tr >
			<td >FBS (Fetal bovine serum) superior</td>
			<td >Biochrom</td>
			<td >S0615</td>
			<td></td>
		</tr>
		<tr >
			<td >Fluorescent beads: TetraSpeck&#8482; Microspheres, 0.1 &#181;m, fluorescent blue/green/orange/dark red</td>
			<td >Thermo Fisher Scientific</td>
			<td >T7279</td>
			<td>fluorescent microspheres</td>
		</tr>
		<tr >
			<td >Glutamine</td>
			<td >Biochrom</td>
			<td >#0951C</td>
			<td></td>
		</tr>
		<tr >
			<td >HeLa cells&#160;</td>
			<td >DSMZ</td>
			<td>ACC-57</td>
			<td>Cervical carcinoma cells from patient Henrietta Lacks</td>
		</tr>
		<tr >
			<td >Hela cells CI::paGFP, stable</td>
			<td >Muster et al., PLOSOne 2010</td>
			<td></td>
			<td></td>
		</tr>
		<tr >
			<td >Hela cells CV g::Halo7-Tag, stable</td>
			<td >Appelhans et al., NanoLett 2012</td>
			<td></td>
			<td></td>
		</tr>
		<tr >
			<td >Hela cells Tom20::Halo7-Tag, stable</td>
			<td >Appelhans et al., NanoLett 2012</td>
			<td></td>
			<td></td>
		</tr>
		<tr >
			<td >Image splitter</td>
			<td >Photometrics</td>
			<td >Dual-View QV2</td>
			<td>image splitter emission</td>
		</tr>
		<tr >
			<td >Imaging processing software&#160;</td>
			<td >ImageJ2 / Fiji</td>
			<td >freeware</td>
			<td></td>
		</tr>
		<tr >
			<td >Immersion Oil - ImmersolTM 518 F (ne = 1.518, ve = 45)</td>
			<td >Carl Zeiss Jena GmbH</td>
			<td >444960-0000-000</td>
			<td></td>
		</tr>
		<tr >
			<td >Inverted epifluorescence microscope</td>
			<td >Olympus IX-71/73/83</td>
			<td ></td>
			<td></td>
		</tr>
		<tr >
			<td >Laser 561 nm, 200 mW</td>
			<td >CrystaLaser</td>
			<td>CL-561-200</td>
			<td>561 nm emission</td>
		</tr>
		<tr >
			<td >Laser 642 nm, 140 mW</td>
			<td >Omicron</td>
			<td >Luxx-642-140</td>
			<td>642 nm emission</td>
		</tr>
		<tr >
			<td >MATLAB</td>
			<td >MathWorks</td>
			<td >version R2013a</td>
			<td></td>
		</tr>
		<tr >
			<td >MEM with Earle&#39;s Balanced Salt Solution 2.2 g/L NaHCO3, stable glutamine w/o PR</td>
			<td >Biochrom</td>
			<td >FG-0385</td>
			<td></td>
		</tr>
		<tr >
			<td >MEM with Earle&#39;s Balanced Salt Solution with 2.2 g/L NaHCO3, stable glutamine, Phenolred</td>
			<td >Biochrom</td>
			<td >FG-0325</td>
			<td></td>
		</tr>
		<tr >
			<td >MitoTracker&#174; Deep Red FM</td>
			<td >Thermo Fisher Scientific</td>
			<td >M22426</td>
			<td>dye</td>
		</tr>
		<tr >
			<td >MitoTracker&#174; Green FM</td>
			<td >Thermo Fisher Scientific</td>
			<td >M7514</td>
			<td>dye</td>
		</tr>
		<tr >
			<td >Multi-mode-optical polarization maintaining monomode fiber</td>
			<td >Pointsource/Qioptiq</td>
			<td></td>
			<td>KineFLEX</td>
		</tr>
		<tr >
			<td >NHS-PEG-MAL, Rapp Polymer&#160;</td>
			<td >Rapp Polymere GmbH T&#252;bingen</td>
			<td ></td>
			<td>coverslip coating</td>
		</tr>
		<tr >
			<td >non-essential amino acids (NEAA)</td>
			<td >Biochrom</td>
			<td >#0802E</td>
			<td></td>
		</tr>
		<tr >
			<td >PEG 800 (Polyethylene glycol) 10 %</td>
			<td >Carl Roth GmbH</td>
			<td >Art No. 0263.1</td>
			<td>coverslip coating</td>
		</tr>
		<tr >
			<td >Penicillin/Streptomycin</td>
			<td >Biochrom</td>
			<td >#0122E</td>
			<td></td>
		</tr>
		<tr >
			<td >Plasmid for PINK1-Halo7-Tag expression</td>
			<td >Beinlich et al., ACS Chemical Biology 2015</td>
			<td></td>
			<td></td>
		</tr>
		<tr >
			<td >Poly-L-lysine (1.2 mg/ml)</td>
			<td >Sigma-Aldrich &#38; Co.</td>
			<td >Cat. No.P9155</td>
			<td>coverslip coating</td>
		</tr>
		<tr >
			<td >RGD Peptide (Ac-CGRGDS-COOH)</td>
			<td >Coring System Diagnostix GmbH, Gernsheim</td>
			<td ></td>
			<td>coverslip coating / Intergrin receptor motif</td>
		</tr>
		<tr >
			<td >Silicon Rhodamine linked to HaloTag&#174;-Ligand (SiRHTL)&#160;</td>
			<td >personal gift from Kai Johnson</td>
			<td ></td>
			<td>dye</td>
		</tr>
		<tr >
			<td >Software analysis plugin</td>
			<td >self-written C. P. Richter, Biophysik Osnabr&#252;ck</td>
			<td >SLIMFAST 16g</td>
			<td></td>
		</tr>
		<tr >
			<td >Tetramethylrhodamine / SNAP-Cell&#174; TMR-Star linked to SNAP-Ligand (TMRstar)&#160;</td>
			<td >New England Biolab&#174;</td>
			<td >S9105S</td>
			<td>dye</td>
		</tr>
		<tr >
			<td >Tetramethylrhodamine linked to HaloTag&#174;-Ligand (TMRHTL)&#160;</td>
			<td >Promega</td>
			<td >G8251</td>
			<td>dye</td>
		</tr>
		<tr >
			<td >TIRF condensor</td>
			<td >Olympus</td>
			<td>Cell^TIRF MITICO System</td>
			<td>TIRF condensor</td>
		</tr>
		<tr >
			<td >TIRF microscope controlling software</td>
			<td >Olympus cellSens 1.12</td>
			<td ></td>
			<td></td>
		</tr>
		<tr >
			<td >TIRF objective</td>
			<td>Olympus</td>
			<td>150x oil objective (N.A. 1.45; Olympus UAPO)</td>
			<td></td>
		</tr>
		<tr >
			<td >Trypsin/EDTA 10x</td>
			<td >Biochrom</td>
			<td >#0266</td>
			<td></td>
		</tr>
		<tr >
			<td >Water H2O 99,5 % Rotipuran&#174; Low organic&#160;</td>
			<td >Carl Roth GmbH</td>
			<td >Art. No. HN57.1</td>
			<td></td>
		</tr>
	</tbody>
</table>

multi-color localization microscopy of single membrane proteins in organelles of live mammalian cells

Subcompartments 세포에 있는 단백질의 지역화에 대 한 지식을 그들의 특정 한 기능을 이해 하는 것이 결정적 이다. 여기, 우리는 지역화를 생성 하 고이 단백질의 지도 추적 하 여 단백질을 위해 액세스할 수 있는 microcompartments의 결정에 대 한 수 있도록 슈퍼 해상도 기법 제시. 또한, 멀티 컬러 지역화 현미경으로 지역화 및 추적 프로필 다른 subcompartments에 있는 단백질의 얻을 수 있습니다 동시에. 기술은 살아있는 세포에 대 한 특정 이며 단일 모바일 막 단백질의 반복적인 이미지에 기반. 관심사의 단백질 유전자 특정, 소위 자체 라벨 태그와 융합 된다. 이 태그는 기판 공유 방식으로 반응 하는 효소. 이러한 기판에 활용 된 형광 염료입니다. 형광과 효소 태그 단백질의 반응 레이블이 단백질에 기판 결과 표시. 여기, Tetramethylrhodamine (TMR)와 실리콘 Rhodamine (선생님)는 효소의 기질에 부착 된 형광 염료로 사용 됩니다. NM 범위에 오후에 기질 농도 사용 하 여 하위 화학 량 론 라벨 이루어집니다 뚜렷한 신호 귀착되는. 이러한 신호 ~ 15-27와 지역화는 nm 정밀도. 기술을은 사용할 수 막 투과성 염료와 효소 레이블이 자체적으로 지정 하는 것이 레 퍼 토리에 의해 색상 수는 제한 하는 의하여 단일 분자의 멀티 컬러 이미징 할 수 있습니다. 우리 품질 관리 효소 (Pten)의 지역화를 결정 하 여 기술의 타당성을 보여줍니다-다른 막 단백질에 관하여 처리 하는 동안 다른 미토 콘 드 리아 구획에 니 1 (PINK1)을 유발. 단일 분자 무서 워 또는 공동 추적에 의해 다르게 레이블이 단일 단백질 간의 진정한 실제 상호 작용에 대 한 테스트는 제한 하지만, 낮은 라벨도 두 개의 인접 한 단백질을 동시에 표시 하는 데에 대 한 확률 감소 때문입니다. 기술은 단백질 막 구획에 이미징에 대 한 강한 동안, 대부분의 경우 높은 모바일 수용 성 단백질의 지역화가 결정 적합 하지 않다.

멀티 컬러 이미징 및 colocalization 분석은 단백질의 하위 organellar 지역화가 결정을 도울 수 있다. 우리가 시연이 이전 cytosolic 인산 가수분해 효소와 tensin homologue, PINK1, 미토 콘 드 리아 프로 테아 제17에 의해 그것의 처리로 인해 다른 하위-미토 콘 드리 아 위치는. PINK1 미토 콘 드 리아 기능34,35보장 하는 중요 한 ?...

Watch this Scientific Journal Video about Multi-color Localization Microscopy of Single Membrane Proteins in Organelles of Live Mammalian Cells at JoVE.com

Multi-color Localization Microscopy of Single Membrane Proteins in Organelles of Live Mammalian Cells

여기, 우리 살아있는 세포의 세포에 단일 막 단백질의 다 색 지역화에 대 한 프로토콜을 제시. Fluorophores 연결할 자체 라벨 단백질 사용 됩니다. 단백질, 세포 기관이 동일한의 다른 막 구획에 있는 ~ 18의 정밀도로 지역화할 수 nm.

살아있는 포유류 세포의 세포에서 단일 막 단백질의 다 색 지역화 현미경

Knowledge about the localization of proteins in cellular subcompartments is crucial to understand their specific function. Here, we present a ...

multi-color-localization-microscopy-single-membrane-proteins

Research

JoVE Journal

Biology

8.4K 조회수.  University of Osnabrück. 여기, 우리 살아있는 세포의 세포에 단일 막 단백질의 다 색 지역화에 대 한 프로토콜을 제시. Fluorophores 연결할 자체 라벨 단백질 사용 됩니다. 단백질, 세포 기관이 동일한의 다른 막 구획에 있는 ~ 18의 정밀도로 지역화할 수 nm.

비디오: Multi-color Localization Microscopy of Single Membrane Proteins in Organelles of Live Mammalian Cells

Long-term Imaging Mammalian Cells using Wide-Field Microscopy

Actually what I'm gonna do, mount it in here first and then swap out You. So now I'm gonna aspirate try and be as gentle as possible.Okay. A few seconds just holding.Okay.Alright.So the important features of our lifestyle imaging grid are that, so it's an inverted scope, which means the objective, the samples here in the objective is underneath. So the objective is pointing up and the whole scope, or practically the whole, practically the whole scope, including the objectives and the sample are at 37 degrees. So everything in this plastic box is at 37 degrees.And right on top of the stage we have an air and CO2 mix. That is 5%CO2. So the idea is that the sample is actually in a cell, it's like a cell incubator.And so we have, this is our mixer for the air and the CO2 and, and it gets humidified and heated and then piped onto the, the sample on the stage.Okay. And today we're just gonna be doing fluorescence one channel GFP fluorescence. This is the hose that the CO2 and 5%CO2 goes in and it just fits into the stage holder.That's important. And then we can close these, take these down, and then we go to our first position. And what I'm gonna do is go to the first field, which is my control sample, and I'll pick positions based on what I see on the screen.So I just make sure I actually look into the microscope in each new, well, because the focal plane for each of the wells is different, the, the dish is not perfectly flat on the bottom. So you will need to make fine adjustments when you move from well to the well. So right now I'm on the first, well, what I'll do is I'll focus, so I just hit, I just told, I just turned on the light, the transmitted light for the microscope.And I have make sure all the light is going to the eye pieces. And so I just look in, make sure I get a nice clean field. And then what I'll do is turn that light off, turn the fluorescence light on, make sure the cells that I'm looking at look healthy and they're not apoptotic.And, and I turn that off. And what I do next is send, so now I'm gonna start picking positions, which means I have to te send the light path to the camera. This is the camera right here.So I tell the microscope to send all the camera, they don't see anything in the eye pieces. What I'll do is in the software controlling the microscope, I'll choose the right filter set, which for our purposes is psy. And then set an exposure time.And I know these cells very well and I know that they take a 0.2 second exposure time. So I tell, that's what I tell the software to do. And what I'll do is hit focus.This is, and it's basically just alive. The, A light will turn on and you can, oh, I don't know if you can see cells, but the reason this is a good field is because there's, all the cells are, even in terms of their fluorescence, There are no apoptotic cells. Apoptotic cells tend to be very bright and there's no dirt or schmutz in the field.And you can see that they're actually, this is a metaphase cell and that's a metaphase cell, that's a cell that's probably just exited mitosis. And I can just tell that because it looks like those are, those two sets of chromatin are very nicely oriented to each other. Like they just exited an face.So that's a good field. So, and now that I know that the exposure time and the filter set is correct, and this is gonna be software specific, I'll go and I'll take positions and now the software has memorized the X, Y, Z position of that field. And then when I do pick another field, it's, and I'll, so when I'm picking, when I'm picking new fields, but in the same, well, I'll use the, I'll move the i'll, I'll turn the shutter, I'll open the shutter and I'll look to see what I see on the screen and I'll pick fields based on that versus looking in the field.So I don't see any of my tonics in there. But again, even nicely centered, these cells will go through my PS I continue, here's a good example. Here's a good example of what I would avoid that, see how bright that is?That's very bright. That's probably remnants of an apoptotic cell. And the reason I would avoid that is because since it's so bright, when the software auto focuses, it will autofocus just on that and it won't be in the same plane as all these other cells.And so I won't get any information from that field. That looks nice. There's a, this is a pro metaphase right here, That's A metaphase.So, and I'm gonna take three positions per well. So that was three positions and now I'm going to go to my next Well, so you can, so what I will probably do is take images every 10 minutes. So it's a compromise.Lifestyle imaging is always a compromise, right? You have to image, you have to keep the cells healthy, especially if you're interested in mitosis. So you have to minimize their exposure to the fluorescent line.And, but you wanna get information. So you have to take images, you have to, so you have to compromise, you have to make a choice about what you want to capture, what kind of information you wanna capture. For our purposes, mitosis tends to take about an hour.So if we're taking 10 minute intervals, that's pretty good. We see prophase, we see metaphase, we see anaphase, and we can, we can see when there are, there are treatments or drugs or siRNAs that affect those specific cell cycle stages. So for our purposes, that's enough, but we always want more.We always want more positions or finer time and interval or something like that. So it's a compromise. So, and then I'll hit start.And so our software, it does an autofocusing pass on the first pass. So once I hit start, it should start auto autofocusing and you'll see the shutter open, open and close between auto focusing. So I'll hit start.So that's the shutter opening and closing. The Z motor is engaging and it's actually trying to find the plane with the most contrast, which will be the most in focus. You can actually see on the screen going in and out of finding the best plane of focus that might be worrisome.So what it does is it, it drives the Z motor to find the best, the most in focus plane focus, well the most in image. And then it acquires picture there and then it learns that Z position. And then we'll use that Z position for the next 12 passes.And then we'll do the auto focusing pass again. What Kind of experiments do they do? Okay, so our lab is mostly interested in understanding what regulates mitic progression, or at least I'm most interested in understanding that.So with live cell imaging and especially our multi position, long-term imaging scope, you can take, you can film cells for two or three days entering anding mitosis, and you can image multiple rounds of mitosis so you can understand. And then you can put drugs or RNAs or any kind of perturbations on the cells that you would like to study. So you can understand how, how those drugs or, or genes are, are important in regulating mitotic progression.Because it's not fixed cell work and live cell work, you can understand what, when you need to have a perturbation to affect mitosis or what stage of mitosis is affected. So it's really powerful in that respect. What, what are the main technical elements of this experiments?What are the possible problems? Well, the biggest problem besides getting the rig set up, getting the rig set up is not trivial. A lot of people have the rig, but just making sure it works well for your application.The financial element is not, you know, is not small. So there's the setting up of the apparatus and then, and then once you gather the data, there's a real data analysis issue. It takes these movie, if, so, if you're gathering 40 movies each with 30 cells, so you have 40 in 40 fields that you just filmed and each of those fields has 30 cells, then you have to sit down with each one of those movies and look at each one of those cells in that movie.So it takes a really long time to do data analysis. And that's, so it takes a week to analyze data that it took you two days to collect. So there's a, that's a very big obstacle in terms of gathering lots of data.So it's not, while it's high throughput data collection, it's not high throughput analysis. So what would you make to make this experiment really high throughput? So our lab is in the process of developing a program that does the data analysis automatically.And it's a pretty decent program. It's not perfect. The human eye is always better, but it's getting there.So What are the interesting application of this experiment? Maybe other fields you can mention? Besides cell division?You mean for the, oh, for the live cell imaging? Yes.Well, you can do cell motility assays. You can, depending on the, the microscopy that's involved, you can, you know, look at how cells, you could look at tumor development if you really wanted to.But there, you, you're, if as long as you have the right imaging set up, you can, you're pretty much not limited in terms of anything. Our scope happens to be just a wide field and we use 20 by 20 x objective. So it's a pretty low resolution set up, but that's sufficient for what we need to see.So there are, but there definitely aren't, you wouldn't be limited. Anything that has any dynamic kind of experiment, which is biology, it would be, would really benefit from lifestyle imaging. So calcium imaging, although you couldn't do it on our apparatus, that's a live cell.You definitely need live cell imaging for that. Like I said, patient assays, motility assays, those kinds of things would really benefit from live cell imaging. Would you like to tell a few words about your previous experience?How long do you work on these techniques? What do you you work on before? Wow.So in my PhD I didn't work.I did a lot of confocal microscopy, but no lifestyle imaging. And so during my postdoc I was, I helped Dr.King get this apparatus that, that we just used to set up these fragment, get that up and running. And, and so during my postdoc, I had a lot of experience with both widefield with TimeLapse imaging on our scope, which is the widefield and also TimeLapse imaging with confocal microscopy.And I would say that it's really powerful. You get a lot of information, but it's not easy to get working perfectly. So it really requires a lot of attention and a lot of attention to details at every little step of the process.And, and then you still have problems. So it's a tough application, but you can really get, if, if it's what you need to have to, to study your problem, your scientific problem, then it, it's invaluable in that respect, but it's tough. So find someone who knows what they're doing and use them.That's my advice. So good.

와이드 필드 현미경을 사용하여 장기 이미징 포유 동물 세포

연구

생물학

Crystallizing Membrane Proteins for Structure Determination using Lipidic Mesophases

A detailed protocol for crystallizing membrane proteins by using lipidic mesophases is described. This method has variously been referred to as the lipidic cubic phase or in meso method. The method has been shown to be quite versatile in that it has been used to solve X-ray crystallographic structures of prokaryotic and eukaryotic proteins, proteins that are monomeric, homo- and hetero-multimeric, chromophore-containing and chromophore-free, and alpha-helical and beta-barrel proteins. Recent successes using in meso crystallization are the human engineered beta2-adrenergic and adenosine A2a G protein-coupled receptors. Protocols are presented for reconstituting the membrane protein into the monoolein-based mesophase, and for setting up crystallizations in the manual mode. Additional steps in the overall process, such as crystal harvesting, are to be addressed in future video articles. The time required to prepare the protein-loaded mesophase and to set up a crystallization plate manually is about one hour.

Herein is described the procedure implemented in the Caffrey Membrane Structural and Functional Biology Group to set up manually crystallization trials of membrane proteins in lipidic mesophases.

Lipidic Mesophases를 사용하여 구조 결정을위한 막 단백질 Crystallizing

A detailed protocol for crystallizing membrane proteins by using lipidic mesophases is described. This method has variously been referred to as the ...

Crystallization of Membrane Proteins in Lipidic Mesophases

Membrane proteins perform critical functions in living cells related to signal transduction, transport and energy transformations, and, as such, are implicated in a multitude of malfunctions and diseases. However, a structural and functional understanding of membrane proteins is strongly lagging behind that of their soluble partners, mainly, due to difficulties associated with their solubilization and generation of diffraction quality crystals. Crystallization in lipidic mesophases (also known as in meso or LCP crystallization) is a promising technique which was successfully applied to obtain high resolution structures of microbial rhodopsins, photosynthetic proteins, outer membrane beta barrels and G protein-coupled receptors. In meso crystallization takes advantage of a native-like membrane environment and typically produces crystals with lower solvent content and better ordering as compared to traditional crystallization from detergent solutions. The method is not difficult, but requires an understanding of lipid phase behavior and practice in handling viscous mesophase materials. Here we demonstrate a simple and efficient way of making LCP and reconstituting a membrane protein in the lipid bilayer of LCP using a syringe mixer, followed by dispensing nanoliter portions of LCP into an assay or crystallization plate, conducting pre-crystallization assays and harvesting crystals from the LCP matrix. These protocols provide a basic guide for approaching in meso crystallization trials; however, as with any crystallization experiment, extensive screening and optimization are required, and a successful outcome is not necessarily guaranteed.

The protocols describe the essential steps for obtaining diffraction quality crystals of a membrane protein starting from reconstitution of the protein in a lipidic cubic phase (LCP), finding initial conditions with LCP-FRAP pre-crystallization assays, setting up LCP crystallization trials and harvesting crystals.

Lipidic Mesophases의 막 단백질의 결정화

Membrane proteins perform critical functions in living cells related to signal transduction, transport and energy transformations, and, as such, are ...

Nano-fEM: Protein Localization Using Photo-activated Localization Microscopy and Electron Microscopy

Mapping the distribution of proteins is essential for understanding the function of proteins in a cell. Fluorescence microscopy is extensively used for protein localization, but subcellular context is often absent in fluorescence images. Immuno-electron microscopy, on the other hand, can localize proteins, but the technique is limited by a lack of compatible antibodies, poor preservation of morphology and because most antigens are not exposed to the specimen surface. Correlative approaches can acquire the fluorescence image from a whole cell first, either from immuno-fluorescence or genetically tagged proteins. The sample is then fixed and embedded for electron microscopy, and the images are correlated 1-3. However, the low-resolution fluorescence image and the lack of fiducial markers preclude the precise localization of proteins.
Alternatively, fluorescence imaging can be done after preserving the specimen in plastic. In this approach, the block is sectioned, and fluorescence images and electron micrographs of the same section are correlated 4-7. However, the diffraction limit of light in the correlated image obscures the locations of individual molecules, and the fluorescence often extends beyond the boundary of the cell.
Nano-resolution fluorescence electron microscopy (nano-fEM) is designed to localize proteins at nano-scale by imaging the same sections using photo-activated localization microscopy (PALM) and electron microscopy. PALM overcomes the diffraction limit by imaging individual fluorescent proteins and subsequently mapping the centroid of each fluorescent spot 8-10.
We outline the nano-fEM technique in five steps. First, the sample is fixed and embedded using conditions that preserve the fluorescence of tagged proteins. Second, the resin blocks are sectioned into ultrathin segments (70-80 nm) that are mounted on a cover glass. Third, fluorescence is imaged in these sections using the Zeiss PALM microscope. Fourth, electron dense structures are imaged in these same sections using a scanning electron microscope. Fifth, the fluorescence and electron micrographs are aligned using gold particles as fiducial markers. In summary, the subcellular localization of fluorescently tagged proteins can be determined at nanometer resolution in approximately one week.

We describe a method to localize fluorescently tagged proteins in electron micrographs. Fluorescence is first localized using photo-activated localization microscopy on ultrathin sections. These images are then aligned to electron micrographs of the same section.

나노 FEM : 사진 활성화 된 현지화 현미경과 전자 현미경을 사용하여 단백질 현지화

Mapping the distribution of proteins is essential for understanding the function of proteins in a cell. Fluorescence microscopy is extensively used for ...

Use of a Robot for High-throughput Crystallization of Membrane Proteins in Lipidic Mesophases

Structure-function studies of membrane proteins greatly benefit from having available high-resolution 3-D structures of the type provided through macromolecular X-ray crystallography (MX). An essential ingredient of MX is a steady supply of ideally diffraction-quality crystals. The in meso or lipidic cubic phase (LCP) method for crystallizing membrane proteins is one of several methods available for crystallizing membrane proteins. It makes use of a bicontinuous mesophase in which to grow crystals. As a method, it has had some spectacular successes of late and has attracted much attention with many research groups now interested in using it. One of the challenges associated with the method is that the hosting mesophase is extremely viscous and sticky, reminiscent of a thick toothpaste. Thus, dispensing it manually in a reproducible manner in small volumes into crystallization wells requires skill, patience and a steady hand. A protocol for doing just that was developed in the Membrane Structural &amp; Functional Biology (MS&amp;FB) Group1-3. JoVE video articles describing the method are available1,4.
The manual approach for setting up in meso trials has distinct advantages with specialty applications, such as crystal optimization and derivatization. It does however suffer from being a low throughput method. Here, we demonstrate a protocol for performing in meso crystallization trials robotically. A robot offers the advantages of speed, accuracy, precision, miniaturization and being able to work continuously for extended periods under what could be regarded as hostile conditions such as in the dark, in a reducing atmosphere or at low or high temperatures. An in meso robot, when used properly, can greatly improve the productivity of membrane protein structure and function research by facilitating crystallization which is one of the slow steps in the overall structure determination pipeline.
In this video article, we demonstrate the use of three commercially available robots that can dispense the viscous and sticky mesophase integral to in meso crystallogenesis. The first robot was developed in the MS&amp;FB Group5,6. The other two have recently become available and are included here for completeness.
An overview of the protocol covered in this article is presented in Figure 1. All manipulations were performed at room temperature (~20 &deg;C) under ambient conditions.

Herein is described a robotic approach to high-throughput crystallization of membrane proteins in lipidic mesophases for use in structure determination using macromolecular X-ray crystallography. Three robots capable of handling the viscous and sticky protein-laden mesophase integral to the method are introduced.

Lipidic Mesophases의 막 단백질의 높은 처리량을 결정하기위한 로봇의 사용

Structure-function studies of membrane proteins greatly benefit from having available high-resolution 3-D structures of the type provided through ...

Harvesting and Cryo-cooling Crystals of Membrane Proteins Grown in Lipidic Mesophases for Structure Determination by Macromolecular Crystallography

An important route to understanding how proteins function at a mechanistic level is to have the structure of the target protein available, ideally at atomic resolution. Presently, there is only one way to capture such information as applied to integral membrane proteins (Figure 1), and the complexes they form, and that method is macromolecular X-ray crystallography (MX). To do MX diffraction quality crystals are needed which, in the case of membrane proteins, do not form readily. A method for crystallizing membrane proteins that involves the use of lipidic mesophases, specifically the cubic and sponge phases1-5, has gained considerable attention of late due to the successes it has had in the G protein-coupled receptor field6-21 (<a href="http://www.mpdb.tcd.ie" target="_blank">www.mpdb.tcd.ie</a>). However, the method, henceforth referred to as the in meso or lipidic cubic phase method, comes with its own technical challenges. These arise, in part, due to the generally viscous and sticky nature of the lipidic mesophase in which the crystals, which are often micro-crystals, grow. Manipulating crystals becomes difficult as a result and particularly so during harvesting22,23. Problems arise too at the step that precedes harvesting which requires that the glass sandwich plates in which the crystals grow (Figure 2)24,25 are opened to expose the mesophase bolus, and the crystals therein, for harvesting, cryo-cooling and eventual X-ray diffraction data collection.
The cubic and sponge mesophase variants (Figure 3) from which crystals must be harvested have profoundly different rheologies4,26. The cubic phase is viscous and sticky akin to a thick toothpaste. By contrast, the sponge phase is more fluid with a distinct tendency to flow. Accordingly, different approaches for opening crystallization wells containing crystals growing in the cubic and the sponge phase are called for as indeed different methods are required for harvesting crystals from the two mesophase types. Protocols for doing just that have been refined and implemented in the Membrane Structural and Functional Biology (MS&amp;FB) Group, and are described in detail in this JoVE article (Figure 4). Examples are given of situations where crystals are successfully harvested and cryo-cooled. We also provide examples of cases where problems arise that lead to the irretrievable loss of crystals and describe how these problems can be avoided. In this article the Viewer is provided with step-by-step instructions for opening glass sandwich crystallization wells, for harvesting and for cryo-cooling crystals of membrane proteins growing in cubic and in sponge phases.

Herein is described procedures implemented in the Caffrey Membrane Structural and Functional Biology Group to harvest and cryo-cool membrane protein crystals grown in lipidic cubic and sponge phases for use in structure determination using macromolecular X-ray crystallography.

Macromolecular의 결정학에 의해 구조 결정에 대한 Lipidic Mesophases에서 재배 막 단백질의 수확 및 Cryo 냉각 크리스털

An important route to understanding how proteins function at a mechanistic level is to have the structure of the target protein available, ideally at ...

Monitoring Plasmid Replication in Live Mammalian Cells over Multiple Generations by Fluorescence Microscopy

Few naturally-occurring plasmids are maintained in mammalian cells. Among these are genomes of gamma-herpesviruses, including Epstein-Barr virus (EBV) and Kaposi's Sarcoma-associated herpesvirus (KSHV), which cause multiple human malignancies 1-3. These two genomes are replicated in a licensed manner, each using a single viral protein and cellular replication machinery, and are passed to daughter cells during cell division despite their lacking traditional centromeres 4-8.
Much work has been done to characterize the replications of these plasmid genomes using methods such as Southern blotting and fluorescence in situ hybridization (FISH). These methods are limited, though. Quantitative PCR and Southern blots provide information about the average number of plasmids per cell in a population of cells. FISH is a single-cell assay that reveals both the average number and the distribution of plasmids per cell in the population of cells but is static, allowing no information about the parent or progeny of the examined cell.
Here, we describe a method for visualizing plasmids in live cells. This method is based on the binding of a fluorescently tagged lactose repressor protein to multiple sites in the plasmid of interest 9. The DNA of interest is engineered to include approximately 250 tandem repeats of the lactose operator (LacO) sequence. LacO is specifically bound by the lactose repressor protein (LacI), which can be fused to a fluorescent protein. The fusion protein can either be expressed from the engineered plasmid or introduced by a retroviral vector. In this way, the DNA molecules are fluorescently tagged and therefore become visible via fluorescence microscopy. The fusion protein is blocked from binding the plasmid DNA by culturing cells in the presence of IPTG until the plasmids are ready to be viewed.
This system allows the plasmids to be monitored in living cells through several generations, revealing properties of their synthesis and partitioning to daughter cells. Ideal cells are adherent, easily transfected, and have large nuclei. This technique has been used to determine that 84% of EBV-derived plasmids are synthesized each generation and 88% of the newly synthesized plasmids partition faithfully to daughter cells in HeLa cells. Pairs of these EBV plasmids were seen to be tethered to or associated with sister chromatids after their synthesis in S-phase until they were seen to separate as the sister chromatids separated in Anaphase10. The method is currently being used to study replication of KSHV genomes in HeLa cells and SLK cells. HeLa cells are immortalized human epithelial cells, and SLK cells are immortalized human endothelial cells. Though SLK cells were originally derived from a KSHV lesion, neither the HeLa nor SLK cell line naturally harbors KSHV genomes11. In addition to studying viral replication, this visualization technique can be used to investigate the effects of the addition, removal, or mutation of various DNA sequence elements on synthesis, localization, and partitioning of other recombinant plasmid DNAs.

A method of observing individual DNA molecules in live cells is described. The technique is based on the binding of a fluorescently tagged lac repressor protein to binding sites engineered into the DNA of interest. This method can be adapted to follow many recombinant DNAs in live cells over time.

형광 현미경으로 여러 세대 이상 라이브 포유류의 세포에 플라스미드 복제 모니터링

Few naturally-occurring plasmids are maintained in mammalian cells.  Among these are genomes of gamma-herpesviruses, including Epstein-Barr virus  (EBV) ...

Intravital Microscopy for Imaging Subcellular Structures in Live Mice Expressing Fluorescent Proteins

Here we describe a procedure to image subcellular structures in live rodents that is based on the use of confocal intravital microscopy. As a model organ, we use the salivary glands of live mice since they provide several advantages. First, they can be easily exposed to enable access to the optics, and stabilized to facilitate the reduction of the motion artifacts due to heartbeat and respiration. This significantly facilitates imaging and tracking small subcellular structures. Second, most of the cell populations of the salivary glands are accessible from the surface of the organ. This permits the use of confocal microscopy that has a higher spatial resolution than other techniques that have been used for in vivo imaging, such as two-photon microscopy. Finally, salivary glands can be easily manipulated pharmacologically and genetically, thus providing a robust system to investigate biological processes at a molecular level.
In this study we focus on a protocol designed to follow the kinetics of the exocytosis of secretory granules in acinar cells and the dynamics of the apical plasma membrane where the secretory granules fuse upon stimulation of the beta-adrenergic receptors. Specifically, we used a transgenic mouse that co-expresses cytosolic GFP and a membrane-targeted peptide fused with the fluorescent protein tandem-Tomato. However, the procedures that we used to stabilize and image the salivary glands can be extended to other mouse models and coupled to other approaches to label in vivo cellular components, enabling the visualization of various subcellular structures, such as endosomes, lysosomes, mitochondria, and the actin cytoskeleton.

Intravital microscopy is a powerful tool that enables imaging various biological processes in live animals. In this article, we present a detailed method for imaging the dynamics of subcellular structures, such as the secretory granules, in the salivary glands of live mice.

형광 단백질을 표현 라이브 마우스의 이미징 세포 이하의 구조물의 intravital 현미경

Here we describe a procedure to image subcellular structures in live rodents that is based on the use of confocal intravital microscopy. As a model organ, ...

In vivo Clonal Tracking of Hematopoietic Stem and Progenitor Cells Marked by Five Fluorescent Proteins using Confocal and Multiphoton Microscopy

We developed and validated a fluorescent marking methodology for clonal tracking of hematopoietic stem and progenitor cells (HSPCs) with high spatial and temporal resolution to study in vivo hematopoiesis using the murine bone marrow transplant experimental model. Genetic combinatorial marking using lentiviral vectors encoding fluorescent proteins (FPs) enabled cell fate mapping through advanced microscopy imaging. Vectors encoding five different FPs: Cerulean, EGFP, Venus, tdTomato, and mCherry were used to concurrently transduce HSPCs, creating a diverse palette of color marked cells. Imaging using confocal/two-photon hybrid microscopy enables simultaneous high resolution assessment of uniquely marked cells and their progeny in conjunction with structural components of the tissues. Volumetric analyses over large areas reveal that spectrally coded HSPC-derived cells can be detected non-invasively in various intact tissues, including the bone marrow (BM), for extensive periods of time following transplantation. Live studies combining video-rate multiphoton and confocal time-lapse imaging in 4D demonstrate the possibility of dynamic cellular and clonal tracking in a quantitative manner.

In vivo Clonal Tracking of Hematopoietic Stem and Progenitor Cells Marked by Five Fluorescent Proteins using Confocal and Multiphoton Microscopy

Combinatorial 5 fluorescent proteins marking of hematopoietic stem and progenitor cells allows in vivo clonal tracking via confocal and two-photon microscopy, providing insights into bone marrow hematopoietic architecture during regeneration. This method allows non-invasive fate mapping of spectrally-coded HSPCs-derived cells in intact tissues for extensive periods of time following transplantation.

공 초점 및 다중 광자 현미경을 사용하여 다섯 형광 단백질에 의해 표시됨 조혈 줄기 및 전구 세포의 생체 내 클론 추적에서

We developed and validated a fluorescent marking methodology for clonal tracking of hematopoietic stem and progenitor cells (HSPCs) with high spatial and ...

Efficient Mammalian Cell Expression and Single-step Purification of Extracellular Glycoproteins for Crystallization

Production of secreted mammalian proteins for structural and biophysical studies can be challenging, time intensive, and costly. Here described is a time and cost efficient protocol for secreted protein expression in mammalian cells and one step purification using nickel affinity chromatography. The system is based on large scale transient transfection of mammalian cells in suspension, which greatly decreases the time to produce protein, as it eliminates steps, such as developing expression viruses or generating stable expressing cell lines. This protocol utilizes cheap transfection agents, which can be easily made by simple chemical modification, or moderately priced transfection agents, which increase yield through increased transfection efficiency and decreased cytotoxicity. Careful monitoring and maintaining of media glucose levels increases protein yield. Controlling the maturation of native glycans at the expression step increases the final yield of properly folded and functional mammalian proteins, which are ideal properties to pursue X-ray crystallography. In some cases, single step purification produces protein of sufficient purity for crystallization, which is demonstrated here as an example case.

This is a quick, cost-efficient protocol for the production of secreted, glycosylated mammalian proteins and subsequent single-step purification with sufficient yields of homogenous protein for X-ray crystallography and other biophysical studies.

효율적인 포유 동물 세포 발현 및 결정화에 대한 세포 외 당 단백질의 단일 단계 정화

Production of secreted mammalian proteins for structural and biophysical studies can be challenging, time intensive, and costly. Here described is a time ...
