The authors thank Tom Yohannan for the editorial advice and M. Segura-Feliu for the technical assistance. This work was funded by the CERCA Programme and by the Commission for Universities and Research of the Department of Innovation, Universities, and Enterprise of the Generalitat de Catalunya (SGR2017-648). This work was funded by the Spanish Ministry of Research, Innovation and University (MEICO) through BFU2015-67777-R and and RTI2018-099773-B-100, the Spanish Prion Network (Prionet Spain AGL2017-90665-REDT), and the Institute Carlos III, CIBERNED (PRY-2018-2).

All animal experiments were performed under the guidelines and protocols of the Ethical Committee for Animal Experimentation (CEEA) of the University of Barcelona, and the protocol for the use of rodents in this study was reviewed and approved by the CEEA of the University of Barcelona (CEEA approval #276/16 and 141/15).&#160;
1. Purification of Rat Tail Collagen
<ol>
	<li>Collect adult Sprague-Dawley rat tails (8-9 weeks old) after sacrificing the animal following ethical guidelines and rinse in 95% ethanol. Place 2-4 tails on ice (4 &#176;C) and keep them covered with ice during the process. &#160;</li>
	<li>To obtain tail tendons, fix the tail at the most caudal vertebrae of the tail using a hemostat and compress the tail with a second hemostat positioned around 5-7 mm from the first. Break the tail by twisting it sharply with both hemostats. To do this, fold/unfold the vertebrae several times until it breaks.</li>
	<li>Pull the vertebrae slowly with the hemostat to detach the tendons from their sheath as it comes out. At this moment, cut tendons with small scissors. Keep these tendon pieces in a sterile 100 mm Petri dish on ice.</li>
	<li>Repeat the clamping and sliding for the rest of the tail&#160;until the tendons are totally extracted.</li>
	<li>Repeat steps 1.2-1.4 for all the obtained tails.</li>
	<li>Observe the tendons under a microscope. Discard blood vessels by cutting with small scissors and holding with straight fine forceps to improve the tendon&#8217;s purity and rinse the tendons 3 times with ultrapure water.</li>
	<li>Collect 3-4 g of wet tendons. Dissolve the tendons in 150 mL of 3% glacial acetic acid at 4 &#176;C in a 200-250 mL glass conical flask for 24-36 h, under gentle stirring.</li>
	<li>Centrifuge at 20,000 x g for 1 h. In parallel, prepare the dialysis tubing membrane by cutting a piece of around 10-15 cm in length and boil it in ultrapure water containing 1 mM ethylenediaminetetraacetic acid (EDTA) for 15 min. Thereafter, gently rinse the dialysis membrane thoroughly with ultrapure water.</li>
	<li>After centrifugation, collect the supernatant in the dialysis tubing membrane by decantation. The pellet contains acidic insoluble material (non-collagenous proteins) and the supernatant contains soluble collagen proteins.</li>
	<li>Dialyze the supernatant against 2 L of sterile 0.1x Minimum Essential Medium Eagle (MEM), pH 4.0 in a 2-5 L glass beaker. Dialyze for 3 days. Change 0.1x MEM solution at least twice a day checking the pH at every change before using. If pH has turned basic, modify it with a few drops of 0.1 M acetic acid until pH is 4.0.</li>
	<li>After dialysis, add antibiotics (1.5 mL of penicillin/streptomycin (Pen-Strep)) to the dialyzed collagen solution. Make 5 mL aliquots of the collagen stock solution and store at 4 &#176;C.
	NOTE: From this point, all handling procedures must be performed under sterile conditions in a laminar flow hood.</li>
	<li>Proceed with the gelation test of the prepared collagen stock solution following the next steps.
	<ol>
		<li>Since the stock collagen is usually too concentrated, prepare 3 working dilutions (75%, 50%, and 25% collagen solution) by diluting the stock in 0.1x MEM, pH 4.0. The final volume recommended for each working dilution is 5 mL. In each condition, check the protein concentration using a protein colorimetric assay.</li>
		<li>Place several empty 1.5 mL conical centrifuge tubes (one for each working dilution), 10x MEM tubes, 7.5% sodium bicarbonate solution and different working dilutions of collagen on ice. Wait until these are cooled.</li>
		<li>Add 40-50 &#181;L of 10x MEM to a cold (4 &#176;C) centrifuge tube. Next, mix it gently with 7-8 &#956;L of sodium bicarbonate solution.</li>
		<li>Add 310-330 &#956;L of one of the different collagen dilutions to this tube and mix it gently with the pipette avoiding any bubble formation. Keep the collagen-MEM-sodium bicarbonate mixture on ice (4 &#176;C) for at least 5 min.</li>
		<li>Pipette 10-25 &#956;L of the mixture into a 35 mm Petri dish.</li>
		<li>Place the Petri dish in the CO2 incubator set at 37 &#176;C until the gelation of the hydrogel (&#177; 15-20 min) is observed.</li>
		<li>Repeat steps 1.12.3-1.12.6 for the remaining collagen dilutions in different Petri dishes.</li>
		<li>Select the collagen working dilution that renders the best results.
		NOTE: The best gelled hydrogel should have a uniform translucent texture, grey color and should not be lumpy or stringy. In our experience, a dilution of 3:1 (Collagen: 0.1x MEM) generates the best experimental results.</li>
	</ol>
	</li>
</ol>
2. Preparation of Cell (COS1) Aggregates Genetically-modified to Secrete a Candidate Molecule in 3-D Collagen Hydrogels
<ol>
	<li>Plate 2 x 106&#160;COS1 cells into a 35 mm Petri dishes and incubate with complete culture medium composed of 100 mL of D-MEM containing 10% (vol/vol) heat-inactivated fetal bovine serum, 0.5% (wt/vol) glutamine and 1% (wt/vol) Pen/Strep in a cell culture&#160;incubator, in order to reach 70-80% confluency overnight. Prepare one Petri dish for each transfection procedure.</li>
	<li>The following day transfect COS1 cells with the DNA encoding the candidate molecule (Netrin-1 or Sema3E) using liposome-based transfection method following the manufacturer&#39;s instructions.
	<ol>
		<li>To do this, mix 250 &#181;L of serum-free medium and DNA (1-2 &#956;g per condition) to a 1.5 mL centrifuge tube (DNA tube) and mix. Incubate at room temperature (RT) for 5 min. Prepare a second tube (liposomal tube) by adding 240 &#181;L of the serum-free medium and 10 &#181;L of the liposomal transfection reagent. Incubate at RT for 5 min.</li>
		<li>After incubation, add the content of the DNA-tube to the liposomal tube and mix gently. Now incubate at RT for 15 min. Replace the medium on the cultured cells with 1.5 mL of the serum-free medium and add the DNA-liposomes mixture to the Petri dish slowly dropwise. Incubate for 3 h in the CO2 cell culture incubator.</li>
	</ol>
	</li>
	<li>After 3 h of transfection incubation, replace the medium with the complete culture medium and incubate overnight in the incubator.</li>
	<li>Next day, rinse the cells with 0.1 M Dulbecco&#8217;s phosphate buffered saline (D-PBS), treat cultures with Trypsin-EDTA (800 &#181;L per each dish for 5-15 min in the CO2 incubator) and collect detached cells with 15 mL of complete culture medium.</li>
	<li>Centrifuge the cells at 4 &#176;C at 130 x g for 5 min. After centrifugation, remove media and preserve the pellet containing COS1 cells on ice.</li>
	<li>Repeat steps 1.12.3-1.12.6 to prepare the collagen working mixture.</li>
	<li>Add 100-150 &#956;L of the collagen mixture to the pellet of the transfected cells and mix gently by pipetting up and down and spread 45-50 &#181;L of this mixture onto a Petri dish (35 mm diameter) to form a uniform band of collagen-cells of around 1-1.5 cm in length. Place the dish in the incubator at 37 &#176;C (5% CO2) until the gelation (&#177; 15-20 min) is observed.</li>
	<li>Prepare a second strip containing control cells (mock transfection) in a second culture dish and plate it in the incubator (&#177; 15-20 min) and when gelation is completed add 3-4 mL of warmed (37 &#176;C) COS1 complete culture medium to each dish containing the gelled collagen-cells strips and keep them in the CO2 cell culture incubator. Thereafter, cut the collagen-cells strips to generate small square pieces (400 to 500 &#181;m in length) using a fine scalpel or a tissue chopper.</li>
	<li>Transfer all the sections from the same transfection condition to a Petri dish containing 3-3.5 mL of neuronal culture media (NCM) and check under a dissection microscope the quality of the pieces. Again, keep them in the CO2 cell culture incubator.
	NOTE: Neuronal culture medium consists of Neurobasal medium containing 1-5% (vol/vol) heat-inactivated horse serum, 2 mM glutamine, 0.5% (wt/vol) glucose, 1% (wt/vol) Pen-Strep solution and 0.044% (wt/vol) NaHCO3. Ensure that the pH is between 7.2-7.3.</li>
</ol>
3. Generation of Embryonic Explant for Culture
<ol>
	<li>Sterilize the surgical tools (scissors, scalpel blade handle, straight and curved forceps) by autoclaving following routine sterilization guidelines. In parallel prepare 500 mL of Hank&#8217;s balanced salt solution-glucose buffer and 4-5 Petri dishes (100 mm diameter) containing 10 mL of HBSS-G. Place these plates on ice (4 &#176;C).</li>
	<li>Sacrifice the pregnant female rat (embryonic day 16.5) outside the sterile area, following the approved ethical procedures. Cut the embryo horns with scissors from the abdominal cavity and place it into a large Petri dish containing cold HBSS-G.</li>
	<li>Place the dish in the laminar flow hood and extract the embryos with straight forceps. Place them into a new dish containing cold HBSS-G. Next, remove the skin of the embryo using small forceps and carefully dissect the brain using the curved and straight forceps. Place them into a dish containing cold HBSS-G.</li>
	<li>Under a dissecting microscope, cut the brain in half along the midline to separate both the hemispheres with the scalpel or fine scissors and remove the diencephalon, the meninges and blood vessels from the brain pieces with fine forceps.</li>
	<li>Repeat steps 3.3-3.4&#160;with the rest of the embryos. Do not delay the dissection for more than 2 h to preserve the tissue quality.</li>
	<li>Clean all parts of the tissue chopper with 100% ethanol (especially the polytetrafluoroethylene (PTFE) cutting plate and the razor blade). Keep the tissue chopper in the laminar flux hood under UV illumination for 15 min.</li>
	<li>Transfer each tissue piece (e.g., cortex with hippocampus) to the cutting plate of the tissue chopper. For hippocampus, place it perpendicular to the razor blade and obtain tissue sections of 450-500 &#181;m in thickness.</li>
	<li>Prepare several 35 mm Petri dishes with 3-4 mL of complete NCM and transfer tissue pieces from the tissue chopper plate to the Petri dishes. Many dishes may be needed as regions of interest are dissected.</li>
	<li>Finish the tissue dissection in the complete NCM using fine tungsten needles. Check the quality of the obtained slices under the dissecting microscope. Ensure that the layers are clearly identifiable in the darkfield optics&#160;and dissect the region of interest (e.g., CA region of the hippocampus) with tungsten needles. Discard damaged slices. Keep hippocampal explants in complete NCM medium in the CO2 incubator.</li>
</ol>
4. Preparation of 3-D Co-cultures in Collagen Hydrogels
<ol>
	<li>Place several sterile 4-well culture plates in the laminar flow hood and prepare a collagen working mixture as previously indicated in steps 1.12.2-1.12.6.</li>
	<li>Place 15-20 &#956;L of the hydrogel mixture into the bottom of a well to produce a circular collagen base. Repeat this step for the rest of the wells. Do not prepare more than five plates at the same time to avoid excessive liquid evaporation from the hydrogel base.</li>
	<li>Keep the dishes in the incubator until the complete gelation (&#177; 15-20 min) is observed and take the plates out of the incubator only when the gelation is completed. Check the quality of the gelled collagen.</li>
	<li>Transfer a small piece of COS1 cell aggregate with a pipette. Place it onto the hydrogel base and place a tissue piece on the same base with a pipette close to the piece of cells aggregate at one explant-size.</li>
	<li>Prepare a new working collagen mixture on ice as in steps 1.12.2-1.12.6.</li>
	<li>Gently pipette 15-20 &#956;L of this new mixture and cover the explant and cell aggregate. A sandwich-like hydrogel culture will be observed. At this moment, re-orientate the explant with a fine tungsten needle (do not touch the COS1 cell aggregate!), so it faces the cell aggregate at &#177; 500-600 &#956;m.</li>
	<li>Return the plate to the incubator until the gelation is observed (&#177; 10-15 min), and 0.5 mL of complete NCM supplemented with 2% B27 supplement and keep cultures for 36 to 48 h in the incubator (37 &#176;C, 5% CO2).</li>
</ol>
5. Fixation of Explant-cell Aggregate Co-cultures and Immunocytochemical Procedure
<ol>
	<li>After 36-48 h of incubation, remove the medium and rinse with 0.1 M phosphate buffered saline (PBS), pH 7.3. Thereafter, fix the cultures for 1 h with 4% paraformaldehyde in 0.1 M phosphate buffer (PB), pH 7.3, at 4 &#176;C.</li>
	<li>Remove the fixative and gently rinse the cultures 3-4 times (10-15 min each) in 0.1 M PB, pH 7.3.</li>
	<li>Detach the hydrogel sandwich from the bottom of the well with spatula or forceps. Transfer the collagen block with a fine paintbrush to a 6-well culture plate containing 0.1 M PBS with 0.5% non-ionic detergent.</li>
	<li>Incubate free-floating hydrogels in the blocking solution (10% serum, 0.5% non-ionic surfactant, and 0.2% gelatin in 0.1 M PBS) for 2-3 h at RT with gentle agitation.</li>
	<li>Rinse 3 times (10-15 min each) with 0.1 M PBS containing 0.5% non-ionic surfactant.</li>
	<li>Incubate with primary antibody diluted in PBS containing 5% serum, 0.5% non-ionic surfactant, 0.2% gelatin, and 0.02% sodium azide. Incubate with the primary antibody for 36-48 h at 4 &#176;C on a shaker.
	NOTE: Usually an antibody against class III &#946;-tubulin (&#945;-TUJ-1) (diluted 1:2,000) is used to define axonal growth in 3-D hydrogel cultures.</li>
	<li>After incubation, rinse as in step 5.5.</li>
	<li>Incubate with secondary antibody for 4 h at RT (or 6-7 h at 4 &#176;C) on a shaker diluted in 5% serum, 0.5% non-ionic surfactant, and 0.2% gelatin. A horse anti-mouse biotinylated antibody (diluted 1:200) is used in this experiment.</li>
	<li>Rinse cultures as in 5.5.</li>
	<li>Incubate the cultures for 2 days at 4 &#176;C with avidin-biotin complex (ABC) solution 1:100 diluted in PBS containing 5% serum, 0.5% non-ionic surfactant, and 0.2% gelatin. Alternatively, use horseradish peroxidase (HRP)-tagged streptavidin (diluted 1:300-400) in the same buffer.</li>
	<li>Rinse cultures as described in 5.5.</li>
	<li>Rinse the cultures several times with 0.1 M Tris-HCl buffer, pH 7.6 for 1 h.</li>
	<li>Incubate the cultures with 0.03% of 3,3&#8242;-Diaminobenzidine tetrahydrochloride (DAB) solution in 0.1 M Tris-HCl, pH 7.6.</li>
	<li>Add 5-8 &#181;L of 1% H2O2 and wait 10-15 min. Monitor the development of DAB under a microscope using a 4-10x objective.</li>
	<li>Stop the reaction by removing DAB solution with 0.1 M Tris-HCl buffer, pH 7.6.</li>
	<li>Rinse the cultures in PBS for 30 min (several changes).</li>
	<li>Mount the hydrogels onto glass slides using aqueous-based mounting media.</li>
	<li>Analyze the length and distribution of the axons inside the hydrogel using Sholl analysis plug-in or with NeuriteJ plug-in for ImageJ software30.</li>
</ol>

<ol>
	<li>Ram&#243;n y Cajal, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Les nouvelles id&#233;es sur la structure du syst&#232;me nerveux chez l'homme et chez les vert&#233;br&#233;s. , (1894).</li><li>Ram&#243;n y Cajal, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Nuevo concepto de la histolog&#237;a de los centros nerviosos. , (1893).</li><li>Marin, O., Valiente, M., Ge, X., Tsai, L. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Guiding+neuronal+cell+migrations.">Guiding neuronal cell migrations.</a> Cold Spring Harbor Perspectives in Biology. 2 (2), 001834 (2010).</li><li>Tessier-Lavigne, M., Goodman, C. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+molecular+biology+of+axon+guidance.">The molecular biology of axon guidance.</a> Science. 274 (5290), 1123-1133 (1996).</li><li>Dickson, B. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+mechanisms+of+axon+guidance.">Molecular mechanisms of axon guidance.</a> Science. 298 (5600), 1959-1964 (2002).</li><li>Kolodkin, A. L., Tessier-Lavigne, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+and+molecules+of+neuronal+wiring:+a+primer.">Mechanisms and molecules of neuronal wiring: a primer.</a> Cold Spring Harbor Perspectives in Biology. 3 (6), 001727 (2011).</li><li>Rosentreter, S. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Response+of+retinal+ganglion+cell+axons+to+striped+linear+gradients+of+repellent+guidance+molecules.">Response of retinal ganglion cell axons to striped linear gradients of repellent guidance molecules.</a> Journal of Neurobiology. 37 (4), 541-562 (1998).</li><li>Knoll, B., Weinl, C., Nordheim, A., Bonhoeffer, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stripe+assay+to+examine+axonal+guidance+and+cell+migration.">Stripe assay to examine axonal guidance and cell migration.</a> Nature Protocols. 2 (5), 1216-1224 (2007).</li><li>von Philipsborn, A. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Growth+cone+navigation+in+substrate-bound+ephrin+gradients.">Growth cone navigation in substrate-bound ephrin gradients.</a> Development. 133 (13), 2487-2495 (2006).</li><li>Chen, H., He, Z., Tessier-Lavigne, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Axon+guidance+mechanisms:+semaphorins+as+simultaneous+repellents+and+anti-repellents.">Axon guidance mechanisms: semaphorins as simultaneous repellents and anti-repellents.</a> Nature Neuroscience. 1 (6), 436-439 (1998).</li><li>Jessell, T. M., Sanes, J. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Development.+The+decade+of+the+developing+brain.">Development. The decade of the developing brain.</a> Current Opinion in Neurobiology. 10 (5), 599-611 (2000).</li><li>Serafini, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+netrins+define+a+family+of+axon+outgrowth-promoting+proteins+homologous+to+C.+elegans+UNC-6.">The netrins define a family of axon outgrowth-promoting proteins homologous to C. elegans UNC-6.</a> Cell. 78 (3), 409-424 (1994).</li><li>Charron, F., Tessier-Lavigne, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+brain+wiring+functions+for+classical+morphogens:+a+role+as+graded+positional+cues+in+axon+guidance.">Novel brain wiring functions for classical morphogens: a role as graded positional cues in axon guidance.</a> Development. 132 (10), 2251-2262 (2005).</li><li>Fournier, M. F., Sauser, R., Ambrosi, D., Meister, J. J., Verkhovsky, A. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Force+transmission+in+migrating+cells.">Force transmission in migrating cells.</a> Journal of Cell Biology. 188 (2), 287-297 (2010).</li><li>Dent, E. W., Gertler, F. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cytoskeletal+dynamics+and+transport+in+growth+cone+motility+and+axon+guidance.">Cytoskeletal dynamics and transport in growth cone motility and axon guidance.</a> Neuron. 40 (2), 209-227 (2003).</li><li>Lowery, L. A., Van Vactor, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+trip+of+the+tip:+understanding+the+growth+cone+machinery.">The trip of the tip: understanding the growth cone machinery.</a> Nature Reviews Molecular Cell Biology. 10 (5), 332-343 (2009).</li><li>Castellani, V. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Protocols for Neuronal Cell Culture. , (2001).</li><li>Gahwiler, B. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Organotypic+monolayer+cultures+of+nervous+tissue.">Organotypic monolayer cultures of nervous tissue.</a> Journal of Neuroscience Methods. 4 (4), 329-342 (1981).</li><li>Bornstein, M. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reconstituted+rattail+collagen+used+as+substrate+for+tissue+cultures+on+coverslips+in+Maximow+slides+and+roller+tubes.">Reconstituted rattail collagen used as substrate for tissue cultures on coverslips in Maximow slides and roller tubes.</a> Laboratory Investigation. 7 (2), 134-137 (1958).</li><li>Billings-Gagliardi, S., Wolf, M. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+simple+method+for+examining+organotypic+CNS+cultures+with+Nomarski+optics.">A simple method for examining organotypic CNS cultures with Nomarski optics.</a> In Vitro. 13 (6), 371-377 (1977).</li><li>Bell, E., Ivarsson, B., Merrill, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Production+of+a+tissue-like+structure+by+contraction+of+collagen+lattices+by+human+fibroblasts+of+different+proliferative+potential+in+vitro.">Production of a tissue-like structure by contraction of collagen lattices by human fibroblasts of different proliferative potential in vitro.</a> Proceedings of the National Academy of Science. 76 (3), 1274-1278 (1979).</li><li>Lumsden, A. G., Davies, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Earliest+sensory+nerve+fibres+are+guided+to+peripheral+targets+by+attractants+other+than+nerve+growth+factor.">Earliest sensory nerve fibres are guided to peripheral targets by attractants other than nerve growth factor.</a> Nature. 306 (5945), 786-788 (1983).</li><li>Chedotal, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Semaphorins+III+and+IV+repel+hippocampal+axons+via+two+distinct+receptors.">Semaphorins III and IV repel hippocampal axons via two distinct receptors.</a> Development. 125 (21), 4313-4323 (1998).</li><li>Kennedy, T. E., Serafini, T., de la Torre, J. R., Tessier-Lavigne, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Netrins+are+diffusible+chemotropic+factors+for+commissural+axons+in+the+embryonic+spinal+cord.">Netrins are diffusible chemotropic factors for commissural axons in the embryonic spinal cord.</a> Cell. 78 (3), 425-435 (1994).</li><li>Klein, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Eph/ephrin+signaling+in+morphogenesis,+neural+development+and+plasticity.">Eph/ephrin signaling in morphogenesis, neural development and plasticity.</a> Current Opinion in Cell Biology. 16 (5), 580-589 (2004).</li><li>Wang, K. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Biochemical+purification+of+a+mammalian+slit+protein+as+a+positive+regulator+of+sensory+axon+elongation+and+branching.">Biochemical purification of a mammalian slit protein as a positive regulator of sensory axon elongation and branching.</a> Cell. 96 (6), 771-784 (1999).</li><li>Emonard, H., Grimaud, J. A., Nusgens, B., Lapiere, C. M., Foidart, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reconstituted+basement-membrane+matrix+modulates+fibroblast+activities+in+vitro.">Reconstituted basement-membrane matrix modulates fibroblast activities in vitro.</a> Journal of Cell Physiology. 133 (1), 95-102 (1987).</li><li>Knapp, D. M., Helou, E. F., Tranquillo, R. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+fibrin+or+collagen+gel+assay+for+tissue+cell+chemotaxis:+assessment+of+fibroblast+chemotaxis+to+GRGDSP.">A fibrin or collagen gel assay for tissue cell chemotaxis: assessment of fibroblast chemotaxis to GRGDSP.</a> Experimental Cell Research. 247 (2), 543-553 (1999).</li><li>Kapur, T. A., Shoichet, M. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Immobilized+concentration+gradients+of+nerve+growth+factor+guide+neurite+outgrowth.">Immobilized concentration gradients of nerve growth factor guide neurite outgrowth.</a> Journal of Biomedical Materials Research Part A. 68 (2), 235-243 (2004).</li><li>Torres-Espin, A., Santos, D., Gonzalez-Perez, F., del Valle, J., Navarro, X. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neurite-J:+an+image-J+plug-in+for+axonal+growth+analysis+in+organotypic+cultures.">Neurite-J: an image-J plug-in for axonal growth analysis in organotypic cultures.</a> Journal of Neuroscience Methods. 236, 26-39 (2014).</li><li>Balestrini, J. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Comparative+biology+of+decellularized+lung+matrix:+Implications+of+species+mismatch+in+regenerative+medicine.">Comparative biology of decellularized lung matrix: Implications of species mismatch in regenerative medicine.</a> Biomaterials. 102, 220-230 (2016).</li><li>Qian, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Kinetic+Analysis+of+the+Digestion+of+Bovine+Type+I+Collagen+Telopeptides+with+Porcine+Pepsin.">Kinetic Analysis of the Digestion of Bovine Type I Collagen Telopeptides with Porcine Pepsin.</a> Journal of Food Science. 81 (1), 27-34 (2016).</li><li>Eyre, D. R., Weis, M., Hudson, D. M., Wu, J. J., Kim, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+novel+3-hydroxyproline+(3Hyp)-rich+motif+marks+the+triple-helical+C+terminus+of+tendon+type+I+collagen.">A novel 3-hydroxyproline (3Hyp)-rich motif marks the triple-helical C terminus of tendon type I collagen.</a> Journal of Biological Chemistry. 286 (10), 7732-7736 (2011).</li><li>Garnotel, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+blood+monocytes+interact+with+type+I+collagen+through+alpha+x+beta+2+integrin+(CD11c-CD18,+gp150-95).">Human blood monocytes interact with type I collagen through alpha x beta 2 integrin (CD11c-CD18, gp150-95).</a> Journal of Immunology. 164 (11), 5928-5934 (2000).</li><li>Montolio, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+semaphorin+3A+inhibitor+blocks+axonal+chemorepulsion+and+enhances+axon+regeneration.">A semaphorin 3A inhibitor blocks axonal chemorepulsion and enhances axon regeneration.</a> Chemistry and Biology. 16 (7), 691-701 (2009).</li><li>Garcia-Gareta, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Collagen+gels+and+the+'Bornstein+legacy':+from+a+substrate+for+tissue+culture+to+cell+culture+systems+and+biomaterials+for+tissue+regeneration.">Collagen gels and the 'Bornstein legacy': from a substrate for tissue culture to cell culture systems and biomaterials for tissue regeneration.</a> Experimental Dermatology. 23 (7), 473-474 (2014).</li></ol>

The authors have nothing to disclose.

The growth of developing axons is mainly invasive and includes ECM degradation and remodeling. Using the procedure presented here, researchers can obtain a homogenous 3-D matrix formed by the natural type I collagen in which axons (or cells) can respond to a chemical gradient secreted by genetically-modified cells as they do in vivo. Different axonal responses to gradients of attractive or inhibitory cues (protein, lipids, etc.) can be easily compared to specific control (mock transfected cells). As advantages, we must m...

Neuronal axons, ending in axonal growth cones, migrate long distances through the extracellular matrix (ECM) of the embryo over specific pathways to reach their appropriate targets. The growth cone is the distal portion of the axon and it is specialized to sense the physical and molecular environment of the cell1,2. From a molecular point of view, growth cones are guided by at least four different molecular mechanisms: contact attraction, chemoattraction, contact repulsion, and chemorepulsion triggered by different axonal guidance cues3,4,5,6. Contact-mediated processes can be partially monitored in two-dimensional (2D) cultures on micro-patterned substrates (e.g., with stripes7,8 or spots9 containing the molecules). However, axons can navigate to their target in a non-diffusive manner by sensing several attractive and repulsive molecules from guidepost cells in the environment4,5,10. Here, we describe an easy method of 3-D culture to check whether a secreted molecule induces chemorepulsive or chemoattractive effects on developing axons.
The earliest studies aimed to determine the effects of axon guidance cues used explant cultures in three-dimensional (3-D) matrices to generate gradients simulating in vivo conditions11,12. This approach, together with in vivo experiments, allowed for the identification of four major families of guidance cues: Netrins, Slits, Semaphorins, and Ephrins4,5,6. These molecular cues and other factors13 are integrated by the growing axons, triggering the dynamics of adhesion complexes and transducing mechanical forces via the cytoskeleton14,15,16. To generate molecular gradients in 3-D cultures for axonal navigation, pioneering researchers used plasma clot substrates17, which was also used for organotypic slice preparations18. However, in 1958, a new protocol to generate 3-D collagen hydrogels was reported for studying with Maximow&#180;s devices19, a culture platform, used in several studies suitable for microscopic observations20. Another pioneer study reported collagen gel as a tool to embed human fibroblasts for studying the differentiation of fibroblasts into myofibroblasts in wound healing processes21. In parallel, Lumsden and Davies applied collagen from the bovine dermis to analyze the putative effect of nerve growth factor (NGF) on the guiding of sensory nerve fibers22. With the development of new culture platforms (e.g., multi-well plates) by different companies and laboratories, collagen cultures were adapted to these new devices6,23,24,25,26. In parallel, an extract of ECM material derived from the Engelbreth-Holm-Swarm tumor cell line was made commercially available to expand these studies27.
Recently, several protocols have been developed to generate molecular gradients with putative roles in axon guidance using 3-D hydrogels (e.g., collagen, fibrin, etc.)28. Alternatively, the candidate molecule can be immobilized at different concentration in a porous matrix (e.g., NGF29) or generated by culturing in a small region of the 3-D hydrogel cell aggregates secreting the molecule to generate a radial gradient4,23,24,25,26. The last possibility will be explained in this protocol.
The procedure presented here is an easy, fast and highly reproducible method based on the analysis of axonal growth in 3-D hydrogel cultures of the embryonic mouse brain. In comparison with other methods, the protocol is well suited for non-trained researchers and can be fully developed after a short training (1-2 weeks). In this protocol, we first isolate collagen from adult rat tails to further generate 3-D matrices in which genetically-modified cell aggregates are cultured in front of the embryonic neuronal tissue. These cell aggregates form radial chemical gradients of a candidate molecule which elicits a response for the growing axons. Finally, the evaluation of the effects of the molecule on growing axons can easily be performed using a phase contrast microscopy or, alternatively, immunocytochemical methods.

<table border="0" cellpadding="0" cellspacing="0" style="width:1176px;" width="1176">
	<colgroup>
		<col />
		<col />
		<col />
		<col />
	</colgroup>
	<tbody>
		<tr height="24">
			<td height="24" style="height:24px;width:455px;">Material</td>
			<td style="width:211px;"></td>
			<td style="width:344px;"></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">3,3&#8242;-Diaminobenzidine tetrahydrochloride 10 mg tablets (DAB)</td>
			<td>Sigma</td>
			<td>D5905</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Adult Sprague-Dawley rats (8 to 9 weeks old)&#160;</td>
			<td>Criffa-Credo, Lyon, France</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">Avidin-biotin-peroxidase complex (ABC)</td>
			<td>Vector Labs</td>
			<td>PK-4000</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="24">
			<td height="24" style="height:24px;">B27 serum-free supplement 50x&#160;</td>
			<td>Invitrogen</td>
			<td>17504-044</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="20">
			<td height="20" style="height:20px;">Bicinchoninic acid (BCA) protein assay kit</td>
			<td>Pierce</td>
			<td>23225</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">cDNA plasmid vectors</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="23">
			<td height="23" style="height:23px;">COS1 cell lines</td>
			<td>ATTC</td>
			<td>CRL-1570</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">D-(+)-Glucose</td>
			<td>Sigma</td>
			<td>16325</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="26">
			<td height="26" style="height:26px;">D-(+)-glucose (45% solution in water) for complete Neurobasal medium</td>
			<td>Sigma</td>
			<td>G8769</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="24">
			<td height="24" style="height:24px;">D-MEM (Dulbecco&#39;s Modified Eagle Medium 1x ) for COS1 culture medium</td>
			<td>Invitrogen</td>
			<td>41966-029</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="27">
			<td height="27" style="height:27px;">Dulbecco&#8217;s phosphate buffered saline 10x (without Ca2+ and Mg2+) (D-PBS) for cultures</td>
			<td>Invitrogen</td>
			<td>14200</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="27">
			<td height="27" style="height:27px;">Ethanol&#160;</td>
			<td>merck</td>
			<td>108543</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">Ethylenediaminetetraacetic acid dihydrate disodium salt (EDTA)</td>
			<td>Sigma</td>
			<td>E5134</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">Fluorescence mounting media (e.g., Fluoromount-G or similar)</td>
			<td>Electron Microscopy Sciences (EMS)</td>
			<td>17984-25</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="24">
			<td height="24" style="height:24px;">Gelatin powder&#160;</td>
			<td>Sigma</td>
			<td>G1890</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="23">
			<td height="23" style="height:23px;">Glacial acetic acid (Panreac, cat. no. 211008)</td>
			<td>Panreac</td>
			<td>211008</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="26">
			<td height="26" style="height:26px;">Hank&#8217;s balanced salt solution&#160;</td>
			<td>Invitrogen</td>
			<td>24020083</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="23">
			<td height="23" style="height:23px;">Heat-inactivated foetal bovine serum&#160;</td>
			<td>Invitrogen</td>
			<td>10108-165</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="22">
			<td height="22" style="height:22px;">Heat-inactivated horse serum&#160;</td>
			<td>Invitrogen</td>
			<td>26050-088</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="23">
			<td height="23" style="height:23px;">Hydrogen peroxide (H2O2, 32 to 33% in water)</td>
			<td>Sigma</td>
			<td>316989</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">L-glutamine 200 mM solution (100x) for complete Neurobasal and COS1 medium</td>
			<td>Invitrogen</td>
			<td>25030-024</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Lipofectamine 2000 Reagent</td>
			<td>Invitrogen</td>
			<td>11668-019</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="27">
			<td height="27" style="height:27px;">Mice pregnant female (embryonic day 12.5 to 16.5; E12.5-16.5)&#160;</td>
			<td>Criffa-Credo, Lyon, France</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Modified Minimum Essential Medium Eagle (MEM)</td>
			<td>Invitrogen</td>
			<td>11012-044</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Monoclonal antibody against class III &#946;-tubulin (clone TUJ-1)</td>
			<td>Biolegend</td>
			<td>801201</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">N-2 supplement 100x&#160;</td>
			<td>Invitrogen</td>
			<td>17502-048</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Neurobasal medium&#160;</td>
			<td>Invitrogen</td>
			<td>21103049</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Paraformaldehyde</td>
			<td>Merck</td>
			<td>1,040,051,000</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Penicillin/streptomycin solution 100x&#160;</td>
			<td>Invitrogen</td>
			<td>15140-22</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Phosphate buffered saline 10x (PBS) for immunocytochemistry</td>
			<td>Invitrogen</td>
			<td>AM9624</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Secondary antibody: biotinylated horse anti-mouse&#160;</td>
			<td>Vector Labs</td>
			<td>BA-2000</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Serum-free medium (Opti-MEM)</td>
			<td>Invitrogen</td>
			<td>11058-021</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Sodium azide&#160;</td>
			<td>Panreac</td>
			<td>162712</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Sodium bicarbonate solution 7.5%&#160;</td>
			<td>Invitrogen</td>
			<td>25080-094</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Sterile culture grade H2O&#160;</td>
			<td>Sigma</td>
			<td>W3500</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">TritonTM X-100&#160;</td>
			<td>Sigma</td>
			<td>X100</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Trizma base&#160;</td>
			<td>Sigma</td>
			<td>T1503</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Trypsin-EDTA (Trypsin (0.05% (wt/vol) with EDTA (1x)</td>
			<td>Invitrogen</td>
			<td>25300-054</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:455px;">Equipment</td>
			<td style="width:211px;"></td>
			<td style="width:344px;"></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">1 large and 1 small curved scissors for dissection&#160;</td>
			<td>Fine tools Instruments or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">1.5-ml conical centrifuge tubes&#160;</td>
			<td>Eppendorf or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">15-ml conical centrifuge tubes&#160;</td>
			<td>Corning or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">2 haemostats&#160;&#160;</td>
			<td>Fine tools Instruments or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">2 small straight dissecting scissors</td>
			<td>Fine tools Instruments or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">200-ml centrifuge tubes for centrifugation</td>
			<td>Nalgene or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">200-ml sterile glass conical flasks</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">2-litre glass beaker</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">4- and 6-well culture plates&#160;</td>
			<td>Nunc</td>
			<td>176740 and 140675</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Automatic pipette pumps and disposable 10 ml and 25 ml filter-containing sterile plastic pipettes.</td>
			<td colspan="2">Gilson, Brand, Eppendorf or similar&#160;</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Automatic pipettes, sterile filter tips and current sterile tips&#160;</td>
			<td>Gilson, Eppendorf or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Bench top microcentrifuge with angle fixed rotor&#160;</td>
			<td colspan="2">Eppendorf, Beckman Coulter or similar</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Bench top refrigerated centrifuge with swing-bucket rotor (with 1.5, 15 and 50 ml tube adaptors)</td>
			<td colspan="2">Eppendorf, Beckman Coulter or similar</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Cell culture incubator at 37 &#186;C, 5% CO2 and 95% air</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Dialysis tubing cellulose membrane</td>
			<td>Sigma</td>
			<td>D9402</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Dialysis tubing closures&#160;</td>
			<td>Sigma</td>
			<td>Z37101-7</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Disposable glass pipettes</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Dissecting microscope with dark field optics&#160;</td>
			<td>Olympus SZ51 or similar&#160;</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td colspan="2" height="21" style="height:21px;">High-speed refrigerated Beckman Coulter centrifuge or similar with angle fixed rotor</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Laminar flow hood</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Large 100-mm, 60-mm and small 35-mm &#216; cell culture dishes&#160;</td>
			<td>Nunc</td>
			<td>&#160;150679 , 150288 and 150318, respectively</td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Magnetic stirrer and magnetic spin bars</td>
			<td>IKA or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">McIlwain tissue chopper</td>
			<td>Mickle Laboratory Engineering</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">One pair of fine straight forceps and one pair of curved forceps&#160;</td>
			<td>Fine tools Instruments or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Razor blades for the tissue chopper</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Scalpels (number 15 and 11)</td>
			<td></td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;">Two pairs of fine spatulas for transferring collagen and tissue pieces</td>
			<td>Fine tools Instruments or similar</td>
			<td></td>
			<td style="width:167px;"></td>
		</tr>
	</tbody>
</table>

generation of 3-d collagen-based hydrogels to analyze axonal growth and behavior during nervous system development

This protocol uses natural type I collagen to generate three-dimensional (3-D) hydrogel for monitoring and analyzing the axonal growth. The protocol is centered on culturing small pieces of embryonic or early postnatal rodent brains inside a 3-D hydrogel formed by the rat tail tendon-derived type I collagen with specific porosity. Tissue pieces are cultured inside the hydrogel and confronted to specific brain fragments or genetically-modified cell aggregates to produce and secrete molecules suitable for creating a gradient inside the porous matrix. The steps of this protocol are simple and reproducible but include critical steps to be considered carefully during its development. Moreover, the behavior of growing axons can be monitored and analyzed directly using a phase-contrast microscope or mono/multiphoton fluorescence microscope after fixation by immunocytochemical methods.

Here, we present a widely accessible methodology to study axonal growth in 3-D hydrogel collagen cultures of embryonic mouse nervous system. To this end, we isolated collagen from adult rat tails to generate 3-D matrices in which we cultured genetically-modified cell aggregates expressing Netrin-1 or Sema3E confronted with embryonic neuronal tissue (e.g., CA region of the hippocampus). These cell aggregates formed a radially distributed gradient of the candidate molecule inside the collagen matrix. Finally, to evaluate t...

Watch this Scientific Journal Video about Generation of 3-D Collagen-based Hydrogels to Analyze Axonal Growth and Behavior During Nervous System Development at JoVE.com

Generation of 3-D Collagen-based Hydrogels to Analyze Axonal Growth and Behavior During Nervous System Development

Here, we provide a method for analyzing the behavior of growing axons in 3D matrices, mimicking their natural development.

This protocol uses natural type I collagen to generate three-dimensional (3-D) hydrogel for monitoring and analyzing the axonal growth. The protocol is ...

generation-3-d-collagen-based-hydrogels-to-analyze-axonal-growth

Research

JoVE Journal

Neuroscience

5.6K Views.  Parc Científic de Barcelona. Here, we provide a method for analyzing the behavior of growing axons in 3D matrices, mimicking their natural development.

Video: Generation of 3-D Collagen-based Hydrogels to Analyze Axonal Growth and Behavior During Nervous System Development

Scalable Fluidic Injector Arrays for Viral Targeting of Intact 3-D Brain Circuits

Our understanding of neural circuits--how they mediate the computations that subserve sensation, thought, emotion, and action, and how they are corrupted in neurological and psychiatric disorders--would be greatly facilitated by a technology for rapidly targeting genes to complex 3-dimensional neural circuits, enabling fast creation of "circuit-level transgenics." We have recently developed methods in which viruses encoding for light-sensitive proteins can sensitize specific cell types to millisecond-timescale activation and silencing in the intact brain. We here present the design and implementation of an injector array capable of delivering viruses (or other fluids) to dozens of defined points within the 3-dimensional structure of the brain (Figure. 1A, 1B). The injector array comprises one or more displacement pumps that each drive a set of syringes, each of which feeds into a polyimide/fused-silica capillary via a high-pressure-tolerant connector. The capillaries are sized, and then inserted into, desired locations specified by custom-milling a stereotactic positioning board, thus allowing viruses or other reagents to be delivered to the desired set of brain regions. To use the device, the surgeon first fills the fluidic subsystem entirely with oil, backfills the capillaries with the virus, inserts the device into the brain, and infuses reagents slowly (&lt;0.1 microliters/min). The parallel nature of the injector array facilitates rapid, accurate, and robust labeling of entire neural circuits with viral payloads such as optical sensitizers to enable light-activation and silencing of defined brain circuits. Along with other technologies, such as optical fiber arrays for light delivery to desired sets of brain regions, we hope to create a toolbox that enables the systematic probing of causal neural functions in the intact brain. This technology may not only open up such systematic approaches to circuit-focused neuroscience in mammals, and facilitate labeling of brain regions in large animals such as non-human primates, but may also open up a clinical translational path for cell-specific optical control prosthetics, whose precision may enable improved treatment of intractable brain disorders. Finally, such devices as described here may facilitate precisely-timed fluidic delivery of other payloads, such as stem cells and pharmacological agents, to 3-dimensional structures, in an easily user-customizable fashion.

Controlling and analyzing neural circuits in vivo would be facilitated by a technology for delivery of viruses and other reagents to desired 3-dimensional sets of brain regions. We demonstrate customized fluidic injector array fabrication, and delivery of virally-encoded optical sensitizers, enabling optical manipulation of complex brain circuits.

Our understanding of neural circuits--how they mediate the computations that subserve sensation, thought, emotion, and action, and how they are corrupted ...

Cryopreservation of Cortical Tissue Blocks for the Generation of Highly Enriched Neuronal Cultures

In this study, we outline a standardized protocol for the successful cryopreservation and thawing of cortical brain tissue blocks to generate highly enriched neuronal cultures. For this protocol the freezing medium used is 10% dimethyl sulfoxide (DMSO) diluted in Hank's Buffered Salt Solution (HBSS). Blocks of cortical tissue are transferred to cryovials containing the freezing medium and slowly frozen at -1&deg;C/min in a rate-controlled freezing container. Post-thaw processing and dissociation of frozen tissue blocks consistently produced neuronal-enriched cultures which exhibited rapid neuritic growth during the first 5 days in culture and significant expansion of the neuronal network within 10 days. Immunocytochemical staining with the astrocytic marker glial fibrillary acidic protein (GFAP) and the neuronal marker beta-tubulin class III, revealed high numbers of neurons and astrocytes in the cultures. Generation of neural precursor cell cultures after tissue block dissociation resulted in rapidly expanding neurospheres, which produced large numbers of neurons and astrocytes under differentiating conditions. This simple cryopreservation protocol allows for the rapid, efficient, and inexpensive preservation of cortical brain tissue blocks, which grants increased flexibility for later generation of neuronal, astrocyte, and neuronal precursor cell cultures.

Here, we describe a method for efficient cryopreservation and thawing of cortical brain tissue blocks to generate highly enriched neuronal cultures. This simple protocol provides flexibility for later generation of neuronal, astrocyte, and neuronal precursor cell cultures.

In this study, we outline a standardized protocol for the successful cryopreservation and thawing of cortical brain tissue blocks to generate highly ...

Mechanical Manipulation of Neurons to Control Axonal Development

Cell manipulations and extension of neuronal axons can be accomplished with calibrated glass micro-fibers capable of measuring and applying forces in the 10-1000 &mu;dyne range1,2. Force measurements are obtained through observation of the Hookean bending of the glass needles, which are calibrated by a direct and empirical method3. Equipment requirements and procedures for fabricating, calibrating, treating, and using the needles on cells are fully described. The force regimes previously used and different cell types to which these techniques have been applied demonstrate the flexibility of the methodology and are given as examples for future investigation4-6. The technical advantages are the continuous 'visualization' of the forces produced by the manipulations and the ability to directly intervene in a variety of cellular events. These include direct stimulation and regulation of axonal growth and retraction7; as well as detachment and mechanical measurements on any type of cultured cell8.

Application and direct measurements of forces on neurons in the 2-1000 microdyne range are achieved with high precision using calibrated glass needles. This methodology can be used to control and measure several aspects of axonal development, including axonal initiation, axonal tension, velocity of axonal elongation, and force vectors.

Cell manipulations and extension of neuronal axons can be accomplished with calibrated glass micro-fibers capable of measuring and applying forces in the ...

An Injury Paradigm to Investigate Central Nervous System Repair in Drosophila

An experimental method has been developed to investigate the cellular responses to central nervous system (CNS) injury using the fruit-fly Drosophila. Understanding repair and regeneration in animals is a key question in biology. The damaged human CNS does not regenerate, and understanding how to promote the regeneration is one of main goals of medical neuroscience. The powerful genetic toolkit of Drosophila can be used to tackle the problem of CNS regeneration.
A lesion to the CNS ventral nerve cord (VNC, equivalent to the vertebrate spinal cord) is applied manually with a tungsten needle. The VNC can subsequently be filmed in time-lapse using laser scanning confocal microscopy for up to 24 hr to follow the development of the lesion over time. Alternatively, it can be cultured, then fixed and stained using immunofluorescence to visualize neuron and glial cells with confocal microscopy. Using appropriate markers, changes in cell morphology and cell state as a result of injury can be visualized. With ImageJ and purposely developed plug-ins, quantitative and statistical analyses can be carried out to measure changes in wound size over time and the effects of injury in cell proliferation and cell death. These methods allow the analysis of large sample sizes. They can be combined with the powerful genetics of Drosophila to investigate the molecular mechanisms underlying CNS regeneration and repair.

An Injury Paradigm to Investigate Central Nervous System Repair in Drosophila

An injury paradigm using the Drosophila larval ventral nerve cord to investigate central nervous system regeneration and repair is described. Stabbing followed by laser scanning confocal microscopy in time-lapse and fixed specimens, combined with quantitative analysis with purposefully developed software and genetics, are used to investigate the molecular mechanisms of CNS regeneration and repair.

An experimental method has been developed to investigate the cellular responses to central nervous system (CNS) injury using the fruit-fly Drosophila. ...

Direct Intraventricular Delivery of Drugs to the Rodent Central Nervous System

Due to an inability to cross the blood brain barrier, certain drugs need to be directly delivered into the central nervous system (CNS). Our lab focuses specifically on antisense oligonucleotides (ASOs), though the techniques shown in the video here can also be used to deliver a plethora of other drugs to the CNS. Antisense oligonucleotides (ASOs) have the capability to knockdown sequence-specific targets 1 as well as shift isoform ratios of specific genes 2. To achieve widespread gene knockdown or splicing in the CNS of mice, the ASOs can be delivered into the brain using two separate routes of administration, both of which we demonstrate in the video.
The first uses Alzet osmotic pumps, connected to a catheter that is surgically implanted into the lateral ventricle. This allows the ASOs to be continuously infused into the CNS for a designated period of time. The second involves a single bolus injection of a high concentration of ASO into the right lateral ventricle. Both methods use the mouse cerebral ventricular system to deliver the ASO to the entire brain and spinal cord, though depending on the needs of the study, one method may be preferred over the other.

We describe a method to target drugs to the central nervous system by either implanting a catheter or performing a bolus injection into the right lateral ventricle in mice. We focus specifically on the delivery of antisense oligonucleotides. This technique is readily adaptable to other drugs and to rats.

Due to an inability to cross the blood brain barrier, certain drugs need to be directly delivered into the central nervous system (CNS). Our lab focuses ...

Designing and Implementing Nervous System Simulations on LEGO Robots

We present a method to use the commercially available LEGO Mindstorms NXT robotics platform to test systems level neuroscience hypotheses. The first step of the method is to develop a nervous system simulation of specific reflexive behaviors of an appropriate model organism; here we use the American Lobster. Exteroceptive reflexes mediated by decussating (crossing) neural connections can explain an animal's taxis towards or away from a stimulus as described by Braitenberg and are particularly well suited for investigation using the NXT platform.1 The nervous system simulation is programmed using LabVIEW software on the LEGO Mindstorms platform. Once the nervous system is tuned properly, behavioral experiments are run on the robot and on the animal under identical environmental conditions. By controlling the sensory milieu experienced by the specimens, differences in behavioral outputs can be observed. These differences may point to specific deficiencies in the nervous system model and serve to inform the iteration of the model for the particular behavior under study. This method allows for the experimental manipulation of electronic nervous systems and serves as a way to explore neuroscience hypotheses specifically regarding the neurophysiological basis of simple innate reflexive behaviors. The LEGO Mindstorms NXT kit provides an affordable and efficient platform on which to test preliminary biomimetic robot control schemes. The approach is also well suited for the high school classroom to serve as the foundation for a hands-on inquiry-based biorobotics curriculum.

An approach to neural network modeling on the LEGO Mindstorms robotics platform is presented. The method provides a simulation tool for invertebrate neuroscience research in both the research lab and the classroom. This technique enables the investigation of biomimetic robot control principles.

We present a method to use the commercially available LEGO Mindstorms NXT robotics platform to test systems level neuroscience hypotheses. The first step ...

In vivo Optogenetic Stimulation of the Rodent Central Nervous System

The ability to probe defined neural circuits in awake, freely-moving animals with cell-type specificity, spatial precision, and high temporal resolution has been a long sought tool for neuroscientists in the systems-level search for the neural circuitry governing complex behavioral states. Optogenetics is a cutting-edge tool that is revolutionizing the field of neuroscience and represents one of the first systematic approaches to enable causal testing regarding the relation between neural signaling events and behavior. By combining optical and genetic approaches, neural signaling can be bi-directionally controlled through expression of light-sensitive ion channels (opsins) in mammalian cells. The current protocol describes delivery of specific wavelengths of light to opsin-expressing cells in deep brain structures of awake, freely-moving rodents for neural circuit modulation. Theoretical principles of light transmission as an experimental consideration are discussed in the context of performing in vivo optogenetic stimulation. The protocol details the design and construction of both simple and complex laser configurations and describes tethering strategies to permit simultaneous stimulation of multiple animals for high-throughput behavioral testing.

In vivo Optogenetic Stimulation of the Rodent Central Nervous System

Optogenetics has become a powerful tool for use in behavioral neuroscience experiments. This protocol offers a step-by-step guide to the design and set-up of laser systems, and provides a full protocol for carrying out multiple and simultaneous in vivo optogenetic stimulations compatible with most rodent behavioral testing paradigms.

The ability to probe defined neural circuits in awake, freely-moving animals with cell-type specificity, spatial precision, and high temporal resolution ...

The Olfactory System as a Model to Study Axonal Growth Patterns and Morphology In Vivo

The olfactory system has the unusual capacity to generate new neurons throughout the lifetime of an organism. Olfactory stem cells in the basal portion of the olfactory epithelium continuously give rise to new sensory neurons that extend their axons into the olfactory bulb, where they face the challenge to integrate into existing circuitry. Because of this particular feature, the olfactory system represents a unique opportunity to monitor axonal wiring and guidance, and to investigate synapse formation. Here we describe a procedure for in vivo labeling of sensory neurons and subsequent visualization of axons in the olfactory system of larvae of the amphibian Xenopus laevis. To stain sensory neurons in the olfactory organ we adopt the electroporation technique. In vivo electroporation is an established technique for delivering fluorophore-coupled dextrans or other macromolecules into living cells. Stained sensory neurons and their axonal processes can then be monitored in the living animal either using confocal laser-scanning or multiphoton microscopy. By reducing the number of labeled cells to few or single cells per animal, single axons can be tracked into the olfactory bulb and their morphological changes can be monitored over weeks by conducting series of in vivo time lapse imaging experiments. While the described protocol exemplifies the labeling and monitoring of olfactory sensory neurons, it can also be adopted to other cell types within the olfactory and other systems.

The Olfactory System as a Model to Study Axonal Growth Patterns and Morphology In Vivo

We describe a protocol for in vivo labeling of olfactory sensory neurons by electroporation and subsequent confocal laser-scanning or multiphoton microscopy to visualize neuronal morphology and its development over time.

The olfactory system has the unusual capacity to generate new neurons throughout the lifetime of an organism. Olfactory stem cells in the basal portion of ...

3-D Imaging and Analysis of Neurons Infected In Vivo with Toxoplasma gondii

Toxoplasma gondii is an obligate, intracellular parasite with a broad host range, including humans and rodents. In both humans and rodents, Toxoplasma establishes a lifelong persistent infection in the brain. While this brain infection is asymptomatic in most immunocompetent people, in the developing fetus or immunocompromised individuals such as acquired immune deficiency syndrome (AIDS) patients, this predilection for and persistence in the brain can lead to devastating neurologic disease. Thus, it is clear that the brain-Toxoplasma interaction is critical to the symptomatic disease produced by Toxoplasma, yet we have little understanding of the cellular or molecular interaction between cells of the central nervous system (CNS) and the parasite. In the mouse model of CNS toxoplasmosis it has been known for over 30 years that neurons are the cells in which the parasite persists, but little information is available about which part of the neuron is generally infected (soma, dendrite, axon) and if this cellular relationship changes between strains. In part, this lack is secondary to the difficulty of imaging and visualizing whole infected neurons from an animal. Such images would typically require serial sectioning and stitching of tissue imaged by electron microscopy or confocal microscopy after immunostaining. By combining several techniques, the method described here enables the use of thick sections (160 &#181;m) to identify and image whole cells that contain cysts, allowing three-dimensional visualization and analysis of individual, chronically infected neurons without the need for immunostaining, electron microscopy, or serial sectioning and stitching. Using this technique, we can begin to understand the cellular relationship between the parasite and the infected neuron.

3-D Imaging and Analysis of Neurons Infected In Vivo with Toxoplasma gondii

Using this protocol, we were able to image 160 &#181;m thick brain sections from mice infected with the parasite Toxoplasma gondii, which enables visualization and analysis of the spatial relationship between the encysting parasite and the infected neuron.

Toxoplasma gondii is an obligate, intracellular parasite with a broad host range, including humans and rodents. In both humans and rodents, Toxoplasma ...

Modification of a Colliculo-thalamocortical Mouse Brain Slice, Incorporating 3-D printing of Chamber Components and Multi-scale Optical Imaging

The ability of the brain to process sensory information relies on both ascending and descending sets of projections. Until recently, the only way to study these two systems and how they interact has been with the use of in vivo preparations. Major advances have been made with acute brain slices containing the thalamocortical and cortico-thalamic pathways in the somatosensory, visual, and auditory systems. With key refinements to our recent modification of the auditory thalamocortical slice1, we are able to more reliably capture the projections between most of the major auditory midbrain and forebrain structures: the inferior colliculus (IC), medial geniculate body (MGB), thalamic reticular nucleus (TRN), and the auditory cortex (AC). With portions of all these connections retained, we are able to answer detailed questions that complement the questions that can be answered with in vivo preparations. The use of flavoprotein autofluorescence imaging enables us to rapidly assess connectivity in any given slice and guide the ensuing experiment. Using this slice in conjunction with recording and imaging techniques, we are now better equipped to understand how information processing occurs at each point in the auditory forebrain as information ascends to the cortex, and the impact of descending cortical modulation. 3-D printing to build slice chamber components permits double-sided perfusion and broad access to networks within the slice and maintains the widespread connections key to fully utilizing this preparation.

Using multiple angles to cut the mouse pup brain, we improve upon a previously-described acute brain slice which captures the connections between most of the major auditory midbrain and forebrain structures.

The ability of the brain to process sensory information relies on both ascending and descending sets of projections. Until recently, the only way to study ...
