The authors wish to thank Jeanette Hayes-Klug and Kelly Anderson for management of the muntjac colony, Dr. Alan Young for introducing us to the muntjac and Mr. Cleve Tedford of Cervid Solutions Inc. for providing the seed muntjac for this project. This work was supported by NIH grant R01AI093634.

1. Procedural Preparation
All animal procedures described have been reviewed and approved by the Institutional Animal Care and Use Committee at Colorado State University, an Association for Assessment and Accreditation of Laboratory Animal Care (AAALAC), Intl. accredited institution.
<ol>
	<li>Prior to examination, immobilize animals using appropriate sedation or anesthesia protocols to provide relaxation and allow for appropriate positioning. One handler restrains the deer while a second person administers the sedation to the animal.
	Note: The authors have found the following combination to provide effective sedation in this species: butorphanol (0.45 mg/kg), azaperone (0.035 mg/kg), and medetomidine (0.04 mg/kg), administered intramuscularly in the gluteal muscles.</li>
	<li>Once the doe has reached a plane of sedation that allows for compliant handling, position her in either dorsal or lateral recumbency on an examination table or within a V-trough. Elevate the head, neck, and thorax slightly (approximately 20-30&#176;) to reduce the risk of regurgitation and aspiration of rumenal contents and to facilitate proper ventilation during the procedure.
	Note: In most cervids or other ruminant species, abdominal ultrasound is performed in standing animals; however, the small size and behavioral considerations of this species requires heavy sedation for examination and sternal positioning is therefore more difficult and may preclude effective imaging technique. Positioning the animal midway between sternal and lateral recumbency may be ideal for reducing the risk of regurgitation and hypoventilation and should be considered if possible. In any recumbent position, it is critical to carefully monitor the animals&#39; respirations and immediately stop the examination and place the animal in sternal recumbency if regurgitation or hypoventilation is noted.</li>
	<li>If necessary, clip hair from the area of the abdomen to be examined in order to achieve adequate contact between the footprint of the transducer and the skin.
	Note: In early gestation, evidence of pregnancy can be detected in the caudal abdomen near the mammary glands. This region of the muntjac is typically hairless, and therefore shaving may not be indicated at this time. As the fetus grows and the uterus distends to occupy a more cranial position in the abdomen, clipping of the hair will be necessary prior to imaging. Care should be taken to avoid causing any mechanical trauma to the skin, including lacerations from razor blades or thermal injury from electrical clippers.</li>
	<li>Position the ultrasound unit in a location that allows the technician to easily visualize the monitor while conducting the examination with his or her dominant hand. Input animal identification information (name, identification number, etc.) into the system to automatically label saved images and video loops.</li>
</ol>
2. Transabdominal Reproductive Ultrasound Examination
<ol>
	<li>Apply a generous amount of acoustic coupling gel to the caudal abdomen.</li>
	<li>Place a 5-10 MHz curved linear transducer on the skin of the caudal abdomen, immediately cranial to the pubis, and move it slowly in a cranial direction to evaluate the structures within the pelvic cavity. Scan the left and right quadrants of the caudal abdomen to assess both horns of the muntjac&#39;s bicornuate uterus.
	Note: Comprehensive abdominal ultrasound involves assessment of all abdominal viscera, including the liver, kidneys, spleen, gastrointestinal tract, urinary bladder, and reproductive tract. For the purposes of this protocol, only examination of pregnancy will be discussed in detail; however, the normal appearance of other caudal abdominal organs should be recognized as these structures are likely to be encountered during the course of the study. Organs most commonly seen in this location include segments of the gastrointestinal tract, the urinary bladder, and the reproductive tract. The large and small intestines are identified by the characteristically layered appearance of the intestinal wall. The lumen may or may not be pronounced depending on the type and amount of contents, which may include fluid, gas, mucous, or food particles. The urinary bladder may be difficult to identify unless distended with urine, and the layers of the bladder wall are significantly less distinct than those of the intestines. Apart from the uterus, the ovaries may also be found on ultrasound of the reproductive tract of the female muntjac. The ovaries will appear as ovoid structures near the caudal pole of the kidneys, and their appearance may change over the course of the estrous cycle. The presence of multiple mature, fluid-filled follicles within the cortex is suggestive of estrus.
	Note: By rotating and/or &#34;fanning&#34; the scanhead of the transducer, structures can be evaluated in transverse or sagittal planes.
	<ol>
		<li>If needed to differentiate a gravid uterus from the urinary bladder, empty the bladder manually by applying gentle pressure to the caudal abdomen or by placing a urinary catheter and repeating the scan.
		Note: Manual expression of the bladder should only be attempted when the animal is in a sternal or upright position, which facilitates a more natural orientation of the abdominal viscera and reduces the risk of trauma to other structures. The uterus may also be differentiated from the urinary bladder by assessing the thickness of the organ&#39;s wall. The typical thickness of a moderately distended bladder is approximately 1.4 mm24, while the authors have found that the more muscular wall of the gravid uterus in the muntjac generally measures between 7-8 mm.
		Note: Early pregnancy is difficult to diagnose definitively due to a lack of identifiable fetal structures, and in fact the first indication of pregnancy may simply be a small fluid pocket in the caudal abdomen. If seen at this time, the developing embryo will appear as a hyperechoic, ovoid to amorphous structure within the uterus (Figure 1).</li>
	</ol>
	</li>
	<li>Make adjustments to the depth, frequency, and gain as necessary to improve contrast and image detail.
	Note: higher frequencies are associated with shorter wavelengths, which are necessary for improved image resolution. Most transducers are capable of operating within a range of frequencies (for example, 6-10 MHz)24. Frequency can be adjusted using the scanner controls on the ultrasound unit, and increasing frequency will result in a clearer image. Increasing frequency concurrently decreases the depth of sound wave penetration; therefore, reducing the frequency may be necessary to visualize deeper structures, but resolution may become compromised24. For this reason it is important to select the highest frequency possible to reach the desired tissue depth. Adjustments to the gain controls will alter the amplification of sound waves returning to the transducer from the tissues and affect the degree of contrast in the image24. The gain should be set to a point where optimal contrast between hyperechoic and hypoechoic tissues is achieved, and these settings may need to be adjusted depending on the structures that are being imaged.</li>
</ol>
3. Obtaining Fetal Measurements
Note: Gestational age in many domestic animal species can be estimated using established reference ranges for fetal measurements obtained from ultrasound examination. The most commonly used measurements include straight crown-rump length (SCRL), chest depth (CD), and head length (HL)17. While sufficient data has not yet been collected to develop reliable gestational age guidelines in Reeves&#39; muntjac deer, measurements may be collected in order to begin establishing these references. Fetal heart rate (FHR) has been shown in other species of cervid and ruminant to increase linearly as gestation progresses to a certain point (typically around day 60 of gestation), at which time the heart rate begins to decrease17. FHR may be used to estimate gestational age in conjunction with other ultrasound observations, however it is more commonly used as a measure of fetal viability17,24. FHR has been calculated in Reeves&#39; muntjac as early as 35 days post-observed mating.
<ol>
	<li>To measure SCRL, locate the uterus on the monitor and make fine adjustments to the position of the transducer until a sagittal view of the entire fetus is obtained (Figures 2 and 3). Freeze the image and measure the distance between the most dorsal aspect of the skull and the base of the sacrum (Figures 2 and 3).</li>
	<li>To measure CD, obtain a sagittal view of the fetus (the same image may be used to measure SCRL) and measure the distance between the dorsal and ventral aspects of the thorax (Figures 2 and 3).</li>
	<li>To measure HL, using the same sagittal view of the fetus as described for the SCRL and CD measurements, measure the distance from the occipital crest to the base of nose (Figures 2 and 3).</li>
	<li>To calculate fetal heart rate, identify the heart within the thoracic cavity of the fetus by visualizing its rhythmical contractions. Calculate the heart rate by counting the number of contractions (heart beats) that occur within a 1 min period of time.
	Note: If the ultrasound unit being used has Doppler capabilities, this feature may be employed to further assist in distinguishing the heart from other nonspecific fetal movements.</li>
	<li>Verify that all saved images and video loops include all necessary identifying information, including animal name or number, date, measurements, and appropriate structure labels.</li>
</ol>
4. Procedural Conclusions and Recovery
<ol>
	<li>Remove all residual ultrasound contact gel from the animal&#39;s abdomen using a soft cloth or paper towels. Clean the gel from the transducer prior to storage.</li>
	<li>If using the sedation protocol described in step 1.1, administer atipamezole subcutaneously at a dose of 0.25 mg/kg to reverse the effects of medetomidine. If using a different sedation protocol in which an antagonist is available, administer this agent to the animal according to published dosages at the conclusion of the procedure to speed recovery.</li>
	<li>Place the muntjac on a soft bedded surface in sternal recumbency, with the head slightly elevated to reduce the risk of regurgitation and aspiration of rumenal contents. Monitor the animal closely until fully recovered and able to ambulate around the enclosure without assistance.</li>
</ol>

<ol>
	<li>White, I. R., Russel, A. J., Wright, I. A., Whyte, T. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+ultrasonic+scanning+in+the+diagnosis+of+pregnancy+and+the+estimation+of+gestational+age+in+cattle.">Real-time ultrasonic scanning in the diagnosis of pregnancy and the estimation of gestational age in cattle.</a> Vet Rec. 117 (1), 5-8 (1985).</li><li>Sergeev, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+ultrasound+imaging+for+predicting+ovine+fetal+age.">Real-time ultrasound imaging for predicting ovine fetal age.</a> Theriogenology. 34 (3), 593-601 (1990).</li><li>Aiumlamai, S., Fredriksson, G., Nilsfors, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+ultrasonography+for+determining+the+gestational+age+of+ewes.">Real-time ultrasonography for determining the gestational age of ewes.</a> Vet. Rec. 131 (24), 560-562 (1992).</li><li>Lee, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasonic+measurement+of+fetal+parameters+for+estimation+of+gestational+age+in+Korean+black+goats.">Ultrasonic measurement of fetal parameters for estimation of gestational age in Korean black goats.</a> J. Vet. Med. Sci. 67 (5), 497-502 (2005).</li><li>Renaudin, C. D., Gillis, C. L., Tarantal, A. F., Coleman, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaluation+of+equine+fetal+growth+from+day+100+of+gestation+to+parturition+by+ultrasonography.">Evaluation of equine fetal growth from day 100 of gestation to parturition by ultrasonography.</a> J. Reprod. Fertil. Suppl. (56), 651-660 (2000).</li><li>Lopate, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Estimation+of+gestational+age+and+assessment+of+canine+fetal+maturation+using+radiology+and+ultrasonography:+a+review.">Estimation of gestational age and assessment of canine fetal maturation using radiology and ultrasonography: a review.</a> Theriogenology. 70 (3), 397-402 (2008).</li><li>Gatel, L., Rosset, E., Chalvet-Monfray, K., Buff, S., Rault, D. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Relationships+between+fetal+biometry,+maternal+factors+and+birth+weight+of+purebred+domestic+cat+kittens.">Relationships between fetal biometry, maternal factors and birth weight of purebred domestic cat kittens.</a> Theriogenology. 76 (9), 1716-1722 (2011).</li><li>Mulley, R. C., English, A. W., Rawlinson, R. J., Chapple, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pregnancy+diagnosis+of+fallow+deer+by+ultrasonography.">Pregnancy diagnosis of fallow deer by ultrasonography.</a> Aust. Vet. J. 64 (8), 257-258 (1987).</li><li>Willard, S. T., Sasser, R. G., Jaques, J. T., White, D. R., Neuendorff, D. A., Randel, R. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Early+pregnancy+detection+and+the+hormonal+characterization+of+embryonic-fetal+mortality+in+fallow+deer+(Dama+dama).">Early pregnancy detection and the hormonal characterization of embryonic-fetal mortality in fallow deer (Dama dama).</a> Theriogenology. 49 (4), 861-869 (1998).</li><li>Willard, S. T., Petty, S. J., Sasser, R. G., White, D. L., Randel, R. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pregnancy+detection+and+the+effects+of+age,+body+weight,+and+previous+reproductive+performance+on+pregnancy+status+and+weaning+rates+of+farmed+fallow+deer+(Dama+dama).">Pregnancy detection and the effects of age, body weight, and previous reproductive performance on pregnancy status and weaning rates of farmed fallow deer (Dama dama).</a> J. Anim. Sci. 77 (1), 32-38 (1999).</li><li>Lenz, M. F., English, A. W., Dradjat, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+ultrasonography+for+pregnancy+diagnosis+and+foetal+ageing+in+fallow+deer.">Real-time ultrasonography for pregnancy diagnosis and foetal ageing in fallow deer.</a> Aust. Vet. J. 70 (10), 373-375 (1993).</li><li>White, I. R., McKelvey, W. A., Busby, S., Sneddon, A., Hamilton, W. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diagnosis+of+pregnancy+and+prediction+of+fetal+age+in+red+deer+by+real-time+ultrasonic+scanning.">Diagnosis of pregnancy and prediction of fetal age in red deer by real-time ultrasonic scanning.</a> Vet. Rec. 124 (15), 395-397 (1989).</li><li>Bingham, C. M., Wilson, P. R., Davies, A. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+ultrasonography+for+pregnancy+diagnosis+and+estimation+of+fetal+age+in+farmed+red+deer.">Real-time ultrasonography for pregnancy diagnosis and estimation of fetal age in farmed red deer.</a> Vet. Rec. 126 (5), 102-106 (1990).</li><li>Wilson, P. R., Bingham, C. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Accuracy+of+pregnancy+diagnosis+and+prediction+of+calving+date+in+red+deer+using+real-time+ultrasound+scanning.">Accuracy of pregnancy diagnosis and prediction of calving date in red deer using real-time ultrasound scanning.</a> Vet. Rec. 126 (6), 133-135 (1990).</li><li>Revol, B., Wilson, P. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasonography+of+the+reproductive+tract+and+early+pregnancy+in+red+deer.">Ultrasonography of the reproductive tract and early pregnancy in red deer.</a> Vet. Rec. 128 (10), 229-233 (1991).</li><li>Revol, B., Wilson, P. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Foetal+ageing+in+farmed+red+deer+using+real-time+ultrasonography.">Foetal ageing in farmed red deer using real-time ultrasonography.</a> Anim. Reprod. Sci. 25 (3), 241-253 (1991).</li><li>Yanagawa, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fetal+age+estimation+of+Hokkaido+sika+deer+(Cervus+nippon+yesoensis)+using+ultrasonography+during+early+pregnancy.">Fetal age estimation of Hokkaido sika deer (Cervus nippon yesoensis) using ultrasonography during early pregnancy.</a> J. Reprod. Dev. 55 (2), 143-148 (2009).</li><li>Savela, H., Vahtiala, S., Lindeberg, H., Dahl, R. E., Beckers, J. F., Saarela, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparison+of+accuracy+of+ultrasonography,+progesterone,+and+pregnancy-associated+glycoprotein+tests+for+pregnancy+diagnosis+in+semidomesticated+reindeer.">Comparison of accuracy of ultrasonography, progesterone, and pregnancy-associated glycoprotein tests for pregnancy diagnosis in semidomesticated reindeer.</a> Theriogenology. 72 (9), 1229-1236 (2009).</li><li>Vahtiala, S., Sakkinen, H., Dahl, E., Beckers, J. F., Ropstad, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ultrasonography+in+early+pregnancy+diagnosis+and+measurements+of+fetal+size+in+reindeer+(Rangifer+tarandus+tarandus).">Ultrasonography in early pregnancy diagnosis and measurements of fetal size in reindeer (Rangifer tarandus tarandus).</a> Theriogenology. 61 (4), 785-795 (2004).</li><li>Chapman, N. G., Harris, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evidence+that+the+seasonal+antler+cycle+of+adult+Reeves'+muntjac+(Muntiacus+reevesi)+is+not+associated+with+reproductive+quiescence.">Evidence that the seasonal antler cycle of adult Reeves' muntjac (Muntiacus reevesi) is not associated with reproductive quiescence.</a> J. Reprod. Fertil. 92 (2), 361-369 (1991).</li><li>Chapman, D. I., Chapman, N. G., Dansie, O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+periods+of+conception+and+parturition+in+feral+Reeves'+muntjac+(Muntiacus+reevesi)+in+southern+England,+based+upon+age+of+juvenile+animals.">The periods of conception and parturition in feral Reeves' muntjac (Muntiacus reevesi) in southern England, based upon age of juvenile animals.</a> J. Zool. 204 (4), 575-578 (1984).</li><li>Chapman, N. G., Furlong, M., Harris, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reproductive+strategies+and+the+influence+of+date+of+birth+on+growth+and+sexual+development+of+an+aseasonally-breeding+ungulate:+Reeves'+muntjac+(Muntiacus+reevesi).">Reproductive strategies and the influence of date of birth on growth and sexual development of an aseasonally-breeding ungulate: Reeves' muntjac (Muntiacus reevesi).</a> J. Zool. 241 (3), 551-570 (1996).</li><li>Liming, S., Yingying, Y., Xingsheng, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparative+cytogenetic+studies+on+the+red+muntjac,+Chinese+muntjac,+and+their+F1+hybrids.">Comparative cytogenetic studies on the red muntjac, Chinese muntjac, and their F1 hybrids.</a> Cytogenet. Cell Genet. 26 (1), 22-27 (1980).</li><li>Nyland, T. G., Mattoon, J. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Chapter 2. Small Animal Diagnostic Ultrasound. , 19-29 (2002).</li><li>Huang, F., Cockrell, D. C., Stephenson, T. R., Noyes, J. H., Sasser, R. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+serum+pregnancy+test+with+a+specific+radioimmunoassay+for+moose+and+elk+pregnancy-specific+protein+B.">A serum pregnancy test with a specific radioimmunoassay for moose and elk pregnancy-specific protein B.</a> J. Wildl. Manag. 64, 492-499 (2000).</li></ol>

The authors have nothing to disclose.

This protocol describes the application of transabdominal ultrasonography for pregnancy diagnosis in Reeves&#39; muntjac deer. Consistent with other ultrasound studies, appropriate equipment and technical proficiency are imperative to a successful reproductive examination of the muntjac doe. Careful review of basic mammalian anatomy, the physical principles of diagnostic ultrasound, and the typical ultrasonographic appearance of the abdominal viscera will aid in the reduction of mistaken diagnoses. Furthermore, selection...

Ultrasonographic examination is a well-described method of pregnancy diagnosis in cattle1, sheep2,3, goats4, horses5, companion animals6,7,&#160;and other domestic animal species. This imaging modality has also been identified as a valuable tool for pregnancy detection and fetal age estimation in several species of captive cervids, including fallow deer8-11, red deer12-16, Hokkaido sika deer17, and reindeer18,19. In many cases, ultrasonography has produced higher accuracy rates than other mechanisms of pregnancy detection, such as serum progesterone or pregnancy-associated glycoprotein analysis9,18. Furthermore, ultrasonographic visualization of the reproductive tract can provide additional information regarding fetal viability, gestational age, and identification of developmental abnormalities that would otherwise be difficult to assess. The utility of ultrasonography for evaluating reproductive status suggests that this methodology should be adapted to other species in which active breeding programs are used.
Reeves&#39; muntjac deer (Muntiacus reevesi) are a small cervid species native to southeast Asia20. While the reproductive cycle of these animals is not well-characterized in their native territories, studies of feral populations in parts of southern England have improved understanding of their breeding patterns20. Unlike most cervids, Reeves&#39; muntjac appear to breed year-round, with no apparent seasonal fawning peaks20-22. Female muntjac typically give birth to a single fawn following a 210-day gestation period, and reliably enter a postpartum estrus within 24 hr20-22. Does that do not conceive during this postpartum period will return to estrus approximately 24-25 days later20. In captive situations, reproduction is typically achieved by housing does with one or more intact male. This system produces satisfactory conception rates and requires little technical skill for personnel, however exact breeding dates are difficult, if not impossible, to determine.
Muntjac are commonly used in cytogenetic studies due to the wide range of diploid chromosome numbers and high rate of karyotypic diversification among the different species23. These animals are also currently being investigated as a model of prion disease pathogenesis and transmission, with particular interest placed on the study of vertical transmission of chronic wasting disease (CWD) in cervids. The importance of the muntjac in a number of different research applications suggests that improved reproductive technologies should be established to complement current investigative procedures. Specifically, noninvasive mechanisms to assess the gestational period could potentially elucidate critical variations in reproductive performance and fetal growth and development under different experimental conditions. Furthermore, the development of real-time fetal measurement references would be potentially valuable in estimating gestational age in situations where breeding dates cannot be determined. Previous studies have described mechanisms for using fetal measurements, such as crown-rump length (CRL), chest depth (CD), and head length (HL) to estimate the approximate stage of gestation in cervid species11-14, 16,17. Additionally, some of these studies have also established guidelines describing when specific developmental milestones, such as skeletal mineralization or fetal heartbeat, can be identified8-19. While these data may be useful to help guide reproductive ultrasound analysis in the muntjac, most of the other cervid species studied have much larger body size and longer gestational periods, reducing the translational value of these studies for muntjac applications.
The protocol outlined here describes transabdominal ultrasonography of the female muntjac for the purposes of diagnosing and monitoring pregnancy. Successful execution of this protocol can facilitate early pregnancy detection and evaluation of fetal growth and development. This technique has valuable applications in the conduct of studies investigating reproduction, in utero development, or vertical transmission of infectious diseases in a small cervid model&#160;and may also be useful for clinical purposes in captive breeding operations.

<table border="0" cellpadding="0" cellspacing="0" width="547">
	<colgroup>
		<col />
		<col />
		<col />
		<col />
	</colgroup>
	<tbody>
		<tr height="61">
			<td height="61" style="height:61px;width:187px;">Butorphanol tartrate (Torbugesic) (0.45 mg/kg)</td>
			<td style="width:127px;">Fort Dodge Animal Health, Fort Dodge, Iowa</td>
			<td style="width:64px;">NADA 135-780</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="41">
			<td height="41" style="height:41px;width:187px;">Azaperone tartrate (0.035 mg/kg)</td>
			<td style="width:127px;">ZooPharm</td>
			<td style="width:64px;"></td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="41">
			<td height="41" style="height:41px;width:187px;">Medetomidine HCl (0.04 mg/kg)</td>
			<td style="width:127px;">ZooPharm</td>
			<td style="width:64px;"></td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="41">
			<td height="41" style="height:41px;width:187px;">Ultrasound contact gel</td>
			<td style="width:127px;">Medline, Mundelein, Illinois</td>
			<td style="width:64px;">MDS092005</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="41">
			<td height="41" style="height:41px;width:187px;">Atipamezole hydrochloride (Antisedan) (0.25 mg/kg)</td>
			<td style="width:127px;">Orion Corporation, Espoo, Finland</td>
			<td style="width:64px;">NADA 141-033</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="20">
			<td height="20" style="height:20px;"></td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr height="20">
			<td height="20" style="height:20px;"></td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Table 2 Equipment</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr height="41">
			<td height="41" style="height:41px;width:187px;">Name of Equipment</td>
			<td style="width:127px;">Company</td>
			<td style="width:64px;">Catalog Number</td>
			<td style="width:171px;">Comments</td>
		</tr>
		<tr height="201">
			<td height="201" style="height:201px;width:187px;">V-trough (optional)</td>
			<td style="width:127px;">N/A</td>
			<td style="width:64px;">N/A</td>
			<td style="width:171px;">Animal may be supported in dorsal recumbency on a standard examination table or other surface without the use of a V-trough</td>
		</tr>
		<tr height="61">
			<td height="61" style="height:61px;width:187px;">Electrical clippers or razor blades for hair removal</td>
			<td style="width:127px;">Oster, McMinnville, Tennessee</td>
			<td style="width:64px;">78005-140</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="61">
			<td height="61" style="height:61px;width:187px;">Ultrasound system: Ibex Pro portable ultrasound</td>
			<td style="width:127px;">E.I. Medical Imaging, Loveland, CO</td>
			<td style="width:64px;">Ibex Pro</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="61">
			<td height="61" style="height:61px;width:187px;">5-10 MHz transducer: CL3.8 5-2.5 MHz 60 mm curved linear array</td>
			<td style="width:127px;">E.I. Medical Imaging, Loveland, CO</td>
			<td align="right" style="width:64px;">290420</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:187px;">3 ml syringes</td>
			<td style="width:127px;">Covidien</td>
			<td align="right" style="width:64px;">1.18E+09</td>
			<td style="width:171px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:187px;">22 G needles</td>
			<td style="width:127px;">Covidien</td>
			<td align="right" style="width:64px;">8.88E+09</td>
			<td style="width:171px;"></td>
		</tr>
	</tbody>
</table>

transabdominal ultrasound for pregnancy diagnosis in reeves' muntjac deer

Reeves' muntjac deer (Muntiacus reevesi) are a small cervid species native to southeast Asia, and are currently being investigated as a potential model of prion disease transmission and pathogenesis. Vertical transmission is an area of interest among researchers studying infectious diseases, including prion disease, and these investigations require efficient methods for evaluating the effects of maternal infection on reproductive performance. Ultrasonographic examination is a well-established tool for diagnosing pregnancy and assessing fetal health in many animal species1-7, including several species of farmed cervids8-19, however this technique has not been described in Reeves' muntjac deer. Here we describe the application of transabdominal ultrasound to detect pregnancy in muntjac does and to evaluate fetal growth and development throughout the gestational period. Using this procedure, pregnant animals were identified as early as 35 days following doe-buck pairing and this was an effective means to safely monitor the pregnancy at regular intervals. Future goals of this work will include establishing normal fetal measurement references for estimation of gestational age, determining sensitivity and specificity of the technique for diagnosing pregnancy at various stages of gestation, and identifying variations in fetal growth and development under different experimental conditions.

Using the protocol described here, pregnancy can be diagnosed and monitored in Reeve&#39;s muntjac deer with minimally invasive techniques. The earliest time point that pregnancy could be detected by the authors was approximately 35 days following observed mating behavior.
In the early stages of gestation, pregnancy was diagnosed by visualizing a fluid-filled uterus identified as an anechoic space in the caudal abdomen. Within the uterus, the developing embryo appeared as a hyperechoic, ovoid ...

Watch this Scientific Journal Video about Transabdominal Ultrasound for Pregnancy Diagnosis in Reeves' Muntjac Deer at JoVE.com

Transabdominal Ultrasound for Pregnancy Diagnosis in Reeves' Muntjac Deer

Transabdominal ultrasound is described as an effective, noninvasive means for assessing reproductive status in Reeves' muntjac deer. These methods can be used to achieve early pregnancy diagnosis and to evaluate fetal viability. Future applications of this technique include estimation of gestational age and effects of maternal disease on fetal development.

Reeves' muntjac deer (Muntiacus reevesi) are a small cervid species native to southeast Asia, and are currently being investigated as a potential model of ...
