This work is a part of the STW project "Integral solution for sustainable construction (IS2C, Fleur van Rossem for her support during the chip fabrication, Justyna Wiedemair for the chip design and Allison Bidulock for her support during the manuscript preparation.

1.チップ製造注：チップは、Ag / AgClの作用電極（WE）、銀/塩化銀擬似参照電極（擬似RE）とガラスチップ上に白金対向電極から構成されています。銀金属16を処理し 、標準的なクリーンルームを使用して、ガラスチップ上に堆積されます。次いで、それを表面上に塩化銀層を形成するために30秒間の0.1MのFeCl 3溶液中に塩素化されています。銀/塩化銀WE（面積= 9.812 平方ミリメートル）は 、図1に示すように、銀/塩化銀疑似REに囲まれ、中央部に位置しています。 <ol><li>平面銀電極を形成するために、ガラス上に金属銀を析出。次のようにクリーンルームでのステップバイステップのチップ製造を与えられます： <ol><li>リソグラフィー<ol><li>ウェハ洗浄のために、濃に最初のガラスウェハを浸します。表面をきれいにするために任意の有機汚染物を除去した後、1 M KOHにするHNO 3風呂。 </li><li> （厚さ200nm）にポジ型レジスト写真を適用しますスピンコーティングによりウエハ、15分間95℃でレジストをプリベーク。 </li><li>ガラスマスクを介して、5秒間UV光にウェハを公開します。 </li><li>現像液中​​のフォトレジストを開発します。これは、電極が堆積され、残りの領域をレジスト未露光によってカバーされるガラスの面積を公開します。 </li></ol></li><li>ガラスエッチング<ol><li>ガラスの露出領域をエッチングするためにKOHの浴に開発ガラスウェーハを浸します。 </li></ol></li><li>金属蒸着（スパッタリング） <ol><li>露出したガラスエリアでの預金銀金属。 <ol><li>第一のガラスのための接着層として20nmのチタン（スパッタリングによって）チタン（Ti）層を堆積させます。 </li><li>次いで、銀とTiとの間の拡散バリアとして（スパッタリングによって）70n​​mのパラジウム（Pd）層を堆積させます。 </li><li>最後に、銀金属の500 nmのを堆積させます。これは、堆積された金属の厚さです。作用電極の面積を4mm 2です。 </li><li> Rを削除しますアセトン浴中でリフトオフ法によりレジストをemaining。 </li></ol></li><li>シングルチップサイズにウェハをDICE。チップは現在、オンチップのAg / AgCl電極を形成するために塩素化される準備ができています。 </li></ol></li></ol></li><li> 図1に示すように、社内で設計されたポリテトラフルオロエチレンチップホルダにチップを置きます。ホルダーは、プッシュピン（またはバネ式のピン）を介して容易に電気的接続を提供し、電気化学セルが含まれています。 </li><li>チップ上のAg / AgCl電極を形成する銀電極を塩化物にします。そのために、30秒間、細胞中の0.1MのFeCl 3溶液を注ぎます。または電極のシルバー色まで暗い灰色がかったなり。短い浸漬時間は、Ag / AgClでの析出につながることができ、一方、より長い浸漬は重要ではありません。 </li><li>残りのFeCl 3【選択チップをきれいにするために脱イオン水でチップをすすぐ今クロノ測定に使用する準備が整いました。 </li></ol>2.電解準備注：電解質は、0.5M KNO 3における塩化カリウムの異なる濃度で調製しました。 <ol><li> 50のKCl電解質原液（溶液50ml中のKClの0.186グラム）の50ミリリットルを準備します。 </li><li>同じ溶液中0.5 M KNO 3バックグラウンド電解質を形成するために、KNO 3の2.52グラムを追加します。 </li><li>脱イオン水50mlにKNO 3の2.52グラムを追加し、他の言葉ではM. 0.5にゼロとKNO 3に塩化物の出発濃度を保管してください。 </li><li>以下の手順に示すように、体系的に、電解質（1ミリモルから6ミリメートル）の塩化物イオン濃度を増加させるための50mMのKClを加えます。 <ol><li> 1 mMの[CL]を取得するために、0.5M KNO 3の4.9ミリリットルに50mMのKClを100μlのを追加します。 </li><li> 2 mMの[CL]を取得するステップ2.4​​.1の溶液に50mMのKCl溶液の104μLを加えます。 </li><li> sの中に50mMのKCl溶液の108.41μLを追加3 mMの[CL]を取得するためのステップ2.4​​.2のolution。 </li><li> 4 mMの[CL]を取得するステップ2.4​​.3の溶液に50mMのKCl溶液の113.19μLを加えます。 </li><li> 5 mMの[CL]を取得するステップ2.4​​.4の溶液に50mMのKCl溶液の118.2μLを加えます。 </li><li> 6 mMの[CL]を取得するステップ2.4​​.5の溶液に50mMのKCl溶液の123.3μLを加えます。 </li></ol></li></ol> 3.実験のセットアップ注：測定は、ポテンショスタット（生物学的科学器具、フランス）を用いて行きました。 <ol><li>チップホルダにチップを置き、ポテンショスタットの対応する端子に接続します。 </li><li> Ag / AgCl電極をポテンショスタットの作用電極端子を接続します。 </li><li>別のAg / AgCl電極をポテンショスタットの参照電極端子を接続します。 </li><li>白金電極にポテンショスタットの対向電極端子を接続します。 </li><li>カンプを配置周囲の騒音を避けるために、ファラデーケージ内LETE実験のセットアップ。 </li></ol> 4.機器の操作設定注：電気化学セルの動作パラメータは、ポテンシオスタットのユーザインタフェースを介して制御されます。印加電流パルス中のAg / AgClをWEの電位応答は、塩化物イオンの異なる濃度について測定されます。 <ol><li>ポテンショスタットのプログラムでは、技術のクロノを開き、動作パラメータを設定します。 <ol><li>要件に応じて次のパラメータを設定します。 <ol><li>電流（I S） </li><li>印加電流（T 秒 ）の時間</li></ol></li><li>ポテンショスタットプログラムで再生ボタンをクリックすることで、この技術を起動します。 注：ポテンショスタットプログラムが適用される電流パルスの下で時間の関数としての潜在的な応答が表示されます。 </li></ol></li></ol> 5.測定とデータAnalysiの<ol><li>電解液中のClイオン濃度対遷移時間の検量線を描画します。 <ol><li>系統的に、塩化カリウム電解液中のCl濃度を変更します。 <ol><li>電気化学セル中の0.5M KNO 3バックグラウンド電解質と1のKClの5ミリリットルで測定を開始します。 </li><li>ポテンショスタットを使用してクロノ実験を開始し、10ミリアンペア/ cm -2で10秒間の電流を印加し、データを格納します。 </li><li>系統的に1 mMの刻みで6 mmの濃度を変更し、測定を繰り返します。 </li></ol></li><li> a.mptファイルとして測定されたデータを格納し、データ処理プログラムのデータファイルを分析します。 <ol><li>電位応答の一次導関数を計算し、一次微分のピークを計算するために社内開発されたデータ処理プログラムを使用してデータを分析します。一次導関数のピークは、遷移時間です。 注：完全なタラをデータ処理プログラムのINGはのアッバスら、2014補足情報に記載されています。 </li></ol></li><li> 1時間ごとの間隔で測定を3回繰り返します。 </li><li>データ処理プログラムですべてのデータファイルを開き、各測定のための遷移時間を計算します。遷移時間計算の詳細手順は以下のとおりであります： <ol><li>クロノ計測のデータファイルから取得した対時間の電位差をプロットします。 </li><li>電位応答の一次導関数を計算します。 </li><li>一次導関数の最大値と、それの時間を示します。一次導関数の最大値の時間は、遷移時間です。 </li></ol></li><li>検量線は、CLイオン濃度に対する遷移時間の平方根をプロット。 </li><li>測定したデータに沿って砂の式25に基づく理論曲線をプロットします。拡散coefficを逆算データプロットからient。 <ol><li>遷移時間との間で測定されたデータプロットで[CL]ライン上の任意の点を取ると、遷移時間の値と[CL]を記録します。砂の方程式は以下のように与えられます。 τ=（FC * / 2J（1-T のCl - ））2Dπ トランスポート番号であり、Dは拡散係数である-ここで、C *は、バルクのClイオン濃度であり、Fはファラデー定数、Jは電流密度、T Clです 。ネグレクトトンのCl -それは、より高いバックグラウンド電解質濃度のためにゼロに近づくので。 </li><li>拡散係数の砂方程式で唯一残っている変数。遷移時間、塩化物イオン濃度および拡散係数の値を取得砂式の印加電流値を置きます。 </li></ol></li></ol></li><li>ドリフト測定<ol><li>中のKClの1 mMと5ミリリットルを注ぎます電気化学セル。 </li><li>ポテンショスタットでは、現在適用されているが、午前10時-2、時間は10秒となるように設定します。 </li><li>測定間の3時間の間隔で3つの測定毎日で2週間のための潜在的な応答を測定します。 </li><li>電解質、 すなわち、1のKCl、測定を行う前に、毎日更新します。 </li><li>測定値の2週間にわたって遷移時間をプロットします。一日あたりの遷移時間の変化は、遷移時間応答のドリフトです。 </li></ol></li><li>遷移時間測定の擬似参照電極の影響 注：このような銀/塩化銀線、白金線と鋼線のような様々な擬似参照は、遷移時間を測定するために試験されます。 <ol><li>電気化学セルでのKCl電解質の4 mMのを注ぎます。 </li><li>擬似参照電極として銀/塩化銀を使用し、ポテンシオスタットの参照電極端子に接続します。陽極電流パルスのCl＆＃へ713;イオンは、Ag / AgClの作用電極の近くに空乏化されます。 </li><li> 10秒間15アム-2の電流密度を印加することにより、クロノ測定を行います。 </li><li>擬似参照電極として白金で測定を繰り返し、データを記録します。 </li><li>擬似参照電極としての鋼棒を用いた測定を繰り返し、データを記録します。 </li><li>使用される様々な擬似参照電極のための測定された遷移時間をプロットします。 </li><li> KCl 5mMのと測定の完全なセットを繰り返し、様々な擬似参照電極を使用して遷移時間をプロットします。 </li></ol></li></ol>

<ol>
	<li>Page, C., Treadaway, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Aspects+of+the+electrochemistry+of+steel+in+concrete.">Aspects of the electrochemistry of steel in concrete.</a> Nature. 297, 109-115 (1982).</li><li>Koleva, D. A., Hu, J., van Breugel, K., Boshkov, N., de Wit, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Conventional+and+pulse+cathodic+protection+of+reinforced+concrete:+electrochemical+approach+and+microstructural+investigations.">Conventional and pulse cathodic protection of reinforced concrete: electrochemical approach and microstructural investigations.</a> ECS Transactions. 1, 287-298 (2006).</li><li>Montemor, M., Simoes, A., Ferreira, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chloride-induced+corrosion+on+reinforcing+steel:+from+the+fundamentals+to+the+monitoring+techniques.">Chloride-induced corrosion on reinforcing steel: from the fundamentals to the monitoring techniques.</a> Cement and Concrete Composites. 25, 491-502 (2003).</li><li>Wegen, G., Polder, R. B., Breugel, K. V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Guideline+for+service+life+design+of+structural+concrete:+A+performance+based+approach+with+regard+to+chloride+induced+corrosion.">Guideline for service life design of structural concrete: A performance based approach with regard to chloride induced corrosion.</a> Heron. 57 (3), (2012).</li><li>Yoon, I., Koenders, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Theoretical+time+evolution+of+critical+chloride+content+in+concrete.">Theoretical time evolution of critical chloride content in concrete.</a> Structural Durability &amp; Health Monitoring. 5, 275-294 (2010).</li><li>Du, R. G., Hu, R. G., Huang, R. S., Lin, C. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=In+situ+measurement+of+Cl-concentrations+and+pH+at+the+reinforcing+steel/concrete+interface+by+combination+sensors.">In situ measurement of Cl-concentrations and pH at the reinforcing steel/concrete interface by combination sensors.</a> Analytical Chemistry. 78, 3179-3185 (2006).</li><li>Angst, U., Elsener, B., Larsen, C. K., Vennesland, &. #. 2. 1. 6. ;. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Potentiometric+determination+of+the+chloride+ion+activity+in+cement+based+materials.">Potentiometric determination of the chloride ion activity in cement based materials.</a> Journal of Applied Electrochemistry. 40, 561-573 (2010).</li><li>Laferri&#232;re, F., Inaudi, D., Kronenberg, P., Smith, I. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+system+for+early+chloride+detection+in+concrete.">A new system for early chloride detection in concrete.</a> Smart Materials and Structures. 17, 045017 (2008).</li><li>Tang, J. L., Wang, J. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Measurement+of+chloride-ion+concentration+with+long-period+grating+technology.">Measurement of chloride-ion concentration with long-period grating technology.</a> Smart Materials and Structures. 16, 665 (2007).</li><li>Kohri, M., Ueda, T., Mizuguchi, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Application+of+a+near-infrared+spectroscopic+technique+to+estimate+the+chloride+ion+content+in+mortar+deteriorated+by+chloride+attack+and+carbonation.">Application of a near-infrared spectroscopic technique to estimate the chloride ion content in mortar deteriorated by chloride attack and carbonation.</a> Journal of Advanced Concrete Technology. 8, 15-25 (2010).</li><li>Tripathi, S. R., Inoue, H., Hasegawa, T., Kawase, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Non-destructive+Inspection+of+Chloride+Ion+in+Concrete+Structures+Using+Attenuated+Total+Reflection+of+Millimeter+Waves.">Non-destructive Inspection of Chloride Ion in Concrete Structures Using Attenuated Total Reflection of Millimeter Waves.</a> Journal of Infrared, Millimeter, and Terahertz Waves. 34, 181-186 (2013).</li><li>Abbas, Y., Olthuis, W., van den Berg, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+chronopotentiometric+approach+for+measuring+chloride+ion+concentration.">A chronopotentiometric approach for measuring chloride ion concentration.</a> Sensors and Actuators B: Chemical. 188, 433-439 (2013).</li><li>Climent-Llorca, M. A., Viqueira-P&#233;rez, E., L&#242;pez-Atalaya, M. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Embeddable+Ag/AgCl+sensors+for+in-situ+monitoring+chloride+contents+in+concrete.">Embeddable Ag/AgCl sensors for in-situ monitoring chloride contents in concrete.</a> Cement and Concrete Research. 26, 1157-1161 (1996).</li><li>Myrdal, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> The electrochemistry and characteristics of embeddable reference electrodes for concrete. , (2014).</li><li>Angst, U., Vennesland, &. #. 2. 1. 6. ;., Myrdal, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diffusion+potentials+as+source+of+error+in+electrochemical+measurements+in+concrete.">Diffusion potentials as source of error in electrochemical measurements in concrete.</a> Materials and Structures. 42, 365-375 (2009).</li><li>Abbas, Y., de Graaf, D. B., Olthuis, W., van den Berg, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=No+more+conventional+reference+electrode:+Transition+time+for+determining+chloride+ion+concentration.">No more conventional reference electrode: Transition time for determining chloride ion concentration.</a> Analytica Chimica Acta. 821, 81-88 (2014).</li><li>Meyer, R. E., Posey, F. A., Lantz, P. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chronopotentiometry+of+the+Ag&#8722;+AgCl+system+and+analysis+for+the+chloride+ion.">Chronopotentiometry of the Ag&#8722; AgCl system and analysis for the chloride ion.</a> Journal of Electroanalytical Chemistry and Interfacial Electrochemistry. 19, 99-109 (1968).</li><li>Olthuis, W., Langereis, G., Bergveld, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+metrits+of+differential+measuring+in+time+and+space.">The metrits of differential measuring in time and space.</a> Biocybernetics and Biomedical Engineering. 21, 5-26 (2001).</li><li>Bakker, E., Bhakthavatsalam, V., Gemene, K. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Beyond+potentiometry:+robust+electrochemical+ion+sensor+concepts+in+view+of+remote+chemical+sensing.">Beyond potentiometry: robust electrochemical ion sensor concepts in view of remote chemical sensing.</a> Talanta. 75, 629-635 (2008).</li><li>Olthuis, W., Bomer, J., Bergveld, P., Bos, M., Van der Linden, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Iridium+oxide+as+actuator+material+for+the+ISFET-based+sensor-actuator+system.">Iridium oxide as actuator material for the ISFET-based sensor-actuator system.</a> Sensors and Actuators B: Chemical. 5, 47-52 (1991).</li><li>Bergveld, P., Eijkel, J., Olthuis, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+protein+concentrations+with+chronopotentiometry.">Detection of protein concentrations with chronopotentiometry.</a> Biosensors and Bioelectronics. 12, 905-916 (1997).</li><li>Iwamoto, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Derivative+chronopotentiometry.">Derivative chronopotentiometry.</a> Analytical Chemistry. 31, 1062-1065 (1959).</li><li>Olthuis, W., Bergveld, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Simplified+design+of+the+coulometric+sensor-actuator+system+by+the+application+of+a+time-dependent+actuator+current.">Simplified design of the coulometric sensor-actuator system by the application of a time-dependent actuator current.</a> Sensors and Actuators B: Chemical. 7, 479-483 (1992).</li><li>Olthuis, W., Bergveld, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Integrated+coulometric+sensor-actuator+devices.">Integrated coulometric sensor-actuator devices.</a> Microchimica Acta. 121, 191-223 (1995).</li><li>Bard, A. J., Faulkner, L. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Electrochemical methods: fundamentals and applications. , (2001).</li><li>Bakker, E., B&#252;hlmann, P., Pretsch, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Polymer+Membrane+Ion-Selective+Electrodes-What+are+the+Limits?+.">Polymer Membrane Ion-Selective Electrodes-What are the Limits? .</a> Electroanalysis. 11, 915-933 (1999).</li></ol>

The authors have nothing to disclose.

遷移時間は変曲の瞬間です。それは、基準電位、すなわち、参照電極の理論的に独立しています。したがって、任意の金属線は、遷移時間測定のための擬似参照電極として用いることができます。コンクリート中の塩化物イオンの既存の電位差測定とは対照的に、この方法は、長期的かつキャリブレーションのない測定を可能にします。さらに感度及び濃度の検出範囲は、印加される?...

Ag / AgCl電極の遷移時間測定に基づいて、塩化物イオンセンサが提供されます。目的は、電解液中の塩化物イオンの長時間連続監視中に固有のドリフトを回避することです。 Ag / AgCl電極の動的な測定手法であるクロノポテンシオメトリー測定は、この目的のために使用されます。ここでのAg / AgCl電極の電位の変化の割合は、刺激（定電流パルス）の間に測定されます。このアプローチの利点は、次のような現場アプリケーション、従って長期（数年）のためのClイオン濃度の検出を可能にする、液体接合参照電極を逃亡し、代わりに、擬似参照電極としての金属製のワイヤを使用し、 で実証されていますコンクリート構造物内部の測定。 コンクリート構造物中の塩化物イオンが劣化1,2の主要な原因の1つです。これは、補強鋼aで孔食開始します構造3の最終的な失敗でND結果。そのため、コンクリート中のClイオンを測定することは、構造4,5の寿命やメンテナンスサイクルを予測することは避けられません。異なる感知原理は、電気化学的な6,7、光学8,9電磁10,11として、コンクリート中の塩化物イオンの測定のために報告されています。しかし、かさばるセットアップを持っている光学、電磁方法、スタンドアロンシステムとして統合し、選択性12の問題を持ってすることは困難です。電気化学的手法では、銀/塩化銀電極の電位差測定は、技術のアプローチ6,7,13の状態です。有望な結果にもかかわらず、このアプローチは、欠陥のあるデータ14,15における基準電位と拡散電位降下結果のドリフトので、実験室規模の測定に限定されています。動的電気化学測定（DEM）に基づいて、遷移時間のアプローチは、潜在的に問題を軽減することができ16ドリフト 。 DEMでは、適用される刺激に対するシステムの応答は、17から19を測定しました。そのようなシステムの例は、クロノポテンショメトリーです。ここで適用される電流パルスは、電極表面近くにイオンを枯渇させる刺激として使用され、対応する電位応答が測定されます。 Ag / AgCl電極で陽極電流がファラデー反応を開始銀（Ag + CL <img alt="図1" src="/files/ftp_upload/53312/arrow.jpg" /> AgCl + e）は、電極表面近くのClイオンの枯渇をもたらします。電位変化は、印加される電流の関数であり、電解質12,20で（選択）イオンの濃度です。現時点では、これらのイオンは、変曲点21を与え 、完全に電極表面近傍に急速に電位上昇の変化率を枯渇させます。電位 - 時間応答曲線（クロノポテンショグラム）上の変曲点は、​​遷移時間を示すから決定することができます電位応答22の一次導関数の最大値。遷移時間は、イオン濃度の特徴です。このアプローチは、異なるイオン濃度17および電解質23,24のpHを決定するために使用されています。 （電流が印加される）作用電極としてのAg / AgCl電極の場合に枯渇イオンは、塩化物イオン17あろう。したがって、その遷移時間を測定し、その濃度を決定します。

<table><tbody><tr><td>Platinum wire (&amp;ge;99.99% trace metals)</td><td>Sigma Aldrich, the Netherlands</td><td>EP1330-1EA</td><td></td></tr><tr><td>Potassium chloride (BioXtra, &amp;ge;99.0%)</td><td>Sigma Aldrich, the Netherlands</td><td>P9333-500G</td><td></td></tr><tr><td>Potassium hydroxide (90% pure reagent grade)</td><td>Sigma Aldrich, the Netherlands</td><td>484016-1KG</td><td></td></tr><tr><td>Ferric chloride&amp;nbsp;</td><td>Sigma Aldrich, the Netherlands</td><td>451649-1G</td><td></td></tr><tr><td>potassium nitrate (&gt;99% reagent grade)&amp;nbsp;</td><td>Sigma Aldrich, the Netherlands</td><td>P6083-500G</td><td></td></tr><tr><td>Ag/AgCl liquid junction reference electrode&amp;nbsp;</td><td>BASi, USA</td><td>model MF-2079</td><td></td></tr><tr><td>VSP potentiostat</td><td>Biologic Science Instruments, France</td><td>VSP 300</td><td></td></tr><tr><td>Steel wire</td><td>Microlab TU Delft</td><td></td><td></td></tr><tr><td>Silver wire&amp;nbsp;</td><td>Sigma Aldrich, the Netherlands</td><td></td><td></td></tr></tbody></table>

dynamic electrochemical measurement of chloride ions

This protocol describes the dynamic measurement of chloride ions using the transition time of a silver silver chloride (Ag/AgCl) electrode. Silver silver chloride electrode is used extensively for potentiometric measurement of chloride ions concentration in electrolyte. In this measurement, long-term and continuous monitoring is limited due to the inherent drift and the requirement of a stable reference electrode. We utilized the chronopotentiometric approach to minimize drift and avoid the use of a conventional reference electrode. A galvanostatic pulse is applied to an Ag/AgCl electrode which initiates a faradic reaction depleting the Cl&#713; ions near the electrode surface. The transition time, which is the time to completely deplete the ions near the electrode surface, is a function of the ion concentration, given by the Nernst equation. The square root of the transition time is in linear relation to the chloride ion concentration. Drift of the response over two weeks is negligible (59 &#181;M/day) when measuring 1 mM [Cl&#713;]using a current pulse of 10 Am-2. This is a dynamic measurement where the moment of transition time determines the response and thus is independent of the absolute potential. Any metal wire can be used as a pseudo-reference electrode, making this approach feasible for long-term measurement inside concrete structures.

Ag / AgCl電極は、標準的なクリーンルームのプロセスを用いてガラスチップ（ 図1.）上に製造されます。クロノポテンシオメトリー測定セットアップ（ 図2）を使用し、応答をポテンシオスタットを用いて測定しました。遷移時間でのClイオン濃度の影響を観察するために、0.5 M KNO 3バックグラウンド中のClイオンの4、5及び6ミリモルを?...

Watch this Scientific Journal Video about Dynamic Electrochemical Measurement of Chloride Ions at JoVE.com

Dynamic Electrochemical Measurement of Chloride Ions

Dynamic measurement of chloride ions is presented. Transition time of an Ag/AgCl electrode, during a chronopotentiometric technique, can give the concentration of chloride ions in electrolyte. This method does not require a stable conventional reference electrode.

塩化物イオンの動的電気化学測定

This protocol describes the dynamic measurement of chloride ions using the transition time of a silver silver chloride (Ag/AgCl) electrode. Silver silver ...
