Name: establishment and characterization of small bowel neuroendocrine tumor spheroids
Uploaded: 2019-10-14T13:00:00.000+00:00
Duration: 9 min 43 s
Description: Watch this Scientific Journal Video about Establishment and Characterization of Small Bowel Neuroendocrine Tumor Spheroids at JoVE.com

This work was supported by NIH grants P50 CA174521 (to J.R. Howe and A.M. Bellizzi). P.H. Ear is a recipient of the P50 CA174521 Career Enhancement Program award.

All experiments using human neuroendocrine tumor samples have been approved by the University of Iowa Hospital and Clinics IRB committee (Protocol number 199911057). A list of all materials and equipment is described in the Table of Materials. A list of growth media and key solutions is found in Table 1.
1. Small bowel neuroendocrine tumor (SBNET) collection and cell dissociation
<ol>
	<li>Obtain resected patient SBNET samples after tumor tissues confirmation from the Surgical Pathology Core.</li>
	<li>Cut SBNETs into 5 mm&#160;cubes and store in 25 mL of DMEM/F12 medium in a conical tube for the transportation to the laboratory.</li>
	<li>Transfer the tumors in DMEM containing 1% FBS, 1% penicillin/streptomycin (Pen/Strep), 1% glutamine (Wash Medium) and incubate in this Wash Medium for 15 min.</li>
	<li>Transfer tumors to a new dish and mince tumors to less than 1 mm pieces using sterile curved scissors.</li>
	<li>Transfer the minced tissues to a new 50 mL tube containing 25 mL of Wash Medium.</li>
	<li>Centrifuge the sample at 500 x g for 15 min at 4 &#176;C.</li>
	<li>Discard the supernatant and resuspend the pellets in 10 mL of Wash Medium containing collagenase (100 U/mL) and DNase (0.1 mg/mL).</li>
	<li>Allow the digestion of the minced tumors to occur in a 37 &#176;C incubator with slow shaking (50 rpm) for 1.5 h.</li>
</ol>
2. Culture of SBNETs as tumor spheroids in ECM
<ol>
	<li>After digestion is completed (step 1.8), centrifuge at 500 x g for 15 min at 4 &#176;C, discard the supernatant and resuspend the pellet in 15 mL of Wash Medium.</li>
	<li>Place a 70 &#181;m cell strainer on top of a new 50 mL tube and transfer 10 mL of the Wash Medium over the cell strainer. Swirl the Wash Medium to cover the side of the plastic tube to prevent NET cells from sticking to the side of the plastic tube.</li>
	<li>Filter the cell suspension through cell strainer.</li>
	<li>Centrifuge at 500 x g for 15 min at 4 &#176;C, discard the supernatant, resuspend the pellet in 200 &#181;L of Wash Medium (total volume is ~ 250 &#181;L) and place it on ice.</li>
	<li>Transfer 5 &#181;L of cells to 500 &#181;L of Wash Medium (1/100 dilution factor). Use the diluted cells for cell counting using a hemocytometer to obtain the number of cells per milliliter. Multiply by 100 to correct for the dilution factor.</li>
	<li>Multiply the number of cells per mL obtained in step 2.5 by the total volume of cells in suspension obtained in step 2.4 (~ 250 &#181;L).</li>
	<li>Centrifuge at 500 x g for 15 min at 4 &#176;C, discard the supernatant, and resuspend the cells in liquid ECM (1 x 106 cells/mL) and keep on ice.</li>
	<li>Transfer 5-20 &#181;L of SBNET spheroids in ECM to a 96-well plate and allow the liquid ECM to solidify by placing the plate in a 37 &#176;C incubator for 5 min.</li>
	<li>Add 200 &#181;L of SBNET culture medium (DMEM/F12 + 10% FBS + 1% PEN/STREP + 1% Glutamine + 10 mM nicotinamide + 10 &#181;g/mL insulin) to each well of the 96-well plate containing the SBNET spheroids in ECM.</li>
	<li>Alternatively, culture SBNET organoids in stem cell media similar to what has previously been described for growing either human liver or pancreatic organoids9 and listed in the Table of Materials.</li>
	<li>Change media every 5-7 days.</li>
</ol>
3. Quantification of SBNET spheroid size using ImageJ
<ol>
	<li>Take 5-10 pictures of SBNET spheroids at Day 1, 4, 7, 14, 23 and 97 of the culture using a 10x objective.</li>
	<li>Open saved images in ImageJ. Go to the Analyze tab, select the Set Measurements option and place a check on the Area option.</li>
	<li>Use the oval selection tool from the tool bar to generate an ellipsoid or circle around a well-focused spheroid.</li>
	<li>Go to the Analyze tab and select the Measure option. Repeat steps 3.4 and 3.5 in order to get area measurement from 25-50 SBNET spheroids. The values are provided in pixel square.</li>
	<li>Convert the pixel area to &#181;m2 by dividing the size of each pixel with the length of each pixel to &#181;m conversion factor of the microscopy images.
	NOTE: SBNET cells grow mainly as spheroids and sometime as ellipsoids.</li>
</ol>
4. Characterization of SBNETS spheroids by immunofluorescence
<ol>
	<li>Transfer the organoids grown in ECM to a 1.5 mL tube using a P1000 pipette.</li>
	<li>Centrifuge at 1,500 x g for 1 min and remove the supernatant.</li>
	<li>Wash the organoid culture by adding 1 mL of PBS, mix, centrifuge at 1,500 x g for 1 min and remove the supernatant.</li>
	<li>Fix the organoids by adding 500 &#181;L of 4% paraformaldehyde and incubate for 15 min.</li>
	<li>Wash the culture twice with 1 mL of PBS.</li>
	<li>Permeabilize the culture by adding 500 &#181;L of PBS + 3% BSA + 0.1% Triton X 100 for 5 min.</li>
	<li>Then wash for three times with 1 mL of PBS + 3% BSA.</li>
	<li>Incubate for 1 h with primary antibodies against synaptophysin (SYP)10 at 1/600 dilution or chromogranin A (CgA)11 and somatostatin receptor 2 (SSTR2)12 at 1/400 dilution in antibody buffer (2.5% bovine serum albumin, 0.1% sodium azide, 25 mM Tris pH 7.4, 150 mM sodium chloride).
	NOTE: Use 300 &#181;L or more of antibody solution per tube.</li>
	<li>Wash three times with 1 mL of PBS + 3% BSA.</li>
	<li>Incubate with secondary antibodies coupled to FITC at 1/500 dilution in antibody buffer for 1 h. Use 300 &#181;L or more of antibody solution per tube.</li>
	<li>Wash 3 times with 1 mL of PBS + 3% BSA. Make sure to aspirate and discard all the supernatant.</li>
	<li>Add 5 &#181;L of mounting medium containing the nuclear stain DAPI.</li>
	<li>Use a P20 pipette to transfer 5 &#181;L of the SBNET spheroids from step 4.12 to a glass slide and seal with a cover slip.</li>
	<li>Take images using a fluorescent microscope using the 10x, 20x or 40x objectives.</li>
</ol>
5. SBNET spheroids characterization by immunohistochemistry (IHC)
<ol>
	<li>Transfer SBNET spheroids from the culture plate to a 1.5 mL tube by using a P1000 pipette.</li>
	<li>Centrifuge at 1,500 x g for 1 min and remove the supernatant.</li>
	<li>Fix SBNET spheroids by adding 500 &#181;L of 10% formalin to the tube from step 5.2 and incubate at room temperature for 2-5 days prior to paraffin embedding and cut 4 &#181;m thick spheroid sections.</li>
	<li>Deparaffinize, rehydrate, and use heat-induced epitope retrieval in Antigen Retrieval Solution at pH 9 by heating to 97 &#176;C for 20 min using the 3-in-1 automated slide processing station to prepare slides for antibody incubation.</li>
	<li>Block slides and incubate with primary antibodies against SYP10 at a 1/100 dilution for 15 min, CgA11 at a 1/800 dilution for 15 min, and SSTR212 at a 1/5,000 dilution for 30 min.</li>
	<li>Incubate with the secondary antibody detection system for 15 min for the anti-SYP and CgA staining and 30 min for anti-SSTR2 staining. Take pictures using a 400x objective.</li>
</ol>
6. Treatment of SBNET organoids with rapamycin
<ol>
	<li>Dissolve rapamycin in DMSO to obtain a 10 mM stock solution.</li>
	<li>Prepare SBNET culture medium with DMSO (e.g., 1 mL of SBNET culture medium + 1 &#181;L of DMSO) and SBNET culture medium with 10 &#181;M of rapamycin (e.g., 1 mL of SBNET culture medium + 1 &#181;L of 10 mM rapamycin stock solution).</li>
	<li>Transfer 200 &#181;L media with SBNET culture medium with DMSO or 10 &#181;M rapamycin to SBNET spheroid cultures.</li>
	<li>Incubate SBNET spheroids for 5 days in 37 &#176;C incubator.</li>
	<li>Add 1 &#181;M of ethidium homodimer and incubate for 30 min. Remove the medium containing ethidium homodimer, wash with 200 &#181;L of PBS, and transfer 200 &#181;L of PBS to each well.</li>
	<li>Take microscopy images of SBNET spheroids with and without drug treatment using the red filter cube with the 10x, 20x, or 40x objectives of a fluorescent microscope.
	NOTE: Dead cells stained with Ethidium homodimer appears as red using the red filter cube G of a commercially available microscope (Table of Materials). Alternatively, the signal can be captured using a spectrophotometer at 535 nm excitation and 624 nm emission.</li>
</ol>
7. Splitting SBNET spheroids
NOTE: This is done for expansion and for sharing with other researchers.
<ol>
	<li>Use a P1000 pipette to mechanically break the ECM and aspirate the ECM with SBNET spheroids to a sterile 1.5 mL tube.</li>
	<li>Centrifuge at 1,000 x g at 4 &#176;C, remove all the supernatant and place the tube on ice.</li>
	<li>Add 2-4x the volume of new ECM to the pellet. Mix the new ECM with the old ECM and SBNET spheroids by pipetting up and down 10x. Avoiding introducing air bubbles.</li>
	<li>Transfer 5-20 &#181;L of the ECM and SBNET spheroids mixture to a new plate and allow ECM to solidify.</li>
	<li>Cover with new SBNET medium and transfer to the incubator. The recovery rate is approximately 95 to 100%.</li>
	<li>For shipping SBNET spheroids to another lab, transfer SBNET spheroids with new ECM to a T25 flask and allow ECM to solidify.</li>
	<li>Fill the T25 flask with SBNET spheroid medium, screw on the cap tightly, and prepare shipment package.</li>
	<li>Upon receiving an SBNET spheroid culture, remove the culture medium and perform step 7.1 to 7.5 to put SBNET spheroids back in culture.</li>
</ol>
8. Cryostorage and recovery of SBNET spheroids
<ol>
	<li>Transfer SBNET spheroids from 5-10 small wells to a 15 mL tube. Centrifuge at 500 x g for 15 min at 4 &#176;C, remove supernatant, resuspend in freezing medium (90% FBS + 10% DMSO), store in a cell freezing container, and place this at -80 &#176;C.</li>
	<li>Transfer to the liquid nitrogen for longer storage.</li>
	<li>To recover SBNET spheroids, place the frozen vial on ice and wait until the content is completely thawed. Invert the tube and re-place on ice in order to speed up the thawing process.</li>
	<li>Once the sample is thawed, placed inside a pre-chilled centrifuge and spin at 1,000 x g for 10 min.</li>
	<li>Remove the supernatant and resuspend the spheroids in ECM. Keep the tube on ice, transfer 20 &#181;L to a new plate, and wait for the ECM to solidify.</li>
	<li>Transfer 200 &#181;L of SBNET culture medium with 10 &#181;M of ROCK inhibitor (Y-27632)13 and transfer to the incubator.</li>
	<li>Allow SBNET spheroids to recover and grow for 1 week. Remove the old culture medium, replenish with 200 &#181;L of SBNET culture medium and return to the incubator.</li>
	<li>Allow SBNET spheroids to continue to grow.
	NOTE: It takes at least 1 week for rapidly growing spheroids to start to recover after cryopreservation13. SBNET spheroids take a minimum of 2-4 weeks to start growing. Many SBNET cells will die within the first 2 weeks and the survival rate is less than 10%. Since this is a very time-consuming and low yield process, it is better to share with other researchers SBNET spheroids in culture flasks (as described in step 7). Cryostorage and recovery should only be used as a backup plan in case of a bacterial contamination occurs.</li>
</ol>

<ol>
	<li>Maxwell, J. E., Sherman, S. K., Howe, J. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Translational+Diagnostics+and+Therapeutics+in+Pancreatic+Neuroendocrine+Tumors.">Translational Diagnostics and Therapeutics in Pancreatic Neuroendocrine Tumors.</a> Clinical Cancer Research. 22, 5022-5029 (2016).</li><li>Pfragner, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Establishment+of+a+continuous+cell+line+from+a+human+carcinoid+of+the+small+intestine+(KRJ-I).">Establishment of a continuous cell line from a human carcinoid of the small intestine (KRJ-I).</a> International Journal of Oncology. 8, 513-520 (1996).</li><li>Kolby, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+transplantable+human+carcinoid+as+model+for+somatostatin+receptor-mediated+and+amine+transporter-mediated+radionuclide+uptake.">A transplantable human carcinoid as model for somatostatin receptor-mediated and amine transporter-mediated radionuclide uptake.</a> American Journal of Pathology. 158, 745-755 (2001).</li><li>Van Buren, G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+development+and+characterization+of+a+human+midgut+carcinoid+cell+line.">The development and characterization of a human midgut carcinoid cell line.</a> Clinical Cancer Research. 13, 4704-4712 (2007).</li><li>Pfragner, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Establishment+and+characterization+of+three+novel+cell+lines+-+P-STS,+L-STS,+H-STS+-+derived+from+a+human+metastatic+midgut+carcinoid.">Establishment and characterization of three novel cell lines - P-STS, L-STS, H-STS - derived from a human metastatic midgut carcinoid.</a> Anticancer Research. 29, 1951-1961 (2009).</li><li>Ellis, L. M., Samuel, S., Sceusi, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Varying+opinions+on+the+authenticity+of+a+human+midgut+carcinoid+cell+line--letter.">Varying opinions on the authenticity of a human midgut carcinoid cell line--letter.</a> Clinical Cancer Research. 16, 5365-5366 (2010).</li><li>Hofving, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+neuroendocrine+phenotype,+genomic+profile+and+therapeutic+sensitivity+of+GEPNET+cell+lines.">The neuroendocrine phenotype, genomic profile and therapeutic sensitivity of GEPNET cell lines.</a> Endocrine Related Cancer. 25, 367-380 (2018).</li><li>Moreno, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Antitumor+activity+of+rapamycin+and+octreotide+as+single+agents+or+in+combination+in+neuroendocrine+tumors.">Antitumor activity of rapamycin and octreotide as single agents or in combination in neuroendocrine tumors.</a> Endocrine Related Cancer. 15, 257-266 (2008).</li><li>Broutier, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Culture+and+establishment+of+self-renewing+human+and+mouse+adult+liver+and+pancreas+3D+organoids+and+their+genetic+manipulation.">Culture and establishment of self-renewing human and mouse adult liver and pancreas 3D organoids and their genetic manipulation.</a> Nature Protocols. 11, 1724-1743 (2016).</li><li>Saito, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Establishment+of+Patient-Derived+Organoids+and+Drug+Screening+for+Biliary+Tract+Carcinoma.">Establishment of Patient-Derived Organoids and Drug Screening for Biliary Tract Carcinoma.</a> Cell Reports. 27, 1265-1276 (2019).</li><li>Park, S. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Detection+of+bone+marrow+metastases+of+neuroblastoma+with+immunohistochemical+staining+of+CD56,+chromogranin+A,+and+synaptophysin.">Detection of bone marrow metastases of neuroblastoma with immunohistochemical staining of CD56, chromogranin A, and synaptophysin.</a> Applied Immunohistochemisty and Molecular Morphology. 18, 348-352 (2010).</li><li>Clifton-Bligh, R. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Improving+diagnosis+of+tumor-induced+osteomalacia+with+Gallium-68+DOTATATE+PET/CT.">Improving diagnosis of tumor-induced osteomalacia with Gallium-68 DOTATATE PET/CT.</a> The Journal of Clinical Endocrinology and Metabolism. 98, 687-694 (2013).</li><li>Clinton, J., McWilliams-Koeppen, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Initiation,+Expansion,+and+Cryopreservation+of+Human+Primary+Tissue-Derived+Normal+and+Diseased+Organoids+in+Embedded+Three-Dimensional+Culture.">Initiation, Expansion, and Cryopreservation of Human Primary Tissue-Derived Normal and Diseased Organoids in Embedded Three-Dimensional Culture.</a> Current Protocols in Cell Biology. 82, 66 (2019).</li><li>Markovits, J., Roques, B. P., Le Pecq, J. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ethidium+dimer:+a+new+reagent+for+the+fluorimetric+determination+of+nucleic+acids.">Ethidium dimer: a new reagent for the fluorimetric determination of nucleic acids.</a> Analytical Biochemistry. 94, 259-264 (1979).</li><li>Weeber, F., Ooft, S. N., Dijkstra, K. K., Voest, E. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tumor+Organoids+as+a+Pre-clinical+Cancer+Model+for+Drug+Discovery.">Tumor Organoids as a Pre-clinical Cancer Model for Drug Discovery.</a> Cell Chemical Biology. 24, 1092-1100 (2017).</li><li>Sachs, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Living+Biobank+of+Breast+Cancer+Organoids+Captures+Disease+Heterogeneity.">A Living Biobank of Breast Cancer Organoids Captures Disease Heterogeneity.</a> Cell. 172, 373-386 (2018).</li><li>Puca, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient+derived+organoids+to+model+rare+prostate+cancer+phenotypes.">Patient derived organoids to model rare prostate cancer phenotypes.</a> Nature Communication. 9, 2404 (2018).</li><li>Singh, S. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=SSTR2-based+reporters+for+assessing+gene+transfer+into+non-small+cell+lung+cancer:+evaluation+using+an+intrathoracic+mouse+model.">SSTR2-based reporters for assessing gene transfer into non-small cell lung cancer: evaluation using an intrathoracic mouse model.</a> Human Gene Therapy. 22, 55-64 (2011).</li></ol>

The authors have nothing to disclose.

Tumor 3D cultures have become a valuable resource for preclinical drug testing15. Various tumor organoid biobanks have recently been established from breast cancer and prostate cancer tumors16,17. In this study, we provide a detailed protocol to culture SBNET as spheroids and a simple and fast method to validate the spheroid cultures for NET markers by immunofluorescence and test drug sensitivity. From our experience, SBNET spheroids can g...

Small bowel neuroendocrine tumors (SBNETs) originate from enterochromaffin cells of the small intestine. Although SBNETs are generally known to grow slowly, they commonly metastasize to the liver1. While the surgical removal or tumor ablation can be considered in many cases, recurrence is nearly universal, and, therefore, medical therapy plays an important role in management. Tremendous efforts have been invested to generate new SBNET cell lines for drug testing. However, there has been very little success. Only 6 SBNET cell lines (KRJ-I, CND2, GOT1, P-STS, L-STS, H-STS) have been reported2,3,4,5; and unfortunately one cell line no longer expresses NET markers6 and three other SBNET cell lines (KRJ-I, L-STS, H-STS) were determined to be derived from transformed lymphoblasts instead of NETs7. In order to accelerate the identification of drugs for targeting SBNETs, alternative methods for in vitro drug testing are needed.
Here, we take&#160;advantage of the availability of resected SBNETs and have established a way to culture these patient-derived SBNETs as spheroids growing in ECM. The overall goal of this manuscript is to describe a method to culture SBNET as a three-dimensional (3D) culture and outline procedures to characterize these spheroids for the retention of SBNET markers by immunofluorescence staining and immunohistochemistry.
In addition, we demonstrate how these SBNET spheroids can be used for testing the effect of rapamycin, an anti-cancer drug for NETs8. The rationale behind this protocol is to develop a new method to grow SBNET cells in vitro and use them for drug testing. The advantage of this technique over the traditional method of establishing an SBNET cell line is that 3D cultures of SBNETs can rapidly be obtained and drug testing can be done within 3 weeks. SBNET spheroids could potentially be used as a model for performing in vitro drug screens to identify new drugs for SBNET patients. Since SBNET cell lines are not widely available, 3D cultures of SBNET spheroids can serve as a new in vitro model for studying SBNETs and can be shared among scientists in the field.

<table><tbody><tr><td>Anti-rabbit FITC</td><td>Jackson ImmunoResearch</td><td>11-095-152</td><td>Secondary antibody couple to a green fluorophore</td></tr><tr><td>Antigen Retrieval Solution</td><td>Agilent Dako</td><td>S2367</td><td>Solution at pH 9 for preparing slides for IHC</td></tr><tr><td>Autostainer Link 48</td><td>Agilent Dako</td><td>Not Available</td><td>Automated system for antibody staining</td></tr><tr><td>Cell freezing container</td><td>Thermo Scientific</td><td>5100-0001</td><td>Container to for freezing cells</td></tr><tr><td>CellSence</td><td>Olympus</td><td>Version 1.18</td><td>Computer software for using fluorescent microscope</td></tr><tr><td>Chromogranin A antibody</td><td>Abcam-45179</td><td>RB-9003-PO</td><td>Antibodies for IF</td></tr><tr><td>Chromogranin A antibody (clone LK2H10)</td><td>Thermo Scientific</td><td>MA5-13096</td><td>Antibodies for IHC</td></tr><tr><td>Collagenase</td><td>Sigma</td><td>C0130</td><td>Enzyme for digesting tumor tissue</td></tr><tr><td>DMEM</td><td>Gibco</td><td>11965-092</td><td>Medium for tissue preparation</td></tr><tr><td>DMEM/F12</td><td>Gibco</td><td>11320-033</td><td>Medium for organoid cultures</td></tr><tr><td>DMSO</td><td>Sigma</td><td>D8418</td><td>Solvent for dissolving drug</td></tr><tr><td>DNAse</td><td>Sigma</td><td>DN25</td><td>Enzyme for digesting tumor tissue</td></tr><tr><td>Ethidium Homodimer</td><td>Chemodex</td><td>CDX-E0012-T1E</td><td>DNA and RNA binding dye</td></tr><tr><td>FBS</td><td>Gibco</td><td>16000044</td><td>Reagent for culture media</td></tr><tr><td>Fluorescent microscope</td><td>Olympus</td><td>CKX35</td><td>Microscope for taking pictures of SBENT spheroids</td></tr><tr><td>Glutamine</td><td>Gibco</td><td>A2916801</td><td>Reagent for culture media</td></tr><tr><td>ImageJ</td><td>National Institutes of Health</td><td>Version 1.51</td><td>Computer software for image analysis</td></tr><tr><td>Insulin</td><td>Sigma</td><td>I0516</td><td>Reagent for culture media</td></tr><tr><td>Matrigel</td><td>Corning</td><td>356235</td><td>Matrix to embed and anchore organoids</td></tr><tr><td>Mounting medium (VECTASHIELD)</td><td>Vector Laboratories</td><td>H-1200</td><td>Fixative for labelled-cells with a nuclear stain</td></tr><tr><td>Nicotinamide</td><td>Sigma</td><td>72340</td><td>Reagent for culture media</td></tr><tr><td>Paraformaldehyde</td><td>Electron Microscopy Sciences</td><td>15710</td><td>Reagent to fix cells</td></tr><tr><td>PEN/STREP</td><td>Gibco</td><td>15140-122</td><td>Reagent for culture media</td></tr><tr><td>PT Link</td><td>Agilent Dako</td><td>Not Available</td><td>Automated system to prepare slides for IHC staining</td></tr><tr><td>Rapamycin</td><td>Alfa Aesar</td><td>J62473</td><td>Drug that can inhibit NET growth</td></tr><tr><td>Secondary antibodies for IHC</td><td>Agilent Dako</td><td>K8000</td><td>Secondary antibodies for IHC using Polymer-based EnVision FLEX system</td></tr><tr><td>SSTR2 antibody</td><td>GeneScritp</td><td>A01591</td><td>Antibodies for IF</td></tr><tr><td>SSTR2 antibody (clone UMB1)</td><td>Abcam</td><td>ab134152</td><td>Antibodies for IHC</td></tr><tr><td>Synaptophysin antibody</td><td>Abcam</td><td>32127</td><td>Antibodies for IF</td></tr><tr><td>Synaptophysin antibody (clone DAK-SYNAP)</td><td>Agilent Dako</td><td>M7315</td><td>Antibodies for IHC</td></tr><tr><td>TritonX</td><td>Mallinckrodt</td><td>3555 KBGE</td><td>Reagent to permeablize cells</td></tr><tr><td>Y-2763 ROCK inhibitor</td><td>Adipogen</td><td>AG-CR1-3564-M005</td><td>To improve SBNET spheroid viability after freeze thaw</td></tr></tbody></table>

establishment and characterization of small bowel neuroendocrine tumor spheroids

Small bowel neuroendocrine tumors (SBNETs) are rare cancers originating from enterochromaffin cells of the gut. Research in this field has been limited because very few patient derived SBNET cell lines have been generated. Well-differentiated SBNET cells are slow growing and are hard to propagate. The few cell lines that have been established are not readily available, and after time in culture may not continue to express characteristics of NET cells. Generating new cell lines could take many years since SBNET cells have a long doubling time and many enrichment steps are needed in order to eliminate the rapidly dividing cancer-associated fibroblasts. To overcome these limitations, we have developed a protocol to culture SBNET cells from surgically removed tumors as spheroids in extracellular matrix (ECM). The ECM forms a 3-dimensional matrix that encapsulates SBNET cells and mimics the tumor micro-environment for allowing SBNET cells to grow. Here, we characterized the growth rate of SBNET spheroids and described methods to identify SBNET markers using immunofluorescence microscopy and immunohistochemistry to confirm that the spheroids are neuroendocrine tumor cells. In addition, we used SBNET spheroids for testing the cytotoxicity of rapamycin.

There are currently only 2 SBNET cell lines established and published2,3,4,5 and they are not readily available to many researchers. Here, we propose to culture SBNET as spheroids in ECM and use this as an alternative model to study SBNET drug sensitivity. Patient-derived tumor from an SBNET that metastasized to the liver was collected, digested to release SBNET cells, and mixed with liquid ECM...

Watch this Scientific Journal Video about Establishment and Characterization of Small Bowel Neuroendocrine Tumor Spheroids at JoVE.com

Establishment and Characterization of Small Bowel Neuroendocrine Tumor Spheroids

Neuroendocrine tumors (NETs) originate from neuroendocrine cells of the neural crest. They are slow growing and challenging to culture. We present an alternative strategy to grow NETs from the small bowel by culturing them as spheroids. These spheroids have small bowel NET markers and can be used for drug testing.

Small bowel neuroendocrine tumors (SBNETs) are rare cancers originating from enterochromaffin cells of the gut. Research in this field has been limited ...
