A Rat Tibial Growth Plate Injury Model to Characterize Repair Mechanisms and Evaluate Growth Plate Regeneration Strategies

Summary

The growth plate is a cartilaginous region in children's long bones where longitudinal growth occurs. When injured, bony tissue can form and impair growth. We describe a rat model of growth plate injury that leads to bony repair tissue, allowing the study of repair mechanisms and growth plate regeneration strategies.

Abstract

A third of all pediatric fractures involve the growth plate and can result in impaired bone growth. The growth plate (or physis) is cartilage tissue found at the end of all long bones in children that is responsible for longitudinal bone growth. Once damaged, cartilage tissue within the growth plate can undergo premature ossification and lead to unwanted bony repair tissue, which forms a "bony bar." In some cases, this bony bar can result in bone growth deformities, such as angular deformities, or it can completely halt longitudinal bone growth. There is currently no clinical treatment that can fully repair an injured growth plate. Using an animal model of growth plate injury to better understand the mechanisms underlying bony bar formation and to identify ways to inhibit it is a great opportunity to develop better treatments for growth plate injuries. This protocol describes how to disrupt the rat proximal tibial growth plate using a drill-hole defect. This small animal model reliably produces a bony bar and can result in growth deformities similar to those seen in children. This model allows for investigation into the molecular mechanisms of bony bar formation and serves as a means to test potential treatment options for growth plate injuries.

Introduction

Growth plate injuries account for 30% of all pediatric fractures and can result in impaired bone growth¹. In addition to fractures, growth plate injuries may be caused by other etiologies, including osteomyelitis², primary bone tumors³, radiation and chemotherapy⁴, and iatrogenic damage⁵. The growth plate (or physis) is a cartilage region at the end of children's long bones that is responsible for longitudinal bone growth. It drives bone elongation through endochondral ossification; chondrocytes undergo proliferation and hypertrophy and are then remodeled by incoming osteoblasts to form trabecular bone⁶. The growth plate is also a weak area of the developing skeleton, making it prone to injury. The major concern with growth plate fractures or injuries is that the damaged cartilage tissue within the growth plate can be replaced with unwanted bony repair tissue, also known as a "bony bar." Depending on its size and location within the growth plate, the bony bar can lead to angular deformities or complete growth arrest, a devastating sequela for young children that have not yet reached their full height⁷.

There is currently no treatment that can fully repair an injured growth plate. Once the bony bar forms, the clinician must decide whether or not to surgically remove it⁸. Patients with at least 2 years or 2 cm of skeletal growth remaining and with a bony bar that spans less than 50% of the growth plate area are usually candidates for bony bar resection⁸. Surgical removal of the bony bar is often followed by interposition of an autologous fat graft to prevent reformation of the bony tissue and to allow the surrounding uninjured growth plate to restore growth. However, these techniques are problematic and often fail, leading to bony bar recurrence and continued negative effect on growth⁹. There is a critical need to develop effective treatments that not only prevent bony bar formation, but also regenerate the growth plate cartilage, thus restoring normal bone elongation.

The molecular mechanisms underlying bony bar formation have yet to be fully elucidated. A greater understanding of these biological mechanisms could lead to more effective therapeutic interventions for children suffering from growth plate injuries. Since studying these mechanisms in humans is difficult, animal models have been used, especially the rat model of growth plate injury^{10,11,12,13,14,15,16}. The method presented in this paper describes how a drill-hole defect in the rat tibial growth plate leads to predictable and reproducible repair tissue that begins ossification as early as 7 days after injury and forms a fully mature bony bar with remodeling at 28 days after injury¹⁰. This provides a small animal in vivo model in which to study the biological mechanisms of bony bar formation, as well as to evaluate novel therapies that could prevent the bony bar and/or regenerate the growth plate cartilage. For example, this model can be used to test chondrogenic biomaterials that can regenerate growth plate cartilage and offer valuable treatment for children suffering from growth plate injuries. The techniques presented in this paper will describe the surgical methods used to produce the growth plate injury and the subsequent delivery of biomaterials to the injury site. We will also discuss methods to assess bony bar formation and repair tissue.

Protocol

All animal procedures must be approved by the local Institutional Animal Care and Use Committee (IACUC). The animal protocol for the following procedure was approved by the University of Colorado Denver IACUC.

1. Obtain Rats

NOTE: Unless genetically modified animals are desired, 6-week-old, skeletally immature Sprague-Dawley rats are needed at the time of surgery. Other strains could potentially be used; however, the majority of published studies have been performed on Sprague-Dawley rats.

2. Preparation of Surgical Supplies

1. Autoclave surgical supply packs that include one each of the following: #3 scalpel handle, needle holder, Adson forceps, and iris scissors.
2. Autoclave the keyless drill chucks. Drill chucks may be bead sterilized between animal surgeries when operating on multiple animals.
   NOTE: Local IACUC rules pertaining to the use of sterile surgical tools on multiple animals must be adhered to. For example, the University of Colorado Denver IACUC allows for one surgical tool set to be used on up to 5 animals before their discontinuation. Furthermore, surgical tools must be heat sterilized using a bead sterilizer between animals. Additional sterile surgical packs must be used for any additional animals.
3. Autoclave 5-cm Steinmann pins, one for each animal.
   NOTE: To reduce the risk of infection, the Steinmann pins must not be used for multiple animals.
4. Autoclave 1.8-mm dental burs, one for each animal.
   NOTE: To reduce the risk of infection, the dental burs must not be used for multiple animals.
5. Autoclave a wound clip applicator, if applicable. Alternatively, buried sutures may be used to close the cutaneous layer. See step 7.3.
6. If possible, sterilize a rotary drill using irradiation or gas sterilization.
7. Collect the following additional supplies: electric shaver, sterile 3-0 polyglycolic acid sutures, sterile gauze, povidone-iodine, sterile saline, sterile 10-mL syringes, sterile 23-gauge needles, isopropyl alcohol swabs, isoflurane, calipers, post-surgical analgesics (e.g., NSAIDs and buprenorphine), sterile surgical drapes, sterile surgical gloves, sterile #15 scalpel blades, sterile wound clips, anesthesia machine, bead sterilizer, warming pad, and absorbent underpads.

3. Anesthesia and Preparation of Animals

1. Anesthetize the animal by introducing it to a 1- to 2-L induction chamber receiving 1 L/min oxygen flow with 5% isoflurane from a vaporizing system with a passive scavenging system.
   NOTE: Exposure to 5% isoflurane should anesthetize 6-week-old rats within 5 min.
2. Move the animal to the surgical site and maintain the animal under anesthesia with 2 - 3% isoflurane using a nose cone for the remainder of the procedure. Place the animal supine on a warming pad and an absorbent underpad.
   NOTE: The animal does not need to be fixed to the surgical table. Holding the leg as specified in the steps below is a sufficient method of stabilization.
   NOTE: All subsequent procedures are to be done with the animal under anesthesia. 2 - 3% isoflurane should be sufficient to maintain anesthesia in rats at this age. This can be confirmed by testing the bipedal withdrawal reflex.
3. Administer intraoperative analgesics in accordance with institutionally approved policies (e.g. buprenorphine at 0.05 mg/kg and carprofen at 5 mg/kg).

4. Preparation of the Tibia for Surgery

1. Shave the entire hind leg(s) from the medial malleolus to the pelvis with an electric shaver.
2. Measure and record the tibial length from the anterior tibial plateau to the inferior side of the medial malleolus using calipers. Alternatively, measure the whole tibial length using X-ray or microCT^11,12,14. Optionally, measure growth plate dimensions prior to surgery using X-ray or microCT.
3. Clean the surgical site by wiping the entire leg(s), abdomen, and genitalia with alcohol swabs and then with povidone-iodine-soaked gauze.
   NOTE: To minimize the risk of infection, all subsequent procedures, until the animal is removed from anesthesia (step 7.4), must be done under sterile conditions. All of the surgical materials must be accessed using sterile technique. The use of a surgical assistant is highly recommended to maintain sterility throughout the surgery.
4. Wearing sterile surgical gloves, place a fenestrated sterile surgical drape over the animal, leaving the leg(s) exposed through the central fenestration.

5. Surgical Procedure to Access the Growth Plate

Figure 1:Overview of the Surgical Procedure.
A) Location of several anatomical markers used to create a successful growth plate injury. The knee capsule is immediately posterior to the kneecap (white), separating the tibia from the femur. The tibial growth plate (dark red) can be seen inferior to the kneecap and circumventing the tibia. The proximal growth plate is a mostly flat plane, except for the anterior quarter that forms a diagonal plane. The intersection of these two planes forms the growth plate angle, which is used for appropriate drill angulation. The semitendinosus insertion is where the quadriceps muscle inserts in the posterior tibia. B) Incision through the anterior-medial aspect of the tibial soft tissues to access the cortical bone. C) Location of the cortical window using alignment with the distal semitendinosus insertion as a reference point. D) Evaluating the depth of the injury by aligning the bevel on the dental bur with the cortical window.

1. Make a ~1-cm incision through the skin along the medial-anterior aspect of the proximal tibia using a #3 scalpel handle and a #15 blade, starting at the distal end of the medial femoral condyle (Figure 1A).
   1. Pull the skin tight against the underlying bone and hold the leg firmly while making the incision.
      NOTE: This will keep the skin incision at the desired location and will aid in the creation of a clean incision. Do not press too firmly with the scalpel to avoid puncturing the knee capsule, which would result in profuse bleeding and will make the remaining steps difficult.
2. Make note of important anatomical markers, including: 1) the growth plate, 2) the growth plate angle, 3) the knee capsule, and 4) the semitendinosus insertion (Figure 1A).
3. Using the scalpel, make a ~ 0.5-cm incision through the fascia and soft tissues on the medial-anterior aspect of the proximal tibia, from the growth plate to the bottom of the skin incision (Figure 1B).
4. Gently dissect or scrape away the fascia and soft tissues from the tibia using the scalpel (Figure 1B).
   NOTE: It is important to remove or scrape as much soft tissue from the tibia as possible so as not to interfere with the drilling steps.
5. Drill a cortical window through the tibial cortical bone at the diaphysis with a Steinmann pin attached to a rotary tool at 10,000 RPM (low speed of the rotary tool specified in the materials section). Create the cortical window such that it aligns with the distal semitendinosus insertion (Figure 1C).
   1. Hold the drill perpendicular to the tibial diaphysis and drill slowly, being careful not to drill through the other side of the diaphysis; the cortical window needs to be only ~ 2 mm in depth and will be made when no resistance is felt.
   2. As above, hold the leg firmly with the other hand.
      NOTE: A dental bur may be used for this step. However, if a dental bur is used, the leg must be held very firmly to make a clean cortical window and to ensure that the bur grabs and cuts the bone at the desired location. A Steinmann pin is recommended for this step, given its far superior cutting ability.
6. Dab the cortical window with gauze, as light bleeding is expected.

6. Creating the Growth Plate Injury

1. Create a drill hole injury through the central growth plate using a 1.8-mm dental bur attached to a rotary tool.
   NOTE: The proper depth, angle, and direction are critical in disrupting the central growth plate (Figure 1C and D). Instructions for attaining the appropriate depth, angle, and direction are given below.
   1. To measure the appropriate depth using the dental bur, begin by aligning the end of the dental bur with the proximal tibia, where the semitendinosus crosses the knee capsule (Figure 1C).
   2. With the end of the dental bur at the knee capsule, follow the bur shaft along the semitendinosus and make note of where the bur aligns with the cortical window. This is the appropriate depth for the bur to fully disrupt the growth plate without disrupting the articular surface (Figure 1C).
      NOTE: The dental bur is used to measure the appropriate depth. The bur may be marked with a permanent marker at the location where it aligns with the cortical window to reference the depth during drilling. However, if the anatomical markers and the above protocol are closely referenced, the first bevel on the dental burs specified here (FG6) will align appropriately with the cortical window (as seen in Figure 1C).
   3. To attain the appropriate drill angle, hold the rotary tool at an angle of less than 30° with respect to the tibial diaphysis.
      NOTE: This is a visual approximation.
   4. To attain the appropriate drill direction, aim for the growth plate angle (Figure 1C). Draw a visual line along the dental bur to the growth plate angle to aid in creating a central defect.
   5. Turn on the rotary tool to 10,000 RPM (low speed of the rotary tool specified in the materials section) before entering the cortical window.
   6. With the rotary tool at an appropriate angle and direction, enter the cortical window and push the rotary tool until the bur marker aligns with the cortical window. Once the proper depth is attained, remove the rotary tool.
      NOTE: Perform the growth plate disruption in one, quick motion, using minimal time with the bur in the growth plate in order to create a clean injury. This is important for data analysis.
2. Dab the cortical window with gauze for ~ 30 s, as bleeding is expected.
3. Ensure the appropriate depth of the injury by again measuring the bur length (step 6.1.2).
   1. Insert the bur into the drill track (with the rotary tool off) and align the marked bur with the cortical window (Figure 1D).
4. If the depth is inadequate, turn the rotary tool on and push to the desired depth.
   NOTE: Although a second round of drilling is not ideal, fully disrupting the growth plate is paramount to the development of the bony bar.
5. Rinse the drill track with ~ 3 mL of sterile saline using a 10-mL syringe and a 23-gauge needle.
6. Dry the wound with gauze.

7. Post-Injury Procedures

1. If evaluating a biomaterial-based growth plate treatment, inject the biomaterial through the drill track into the injury site using an appropriately sized needle (18- to 26-gauge, depending on the biomaterial viscosity).
   NOTE: The volume of the growth plate injury is ~ 3 µL, and the volume of the drill track is ~ 20 µL. The maximum volume of material that can be injected into the growth plate injury and drill track is between 20 and 25 µL.
2. Close the wound by suturing the fascia with 3-0 polyglycolic acid sutures. Apply bone wax over the cortical window to isolate the underlying bone (optional).
3. Close the skin incision with buried sutures or wound clips.
   NOTE: Wound clips are recommended, as the animal will scratch at the injury site and may open the wound.
4. Remove the animal from isoflurane anesthesia, place it on a warming blanket, and monitor it until it is awake.
5. To reduce the risk of infection, place the animal in a new cage containing dry, autoclaved bedding.
6. Allow the animal to bear weight post-operatively.
7. Monitor the animal every 12 h for 72 h after surgery to check for signs of infection, to ensure that the wound clips remain in place, and to administer postoperative analgesics in accordance with institutionally approved policies (e.g. buprenorphine at 0.05 mg/kg every 12 h for 36 h and carprofen at 5 mg/kg every 24 h for 72 h).
8. Remove the wound clips 10 - 14 days post-surgery under anesthesia.

Results

Successful growth plate injury using this method involves the disruption of the center of the tibial growth plate without disrupting the articular cartilage surface. Bony repair tissue has been reported to begin at approximately 7 days post-injury and becomes fully developed by 28 days post-injury¹³, as visualized by micro computed tomography (micro CT) (Figure 2). Although these timepoints were chosen here to display the beginning and maturation o...

Discussion

A growth plate injury animal model greatly adds to our understanding of the biological mechanisms of this injury, thus potentially leading to more effective therapeutic interventions for children suffering from growth plate injuries. To successfully create a bony bar and to study its formation in vivo using the model presented in this work, it is critical to disrupt the growth plate by drilling to a sufficient depth, without disrupting the articular cartilage. Variation in surgical implementation among animals a...

Materials

Name	Company	Catalog Number	Comments
Scalpel handle	McKesson	MCK42332500
Needle holder	Stoelting	RS-7824
Adson tissue forceps	Sklar	50-3048
Iris Scissors	Sklar	47-1246
Rotary Tool	Dremel	7700	Variable speed rotary tool
Keyless Rotary Tool Chuck	Dremel	4486
Dental Burs	Dental Burs USA	FG6	Round carbide bur, ≤2mm
Steinmann pins	Simpex Medical	T-078
Hair clippers	Wahl	5537N
3-0 PGA surutes	Oasis	MV-J398-V
Sterile gauze 2 x 2"	Covidien	441211
Povidone Iodine	McKesson	922-00801
Sterile saline	Vetone	510224
10 mL luer lock syringe	Becton Dickinson	309604
23 gauge needle	Becton Dickinson	305145
Isopropyl alcohol pads	Dynarex	1113
Isoflurane	IsoFlo	30125-2
Caliper	Mitutoyo	500-196-30
Carprofen	Rimadyl	27180
Buprenorphine	Par Pharmaceuticals Inc	NDC 42023-179
Fenestrated Surgical Drape	McKesson	25-517
Surgical Gloves	Uline	S-20204
#15 Scalpel Blade	Aven	44044
9 mm wound clips	Fine Science Tools	12032-09
Reflex clip applier	World Precision Instruments	500345
Absorbant underpads	McKesson	MON 43723110
Tec 3 Iso Vaporizer	VetEquip	911103
Germinator 500	Braintree Scientific	GER 5287-120V
Warm water recirculator	Kent Scientific	TP-700
Absorbent Underpads	Medline Industries	MSC281230
