이 작품에서 국립 자연 과학 재단 (81771617) 및 자연 과학 재단의 광 동 지방 (2016A030313178) X.F.;에 게 수 여 교부 금에 의해 지원 되었다 심천 기본 연구 기금 (JCYJ20170413165233512) X.F;에 수 여에서 부여 유 니스 케네디 슈 라이버 국립 연구소의 아동 건강 및 보너스 번호 R01HD088549에서 건강의 국가 학회의 인간 발달 (전적으로 저자의 책임은 내용과 반드시 공식 대표 하지 않는다 국립 보건원의 조회) N.N. 하

모든 마우스 실험 동물 관리 및 사용 위원회의 심천 연구소의 첨단 기술, 과학의 중국 아카데미에 의해 승인 되는 프로토콜 (SIAT-IRB-160520-YYS-FXJ-A0232)에 엄격 하 게 따 랐 다.
1. 태 반 Chondroitin 황산 염 A 대상 지질 고분자 나노 입자의 합성
<ol><li>MTX 및 ICG 로드 지질 고분자 나노 입자를 합성 (MNPs와 INPs 각각) plCSA BP 활용 된 나노 입자 (plCSA-MNPs와 plCSA INPs)에 설명 된 대로 자세하게 다른18.</li>
</ol>2. vivo 형광 이미징
<ol><li>
임신 쥐의 준비
	<ol>
<li>한 장에 동일한 긴장의 비옥한 남성 여성 CD-1 마우스 (8-12 주) 장소 (남성: 여성 = 1:2) 확인 하 고 오후에는 질 플러그 다음 아침. 질 플러그 관찰 되는 경우 배아 하루 0.5 (E0.5)으로 마우스를 정의 합니다.</li>
		<li>집 임신 마우스 혼자 어두운 14 h 빛/10 h 동물 병원 체 없는 방에 주기을 E14.5까지 음식과 물에 대 한 무료 액세스를 제공 합니다.</li>
	</ol>
</li>
	<li>
나노 입자의 정 맥 주입
	<ol>
<li>절차, 전에 0.22 μ m 주사기 필터를 통해은 나노 여과 의해 소독. 수량 및 나노 사출의 볼륨을 결정 하기 위해 E11.5에서 임신 마우스 무게. 참고: 나노 사출 볼륨 1% 미만 (볼륨/중량) 임신 마우스의 몸 무게의 이어야 한다. 예를 들어 나노 사출 볼륨 25 g 마우스에 0.25 mL 미만 이어야 한다.</li>
		<li>꼬리 정 맥 팽창가 열 패드와 함께 5-10 분에 대 한 꼬리를 따뜻한.</li>
		<li>28 g 인슐린 주사기에 주입 하기 전에 INPs 또는 plCSA INPs 발음.</li>
		<li>임신 마우스를 꼬리 정 맥에 대 한 액세스를 허용 하는 동안 마우스를 멈출 지주 장치 전송. 꼬리는 알코올 면봉으로 청소 합니다. 다음 꼬리 정 맥에 주사기를 삽입 합니다. 천천히 주입 INPs 또는 plCSA-INPs (5 mg/kg ICG 해당)도 압력에 5-10 s. 참고: 물집에 나타나면 꼬리 때문에이 결과 바늘 임을 나타냅니다 하지 정 맥 주입을 중지 합니다. 주사기는 질병 전송 최소화 하기 위해 마우스 및 교차 오염을 사이 공유 되지 않을.</li>
		<li>사출 시간을 기록 합니다. 한편,는 일반적으로 30-60 s 출혈 정지까지 사출 사이트에 부드러운 압력을 적용 됩니다.</li>
	</ol>
</li>
	<li>
Vivo에서 화상 진 찰
	<ol>
<li>주입 후 30 분 임신 쥐에서 vivo 형광 이미징 시스템을 사용 하 여 이미지.</li>
		<li>Anesthetize 1.0 L/min와 isoflurane 마 취 단위의 관련된 상공에 2-4%의 산소 흐름 속도와 임신 쥐 고 느린에 의해 전체 마 취와 일반 호흡을 확인 합니다. 그런 다음 이미징 챔버로 이동 합니다. 부정사 위치에 동물 유지 이미징 실로 마 취 임신 마우스를 놓습니다.</li>
		<li>입과 마 취를 유지 하기 위해 1.0 L/min의 산소 흐름 속도 1-2 %isoflurane 흡입 수 있도록 코 코 콘 장소.</li>
		<li>ICG 형광 신호를 이미지를 2D 형광 및 사진 매개 변수를 선택 합니다. 설정 자동 으로 노출과에 여기/방출 파장 710/820 nm.</li>
		<li>이미징 절차의 끝에, 마 취, 막으려고 isoflurane 유입 해제 하 고 신중 하 게 그들의 감 금 소를 임신 쥐를 반환.</li>
		<li>나노 사출 후 48 h anesthetize isofluorane와 임신 쥐 그리고 자 궁 탈 댐 희생. 태아와 반응과 Graefe 집게, Graefe 조직 집게를 사용 하 고 해 부가 위를 수집 합니다.</li>
		<li>반응과 태아 이미징 실과 단계 2.3.4에서에서 설명 하는 방법을 사용 하 여 이미지에 놓습니다.</li>
	</ol>
</li>
</ol>3. HFUS 배아 발달의 평가
<ol><li>
동물 모델
	<ol>
<li>얻기 및 단계 2.1에에서 설명 된 대로 임신 쥐를 준비.</li>
		<li>HFUS를 사용 하 여 E 6.5 (3.2 및 3.3.3 프로토콜)에서 이미지 임신 쥐. 첫째, 하루 E6.5에 배아를 시각화 하 여 임신을 확인 하 고 다음 세 그룹으로 임신 쥐를 무작위로 할당: MNP 그룹, plCSA MNP 그룹 및 인산 염 버퍼 식 염 수 (PBS) 그룹.</li>
		<li>주사 PBS, MNPs 또는 plCSA-MNPs (1 mg/kg MTX 상응) 임신 쥐의 꼬리 정 맥으로 매일 2.2 단계에서 설명한 대로 E6.5에서 시작.</li>
	</ol>
</li>
	<li>
이미징에 대 한 준비
	<ol>
<li>나노 입자, 주사 후 24 h 이미지 이미징 시스템 HFUS를 사용 하 여 임신 쥐.</li>
		<li>2.3.2 단계에서 설명한 대로 임신 쥐를 anesthetize. 이미징 플랫폼의 통합된 온도 제어를 켜고, 37-42 ° c 플랫폼을 예 열 테이프를 사용 하 여 플랫폼에 부정사 위치에 임신 쥐를 보호 합니다.</li>
		<li>장소 코 콘 주 둥이 통해 마 취 단위에 연결. 1.0 L/min 꾸준한 마 취를 유지 하는 산소 유량과 2 %isoflurane 적용 됩니다.</li>
		<li>화학적 depilatory 크림을 사용 하 여 복 부에서 머리를 제거 합니다. 물에 젖은 거 즈로 깨끗이 잔여 크림을 닦 고 젤 커플링 음향 복 코트.</li>
	</ol>
</li>
	<li>
영상 절차
	<ol>
<li>기계 팔에서 40 MHz 변환기를 놓습니다.</li>
		<li>초점 영역에서 관심 영역으로 태아와 태 반에의 경도 이미지를 변환기 위치를 조정 합니다.</li>
		<li>
B 모드 영상과 분석 참고: 영화 1<ol>
<li>B 모드 버튼을 클릭 하 고 태아와 태 반 보기에 올 때까지 복 부에 변환기를 낮은. 시작/정지 영상, 씨 네 저장 을 누릅니다을 씨 네 루프 저장 프레임 저장 프레임 이미지를 저장 하 게 스캔/동결 을 누릅니다.</li>
			<li>임신 성 골목 길이 (GS), 태아 크라운 둔 부 길이 (CRL), biparietal 직경 (BPD), 복 부 둘레 (AC), placental 직경 (PD)와 태 반 두께 (PT) 분석 측정 버튼을 클릭 합니다.</li>
		</ol>
</li>
		<li>
PW 도플러 영상 및 분석 참고: 영화 1<ol>
<li>동일을 사용 하 여 프로젝션 스캔, 비밀 번호 버튼을 클릭, 샘플링 볼륨 상자 탯 줄 동맥의 중심에 놓고 스캔/동결 이미징 시작을 누릅니다. 탯 줄 동맥 이미지 수집 하 씨 네 저장 을 클릭 합니다.</li>
			<li>탯 줄 동맥 피크 속도 (UA)를 계산 하기 위해 측정 버튼을 클릭 합니다.</li>
		</ol>
</li>
		<li>
색 도플러 모드 영상 및 분석
		<ol>
<li>동일을 사용 하 여 프로젝션 스캔 컬러 버튼을 클릭을 태아 심장의 이미지를 변환기 위치를 조정. 스캔/동결 이미징 및 씨 네 이미지 수집 저장 시작을 누릅니다.</li>
			<li>태아의 심장 박동 (인사)을 계산 하려면 측정값 단추를 클릭 합니다.</li>
		</ol>
</li>
	</ol>
</li>
</ol>4. HPLC 분석
<ol><li>
조직 준비
	<ol>
<li>늦은 임신에서 MNPs 또는 plCSA-MNPs (1 mg/kg MTX 동등 물)의 단 하나의 복용량을 임신 쥐를 주입 (예., E14.5) 단계 3.1.3에서에서 설명한 대로.</li>
		<li>24 시간 후 240 μ g/몸 무게 (g)에서 avertin의 복 주사 하 여 쥐를 anesthetize. 생쥐는 완전히 마 취 확인 하 발 핀치에 응답을 확인 합니다.</li>
		<li>스프레이 75% 에탄올과 가슴 지역입니다. 심장 관류 (잘라 오른쪽 심 방 및 좌 심 실을 통해 perfuse) 수행 세부19,20 언바운드 나노 입자를 제거 하는 10 분 동안 차가운 0.9% 염 분의 50 mL에에서 앞에서 설명한.</li>
		<li>댐 안락사 태아와 반응과 Graefe 집게가 위, 그리고 Graefe 조직 겸 자, 해 부를 사용 하 여 수집 하 제왕 섹션을 수행 하 고 조직 분석 전에-80 ° C에서 저장 합니다.</li>
		<li>균질 솔루션 (10%과 염소 산)을 준비 하 고 얼음에 계속. 조직의 약 200 mg을 수집 하 고 각 샘플을 균질 솔루션의 500 μ를 추가. 균질 샘플 30 s, 그리고 반복에 대 한 최고 속도 균질 화기를 사용 하 여이 절차를 두 번.</li>
		<li>4 ° c.에 20 분 14000 × g에서 샘플을 원심 HPLC 유리병에 결과 액체를 전송 및 필터 주사기 0.45 μ m 통해 상쾌한 (약 300 μ)을 필터링 합니다. 샘플 튜브를 주입 autosampler 트레이 넣으십시오.</li>
	</ol>
</li>
	<li>
표준의 준비
	<ol>
<li>다음 솔루션 모바일 단계에 대 한 준비: 40 mM 칼륨 인산 염기 (pH 4.5)와 이기 (88:12, v/v). 0.45 μ m 기 공 크기 주사기 필터를 통해 솔루션을 필터링 하 고 깨끗 한 HPLC 저수지 병 결과 액체를 전송. 참고: 0.1 M 인산으로 pH를 조정 합니다. 15 분에 대 한 초음파 진동을 사용 하 여 사용 하는 모바일 단계 때마다 이전 드.</li>
		<li>1.5 mL 원심 분리기 관으로 MTX의 10 밀리 그램 무게. 1 M 수산화 나트륨의 1 mL를 추가 합니다.</li>
		<li>소용돌이 MTX까지 고속에서 완전히 녹 인 다. 참고:이 기본 주식 이며 몇 달 동안-20 ° C에 저장 될 수 있습니다.</li>
		<li>보조 MTX 주식 (500 μ g/mL)를 만들려면 50 μ 모바일 단계의 950 μ에 기본 주식의 희석. 참고: 사용까지 얼음에 저장 하 고 매일 신선한 준비. 사용 하 여 모바일 단계 표준의 준비에 대 한 샘플 주입 후 서로 다른 솔루션을 혼합의 결과로 봉우리를 피하기 위해 중요 하다.</li>
		<li>(표 1) 표준을 만들고 희석 추가 확인 합니다. 얼음에 기준을 저장 하 고 매일 신선한 준비. 표준 직렬 실험 샘플으로 실행 합니다.</li>
	</ol>
</li>
</ol><table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always"><tbody>
<tr>
<td>번호</td>
			<td>최종 농도 (μ g/mL)</td>
			<td>500 μ g/mL, μ</td>
			<td>모바일 phase(μL)</td>
		</tr>
<tr>
<td>1</td>
			<td>0.5</td>
			<td>1</td>
			<td>999</td>
		</tr>
<tr>
<td>2</td>
			<td>1</td>
			<td>2</td>
			<td>998</td>
		</tr>
<tr>
<td>3</td>
			<td>2.5</td>
			<td>5</td>
			<td>995</td>
		</tr>
<tr>
<td>4</td>
			<td>10</td>
			<td>20</td>
			<td>980</td>
		</tr>
<tr>
<td>5</td>
			<td>25</td>
			<td>50</td>
			<td>950</td>
		</tr>
<tr>
<td>6</td>
			<td>50</td>
			<td>100</td>
			<td>900</td>
		</tr>
<tr>
<td>7</td>
			<td>100</td>
			<td>200</td>
			<td>800</td>
		</tr>
</tbody></table>표 1입니다. 표준 곡선의 MTX에 대 한 준비. MTX 표준 솔루션의 최종 농도 0.5-100에서 μ g/mL.
<ol start="3"><li>
HPLC 계측 및 작업 매개 변수 참고: 샘플 용 펌프, UV spectrophotometric 검출기를 장착 하는 HPLC 시스템에 분석 되었다 (313 nm), 및 C18 열 (250 × 4.6 m m, 5 μ m 입자 크기).<ol>
<li>시스템에서 공기를 제거 하는 HPLC degasser를 켭니다. 초기 소음을 줄이기 위해 30 분 모바일 단계와 열 평형 흐름을 켭니다.</li>
		<li>열의 온도 25 ° C를 설정 하 고 1 mL/min의 유량에 20 μ 샘플 볼륨을 주입 실행 방법 분석 시작을 클릭 합니다.</li>
		<li>실행 완료 되 면 수동으로 HPLC 급 이기에 모바일 단계를 변경 합니다. 시스템을 보호 하기 위해 약 15 분 동안 실행 합니다. 참고: 권장된 실행 시간을 다음이 단계를 수행 하려면 실패 손상에서 열 될 수 있습니다.</li>
		<li>정량 분석을 위한 HPLC 시스템 소프트웨어를 사용 하 여 관심사의 표준 MTX 봉우리 아래 영역을 계산 합니다.</li>
	</ol>
</li>
</ol>

<ol>
	<li>Rodger, M. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Association+of+Factor+V+Leiden+and+Prothrombin+Gene+Mutation+and+Placenta-Mediated+Pregnancy+Complications:+A+Systematic+Review+and+Meta-analysis+of+Prospective+Cohort+Studies.">The Association of Factor V Leiden and Prothrombin Gene Mutation and Placenta-Mediated Pregnancy Complications: A Systematic Review and Meta-analysis of Prospective Cohort Studies.</a> PLOS Medicine. 7 (6), e1000292 (2010).</li><li>Rodger, M. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inherited+thrombophilia+and+pregnancy+complications+revisited.">Inherited thrombophilia and pregnancy complications revisited.</a> Obstetrics &amp; Gynecology. 112 (2 Pt 1), 320-324 (2008).</li><li>Brenner, B., Aharon, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Thrombophilia+and+adverse+pregnancy+outcome.">Thrombophilia and adverse pregnancy outcome.</a> Clinics in Perinatology. 34 (4), 527-541 (2007).</li><li>Fisk, N. M., McKee, M., Atun, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Relative+and+absolute+addressability+of+global+disease+burden+in+maternal+and+perinatal+health+by+investment+in+R&amp;D.">Relative and absolute addressability of global disease burden in maternal and perinatal health by investment in R&amp;D.</a> Tropical Medicine &amp; International Health. 16 (6), 662-668 (2011).</li><li>Fisk, N. M., Atun, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Market+failure+and+the+poverty+of+new+drugs+in+maternal+health.">Market failure and the poverty of new drugs in maternal health.</a> PLOS Medicine. 5 (1), e22 (2008).</li><li>Kaitu'u-Lino, T. u. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Targeted+nanoparticle+delivery+of+doxorubicin+into+placental+tissues+to+treat+ectopic+pregnancies.">Targeted nanoparticle delivery of doxorubicin into placental tissues to treat ectopic pregnancies.</a> Endocrinology. 154 (2), 911-919 (2013).</li><li>King, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tumor-homing+peptides+as+tools+for+targeted+delivery+of+payloads+to+the+placenta.">Tumor-homing peptides as tools for targeted delivery of payloads to the placenta.</a> Science Advances. 2 (5), e1600349 (2016).</li><li>Beards, F., Jones, L. E., Charnock, J., Forbes, K., Harris, L. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Placental+Homing+Peptide-microRNA+Inhibitor+Conjugates+for+Targeted+Enhancement+of+Intrinsic+Placental+Growth+Signaling.">Placental Homing Peptide-microRNA Inhibitor Conjugates for Targeted Enhancement of Intrinsic Placental Growth Signaling.</a> Theranostics. 7 (11), 2940-2955 (2017).</li><li>Cureton, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Selective+Targeting+of+a+Novel+Vasodilator+to+the+Uterine+Vasculature+to+Treat+Impaired+Uteroplacental+Perfusion+in+Pregnancy.">Selective Targeting of a Novel Vasodilator to the Uterine Vasculature to Treat Impaired Uteroplacental Perfusion in Pregnancy.</a> Theranostics. 7 (15), 3715-3731 (2017).</li><li>Paul, J. W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Drug+delivery+to+the+human+and+mouse+uterus+using+immunoliposomes+targeted+to+the+oxytocin+receptor.">Drug delivery to the human and mouse uterus using immunoliposomes targeted to the oxytocin receptor.</a> American Journal of Obstetrics and Gynecology. 216 (3), e281-e283 (2017).</li><li>Zhang, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Placenta-specific+drug+delivery+by+trophoblast-targeted+nanoparticles+in+mice.">Placenta-specific drug delivery by trophoblast-targeted nanoparticles in mice.</a> Theranostics. 8 (10), 2765-2781 (2018).</li><li>Fan, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Noninvasive+monitoring+of+placenta-specific+transgene+expression+by+bioluminescence+imaging.">Noninvasive monitoring of placenta-specific transgene expression by bioluminescence imaging.</a> PloS One. 6 (1), e16348 (2011).</li><li>Murata, M., Tahara, K., Takeuchi, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+in+vivo+imaging+of+surface-modified+liposomes+to+evaluate+their+behavior+after+pulmonary+administration.">Real-time in vivo imaging of surface-modified liposomes to evaluate their behavior after pulmonary administration.</a> European Journal of Pharmaceutics and Biopharmaceutics. 86 (1), 115-119 (2014).</li><li>Ito, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=New+whole-body+multimodality+imaging+of+gastric+cancer+peritoneal+metastasis+combining+fluorescence+imaging+with+ICG-labeled+antibody+and+MRI+in+mice.">New whole-body multimodality imaging of gastric cancer peritoneal metastasis combining fluorescence imaging with ICG-labeled antibody and MRI in mice.</a> Gastric Cancer. 17 (3), 497-507 (2014).</li><li>Mazza, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liposome-Indocyanine+Green+Nanoprobes+for+Optical+Labeling+and+Tracking+of+Human+Mesenchymal+Stem+Cells+Post-Transplantation+In+Vivo.">Liposome-Indocyanine Green Nanoprobes for Optical Labeling and Tracking of Human Mesenchymal Stem Cells Post-Transplantation In Vivo.</a> Advanced Healthcare Materials. 6 (21), (2017).</li><li>Greco, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High+frequency+ultrasound+for+in+vivo+pregnancy+diagnosis+and+staging+of+placental+and+fetal+development+in+mice.">High frequency ultrasound for in vivo pregnancy diagnosis and staging of placental and fetal development in mice.</a> PloS One. 8 (10), e77205 (2013).</li><li>Spurney, C. F., Leatherbury, L., Lo, C. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-frequency+ultrasound+database+profiling+growth,+development,+and+cardiovascular+function+in+C57BL/6J+mouse+fetuses.">High-frequency ultrasound database profiling growth, development, and cardiovascular function in C57BL/6J mouse fetuses.</a> Journal of the American Society of Echocardiography. 17 (8), 893-900 (2004).</li><li>Zhang, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Synthesis+and+characterization+of+placental+chondroitin+sulfate+A+(plCSA)+-targeting+lipid-polymer+nanoparticles.">Synthesis and characterization of placental chondroitin sulfate A (plCSA) -targeting lipid-polymer nanoparticles.</a> Journal of Visualized Experiments. , (2018).</li><li>Devraj, K., Guerit, S., Macas, J., Reiss, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=An+In+Vivo+Blood-brain+Barrier+Permeability+Assay+in+Mice+Using+Fluorescently+Labeled+Tracers.">An In Vivo Blood-brain Barrier Permeability Assay in Mice Using Fluorescently Labeled Tracers.</a> Journal of Visualized Experiments. (132), (2018).</li><li>Beeton, C., Chandy, K. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isolation+of+mononuclear+cells+from+the+central+nervous+system+of+rats+with+EAE.">Isolation of mononuclear cells from the central nervous system of rats with EAE.</a> Journal of Visualized Experiments. (10), 527 (2007).</li><li>Watson, E. D., Cross, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+structures+and+transport+functions+in+the+mouse+placenta.">Development of structures and transport functions in the mouse placenta.</a> Physiology. 20 (3), 180-193 (2005).</li><li>Frangioni, J. V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+near-infrared+fluorescence+imaging.">In vivo near-infrared fluorescence imaging.</a> Current Opinion in Chemical Biology. 7 (5), 626-634 (2003).</li><li>Flores, L. E., Hildebrandt, T. B., Kuhl, A. A., Drews, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Early+detection+and+staging+of+spontaneous+embryo+resorption+by+ultrasound+biomicroscopy+in+murine+pregnancy.">Early detection and staging of spontaneous embryo resorption by ultrasound biomicroscopy in murine pregnancy.</a> Reproductive Biology and Endocrinology. 12, 38 (2014).</li><li>Khankin, E. V., Hacker, M. R., Zelop, C. M., Karumanchi, S. A., Rana, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Intravital+high-frequency+ultrasonography+to+evaluate+cardiovascular+and+uteroplacental+blood+flow+in+mouse+pregnancy.">Intravital high-frequency ultrasonography to evaluate cardiovascular and uteroplacental blood flow in mouse pregnancy.</a> Pregnancy Hypertension. 2 (2), 84-92 (2012).</li><li>Phoon, C. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+tools+for+the+developmental+biologist:+ultrasound+biomicroscopy+of+mouse+embryonic+development.">Imaging tools for the developmental biologist: ultrasound biomicroscopy of mouse embryonic development.</a> Pediatric Research. 60 (1), 14-21 (2006).</li><li>Pallares, P., Gonzalez-Bulnes, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Non-invasive+ultrasonographic+characterization+of+phenotypic+changes+during+embryo+development+in+non-anesthetized+mice+of+different+genotypes.">Non-invasive ultrasonographic characterization of phenotypic changes during embryo development in non-anesthetized mice of different genotypes.</a> Theriogenology. 70 (1), 44-52 (2008).</li><li>Parvani, J. G., Gujrati, M. D., Mack, M. A., Schiemann, W. P., Lu, Z. -. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Silencing+&#946;3+integrin+by+targeted+ECO/siRNA+nanoparticles+inhibits+EMT+and+metastasis+of+triple-negative+breast+cancer.">Silencing &#946;3 integrin by targeted ECO/siRNA nanoparticles inhibits EMT and metastasis of triple-negative breast cancer.</a> Cancer Research. 75 (11), 2316-2325 (2015).</li><li>Zhang, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Targeted+delivery+of+doxorubicin+by+CSA-binding+nanoparticles+for+choriocarcinoma+treatment.">Targeted delivery of doxorubicin by CSA-binding nanoparticles for choriocarcinoma treatment.</a> Drug Delivery. 25 (1), 461-471 (2018).</li><li>Jenkins, D. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioluminescent+imaging+(BLI)+to+improve+and+refine+traditional+murine+models+of+tumor+growth+and+metastasis.">Bioluminescent imaging (BLI) to improve and refine traditional murine models of tumor growth and metastasis.</a> Clinical &amp; Experimental Metastasis. 20 (8), 733-744 (2003).</li><li>Keelan, J. A., Leong, J. W., Ho, D., Iyer, K. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Therapeutic+and+safety+considerations+of+nanoparticle-mediated+drug+delivery+in+pregnancy.">Therapeutic and safety considerations of nanoparticle-mediated drug delivery in pregnancy.</a> Nanomedicine. 10 (14), 2229-2247 (2015).</li></ol>

X.F.와 B.Z.는 민 태 반 관련 약물 전달 방법을 포함 하 여 특허 출원 PCT/CN2017/108646 제출 및 그 응용 프로그램에 대 한 발명가. 다른 모든 저자 들은 아무 경쟁 관심사를 선언 합니다.

이 원고에서 우리 plCSA BP-기반 나노 입자 약물의 태 반 배달 대상에 대 한 효율적인 도구 인지 결정 하기 위한 3-방법 시스템 개요. Vivo에서 이미징 적외선 형광 ICG 신호를 모니터링 하는 데 사용 plCSA BP. 사용의 placental 대상 특이성을 확인 HFUS 및 HPLC, 우리 plCSA BP 활용 된 나노 입자 수에 MTX 제공 효율적으로 시연 합니다 태 반 세포, 태아에 게 하지입니다.
Vivo에서 형...

사전 eclampsia, 임신 손실, placental 속보 및 작은 임신 연령 (SGA)를 포함 하 여 중재 하는 태 반 임신 합병증은 일반적이 고 실질적인 태아와 산 모 병 적 상태와 사망률1,2,에 3, 그리고 거의 약4,5장애 임신 치료에 효과적인 것으로 입증 되었습니다. 임신 중 더 선택적이 고 안전한 태 반 대상 약물 전달에 대 한 전략의 개발 현대 약물 치료에 도전 남아 있습니다.
최근 몇 년 동안, 여러 보고서 태 타겟팅 도구로 펩 티 드 또는 항 체 나노 입자 코팅에 의해 uteroplacental 조직에 약물의 타겟된 배달에 집중 했다. 이러한 안티 표 피 성장 인자 수용 체 (EGFR)6 항 체, 등 종양 유도 펩 티 드 (CGKRK 및 iRGD)7, 태 반 대상 펩 티 드8, placental 맥 관 구조 대상 펩 티 드9 에 대 한 항 체는 옥 시 토 신 수용 체10.
여기, 합성 placental chondroitin 황산 염 A 바인딩 펩 티 드 (plCSA-BP) 태11나노 입자와 그들의 마약 페이로드의 대상된 배달에 사용할 수 있습니다 설명 합니다. PlCSA BP-기반 나노 입자는 placental trophoblast 대상 때문에 메서드를 대상으로 보고 uteroplacental를 보완.
비-침략 적 방법으로 이미징 vivo에서 쥐12, 태 반 관련 유전자 발현을 모니터링 하는 데 사용 되었습니다 그리고 indocyanine 그린 (ICG) 나노 입자 형광 이미징 시스템13를 사용 하 여 추적을 널리 이용 되는 , 1415. 따라서, 우리는 plCSA BP 활용 된 나노 로드 ICG (plCSA-INPs) 형광 이미징 임신 쥐에 plCSA INP 분포를 시각화 하 정 맥 주입. 우리는 다음 정 맥 methotrexate (MTX) 주사-임신 쥐에 plCSA-NPs를 로드. 높은 주파수 초음파 (HFUS), 다른 비-침략 적, 실시간 이미징 도구16,17 쥐에 태아 및 태 반 개발을 모니터링 하는 데 사용 되었다. 마지막으로, 우리 반응과 태아에 MTX 분포를 정량화 고성능 액체 크로마토그래피 (HPLC) 사용.
이 프로토콜에서 우리가 자세히 설명 plCSA 혈압 유도 nanocarriers 태 대상 약물 전달의 효율성을 평가 하는 데 사용 하는 3 방법 시스템.

<table><tbody><tr><td>CD-1 mice</td><td>Beijing Vital River</td><td>201</td><td>Female (8-12 week)</td></tr><tr><td>Insulin syringe</td><td>BD</td><td>328421</td><td>for IV injection</td></tr><tr><td>Ethanol absolute</td><td>Sinopharm Chemical</td><td>10009218</td><td>for nanoparticles synthesis</td></tr><tr><td>Soybean lecithin</td><td>Avanti Polar Lipids</td><td>441601</td><td>for nanoparticles synthesis</td></tr><tr><td>DSPE-PEG-COOH</td><td>Avanti Polar Lipids</td><td>880125</td><td>for nanoparticles synthesis</td></tr><tr><td>PLGA</td><td>Sigma-Aldrich</td><td>719897</td><td>for nanoparticles synthesis</td></tr><tr><td>Ultrasonic processor</td><td>Sonics</td><td>VCX130</td><td>for nanoparticles synthesis</td></tr><tr><td>Methotrexate (MTX)</td><td>Sigma-Aldrich</td><td>V900324</td><td>for nanoparticles synthesis</td></tr><tr><td>Indocyanine green (ICG)</td><td>Sigma-Aldrich</td><td>1340009</td><td>for in vivo imaging</td></tr><tr><td>phosphate-buffered saline (PBS)</td><td>Hyclone</td><td>SH30028.01</td><td></td></tr><tr><td>IVIS spectrum instrument</td><td>Perkin Elmer</td><td></td><td>for in vivo imaging</td></tr><tr><td>Ultrasound transmission gel</td><td>Guanggong</td><td>ZC4252418</td><td>for ultrasound imaging</td></tr><tr><td>Isoflurane</td><td>Lunan Pharmaceutical</td><td>I0040</td><td>for maintain the anesthesia</td></tr><tr><td>Depilatory cream</td><td>Nair</td><td>TMG001</td><td>for removing fur</td></tr><tr><td>40 MHz transducer</td><td>VisualSonics</td><td>MS550S</td><td>for ultrasound imaging</td></tr><tr><td>High-frequency ultrasound imaging system</td><td>VisualSonics</td><td>Vevo2100</td><td>for ultrasound imaging</td></tr><tr><td>Avertin</td><td>Sigma-Aldrich</td><td>T48402</td><td>for anesthesia</td></tr><tr><td>Syringe pump</td><td>Mindray</td><td>SK-500III</td><td>forcardiac perfusion</td></tr><tr><td>0.9% saline solution</td><td>Meilunbio</td><td>MA0083</td><td>forcardiac perfusion</td></tr><tr><td>1.5 mL Polypropylene tubes</td><td>AXYGEN</td><td>MCT-150-C</td><td></td></tr><tr><td>-80 &amp;deg;C freezer</td><td>Thermo Fisher Scientific</td><td>88600V</td><td></td></tr><tr><td>Centriguge</td><td>Cence</td><td>H1650R</td><td></td></tr><tr><td>Perchloric acid</td><td>Sigma-Aldrich</td><td>311421</td><td>for precipitating protein</td></tr><tr><td>Homogenizer</td><td>SCIENTZ</td><td>SCIENTZ-48</td><td>for homogenizing tissue</td></tr><tr><td>Syringe filter (0.45 &amp;mu;m)</td><td>Millipore</td><td>SLHV033RS01</td><td></td></tr><tr><td>Sodium hydroxide</td><td>Sinopharm Chemical</td><td>10019763</td><td>for solving MTX</td></tr><tr><td>HPLC vials</td><td>Waters</td><td>670650620</td><td>for HPLC</td></tr><tr><td>Potassium phosphate dibasic</td><td>Sinopharm Chemical</td><td>20032117</td><td>for HPLC</td></tr><tr><td>Acetonitrile</td><td>JKchemical</td><td>932537</td><td>for HPLC</td></tr><tr><td>C18 column</td><td>Waters</td><td>186003966</td><td>for HPLC</td></tr><tr><td>HPLC system</td><td>Shimadzu</td><td></td><td>for HPLC</td></tr></tbody></table>

comprehensive evaluation of the effectiveness and safety of placenta-targeted drug delivery using three complementary methods

더 효과적인 치료 태 반 관련 임신 합병증에 대 한 현재 존재 하 고 도전 남아 태아와 모성의 부작용을 최소화 하면서 태 반에 약물의 타겟된 배달에 대 한 전략을 개발. 타겟된 나노 캐리어 placental 질환을 치료 하는 새로운 기회를 제공 합니다. 우리는 최근에 합성 placental chondroitin 황산 염 A 바인딩 펩 티 드 (plCSA-BP) 태 반에 약물을 전달 하기 위해 나노 가이드 사용 될 수 보여 주었다. 이 프로토콜에서 설명 자세히 plCSA-혈압 사용 세 별도 메서드를 사용 하 여 태 반에 약물 전달의 효율성을 평가 하기 위한 시스템: vivo에서 이미징, 높은-주파수 초음파 (HFUS), 및 높은 성능 액체 착 색 인쇄기 (HPLC)입니다. Vivo에서 를 사용 하 여 이미징, plCSA BP-기반 나노 했다 시각에 살아있는 동물의 반응과 HFUS 및 HPLC는 plCSA BP 활용 된 나노 효율적이 고 구체적으로 전달 토트 태 반에 시연 하는 동안. 따라서, 이러한 방법의 조합은 태 반에 약물의 타겟된 배달 및 여러 가지 임신 합병증에 대 한 새로운 치료 전략의 개발을 위한 효과적인 도구로 사용할 수 있습니다.

이 원고, plCSA BP 활용 된 나노 로드 MTX (plCSA-MNPs) 또는 ICG (plCSA-INPs) 했다 임신 쥐에 정 맥 주입 됩니다. Vivo에서 영상 plCSA INP 주입 후 자 궁 30 분의 지역에서 강한 ICG 신호를 밝혔다. INPs 했다 주로 간, 비장 지역 (그림 1A) 지역화 됩니다. PlCSA-INP 주사 후 48 h, 임신 쥐 ICG 신호 없는 신호와 태 반에만 태아 (그림 1B)에 감지 했다 ?...

Watch this Scientific Journal Video about Comprehensive Evaluation of the Effectiveness and Safety of Placenta-Targeted Drug Delivery Using Three Complementary Methods at JoVE.com

Comprehensive Evaluation of the Effectiveness and Safety of Placenta-Targeted Drug Delivery Using Three Complementary Methods

우리는 안전 및 태 반 대상 약물 전달의 효과 평가 하기 위해 세 가지 방법을 사용 하는 시스템을 설명: vivo에서 이미징 나노 축적, 태 반 및 태아 개발을 모니터링 하 고 주파수 초음파를 모니터링 하 그리고 조직에 약물 전달 척도를 HPLC.

3 보완 방법을 사용 하 여 태 반 대상 약물 전달의 안전과 효율성의 종합 평가
