This work was supported by the LSUHSC Foundation (PLF), and in part by U54 GM104940 from the National Institute of General Medical Sciences of the National Institutes of Health, which funds the Louisiana Clinical and Translational Science Center.

All animal protocols involving tail vein injections and use of the warming/restraining device were reviewed and approved by the local Institutional Animal Care Committee (IACUC).
1. Preparation
<ol>
	<li>Acclimate animals in the housing environment for at least 1 week, and allow food and water ad libitum.
	NOTE: For most new users of this injection technique, animal strains with white or light-colored fur may be preferable as the tail veins are readily visible through the skin. Dark-colored strains of mice (e.g., C57BL/6) or rats (e.g., Brown Norway) have deeply pigmented tails, resulting in a weak color contrast against the vein. It is highly recommended that new users receive adequate training until proficiency is attained.</li>
	<li>Agents for tail vein injection
	<ol>
		<li>Prepare all test agents and solutions aseptically. When administering organisms or cellular materials, take precautions during all steps of processing to maintain pyrogen-free conditions.</li>
		<li>Use only normal saline (0.9% w/v sodium chloride) or balanced salt solutions such as phosphate-buffered saline (PBS) as vehicles for tail vein injection.
		CAUTION: Never use water, oil, or viscous solutions owing to the potential risk of vascular damage. A wide range of pH (4.5&#8211;8.0) is tolerable because of the buffering effect of blood and fast blood flow rates in rodents. However, highly acidic or alkaline solutions can result in unnecessary tissue damage at the injection site and should be avoided.</li>
		<li>Limit the volume and frequency of injection to a minimum. Use the recommended volumes for mice and rats (&#8804;200 &#181;L and &#8804;500 &#181;L, respectively) at body temperature before injection to minimize stress to the animal3.</li>
		<li>Ensure that each preparation of the syringe and needle is free from air bubbles in the solution; if bubbles are present, purge them completely to prevent the risk for embolism.
		NOTE: Typically, 1 mL syringes with 27 G, &#189;-in needles are adequate for most tail vein injections.</li>
		<li>Use appropriate personal protective equipment (PPE) required by local IACUC with the minimum of disposable or dedicated gowns and latex or nitrile gloves. Use of safety glasses is highly recommended when performing tail vein injection.</li>
	</ol>
	</li>
	<li>The warming and restraint device
	<ol>
		<li>Carefully inspect all components before use to ensure that the device is free of any defects (Figure 1).</li>
		<li>Warming device initialization (Figure 2A)
		<ol>
			<li>Place the warming unit on a clean flat benchtop, and power the device on. Ensure that the thermostat power indicator lamp is lit green. Place bedding materials inside the warming chamber to keep the area dry and retain heat.</li>
		</ol>
		</li>
		<li>Restraint device setup (Figure 2B)
		<ol>
			<li>Place the restraint unit alongside the warming unit, and determine the appropriate cone sizes for the animal. If necessary, manually adjust the base widths of the pliable aluminum cone to provide adequate restraint for the animal. Alternatively, replace the cone with custom-fitted models to accommodate mice or rats of varying body sizes.</li>
		</ol>
		</li>
	</ol>
	</li>
</ol>
2. Tail vein injection
<ol>
	<li>Apparatus adjustments
	<ol>
		<li>Setting the internal temperature
		<ol>
			<li>Using the control dial, set the thermostat at the desired temperature. Ensure that the heater indicator is lit red, and that the light bulb illuminates. Monitor the internal temperature display carefully while the bulb is illuminated (heating). The thermostat inactivates the bulb automatically once a target temperature has reached, approximately in 10&#8211;15 min.
			NOTE: Setting a temperature higher than the ambient temperature activates the heater. In general, the recommended housing temperature in standard vivarium conditions vary, ranging from 20 to 26 &#176;C, while the neutral (i.e., comfortable) temperature for laboratory mice is considered to be between 30 and 32 &#176;C42. Therefore, it is recommended that the internal temperature of the warming chamber be elevated slightly higher than thermoneutrality, approximately at 32&#8211;36 &#176;C. Never set the thermostat above the body temperature.</li>
		</ol>
		</li>
		<li>Positioning the restraint platform
		<ol>
			<li>Using the height adjustment knob, adjust the cone height to the optimal level for the user.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Heat treatment (Figure 3A)
	<ol>
		<li>Once the target temperature has been reached (32&#8211;36 &#176;C), gently transfer the animals from the housing cage into the warming chamber.
		NOTE: Heat treatment for 5&#8211;10 min is sufficient to induce vasodilation and enhance the visibility of tail veins. However, animals can be safely held in the thermoregulated chamber for the duration of the procedure (typically 20&#8211;30 min with no sign of hyperthermia). The warming chamber can safely contain 4&#8211;6 mice or one rat.</li>
		<li>Monitor the animal for any signs of acute heat stress (e.g., rapid respiration, lethargy, jumping escape behavior).
		CAUTION: Animals exhibiting signs of hyperthermia should be returned to their cage and monitored until they resume normal activity prior to reuse. If this is because of the internal temperature exceeding the optimal range, ensure that the warming device is turned off.</li>
	</ol>
	</li>
	<li>Injection steps
	<ol>
		<li>Lift the animal by the base of the tail, and remove it from the warming chamber. Introduce the animal onto the cone opening of the restraining unit.
		CAUTION: Never lift mice from the tail end; this can result in serious injuries. Alternative methods of handling should be used for obese or pregnant mice28.</li>
		<li>As the animal grasps on the far edge of the cone with its forelegs, gently pull the tail backward and pass the tail through the open slit. Secure the hind end of the animal at the base of the cone with one hind leg protruding out from the cone so the lateral vein is shown at a position of 12 o&#8217;clock. Either hind leg can be protruded as there are two lateral veins, one on each side (Figure 3B).</li>
		<li>Grasp the tail at the mid- to two-thirds-length with the non-dominant hand between the thumb and forefinger, putting slight tension on the lateral vein to maintain the tail positioning and vasodilation.
		NOTE: Enhanced visibility of the dilated veins by heat treatment enables the user to quickly determine an injection site for the best results (Figure 4).</li>
		<li>Wipe the skin of the injection site with a gauze sponge or pad moistened with 70% alcohol. Clean as gently and quickly as possible to avoid irritation to the tail.
		NOTE: This procedure can be omitted at the discretion of the institutional IACUC.</li>
		<li>Hold the syringe with the dominant hand, and position the needle parallel to the tail. Insert the needle toward the direction of the blood flow, bevel up at a 10&#8211;15&#176; angle (Figure 5A&#8211;B), and advance further into the lumen of the vein by penetrating 2&#8211;4 mm (Figure 5C&#8211;D). Slowly inject the solution.
		NOTE: If the injection is successful, no resistance on the plunger should be felt, and the fluid can be seen moving through the vein. In case of resistance or white blisters above the injection site, remove the needle and attempt a second injection at a site above the original needle placement. Do not attempt to inject below the initial injection site as the fluid will release through the initial site. If injection of one lateral vein is unsuccessful, reposition the animal to the opposite side and make more attempts on the contralateral vein. The maximum number of attempts will depend on where one starts the attempted injection along the vein and the swelling that may occur with missed attempts. Consult the institutional IACUC regulations for mis-injections and associated injuries.</li>
		<li>Remove the needle, and press firmly with the thumb to prevent backflow of the injected solution and/or blood. Continue to apply gentle compression with a clean gauze/wipe or tissue until bleeding has stopped (Figure 6).</li>
		<li>Return the animal to its cage, and monitor for at least 5 min. Ensure that the animal resumes normal activity without further bleeding.</li>
	</ol>
	</li>
</ol>
3. A murine model of fungal bloodstream infection and sepsis
<ol>
	<li>Mouse strains
	<ol>
		<li>Acclimate female Swiss Webster outbred mice at 6 weeks of age per institutionally recommended guidelines. Alternatively, use inbred/genetically modified strains (e.g., C57BL/6 background) for this protocol with modified inocula (see NOTE).
		NOTE (see Discussion for detail): Tail veins of mice with dark fur are often less visible than those with lighter fur due to the deeply pigmented tail (Figure 4). There is varying susceptibility to fungal sepsis/lethality among different mouse strains. Use of mouse strains other than Swiss Webster may require additional protocol optimization by considering relevant factors (e.g., genetic background, age, sex, body size) that could influence host immune status. For example, a lethal challenge in C57BL/6 mice typically requires higher inocula (up to 10x) to achieve the level of mortality seen in Swiss Webster mice.</li>
	</ol>
	</li>
	<li>Microorganisms
	<ol>
		<li>For a lethal challenge (sepsis), streak frozen stocks of Candida albicans strain DAY185 (or strains of choice) onto Sabouraud dextrose agar and incubate at 30 &#176;C for 2 days.</li>
		<li>Transfer a single colony into 10 mL yeast extract-peptone-dextrose broth, and culture to the stationary phase of growth for 18 h at 30 &#176;C with shaking.</li>
	</ol>
	</li>
	<li>Inoculum solutions
	<ol>
		<li>On the day of a lethal challenge, collect the broth culture, and wash the pellet 3 times by centrifugation (800 &#215; g) in sterile PBS.</li>
		<li>Identify viable yeast cells by trypan blue dye exclusion, and enumerate using a hemocytometer. Adjust the cell concentration to 1 x 106 cells/mL in sterile PBS at room temperature.
		NOTE: Each animal will receive 100 &#181;L of the inoculum solution. Prepare an excess volume of the inoculum (&#62;500 &#181;L) to allow for potential loss during the injection procedure. The final inoculum is 1 x 105 cells per mouse. The inoculum volume can be increased up to 200 &#181;L by adjusting the cell concentration accordingly.
		CAUTION: The fungal inoculum solution must be kept at room temperature prior to injection. Warming the inoculum solution to body temperature may induce a morphological change from yeast cells to hyphae. Contrarily, bolus i.v administration of cold solutions can rapidly lower body temperature of the animal and should be avoided.</li>
	</ol>
	</li>
	<li>Intravenous inoculation
	<ol>
		<li>Warm the animals, and induce vasodilation by following the procedures in section 2.</li>
		<li>Inject 100 &#181;L of the inoculum solution into the tail vein using a 1 mL syringe with a 27 G, &#189;-in needle.</li>
	</ol>
	</li>
	<li>Post-inoculation monitoring
	<ol>
		<li>Monitor the animals for the following signs of sepsis-induced morbidity: i) fur aspect (e.g., smooth, ruffled), ii) activity (e.g., moving freely, nonresponsive), iii) posture (e.g., hunched, stiff), iv) behavior (e.g., slow, no relocation), v) chest movements (e.g., normal breathing, dyspnea), vi) eyelids (e.g., open, closed)43.</li>
	</ol>
	</li>
	<li>Sepsis scoring
	<ol>
		<li>Score the observed morbidity according to a modified Mouse Clinical Assessment Score for Sepsis (M-CASS) in a four-point grading scale from 0 to 3 in each category: 0, normal; 1, mild; 2, moderate; 3, severe43.</li>
	</ol>
	</li>
	<li>Optional protocol: Vaccination against fungal sepsis
	<ol>
		<li>Fourteen days prior to a lethal challenge, inoculate mice with Candida dubliniensis strain W&#252;284 or attenuated C. albicans strains, such as &#916;efg1/&#916;cph1 mutant (1x105 cells per mouse), as described in sections 3.2&#8211;3.4 in lieu of C. albicans DAY185.</li>
		<li>Conduct a lethal challenge in the vaccinated mice, as described in sections 3.2&#8211;3.4, and monitor for the signs of sepsis-induced morbidity described in sections 3.5&#8211;3.6.</li>
	</ol>
	</li>
</ol>

The authors have nothing to disclose.

Consistent and accurate dosing are key requirements for experimental reliability in animal models. This is especially important in cases of i.v. administration where systemic bioavailability of injected agents is considerably higher/faster than with other administration routes3. Thus, errors in tail vein injection could have a detrimental impact on study outcomes. Historically, intraperitoneal (i.p.) injection, rather than i.v., has been the most common method for systemic access in rodents due to technical simplicity and convenience. However, administration routes become more crucial when translating preclinical readouts from animals into clinical settings. Hence, there is a need for continuous improvement in rodent protocols that could facilitate successful tail vein injection.
The key advancement in the present protocol is the innovative thermoregulated warming device that enables effective induction of vasodilation in rodents, which dramatically improves the visibility of tail veins and needle alignment. Heating methods that are poorly thermoregulated (e.g., lamps), topical vasodilators or skin irritants (e.g., xylenes) are not only unreliable, but are also unsafe for the animal and should be avoided44. Contrary to other conventional methods, such as immersing the tail in warm water, the autoregulation capability of this device can safely condition multiple animals simultaneously. In addition, this protocol is strengthened further by using the optimally designed restraining device and allowing fast and secure immobilization of the animal in a position that best displays the lateral tail vein.
The transparent tubal formats seen in many current restrainers, though practically well-designed, require more handling time with each animal, thus prolonging the restraining process45. This can be more problematic in rodent strains with aggressive traits that offer limited cooperation46,47. In contrast, the semi-enclosed cone structure of the restraining device permits quick positioning of the animal and aids in minimizing the duration of restraint. Together, the streamlined protocol using the innovative, highly optimized warming/restraining system accelerates the injection procedure, allowing for quick and effective dosing of large groups of animals. In our laboratory, we typically complete an entire injection procedure of 30 mice from heat treatment to post-injection monitoring within 1 h using this protocol.
Despite the advanced features, this device has some apparent disadvantages: the first is the cost of the device and routine light bulb replacement in the warming chamber. However, in addition to the efficiency and speed of injections, the device is durable for repeated use and compatible with most common disinfectants, permitting thorough cleaning of the device between uses. Together, this offsets the initial investment. Second, in situations with limited workspace, a drawback to this protocol may be the requirement for a dedicated bench area large enough to place the two units, side by side, while performing the injection. However, because the device can be utilized broadly across several rodent protocols involving i.v. injections, it is possible that the device could serve as a core instrument similar to other communal vivarium equipment such as isoflurane vaporizers. Regardless, the two units are easily portable and can be bundled and stowed while not in use.
The i.v. lethal challenge model of murine fungal sepsis described in this protocol closely mimics C. albicans bloodstream infections in humans and has been extensively used to study fungal virulence, test efficacy of antifungal therapies, and characterize host immune responses to infection37,39,48. To achieve a reproducible infection, i.v. inoculation via tail vein injection is the most vital step of the protocol to ensure accurate delivery of the organisms into the bloodstream. In fact, animals respond very differently to varying levels of Candida i.v. challenges; administration of too low amounts of inoculum will result in unwanted spontaneous recoveries, whereas animals receiving too high doses will succumb prematurely. The specific window of inoculum sizes for a given organism to induce a consistent level of sepsis/mortality largely depends on both fungal strains and mouse strains.
The current protocol using Swiss Webster mice at the inoculum of 1 x 105 wild-type C. albicans reproducibly induced the onset of sepsis morbidity within 1 day, followed by progressive mortality resulting in 100% lethality by 5&#8211;7 days. In contrast, inocula higher than 1 x 105&#160;typically lead to accelerated deaths (i.e., 1&#8211;2 days at 1 x 106, 3&#8211;4 days at 5 x 105), and those lower than 1 x 105 are sub-lethal. In line with numerous reports in the literature, the use of non-albicans Candida species in lieu of C. albicans results&#160;in significantly diminished lethality40,49. Additionally, the choice of mouse strains, or even the origin of colonies, can have a considerable impact on infection outcomes due to varying susceptibilities between mouse strains, as reported by others39,40,41,50,51,52,53,54,55. Hence, both should be taken into consideration when designing experiments.
Following a lethal i.v. challenge, fungal cells spread rapidly through the bloodstream and begin to invade multiple organs, among which the most affected are the kidneys41. Other organs affected are the brain, spleen, and bone marrow48,56. Regardless, acute sepsis is the ultimate cause of death at the early time points37. As shown in the representative results, sepsis severity can be quantitatively assessed by the Mouse Clinical Assessment Score for Sepsis (M-CASS) based on exhibited signs of a sepsis condition in challenged animals43,57. Among the several surrogate markers of lethal sepsis, hypothermia has been suggested as a critical predictor for imminent death in both clinical and experimental sepsis43,58,59.
Although no formal studies have been conducted to directly compare inbred vs. outbred mice in this model, data obtained from the current protocol using outbred Swiss Webster mice are exceptionally reproducible in various sepsis parameters, despite the presumed genetic heterogeneity. Generally, a pattern of mortality that falls within 3&#8211;5 days is a firm model of acute sepsis, as evidenced by rapid elevation in sepsis morbidity and levels of inflammatory markers within hours of post-lethal challenge50,51. For longer survival times (7&#8211;10 days), mortality is likely the result of microbial burden leading to lethal tissue damage in target organs and the central nervous system. The choice of sepsis or microbial burden can be applied as necessary for evaluating immune functions or responses to anti-inflammatory regimens or antifungal therapies/vaccines, as determined by the inoculum used.
In addition to the i.v. lethal challenge model, intra-abdominal infection with C. albicans in mice via an i.p. challenge can also lead to disseminated candidiasis and subsequent sepsis, although co-inoculation with the bacterial pathogen, Staphylococcus aureus, synergistically enhances mortality compared to C. albicans mono-infection51,60,61. In the i.p. lethal challenge model, substantially higher microbial inocula (1.75 x 107 C. albicans/8 x 107 S. aureus per mouse) are required to cause polymicrobial peritonitis and dissemination of the organisms from the abdominal cavity into the bloodstream. Similarly, gastrointestinal infection with C. albicans in mice treated with immunosuppressive and/or mucosal-damaging agents leads to translocation of the fungal cells into the bloodstream and results in fungal sepsis62,63. Despite the distinctive inoculation routes, the mechanism of ensuing fungal sepsis is largely analogous between the three disease models, involving an uncontrolled systemic proinflammatory response to Candida that leads to organ failure37,51,61. Similarly, in humans, it is this process of the host response, not simply candidemia, that causes the high morbidity/mortality associated with hematogenously disseminated candidiasis acquired in health care settings64,65.
Using the current fungal sepsis model, we demonstrate here that protection against lethal C. albicans infection can be achieved by i.v. pre-immunization/vaccination with C. dubliniensis (avirulent) or attenuated C. albicans mutants, concomitant with significant reduction in sepsis morbidity. The protection is mediated by innate Gr-1+ myeloid-derived suppressor cells that appear to be induced in the bone marrow as a form of trained innate immunity66,67. Efforts are underway to extend the understanding of this novel form of innate immune-mediated protection against C. albicans bloodstream infections.
In conclusion, the innovative rodent warming/restraining device has been instrumental in advancing our ability to perform i.v. injections of large-scale multi-group animal studies in an efficient and effective manner. As such, we have coined the term, Mouse a Minute, for the device. The device specifications are available from the corresponding author upon request for procurement of a similar device. The techniques demonstrated here could serve as a useful tool in rodent models employing tail vein injections across a broad range of research areas.

The use of animal models involving rodents has been a staple of biomedical research. Numerous inbred and outbred strains, as well as genetically modified lines, are available and routinely used in laboratories worldwide. Tail vein injection is one of the essential methods in rodent models requiring intravenous (i.v.) administration of experimental agents. Generally, i.v. injections have major advantages over other routes of administration such as high absorbance rates by bypassing local tissues and the digestive tract and high tolerance to solutions of a wide range of concentrations or non-physiological pH1,2,3,4. Among other viable i.v. routes (e.g., saphenous veins, retro-orbital venous sinus), tail veins are considered the safest and most readily accessible blood vessel in rodents2,3,5,6. Hence, tail vein injection has been widely employed in an array of rodent models including infectious disease models7,8,9, transplantation of biological materials10,11, evaluation of preclinical therapeutics12,13, and toxicological analyses14,15.
Consistency and accuracy of dosing are a critical requirement in successful tail vein injections. Surprisingly, quantitative and qualitative evaluation of tail vein injections in the literature implicates frequent mis-injections16,17. A study reported that twelve out of thirty injections performed by trained injectors left more than 10% of injected doses within the tail18. In addition, the safety and comfort of the animal receiving tail vein injections should be a primary concern during the procedure. Improper restraint can lead to injuries and a range of stress-related pathologies (e.g., weight loss, impaired immune responses) that could introduce substantial variables in sample quality19,20. These errors can cause increased variability in data and poor reproducibility, thus negatively affecting study outcomes.
Induction of vascular dilation in the animal is often necessary when performing tail vein injections due to the small diameter of the vessel, estimated to be 300 &#181;m in mice21. Vasodilation enhances the visibility of tail veins and aids in achieving optimal needle-vein alignment within the venous lumen. A variety of methods have been reported by laboratories such as immersing the tail in warm water22, applying heat to the tail using a warm drape, lamp, or hair dryer23,24, or placing the animal in a warm environment using a heating pad, incubator, or box combined with one of these heat sources25. The devices can be either self-made for specific purposes or available from commercial suppliers. However, many lack thermoregulatory capabilities and if any, the device temperature is poorly maintained and often subject to variations in room temperature. Similarly, the use of a restraining device is necessary for tail vein injections as the use of anesthesia is not recommended26,27. Several types of laboratory-specific or commercial restraining devices have been developed. Typically, the animal is placed in a disposable 50 ml conical tube4, slotted plexiglass walls, a tunnel, or cone28, all of which allow ample exposure of the tail while restricting movements of the animal. However, most restrainers have size limitations due to the rigidity of the materials. Furthermore, modern high-complexity devices, despite the practical and sophisticated designs, do not appear to be feasible for injections involving large groups of animals22.
Mouse models of bloodstream infection and associated sepsis are a prime example of situations requiring the use of this technique. Among all microbial etiology of severe clinical sepsis, fungal sepsis is often a fatal condition with mortality rates of &#62;40% despite antifungal therapy29. In fact, infection by Candida albicans has been reported as the fourth leading cause of hospital-acquired bloodstream infection (candidemia)30,31. In intra-abdominal candidiasis, microorganisms in the gastrointestinal tract can disseminate via the bloodstream and cause polymicrobial sepsis with an even greater mortality32,33,34. As most nosocomial candidemia cases emerge from contaminated central line catheters or indwelling medical devices35,36, i.v. inoculation with C. albicans by tail vein injection can closely mirror human sepsis development and has been a staple method in a mouse model of hematogenously disseminated candidiasis37,38. In this model, mortality that occurs in days can be extended or shortened by adjusting the C. albicans i.v. inoculum39,40,41.
Recently, our laboratory has developed an innovative protocol for an optimally streamlined tail vein injection using an innovative device equipped with a thermoregulated warming unit, paired with an adjustable restraining unit, in one convenient system. This protocol allows researchers to perform tail vein injections in an accurate and timely manner, while animals can be safely conditioned and restrained for the procedure with minimal distress. The techniques demonstrated here, with the use of the advanced warming and restraining device, could serve as a useful tool in various research areas employing rodent models.

<table>
	<tbody>
		<tr>
			<td>Candida albicans strain DAY185</td>
			<td>Carnegie Melon University</td>
			<td>N/A</td>
			<td>provided by the laboratory of Aaron Mitchell</td>
		</tr>
		<tr>
			<td>Candida albicans strain efg1&#916;/&#916; cph1&#916;/&#916;</td>
			<td>University of Tennessee Health Sciences Center</td>
			<td>N/A</td>
			<td>provided by the laboratory of Glen Palmer</td>
		</tr>
		<tr>
			<td>Candida dubliniensis strain W&#252;284</td>
			<td>Trinity College, Dublin, Ireland</td>
			<td>N/A</td>
			<td>provided by the laboratory of Gary Moran</td>
		</tr>
		<tr>
			<td>Mice</td>
			<td>Charles River Laboratories</td>
			<td>551NCICr:SW</td>
			<td>Female Swiss Webster; 6-8 weeks old</td>
		</tr>
		<tr>
			<td>Mice</td>
			<td>Charles River Laboratories</td>
			<td>556NCIC57BL/6</td>
			<td>Female C57BL/6; 6-8 weeks old</td>
		</tr>
		<tr>
			<td>Needles, 27G, &#189;-in</td>
			<td>Becton Dickinson</td>
			<td>305109</td>
			<td>can be substituted from other vendors</td>
		</tr>
		<tr>
			<td>Phosphate buffered saline (PBS)</td>
			<td>GE</td>
			<td>SH30028.02</td>
			<td>can be substituted from other vendors</td>
		</tr>
		<tr>
			<td>Rodent warming and restraining device (Mouse a Minute)</td>
			<td>LSU Health</td>
			<td>custom order</td>
			<td>Mouse a Minute is available for custom ordering from LSU Health</td>
		</tr>
		<tr>
			<td>Sabouraud dextrose agar (SDA)</td>
			<td>Becton Dickinson</td>
			<td>211584</td>
			<td>can be substituted from other vendors</td>
		</tr>
		<tr>
			<td>Syringes, 1 mL</td>
			<td>Becton Dickinson</td>
			<td>309659</td>
			<td>can be substituted from other vendors</td>
		</tr>
		<tr>
			<td>Trypan blue solution</td>
			<td>Sigma</td>
			<td>T8154</td>
			<td></td>
		</tr>
		<tr>
			<td>Yeast peptone dextrose (YPD) broth</td>
			<td>Fisher Scientific</td>
			<td>BP2469</td>
			<td>can be substituted from other vendors</td>
		</tr>
	</tbody>
</table>

a contemporary warming/restraining device for efficient tail vein injections in a murine fungal sepsis model

In rodent models, tail vein injections are important methods for intravenous administration of experimental agents. Tail vein injections typically involve warming of the animal to promote vasodilation, which aids in both the identification of the blood vessels and positioning of the needle into the vessel lumen while securely restraining the animal. Although tail vein injections are common procedures in many protocols and are not considered highly technical if performed correctly, accurate and consistent injections are crucial to obtain reproducible results and minimize variability. Conventional methods for inducing vasodilation prior to tail vein injections generally depend on the use of a heat source such as a heat lamp, electrical/rechargeable heat pads, or pre-heated water at 37 &#176;C. Despite being readily accessible in a standard laboratory setting, these tools evidently suffer from poor/limited thermo-regulatory capacity. Similarly, although various forms of restraining devices are commercially available, they must be used carefully to avoid trauma to the animals. These limitations of the current methods create unnecessary variables in experiments or result in varying outcomes between experiments and/or laboratories.
In this article, we demonstrate an improved protocol using an innovative device that combines an independent, thermally regulated, warming device with an adjustable restraining unit into one system for efficient streamlined tail vein injection. The example we use is an intravenous model of fungal bloodstream infection that results in sepsis. The warming apparatus consists of a heat-reflective acrylic box installed with an adjustable automatic thermostat to maintain the internal temperature at a pre-set threshold. Likewise, the width and height of the cone restraining apparatus can be adjusted to safely accommodate various rodent sizes. With the advanced and versatile features of the device, the technique shown here could become a useful tool across a range of research areas involving rodent models that employ tail vein injections.

The temperature inside the warming chamber is continuously detected by the internal sensor and auto-regulated by the thermostat. First, the control dial of the thermostat was positioned at 78, 85, 90, or 95 &#176;F (26, 29, 32, or 95 &#176;C) to select set temperatures. Once the heater was activated (Figure 7, yellow dots), heat emission by the light bulb rapidly raised the internal temperature during the first 5&#8211;15 min, depending on the set temperature. The heater inactivated the light bulb if the detected internal temperature exceeded the set temperature (gray dots). The initial peak temperatures should rise to 5&#8211;7 &#176;C above the set temperatures in all groups to offset the temperature loss during animal transfer. Subsequently, the device continues to repeat the heat cycle automatically and maintains the warming chamber at the set temperature.
An example of experimental data obtained by successful tail vein injections using the current protocol is shown in Figure 8. In a mouse model of bloodstream candidiasis resulting in sepsis, an i.v. challenge with Candida albicans (1 x 105 cells per mouse) in Swiss Webster mice caused a rapid onset of sepsis and dissemination of the organisms, leading to high mortality within 3&#8211;4 days (open dots) (Figure 8A). In contrast, animals could be protected from sepsis by prior i.v. pre-immunization/vaccination with an avirulent yeast strain, Candida dubliniensis, achieving &#62;95% survival following the lethal i.v. challenge with virulent C. albicans (solid dots). These results in progressive mortality vs. vaccine-mediated protection were obtained reproducibly in four independent experiments (Supplemental Figure 1). Similar protection could be achieved using other avirulent yeast strains such as attenuated C. albicans mutants (&#916;efg1/&#916;cph1) (data not shown). Sepsis could be monitored as well and correlated to mortality; the unvaccinated animals with lethal infection had a significant increase in sepsis-induced morbidity, whereas the vaccinated group exhibited minimal symptoms following the lethal challenge (Figure 8B).
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/61961/61961fig01.jpg" />
Figure 1: Description of the rodent warming and restraining device.&#160;(A) shows the exterior view of the warming device, which consists of:
<ol>
	<li>Thermostat cover &#8211; lift upward by the handle to expose the thermostat</li>
	<li>Electrical enclosure &#8211; sealed permanently for protection</li>
	<li>Chamber lid &#8211; lift upward during animal transfer to/from</li>
	<li>Warming chamber &#8211; removable, cover the floor with bedding before use</li>
	<li>Restraint apparatus &#8211; stowable with the heating device while not in use</li>
	<li>Power switch &#8211; inline rocker switch for main on/off functions</li>
	<li>Power cord &#8211; voltage/current: 120V/10A</li>
</ol>
(B) shows the interior of the warming device:
<ol>
	<li>Incandescent light bulb &#8211; light output at 100 Watts</li>
	<li>Light bulb protective shield &#8211; removable for bulb replacement</li>
	<li>Temperature sensor probe &#8211; located inside the chamber</li>
	<li>Internal temperature thermometer &#8211; place inside the chamber for monitoring temperature</li>
</ol>
(C) shows components of the warming device thermostat:
<ol>
	<li>Internal temperature thermometer</li>
	<li>Thermostat &#8211; auto-regulates the heater</li>
	<li>Setpoint control lever &#8211; minimum/maximum: 78 &#176;F/108 &#176;F (25 &#176;C/42 &#176;C)</li>
	<li>Thermostat power indicator &#8211; green light indicates normal operation</li>
	<li>Thermostat heater indicator &#8211; lit red during heating cycle</li>
</ol>
(D) shows components of the restraining device:
<ol>
	<li>Cone &#8211; pliable aluminum sheet designed for rodent restraint</li>
	<li>Tail channel &#8211; shaped to permit smooth positioning of the tail</li>
	<li>Cone lift platform &#8211; provides sturdy lift of the cone base</li>
	<li>Height adjustment knob &#8211; designed for manual height adjustment</li>
	<li>Scissor jack &#8211; height range from 45&#8211;140 mm (1.77-5.52&#8221;)</li>
	<li>Support plate &#8211; installed with rubber feet to provide stability <a href="https://www.jove.com/files/ftp_upload/61961/61961fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a></li>
</ol>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/61961/61961fig02.jpg" />
Figure 2: The rodent warming and restraining device.&#160;(A) Prior to use, the two parts of the device are placed side by side on a clean bench top. (B) Once the warming device is powered on, the thermostat activates the heater. The light bulb remains lit and emits heat until the warming chamber has reached the set temperature. The warming device automatically repeats the heat cycle to maintain the internal temperature. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig02large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/61961/61961fig03.jpg" />
Figure 3: Mice (C57BL/6) placed in the warming and restraining device.&#160;(A) Mice receiving heat treatment for vasodilation. The animals (4&#8211;6 mice per treatment) are transferred from their housing cage into the warming chamber of the device and heat-treated for a minimum of 5&#8211;10 min. (B) A mouse restrained for tail vein injection. The mouse is transferred from the warming chamber into the cone opening of the restraining device with its tail passing through the open slit. The mouse is gently pulled backward to the far edge of the cone until the base of the tail reaches the tip of the cone. As the animal is drawn toward the base of the cone with a gentle lateral rotation, one hind leg is positioned upward so that it protrudes out from the open slit allowing the lateral tail vein to be positioned at 12 o&#8217;clock. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig03large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" class="xfigimg" src="/files/ftp_upload/61961/61961fig04.jpg" />
Figure 4: Identification of the lateral tail veins in mice.&#160;(A) The tail of an untreated Swiss Webster mouse. The mouse is placed in the restraining device without prior heat treatment for vasodilation. The lateral tail vein can be identified as a thin dark vessel that courses under the skin. (B) The tail of a Swiss Webster mouse treated with the warming device for 10 min. The heat-treated mouse is restrained for tail vein injection. The lateral tail vein is readily visible through the skin due to the enlarged vessel diameter induced by vasodilation. (C) The tail of a C57BL/6 mouse treated with the warming device for 10 min and restrained for tail vein injection. Vasodilation enhances visibility of the tail vein through the deeply pigmented skin although the vein is not as readily visible as in the light-colored Swiss Webster mice due to a weak color contrast against the vein. Red arrows denote the location of the lateral tail vein. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig04large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 5" class="xfigimg" src="/files/ftp_upload/61961/61961fig05.jpg" />
Figure 5: Tail vein injection performed in heat-treated mice (Swiss Webster).&#160;(A&#8211;B) Needle insertion into the lateral tail vein at the injection site. The needle (27 G, &#189;-in) is positioned parallel to the tail vein with the bevel up and pointed toward the blood flow and inserted. (C&#8211;D) Needle placement in the tail vein and injection. The tip of the needle is further advanced 2&#8211;4 mm into the lumen of the vein. The thumb is positioned on the plunger of the syringe, and the desired volume is dispensed with slow and steady pressure. Oval circles indicate injection sites. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig05large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 6" class="xfigimg" src="/files/ftp_upload/61961/61961fig06.jpg" />
Figure 6: Post-injection procedure.&#160;(A) A bleeding area at the injection site. Bleeding and backflow of the injected solution occur immediately after needle removal. This can be minimized by applying firm compression on the injection site with the thumb. (B) Blood clot formation at the injection site. Gentle compression with a clean gauze/wipe facilitates blood clotting on the injection wound. Arrows denote injection sites. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig06large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 7" class="xfigimg" src="/files/ftp_upload/61961/61961fig07.jpg" />
Figure 7: The internal temperature of the warming chamber during use.&#160;The warming device was activated for warming at the designated set temperatures. The warming chamber of the device was monitored for the internal air temperature and heat cycles (light bulb on/yellow dots, off/gray dots) were recorded over 45 min. The orange area indicates the optimal temperature range for induction of vasodilation in rodents. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig07large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 8" class="xfigimg" src="/files/ftp_upload/61961/61961fig08.jpg" />
Figure 8: Sepsis mortality vs. vaccine-mediated protection following a lethal challenge with Candida albicans.&#160;Mice (8 week-old Swiss Webster females) were vaccinated intravenously with avirulent live Candida dubliniensis W&#252;284 (Cd), followed by a lethal intravenous challenge with wild-type C. albicans DAY 185 (1 x 105 cells per mouse) 14 days later. (A) Mortality was assessed over 10 days following the lethal challenge. (B) Animals were monitored for sepsis morbidity and scored according to a modified Mouse Clinical Assessment Score for Sepsis (M-CASS)43. Data are cumulative of 4 independent experiments with 10 mice per group and analyzed using the Mantel-Cox log-rank test. **** p &#60; 0.0001. SEM, standard error of the mean. <a href="https://www.jove.com/files/ftp_upload/61961/61961fig08large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
Supplemental Figure 1: Reproducibility of sepsis mortality and vaccine-mediated survival from a bloodstream Candida albicans challenge. Each panel represents data from four independent experiments included in a cumulative result shown in Figure 8A. Each experiment was conducted using 10 mice per group and analyzed using the Mantel-Cox log-rank test. Ca, Candida albicans. Cd, Candida dubliniensis. **** p &#60; 0.0001. *** p &#60; 0.01. <a href="https://cloudflare.jove.com/files/ftp_upload/61961/supfig01.jpg" target="_blank">Please click here to download this figure.</a>

Watch this Scientific Journal Video about A Contemporary Warming/Restraining Device for Efficient Tail Vein Injections in a Murine Fungal Sepsis Model at JoVE.com

A Contemporary Warming/Restraining Device for Efficient Tail Vein Injections in a Murine Fungal Sepsis Model

Here, we present an effective and efficient method for rodent tail vein injections using a uniquely designed warming/restraining device. By streamlining the initiation of vasodilation and restraining processes, this protocol allows accurate and timely intravenous injections of large groups of animals with minimal distress.

In rodent models, tail vein injections are important methods for intravenous administration of experimental agents. Tail vein injections typically involve ...

a-contemporary-warmingrestraining-device-for-efficient-tail-vein

Research

JoVE Journal

Immunology and Infection

13.8K Views.  Louisiana State University Health-School of Dentistry. Here, we present an effective and efficient method for rodent tail vein injections using a uniquely designed warming/restraining device. By streamlining the initiation of vasodilation and restraining processes, this protocol allows accurate and timely intravenous injections of large groups of animals with minimal distress.

Video: A Contemporary Warming/Restraining Device for Efficient Tail Vein Injections in a Murine Fungal Sepsis Model

Colon Ascendens Stent Peritonitis (CASP) - a Standardized Model for Polymicrobial Abdominal Sepsis

Sepsis remains a persistent problem on intensive care units all over the world. Understanding the complex mechanisms of sepsis is the precondition for establishing new therapeutic approaches in this field. Therefore, animal models are required that are able to closely mimic the human disease and also sufficiently deal with scientific questions. The Colon Ascendens Stent Peritonitis (CASP) is a highly standardized model for polymicrobial abdominal sepsis in rodents. In this model, a small stent is surgically inserted into the ascending colon of mice or rats leading to a continuous leakage of intestinal bacteria into the peritoneal cavity. The procedure results in peritonitis, systemic bacteraemia, organ infection by gut bacteria, and systemic but also local release of several pro- and anti-inflammatory cytokines. The lethality of CASP can be controlled by the diameter of the inserted stent. A variant of this model, the so-called CASP with intervention (CASPI), raises opportunity to remove the septic focus by a second operation according to common procedures in clinical practice. CASP is an easily learnable and highly reproducible model that closely mimics the clinical course of abdominal sepsis. It leads way to study on questions in several scientific fields e.g. immunology, infectiology, or surgery.

Colon Ascendens Stent Peritonitis CASP - a Standardized Model for Polymicrobial Abdominal Sepsis

The Colon Ascendens Stent Peritonitis (CASP) is a highly standardized model for polymicrobial abdominal sepsis in rodents. This article describes the surgical procedure of CASP. The CASP model and its variants allow the systematic investigation of various problems concerning the subject of sepsis.

Sepsis remains a persistent problem on intensive care units all over the world. Understanding the complex mechanisms of sepsis is the precondition for ...

Induction of Graft-versus-host Disease and In Vivo T Cell Monitoring Using an MHC-matched Murine Model

Graft-versus-host disease (GVHD) is the limiting barrier to the broad use of bone marrow transplant as a curative therapy for a variety of hematological deficiencies. GVHD is caused by mature alloreactive T cells present in the bone marrow graft that are infused into the recipient and cause damage to host organs. However, in mice, T cells must be added to the bone marrow inoculum to cause GVHD. Although extensive work has been done to characterize T cell responses post transplant, bioluminescent imaging technology is a non-invasive method to monitor T cell trafficking patterns in vivo.
Following lethal irradiation, recipient mice are transplanted with bone marrow cells and splenocytes from donor mice. T cell subsets from L2G85.B6 (transgenic mice that constitutively express luciferase) are included in the transplant. By only transplanting certain T cell subsets, one is able to track specific T cell subsets in vivo, and based on their location, develop hypotheses regarding the role of specific T cell subsets in promoting GVHD at various time points. At predetermined intervals post transplant, recipient mice are imaged using a Xenogen IVIS CCD camera. Light intensity can be quantified using Living Image software to generate a pseudo-color image based on photon intensity (red = high intensity, violet = low intensity).
Between 4-7 days post transplant, recipient mice begin to show clinical signs of GVHD. Cooke et al.1 developed a scoring system to quantitate disease progression based on the recipient mice fur texture, skin integrity, activity, weight loss, and posture. Mice are scored daily, and euthanized when they become moribund. Recipient mice generally become moribund 20-30 days post transplant.
Murine models are valuable tools for studying the immunology of GVHD. Selectively transplanting particular T cell subsets allows for careful identification of the roles each subset plays. Non-invasively tracking T cell responses in vivo adds another layer of value to murine GVHD models.

Induction of Graft-versus-host Disease and In Vivo T Cell Monitoring Using an MHC-matched Murine Model

Murine bone marrow transplantation is a widely used technique to study immunological mechanisms governing graft-versus-host disease in humans. The ability to monitor T cell trafficking patterns in vivo allows for detailed analysis of the development and perpetuation of T cell responses during graft-versus-host disease.

Graft-versus-host disease (GVHD) is the limiting barrier to the broad use of bone marrow transplant as a curative therapy for a variety of hematological ...

Cecal Ligation and Puncture-induced Sepsis as a Model To Study Autophagy in Mice

Experimental sepsis can be induced in mice using the cecal ligation and puncture (CLP) method, which causes polymicrobial sepsis. Here, a protocol is provided to induce sepsis of varying severity in mice using the CLP technique. Autophagy is a fundamental tissue response to stress and pathogen invasion. Two current protocols to assess autophagy in vivo in the context of experimental sepsis are also presented here. (I) Transgenic mice expressing green fluorescence protein (GFP)-LC3 fusion protein are subjected to CLP. Localized enhancement of GFP signal (puncta), as assayed either by immunohistochemical or confocal assays, can be used to detect enhanced autophagosome formation and, thus, altered activation of the autophagy pathway. (II) Enhanced autophagic vacuole (autophagosome) formation per unit tissue area (as a marker of autophagy stimulation) can be quantified using electron microscopy. The study of autophagic responses to sepsis is a critical component of understanding the mechanisms by which tissues respond to infection. Research findings in this area may ultimately contribute towards understanding the pathogenesis of sepsis, which represents a major problem in critical care medicine.

Experimental sepsis can be induced in mice using the cecal ligation and puncture (CLP) method. Current protocols to assess autophagy in vivo in the context of CLP-induced sepsis are presented here: A protocol for measuring autophagy using (GFP)-LC3 mice, and a protocol for measuring autophagosome formation by electron microscopy.

Experimental sepsis can be induced in mice using the cecal ligation and puncture (CLP) method, which causes polymicrobial sepsis. Here, a protocol is ...

Transplantation of Tail Skin to Study Allogeneic CD4 T Cell Responses in Mice

The study of T cell responses and their consequences during allo-antigen recognition requires a model that enables one to distinguish between donor and host T cells, to easily monitor the graft, and to adapt the system in order to answer different immunological questions. Medawar and colleagues established allogeneic tail-skin transplantation in mice in 1955. Since then, the skin transplantation model has been continuously modified and adapted to answer specific questions. The use of tail-skin renders this model easy to score for graft rejection, requires neither extensive preparation nor deep anesthesia, is applicable to animals of all genetic background, discourages ischemic necrosis, and permits chemical and biological intervention.
In general, both CD4+ and CD8+ allogeneic T cells are responsible for the rejection of allografts since they recognize mismatched major histocompatibility antigens from different mouse strains. Several models have been described for activating allogeneic T cells in skin-transplanted mice. The identification of major histocompatibility complex (MHC) class I and II molecules in different mouse strains including C57BL/6 mice was an important step toward understanding and studying T cell-mediated alloresponses. In the tail-skin transplantation model described here, a three-point mutation (I-Abm12) in the antigen-presenting groove of the MHC-class II (I-Ab) molecule is sufficient to induce strong allogeneic CD4+ T cell activation in C57BL/6 mice. Skin grafts from I-Abm12 mice on C57BL/6 mice are rejected within 12-15 days, while syngeneic grafts are accepted for up to 100 days. The absence of T cells (CD3-/- and Rag2-/- mice) allows skin graft acceptance up to 100 days, which can be overcome by transferring 2 x 104 wild type or transgenic T cells. Adoptively transferred T cells proliferate and produce IFN-&#947; in I-Abm12-transplanted Rag2-/- mice.

Tail-skin transplantation is a powerful model for studying T cell-dependent rejection and tolerance induction during allogeneic immune responses in mice. The advantages of this protocol are minor invasive surgery, and ease of monitoring with no need to sacrifice the recipient mouse.

The study of T cell responses and their consequences during allo-antigen recognition requires a model that enables one to distinguish between donor and ...

A Simple and Efficient Approach to Construct Mutant Vaccinia Virus Vectors

The CRISPR-associated endonuclease Cas9 can edit particular genomic loci directed by a single guide RNA (gRNA). The CRISPR/Cas9 system has been successfully employed for editing genomes of various organisms. Here we describe a protocol for editing the vaccinia virus (VV) genome in the cytoplasm of VV-infected CV-1 cells using the RNA-guided Cas9. RNA-guided Cas9 induces double-stranded DNA breaks facilitating homologous recombination efficiently and specifically in the targeted site of VV and a transgene can be incorporated into these sites by homologous recombination. By using a site-specific homologous vector with transgene(s), a N1L gene-deleted VV with the red fluorescence protein (RFP) gene incorporated in this region was generated with a successful recombination efficiency 10 times greater than that obtained from the conventional homologous recombination method. This protocol demonstrates successful use of RNA-guided Cas9 system to generate mutant VVs with enhanced efficiency.

Vaccinia virus (VV) has been widely used in biomedical research and the improvement of human health. This article describes a simple, highly efficient method to edit the VV genome using a CRISPR-Cas9 system.

The CRISPR-associated endonuclease Cas9 can edit particular genomic loci directed by a single guide RNA (gRNA). The CRISPR/Cas9 system has been ...

A Murine Model of Group B Streptococcus Vaginal Colonization

Streptococcus agalactiae (group B Streptococcus, GBS), is a Gram-positive, asymptomatic colonizer of the human gastrointestinal tract and vaginal tract of 10 - 30% of adults. In immune-compromised individuals, including neonates, pregnant women, and the elderly, GBS may switch to an invasive pathogen causing sepsis, arthritis, pneumonia, and meningitis. Because GBS is a leading bacterial pathogen of neonates, current prophylaxis is comprised of late gestation screening for GBS vaginal colonization and subsequent peripartum antibiotic treatment of GBS-positive mothers. Heavy GBS vaginal burden is a risk factor for both neonatal disease and colonization. Unfortunately, little is known about the host and bacterial factors that promote or permit GBS vaginal colonization. This protocol describes a technique for establishing persistent GBS vaginal colonization using a single &#946;-estradiol pre-treatment and daily sampling to determine bacterial load. It further details methods to administer additional therapies or reagents of interest and to collect vaginal lavage fluid and reproductive tract tissues. This mouse model will further the understanding of the GBS-host interaction within the vaginal environment, which will lead to potential therapeutic targets to control maternal vaginal colonization during pregnancy and to prevent transmission to the vulnerable newborn. It will also be of interest to increase our understanding of general bacterial-host interactions in the female vaginal tract.

A Murine Model of Group B Streptococcus Vaginal Colonization

The purpose of this protocol is to imitate human group B Streptococcus (GBS) vaginal colonization in a murine model. This method may be used to investigate host immune responses and bacterial factors contributing to GBS vaginal persistence, as well as to test therapeutic strategies.

Streptococcus agalactiae (group B Streptococcus, GBS), is a Gram-positive, asymptomatic colonizer of the human gastrointestinal tract and vaginal tract of ...

Stenosis of the Inferior Vena Cava: A Murine Model of Deep Vein Thrombosis

Deep vein thrombosis (DVT) and its devastating complication, pulmonary embolism, are a severe health problem with high mortality. Mechanisms of thrombus formation in veins remain obscure. Lack of mobility (e.g., after surgery or long-haul flights) is one of the main factors leading to DVT. The pathophysiological consequence of the lack of mobility is blood flow stagnation in venous valves. Here, a model is described that mimics such flow disturbance as a thrombosis-driving factor. In this model, partial flow restriction (stenosis) in the inferior vena cava (IVC) is created. Closure of about 90% of the IVC lumen for 48 h results in development of thrombi structurally similar to those in humans. The similarities are: i) most of the thrombus volume is red, i.e., consists of red blood cells and fibrin, ii) presence of a white part (lines of Zahn), iii) non-denuded endothelial monolayer, iv) elevated plasma D-Dimer levels, and v) possibility to prevent thrombosis by low molecular weight heparin. Limitations include variable size of thrombi and the fact that a certain percentage of wild-type mice (0 - 35%) may not produce a thrombus. In addition to visual observation and measurement, thrombi may be visualized by non-invasive technologies, such as ultrasonography, which allows for monitoring the dynamics of thrombus development. At shorter time points (1 - 6 h), intravital microscopy may be applied to directly observe events (e.g., recruitment of cells to the vessel wall) preceding thrombus formation. Use of this method by several teams around the world has made it possible to uncover basic mechanisms of DVT initiation and identify potential targets that might be beneficial for its prevention.

We describe here stenosis in the inferior vena cava as a murine model of deep vein thrombosis. This model recapitulates blood flow restriction, one of the major triggers of venous thrombosis in humans.

Deep vein thrombosis (DVT) and its devastating complication, pulmonary embolism, are a severe health problem with high mortality. Mechanisms of thrombus ...

Deep Vein Thrombosis Induced by Stasis in Mice Monitored by High Frequency Ultrasonography

Venous thrombosis is a common condition affecting 1 - 2% of the population, with an annual incidence of 1 in 500. Venous thrombosis can lead to death through pulmonary embolism or results in the post-thrombotic syndrome, characterized by chronic leg pain, swelling, and ulceration, or in chronic pulmonary hypertension resulting in significant chronic respiratory compromise. This is the most common cardiovascular disease after myocardial infarction and ischemic stroke and is a clinical challenge for all medical disciplines, as it can complicate the course of other disorders such as cancer, systemic disease, surgery, and major trauma.
Experimental models are necessary to study these mechanisms. The stasis model induces consistent thrombus size and a quantifiable amount of thrombus. However, it is necessary to systematically ligate side branches of the inferior vena cava to avoid variability in thrombus sizes and any erroneous data interpretation. We have developed a non-invasive technique to measure thrombus size using ultrasonography. Using this technique, we can assess thrombus development and resolution over time in the same animal. This approach limits the number of mice required for quantification of venous thrombosis consistent with the principle of replacement, reduction, and refinement of animals in research. We have demonstrated that thrombus weight and histological analysis of thrombus size correlate with measurement obtained with ultrasonography. Therefore, the current study describes how to induce deep vein thrombosis in mice using the inferior vena cava stasis model and how to monitor it using high frequency ultrasound.

The present protocol describes the steps to obtain venous thrombosis using a stasis model. In addition, we are using a non-invasive method to measure thrombus formation and resolution over time.

Venous thrombosis is a common condition affecting 1 - 2% of the population, with an annual incidence of 1 in 500. Venous thrombosis can lead to death ...

In Vivo Imaging of Reactive Oxygen Species in a Murine Wound Model

The generation of reactive oxygen species (ROS) is a hallmark of inflammatory processes, but in excess, oxidative stress is widely implicated in various pathologies such as cancer, atherosclerosis and diabetes. We have previously shown that dysfunction of the Nuclear factor (erythroid-derived 2)-like 2 (Nrf2)/ Kelch-like erythroid cell-derived protein 1 (Keap1) signaling pathway leads to extreme ROS imbalance during cutaneous wound healing in diabetes. Since ROS levels are an important indicator of progression of wound healing, specific and accurate quantification techniques are valuable. Several in vitro assays to measure ROS in cells and tissues have been described; however, they only provide a single cumulative measurement per sample. More recently, the development of protein-based indicators and imaging modalities have allowed for unique spatiotemporal analyses. L-012 (C13H8ClN4NaO2) is a luminol derivative that can be used for both in vivo and in vitro chemiluminescent detection of ROS generated by NAPDH oxidase. L-012 emits a stronger signal than other fluorescent probes and has been shown to be both sensitive and reliable for detecting ROS. The time lapse applicability of L-012-facilitated imaging provides valuable information about inflammatory processes while reducing the need for sacrifice and overall reducing the number of study animals. Here, we describe a protocol utilizing L-012-facilitated in vivo imaging to quantify oxidative stress in a model of excisional wound healing using diabetic mice with locally dysfunctional Nrf2/Keap1.

In Vivo Imaging of Reactive Oxygen Species in a Murine Wound Model

We describe a non-invasive in vivo imaging protocol that is streamlined and cost-effective, utilizing L-012, a chemiluminescent luminol-analog, to visualize and quantify reactive oxygen species (ROS) generated in a mouse excisional wound model.

The generation of reactive oxygen species (ROS) is a hallmark of inflammatory processes, but in excess, oxidative stress is widely implicated in various ...

A Controlled Mouse Model for Neonatal Polymicrobial Sepsis

Neonatal sepsis remains a global burden. A preclinical model to screen effective prophylactic or therapeutic interventions is needed. Neonatal mouse polymicrobial sepsis can be induced by injecting cecal slurry intraperitoneally into day of life 7 mice and monitoring them for the following week. Presented here are the detailed steps necessary for the implementation of this neonatal sepsis model. This includes making a homogeneous cecal slurry stock, diluting it to a weight- and litter-adjusted dose, an outline of the monitoring schedule, and a definition of observed health categories used to define humane endpoints. The generation of a homogeneous cecal slurry stock from pooled donors allows for the administration into many litters over time, reducing the variation between donors, and preventing the use of potentially toxic glycerol. The monitoring strategy used allows for the anticipation of survival outcome and the identification of mice that would later progress to death, allowing for an earlier identification of the humane endpoint. Two main behavioral features are used to define the health scores, namely, the ability of the neonatal mice to right themselves when placed on their back and their level of mobility. These criteria could potentially be applied to address humane endpoints in other studies of neonatal disease in mice, as long as a pilot study is performed to confirm accuracy. In conclusion, this approach provides a standardized method to model newborn sepsis in mice, while providing resources to assess animal welfare used to define early humane endpoints for challenged animals.

This protocol provides the necessary steps to establish and evaluate neonatal sepsis in 7-day-old mice.

Neonatal sepsis remains a global burden. A preclinical model to screen effective prophylactic or therapeutic interventions is needed. Neonatal mouse ...
