We kindly thank Dr. Clemens Wendtner for providing tmuCD40-Ligand-HeLa cell line.

The protocol for the generation of murine CD40-activated B cells (mCD40B) from splenocytes is divided into two parts: Part A demonstrates the preparation of murine CD40 ligand (CD40L) expressing HeLa cells (tmuCD40L HeLa), which will be used as plate-bound feeder cells. Part B describes the actual murine CD40-B culture.
A. Preparation of feeder cells (tmuCD40L HeLa)
The tmuCD40L HeLa is an adherent human epithelial cell line, which should never become completely confluent. The cells are therefore splitted twice per week. Culturing over more than 6 weeks is not recommended.
<ol>
 <li>Remove old medium from the primary culture with a sterile pipette and wash cells with 10 mL of 1x PBS. Aspirate the PBS after washing.</li>
 <li>Add 4 mL of 1x Trypsin/EDTA in a 75 cm2 flask for 10-15 minutes at 37&deg;C. Use gentle tapping to detach the cells.</li>
 <li>Add 10 mL of wild type medium and swivel gently to stop digestion with trypsin.</li>
 <li>Transfer the cell suspension into a 50 mL tube with a sterile pipette and spin the cells down at 265 x g for 7 minutes.</li>
 <li>Remove the supernatant and resuspend the cell pellet in 10 mL of wild type medium. Count the cell number of an aliquot of the cell suspension and prepare three 50 mL tubes with the appropriate number of cells:
 <ol>
 <li>2.5 x 106 cells for subculture</li>
 <li>0.4 x 106 cells/well for irradiation used for the murine CD40-B cell culture</li>
 <li>remainder to freeze (if needed).</li>
 </ol>
 </li>
 <li>Spin the cells down at 265 x g for 7 minutes.</li>
 <li>Remove the supernatant.
 <ol>
 <li>For subculturing: resuspend 2.5 x 106 cells in 10 mL selection medium in a 75 cm2 cell culture flask (cell density 2.5 x 105 cells/mL) and incubate the cells at 37&deg;C with 5 % CO2. Split the cells twice per week.</li>
 <li>For the murine CD40-B cell culture: You need 2.4 x 106 cells for one 6-well plate. Resuspend the tmuCD40L HeLa cells in wild type medium at a density of 0.2 x 106 cells/mL and irradiate them at 78 Gy. Plate 2 mL of the cell suspension into each well and incubate them at 37&deg;C with 5 % CO2. Use this prepared plates for B-cell stimulation when tmuCD40L HeLa cells are adherent (at least 4 hours: check adherence using the microscope; do not wait more than 24 h to start B-cell stimulation). (Continue with B.)</li>
 </ol>
 </li>
</ol>
B. Murine CD40-B cell culture
I. Preparation of splenocytes for CD40-stimulation (day 0):
Please note: before you continue ascertain that feeder cells are adherent. Always add fresh solutions of murine interleukin-4, &beta;-Mercaptoethanol and cyclosporin A to the growth medium immediately before use.
<ol>
 <li>Dissect spleen of C57BL/6 mice (haplotype H-2b) and wash it twice in 10-20 mL DMEM supplemented with Gentamycin [15&mu;g/mL] by transferring it with a 10mL pipette tip from one tube to another. Avoid transferring contaminants (e.g. hair) of the mouse. Mince spleen by passing it through a cell strainer (100&mu;m) and rinse strainer with another 10 mL of medium. Spin down splenocytes at 265 x g for 7 min at room temperature, resuspend them in 7mL muCD40-B cell medium, and separate lymphocytes by Ficoll density centrifugation. To do so layer cells on 5 mL Mouse-Pancoll (preheated at room temperature) in a 15 mL tube and centrifuge at 450 x g for 30 min without brake at room temperature. </li>
 <li>Draw off most of the upper layer, leaving the lymphocyte layer undisturbed at the interface. Transfer lymphocyte layer to a fresh 50 mL tube, wash once with 30mL DMEM with Gentamycin [15&mu;g/mL] by spinning down at 265 x g for 7 min to remove other cells. Discard the supernatant and resuspend the cells in 10 mL of mCD40-B washing medium. Determine the cell number in an aliquot of the cell suspension. Determine cell number by counting an aliquot of the cell suspension.</li>
 <li>Spin down the required amount of cells at 265 x g for 7 minutes. For a 6-well plate 5 x 106 cells/well are needed, thus 30 x 106 cells per plate. </li>
 <li>Remove the supernatant and resuspend the lymphocytes at 1.25 x 106 cells/mL in mCD40-B culture medium freshly supplemented with 1 U/mL of interleukin-4 as growth factor, 100 &mu;M &beta;-Mercaptoethanol and 0.63 &mu;g/mL cyclosporin A to prevent outgrowth of T-cells (Given concentrations refer to one mL culture medium!). </li>
 <li>Remove the supernatant from the 6-well plate pre-incubated with tmuCD40L HeLa cells. </li>
 <li>Gently add 4 mL of the lymphocyte suspension (1.25 x 106 cells/mL) to each well of the 6-well plate. </li>
 <li>Incubate the plate at 37&deg;C with 5 % CO2. </li>
 <li>On day 3 reculture the cells (Continue with II.1.). </li>
</ol>
II. Subculture of mCD40B cells (day 3 and then twice a week):
<ol>
 <li>Harvest mCD40B cell cluster by vigorously pipetting up and down with a 10 mL pipette and pool them into a 50 mL tube.</li>
 <li>Spin down at 265 x g for 7 minutes and completely replace the supernatant with mCD40-B washing medium. While counting the cell amount of an aliquot, spin the cells down at 265 x g for 7 minutes. Resuspend mCD40B cells in mCD40-B culture medium at a concentration of 0.75 x 106 cells/mL.</li>
 <li>Add fresh solutions of murine interleukin-4 in a concentration of 1 U/mL, 100 &mu;M &beta;-Mercaptoethanol and 0.63 &mu;g/mL cyclosporin A to the medium.</li>
 <li>Remove the supernatant from a 6-well plate pre-incubated with irradiated tmuCD40L HeLa cells.</li>
 <li>Gently add 4 mL of the mCD40B cell suspension (0.75 x 106cells/mL) to each well of the 6-well plate.</li>
 <li>Incubate plates at 37&deg;C with 5 % CO2.</li>
 <li>Again subculture the cells every 3-4 days to end up with highly pure murine CD40-activated B cells after a total of 14 days. </li>
</ol>
C. Trouble-shooting: What if CD40-B cells do not grow?
<ol>
 <li>Have you checked for CD40 ligand expression of feeder cells?</li>
 <li>Are the plate-bound feeder cells used for the stimulation older than 24h?</li>
 <li>Is there a contamination with mycoplasma?</li>
 <li>Was the interleukin-4 solution used for supplementation freshly thawed and did it have the appropriate biological activity?</li>
 <li>Was &beta;-Mercaptoethanol and cyclosporin A added in the correct concentration?</li>
</ol>

<img src="/files/ftp_upload/1734/1734fig1a.jpg" alt="Figure 1 a" /> Figure 1a.
<img src="/files/ftp_upload/1734/1734fig1b.jpg" alt="Figure 1 b" /> Figure 1b.
<img src="/files/ftp_upload/1734/1734fig1d.jpg" alt="Figure 1 d" /> Figure 1d.
<img src="/files/ftp_upload/1734/1734fig2.jpg" alt="Figure 2" /> Figure 2.

<ol>
	<li>Schultze, J. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD40-activated+human+B+cells:+an+alternative+source+of+highly+efficient+antigen+presenting+cells+to+generate+autologous+antigen-specific+T+cells+for+adoptive+immunotherapy.">CD40-activated human B cells: an alternative source of highly efficient antigen presenting cells to generate autologous antigen-specific T cells for adoptive immunotherapy.</a> J Clin Invest. 100 (11), 2757-2765 (1997).</li><li>Wiesner, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Conditional+immortalization+of+human+B+cells+by+CD40+ligation.">Conditional immortalization of human B cells by CD40 ligation.</a> PLoS ONE. 3, e1464-e1464 (2008).</li><li>Kondo, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+generation+of+antigen-specific+cytotoxic+T+cells+using+retrovirally+transduced+CD40-activated+B+cells.">Efficient generation of antigen-specific cytotoxic T cells using retrovirally transduced CD40-activated B cells.</a> J Immunol. 169 (4), 2164-2171 (2002).</li><li>Liebig, T. M., Fiedler, A., Zoghi, S., Shimabukuro-Vornhagen, A., Bergwelt-Baildon, M. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Generation+of+human+CD40-activated+B+cells.">Generation of human CD40-activated B cells.</a> J Vis Exp. 32, (2009).</li><li>von Bergwelt-Baildon, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD40-activated+B+cells+express+full+lymph+node+homing+triad+and+induce+T-cell+chemotaxis:+potential+as+cellular+adjuvants.">CD40-activated B cells express full lymph node homing triad and induce T-cell chemotaxis: potential as cellular adjuvants.</a> Blood. 107 (7), 2786-2789 (2006).</li><li>Lapointe, R., Bellemare-Pelletier, A., Housseau, F., Thibodeau, J., Hwu, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD40-stimulated+B+lymphocytes+pulsed+with+tumor+antigens+are+effective+antigen-presenting+cells+that+can+generate+specific+T+cells.">CD40-stimulated B lymphocytes pulsed with tumor antigens are effective antigen-presenting cells that can generate specific T cells.</a> Cancer Res. 63 (11), 2836-2843 (2003).</li><li>Ahmadi, T., Flies, A., Efebera, Y., Sherr, D. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD40+Ligand-activated,+antigen-specific+B+cells+are+comparable+to+mature+dendritic+cells+in+presenting+protein+antigens+and+major+histocompatibility+complex+class+I-+and+class+II-binding+peptides.">CD40 Ligand-activated, antigen-specific B cells are comparable to mature dendritic cells in presenting protein antigens and major histocompatibility complex class I- and class II-binding peptides.</a> Immunology. 124 (1), 129-140 (2008).</li><li>Bergwelt-Baildon, M. S. v. o. n. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Human+primary+and+memory+cytotoxic+T+lymphocyte+responses+are+efficiently+induced+by+means+of+CD40-activated+B+cells+as+antigen-presenting+cells:+potential+for+clinical+application.">Human primary and memory cytotoxic T lymphocyte responses are efficiently induced by means of CD40-activated B cells as antigen-presenting cells: potential for clinical application.</a> Blood. 99 (9), 3319-3325 (2002).</li><li>Kondo, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CD40-activated+B+cells+can+be+generated+in+high+number+and+purity+in+cancer+patients:+analysis+of+immunogenicity+and+homing+potential.">CD40-activated B cells can be generated in high number and purity in cancer patients: analysis of immunogenicity and homing potential.</a> Clin Exp Immunol. 155 (2), 249-256 (2009).</li><li>Schultze, J. L., Grabbe, S., von Bergwelt-Baildon, M. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DCs+and+CD40-activated+B+cells:+current+and+future+avenues+to+cellular+cancer+immunotherapy.">DCs and CD40-activated B cells: current and future avenues to cellular cancer immunotherapy.</a> Trends Immunol. 25 (12), 659-664 (2004).</li><li>Mayr, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chromosomal+translocations+are+associated+with+poor+prognosis+in+chronic+lymphocytic+leukemia.">Chromosomal translocations are associated with poor prognosis in chronic lymphocytic leukemia.</a> Blood. 107 (2), 742-751 (2006).</li><li>Mason, N. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RNA-loaded+CD40-activated+B+cells+stimulate+antigen-specific+T-cell+responses+in+dogs+with+spontaneous+lymphoma.">RNA-loaded CD40-activated B cells stimulate antigen-specific T-cell responses in dogs with spontaneous lymphoma.</a> Gene Ther. 15 (13), 955-965 (2008).</li></ol>

The experiments were performed in accordance with the national and European guidelines for laboratory animal keeping. Referring the German animal welfare law the animals were controlled regularly by the proper authorities.

Modifications of this protocol are possible, especially regarding the origin of CD40-stimulus and the type of mouse strain used, also yielding in efficient generation of murine CD40-activated B cells. Ahmadi et al. have shown similar results for mouse fibroblasts transfected with murine CD40-Ligand. In this context presentation of xeno-antigen can be excluded with certainty, but intensive studies regarding security and toxicity in vivo gave no signs for inflammation or auto-immunity reaction in this setting usin...

A. Preparation of Media:
<table border="1">
<tbody>
 <tr>
 <td>Feeder cell wild type medium</td>
 <td>Feeder cell selection medium</td>
 <td>&nbsp;</td>
 </tr>
 <tr>
 <td>Reagent</td>
 <td>Concentration</td>
 <td>Reagent</td>
 <td>Concentration</td>
 </tr>
 <tr>
 <td>RPMI 1640</td>
<td>&nbsp;</td>
 <td>RPMI 1640</td>
<td>&nbsp;</td>
</tr>
 <tr>
 <td> L-Glutamine</td>
 <td>300 &mu;g/mL</td>
 <td> L-Glutamine</td>
 <td>300 &mu;g/mL</td>
 </tr>
 <tr>
 <td>FBS</td>
 <td>10 %</td>
 <td>FBS</td>
 <td>10 %</td>
 </tr>
 <tr>
 <td>HEPES</td>
 <td>10 mM</td>
 <td>HEPES</td>
 <td>10 mM</td>
 </tr>
 <tr>
 <td>Gentamycin</td>
 <td>15 &mu;g/mL</td>
 <td>Gentamycin</td>
 <td>15 &mu;g/mL</td>
 </tr>
 <tr>
<td>&nbsp;</td><td>&nbsp;</td> <td>Hygromycin B</td>
 <td>0.2 mg/mL</td>
 </tr>
</table>
<table border="1">
 <tbody>
 <tr>
 <td>mCD40-B washing medium</td>
 <td>mCD40-B culture medium</td>
 </tr>
 <tr>
 <td>Reagent</td>
 <td>Concentration</td>
 <td>Reagent</td>
 <td>Concentration</td>
 </tr>
 <tr></tr>
 <tr>
 <td>D-MEM</td>
 <td>
 </td>
 <td>D-MEM</td>
 <td>
 </td>
 </tr>
 <tr>
 <td>L-Glutamine</td>
 <td>580 &mu;g/mL</td>
 <td>L-Glutamine</td>
 <td>580 &mu;g/mL</td>
 </tr>
 <tr>
 <td>Glucose</td>
 <td>4.5 mg/mL</td>
 <td>Glucose</td>
 <td>4.5 mg/mL</td>
 </tr>
 <tr>
 <td>HEPES</td>
 <td>10 mM</td>
 <td>HEPES</td>
 <td>10 mM</td>
 </tr>
 <tr>
 <td>Gentamycin</td>
 <td>15 &mu;g/mL</td>
 <td>Gentamycin</td>
 <td>15 &mu;g/mL</td>
 </tr>
 <tr>
 <td>
 </td>
 <td>
 </td>
 <td>MEM</td>
 <td>0.1mM (1x)</td>
 </tr>
 <tr>
 <td>
 </td>
 <td>
 </td>
 <td>FBS</td>
 <td>10%</td>
 </tr>
 </tbody>
</table>
B. Miscellaneous Reagents:
<table border="1">
 <tr>
 <td>Reagent</td>
 <td>Company</td>
 <td>Order No</td>
 </tr>
 <tr>
 <td>RPMI 1640</td>
 <td>Invitrogen Gibco&#174;</td>
 <td>REF 21875</td>
 </tr>
 <tr>
 <td>D-MEM</td>
 <td>Invitrogen Gibco&#174;</td>
 <td>REF 41965</td>
 </tr>
 <tr>
 <td>Dulbecco&#180;s PBS (10x)</td>
 <td>PAA</td>
 <td>Cat No H15-011</td>
 </tr>
 <tr>
 <td>Gencin&#174;</td>
 <td>Delta Select</td>
 <td>Art No 7395800</td>
 </tr>
 <tr>
 <td>FBS</td>
 <td>LONZA</td>
 <td>Cat No DE14-802C</td>
 </tr>
 <tr>
 <td>HEPES Buffer</td>
 <td>PAA</td>
 <td>Cat No S11-001</td>
 </tr>
 <tr>
 <td>MEM NEAA</td>
 <td>Invitrogen Gibco&#174;</td>
 <td>REF 11140</td>
 </tr>
 <tr>
 <td>Hygromycin B</td>
 <td>PAA</td>
 <td>Cat No P02-015</td>
 </tr>
 <tr>
 <td>Recombinant Murine Interleukin-4</td>
 <td>Immunotools</td>
 <td>Cat No 12340045</td>
 </tr>
 <tr>
 <td>Cyclosporin A</td>
 <td>Novartis</td>
 <td>Cat No NDC 0078-0109-01</td>
 </tr>
 <tr>
 <td>Trypsin/EDTA (10x)</td>
 <td>Invitrogen Gibco&#174;</td>
 <td>REF 15400-054</td>
 </tr>
</table>
C. Miscellaneous Supplies:
<table border="1">
<tbody>
 <tr>
 <td>Reagent</td>
 <td>Company</td>
 <td>Order No</td>
 </tr>
 <tr>
 <td>Sterile pipette tips</td>
 <td>Sarstedt</td>
 <td>&nbsp;</td>
 </tr>
 <tr>
 <td>6-well plate</td>
 <td>NUNC</td>
 <td>Cat No 140675</td>
 </tr>
 <tr>
 <td>50mL conical tube</td>
 <td>BD Falcon&trade;</td>
 <td>Cat No 352070</td>
 </tr>
 <tr>
 <td>Tissue culture flask</td>
 <td>Sarstedt</td>
 <td>Cat No 83.1813.002</td>
 </tr>
</tbody>
</table>
