pPV540 and pPV402 were kind gifts from Dr. James Lok at the University of Pennsylvania. We thank Astra Bryant for helpful comments on the manuscript. This work was funded by a Burroughs-Wellcome Fund Investigators in the Pathogenesis of Disease Award, a Howard Hughes Medical Institute Faculty Scholar Award, and National Institutes of Health R01 DC017959 (E.A.H.).

NOTE: Gerbils were used to passage S.&#160;stercoralis, and rats were used to passage S.&#160;ratti. All procedures were approved by the UCLA Office of Animal Research Oversight (Protocol No. 2011-060-21A), which adheres to AAALAC standards and the Guide for the Care and Use of Laboratory Animals. The following tasks must be completed at least one day before microinjecting: worm culturing, preparing microinjection pads, creating constructs for the microinjection mix, and spreading bacteria (E. coli<...

<ol>
	<li>Krolewiecki, A. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+public+health+response+against+Strongyloides+stercoralis:+time+to+look+at+soil-transmitted+helminthiasis+in+full.">A public health response against Strongyloides stercoralis: time to look at soil-transmitted helminthiasis in full.</a> PLoS Neglected Tropical Diseases. 7 (5), 2165 (2013).</li><li>Buonfrate, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+global+prevalence+of+Strongyloides+stercoralis+infection.">The global prevalence of Strongyloides stercoralis infection.</a> Pathogens. 9 (6), 468 (2020).</li><li>Castelletto, M. L., Gang, S. S., Hallem, E. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recent+advances+in+functional+genomics+for+parasitic+nematodes+of+mammals.">Recent advances in functional genomics for parasitic nematodes of mammals.</a> Journal of Experimental Biology. 223, 206482 (2020).</li><li>Evans, T. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transformation+and+microinjection.">Transformation and microinjection.</a> WormBook. , (2006).</li><li>Lok, J. B., Unnasch, T. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgenesis+in+animal+parasitic+nematodes:+Strongyloides+spp.+and+Brugia+spp.">Transgenesis in animal parasitic nematodes: Strongyloides spp. and Brugia spp.</a> WormBook. , (2013).</li><li>Shao, H. G., Li, X. S., Lok, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Heritable+genetic+transformation+of+Strongyloides+stercoralis+by+microinjection+of+plasmid+DNA+constructs+into+the+male+germline.">Heritable genetic transformation of Strongyloides stercoralis by microinjection of plasmid DNA constructs into the male germline.</a> International Journal for Parasitology. 47 (9), 511-515 (2017).</li><li>Schafer, T. W., Skopic, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Parasites+of+the+small+intestine.">Parasites of the small intestine.</a> Current Gastroenterology Reports. 8 (4), 312-320 (2006).</li><li>Stiernagle, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Maintenance+of+C.+elegans.">Maintenance of C. elegans.</a> The C. elegans Research Community, WormBook. , (2006).</li><li>Gang, S. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Targeted+mutagenesis+in+a+human-parasitic+nematode.">Targeted mutagenesis in a human-parasitic nematode.</a> PLoS Pathogens. 13 (10), 1006675 (2017).</li><li>Lok, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Strongyloides+stercoralis:+a+model+for+translational+research+on+parasitic+nematode+biology.">Strongyloides stercoralis: a model for translational research on parasitic nematode biology.</a> The C. elegans Research Community, WormBook. , (2007).</li><li>Hawdon, J. M., Schad, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Long-term+storage+of+hookworm+infective+larvae+in+buffered+saline+solution+maintains+larval+responsiveness+to+host+signals.">Long-term storage of hookworm infective larvae in buffered saline solution maintains larval responsiveness to host signals.</a> Proceedings of the Helminthological Society of Washington (USA). 58 (1), 140-142 (1991).</li><li>Bargmann, C. I., Hartwieg, E., Horvitz, H. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Odorant-selective+genes+and+neurons+mediate+olfaction+in+C.+elegans.">Odorant-selective genes and neurons mediate olfaction in C. elegans.</a> Cell. 74 (3), 515-527 (1993).</li><li>Junio, A. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Strongyloides+stercoralis:+cell-+and+tissue-specific+transgene+expression+and+co-transformation+with+vector+constructs+incorporating+a+common+multifunctional+3'+UTR.">Strongyloides stercoralis: cell- and tissue-specific transgene expression and co-transformation with vector constructs incorporating a common multifunctional 3' UTR.</a> Experimental Parasitology. 118 (2), 253-265 (2008).</li><li>Gang, S. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chemosensory+mechanisms+of+host+seeking+and+infectivity+in+skin-penetrating+nematodes.">Chemosensory mechanisms of host seeking and infectivity in skin-penetrating nematodes.</a> Proceedings of the National Academy of Sciences of the United States of America. 117 (30), 17913-17923 (2020).</li><li>Bryant, A. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+critical+role+for+thermosensation+in+host+seeking+by+skin-penetrating+nematodes.">A critical role for thermosensation in host seeking by skin-penetrating nematodes.</a> Current Biology. 28 (14), 2338-2347 (2018).</li><li>Lok, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nucleic+acid+transfection+and+transgenesis+in+parasitic+nematodes.">Nucleic acid transfection and transgenesis in parasitic nematodes.</a> Parasitology. 139 (5), 574-588 (2012).</li><li>Shao, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transposon-mediated+chromosomal+integration+of+transgenes+in+the+parasitic+nematode+Strongyloides+ratti+and+establishment+of+stable+transgenic+lines.">Transposon-mediated chromosomal integration of transgenes in the parasitic nematode Strongyloides ratti and establishment of stable transgenic lines.</a> PLoS Pathogens. 8 (8), 1002871 (2012).</li><li>Lok, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=piggyBac:+a+vehicle+for+integrative+DNA+transformation+of+parasitic+nematodes.">piggyBac: a vehicle for integrative DNA transformation of parasitic nematodes.</a> Mobile Genetic Elements. 3 (2), 24417 (2013).</li><li>Li, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Successful+transgenesis+of+the+parasitic+nematode+Strongyloides+stercoralis+requires+endogenous+non-coding+control+elements.">Successful transgenesis of the parasitic nematode Strongyloides stercoralis requires endogenous non-coding control elements.</a> International Journal for Parasitology. 36 (6), 671-679 (2006).</li><li>Bryant, A. S., Hallem, E. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Wild+Worm+Codon+Adapter:+a+web+tool+for+automated+codon+adaptation+of+transgenes+for+expression+in+non-Caenorhabditis+nematodes.">The Wild Worm Codon Adapter: a web tool for automated codon adaptation of transgenes for expression in non-Caenorhabditis nematodes.</a> G3. 3 (7), (2021).</li><li>Crane, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+vivo+measurements+reveal+a+single+5'-intron+is+sufficient+to+increase+protein+expression+level+in+Caenorhabditis+elegans.">In vivo measurements reveal a single 5'-intron is sufficient to increase protein expression level in Caenorhabditis elegans.</a> Scientific Reports. 9 (1), 9192 (2019).</li><li>Han, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Improving+transgenesis+efficiency+and+CRISPR-associated+tools+through+codon+optimization+and+native+intron+addition+in+Pristionchus+nematodes.">Improving transgenesis efficiency and CRISPR-associated tools through codon optimization and native intron addition in Pristionchus nematodes.</a> Genetics. 216 (4), 947-956 (2020).</li><li>Adams, S., Pathak, P., Shao, H., Lok, J. B., Pires-daSilva, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Liposome-based+transfection+enhances+RNAi+and+CRISPR-mediated+mutagenesis+in+non-model+nematode+systems.">Liposome-based transfection enhances RNAi and CRISPR-mediated mutagenesis in non-model nematode systems.</a> Scientific Reports. 9 (1), 483 (2019).</li><li>Dulovic, A., Puller, V., Streit, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimizing+culture+conditions+for+free-living+stages+of+the+nematode+parasite+Strongyloides+ratti.">Optimizing culture conditions for free-living stages of the nematode parasite Strongyloides ratti.</a> Experimental Parasitology. 168, 25-30 (2016).</li><li>Harvey, S. C., Gemmill, A. W., Read, A. F., Viney, M. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+control+of+morph+development+in+the+parasitic+nematode+Strongyloides+ratti.">The control of morph development in the parasitic nematode Strongyloides ratti.</a> Proceedings of the Royal Society B: Biological Sciences. 267 (1457), 2057-2063 (2000).</li><li>Kim, A., Pyykko, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Size+matters:+versatile+use+of+PiggyBac+transposons+as+a+genetic+manipulation+tool.">Size matters: versatile use of PiggyBac transposons as a genetic manipulation tool.</a> Molecular and Cellular Biochemistry. 354 (1-2), 301-309 (2011).</li><li>Lok, J. B., Shao, H., Massey, H. C., Li, X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgenesis+in+Strongyloides+and+related+parasitic+nematodes:+historical+perspectives,+current+functional+genomic+applications+and+progress+towards+gene+disruption+and+editing.">Transgenesis in Strongyloides and related parasitic nematodes: historical perspectives, current functional genomic applications and progress towards gene disruption and editing.</a> Parasitology. 144 (3), 327-342 (2017).</li><li>Farboud, B., Meyer, B. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dramatic+enhancement+of+genome+editing+by+CRISPR/Cas9+through+improved+guide+RNA+design.">Dramatic enhancement of genome editing by CRISPR/Cas9 through improved guide RNA design.</a> Genetics. 199 (4), 959-971 (2015).</li><li>Cheong, M. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Identification+of+a+nuclear+receptor/coactivator+developmental+signaling+pathway+in+the+nematode+parasite+Strongyloides+stercoralis.">Identification of a nuclear receptor/coactivator developmental signaling pathway in the nematode parasite Strongyloides stercoralis.</a> Proceedings of the National Academy of Sciences of the United States of America. 118 (8), 2021864118 (2021).</li><li>Nolan, T. J., Megyeri, Z., Bhopale, V. M., Schad, G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Strongyloides+stercoralis:+the+first+rodent+model+for+uncomplicated+and+hyperinfective+strongyloidiasis,+the+Mongolian+gerbil+(Meriones+unguiculatus).">Strongyloides stercoralis: the first rodent model for uncomplicated and hyperinfective strongyloidiasis, the Mongolian gerbil (Meriones unguiculatus).</a> Journal of Infectious Diseases. 168 (6), 1479-1484 (1993).</li><li>Li, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgenesis+in+the+parasitic+nematode+Strongyloides+ratti.">Transgenesis in the parasitic nematode Strongyloides ratti.</a> Molecular and Biochemical Parasitology. 179 (2), 114-119 (2011).</li><li>Viney, M. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Exploiting+the+life+cycle+of+Strongyloides+ratti.">Exploiting the life cycle of Strongyloides ratti.</a> Parasitology Today. 15 (6), 231-235 (1999).</li><li>Stoltzfus, J. D., Massey, H. C., Nolan, T. J., Griffith, S. D., Lok, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Strongyloides+stercoralis+age-1:+a+potential+regulator+of+infective+larval+development+in+a+parasitic+nematode.">Strongyloides stercoralis age-1: a potential regulator of infective larval development in a parasitic nematode.</a> PLoS ONE. 7 (6), 38587 (2012).</li><li>Castelletto, M. L., Massey, H. C., Lok, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Morphogenesis+of+Strongyloides+stercoralis+infective+larvae+requires+the+DAF-16+ortholog+FKTF-1.">Morphogenesis of Strongyloides stercoralis infective larvae requires the DAF-16 ortholog FKTF-1.</a> PLoS Pathogens. 5 (4), 1000370 (2009).</li><li>Douglas, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transgenic+expression+of+a+T+cell+epitope+in+Strongyloides+ratti+reveals+that+helminth-specific+CD4++T+cells+constitute+both+Th2+and+Treg+populations.">Transgenic expression of a T cell epitope in Strongyloides ratti reveals that helminth-specific CD4+ T cells constitute both Th2 and Treg populations.</a> PLoS Pathogens. 17 (7), 1009709 (2021).</li></ol>

The authors declare no conflicts of interest.

This microinjection protocol details the methods for introducing constructs for transgenesis and CRISPR/Cas9-mediated mutagenesis into S.&#160;stercoralis and S.&#160;ratti. For both S.&#160;stercoralis and S.&#160;ratti, post-injection survival and the rate of transgenesis or mutagenesis are subject to several variables that can be fine-tuned.
The first critical consideration for successful transgenesis is how plasmid transgenes are constructed. Previous st...

Strongyloides stercoralis has long been overlooked as an important human pathogen compared to the more widely recognized hookworms and the roundworm Ascaris lumbricoides1. Previous studies of worm burden often severely underestimated the prevalence of S.&#160;stercoralis due to the low sensitivity of common diagnostic methods for S.&#160;stercoralis2. In recent years, epidemiological studies based on improved diagnostic tools have estimated that the true prevalence of S.&#160;stercoralis infections is much higher than previously reported, approximately 610 million people worldwide2.
Both S.&#160;stercoralis and other Strongyloides species, including the closely related rat parasite and common lab model S.&#160;ratti, have an unusual life cycle that is advantageous for experimental genomic studies because it consists of both parasitic and free-living (environmental) generations3 (Figure 1). Specifically, both S.&#160;stercoralis and S.&#160;ratti can cycle through a single free-living generation. The free-living generation consists of post-parasitic larvae that develop into free-living adult males and females; all progeny of the free-living adults develop into infective larvae, which must infect a host to continue the life cycle. Furthermore, this environmental or free-living generation can be experimentally manipulated in the laboratory. Because free-living Strongyloides adults and C. elegans adults share similar morphology, techniques such as intragonadal microinjection that were originally developed for C. elegans can be adapted for use with free-living adult Strongyloides4,5. While DNA is generally introduced into free-living adult females, both males and females of Strongyloides can be microinjected6. Thus, functional genomic tools are available to interrogate many aspects of the biology of Strongyloides. Other parasitic nematodes lack a free-living generation, and as a result, are not as readily amenable to functional genomic techniques3.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/63023/63023fig01.jpg" />
Figure 1: The Strongyloides stercoralis life cycle. The S.&#160;stercoralis parasitic females inhabit the small intestine of their mammalian hosts (humans, non-human primates, dogs). The parasitic females reproduce by parthenogenesis and lay eggs within the small intestine. The eggs hatch while still inside the host into post-parasitic larvae, which are then passed into the environment with feces. If the post-parasitic larvae are male, they develop into free-living adult males. If the post-parasitic larvae are female, they can either develop into free-living adult females (indirect development) or third-stage infective larvae (iL3s; direct development). The free-living males and females reproduce sexually to create progeny that are constrained to become iL3s. Under certain conditions, S.&#160;stercoralis can also undergo autoinfection, in which some of the post-parasitic larvae remain inside the host intestine rather than passing into the environment in feces. These larvae can develop into autoinfective larvae (L3a) inside the host, penetrate through the intestinal wall, migrate through the body, and eventually return to the intestine to become reproductive adults. The life cycle of S.&#160;ratti is similar, except that S.&#160;ratti infects rats and does not have an autoinfective cycle. The environmental generation is key to using Strongyloides species for genetic studies. The free-living adult females (P0) can be microinjected; their progeny, which will all become iL3s, are the potential F1 transgenics. This figure has been modified from Castelletto et al.3. <a href="https://www.jove.com/files/ftp_upload/63023/63023fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
S.&#160;stercoralis shares many aspects of its biology with other gastrointestinal human-parasitic nematodes, including host invasion and host immune modulation. For example, human-parasitic hookworms in the genera Necator and Ancylostoma also infect by skin penetration, navigate similarly through the body, and ultimately reside as parasitic adults in the small intestine7. Thus, many gastrointestinal nematodes likely use common sensory behaviors and immune evasion techniques. As a result, the knowledge gleaned from Strongyloides will complement findings in other less genetically tractable nematodes and lead to a more complete understanding of these complex and important parasites.
This microinjection protocol outlines the method for introducing DNA into Strongyloides free-living adult females to make transgenic and mutant progeny. The strain maintenance requirements, including the developmental timing of adult worms for microinjections and the collection of transgenic progeny, are described. Protocols and a demonstration of the complete microinjection technique, along with protocols for culturing and screening transgenic progeny, are included, along with a list of all necessary equipment and consumables.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>(&#8722;)-Nicotine, &#8805;99% (GC), liquid</td>
			<td>Sigma-Aldrich</td>
			<td>N3876-5ML</td>
			<td>nicotine for paralyzing worms</td>
		</tr>
		<tr>
			<td>3&#34; iron C-clamp, 3&#34; x 2&#34; (capacity x depth)</td>
			<td>VWR</td>
			<td>470121-790</td>
			<td>C-clamp to secure setup to bench top</td>
		</tr>
		<tr>
			<td>Agarose LE</td>
			<td>Phenix</td>
			<td>RBA-500</td>
			<td>agarose for slides</td>
		</tr>
		<tr>
			<td>Bone char, 4 lb pail, 10 x 28 mesh</td>
			<td>Ebonex</td>
			<td>n/a</td>
			<td>charcoal for fecal-charcoal cultures</td>
		</tr>
		<tr>
			<td>Bone char, granules, 10 x 28 mesh</td>
			<td>Reade</td>
			<td>bonechar10x28</td>
			<td>charcoal for fecal-cultures (alternative to the above)</td>
		</tr>
		<tr>
			<td>Coarse micromanipulator</td>
			<td>Narishige</td>
			<td>MMN-1</td>
			<td>coarse micromanipulator</td>
		</tr>
		<tr>
			<td>Corning Costar Spin-X centrifuge tube filters</td>
			<td>Fisher</td>
			<td>07-200-385</td>
			<td>microfilter column</td>
		</tr>
		<tr>
			<td>Cover glass, 48 x 60 mm, No. 1 thickness</td>
			<td>Brain Research Lab</td>
			<td>4860-1</td>
			<td>coverslips (48 x 60 mm)</td>
		</tr>
		<tr>
			<td>Deep Petri dishes, heavy version with 6 vents, 100 mm diameter</td>
			<td>VWR</td>
			<td>82050-918</td>
			<td>10 cm Petri dishes (for fecal-charcoal cultures)</td>
		</tr>
		<tr>
			<td>Eisco retort base w/ rod</td>
			<td>Fisher</td>
			<td>12-000-101</td>
			<td>stand for Baermann apparatus</td>
		</tr>
		<tr>
			<td>Eppendorf FemtoJet microinjector microloader tips</td>
			<td>VWR</td>
			<td>89009-310</td>
			<td>for filling microinjection needles</td>
		</tr>
		<tr>
			<td>Fisherbrand absorbent underpads</td>
			<td>Fisher</td>
			<td>14-206-62</td>
			<td>bench paper (for prepping)</td>
		</tr>
		<tr>
			<td>Fisherbrand Cast-Iron Rings</td>
			<td>Fisher</td>
			<td>14-050CQ</td>
			<td>Baermann o-ring</td>
		</tr>
		<tr>
			<td>Fisherbrand tri-cornered polypropylene beakers</td>
			<td>Fisher</td>
			<td>14-955-111F</td>
			<td>Plastic beaker (for mixing)</td>
		</tr>
		<tr>
			<td>Fisherbrand tri-cornered polypropylene beakers</td>
			<td>Fisher</td>
			<td>14-955-111F</td>
			<td>Plastic beaker (for catch bucket/water bucket)</td>
		</tr>
		<tr>
			<td>Fisherbrand tri-cornered polypropylene beakers</td>
			<td>Fisher</td>
			<td>14-955-111F</td>
			<td>Plastic beaker (x2) (to make holder)</td>
		</tr>
		<tr>
			<td>Gorilla epoxie in syringe</td>
			<td>McMaster-Carr</td>
			<td>7541A51</td>
			<td>glue (to attach tubing)</td>
		</tr>
		<tr>
			<td>Halocarbon oil 700</td>
			<td>Sigma-Aldrich</td>
			<td>H8898-50ML</td>
			<td>halocarbon oil</td>
		</tr>
		<tr>
			<td>High-temperature silicone rubber tubing for food and beverage, 1/2&#34; ID, 5/8&#34; OD</td>
			<td>McMaster-Carr</td>
			<td>3038K24</td>
			<td>tubing (for funnel)</td>
		</tr>
		<tr>
			<td>KIMAX funnels, long stem, 60&#176; Angle, Kimble Chase</td>
			<td>VWR</td>
			<td>89001-414</td>
			<td>Baermann funnel</td>
		</tr>
		<tr>
			<td>Kimberly-Clark Professional Kimtech Science benchtop protectors</td>
			<td>Fisher</td>
			<td>15-235-101</td>
			<td>bench paper (for prepping)</td>
		</tr>
		<tr>
			<td>Leica stereomicroscope with fluorescence</td>
			<td>Leica</td>
			<td>M165 FC</td>
			<td>GFP stereomicroscope for identifying and sorting transgenic worms</td>
		</tr>
		<tr>
			<td>microINJECTOR brass straight arm needle-holder</td>
			<td>Tritech</td>
			<td>MINJ-4</td>
			<td>microinjection needle holder</td>
		</tr>
		<tr>
			<td>microINJECTOR system</td>
			<td>Tritech</td>
			<td>MINJ-1</td>
			<td>microinjection system</td>
		</tr>
		<tr>
			<td>Mongolian Gerbils</td>
			<td>Charles River Laboratories</td>
			<td>213-Mongolian Gerbil</td>
			<td>gerbils for maintenance of S. stercoralis, male 4-6 weeks</td>
		</tr>
		<tr>
			<td>Nasco Whirl-Pak easy-to-close bags, 18 oz</td>
			<td>VWR</td>
			<td>11216-776</td>
			<td>Whirl-Pak sample bags</td>
		</tr>
		<tr>
			<td>Nylon tulle (mesh)</td>
			<td>Jo-Ann Fabrics</td>
			<td>zprd_14061949a</td>
			<td>nylon mesh for Baermann holder</td>
		</tr>
		<tr>
			<td>Platinum wire, 36 Gauge, per inch</td>
			<td>Thomas Scientific</td>
			<td>1233S72</td>
			<td>platinum/iridium wire for worm picks</td>
		</tr>
		<tr>
			<td>Puritan tongue depressors, 152 mm (L) x 17.5 mm (W)</td>
			<td>VWR</td>
			<td>62505-007</td>
			<td>wood sticks (for mixing samples)</td>
		</tr>
		<tr>
			<td>QIAprep Spin Miniprep Kit (250)</td>
			<td>QIAGEN</td>
			<td>27106</td>
			<td>QIAGEN miniprep kit</td>
		</tr>
		<tr>
			<td>Rats-Long Evans</td>
			<td>Envigo</td>
			<td>140 HsdBlu:LE Long Evans</td>
			<td>rats for maintenance of S. ratti, female 4-6 weeks</td>
		</tr>
		<tr>
			<td>Rats-Sprague Dawley</td>
			<td>Envigo</td>
			<td>002 Hsd:Sprague Dawley SD</td>
			<td>rats for maintenance of S. ratti, female 4-6 weeks</td>
		</tr>
		<tr>
			<td>Really Useful Boxes translucent storage boxes with lids, 1.6 L capacity, 7-5/8&#34; x 5-5/16&#34; x 4-5/16&#34;</td>
			<td>Office Depot</td>
			<td>452369</td>
			<td>plastic boxes for humidified chamber</td>
		</tr>
		<tr>
			<td>Shepherd techboard, 8 x 16.5 inches</td>
			<td>Newco</td>
			<td>999589</td>
			<td>techboard</td>
		</tr>
		<tr>
			<td>Stainless steel raised wire floor</td>
			<td>Ancare</td>
			<td>R20SSRWF</td>
			<td>wire cage bottoms</td>
		</tr>
		<tr>
			<td>StalkMarket compostable cutlery spoons, 6&#34;, white, pack of 1,000</td>
			<td>Office Depot</td>
			<td>9587303</td>
			<td>spoons</td>
		</tr>
		<tr>
			<td>Stender dish, stacking type, 37 x 25 mm</td>
			<td>Carolina (Science)</td>
			<td>741012</td>
			<td>watch glasses (small, round)</td>
		</tr>
		<tr>
			<td>Stereomicroscope</td>
			<td>Motic</td>
			<td>K-400 LED</td>
			<td>dissecting prep scope</td>
		</tr>
		<tr>
			<td>Storage tote, color clear/white, outside height 4-7/8 in, outside length 13-5/8 in, Sterilite</td>
			<td>Grainger</td>
			<td>53GN16</td>
			<td>plastic boxes for humidified chamber</td>
		</tr>
		<tr>
			<td>Sutter P-30 micropipette puller</td>
			<td>Sutter</td>
			<td>P-30/P</td>
			<td>needle puller with platinum/iridium filament</td>
		</tr>
		<tr>
			<td>Syracuse watch glasses</td>
			<td>Fisher</td>
			<td>S34826</td>
			<td>watch glasses (large, round)</td>
		</tr>
		<tr>
			<td>Thermo Scientific Castaloy fixed-angle clamps</td>
			<td>Fisher</td>
			<td>05-769-2Q</td>
			<td>funnel clamps (2x)</td>
		</tr>
		<tr>
			<td>Three-axis hanging joystick oil hydrolic micromanipulator</td>
			<td>Narishige</td>
			<td>MM0-4</td>
			<td>fine micromanipulator</td>
		</tr>
		<tr>
			<td>United Mohr pinchcock clamps</td>
			<td>Fisher</td>
			<td>S99422</td>
			<td>Pinch clamps (2x)</td>
		</tr>
		<tr>
			<td>Vented, sharp-edge Petri dishes (60 mm diameter)</td>
			<td>Tritech Research</td>
			<td>T3308P</td>
			<td>6 cm Petri dishes (for small-scale fecal-charcoal cultures)</td>
		</tr>
		<tr>
			<td>VWR light-duty tissue wipers</td>
			<td>VWR</td>
			<td>82003-820</td>
			<td>lining for Baermann holder</td>
		</tr>
		<tr>
			<td>watch glass, square, 1-5/8 in</td>
			<td>Carolina (Science)</td>
			<td>742300</td>
			<td>watch glasses (small, square)</td>
		</tr>
		<tr>
			<td>Whatman qualitative grade plain circles, grade 1, 5.5 cm diameter</td>
			<td>Fisher</td>
			<td>09-805B</td>
			<td>filter paper (for 6 cm Petri dishes)</td>
		</tr>
		<tr>
			<td>Whatman qualitative grade plain circles, grade 1, 9 cm diameter</td>
			<td>Fisher</td>
			<td>09-805D</td>
			<td>filter paper (for 10 cm Petri dishes)</td>
		</tr>
		<tr>
			<td>World Precision Instrument borosilicate glass capillary, 1.2 mm x 4 in</td>
			<td>Fisher</td>
			<td>50-821-813</td>
			<td>glass capillaries for microinjection needles</td>
		</tr>
		<tr>
			<td>X-Acto Knives, No. 1 Knife With No. 11 Blade</td>
			<td>Office Depot</td>
			<td>238816</td>
			<td>X-Acto knives without blades to hold worm picks</td>
		</tr>
		<tr>
			<td>Zeiss AxioObserver A1</td>
			<td>Zeiss</td>
			<td>n/a</td>
			<td>inverted microscope</td>
		</tr>
	</tbody>
</table>

generating transgenics and knockouts in strongyloides species by microinjection

The genus Strongyloides consists of multiple species of skin-penetrating nematodes with different host ranges, including Strongyloides stercoralis and Strongyloides ratti. S.&#160;stercoralis is a human-parasitic, skin-penetrating nematode that infects approximately 610 million people, while the rat parasite S.&#160;ratti is closely related to S.&#160;stercoralis and is often used as a laboratory model for S.&#160;stercoralis. Both S.&#160;stercoralis and S.&#160;ratti are easily amenable to the generation of transgenics and knockouts through the exogenous nucleic acid delivery technique of intragonadal microinjection, and as such, have emerged as model systems for other parasitic helminths that are not yet amenable to this technique.
Parasitic Strongyloides adults inhabit the small intestine of their host and release progeny into the environment via the feces. Once in the environment, the larvae develop into free-living adults, which live in feces and produce progeny that must find and invade a new host. This environmental generation is unique to the Strongyloides species and similar enough in morphology to the model free-living nematode Caenorhabditis elegans that techniques developed for C. elegans can be adapted for use with these parasitic nematodes, including intragonadal microinjection. Using intragonadal microinjection, a wide variety of transgenes can be introduced into Strongyloides. CRISPR/Cas9 components can also be microinjected to create mutant Strongyloides larvae. Here, the technique of intragonadal microinjection into Strongyloides, including the preparation of free-living adults, the injection procedure, and the selection of transgenic progeny, is described. Images of transgenic Strongyloides larvae created using CRISPR/Cas9 mutagenesis are included. The aim of this paper is to enable other researchers to use microinjection to create transgenic and mutant Strongyloides.

If the experiment was successful, the F1 larvae will express the transgene and/or mutant phenotype of interest (Figure 4). However, transformation rates are highly variable and depend on the constructs, the health of the worms, the post-injection culturing conditions, and the skill of the experimenter. In general, a successful experiment will yield &#62;15 F1 larvae per injected female and a transformation rate of &#62;3% for fluorescent markers. If the total number of ...

Watch this Scientific Journal Video about Generating Transgenics and Knockouts in Strongyloides Species by Microinjection at JoVE.com

Generating Transgenics and Knockouts in Strongyloides Species by Microinjection

The functional genomic toolkit for the parasitic nematodes Strongyloides stercoralis and Strongyloides ratti includes transgenesis, CRISPR/Cas9-mediated mutagenesis, and RNAi. This protocol will demonstrate how to use intragonadal microinjection to introduce transgenes and CRISPR components into S.&#160;stercoralis and S.&#160;ratti.

Generating Transgenics and Knockouts in Strongyloides Species by Microinjection

The genus Strongyloides consists of multiple species of skin-penetrating nematodes with different host ranges, including Strongyloides stercoralis and ...

Using microinjection to deliver DNA constructs into Strongyloides allows us to generate knockouts and transgenics, which can be used to study how these worms develop, navigate their environment, and parasitize hosts. So far, this is the only successful technique for generating knockouts and transgenics in these parasites. One day before microinjection, add 180 microliters of the agarose solution onto a cover slip using a glass Pasteur pipette, then immediately drop a second cover slip on top to flatten the agarose into a thin pad.After 5 to 10 seconds, remove the top cover slip by sliding the two apart and determine which slide the agar pad is on, and lay it face up. Then, select a tiny piece of glass shard from a broken cover slip, and using forceps, gently press it into the agar near the top edge of the pad. On the day of the microinjection, line the Baermann holder, which is a sieve made from two plastic rings with two layers of nylon tuile netting secured between them with three overlapping pieces of lab tissue.Then add the fecal-charcoal mixture to the Baermann holder. Next place the Baermann holder with the fecal-charcoal mixture in the funnel, fold the pieces of tissues around the fecal-charcoal mix, and add enough water to submerge most of the fecal charcoal. Then, top the funnel with a 15-centimeter plastic Petri dish lid to contain the odor and label the funnel as needed.After one to two hours, hold a 50-milliliter centrifuge tube under the rubber tubing at the bottom of the funnel and carefully open the clamps at the bottom to dispense 30 to 40 milliliters of water containing worms into the 50-milliliter tube.Then. transfer 15 milliliters of the Baermann water containing the worms to a 15-milliliter centrifuge tube. Spin the tube, remove up to 13 milliliters of the supernatant, and discard it into a liquid waste container with iodine to kill any worms.After collecting all the worms, inspect the pellet of worms at the bottom of the tube. If no worms are visible, wait for one to two hours then collect more worms from the Baermann apparatus. Transfer the worms in as little water as possible to a six-centimeter 2%nematode growth medium plate with a lawn of E.coli HB101 and use this plate as the source plate for the microinjection.Under the dissecting microscope, cover the shard of glass on the microinjection pad cover slip with halocarbon oil using a standard platinum worm pick. Then, place the microinjection pad cover slip on the microinjection scope and locate the shard of glass covered in oil. Align the glass shard such that an edge is perpendicular to the direction of the needle to serve as the surface used to break the needle.Next, using a dissecting microscope, ensure that the needle has no bubbles or debris in the tapered shaft, then secure the needle 1 to 1.5 centimeters into the pressurized holder. Position the tip of the needle in the center of the microscope field-of-view by eye and under low-magnification, position the tip of the needle in the field-of-view perpendicular to the side of the glass shard. Then, switch to higher magnification and align the tip of the needle with the edge of the glass, near, but not touching it.Next, to break the tip of the needle and allow liquid flow, gently tap the needle on the side of the piece of glass while applying continuous pressure from the gas. Once the liquid begins to flow, check the shape of the tip and ensure that it is sharp with easily flowing liquid. When the liquid is flowing well from the needle, move the microinjection slide to the dissecting scope and add one to two microliters of halocarbon oil on the agar pad for placement of the worms.Transfer 20 to 30 young adult Strongyloides to a 2%nematode growth medium plate without bacteria for at least five minutes to remove excess surface bacteria and select single worms for microinjection. Add more worms to the plate as needed while injecting. Using a small amount of halocarbon oil on a worm pick, select a Strongyloides young adult female with one to four eggs in her gonad from the plate without bacteria and transfer the worm into a tiny drop of oil on the agar pad.Using the worm pick, gently position the worm so it is not coiled and the gonad is visible and easy to access. Then, position the worm in the microinjection microscope field-of-view, ensuring that the gonad is on the same side as the needle and positioned so that the needle will contact the gonad at a slight angle. Next, bring the tip of the needle to the side of the worm in the same focal plane.Then, aiming for the gonad arm near the middle of the worm, gently insert the needle into the gonad using a microinjector. Immediately apply pressure to the needle to gently fill the entire gonad arm with the DNA solution. After enough fluid has been injected, remove the needle and observe that the wound closes.Repeat the procedure with the other arm of the gonad, if it is visible. Once the injection is completed, quickly verify that the needle is not clogged by applying pressure with the tip of the needle on the agar pad, then transfer the slide with the injected worm to the dissecting microscope. To recover the injected worm, first place a few drops of worm-buffered saline on the worm to float it off the agar pad.Then collect a small amount of bacteria on a worm pick and touch the worm with the adherent bacteria to remove it from the liquid. Gently transfer the worm to the recovery plate. For behavioral experiments, transfer 20 to 30 larva to a 2%nematode growth medium plate with a thick HB101 bacteria lawn, and under a fluorescence dissecting microscope, identify the larvae expressing the transgene of interest.Then, using a worm pick, select the transgenic larvae and place them in a small watch glass with worm-buffered saline. For microscopy, using a razor blade, score a grid onto the plastic bottom of a 10-centimeter chemotaxis plate to easily track the location of the worms on the plate. Next, add three microliters of larvae in worm-buffered saline into a square on the grid, filling as many squares as needed.Then add 15-to 20-microliter drops of 1%nicotine in water to the worm drops. After four minutes, when the worms are paralyzed, screen them using a fluorescence dissecting microscope. Transgenic Strongyloides stercolaris larvae with an incomplete and complete act-2 mRFPmars expression pattern are show here.The patchy expression in the body wall muscle is more common when the transgene is not integrated into the genome. In contrast, consistent expression throughout the body wall muscle often indicates that the transgene has integrated into the genome. The key step is positioning the needle in the same plane of focus as the gonad to ensure the DNA is injected into the gonad and will be incorporated into the developing eggs.The development of this technique made it possible to study gene function in parasitic nematodes, which is providing new insights into mechanisms of parasitism and host-parasite interactions.
