R01HL138932, RO1HL133100, RO1HL128970, AHACDA34700025

All experimental protocols have been approved by the Institutional Animal Care and Use Committee (MO18M211).
1. Leptin Infusion
NOTE: In order to examine the effect of leptin on breathing, we infused leptin subcutaneously in lean C57BL/6J mice by an osmotic pump to raise circulating leptin levels to those observed in obese mice.
<ol>
	<li>Osmotic pump preparation
	<ol>
		<li>Weigh the empty pump to check the net weight of the solution loaded.</li>
		<li>Add Leptin (5 mg/mL) to the osmotic pump (1 &#956;L/h for 3 days). Fill the pump with a small syringe (1 mL). After filling, close the pump with the provided blunt tipped 27 gauge filling tube.
		NOTE: The syringe and the attached tube should be free of air bubbles.</li>
		<li>After filling, weigh the pump again to check the net weight of the solution.</li>
		<li>Insert the leptin pump subcutaneously in the interscapular area.
		NOTE: If you want to start the infusion immediately, incubate the pre-filled pump in the sterile saline at 37 &#176;C for at least 4 to 6 h (preferably overnight).</li>
	</ol>
	</li>
</ol>
2. Hypoxic Ventilatory Response (HVR)
NOTE: Thermoneutral conditions eliminate stressful factors imposed by cool ambient temperature and significantly modify metabolism in mice. Therefore, all respiratory measurements should be performed at the thermoneutral conditions (t = 30 &#176;C) using a neonatal incubator12 (Figure 1A). The whole body plethysmography chamber (WBP) has been used for all measurements. All animals should be acclimated to the barometric plethysmography chamber and to a sham neck collar for subsequent pulse oximetry recording for 3-5 days prior to the HVR measurements. HVR is recorded between 10 AM and 5 PM. HVR is suppressed during sleep, therefore it can be measured separately during sleep and quiet wakefulness13. To ensure the specific sleep-wake stage of the animal during the HVR measurement, EEG/EMG electrodes should be implanted as an EEG/EMG headmount as previously described14. Animals should be allowed to recover for at least 72 h after the headmount. Sleep staging should be performed in 5 s epochs. NREM sleep is recognized by the slow wave EEG activity occupying greater than 50% of the epoch. Quiet wakefulness is manifested by the alpha EEG activity in the absence of movements. REM sleep is identified by the predominant alpha and theta EEG activity in the presence of reduced muscle tone on EMG. Typically, REM sleep is not observed during the HVR gas challenges.
<ol>
	<li>The HVR recording protocol
	<ol>
		<li>Use the WBP chamber of the following size: internal diameter of 80 mm, height of 50.5 mm, and volume of 0.4 L. The WBP chamber consists of two chambers, sealed and reference chambers, and a circular platform to place the mouse14 (Figure 1B). Inflow and outflow inside the chamber are controlled by positive and negative pressure sources maintaining the atmospheric pressure. This control creates a steady bias flow in the chamber and prevents CO2 retention. For more details about the WBP set up, see Hernandez and colleagues15.</li>
		<li>Measure the temperature inside the chamber and the relative humidity in the room prior to placing the mouse in the WBP.</li>
		<li>Measure the body weight and rectal temperature.</li>
		<li>Put the oximeter collar around the neck of the mouse (the area should be previously shaved).</li>
		<li>Place the mouse inside the WBP and ensure that the chamber is completely sealed in order to avoid air leakages.</li>
		<li>Wait for approximately 30 min until the mouse is quiet and the chamber is at a constant volume.</li>
		<li>Normoxia: after 30 min, if the mouse is quiet, start recording the respiratory signals and peripheral oxygen saturation (SpO2) at normoxia phase (21% FiO2 at 1 atm of pressure) for 20 min, using LabChart 7 Pro (version 7.2).</li>
		<li>Hypoxia: after 20 min of quiet normoxia, start recording the first cycle of acute hypoxia and SpO2. For hypoxia phase, expose the animals to a constant mixed gas flow composed by 10% O2 and 3% CO2 for 5 min.
		<ol>
			<li>During the first 30 sec of hypoxia, the mixed gas flows through the chamber via 2 small side ports at the base allowing the FiO2 to drop from 21% (at 1 atm of pressure) to 10%.</li>
			<li>After the initial 30 s, close one of the small side ports of the WBP chamber and keep recording at the constant hypoxia at 10% FiO2 for 5 min.
			NOTE: The mixture of 10% O2 and 3% CO2 at hypoxia is used in order to maintain eucapnea11.</li>
		</ol>
		</li>
		<li>After the 5 min of hypoxia, expose the mouse to room air again (21% FiO2 at 1 atm of pressure) by switching the inflow source.</li>
		<li>Wait for at least 30 min until the next normoxia recording in order to recover from the previous hypoxic exposure to avoid the ventilatory roll-off phenomenon (i.e., central suppression of breathing during hypoxia16).
		NOTE: Repeat normoxia/hypoxia cycles three times in each mouse to assure reproducibility of the measurements. In our experience, additional (greater than 3 times on a given day) hypoxic exposures should be avoided, because of the ventilatory adaptation (the roll-off phenomenon).</li>
		<li>At the end of the experiment, calibrate the WBP chamber (with the mouse is still inside) by injecting 1 mL of room air 3 times with a syringe plugged in one of the small side ports at the base of the chamber.</li>
		<li>Measure the temperature in the chamber again with the animal inside it.</li>
		<li>Open the chamber and measure the rectal temperature of the mouse before placing it back to its home cage.</li>
	</ol>
	</li>
	<li>HVR calculation
	<ol>
		<li>Digitize all signals for HVR calculation at 1,000 Hz (sampling frequency per channel).
		NOTE: WBP tidal volume analysis is performed in Lab Chart 7 based on Drorbaugh and Fenn equation17. Required variables comprise mouse rectal temperature and the chamber temperature (before and after HVR measurement), relative humidity, and the chamber gas constant. This constant is resultant from WBP pressure deflection after the 1 mL injections of air in the calibration phase. For more details, see Hernandez and colleagues15.</li>
		<li>After calculating the Drorbaugh and Fenn equation, multiply the tidal volume (Vt) chamber channel by the constant.</li>
		<li>Selection of recordings for the analysis
		<ol>
			<li>Normoxia: select only sections of steady breathing with constant tidal volume. Avoid sections in close proximity to mouse&#8217;s movements.</li>
			<li>Hypoxia: discard first 30 s when O2 levels are declining from 21% to 10%, select sections from 30 s to 2 min of 10% O2 exposure (a 90 s interval). Within this interval, select only sections with steady breathing with constant tidal volume. Avoid sections in close proximity to mouse&#8217;s movements. The analysis is reliable if at least 10 s of hypoxia is selected in each cycle.
			NOTE: The peripheral component of chemoreflex governed by CB predominates during the first 1-2 min of exposure16,18,19. During the second phase, between 2 min and 5 min of hypoxic exposure, both peripheral and central component play a role. Finally, the third phase, &#62; 5 min, is characterized by hypoventilation (the roll-off phenomenon) governed predominantly by central chemoreceptors. Our experience shows that mice are often awake during hypoxic exposition because of the manual switches in the airflow source.</li>
		</ol>
		</li>
		<li>After the selection, calculate the mean minute ventilation (VE) at normoxic and hypoxic conditions using the formula VE = respiratory rate X tidal volume.</li>
		<li>Calculate the mean SpO2 at normoxia and hypoxia conditions.</li>
		<li>Calculate the HVR manually using the formula HVR = (VE (10% O2) - VE (21%O2)) / (SpO2 (10% O2) &#8211; SpO2 (21% O2)).
		NOTE: In C57BL/6J mice, the osmotic pump for leptin infusion may impair the accurate SpO2 signal detection by the neck collar. In this case, HVR is calculated based on the FiO2 values at normoxic and hypoxic conditions as HVR = &#916;VE / &#916;FiO211.</li>
	</ol>
	</li>
</ol>
3. Carotid Body Denervation or Carotid Sinus Nerve Dissection (CSND)
NOTE: We performed combined surgical and chemical denervation one week apart, because surgical denervation alone does not abolish the hypoxic chemoreflex.
<ol>
	<li>Surgical preparation
	<ol>
		<li>Perform all the procedures on adult male C57BL/6J mice. Sterilize all surgical instruments. Use sterile surgical gloves, syringes and cotton tipped applicators.</li>
		<li>Anesthetize male C57BL/6J mice with 1-2% isoflurane using a nose cone and place a warm blanket to prevent hypothermia. Isoflurane is carefully titrated to maintain respiratory rate at 1 Hz (60 breaths/min). The adequacy of anesthesia prior to starting surgeries will be assessed by the breathing frequency, the absence of movements and audible noises, the absence of response to tactile stimuli and the forelimb or hindlimb pedal withdrawal reflex.</li>
		<li>Administer Buprenorphine (0.05 mg/kg) intraperitoneally to prevent pain discomfort. Remove the hair at ventral region of the neck and disinfect the area with betadine and alcohol.</li>
		<li>To prevent corneal desiccation, lubricate the mice&#8217;s eyes with sterile ophthalmic ointment during anesthesia.</li>
	</ol>
	</li>
	<li>CSND procedures
	Stage 1: Surgical denervation
	<ol>
		<li>After midline incision, expose the bifurcation of the common carotid arteries by removing connective tissues and adipose tissue.</li>
		<li>Identify the hypoglossal nerve, which is usually very prominent, and then lift it up to expose the glossopharyngeal nerve immediately underneath. Dissect carotid sinus nerves bilaterally using micro spring scissors.</li>
		<li>Close the incision with 6-0 silk suture.</li>
		<li>Administer 1 mL of normal saline subcutaneously to prevent dehydration.</li>
		<li>House the mice in a recovery chamber and monitor their behavior every 15 min for initial 1 h until the mice regain consciousness to maintain sternal recumbency. Return the mice to their home cages after they are fully recovered. Keep monitoring the mice twice per day for next 3 days. Give additional buprenorphine if mice show any signs of pain (e.g., reduced appetite, restlessness).
		Stage 2: Chemical denervation</li>
		<li>One week after the surgery, paint the carotid artery with a solution of 2% phenol diluted in ethanol at the points of branching from the glossopharyngeal nerve to the cranial pole of the CB. The same post-operative care should be provided after the chemical denervation as described above in the surgical denervation section.
		NOTE: For a sham surgery group, the same procedures are performed except the carotid sinus nerve dissection.</li>
		<li>Let the animals recover for 5-7 days before HVR measurements.</li>
	</ol>
	</li>
</ol>
4. Expression of LepRb in the CB using an adenoviral vector (Ad-LepRb) vs control (Ad-LacZ)
<ol>
	<li>Ad-LepRb and Ad-LacZ suspension
	<ol>
		<li>Transfect the mice with adenovirus (Ad-LepRb-GFP, 2-5x1010 pfu/mL for overexpression, Ad-Lacz, 1 x 1010 pfu/mL for control) to the CB area.</li>
		<li>Thaw the Matrigel matrix by submerging the vial in ice in a 4 &#176;C refrigerator overnight.</li>
		<li>Gently suspend adenovirus in liquid Matrigel matrix at 1:5 (1 &#956;L of Matrigel matrix and 4 &#956;L of adenovirus applied bilaterally).</li>
		<li>Always keep viral suspension on ice until it is applied in the CB.</li>
	</ol>
	</li>
	<li>Surgical preparation
	<ol>
		<li>Use the same surgical instruments as the CSND protocol.</li>
		<li>Anesthetize LepRb-deficient db/db mice with 2-2.5% isoflurane using a nose cone and place the animals on a warm blanket to prevent hypothermia. Isoflurane is carefully titrated to maintain respiratory rate at 1 Hz (60 breaths/min). The adequacy of anesthesia will be assessed by the breathing frequency, the absence of movements and audible noises, the absence of response to tactile stimuli and the forelimb or hindlimb pedal withdrawal reflex.</li>
		<li>Administer buprenorphine (0.05 mg/kg) intraperitoneally.</li>
		<li>Remove the hair at ventral region of the neck and disinfect the area with betadine and alcohol as in the CSND protocol.</li>
		<li>To prevent corneal desiccation, lubricate the mice&#8217;s eyes with sterile ophthalmic ointment during anesthesia.</li>
	</ol>
	</li>
	<li>Adenovirus treatment of the CB
	<ol>
		<li>Expose CBs as described in the CSND protocol and apply 5 &#956;L of the viral suspension to the CB area bilaterally.</li>
		<li>Wait 2-3 min until the liquid Matrigel matrix becomes a gel. After confirming that the viral suspension was congealed, close the incision with 6.0 silk suture.</li>
	</ol>
	</li>
	<li>After surgery
	<ol>
		<li>House the mice in a recovery chamber and monitor their behavior every 15 min for initial 1 h until the mice regain consciousness to maintain sternal recumbency. Return the mice to their home cages after they are fully recovered. Keep monitoring the mice twice per day for next 3 days. Give additional buprenorphine if mice show any signs of pain (e.g., reduced appetite, restlessness).</li>
		<li>Administer Buprenorphine (0.05 mg/kg) intraperitoneally as needed to prevent pain discomfort during the post-operative period.</li>
		<li>Measure HVR 9 days after the adenovirus transfection.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>O'donnell, C. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Leptin+prevents+respiratory+depression+in+obesity.">Leptin prevents respiratory depression in obesity.</a> American Journal of Respiratory and Critical Care Medicine. 159, 1477-1484 (1999).</li><li>Polotsky, V. Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Female+gender+exacerbates+respiratory+depression+in+leptin-deficient+obesity.">Female gender exacerbates respiratory depression in leptin-deficient obesity.</a> American Journal of Respiratory and Critical Care Medicine. 164, 1470-1475 (2001).</li><li>Bassi, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Central+leptin+replacement+enhances+chemorespiratory+responses+in+leptin-deficient+mice+independent+of+changes+in+body+weight.">Central leptin replacement enhances chemorespiratory responses in leptin-deficient mice independent of changes in body weight.</a> Pflu&#776;gers Archiv: European Journal of Physiology. 464, 145-153 (2012).</li><li>Inyushkina, E. M., Merkulova, N. A., Inyushkin, A. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+of+the+respiratory+activity+of+leptin+at+the+level+of+the+solitary+tract+nucleus.">Mechanisms of the respiratory activity of leptin at the level of the solitary tract nucleus.</a> Neuroscience and Behavioral Physiology. 40, 707-713 (2010).</li><li>Considine, R. V., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Serum+immunoreactive-leptin+concentrations+in+normal-weight+and+obese+humans.">Serum immunoreactive-leptin concentrations in normal-weight and obese humans.</a> New England Journal of Medicine. 334, 292-295 (1996).</li><li>Maffei, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Leptin+levels+in+human+and+rodent:+measurement+of+plasma+leptin+and+ob+RNA+in+obese+and+weight-reduced+subjects.">Leptin levels in human and rodent: measurement of plasma leptin and ob RNA in obese and weight-reduced subjects.</a> Nature Medicine. 1, 1155-1161 (1995).</li><li>Phipps, P. R., Starritt, E., Caterson, I., Grunstein, R. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Association+of+serum+leptin+with+hypoventilation+in+human+obesity.">Association of serum leptin with hypoventilation in human obesity.</a> Thorax. 57, 75-76 (2002).</li><li>Berger, S., Polotsky, V. Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Leptin+and+Leptin+Resistance+in+the+Pathogenesis+of+Obstructive+Sleep+Apnea:+A+Possible+Link+to+Oxidative+Stress+and+Cardiovascular+Complications.">Leptin and Leptin Resistance in the Pathogenesis of Obstructive Sleep Apnea: A Possible Link to Oxidative Stress and Cardiovascular Complications.</a> Oxidative Medicine and Cellular Longevity. 2018, 5137947 (2018).</li><li>Ribeiro, M. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High+fat+diet+blunts+the+effects+of+leptin+on+ventilation+and+on+carotid+body+activity.">High fat diet blunts the effects of leptin on ventilation and on carotid body activity.</a> The Journal of Physiology. 96, 3187-3199 (2018).</li><li>Yuan, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Leptin+signaling+in+the+carotid+body+regulates+a+hypoxic+ventilatory+response+through+altering+TASK+channel+expression.">Leptin signaling in the carotid body regulates a hypoxic ventilatory response through altering TASK channel expression.</a> Frontiers in Physiology. 9, 249 (2018).</li><li>Caballero-Eraso, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Leptin+acts+in+the+carotid+bodies+to+increase+minute+ventilation+during+wakefulness+and+sleep+and+augment+the+hypoxic+ventilatory+response.">Leptin acts in the carotid bodies to increase minute ventilation during wakefulness and sleep and augment the hypoxic ventilatory response.</a> The Journal of Physiology. 591, 151-172 (2018).</li><li>Jun, J. C., Shin, M. K., Yao, Q., Devera, R., Fonti-Bevans, S., Polotsky, V. Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Thermoneutrality+modifies+the+impact+of+hypoxia+on+lipid+metabolism.">Thermoneutrality modifies the impact of hypoxia on lipid metabolism.</a> American Journal of Physiology Endocrinology and Metabolism. 304, 424-435 (2012).</li><li>Polotsky, V. Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Impact+of+interrupted+leptin+pathways+on+ventilatory+control.">Impact of interrupted leptin pathways on ventilatory control.</a> Journal of Applied Physiology. 96, 991-998 (2004).</li><li>Pho, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+leptin+replacement+on+sleep-disordered+breathing+in+the+leptin-deficient+ob/ob+mouse.">The effect of leptin replacement on sleep-disordered breathing in the leptin-deficient ob/ob mouse.</a> Journal of Applied Physiology. 120, 78-86 (2016).</li><li>Hernandez, A. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+whole+body+plethysmography+system+for+the+continuous+characterization+of+sleep+and+breathing+in+a+mouse.">Novel whole body plethysmography system for the continuous characterization of sleep and breathing in a mouse.</a> Journal of Applied Physiology. 112, 671-680 (2012).</li><li>Powell, F. L., Milsom, W. K., Mitchell, G. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Time+domains+of+the+hypoxic+ventilatory+response.">Time domains of the hypoxic ventilatory response.</a> Respiration Physiology. 112, 123-134 (1998).</li><li>Drorbaugh, J. E., Fenn, W. O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+barometric+method+for+measuring+ventilation+in+newborn+infants.">A barometric method for measuring ventilation in newborn infants.</a> Pediatrics. 16, 81-87 (1955).</li><li>Duffin, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Measuring+the+ventilatory+response+to+hypoxia.">Measuring the ventilatory response to hypoxia.</a> The Journal of Physiology. 587, 285-293 (2007).</li><li>Teppema, L. J., Dahan, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Ventilatory+Response+to+Hypoxia+in+Mammals:+Mechanisms,+Measurement,+and+Analysis.">The Ventilatory Response to Hypoxia in Mammals: Mechanisms, Measurement, and Analysis.</a> Physiological Reviews. 90, 675-754 (2010).</li><li>Nurse, C. A., Fearon, I. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Carotid+body+chemoreceptors+in+dissociated+cell+culture.">Carotid body chemoreceptors in dissociated cell culture.</a> Microscopy Research and Technique. 59, 249-255 (2002).</li><li>Kumar, P., Prabhakar, N. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Peripheral+chemoreceptors:+function+and+plasticity+of+the+carotid+body.">Peripheral chemoreceptors: function and plasticity of the carotid body.</a> Comprehensive Physiology. 2, 141-219 (2012).</li><li>Roux, J. C., Peyronnet, J., Pascual, O., Dalmaz, Y., Pequignot, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ventilatory+and+central+neurochemical+reorganisation+of+O2+chemoreflex+after+carotid+sinus+nerve+transection+in+rat.">Ventilatory and central neurochemical reorganisation of O2 chemoreflex after carotid sinus nerve transection in rat.</a> The Journal of Physiology. 522, 493-501 (2000).</li></ol>

The authors have no conflicting interests or disclosures.

The main focus of our study was to examine respiratory effects of leptin signaling in the CB. Several protocols have been developed to assess the role of leptin in a mechanistic fashion. First, specific contribution of CB to the HVR was analyzed by careful quantification of the HVR during the first 2 min of hypoxic exposure. Second, the relevance of CB in leptin-mediated up-regulation of control of breathing was examined by two complementary approaches. In lean wild-type mice with low leptin levels, the HVR was measured ...

An adipocyte produced hormone leptin acts in the hypothalamus to suppress food intake and increase metabolic rate. Studies performed in our laboratory1,2 and by other investigators3,4 showed that leptin increases the hypercapnic ventilatory response (HVR) preventing obesity hypoventilation in leptin deficient obesity. However, a majority of obese individuals have high plasma leptin levels and demonstrate resistance to the metabolic and respiratory effects of the hormone5,6,7,8. Resistance to leptin is multifactorial, but limited permeability of the blood-brain barrier (BBB) to leptin plays a major role. We propose that leptin acts below BBB in a key organ of peripheral hypoxic sensitivity, the carotid bodies (CB), to defend breathing in obese individuals. CBs express the long functional isoform of leptin receptor, LepRb, but the role of CB in respiratory effects of leptin has not been sufficiently elucidated9,10.
The goal of our method was to examine the effect of leptin signaling in the CB on HVR. Our rationale was to perform (a) loss of function experiments infusing leptin in mice with intact carotid bodies and denervated carotid bodies followed by HVR measurements; (b) gain of function experiments in db/db mice lacking LepRb, in which we measured the HVR at baseline and after expression of LepRb exclusively in CB. The advantage of our techniques was that we performed all our experiments in unrestrained unanesthetized mice during sleep and wakefulness. Previous investigators either performed their experiments under anesthesia9 or did not measure effects of leptin during sleep10. In addition, our study is the first to utilize a unique gain of function approach with selective LepRb expression in CB described above.
In the broad context, our approach can be generalized to other receptors expressed in CB and their role in hypoxic sensitivity. Investigators can infuse a ligand to a receptor of interest and measure the HVR at baseline and after CB denervation. As a complementary approach, a receptor of interest can be overexpressed in CB and HVR measurements can be performed before and after overexpression using our technology described in this manuscript.

<table>
	<tbody>
		<tr>
			<td>1ml Insulin Syringes</td>
			<td>BD Biosciences</td>
			<td>309311</td>
			<td></td>
		</tr>
		<tr>
			<td>1x PBS (pH 7.4)</td>
			<td>Gibco</td>
			<td>10010-023</td>
			<td>500 ml</td>
		</tr>
		<tr>
			<td>Ad-Lacz</td>
			<td>Dr. Christopher Rhodes (University of Chicago)</td>
			<td></td>
			<td>1x1010 pfu/ml</td>
		</tr>
		<tr>
			<td>Ad-LepRb-GFP</td>
			<td>Vector Biolabs</td>
			<td>ADV-263380</td>
			<td>2-5x1010 pfu/ml</td>
		</tr>
		<tr>
			<td>Anesthetic cart</td>
			<td>Atlantic Biomedical</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Betadine</td>
			<td>Purdue Products Ltd.</td>
			<td>12496-0757-5</td>
			<td></td>
		</tr>
		<tr>
			<td>Buprenorphine (Buprenex)</td>
			<td>Reckitt Benckiser Healthcare Ltd.</td>
			<td>12496-0757-5</td>
			<td>0.3mg/ml</td>
		</tr>
		<tr>
			<td>C57Bl/6J</td>
			<td>Jackson laboratory</td>
			<td>000664</td>
			<td>Mice Strain</td>
		</tr>
		<tr>
			<td>Cotton Gauze Sponges</td>
			<td>Fisherbrand</td>
			<td>22-362-178</td>
			<td></td>
		</tr>
		<tr>
			<td>db/db</td>
			<td>Jackson laboratory</td>
			<td>000697</td>
			<td>Mice Strain</td>
		</tr>
		<tr>
			<td>Ethanol</td>
			<td>Pharmco-AAPER</td>
			<td>111000200</td>
			<td></td>
		</tr>
		<tr>
			<td>Isoflurane</td>
			<td>Vetone</td>
			<td>502017</td>
			<td></td>
		</tr>
		<tr>
			<td>Lab Chart</td>
			<td>Data Science International (DSI)</td>
			<td></td>
			<td>Software</td>
		</tr>
		<tr>
			<td>Matrigel Matrix</td>
			<td>BD Biosciences</td>
			<td>356234</td>
			<td></td>
		</tr>
		<tr>
			<td>Micro Spring Scissors</td>
			<td>World Precision Instruments (WPI)</td>
			<td>14124</td>
			<td></td>
		</tr>
		<tr>
			<td>Mouse Ox Plus</td>
			<td>STARR Life Sciences Corp.</td>
			<td></td>
			<td>Software</td>
		</tr>
		<tr>
			<td>Mouse Ox Plus Collar Sensor</td>
			<td>STARR Life Sciences Corp.</td>
			<td>015022-2</td>
			<td>Medium Collar Clip Special 7&#8221;</td>
		</tr>
		<tr>
			<td>Mouse Whole Body Plethysmography Chamber</td>
			<td>Data Science International (DSI)</td>
			<td>PLY3211</td>
			<td></td>
		</tr>
		<tr>
			<td>Ohio Care Plus Incubator</td>
			<td>Ohmeda</td>
			<td>HCHD000173</td>
			<td></td>
		</tr>
		<tr>
			<td>Operating Scissors</td>
			<td>World Precision Instruments (WPI)</td>
			<td>501753-G</td>
			<td>Straight</td>
		</tr>
		<tr>
			<td>Osmotic Pump</td>
			<td>Alzet</td>
			<td>1003D</td>
			<td>1ul per hour, 3 days</td>
		</tr>
		<tr>
			<td>Phenol</td>
			<td>Sigma-Aldrich</td>
			<td>P4557</td>
			<td></td>
		</tr>
		<tr>
			<td>Recombinant Mouse Leptin protein</td>
			<td>R&#38;D systems</td>
			<td>498-OB-05M</td>
			<td>5mg</td>
		</tr>
		<tr>
			<td>Saline</td>
			<td>RICCA Chemical</td>
			<td>7210-16</td>
			<td>0.9% Sodium Chloride</td>
		</tr>
		<tr>
			<td>Sterile Surgical Suture</td>
			<td>DemeTech</td>
			<td>DT-639-1</td>
			<td>Silk, size 6-0</td>
		</tr>
		<tr>
			<td>Thermometer</td>
			<td>Innovative Calibration Solutions (INNOCAL)</td>
			<td>EW 20250-91</td>
			<td></td>
		</tr>
	</tbody>
</table>

experimental approach to examine leptin signaling in the carotid bodies and its effects on control of breathing

An adipocyte-produced hormone leptin is a potent respiratory stimulant, which may play an important role in defending respiratory function in obesity. The carotid bodies (CB), a key organ of peripheral hypoxic sensitivity, express the long functional isoform of leptin receptor (LepRb) but the role of leptin signaling in control of breathing has not been fully elucidated. We examined the hypoxic ventilatory response (HVR) (1) in C57BL/6J mice before and after leptin infusion at baseline and after CB denervation; (2) in LepRb-deficient obese db/db mice at baseline and after LepRb overexpression in CBs. In C57BL/6J mice, leptin increased HVR and effects of leptin on HVR were abolished by CB denervation. In db/db mice, LepRb expression in CB augmented the HVR. Therefore, we conclude that leptin acts in CB to augment responses to hypoxia.

Continuous infusion of leptin significantly increased HVR in lean C57BL/6J mice from 0.23 to 0.31 mL/min/g/&#916;FiO2 (P &#60; 0.001, Figure 2)11. CSND abolished the leptin-induced increase in HVR (Figure 2), while no attenuating effects of CSND on HVR were observed in sham surgery group after leptin infusion.
LepRb expression in the CB of LepRb-deficient obese...

Watch this Scientific Journal Video about Experimental Approach to Examine Leptin Signaling in the Carotid Bodies and its Effects on Control of Breathing at JoVE.com

Experimental Approach to Examine Leptin Signaling in the Carotid Bodies and its Effects on Control of Breathing

Our study focuses on the effects of leptin signaling in carotid body (CB) on the hypoxic ventilatory response (HVR). We performed &#39;loss of function&#39; experiments measuring the effect of leptin on HVR after CB denervation and &#39;gain of function&#39; experiments measuring HVR after overexpression of the leptin receptor in CB.

An adipocyte-produced hormone leptin is a potent respiratory stimulant, which may play an important role in defending respiratory function in obesity. The ...
