This work was funded by the National Centre for the Replacement, Refinement and Reduction of Animals in Research (NC3Rs) CRACK IT funding.

1. Fibers
<ol>
	<li>Manufacture the fibers by phase inversion spin casting (spinning). Details of this method can be found in23,24.
	NOTE: For this work the fibers are manufactured in-house using a non-biodegradable proprietary polymer, NMP as the solvent and H2O as the non-solvent. Details of other suitable polymers can be found in the discussion. The fibers used in the system described here are 1.05mm outer diameter with a 600-700 &#181;m lumen diameter. The fibers are porous with pore diameters measuring 2.28 &#181;m &#177; 1.5 &#181;m (mean &#177; standard deviation). This is designed to separate cells from the media feed in the fiber lumen, replicating the liver sinusoid or vasculature of other tissues. Fibers can also be purchased from membrane suppliers such as Pall.</li>
</ol>
2. Module Fabrication
NOTE: The modules used in this study are made from 1 mm thick borosilicate glass with 2 side ports (Figure 2A). The fibers in the module described here have an outer surface area of 4.95 cm2 which is the equivalent of roughly half of a well of a 6-well plate.
<ol>
	<li>Siliconize modules before first use by coating the inner surface with Sigmacote (Table 1) and allowing to dry in a fume hood. Autoclave (121 &#176;C, 1 atm, 20 min) to increase the life of the treatment.</li>
	<li>Using a scalpel cut 75 mm-long fibers and insert three fibers into each module leaving ~7 mm excess length at each end (Figure 3A).</li>
	<li>Place ~0.5 ml of silicone glue (Table 1) into a weighing boat. Use a P200 pipette tip to pick up a small amount of silicone and work the glue into the ends of the module around the fibers to form a 3-5 mm plug (Figure 3B). Allow to dry for &#62;3 hr.</li>
	<li>Using a scalpel cut the silicone flush with the glass module ends (Figure 3C).</li>
	<li>Wrap a small amount (~4 layers) of polytetrafluoroethylene (PTFE) tape around one side port.</li>
</ol>
3. System Setup and Sterilization
NOTE: Pump tubing and modules with fibers are not autoclaved and are sterilized using 70% ethanol. The authors recommend calibrating the pump tubing with the pump to be used. The procedure below is carried out in a laminar flow hood.
<ol>
	<li>Autoclave (as section 2.1) all autoclavable components prior to set-up.</li>
	<li>Set-up
	<ol>
		<li>Place 10 ml 70% ethanol into the reservoir bottle and set-up the reservoir bottle, Q-series cap, feed tube, pump and pump tubing (Table 1) as in Figure 4.</li>
		<li>Loosely place an end cap over the PTFE-taped side port. Slide the ends of the L/S16 module connectors over the module ends and free side port. Connect a 40 mm section of L/S13 tubing to the module connector nearest the capped side port (Table 1) as in Figure 2B.</li>
		<li>Connect the module to the pump tubing, ensuring to orientate the module so the capped side port is nearest the pump.</li>
		<li>Connect the permeate line and retentate line to the module connectors and the L/S14 of the Y-connector on the reservoir bottle (Table 1). Ensure that the set-up resembles the schematics in Figure 4.</li>
	</ol>
	</li>
	<li>Sterilization
	<ol>
		<li>Pump ethanol through the module at 800 &#181;l/hr (267 &#181;l/hr per fiber) for enough time to treat unautoclaved components for &#62;30 min (adjust times if other sterilizing methods are used; see25).</li>
	</ol>
	</li>
	<li>Wash
	<ol>
		<li>To wash the ethanol out of the system, first turn off the pump and drain the tubing. First, detach the pump tubing from the module adaptor tubing. Hold the module aloft to drain the ethanol out of the fibers and retentate line, back into the reservoir bottle. Remove the side port end cap from the module to drain the ethanol from the module itself, and the permeate line. Reattach the side port end cap. Reverse the flow of media on the pump to drain the pump tubing and feed line of ethanol. Turn off the pump, and reattach the pump tubing to the module adaptor.</li>
		<li>Unscrew the ethanol bottle from the lid and replace with a bottle containing 10 ml of cell growth medium (such as EMEM, GMEM, DMEM or RPMI) without serum. Pump the medium through the system at 800 &#181;l/hr until the retentate line is full of media. Clamp the retentate line to force permeation of the media through the fibers to wash the module. Wash for ~2 hr.</li>
	</ol>
	</li>
</ol>
4. Seeding
NOTE: The media and supplements used in this protocol should be those that are established for the desired cell type. Please refer to the literature, the European Collection of Cell Cultures (ECACC) and American Type Culture Collection (ATCC) for further information. Prior to this method cells should be maintained according to established protocols for the desired cell type. For this work the hepatocarcinoma cell line HepG2/C3A subclone were maintained according to the distributors recommendations (ATCC).
NOTE: The seeding protocol presented below also serves to pre-culture the module with cell culture medium prior to cell growth. Should a more extensive pre-culture be required then this should be carried out prior to seeding the module by draining the wash media from the system, replacing with growth media and permeating this through the module for few hours. See section 7.5.2.1 for details on replacing media in the system.
<ol>
	<li>Prepare a single cell suspension by trypsinization according to established protocols for the desired cell type. A general protocol for a T75 culture is as follows:
	NOTE: The number of cells to use in the seeding step should be empirically determined for your desired cell type. The bioreactors described here are seeded at a 35-fold higher cells density (cell/cm2) than used in 2D tissue culture plastic for a 7 day culture.
	<ol>
		<li>Wash the cells by adding 10 ml phosphate buffered saline (PBS), aspirate, then add 3 ml 0.05% trypsin ethylenediaminetetraacetic acid (EDTA) (enough to cover the cells) and incubate at 37 &#176;C, 5% CO2 for 5 min.</li>
		<li>Harvest cells in 7 ml growth media supplemented with 10% fetal bovine serum (FBS) to neutralize the trypsin. Mix well, add 10 &#181;l to the chamber of a hemocytometer and count the cells.</li>
		<li>Centrifuge at 200 x g for 5 min to pellet the cells.</li>
		<li>Aspirate the supernatant and resuspend cells at 4x106/ml in growth media supplemented as required for the desired cell type.</li>
	</ol>
	</li>
	<li>Turn off the pump and drain the feed tube and module as in 3.4.1.</li>
	<li>Detach the module from the module connectors and attach module end caps (Table 1) pre-sterilized in 70% ethanol, leaving one side port free.</li>
	<li>Transfer ~500 &#181;l of the cell suspension (2x106 cells) (4.1.4) to the module using an 18 G needle and 1 ml syringe, taking care to avoid bubble formation and not to damage the fibers.
	<ol>
		<li>Cap the side port using an end cap. Incubate the cells at 37 &#176;C, 5% CO2 for 2-4 hr with manual turning of the module by 180&#176; every 5 min. Alternatively the modules can be attached to a tube rotator with an intermittent mixing setting (Table 1).</li>
	</ol>
	</li>
	<li>Following seeding, attach an end cap onto an injection port (Table 1) pre-sterilized in 70% ethanol, and attach this to the PTFE-taped side port. Remove the other side port end cap and slowly drain the cells by injecting air into the attached injection port using a 27 G needle and 1 ml syringe.
	<ol>
		<li>Replace the injection port with an end cap. Slowly fill the module with media using the free side port and an 18 G needle with a 1 ml syringe. Remove the module end caps and attach the module to the tubing using the module connectors.</li>
	</ol>
	</li>
	<li>Replace the wash media bottle with one containing 50 ml growth media and supplements following the procedure detailed in 7.5.2.1. Pump the growth media through the system at 800 &#181;l/hr.</li>
</ol>
5. Proliferation
NOTE: The fibers used in the research system described here are set to permeate at ~80 &#181;l/hr, with an 800 &#181;l/hr feed rate.
<ol>
	<li>Use the fibers to grow the cells for periods of up to 7 days in a humidified incubator set at 37 &#176;C, 5% CO2.
	NOTE: Monitoring of nutrients and metabolites during the growth phase can provide useful information on the proliferation, metabolic uptake and output of the cells and nutrient and metabolite levels in the media. For example glucose usage and lactate production. Kits are available from various suppliers that can quantitate these factors from media (see Table 1 for those used in this study). Injection ports can be added to the permeate and retentate tubing and media sampled via a 27 G needle and syringe, and media can be sampled from the media reservoir bottle. This gives nutrient and metabolism information for the input and both output streams. Sampling should be carried out in a laminar flow hood. Sterilize injection ports before sampling by holding an ethanol soaked blue roll against the port for &#62;30 sec.</li>
</ol>
6. Excision
NOTE: Fibers can be excised from the module at the end of an experiment for analysis.
<ol>
	<li>Unplug and drain the HFB.</li>
	<li>Insert a scalpel/micro knife (Table 1) blade between the glass and silicone. Turn the module so as to cut away the silicone from the glass. Repeat this procedure at both ends of the module.</li>
	<li>Using the blade hook out the silicone plug from one end and gently pull. Ensure that the fibers come with it.</li>
</ol>
7. Cell Analysis
<ol>
	<li>Cell numbers
	NOTE: For the C3A cells used in this study any time points within the 7 day growth period are suitable for use in this calculation as growth rates do not substantially change over the cell densities achieved in this timeframe.
	<ol>
		<li>After excision (Section 6) dip the fibers into PBS to wash and cut them into a 1.5 ml tube containing 0.5 ml Tris EDTA (TE) buffer. Subject this to two freeze-thaw cycles in a -80 &#176;C freezer. Measure the DNA content using PicoGreen and determine cell numbers by comparing this value to a standard curve made with the desired cell type26.</li>
	</ol>
	</li>
	<li>Cell proliferation rates
	<ol>
		<li>Using the cell numbers calculated at two different time points calculate the specific growth rate &#181; (Equation 1) where Ln(X1) is the natural log of the cell number at the first time point and Ln(X2) is the natural log of the cell number at the second time point.

		&#181;=(Ln(X2)-Ln(X1))/time(hr)&#160;&#160;&#160;&#160;&#160; (1)

		From this calculate the population doubling times (dT) (Equation 2) where &#181; is the specific growth rate.

		dT=Ln2/&#181; &#160; &#160;&#160; (2)</li>
	</ol>
	</li>
	<li>Cell viability
	<ol>
		<li>After excision (Section 6) dip the fibers into PBS to wash and cut them into a 1.5 ml tube containing 500 &#181;l 0.05% trypsin ethylenediaminetetraacetic acid (EDTA). Incubate at 37 &#176;C for 10 min.</li>
		<li>Mix and add 10 &#181;l of cell suspension to 10 &#181;l trypan blue. Load 10 &#181;l onto a haemocytometer and count the number of dead (blue) and alive cells.</li>
	</ol>
	</li>
	<li>Imaging
	<ol>
		<li>After excision dip the fibers into PBS to wash and use scissors to cut them into smaller lengths into a 24-well plate. Add 400 &#181;l 4% paraformaldehyde (in PBS) and incubate at RT for 20 min.</li>
		<li>Wash with PBS by pipetting 400 &#181;l on and off. Repeat this step with fresh PBS.</li>
		<li>Add 400 &#181;l 4&#39;,6-diamidino-2-phenylindole (DAPI) diluted in PBS to approx. 100 ng/ml and incubate at RT for 20 min. Protect from light.</li>
		<li>Wash with PBS twice (as 7.3.2) and once with H2O. Add a fluorescence mounting medium to cover the fiber and image immediately to collect data before the samples dry (DAPI ex/em; 359/461 nm).</li>
		<li>Take images at different focal planes and use &#39;focus stacking&#39; software (e.g., stack focuser plugin for ImageJ, below) to make a composite image showing a greatly expanded depth of field. This is required as the fibers are not flat.
		<ol>
			<li>Download ImageJ (http://imageJ.nih.gov/ij/) and the &#8216;stack-focuser&#8217; plugin (http://rsb.info.nih.gov/ij/plugins/stack-focuser.html).</li>
			<li>In ImageJ open the images to be stacked. Then in the &#39;Image&#39; menu go to &#39;Stacks&#39;-&#39;Images to Stack&#39;. In the &#39;Plugins&#39; menu go to &#39;Stack Focuser&#39;. Specify an n for nxn kernel. Trial and error with &#39;n&#39; may be required in order to generate an image with little &#39;noise&#39;. Values between 11 &#38; 77 tend to work well.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Albumin secretion
	NOTE: This is a hepatocyte cell function test and not a general test of cell function.
	<ol>
		<li>Seed cells (HepG2/C3A) onto 2D tissue culture plastic at 10,667/cm2 and grown for 6 days. Seed HFBs as described in Section 4 and grow for 6 days.</li>
		<li>Following this proliferation period change the culture media (EMEM + 10% FBS, 1x glutamine &#38; 1x penicillin/streptomycin) for the tissue culture plastic and HFB to a serum free Williams E media supplemented with 1x glutamine and 1x penicillin/streptomycin for 24 hr:
		<ol>
			<li>Drain the tubing and HFB module following the steps set out in 3.4.1. Unscrew the reservoir bottle and replace this with a bottle containing the Williams E media. Pump this through the HFB at 800 &#181;l/hr.</li>
		</ol>
		</li>
		<li>Following 24 hr, take media samples. Quantify secreted albumin by ELISA according to the manufacturer&#39;s instructions (Table 1). Dilute media samples 1 in 10 to 1 in 40 before use in order to bring albumin concentrations within the range of the standard curve.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Lewis, W. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Experimental+evidence+in+support+of+the+theory+of+outgrowth+of+the+axis+cylinder.">Experimental evidence in support of the theory of outgrowth of the axis cylinder.</a> American J Anat. 6 (1), 461-471 (1906).</li><li>Harrison, R. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+development+of+peripheral+nerve+fibers+in+altered+surroundings.">The development of peripheral nerve fibers in altered surroundings.</a> Wilhelm Roux Arch Entwickl Mech Org. 30 (2), 15-33 (1910).</li><li>Ding, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+genome-scale+RNAi+screen+for+Oct4+modulators+defines+a+role+of+the+Paf1+complex+for+Embryonic+Stem+Cell+identity.">A genome-scale RNAi screen for Oct4 modulators defines a role of the Paf1 complex for Embryonic Stem Cell identity.</a> Cell Stem Cell. 4 (5), 403-415 (2009).</li><li>Groeber, F., Holeiter, M., Hampel, M., Hinderer, S., Schenke-Layland, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Skin+tissue+engineering+-In+vivo+and+in+vitro+applications.">Skin tissue engineering -In vivo and in vitro applications.</a> Adv Drug Deliv Rev. 63 (4), 352-366 (2011).</li><li>Sinden, J. D., Vishnubhatla, I., Muir, K. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Prospects+for+stem+cell-derived+therapy+in+stroke.">Prospects for stem cell-derived therapy in stroke.</a> Prog Brain Res. 201, 119-167 (2012).</li><li>Ouyang, A., Yang, S. -. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+two-stage+perfusion+fibrous+bed+bioreactor+system+for+mass+production+of+embryonic+stem+cells.">A two-stage perfusion fibrous bed bioreactor system for mass production of embryonic stem cells.</a> Expert Opin Biol Ther. 8 (7), 895-909 (2008).</li><li>Carnachan, R. J., Bokhari, M., Przyborski, S. A., Cameron, N. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Taloring+the+morphology+of+emulsion-templated+porous+polymers.">Taloring the morphology of emulsion-templated porous polymers.</a> Soft Matter. 2 (7), 608-616 (2006).</li><li>Deshpande, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Simplifying+corneal+surface+regeneration+using+a+biodegradable+synthetic+membrane+and+limbal+tissue+explants.">Simplifying corneal surface regeneration using a biodegradable synthetic membrane and limbal tissue explants.</a> Biomaterials. 34 (21), 5088-5106 (2013).</li><li>Storm, M. P., Orchard, C. B., Bone, H. K., Chaudhuri, J. B., Welham, M. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Three-dimensional+culture+systems+for+the+expansion+of+pluripotent+embryonic+stem+cells.">Three-dimensional culture systems for the expansion of pluripotent embryonic stem cells.</a> Biotechnol Bioeng. 107 (4), 683-695 (2010).</li><li>Wung, N., Acott, S. M., Tosh, D., Ellis, M. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hollow+fibre+membrane+bioreactors+for+tissue+engineering+applications.">Hollow fibre membrane bioreactors for tissue engineering applications.</a> Biotechnol Lett. 36 (12), 2357-2366 (2014).</li><li>Ellis, M., Jarman-Smith, M., Chaudhuri, J. B., Chaudhuri, J., Al-Rubeai, <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioreactor+systems+for+tissue+engineering:+A+four-dimensional+challenge.">Bioreactor systems for tissue engineering: A four-dimensional challenge.</a> Bioreactors for tissue engineering; principles, design and operation. , 1-18 (2005).</li><li>Silva, A. I., Mateus, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development+of+a+polysulfone+hollow+fibre+vascular+bio-artificial+pancreas+device+for+in+vitro+studies.">Development of a polysulfone hollow fibre vascular bio-artificial pancreas device for in vitro studies.</a> J Biotechnol. 139 (3), 236-249 (2009).</li><li>De Bartolo, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+hepatocyte+functions+in+a+crossed+hollow+fiber+membrane+bioreactor.">Human hepatocyte functions in a crossed hollow fiber membrane bioreactor.</a> Biomaterials. 30 (13), 2531-2543 (2009).</li><li>Schmelzer, E., Finoli, A., Nettleship, I., Gerlach, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Long-term+three-dimensional+perfusion+culture+of+human+adult+bone+marrow+mononuclear+cells+in+bioreactors.">Long-term three-dimensional perfusion culture of human adult bone marrow mononuclear cells in bioreactors.</a> Biotechnol Bioeng. 112 (4), 801-810 (2015).</li><li>Tapia, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Production+of+high-titer+human+influenza+A+virus+with+adherent+and+suspension+MDKC+cells+cultured+in+a+single-use+hollow+fiber+bioreactor.">Production of high-titer human influenza A virus with adherent and suspension MDKC cells cultured in a single-use hollow fiber bioreactor.</a> Vaccine. 32 (8), 1003-1011 (2014).</li><li>Deng, X., Zhang, G., Shen, C., Yin, J., Meng, Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Hollow+fiber+culture+accelerates+differentiation+of+Caco-2+cells.">Hollow fiber culture accelerates differentiation of Caco-2 cells.</a> Appl Microbiol Biotechnol. 97 (15), 6943-6955 (2013).</li><li>Schutte, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rat+primary+hepatocytes+show+enhanced+performance+and+sensitivity+to+acetaminophen+during+three-dimensional+culture+on+a+polystyrene+scaffold+designed+for+routine+use.">Rat primary hepatocytes show enhanced performance and sensitivity to acetaminophen during three-dimensional culture on a polystyrene scaffold designed for routine use.</a> Assay Drug Dev Technol. 9 (5), 475-486 (2011).</li><li>Bokhari, M., Carnachan, R. J., Cameron, N. R., Przyborski, S. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+cell+culture+device+enabling+three-dimensional+cell+growth+and+improved+cell+function.">Novel cell culture device enabling three-dimensional cell growth and improved cell function.</a> Biochem Biophys Res Commun. 354 (4), 1095-1100 (2007).</li><li>Bokhari, M., Carnachan, R. J., Cameron, N. R., Przyborski, S. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Culture+of+HepG2+liver+cells+on+three+dimensional+polystyrene+scaffolds+enhances+cell+structure+and+function+during+toxicological+challenge.">Culture of HepG2 liver cells on three dimensional polystyrene scaffolds enhances cell structure and function during toxicological challenge.</a> J Anat. 211 (4), 567-576 (2007).</li><li>Vivares, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Morphological+behaviour+and+metabolic+capacity+of+cryopreserved+human+primary+hepatocytes+cultivated+in+a+perfused+multiwell+device.">Morphological behaviour and metabolic capacity of cryopreserved human primary hepatocytes cultivated in a perfused multiwell device.</a> Xenobiotica. 45 (1), 29-44 (2015).</li><li>Smith, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+neural+stem+cell-derived+cultures+in+three-dimensional+substrates+form+spontaneously+functional+neuronal+networks.">Human neural stem cell-derived cultures in three-dimensional substrates form spontaneously functional neuronal networks.</a> J Tissue Eng Regen Med. , (2015).</li><li>Davidson, A. J., Ellis, M. J., Chaudhuri, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+theoretical+approach+to+Zonation+in+a+bioartificial+liver.">A theoretical approach to Zonation in a bioartificial liver.</a> Biotechnol Bioeng. 109 (1), 234-243 (2012).</li><li>Mulder, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> The basic principles of membrane technology. 2nd ed. , (1996).</li><li>Ellis, M. J., Chaudhuri, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Poly(lactic-co-glycolic+acid)+hollow+fibre+membranes+for+use+as+a+tissue+engineering+scaffold.">Poly(lactic-co-glycolic acid) hollow fibre membranes for use as a tissue engineering scaffold.</a> Biotechnol Bioeng. 96 (1), 177-187 (2007).</li><li>Shearer, H., Ellis, M. J., Perera, S. P., Chaudhuri, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+common+sterilization+methods+on+the+structure+and+properties+of+poly(D,L+lactic-co-glycolic+acid)+scaffolds.">Effects of common sterilization methods on the structure and properties of poly(D,L lactic-co-glycolic acid) scaffolds.</a> Tissue Eng. 12 (10), 2717-2727 (2006).</li><li>Forsey, R. W., Chaudhuri, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Validity+of+DNA+analysis+to+determine+cell+numbers+in+tissue+engineering+scaffolds.">Validity of DNA analysis to determine cell numbers in tissue engineering scaffolds.</a> Biotechnol Lett. 31 (6), 819-823 (2009).</li><li>Williamson, M. R., Coombes, A. G. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Gravity+spinning+of+polycaprolactone+fibres+for+applications+in+tissue+engineering.">Gravity spinning of polycaprolactone fibres for applications in tissue engineering.</a> Biomaterials. 25 (3), 459-465 (2004).</li><li>El-Salmawy, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+and+properties+of+pronectin+F-coated+biodegradable+hollow+fibres.">Preparation and properties of pronectin F-coated biodegradable hollow fibres.</a> J Artif Organs. 8 (4), 245-251 (2005).</li><li>Meneghello, G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fabrication+and+characterization+of+poly(lactic-co-glycolic+acid)/polyvinyl+alcohol+blended+hollow+fibre+membranes+for+tissue+engineering+applications.">Fabrication and characterization of poly(lactic-co-glycolic acid)/polyvinyl alcohol blended hollow fibre membranes for tissue engineering applications.</a> J Memb Sci. 344 (1-2), 55-61 (2009).</li></ol>

MJE is a founder and director of Cellesce Ltd which aims to provide bioprocessing solutions for tissue engineering-based research and industry.

This manuscript describes the set-up and operation of a hollow fiber bioreactor (HFB) system for mammalian cell culture and its utility is demonstrated in proliferating the hepatocyte cell line HepG2/C3A. The system is designed to fit onto the shelf of a standard incubator and its set-up is simple enough to be carried out by any competent cell biologist familiar with aseptic technique.
The fibers used in the research system described here are manufactured in house by phase inversion spin casting (spinning) using a non-biodegradable proprietary polymer. It is possible to make fibers by spinning from a variety of materials suitable for cell culture, both biodegradable and non-biodegradable, for example; polycaprolactone (PCL)27, poly-L-lactide acid (PLLA)28, poly(lactic-co-glycolic acid) (PLGA)29, polysulfone (PSU)12 and polyetheretherketone (PEEK)13. Each has different properties and should be chosen based on the needs of the system. Check the compatibility of the employed fiber with the ethanol used in the sterilization step. PLGA is known to plasticize with ethanol necessitating an alternative treatment such as antibiotic/antimycotic solution25.
The dimensions of the glass modules used here were chosen based on the needs of the current research. Different sizes can be made by any reputable glass blowing company. A consideration in module size is the number of cells, which is linked to the number of fibers in the module and likely flow rates. The more cells there are in the module the higher the flow rates will need to be in order to maintain favorable culture conditions at the outflow end of the bioreactor. This will reach a limit as some point and some trial and error may be required with monitoring of media conditions in the module permeate. Mathematical modelling may provide some insights into the required module dimensions and flow rates22.
The dimensions of the apparatus used here is designed to fit onto an incubator shelf. The length of the tubing is dictated by the length needed to reach between the connectors whilst also allowing enough movement of components to allow for set-up and operation. If time course sampling is required, for example in the monitoring of media conditions in the module permeate then injection ports can be added to the retentate and permeate lines to facilitate this.
A prerequisite for any cell culture system is to keep cells alive and in most cases growing. In the light of studies demonstrating a more in vivo-like phenotype in cells grown in 3D culture systems it also seems important to provide an environment that closely mimics the in vivo environment encountered by the cells. This last point is often neglected in 2D cell culture in favor of the convenience this culture system offers. The HFB mimics in vivo capillary networks by delivering nutrients to the cells through the lumen of fibers. The waste products are also removed from the system by the dynamic flow. This creates an in vivo-like system for cell culture and one that closely mimics the in vivo environment seen by hepatocytes, making this system a better choice compared to 2D tissue culture plastic for culturing these cells. This is corroborated by the fact the cells secrete 15-fold the amount of albumin, an important hepatic function, in the HFB culture system compared to those grown on 2D tissue culture plastic.
Whilst the HFB system is suited to most if not all anchorage dependent cell types, the example here is for hepatocytes because there is a real need to be able to culture functional, more in vivo-like hepatocytes for use in drug development by the pharmaceutical industry and in bioartificial liver devices for the extracorporeal support of liver failure patients. The need for more functional cells extends beyond these examples, particularly as the field of regenerative medicine enters a phase of translational work. The advantages of a more in vivo-like culture environment should not be overlooked.

Tissue culture is an established technique for the growth and/or maintenance of cells that has been utilized for over 100 years1,2. The convenience of studying cells and responses ex vivo has far reaching advantages allowing experiments that would otherwise be extremely challenging if not impossible, for example the generation of genetically engineered cell lines and the use of reporter cells in high throughput screening assays3. More recently tissue culture has given rise to the field of tissue engineering, for the generation of in vitro models and for regenerative medicine. With these applications, interest in dynamic 3-dimensional (3D) culture systems has grown significantly.
3D culture methods (defined here as a 3D culture substrate and/or the introduction of directional dynamic flow) better recapitulate the architecture of the in vivo cellular environment, important for achieving a more physiological-like function. The ability to extract, grow, differentiate and transplant cells with the aim of repairing diseased and damaged tissue is a field of study that has a huge potential for patient benefit and commercial opportunity. For example the use of autologous keratinocytes for treating burns (see4) and the use of cell based therapies for the treatment of stroke (see5). Likewise, the market for in vitro models spans drug discovery to stratified medicine applications. The convention in tissue culture is the growth of adherent or anchorage dependent cell types on the 2-dimensional (2D) surface of a tissue culture flask. Whilst currently accepted as the gold standard in a research setting, recent interest in tissue engineering applications has highlighted the fact that current 2D tissue culture environment is inadequate for the required scale-up in cell production6.
For adherent cell types a scaffold is required, which will vary depending on end use, in terms of both the chemical composition and mechanical properties. Some systems employ scaffolds as well-plate inserts consisting of highly porous matrix formed from high internal phase emulsion templating (see7) or electrospun fibers (see8) requiring minimum adaptation from conventional 2D culture techniques. Cells can be seeded onto microcarriers of varying compositions and grown in stirred tanks that deliver nutrients and signaling molecules, and carry away waste products (mass transport) through a dynamic well mixed environment9. However, these systems are limited in their in vivo-like environment and further improvements can be made with regards to scale-up costs. Hollow fiber bioreactors (HFBs) are a 3D culture system that consist of fibers fixed into a module with cells typically seeded on the outside of the porous fibers and media delivered through the fiber lumen (reviewed in10) (Figure 1). HFBs offer an in vivo-like environment with the fibers mimicking blood capillaries and shielding the cells from the shear stresses associated with dynamic media delivery, while allowing defined shear to be applied to cells the via fluid flow through the side ports if desired. This creates a versatile culture system with superior mass transport in which high cell densities can be reached11. The HFB system is well suited for the maintenance of anchorage dependent cell types and has been used to culture a variety of cells including rat pancreatic islets of Langerhans12, mouse &#946;-TC-3 insulinoma cell line12, primary human hepatocytes13, human bone marrow mononuclear cells14, Madin Darby canine kidney cells (MDCK)15 and Caco-2 cells16 to name a few.
In addition to the system advantages of mass transfer and scale-up, cells grown in 3D tissue culture systems tend to be more in vivo-like in morphology and more responsive to experimental cues. For example rat primary hepatocytes show a more cuboidal morphology, increased viability, greater induction of cytochrome-P450 enzyme activity and increased sensitivity to paracetamol toxicity when grown in a commercially available polystyrene scaffold compared to cells grown in 2D culture17. Using the same scaffold the hepatocarcinoma cell line HepG2 has also been shown to increase albumin production18 and show a more in vivo-like response to methotrexate compared to 2D cultured cells19. Primary human hepatocytes demonstrated delayed dedifferentiation, higher cytochrome-P450 activity and increased clearance for 4/5 compounds tested in a perfusion culture system20. Human neural stem cell derived neurons and glia cultured in a commercially available polystyrene scaffold exhibited both high (action potential) and low-frequency (local field potential) spontaneous activity whereas no neuronal activity was detected in the 2D cultured cells21. Caco-2 cells demonstrated enhanced differentiation in a HFB compared to 2D culture measured by increased alkaline phosphatase, &#947;-glutamyltransferase and P-glycoprotein activity and higher expression of F-actin and zona occludens-1 protein16. Despite the advantages, the routine culturing of cells in systems other than a 2D tissue culture flask surface is still not practiced in many laboratories, although the number of publications citing 3D cell culture is growing (8-fold increase in the last 10 years. Source: PubMed &#39;Results by Year&#39; tool probed with &#39;3D culture&#39;).
This manuscript describes the set-up and operating conditions of a HFB system for mammalian cell culture and demonstrates its utility in culturing the hepatocarcinoma cell line HepG2/C3A. The aim of this method is to culture the cells in a more in vivo-like culture system that retains enough simplicity to make it amenable to those who are new to 3D culture systems. The rationale behind using HFBs in the application describe here, which is to improve the predictability of liver models is that it is theoretically possible to mimic a hepatic sinusoid within the HFB environment22. This is not currently feasible with other culture systems.

<table><tbody><tr><td>Glass HFB Module</td><td>Soham Scientific</td><td>&amp;nbsp;---&amp;nbsp;</td><td>Custom Item. (Section 2)</td></tr><tr><td>Sigmacote</td><td>Sigma-Aldrich</td><td>SL2</td><td>(Section 2.1)</td></tr><tr><td>Silicoset 151</td><td>Intertronics</td><td>ACCSS151</td><td>Silicone Glue. (Section 2.3)</td></tr><tr><td>PTFE tape</td><td>Sigma-Aldrich</td><td>Z104388</td><td>(Section 2.5)</td></tr><tr><td>Reservoir bottle</td><td>Fisher</td><td>11972619</td><td>PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5&amp;nbsp;cm section of the supplied PTFE tubing under the 1&amp;nbsp;mm adapter and a 4&amp;nbsp;cm section under the 3&amp;nbsp;mm adapter. (Section 3.2.1)</td></tr><tr><td>Q-series cap</td><td>Kinesis</td><td>00932Q-3V</td><td>PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5&amp;nbsp;cm section of the supplied PTFE tubing under the 1&amp;nbsp;mm adapter and a 4&amp;nbsp;cm section under the 3&amp;nbsp;mm adapter. (Section 3.2.1)</td></tr><tr><td>Adapter, Male, 1.0&amp;nbsp;mm ID</td><td>Kinesis</td><td>008NB10-KD5L</td><td>PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5&amp;nbsp;cm section of the supplied PTFE tubing under the 1&amp;nbsp;mm adapter and a 4&amp;nbsp;cm section under the 3&amp;nbsp;mm adapter. (Section 3.2.1)</td></tr><tr><td>Adapter, Male, 3.0&amp;nbsp;mm ID</td><td>Kinesis</td><td>008NB30-KD5L</td><td>PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5&amp;nbsp;cm section of the supplied PTFE tubing under the 1&amp;nbsp;mm adapter and a 4&amp;nbsp;cm section under the 3&amp;nbsp;mm adapter. (Section 3.2.1)</td></tr><tr><td>Fitting Nut</td><td>Kinesis</td><td>U-350</td><td>PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5&amp;nbsp;cm section of the supplied PTFE tubing under the 1&amp;nbsp;mm adapter and a 4&amp;nbsp;cm section under the 3&amp;nbsp;mm adapter. (Section 3.2.1)</td></tr><tr><td>Neoprene tubing</td><td>Fisher</td><td>10366344</td><td>Attach the Hepa filter to 6cm of neoprene tubing and attach this to the &#039;fitting nut&#039;. Attach a 2x 30&amp;nbsp;mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3&amp;nbsp;cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3&amp;nbsp;mm ID adapter. (Section 3.2.1)</td></tr><tr><td>HEPA-vent</td><td>Fisher</td><td>11374634</td><td>Attach the Hepa filter to 6cm of neoprene tubing and attach this to the &#039;fitting nut&#039;. Attach a 2x 30&amp;nbsp;mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3&amp;nbsp;cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3&amp;nbsp;mm ID adapter. (Section 3.2.1)</td></tr><tr><td>Y-connector, barbed</td><td>Cole Parmer</td><td>OU-06295-10</td><td>Attach the Hepa filter to 6&amp;nbsp;cm of neoprene tubing and attach this to the &#039;fitting nut&#039;. Attach a 2x 30&amp;nbsp;mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3&amp;nbsp;cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3&amp;nbsp;mm ID adapter. (Section 3.2.1)</td></tr><tr><td>L/S16 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-16</td><td>Attach the Hepa filter to 6cm of neoprene tubing and attach this to the &#039;fitting nut&#039;. Attach a 2x 30&amp;nbsp;mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3&amp;nbsp;cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3&amp;nbsp;mm ID adapter. (Section 3.2.1)</td></tr><tr><td>L/S14 Silicone tubing</td><td>Cole Parmer</td><td>WZ-96410-14</td><td>Attach the Hepa filter to 6cm of neoprene tubing and attach this to the &#039;fitting nut&#039;. Attach a 2x 30&amp;nbsp;mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3&amp;nbsp;cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3&amp;nbsp;mm ID adapter. (Section 3.2.1)</td></tr><tr><td>L/S13 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-13</td><td>80&amp;nbsp;cm to connect the 1.0&amp;nbsp;mm barbed adapter on the Q-series cap to the pump tubing = Feed tube. (Section 3.2.1)</td></tr><tr><td>WM 205U/CA pump</td><td>Fisher</td><td>1248-6300</td><td>(Section 3.2.1)</td></tr><tr><td>WM pump tubing, PVC, blue-orange, 0.25&amp;nbsp;mm bore</td><td>Fisher</td><td>12416310</td><td>PTFE the screw thred of the male adapter and connect the female adapter. Work the pump tubing over one of the barbs. Repeat this set-up at the other end of the tubing. (Section 3.2.1)</td></tr><tr><td>Adapter, Male, 1.0&amp;nbsp;mm ID</td><td>Kinesis</td><td>008NB10-KD5L</td><td>PTFE the screw thread of the male adapter and connect the female adapter. Work the pump tubing over one of the barbs. Repeat this set-up at the other end of the tubing. (Section 3.2.1)</td></tr><tr><td>Adapter, Female, 1.0&amp;nbsp;mm ID</td><td>Kinesis</td><td>008NB10-KD2L</td><td>PTFE the screw thred of the male adapter and connect the female adapter. Work the pump tubing over one of the barbs. Repeat this set-up at the other end of the tubing. (Section 3.2.1)</td></tr><tr><td>Female Luer cap</td><td>Cole Parmer</td><td>WZ-45508-64</td><td>Side port end caps. (Section 3.2.2)</td></tr><tr><td>L/S13 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-13</td><td>40&amp;nbsp;mm section to connect the pump tubing to a module connector. (Section 3.2.2)</td></tr><tr><td>L/S16 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-16</td><td>3x 30&amp;nbsp;mm of L/S16 fitted to 3x reducers = module connectors. (Section 3.2.2)</td></tr><tr><td>Barbed reducer 1/8&quot;x1/16&quot;</td><td>Cole Parmer</td><td>30616-43</td><td>3x 30&amp;nbsp;mm of L/S16 fitted to 3x reducers = module connectors. (Section 3.2.2)</td></tr><tr><td>L/S13 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-13</td><td>55&amp;nbsp;cm section to connect the retentate to the L/S14 of the Y-connector on the Q-series cap. (Section 3.2.4)</td></tr><tr><td>L/S13 Silicone tubing</td><td>Cole Parmer</td><td>OU-96410-13</td><td>45&amp;nbsp;cm section to connect the permeate to the L/S14 of the Y-connector on the Q-series cap. (Section 3.2.4)</td></tr><tr><td>Straight barbed union</td><td>Cole Parmer</td><td>WZ-30612-43</td><td>Attach to the end of the L/S13 that will connect with the L/S14 of the Y-connector. (Section 3.2.4)</td></tr><tr><td>Clamp</td><td>VWR</td><td>229-0609</td><td>(Section 3.4.2)</td></tr><tr><td>4&amp;nbsp;mm Silicone tubing</td><td>Fisher</td><td>FB68858</td><td>Fold over a 40&amp;nbsp;mm section of tubing and secure with a cable tie = Module end cap. (Section 4.3)</td></tr><tr><td>Cable tie</td><td>Fisher</td><td>12326377</td><td>Fold over a 40&amp;nbsp;mm section of tubing and secure with a cable tie = Module end cap. (Section 4.3)</td></tr><tr><td>MACSmix tube rotator</td><td>Miltenyi Biotech</td><td>130-090-753</td><td>An adaptation may be required to attach the modules. (Section 4.4)</td></tr><tr><td>Leur Injection port</td><td>Thistle Scientific</td><td>IB-10820</td><td>Attach the end cap to the injection port. (Section 4.5)</td></tr><tr><td>Female Luer cap</td><td>Cole Parmer</td><td>WZ-45508-64</td><td>Attach the end cap to the injection port. (Section 4.5)</td></tr><tr><td>L-lactic acid kit</td><td>Megazyme</td><td>K-LATE</td><td>(Section 5)</td></tr><tr><td>D-glucose kit</td><td>Megazyme</td><td>K-GLUC</td><td>(Section 5)</td></tr><tr><td>Scalpel / micro knife</td><td>InterFocus</td><td>10315-12</td><td>(Section 6.2)</td></tr><tr><td>Albumin ELISA</td><td>Bethyl Labs</td><td>E80-129</td><td>(Section 7.4.3)</td></tr></tbody></table>

hollow fiber bioreactors for in vivo-like mammalian tissue culture

Tissue culture has been used for over 100 years to study cells and responses ex vivo. The convention of this technique is the growth of anchorage dependent cells on the 2-dimensional surface of tissue culture plastic. More recently, there is a growing body of data demonstrating more in vivo-like behaviors of cells grown in 3-dimensional culture systems. This manuscript describes in detail the set-up and operation of a hollow fiber bioreactor system for the in vivo-like culture of mammalian cells. The hollow fiber bioreactor system delivers media to the cells in a manner akin to the delivery of blood through the capillary networks in vivo. The system is designed to fit onto the shelf of a standard CO2 incubator and is simple enough to be set-up by any competent cell biologist with a good understanding of aseptic technique. The systems utility is demonstrated by culturing the hepatocarcinoma cell line HepG2/C3A for 7 days. Further to this and in line with other published reports on the functionality of cells grown in 3-dimensional culture systems the cells are shown to possess increased albumin production (an important hepatic function) when compared to standard 2-dimensional tissue culture.

Cell seeding is a critical step. The ability of cells to adhere to the fiber in a 3D set-up is considerably less than that seen for 2D tissue culture plastic. This is likely due to the reduced contact time between cell and substrate. In the HFB the cells fall through the module during the static phases of seeding. These are considerably shorter in time compared to the one continuous static phase used in 2D. Cells have to make connections to the substrate in this time. Additionally, due to the curved nature of the fibers there is no flat surface for the cells to rest and make connections like there is in 2D culture. Whilst this can be compounded by the chemistry of the fiber employed we know this not to be the case for the polymer employed in this study (data not shown). Increasing the seeding time and cell seeding density leads to the formation of cell aggregates that fall through the module during the static phases at a faster rate than single cells and further reduces the contact time between cells and substrate. Increasing the time also leads to yellowing of the media as there is a high density of cells and no media exchange during this step. Using the conditions described in Section 4 cell seeding rates of ~15% are consistently achieved with the HepG2/C3A cells (Figure 5A). Whilst this may be considered a low fraction there are enough cells to generate well-populated fibers in a matter of days (Figures 5B and 6); following a seven-day proliferation period the cell density reached in the HFB is approaching 3x105/cm2. This is an appropriate density for many assays utilizing hepatocytes and can be considered to be reaching confluence.
The proliferation rates achieved in the HFB are slower when compared to that achieved in 2D cell culture (Figure 5C). This is unlikely to be due to loss of cells in the dynamic flow of the system as cell counts in the media are low (average &#177; SEM: 20,343 cells &#177; 3,674 cells per 24 hr at confluence, which is 4% of the total cells) and this does not increase when the permeation rate is turned up to 400 &#181;l/hr (data not shown). It is also unlikely to be due to a decrease in viability and subsequent loss of cells (see Figure 5D and below). It may be explained, at least in part by the fact this cell line was clonally derived from HepG2 and selected on its ability to show contact inhibition of cell proliferation. The cells in the HFB are seeded at 6x the density of the 2D cells which may lead to slower proliferation rates.
Viability remains high throughout the HFB with cells exhibiting &#62;90%. Whilst there is a slight decrease in viability at the outlet end compared to the inlet this was not found to be significant (t-test p=0.22).
Monitoring of glucose consumption and lactic acid production has been used to tune the media feed rate and media volume in the system. Using 800 &#181;l/hr and a total media volume of 50 ml the glucose and lactic acid levels are maintained above and below (respectively) those seen in standard tissue culture plastic culture.
Albumin secretion is a key liver function carried out by hepatocytes. It is secreted into the serum where it plays several roles in transport and homeostasis. The albumin secretion by cells grown in the HFB is 15-fold higher than that in cells grown on 2D (Figure 7). This demonstrates the cells are functional in the HFB and at least in the case of albumin secretion, this function is elevated in the HFB.
<img alt="Figure 1" src="/files/ftp_upload/53431/53431fig1.jpg" />
Figure 1. The in vivo-like environment of a HFB. Cells are seeded onto the outside of the porous fibers. Media is delivered through the fiber lumen, mimicking a blood capillary. (A) Longitudinal section of a fiber (not to scale). (B) Cross section of a 3 fiber reactor. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" src="/files/ftp_upload/53431/53431fig2.jpg" />
Figure 2. The HFB module. (A) The dimensions of the module used in this study. The dimensions were chosen to fit 3 fibers and fulfil the needs of the current research project. Different sizes can be manufactured and tailored for individual systems and fibers. (B) A photograph of the module with attached end cap and module connectors. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" src="/files/ftp_upload/53431/53431fig3.jpg" />
Figure 3. Module fabrication.&#160;(A) Fibers are cut to size and inserted into the module. (B) Fibers are glued into the module, allowed to dry. (C) The ends are cut flush with the glass. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" src="/files/ftp_upload/53431/53431fig4.jpg" />
Figure 4. HFB system set-up. Arrows indicate direction of media flow. Red = feed tube. Yellow = pump tube. White = HFB module. Green = retentate tube with clamp. Blue = permeate tube. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig4large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 5" src="/files/ftp_upload/53431/53431fig5.jpg" />
Figure 5. Seeding, proliferation, viability and biochemical analysis.&#160;(A) Percent of cells seeded. Black diamonds represent individual HFBs. The red bar is the mean. (B) Cells densities at seeding and after a 7 day proliferation period. 2D cell numbers were determined by trypsinization and counting using a haemocytometer. HFB cell numbers were determined using the PicoGreen assay and a standard curve produced from C3A cells26. n=5-6. Bars = SEM. (C) Population doubling times. n=5-7. Bars = SEM. (D) Viability determined by trypan blue exclusion at the end of a 7 day proliferation. Inlet, central and outlet represent regions within the HFB. n=3-5. Bars=SEM. (E&#38;F) Glucose consumption and lactic acid production. Levels were monitored at the reservoir bottle (inlet) as well as the retentate and permeate outlets and compered to routine culture on tissue culture plastic (media changed on day 3&#38;5). n=3-5. Bars=SEM. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig5large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 6" src="/files/ftp_upload/53431/53431fig6.jpg" />
Figure 6. Images of cells grown on fibers in a HFB. Cells were seeded and grown for 48 hr before fibers were excised, washed in PBS, fixed in 4% paraformaldehyde, washed in PBS and nuclei stained with DAPI. Each image is a composite of 12 &#39;focus stacked&#39; images in order to increase the depth of field of the resulting image. Areas of higher and lower cell density are found along the fiber at this time point and are shown. Where present fiber boundaries are denoted with a red dashed line. Images were taken on an inverted fluorescence microscope. Image = 10X objective. Bar = 200 &#181;m. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig6large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 7" src="/files/ftp_upload/53431/53431fig7.jpg" />
Figure 7. Albumin secretion. Cells were seeded onto tissue culture plastic at 10,667/cm2 and in the HFB as described in Section 4. Cells were proliferated for 6 days. Following this proliferation period the tissue culture plastic and HFB culture media was changed for a serum free Williams E media supplemented with glutamine and penicillin/streptomycin for 24 hr. Media samples were taken and an albumin quantified by ELISA according to the manufactures instructions (Table 1). n=5-6. Bars = SEM. <a href="https://www.jove.com/files/ftp_upload/53431/53431fig7large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<table fo:keep-together.within-page="1">
	<tbody>
		<tr>
			<td>Section</td>
			<td>Name of Equipment</td>
			<td>Company</td>
			<td>Cat. No.</td>
			<td>Notes</td>
			<td>Images</td>
		</tr>
		<tr>
			<td>2</td>
			<td>Glass HFB Module</td>
			<td>Soham Scientific</td>
			<td>&#160;---&#160;</td>
			<td>Custom Item.</td>
			<td rowspan="4"></td>
		</tr>
		<tr>
			<td>2.1</td>
			<td>Sigmacote&#174;</td>
			<td>Sigma-Aldrich</td>
			<td>SL2</td>
			<td></td>
		</tr>
		<tr>
			<td>2.3</td>
			<td>Silicoset 151</td>
			<td>Intertronics</td>
			<td>ACCSS151</td>
			<td>Silicone Glue.</td>
		</tr>
		<tr>
			<td>2.5</td>
			<td>PTFE tape</td>
			<td>Sigma-Aldrich</td>
			<td>Z104388</td>
			<td></td>
		</tr>
		<tr>
			<td rowspan="15">3.2.1</td>
			<td>Reservoir bottle</td>
			<td>Fisher</td>
			<td>11972619</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Q-series cap</td>
			<td>Kinesis</td>
			<td>00932Q-3V</td>
			<td rowspan="4">PTFE the screw threads of the adapters and fitting nut. Attach to the Q-series cap. Attach an 8.5 cm section of the supplied PTFE tubing under the 1 mm adapter and a 4 cm section under the 3 mm adapter.</td>
			<td rowspan="4"><img alt="Table Figure 1" src="/files/ftp_upload/53431/53431tablefig1.jpg" /></td>
		</tr>
		<tr>
			<td>Adapter, Male, 1.0 mm ID</td>
			<td>Kinesis</td>
			<td>008NB10-KD5L</td>
		</tr>
		<tr>
			<td>Adapter, Male, 3.0 mm ID</td>
			<td>Kinesis</td>
			<td>008NB30-KD5L</td>
		</tr>
		<tr>
			<td>Fitting Nut</td>
			<td>Kinesis</td>
			<td>U-350</td>
		</tr>
		<tr>
			<td>Neoprene tubing</td>
			<td>Fisher</td>
			<td>10366344</td>
			<td rowspan="5">Attach the Hepa filter to 6 cm of neoprene tubing and attach this to the &#39;fitting nut&#39;. Attach a 2x 30 mm sections of L/S14 tubing to the top two barbs of the Y-connector and a 3 cm section of L/S16 tubing to the bottom. Attach this to the barb of the 3 mm ID adapter. (Section 3.2.1)</td>
			<td rowspan="5"><img alt="Table Figure 2" src="/files/ftp_upload/53431/53431tablefig2.jpg" /></td>
		</tr>
		<tr>
			<td>HEPA-vent</td>
			<td>Fisher</td>
			<td>11374634</td>
		</tr>
		<tr>
			<td>Y-connector, barbed</td>
			<td>Cole Parmer</td>
			<td>OU-06295-10</td>
		</tr>
		<tr>
			<td>L/S16 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-16</td>
		</tr>
		<tr>
			<td>L/S14 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>WZ-96410-14</td>
		</tr>
		<tr>
			<td>L/S13 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-13</td>
			<td>80 cm to connect the 1.0 mm barbed adapter on the Q-series cap to the pump tubing = Feed tube.</td>
			<td></td>
		</tr>
		<tr>
			<td>WM 205U/CA pump</td>
			<td>Fisher</td>
			<td>1248-6300</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>WM pump tubing, PVC, blue-orange, 0.25 mm bore</td>
			<td>Fisher</td>
			<td>12416310</td>
			<td rowspan="3">PTFE the screw thread of the male adapter and connect the female adapter. Work the pump tubing over one of the barbs. Repeat this set-up at the other end of the tubing. (Section 3.2.1)</td>
			<td rowspan="3"><img alt="Table Figure 3" src="/files/ftp_upload/53431/53431tablefig3.jpg" /></td>
		</tr>
		<tr>
			<td>Adapter, Male, 1.0 mm ID</td>
			<td>Kinesis</td>
			<td>008NB10-KD5L</td>
		</tr>
		<tr>
			<td>Adapter, Female, 1.0 mm ID</td>
			<td>Kinesis</td>
			<td>008NB10-KD2L</td>
		</tr>
		<tr>
			<td rowspan="4">3.2.2</td>
			<td>Female Luer cap</td>
			<td>Cole Parmer</td>
			<td>WZ-45508-64</td>
			<td>Side port end caps.</td>
			<td rowspan="4"><img alt="Table Figure 4" src="/files/ftp_upload/53431/53431tablefig4.jpg" /> <img alt="Table Figure 5" src="/files/ftp_upload/53431/53431tablefig5.jpg" /></td>
		</tr>
		<tr>
			<td>L/S13 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-13</td>
			<td>40 mm section to connect the pump tubing to a module connector.</td>
		</tr>
		<tr>
			<td>L/S16 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-16</td>
			<td rowspan="2">3x 30 mm of L/S16 fitted to 3x reducers = module connectors. (Section 3.2.2)</td>
		</tr>
		<tr>
			<td>Barbed reducer 1/8&#34; x 1/16&#34;</td>
			<td>Cole Parmer</td>
			<td>30616-43</td>
		</tr>
		<tr>
			<td rowspan="3">3.2.4</td>
			<td>L/S13 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-13</td>
			<td>55 cm section to connect the retentate to the L/S14 of the Y-connector on the Q-series cap.</td>
			<td rowspan="3"><img alt="Table Figure 6" src="/files/ftp_upload/53431/53431tablefig6.jpg" /></td>
		</tr>
		<tr>
			<td>L/S13 Silicone tubing</td>
			<td>Cole Parmer</td>
			<td>OU-96410-13</td>
			<td>45 cm section to connect the permeate to the L/S14 of the Y-connector on the Q-series cap.</td>
		</tr>
		<tr>
			<td>Straight barbed union</td>
			<td>Cole Parmer</td>
			<td>WZ-30612-43</td>
			<td>Attach to the end of the L/S13 that will connect with the L/S14 of the Y-connector.</td>
		</tr>
		<tr>
			<td>3.4.2</td>
			<td>Clamp</td>
			<td>VWR</td>
			<td>229-0609</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td rowspan="2">4.3</td>
			<td>4 mm Silicone tubing&#160;</td>
			<td>Fisher</td>
			<td>FB68858</td>
			<td rowspan="2">Fold over a 40 mm section of tubing and secure with a cable tie = Module end cap. (Section 4.3)</td>
			<td rowspan="2"><img alt="Table Figure 7" src="/files/ftp_upload/53431/53431tablefig7.jpg" /></td>
		</tr>
		<tr>
			<td>Cable tie</td>
			<td>Fisher</td>
			<td>12326377</td>
		</tr>
		<tr>
			<td>4.4</td>
			<td>MACSmix tube rotator</td>
			<td>Miltenyi Biotech</td>
			<td>130-090-753</td>
			<td>An adaptation may be required to attach the modules.</td>
			<td></td>
		</tr>
		<tr>
			<td rowspan="2">4.5</td>
			<td>Leur Injection port</td>
			<td>Thistle Scientific</td>
			<td>IB-10820</td>
			<td rowspan="2">Attach the end cap to the injection port. (Section 4.5)</td>
			<td rowspan="2"></td>
		</tr>
		<tr>
			<td>Female Luer cap</td>
			<td>Cole Parmer</td>
			<td>WZ-45508-64</td>
		</tr>
		<tr>
			<td>5</td>
			<td>L-lactic acid kit</td>
			<td>Megazyme</td>
			<td>K-LATE</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>5</td>
			<td>D-glucose kit</td>
			<td>Megazyme</td>
			<td>K-GLUC</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>6.2</td>
			<td>Scalpel / micro knife</td>
			<td>InterFocus</td>
			<td>10315-12</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>7.4.3</td>
			<td>Albumin ELISA</td>
			<td>Bethyl Labs</td>
			<td>E80-129</td>
			<td></td>
			<td></td>
		</tr>
	</tbody>
</table>
Table 1. Components of the HFB set-up. The text section relevant to each component is given in column 1.

Watch this Scientific Journal Video about Hollow Fiber Bioreactors for In Vivo-like Mammalian Tissue Culture at JoVE.com

Hollow Fiber Bioreactors for In Vivo-like Mammalian Tissue Culture

The functional behavior of cells in culture can be improved by culturing in more in vivo-like 3-dimensional culture environments16-21. This manuscript describes the set-up and operation of a hollow fiber bioreactor system for in vivo-like mammalian tissue culture.

Hollow Fiber Bioreactors for In Vivo-like Mammalian Tissue Culture

Tissue culture has been used for over 100 years to study cells and responses ex vivo. The convention of this technique is the growth of anchorage ...

hollow-fiber-bioreactors-for-in-vivo-like-mammalian-tissue-culture

Research

JoVE Journal

Bioengineering

16.2K Views.  University of Bath. The functional behavior of cells in culture can be improved by culturing in more in vivo-like 3-dimensional culture environments16-21. This manuscript describes the set-up and operation of a hollow fiber bioreactor system for in vivo-like mammalian tissue culture.

Video: Hollow Fiber Bioreactors for In Vivo-like Mammalian Tissue Culture

Engineering Biological-Based Vascular Grafts Using a Pulsatile Bioreactor

Much effort has been devoted to develop and advance the methodology to regenerate functional small-diameter arterial bypasses. In the physiological environment, both mechanical and chemical stimulation are required to maintain the proper development and functionality of arterial vessels1,2.
Bioreactor culture systems developed by our group are designed to support vessel regeneration within a precisely controlled chemo-mechanical environment mimicking that of native vessels. Our bioreactor assembly and maintenance procedures are fairly simple and highly repeatable3,4. Smooth muscle cells (SMCs) are seeded onto a tubular polyglycolic acid (PGA) mesh that is threaded over compliant silicone tubing and cultured in the bioreactor with or without pulsatile stimulation for up to 12 weeks. There are four main attributes that distinguish our bioreactor from some predecessors. 1) Unlike other culture systems that simulate only the biochemical surrounding of native blood vessels, our bioreactor also creates a physiological pulsatile environment by applying cyclic radial strain to the vessels in culture. 2) Multiple engineered vessels can be cultured simultaneously under different mechanical conditions within a controlled chemical environment. 3) The bioreactor allows a mono layer of endothelial cells (EC) to be easily coated onto the luminal side of engineered vessels for animal implantation models. 4) Our bioreactor can also culture engineered vessels with different diameter size ranged from 1 mm to 3 mm, saving the effort to tailor each individual bioreactor to fit a specific diameter size.
The engineered vessels cultured in our bioreactor resemble native blood vessels histologically to some degree. Cells in the vessel walls express mature SMC contractile markers such as smooth muscle myosin heavy chain (SMMHC)3. A substantial amount of collagen is deposited within the extracellular matrix, which is responsible for ultimate mechanical strength of the engineered vessels5. Biochemical analysis also indicates that collagen content of engineered vessels is comparable to that of native arteries6. Importantly, the pulsatile bioreactor has consistently regenerated vessels that exhibit mechanical properties that permit successful implantation experiments in animal models3,7. Additionally, this bioreactor can be further modified to allow real-time assessment and tracking of collagen remodeling over time, non-invasively, using a non-linear optical microscopy (NLOM)8. To conclude, this bioreactor should serve as an excellent platform to study the fundamental mechanisms that regulate the regeneration of functional small-diameter vascular grafts.

Our group has developed a bioreactor culture system that mimics the physiological pulsatile stresses of the cardiovascular system to regenerate implantable small-diameter vascular grafts.

Much effort has been devoted to develop and advance the methodology to regenerate functional small-diameter arterial bypasses. In the physiological ...

Chip-based Three-dimensional Cell Culture in Perfused Micro-bioreactors

We have developed a chip-based cell culture system for the three-dimensional cultivation of cells. The chip is typically manufactured from non-biodegradable polymers, e.g., polycarbonate or polymethyl methacrylate by micro injection molding, micro hot embossing or micro thermoforming. But, it can also be manufactured from bio-degradable polymers. Its overall dimensions are 0.7 1 x 20 x 20 x 0.7 1 mm (h x w x l). The main features of the chips used are either a grid of up to 1156 cubic micro-containers (cf-chip) each the size of 120-300 x 300 x 300 &mu; (h x w x l) or round recesses with diameters of 300 &mu; and a depth of 300 &mu; (r-chip). The scaffold can house 10 Mio. cells in a three-dimensional configuration. For an optimal nutrient and gas supply, the chip is inserted in a bioreactor housing. The bioreactor is part of a closed steril circulation loop that, in the simplest configuration, is additionaly comprised of a roller pump and a medium reservoir with a gas supply. The bioreactor can be run in perfusion, superfusion, or even a mixed operation mode. We have successfully cultivated cell lines as well as primary cells over periods of several weeks. For rat primary liver cells we could show a preservation of organotypic functions for more than 2 weeks. For hepatocellular carcinoma cell lines we could show the induction of liver specific genes not or only slightly expressed in standard monolayer culture. The system might also be useful as a stem cell cultivation system since first differentiation experiments with stem cell lines were promising.

We describe a chip-based platform for the three-dimensional cultivation of cells in micro-bioreactors. One chip can house up to 10 Mio. cells that can be cultivated under precisely defined conditions with regard to fluid flow, oxygen tension etc. in a sterile, closed circulation loop.

We have developed a chip-based cell culture system for the three-dimensional cultivation of cells. The chip is typically manufactured from ...

Biology

Tissue Engineering of a Human 3D in vitro Tumor Test System

Cancer is one of the leading causes of death worldwide. Current therapeutic strategies are predominantly developed in 2D culture systems, which inadequately reflect physiological conditions in vivo. Biological 3D matrices provide cells an environment in which cells can self-organize, allowing the study of tissue organization and cell differentiation. Such scaffolds can be seeded with a mixture of different cell types to study direct 3D cell-cell-interactions. To mimic the 3D complexity of cancer tumors, our group has developed a 3D in vitro tumor test system.
	Our 3D tissue test system models the in vivo situation of malignant peripheral nerve sheath tumors (MPNSTs), which we established with our decellularized porcine jejunal segment derived biological vascularized scaffold (BioVaSc). In our model, we reseeded a modified BioVaSc matrix with primary fibroblasts, microvascular endothelial cells (mvECs) and the S462 tumor cell line. For static culture, the vascular structure of the BioVaSc is removed and the remaining scaffold is cut open on one side (Small Intestinal Submucosa SIS-Muc). The resulting matrix is then fixed between two metal rings (cell crowns).
	Another option is to culture the cell-seeded SIS-Muc in a flow bioreactor system that exposes the cells to shear stress. Here, the bioreactor is connected to a peristaltic pump in a self-constructed incubator. A computer regulates the arterial oxygen and nutrient supply via parameters such as blood pressure, temperature, and flow rate. This setup allows for a dynamic culture with either pressure-regulated pulsatile or constant flow.
	In this study, we could successfully establish both a static and dynamic 3D culture system for MPNSTs. The ability to model cancer tumors in a more natural 3D environment will enable the discovery, testing, and validation of future pharmaceuticals in a human-like model.

Tissue Engineering of a Human 3D in vitro Tumor Test System

Methods to create human 3D tumor tissues as test systems are described. These technologies are based on a decellularized Biological Vascularized Scaffold (BioVaSc), primary human cells and a tumor cell line, which can be cultured under static as well as under dynamic conditions in a flow bioreactor.

Cancer is one of the leading causes of death worldwide.  Current therapeutic strategies are predominantly developed in 2D culture  systems, which ...

Interview: Bioreactors and Surfaced-Modified 3D-Scaffolds for Stem Cell Research

A Nature Editorial in 2003 asked the question "Good-bye, flat biology?" What does this question imply? In the past, many in vitro culture systems, mainly monolayer cultures, often suffered from the disadvantage that differentiated primary cells had a relatively short life-span and de-differentiated during culture. As a consequence, most of their organ-specific functions were lost rapidly. Thus, in order to reproduce better conditions for these cells in vitro, modifications and adaptations have been made to conventional monolayer cultures.
The last generation of CellChips -- micro-thermoformed containers -- a specific technology was developed, which offers the additional possibility to modify the whole surface of the 3D formed containers. This allows a surface-patterning on a submicron scale with distinct signalling molecules. Sensors and signal electrodes may be incorporated. Applications range from basic research in cell biology to toxicology and pharmacology. Using biodegradable polymers, clinical applications become a possibility. Furthermore, the last generation of micro-thermoformed chips has been optimized to allow for cheap mass production.

In the past many in vitro culture systems -- mainly monolayer cultures -- often suffered from the disadvantage that differentiated primary cells had a relatively short life-span and de-differentiated during culture. As a consequence, most of their organ-specific functions were lost rapidly. Thus, in order to reproduce better conditions for these cells in vitro, modifications and adaptations have been made to conventional monolayer cultures.

A Nature Editorial in 2003 asked the question  "Good-bye, flat biology?"  What does this question imply? In the past, many in vitro culture systems,  ...

Cultivation of Mammalian Cells Using a Single-use Pneumatic Bioreactor System

Recent advances in mammalian, insect, and stem cell cultivation and scale-up have created tremendous opportunities for new therapeutics and personalized medicine innovations. However, translating these advances into therapeutic applications will require in vitro systems that allow for robust, flexible, and cost effective bioreactor systems. There are several bioreactor systems currently utilized in research and commercial settings; however, many of these systems are not optimal for establishing, expanding, and monitoring the growth of different cell types. The culture parameters most challenging to control in these systems include, minimizing hydrodynamic shear, preventing nutrient gradient formation, establishing uniform culture medium aeration, preventing microbial contamination, and monitoring and adjusting culture conditions in real-time. Using a pneumatic single-use bioreactor system, we demonstrate the assembly and operation of this novel bioreactor for mammalian cells grown on micro-carriers. This bioreactor system eliminates many of the challenges associated with currently available systems by minimizing hydrodynamic shear and nutrient gradient formation, and allowing for uniform culture medium aeration. Moreover, the bioreactor&#8217;s software allows for remote real-time monitoring and adjusting of the bioreactor run parameters. This bioreactor system also has tremendous potential for scale-up of adherent and suspension mammalian cells for production of a variety therapeutic proteins, monoclonal antibodies, stem cells, biosimilars, and vaccines.

Using a pneumatic bioreactor, we demonstrate the assembly, operation, and performance of this single-use bioreactor system for the growth of mammalian cells.

Recent advances in mammalian, insect, and stem cell cultivation and scale-up have created tremendous opportunities for new therapeutics and personalized ...

Perfusable Vascular Network with a Tissue Model in a Microfluidic Device

A spheroid (a multicellular aggregate) is regarded as a good model of living tissues in the human body. Despite the significant advancement in the spheroid cultures, a perfusable vascular network in the spheroids remains a critical challenge for long-term culture required to maintain and develop their functions, such as protein expressions and morphogenesis. The protocol presents a novel method to integrate a perfusable vascular network within the spheroid in a microfluidic device. To induce a perfusable vascular network in the spheroid, angiogenic sprouts connected to microchannels were guided to the spheroid by utilizing angiogenic factors from human lung fibroblasts cultured in the spheroid. The angiogenic sprouts reached the spheroid, merged with the endothelial cells co-cultured in the spheroid, and formed a continuous vascular network. The vascular network could perfuse the interior of the spheroid without any leakage. The constructed vascular network may be further used as a route for supply of nutrients and removal of waste products, mimicking blood circulation in vivo. The method provides a new platform in spheroid culture toward better recapitulation of living tissues.

The protocol describes how to engineer a perfusable vascular network in a spheroid. The spheroid's surrounding microenvironment is devised to induce angiogenesis and connect the spheroid to the microchannels in a microfluidic device. The method allows the perfusion of the spheroid, which is a long-awaited technique in three-dimensional cultures.

A spheroid (a multicellular aggregate) is regarded as a good model of living tissues in the human body. Despite the significant advancement in the ...

Culturing and Applications of Rotating Wall Vessel Bioreactor Derived 3D Epithelial Cell Models

Cells and tissues in the body experience environmental conditions that influence their architecture, intercellular communications, and overall functions. For in vitro cell culture models to accurately mimic the tissue of interest, the growth environment of the culture is a critical aspect to consider. Commonly used conventional cell culture systems propagate epithelial cells on flat two-dimensional (2-D) impermeable surfaces. Although much has been learned from conventional cell culture systems, many findings are not reproducible in human clinical trials or tissue explants, potentially as a result of the lack of a physiologically relevant microenvironment.
Here, we describe a culture system that overcomes many of the culture condition boundaries of 2-D cell cultures, by using the innovative rotating wall vessel (RWV) bioreactor technology. We and others have shown that organotypic RWV-derived models can recapitulate structure, function, and authentic human responses to external stimuli similarly to human explant tissues 1-6. The RWV bioreactor is a suspension culture system that allows for the growth of epithelial cells under low physiological fluid shear conditions. The bioreactors come in two different formats, a high-aspect rotating vessel (HARV) or a slow-turning lateral vessel (STLV), in which they differ by their aeration source. Epithelial cells are added to the bioreactor of choice in combination with porous, collagen-coated microcarrier beads (Figure 1A). The cells utilize the beads as a growth scaffold during the constant free fall in the bioreactor (Figure 1B). The microenvironment provided by the bioreactor allows the cells to form three-dimensional (3-D) aggregates displaying in vivo-like characteristics often not observed under standard 2-D culture conditions (Figure 1D). These characteristics include tight junctions, mucus production, apical/basal orientation, in vivo protein localization, and additional epithelial cell-type specific properties.
The progression from a monolayer of epithelial cells to a fully differentiated 3-D aggregate varies based on cell type1, 7-13. Periodic sampling from the bioreactor allows for monitoring of epithelial aggregate formation, cellular differentiation markers and viability (Figure 1D). Once cellular differentiation and aggregate formation is established, the cells are harvested from the bioreactor, and similar assays performed on 2-D cells can be applied to the 3-D aggregates with a few considerations (Figure 1E-G). In this work, we describe detailed steps of how to culture 3-D epithelial cell aggregates in the RWV bioreactor system and a variety of potential assays and analyses that can be executed with the 3-D aggregates. These analyses include, but are not limited to, structural/morphological analysis (confocal, scanning and transmission electron microscopy), cytokine/chemokine secretion and cell signaling (cytometric bead array and Western blot analysis), gene expression analysis (real-time PCR), toxicological/drug analysis and host-pathogen interactions. The utilization of these assays set the foundation for more in-depth and expansive studies such as metabolomics, transcriptomics, proteomics and other array-based applications. Our goal is to present a non-conventional means of culturing human epithelial cells to produce organotypic 3-D models that recapitulate the human in vivo tissue, in a facile and robust system to be used by researchers with diverse scientific interests.

A rotating cell culture system that allows epithelial cells to grow under physiological conditions resulting in 3-D cellular aggregate formation is described. The aggregates generated display in vivo-like characteristics not observed in conventional culture models and serve as a more accurate organotypic model system for a multitude of scientific investigations.

Cells and tissues in the body experience environmental conditions that influence their architecture, intercellular communications, and overall functions. ...

Fibroblast Derived Human Engineered Connective Tissue for Screening Applications

Fibroblasts are phenotypically highly dynamic cells, which quickly transdifferentiate into myofibroblasts in response to biochemical and biomechanical stimuli. The current understanding of fibrotic processes, including cardiac fibrosis, remains poor, which hampers the development of new anti-fibrotic therapies. Controllable and reliable human model systems are crucial for a better understanding of fibrosis pathology. This is a highly reproducible and scalable protocol to generate engineered connective tissues (ECT) in a 48-well casting plate to facilitate studies of fibroblasts and the pathophysiology of fibrotic tissue in a 3-dimensional (3D) environment. ECT are generated around the poles with tunable stiffness, allowing for studies under a defined biomechanical load. Under the defined loading conditions, phenotypic adaptations controlled by cell-matrix interactions can be studied. Parallel testing is feasible in the 48-well format with the opportunity for the time-course analysis of multiple parameters, such as tissue compaction and contraction against the load. From these parameters, biomechanical properties such as tissue stiffness and elasticity can be studied.

Presented here is a protocol to generate engineered connective tissues for a parallel culture of 48 tissues in a multi-well plate with double poles, suitable for mechanistic studies, disease modeling, and screening applications. The protocol is compatible with fibroblasts from different organs and species and is exemplified here with human primary cardiac fibroblasts.

Fibroblasts are phenotypically highly dynamic cells, which quickly transdifferentiate into myofibroblasts in response to biochemical and biomechanical ...

Imaging-Guided Bioreactor for Generating Bioengineered Airway Tissue

Repeated injury to airway tissue can impair lung function and cause chronic lung disease, such as chronic obstructive pulmonary disease. Advances in regenerative medicine and bioreactor technologies offer opportunities to produce lab-grown functional tissue and organ constructs that can be used to screen drugs, model disease, and engineer tissue replacements. Here, a miniaturized bioreactor coupled with an imaging modality that allows in situ visualization of the inner lumen of explanted rat trachea during in vitro tissue manipulation and&#160;culture is described. Using this bioreactor, the protocol demonstrates imaging-guided selective removal of endogenous cellular components while preserving the intrinsic biochemical features and ultrastructure of the airway tissue matrix. Furthermore, the delivery, uniform distribution, and subsequent prolonged culture of exogenous cells on the decellularized airway lumen with optical monitoring in situ are shown. The results highlight that the imaging-guided bioreactor can potentially be used to facilitate the generation of functional in vitro airway tissues.

The protocol describes an imaging-enabled bioreactor that allows the selective removal of the endogenous epithelium from the rat trachea and homogenous distribution of exogenous cells on the lumen surface, followed by long-term in vitro culture of the cell-tissue construct.

Repeated injury to airway tissue can impair lung function and cause chronic lung disease, such as chronic obstructive pulmonary disease. Advances in ...

Designing a Bioreactor to Improve Data Acquisition and Model Throughput of Engineered Cardiac Tissues

Heart failure remains the leading cause of death worldwide, creating a pressing need for better preclinical models of the human heart. Tissue engineering is crucial for basic science cardiac research; in vitro human cell culture eliminates the interspecies differences of animal models, while a more tissue-like 3D environment (e.g., with extracellular matrix and heterocellular coupling) simulates in vivo conditions to a greater extent than traditional two-dimensional culture on plastic Petri dishes. However, each model system requires specialized equipment, for example, custom-designed bioreactors and functional assessment devices. Additionally, these protocols are often complicated, labor-intensive, and plagued by the failure of the small, delicate tissues.
This paper describes a process for generating a robust human engineered cardiac tissue (hECT) model system using induced pluripotent stem-cell-derived cardiomyocytes for the longitudinal measurement of tissue function. Six hECTs with linear strip geometry are cultured in parallel, with each hECT&#160;suspended from a pair of force-sensing polydimethylsiloxane (PDMS) posts attached to PDMS racks. Each post is capped with a black PDMS stable post tracker (SPoT), a new feature that improves the ease of use, throughput, tissue retention, and data quality. The shape allows for the reliable optical tracking of post deflections, yielding improved twitch force tracings with absolute active and passive tension. The cap geometry eliminates tissue failure due to hECTs slipping off the posts, and as they involve a second step after PDMS rack fabrication, the SPoTs can be added to existing PDMS post-based designs without major changes to the bioreactor fabrication process.
The system is used to demonstrate the importance of measuring hECT function at physiological temperatures and shows stable tissue function during data acquisition. In summary, we describe a state-of-the-art model system that reproduces key physiological conditions to advance the biofidelity, efficiency, and rigor of engineered cardiac tissues for in vitro applications.

Three-dimensional cardiac tissues bioengineered using stem-cell-derived cardiomyocytes have emerged as promising models for studying healthy and diseased human myocardium in vitro while recapitulating key aspects of the native cardiac niche. This manuscript describes a protocol for fabricating and analyzing high-content engineered cardiac tissues generated from human induced pluripotent stem-cell-derived cardiomyocytes.

Heart failure remains the leading cause of death worldwide, creating a pressing need for better preclinical models of the human heart. Tissue engineering ...

Hollow Fiber Bioreactors for In Vivo-like Mammalian Tissue Culture

Summary

Explore More Videos

Engineering Biological-Based Vascular Grafts Using a Pulsatile Bioreactor

Chip-based Three-dimensional Cell Culture in Perfused Micro-bioreactors

Tissue Engineering of a Human 3D in vitro Tumor Test System

Interview: Bioreactors and Surfaced-Modified 3D-Scaffolds for Stem Cell Research

Cultivation of Mammalian Cells Using a Single-use Pneumatic Bioreactor System

Perfusable Vascular Network with a Tissue Model in a Microfluidic Device

Culturing and Applications of Rotating Wall Vessel Bioreactor Derived 3D Epithelial Cell Models

Fibroblast Derived Human Engineered Connective Tissue for Screening Applications

Imaging-Guided Bioreactor for Generating Bioengineered Airway Tissue

Designing a Bioreactor to Improve Data Acquisition and Model Throughput of Engineered Cardiac Tissues
