1. PTIRF System Setup
The pTIRFM technique is built on an inverted microscope platform. Laser beams are directed through a side illumination port and a nonpolarizing side-facing filter cube, and then focused onto the back focal plane of a 60X 1.49 NA TIRF objective. Two additional lenses (1.6X and 2X) in the emission path between the microscope and EMCCD camera give a final pixel size of approximately 80 nm. Laser beams are guided using software controlled galvanometer mirrors for rapid switching between epi- and total internal reflection (TIR) illumination. The protocol described below assumes that optics for TIRF are already positioned on the air table in the optimum positions for fluorophore excitation and imaging. It describes how polarization optics are added to an existing TIRF microscope set-up to enable imaging of cell membrane deformations. A schematic of our laboratory&#39;s optical set-up for generating both TIR and polarization-based TIR is shown in Figure 1A. The protocol assumes the use of a 488-nm laser for excitation of fluorescent vesicle proteins and a 561&#160;nm laser for the imaging of the carbocyanine dye, diD.
<ol>
	<li>Power on all microscope components, lasers, and computers.</li>
	<li>Direct a beam from the 488&#160;nm laser to the back focal plane (BFP) of the 1.49 NA lens as illustrated in Figure 1A. If the laser beam is focused on the BFP, it will emerge collimated and appear as small well-defined spot on the ceiling directly above the objective.</li>
	<li>Adjust the X galvanometer mirror (the mirror located in the equivalent sample plane) so that laser beam is moved off-axis and emerges from the objective at progressively steeper angles to the objective normal.</li>
	<li>Next, verify that TIR is achieved. Add 10 &#956;l of fluorescent microspheres to a 1&#160;ml volume of PSS in a glass-bottom dish. Only fluorescence from microspheres on the bottom of the dish, closest to the TIR interface, should be detected. Detection of floating microspheres indicates that the angle between the incident light and objective normal is insufficient.

	The section below describes the set-up of the optical components necessary for polarization-based imaging.</li>
	<li>Using the aligned 488&#160;nm beam as a guide, adjust the position of the raw 561&#160;nm laser beam so it is traveling along an identical optical path. The 561&#160;nm laser will be used for imaging of the carbocyanine dye, diD.</li>
	<li>Insert a diverging lens and mirrors downstream of the 561&#160;nm laser. Using the mirrors, adjust the beam so that it is coaligned with the 488&#160;nm beam and the spot is in focus on the ceiling when the galvanometer mirrors are in the &#34;0&#34; position.</li>
	<li>Center a quarter-wave plate (QW) in the beam path immediately downstream of the laser aperture. Use a QW which is either achromatic or tuned to the excitation wavelength. A QW will circularly polarize any linearly polarized light which enters at a 45&#176; angle with the optical axis. Some optical components, such as the polarization cubes, have an attenuation bias towards one axis of polarization. The QW may be rotated to compensate for this bias. This adjustment will result in an elliptically polarized beam. A QW is necessary because the laser beam itself is highly linearly polarized (vertically) as it emerges from the aperture.</li>
	<li>Place a polarization cube (PC1) downstream of the elliptically polarized beam. The polarization cube reflects the vertical (y) component of the electric field and passes the horizontal (x) component. The polarization cube is placed on a small translating stage to facilitate subsequent alignment of polarization beam paths.</li>
	<li>Use a second polarizing cube (PC2) and mirrors (Figure 1A) to recombine the beams.</li>
	<li>Place a shutter between the first polarization cube (PC1) and the vertical component mirror. Place a second shutter between the horizontal component mirror and second polarization cube (PC2). These shutters are controlled by the imaging software enabling the user to rapidly select between beam polarizations.</li>
	<li>Use a polarizing filter to verify the electric field orientation in each beam path. A polarizing filter will only allow transmission in line with the filter&#39;s axis.</li>
	<li>Verify that the vertical and horizontal components of the laser beam are aligned with each other and the 488&#160;nm beam. Make adjustments as necessary. The three beams should all be focused on the BFP and emerge collimated from the objective to the same spot on the ceiling. This spot can be marked by an X to facilitate future alignment.</li>
	<li>Place a drop of immersion oil on the objective. Place the dish containing fluorescent microspheres (see step&#160;4 above) on the objective.</li>
	<li>Enter TIR by moving the X galvanometer mirror. In TIR, the vertical component of the beam is the s-pol and the horizontal component of the beam is now the p-pol. Adjust the relative intensity between the beams by rotating the QW plate. View each polarized evanescent field with a rhodamine sample, which is predicted to be randomly oriented. Rotate the QW plate to match the average pixel intensities. If necessary, add a neutral density filter in one polarized beam path to attenuate its intensity.</li>
</ol>
2. Chromaffin Cell Isolation
A procedure for isolating healthy chromaffin cells from the calf adrenal gland is provided below. It is adapted from previously published protocols by Wick, Senter, et al.19 and O&#39;Connor, Mahata&#160;et al.20&#160;After isolation, cells are electroporated with plasmid(s) of interest using an electroporation system. This system results in 20-30% of cells expressing the desired fluorescent proteins. Typically, 70% of cells survive the electroporation process. Details of the PSS and media components are provided in Tables 2, 3, and 4.
<ol>
	<li>Two days before the cell prep, treat 35-mm optical quality glass-bottom (0.17&#160;mm thick) dishes with 1 ml poly-D-lysine (0.1 mg/ml) followed by 1.25 ml bovine collagen. Leave dishes to air dry in tissue culture hood.</li>
	<li>Obtain bovine adrenal glands from the abattoir. Keep the glands on ice while they are transported back to the lab. The bovine adrenal glands may be encased in a thick layer of fat. Use surgical scissors to remove excess fat and expose the adrenal vein opening. Perfuse the vein with prep-PSS repeatedly until the gland is purged of blood.</li>
	<li>Next, slowly pipette 2 ml of TH-PSS solution into the vein opening until the gland swells. Incubate the inflated glands at 37 &#176;C for 15 min. Repeat the TH-PSS treatment and incubate again.</li>
	<li>Cut through the outer adrenal cortex around the edge of the gland with scissors and peel the gland apart to expose the medulla. Use a scalpel to gently scrape and separate the medulla from the cortical tissue.</li>
	<li>Mince the medulla with a pair of scalpel blades for 5-10 min.</li>
	<li>A final digestion step is necessary to isolate individual chromaffin cells. Pour the minced cell suspension into a spinner flask. Partially fill the flask with a 2:1 ratio of TH-PSS (30 ml) to TL-PSS (15 ml) and incubate for 30 min at 37 &#176;C while spinning at approximately 100 rpm.</li>
	<li>Separate the individual chromaffin cells from undigested tissue by filtering through a 400&#160;&#956;m mesh. Collect the filtrate. Centrifuge at 200 x g to pellet the cells, and resuspend in ice cold PSS.</li>
	<li>Filter the cells through a 250&#160;&#956;m mesh, pellet, and finally resuspend in electroporation buffer (see step 2.9).</li>
	<li>Count cells using a hemocytometer and prepare for transfection.</li>
	<li>Transfect cells with the electroporation system according to the manufacturer&#39;s recommendations. The precise conditions for electroporation must be determined empirically. Note: The settings which provide the best balance between transfection efficiency and cell survival rate for this preparation of bovine chromaffin cells are 1,100 V, 40 msec, and 1 pulse. We estimate that with these conditions, 20-30% of cells are transfected. About 30% of the cells do not survive the electroporation process.</li>
	<li>Plate cells gently on poly-D-lysine and collagen treated dishes in 1 ml of warmed electroporating media.</li>
	<li>Place dishes in a 37 &#176;C incubator (5% CO2). Add 1 ml of 2x antibiotic media to each dish after 6 hr. Change the media to normal media the next day.</li>
	<li>Chromaffin cells are typically imaged 2-5 days after electroporation.</li>
</ol>
3. pTIRF Image Acquisition
<ol>
	<li>Power on imaging system and start acquisition software.</li>
	<li>Verify that lasers are aligned. Check evanescent field profile using microspheres.</li>
	<li>Prepare the global and local perfusion system. Clean solution reservoirs with filtered deionized H2O and fill with basal and stimulating PSS solutions.</li>
	<li>Before imaging chromaffin cells, verify that the p-pol and s-pol excitations illuminate the same region of the viewing field and that the illumination intensities are roughly equivalent. To do this, fill a glass-bottom dish with 2 ml of PSS containing rhodamine at a final concentration of 10 mM. Sequentially excite the rhodamine sample with p-pol and s-pol light and capture the images. In practice, the P and S emissions from diD are normalized to the mean of the P and S rhodamine emissions. See the Image Analysis and Discussion sections for further details.</li>
	<li>Now proceed to staining bovine chromaffin cells with diD. Rinse culture media from the dish containing the chromaffin cells and replace with 2 ml of basal-PSS. Add 10 &#956;l of 10 mM diD (diluted in ethanol) directly to the dish containing the cells. Gently agitate dish for 2-10 sec&#160;and remove the diD + PSS solution.</li>
	<li>Wash the dish 3-4x with basal-PSS to remove any residual diD. The cells are now stained and ready to use.</li>
	<li>Add a drop of immersion oil to the objective. Place dish containing diD-stained chromaffin cells on top of the objective.</li>
	<li>Viewing the dish either through the objective or on the camera, find a cell which is transfected with the protein of interest and stained with diD. A well-stained cell exhibits a P emission that vividly highlights the edges of the cell; the S emission should be roughly uniform across the cell footprint (i.e.&#160;the region of the cell that is adhered to the glass and imaged in TIRF).</li>
	<li>Position the local perfusion needle so that it is roughly 100 &#956;m away from the cell.</li>
	<li>Focus on the cell membrane and activate the autofocus hardware immediately before cell stimulation/image acquisition.</li>
	<li>Begin image acquisition. Perfuse cells for 10 sec with a basal solution and then for 60 sec with a depolarizing 56 mM KCl solution. Acquire images while rapidly shuttering between 561 nm p-pol, 561 nm s-pol (to monitor changes in P and S emission of diD) and 488 nm excitation (to image the transfected vesicle probe). Examples of images acquired during experiments are shown in Figure 2 and Figure 3.</li>
</ol>
4. Image Analysis
Calculations for image processing may be performed with ImageJ, but utilizing scripts in a flexible programming language such as IDL or Matlab can greatly increase analysis throughput by automating the task. Two types of images must be calculated to obtain topological information from raw emission images - the P/S and P+2S. P/S reports on local membrane deformations while the P+2S sum reports on the total membrane dye in a given region of the field.
<ol>
	<li>All images should be background subtracted. Choose an off-cell ROI, measure the average pixel intensity in the ROI, and then subtracting that value from all pixels in the image stack.</li>
	<li>To calculate P/S, divide each &#34;P&#34; emission frame by the subsequent &#34;S&#34; emission frame (pixel-to-pixel). P/S varies with the relative intensities of the p- and s-pol excitations, biases in the optical system, and interference fringes. To reduce these effects, normalize the P/S ratios from obtained from diD emission to the ratio obtained with a solution containing 10 mM rhodamine18.</li>
	<li>Exocytosis of individual DCVs is evident from a sudden change in intensity of a fluorescent vesicle protein, such as Synaptotagmin-1 pHluorin (Figure 2B). Determine changes in P/S and P+2S by averaging the pixels in a 240&#160;nm radius ROI centered over localized increases in the P/S ratio at sites of exocytosis. When fusion occurs without an evident increase in P/S, the ROI is centered over the region of the fusing DCV.</li>
	<li>Computer simulations can be performed to interpret P/S and P+2S membrane intensity changes in terms of simple geometries of a dilating fusion pore. For details of the simulations, please see Anantharam&#160;et al.18</li>
</ol>

<ol>
	<li>Chernomordik, L. V., Zimmerberg, J., Kozlov, M. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Membranes of the world unite! Cell Biol. 175, 201-207 (2006).</li><li>Chapman, E. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=How+does+synaptotagmin+trigger+neurotransmitter+release.">How does synaptotagmin trigger neurotransmitter release.</a> Annu. Rev. Biochem. 77, 615-641 (2008).</li><li>Hinshaw, J. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamin+and+its+role+in+membrane+fission.">Dynamin and its role in membrane fission.</a> Annu. Cell Dev. Biol. 16, 483-519 (2000).</li><li>Lang, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ca2+-triggered+peptide+secretion+in+single+cells+imaged+with+green+fluorescent+protein+and+evanescent-wave+microscopy.">Ca2+-triggered peptide secretion in single cells imaged with green fluorescent protein and evanescent-wave microscopy.</a> Neuron. 18 (6), 857-863 (1997).</li><li>Steyer, J. A., Horstman, H., Almers, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transport,+docking+and+exocytosis+of+single+secretory+granules+in+live+chromaffin+cells.">Transport, docking and exocytosis of single secretory granules in live chromaffin cells.</a> Nature. 388, 474-478 (1997).</li><li>Allersma, M. W., Wang, L., Axelrod, D., Holz, R. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Visualization+of+regulated+exocytosis+with+a+granule-membrane+probe+using+total+internal+reflection+microscopy.">Visualization of regulated exocytosis with a granule-membrane probe using total internal reflection microscopy.</a> Mol. Biol. Cell. 15, 4658-4668 (2004).</li><li>Toomre, D., Steyer, J. A., Keller, P., Almers, W., Simons, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fusion+of+constitutive+membrane+traffic+with+the+cell+surface+observed+by+evanescent+wave+microscopy.">Fusion of constitutive membrane traffic with the cell surface observed by evanescent wave microscopy.</a> J. Cell Biol. 149, 33-40 (2000).</li><li>Schmoranzer, J., Goulian, M., Axelrod, D., Simon, S. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+constitutive+exocytosis+with+total+internal+reflection+fluorescence+microscopy.">Imaging constitutive exocytosis with total internal reflection fluorescence microscopy.</a> J. Cell Biol. 149, 23-32 (2000).</li><li>Heinemann, C., Chow, R. H., Neher, E., Zucker, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Kinetics+of+the+secretory+response+in+bovine+chromaffin+cells+following+flash+photolysis+of+caged+Ca2.">Kinetics of the secretory response in bovine chromaffin cells following flash photolysis of caged Ca2.</a> Biophys. J. 67, 2546-2557 (1994).</li><li>Heidelberger, R., Heinemann, C., Neher, E., Matthews, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Calcium+dependence+of+the+rate+of+exocytosis+in+a+synaptic+terminal.">Calcium dependence of the rate of exocytosis in a synaptic terminal.</a> Nature. 371 (6497), 513-515 (1994).</li><li>Chow, R. H., Klingauf, J., Heinemann, C., Zucker, R. S., Neher, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+determining+the+time+course+of+secretion+in+neuroendocrine+cells.">Mechanisms determining the time course of secretion in neuroendocrine cells.</a> Neuron. 16, 369-376 (1996).</li><li>Thompson, N. L., McConnell, H. M., Burhardt, T. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Order+in+supported+phospholipid+monolayers+detected+by+the+dichroism+of+fluorescence+excited+with+polarized+evanescent+illumination.">Order in supported phospholipid monolayers detected by the dichroism of fluorescence excited with polarized evanescent illumination.</a> Biophys. J. 46, 739-747 (1984).</li><li>Sund, S. E., Swanson, J. A., Axelrod, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cell+membrane+orientation+visualized+by+polarized+total+internal+reflection+fluorescence.">Cell membrane orientation visualized by polarized total internal reflection fluorescence.</a> Biophys. J. 77, 2266-2283 (1999).</li><li>Zenisek, D., Steyer, J. A., Feldman, M. E., Almers, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+membrane+marker+leaves+synaptic+vesicles+in+milliseconds+after+exocytosis+in+retinal+bipolar+cells.">A membrane marker leaves synaptic vesicles in milliseconds after exocytosis in retinal bipolar cells.</a> Neuron. 35, 1085-1097 (2002).</li><li>Anantharam, A., Axelrod, D., Holz, R. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+imaging+of+plasma+membrane+deformations+reveals+pre-fusion+membrane+curvature+changes+and+a+role+for+dynamin+in+the+regulation+of+fusion+pore+expansion.">Real-time imaging of plasma membrane deformations reveals pre-fusion membrane curvature changes and a role for dynamin in the regulation of fusion pore expansion.</a> J. Neurochem. , 10-1111 (2012).</li><li>Anantharam, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+role+for+the+dynamin+GTPase+in+the+regulation+of+fusion+pore+expansion.">A new role for the dynamin GTPase in the regulation of fusion pore expansion.</a> Mol. Biol. Cell. 22, 1907-1918 (2011).</li><li>Anantharam, A., Axelrod, D., Holz, R. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Polarized+TIRFM+reveals+changes+in+plasma+membrane+topology+before+and+during+granule+fusion.">Polarized TIRFM reveals changes in plasma membrane topology before and during granule fusion.</a> Cell Mol. Neurobiol. 30, 1343-1349 (2010).</li><li>Anantharam, A., Onoa, B., Edwards, R. H., Holz, R. W., Axelrod, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Localized+topological+changes+of+the+plasma+membrane+upon+exocytosis+visualized+by+polarized+TIRFM.">Localized topological changes of the plasma membrane upon exocytosis visualized by polarized TIRFM.</a> J. Cell. 188, 415-428 (2010).</li><li>Wick, P. W., Senter, R. A., Parsels, L. A., Holz, R. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transient+transfection+studies+of+secretion+in+bovine+chromaffin+cells+and+PC12+cells:+generation+of+kainate-sensitive+chromaffin+cells.">Transient transfection studies of secretion in bovine chromaffin cells and PC12 cells: generation of kainate-sensitive chromaffin cells.</a> J. Biol. Chem. 268, 10983-10989 (1993).</li><li>O'Connor, D. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Primary+culture+of+bovine+chromaffin+cells.">Primary culture of bovine chromaffin cells.</a> Nat. Protoc. 2, 1248-1253 (2007).</li><li>Nakai, J., Ohkura, M., Imoto, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+high+signal-to-noise+Ca2++composed+of+a+single+green+fluorescent+protein.">A high signal-to-noise Ca2+ composed of a single green fluorescent protein.</a> Nat. Biotechnol. 19, 137-141 (2001).</li><li>Akerboom, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimization+of+a+GCaMP+calcium+indicator+for+neural+activity+imaging.">Optimization of a GCaMP calcium indicator for neural activity imaging.</a> Neurosci. 32, 13819-13840 (2012).</li></ol>

The authors have nothing to disclose.

Polarization-based TIRFM detects rapid, submicroscopic changes in membrane topology. Implementing the technique is relatively straightforward, particularly if TIRF optics are already in place. All that is needed is a quarter-wave plate, two polarizing cubes, and shutters to separate p-pol and s-pol illumination paths. The precise position of these components on the table is usually dictated by space available.
In order to obtain membrane topological information, the fluorescent probe used should intercalate with a fixed or known orientation. The technique, as described in this article, assumes the use of carbocyanine dyes but other dyes, such as FM1-4314, may also be used. The membrane staining procedure itself is straightforward. Cultured cells require only a very brief exposure (less than 10 sec) to a small quantity of diI/diD to obtain exuberant labeling of the membrane. Adding excess dye leads to light scattering aggregates on the glass which diminish image quality. Over-incubating cells with dye leads to dye internalization which has detrimental effects on image quality and possibly cell viability. If a cell is stained well, there will be clear distinction in the P and S emission images. As shown in Figure 2A, the P emission will vividly highlight areas of the membrane that are coverslip oblique (i.e.&#160;the edges of the cell footprint) while the S emission intensity will be roughly uniform over the cell footprint. If a clear distinction between P and S is not apparent, then it is possible that the cell is poorly adhered to the substrate or the cell membrane is not healthy, and the cell is not used for experiments.
Our previous studies describing pTIRFM utilized diI as the fluorescent membrane probe. Here, we utilize diD because it is suitable for dual-color imaging experiments that employ GFP/pHluorin as the other fluorophore. We excite diD with a 561 nm laser rather than 640 nm laser (which is closer to its excitation peak) because the fluorophore bleaches more rapidly at 640 nm. Despite the fact that the 561&#160;nm laser is on the tail of diD&#39;s published excitation spectrum, fluorescence is efficiently emitted. Another advantage of the 561&#160;nm laser is that it excites both diI and diD enabling us to use the same polarization setup for both probes. Note that the orientation of the fluorophore in the membrane will affect the interpretation of membrane topology. For example, if a fluorophore were oriented with its transition dipoles perpendicular to the membrane plane (rather than parallel, or nearly parallel, as is the case with diI or diD), then nonplanar membrane regions will be more readily highlighted by the S rather than the P emission.
We have also described techniques for isolation and electroporation of bovine adrenal chromaffin cells. The bovine chromaffin cell is an excellent secretory model. It has the advantages of being easy to maintain in culture, responsive to a variety of secretogogues, and possessing large secretory vesicles that are readily visualized with conventional light microscopy. To express fluorescent proteins, cells are electroporated in suspension prior to plating on collagen-treated culture dishes. In our experience, expression efficiency is much higher with electroporation than with either Ca2+-phosphate or Lipofectamine reagents. The drawback of electroporation is that it requires more cells (as many do not survive the process) and expensive commercial reagents. For reasons that are unclear to us, not every membrane incorporates diD. In addition, only a fraction of the cells on the dish are transfected. Finding cells that are transfected AND are stained well with diD can be time consuming which is why optimizing conditions for staining and electroporation is well worth the effort.
In summary, this article describes how pTIRFM is implemented to monitor the rapid and localized membrane deformations that occur during fusion of dense core vesicles in bovine chromaffin cells. Although only one application is discussed, the technique is ideally suited for the study of other biological processes that involve changes in membrane shape, including endocytosis, cytokinesis, and cell motility.

The proper execution of exocytosis requires extreme changes in membrane bilayer shape to be precisely orchestrated. Prior to fusion, local bending of the plasma membrane under the granule occurs, in part to reduce the energy barrier for interaction of bilayers. Later, as membranes merge, areas of high curvature are generated and must be stabilized. Finally, fused membranes must be bent out of their initial shape to expand the fusion pore and enable content release1. Because membranes alone are unlikely to undergo such dramatic and coordinated changes, proteins are necessary to mediate events. But how they act to influence changes in membrane topology during the fusion process remains very much an open question.
Excellent in vitro models exist to visualize membrane curvature. The use of negative-stain EM, for instance, has been important for shaping current molecular models for the actions of two major trafficking proteins - synaptotagmin and dynamin (for reviews, see Chapman2 and Henshaw3). Most real-time assays of exocytosis do not detect curvature directly. Instead, curvature is inferred from assays that report on the kinetics of lumenal cargo release4-8 or changes in membrane area9-11. PTIRFM bridges the gap between in vivo and in vitro studies by enabling direct, real-time measurements of changes in membrane micromorphology.
PTIRFM, in a nonimaging mode, was pioneered by Axelrod and colleagues to measure the orientation of NPD-PE incorporated within a model membrane12. The technique was then applied to visualize dynamic changes in living cells labeled with diI and FM1-4313-18. In pTIRFM, two evanescent field polarizations are used to sequentially excite a membrane-embedded probe: p-polarization (in the plane of incidence) and s-polarization (perpendicular to the plane of incidence). Prior to imaging, the probe - in this case, diD - is briefly added to the extracellular medium and is allowed to intercalate in the plasma membranes of the cells to be studied. In regions where the membrane is nonparallel to the coverglass (as in a membrane ruffle or indentation), the diD will also be nonparallel. Therefore, such regions will be excitable by the p-pol beam. The p-pol beam will less effectively excite diD in membrane regions that are mostly parallel to the coverglass. Pixel-to-pixel ratio images (P/S) reporting on the emission from sequential p- and s-pol excitation of diD will therefore specifically highlight regions of membrane deformation. In theory, the P/S ratio images are sensitive to even small angles of plasma membrane deviation from the coverglass, with the amplitude of the changes predicted by computer simulations18. P/S images are also independent of fluorophore distance from the coverglass surface and local fluorophore concentration. Local fluorophore concentration is instead provided by images reporting on the pixel-to-pixel sum of the P emission and 2 times the S emission (P+2S). The P+2S measurement is sensitive to the precise geometry of the indentation, with some, little, or no change possible. This can be shown by computer simulations that model transitions of a fusion pore from an early (i.e.&#160;with a narrow neck) to a later state16,18. The P+2S of a fused vesicle attached to the plasma membrane via a narrow neck (and with more diD close to the interface) is predicted to be greater, for example, than that of a fused vesicle with a much wider pore (where the diD is within the dimmest part of the evanescent field).
In this article, we discuss how pTIRFM is implemented and utilized to study the rapid, localized changes in membrane shape that occur during fusion pore dilation. While only one application is explicitly discussed, the methods are generalizable to a variety of other cell biological processes that directly or indirectly involve membrane remodeling.

<table border="0" cellpadding="0" cellspacing="0" width="817">
	<tbody>
		<tr height="17">
			<td height="17" style="height:17px;width:277px;">iXon3 EMMCD Camera</td>
			<td style="width:179px;">Andor</td>
			<td style="width:147px;">897</td>
			<td style="width:215px;"></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">IX81 Inverted Microscope</td>
			<td>Olympus</td>
			<td></td>
			<td>Side-mounted Filtercube Assembly</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">43 Series Ar-Ion Laser</td>
			<td>CVI Milles Griot Laser Optics</td>
			<td>543-AP-A01</td>
			<td>Tunable to 488nm</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Sapphire 561 LP Diode Laser</td>
			<td>Coherent</td>
			<td></td>
			<td>561nm</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Scanning Galvo Mirror System</td>
			<td>Thorlabs</td>
			<td>GVS102</td>
			<td></td>
		</tr>
		<tr height="19">
			<td height="19" style="height:19px;">VC3 Channel Focal Perfusion System</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA VC3X4PP</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">QMM Quartz MicroManifold</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA QMM-4</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">10 PSI Pressure Regulator</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA PR10</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Manipulator</td>
			<td>Burleigh</td>
			<td>TS 5000-150</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Mounted Achromatic Quarter-Wave Plate</td>
			<td>Thorlabs</td>
			<td>AQWP05M-600</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">420-680nm Polarizing Beamsplitter Cube</td>
			<td>Thorlabs</td>
			<td>PBS201</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Six Station Neutral Density Wheel</td>
			<td>Thorlabs</td>
			<td>FW1AND</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Stepper-motor Driven SmartShutter</td>
			<td>Sutter Instruments</td>
			<td>IQ25-1219</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">HQ412lp Dichroic Filter</td>
			<td>Chroma</td>
			<td>NC255583</td>
			<td>Joins 488nm and 561nm beams</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Coated Plano-Concave Lens</td>
			<td>Edmund Optics</td>
			<td>PCV 100mm VIS 0</td>
			<td>Diverges 488nm beam</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Coated Plano-Concave Lens</td>
			<td>Edmund Optics</td>
			<td>PCV 250mm VIS 0</td>
			<td>Diverges 561nm beam</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Coated Plano-Convex Lens</td>
			<td>Edmund Optics</td>
			<td>PCX 125mm VIS 0</td>
			<td>Focuses both beams</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Coated Plano-Convex Lens</td>
			<td>Edmund Optics</td>
			<td>PCX 50mm VIS 0</td>
			<td>Cemented to filter cube assembly</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">z488/561rpc Dichroic</td>
			<td>Chroma</td>
			<td>z488/561rpc</td>
			<td>Filtercube dichroic</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">z488/561_TIRF Emission Filter</td>
			<td>Chroma</td>
			<td>z488/561m_TIRF</td>
			<td>Filtercube emission</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">UIS2 60x Objective</td>
			<td>Olympus</td>
			<td>UPLSAPO 60XO</td>
			<td>NA 1.37</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Neon Transfection System</td>
			<td>Invitrogen</td>
			<td>MPK 5000</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">MetaMorph Imaging Software</td>
			<td>Molecular Devices</td>
			<td></td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">DiI Membrane Dye</td>
			<td>Invitrogen</td>
			<td>V-22885</td>
			<td>For Alignment Purposes</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">TH Liberase</td>
			<td>Roche</td>
			<td>5401135001</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">TL Liberse</td>
			<td>Roche</td>
			<td>5401020001</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">DNAse I Type IV from bovine</td>
			<td>Sigma</td>
			<td>D5025</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Hemocytometer</td>
			<td>Fisher</td>
			<td>0267110</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">DiD Membrane Dye</td>
			<td>Invitrogen</td>
			<td>D-7757</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Rhodamine</td>
			<td>Invitrogen</td>
			<td>R634</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">.22 &#956;m Membrane Syringe Filter Unit</td>
			<td>Millipore</td>
			<td>SLGS033SS</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Fluoresbrite Polychromatic Red Microspheres</td>
			<td>Polysciences</td>
			<td>19507</td>
			<td>0.5 microns</td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">Immersion Oil</td>
			<td>Sigma</td>
			<td>56822</td>
			<td></td>
		</tr>
		<tr height="17">
			<td height="17" style="height:17px;">LabVIEW</td>
			<td>National Instruments</td>
			<td></td>
			<td>Controlls galvo mirrors</td>
		</tr>
		<tr height="19">
			<td height="19" style="height:19px;">Spinner Flask</td>
			<td>Bellco</td>
			<td>1965-00250</td>
			<td></td>
		</tr>
	</tbody>
</table>

imaging plasma membrane deformations with ptirfm

To gain novel insights into the dynamics of exocytosis, our group focuses on the changes in lipid bilayer shape that must be precisely regulated during the fusion of vesicle and plasma membranes. These rapid and localized changes are achieved by dynamic interactions between lipids and specialized proteins that control membrane curvature. The absence of such interactions would not only have devastating consequences for vesicle fusion, but a host of other cellular functions that involve control of membrane shape. In recent years, the identity of a number of proteins with membrane-shaping properties has been determined. What remains missing is a roadmap of when, where, and how they act as fusion and content release progress.
Our understanding of the molecular events that enable membrane remodeling has historically been limited by a lack of analytical methods that are sensitive to membrane curvature or have the temporal resolution to track rapid changes. PTIRFM satisfies both of these criteria. We discuss how pTIRFM is implemented to visualize and interpret rapid, submicron changes in the orientation of chromaffin cell membranes during dense core vesicle (DCV) fusion. The chromaffin cells we use are isolated from bovine adrenal glands. The membrane is stained with a lipophilic carbocyanine dye,1,1&#39;-dioctadecyl-3,3,3&#39;,3&#39;-tetramethylindodicarbocyanine, 4-chlorobenzenesulfonate, or&#160;diD. DiD intercalates in the membrane plane with a &#34;fixed&#34; orientation and is therefore sensitive to the polarization of the evanescent field. The diD-stained cell membrane is sequentially excited with orthogonal polarizations of a 561&#160;nm laser (p-pol, s-pol). A 488&#160;nm laser is used to visualize vesicle constituents and time the moment of fusion. Exocytosis is triggered by locally perfusing cells with a depolarizing KCl solution. Analysis is performed offline using custom-written software to understand how diD emission intensity changes relate to fusion pore dilation.

Conventional and polarized TIRFM imaging techniques are implemented on the same air table. The configuration of the optical elements is similar, with the major difference that the excitation light is polarized (Figure 1A). Polarized light preferentially excites fluorophores with absorption dipoles in the polarization direction. Thus, for pTIRFM to be effective at monitoring membrane topological changes, the probe that is used must intercalate in the membrane with a fixed orientation. The fluorescent carbocyanine dyes (diI, diD) intercalate into lipid bilayers in an oriented fashion with transition dipoles in the membrane plane (Figure 1B). P-polarized illumination (Figure 1C) of diD-labeled membranes selectively excites coverslip-oblique fluorophores (RED in Figures 1B and&#160;1D).
Exuberant membrane labeling of chromaffin cells is achieved after a brief incubation with diD. Figure 2A shows an example of a cell membrane that is stained well. A healthy, adherent cell will exhibit distinct differences in P and S emissions. The P emission image shows a brighter cell border with respect to the rest of cell. The S emission image shows roughly uniform fluorescence across the cell footprint. Calculated pixel-to-pixel P/S and P+2S images are sensitive to membrane curvature and dye concentration, respectively. The chromaffin cell shown has also been transfected with Synaptotagmin-1 pHluorin (Syt-1) to label secretory vesicles (Figure 2B).
The chromaffin cell is stimulated with 56 mM KCl to depolarize the cell membrane and trigger exocytosis. A number of brightly fluorescent Syt-1 pHluorin spots suddenly become evident as DCVs fuse (Figure 2B, right panel). A white box is drawn around one fusion event (Figure 2B, right panel). This fusion event is analyzed in Figures 2C and 2D. Figure 2C shows frame-by-frame changes in Syt-1-pHluorin, P/S, and P+2S image intensities. Fluorescence intensity of Syt-1 quickly diminishes as the protein diffuses away from the fusion site (Figure 2D). The indentation representing the fused vesicle/plasma membrane complex diminishes at a relatively slower rate (Note graphs in Figure 2D). The illustration (Figure 2E) depicts one interpretation of these measurements.
The rapid and localized membrane deformations shown in Figure 2 are a result of stimulus-evoked Ca2+ influx. This is shown in Figure 3A. A chromaffin cell is transfected with the genetic Ca2+ indicator GCaMP5G21,22 and stimulated with 56 mM KCl. Membrane depolarization causes a significant increase in GCaMP5G fluorescence (Figures 3A&#160;and&#160;3B) signifying an increase in subplasmalemmal Ca2+ levels. A 30 x 20 pixel region of the cell is selected and frame-by-frame changes in GCaMP5G, P/S, and P+2S pixel intensities are shown in the images (Figure 3B) and graphs (Figure 3C). Time &#34;0&#34; designates the frame before a change a P/S is evident (i.e.&#160;the frame before exocytosis). The white arrowheads indicate that the membrane deformation (increase in P/S) is accompanied by a decrease in P+2S emission. The cytosolic GCaMP5G protein is excluded from the area by the fused DCV. Note also the sudden decrease in GCaMP5G intensity at time 0 in Figure 3C, left panel. The long-lived increase in P/S and decrease in P+2S suggest a fusion pore that dilates slowly (Figure 3D).
<img alt="Figure 1" src="/files/ftp_upload/51334/51334fig1.jpg" />
Figure 1. Illustrations for the pTIRFM technique. A)&#160;A schematic for combining conventional with polarization-based TIRF imaging is shown. A quarter-wave (QW) plate is placed in front of a 561-nm sapphire laser to elliptically polarize the laser beam. A polarizing cube (PC1) is used to separate polarizations into linear vertical (v) and horizontal (h) components. The vertical and horizontal components become the p-pol and s-pol excitation beams, respectively, at the TIR surface. The p-pol and s-pol paths are independently shuttered (S1 and S2). They are recombined with mirrors and a second polarizing cube (PC2). They join the 488&#160;nm beam (also independently shuttered, S3) via a beam steering element consisting of a mirror and nonpolarizing dichroic mirror (DC). Lenses (L) are used to expand and focus the beams. Combined 488-nm and 561-nm beams are steered to a side illumination port of the microscope via galvanometer mirrors (GM). They focus to the back focal plane (BFP) of the objective. Photons emitted from fluorophores are captured on an EMCCD camera connected to a PC. B)&#160;DiD labeling is performed by briefly incubating cells with the dye and washing repeatedly to remove excess. DiD intercalates in the membrane with its transition dipole moments roughly in the membrane plane. C)&#160;The incident light polarized in the plane of incidence (p-pol) creates an evanescent field that is predominantly polarized normal to the interface, as shown. D)&#160;Illumination of a diD-labeled membrane with p-polarized light will selectively excite those fluorophores that are coverglass-oblique (RED). If this were an s-polarized evanescent field, those fluorophores that are parallel to the coverglass would be excited instead (BLACK).
<img alt="Figure 2" src="/files/ftp_upload/51334/51334fig2.jpg" />
Figure 2. Monitoring cell membrane deformations with pTIRFM. A)&#160;Raw P and S emission images along with calculated P/S and P+2S emission images are shown. Scale bar, 3.2 &#956;m. B)&#160;A chromaffin cell expressing Syt-1 pHluorin is depolarized with KCl. A number of brightly fluorescent spots (right panel) indicate the fusion of individual DCVs. Scale bar, 3.2 &#956;m. C)&#160;Frame-by-frame images of a fusing Syt-1 pHluorin DCV. Times (above images) are in seconds. Time 0 designates frame before fusion of the DCV. Corresponding P/S and P+2S emission images are also shown. Scale bar is 1 &#956;m. D)&#160;Graphs for images in C.&#160;Dotted line is at time 0 -- the fusion frame. E)&#160;One possible interpretation of the results in C and D is shown. <a href="https://www.jove.com/files/ftp_upload/51334/51334fig2highres.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" src="/files/ftp_upload/51334/51334fig3.jpg" />
Figure 3. Deformations are a result of stimulus-evoked Ca2+ influx. A)&#160;A chromaffin cell transfected with GCaMP5G is depolarized with 56 mM KCl. The resulting increase in GCaMP5G fluorescence signifies an increase in subplasmalemmal Ca2+ levels. B)&#160;Frame-by-frame images of 30 x 20 pixel area of cell in A. Times above images are in seconds. White arrowheads indicate a region of P/S increase and P+2S decrease. Cytosolic GCaMP5G protein is excluded from the region by the fusing DCV. Scale bar, 1 &#956;m. C)&#160;Graphs for images shown in B. D)&#160;One possible interpretation of the results in B and C is shown. <a href="https://www.jove.com/files/ftp_upload/51334/51334fig3highres.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<table border="0" cellpadding="0" cellspacing="0">
	<tbody>
		<tr>
			<td>iXon3 EMMCD Camera</td>
			<td>Andor</td>
			<td>897</td>
			<td></td>
		</tr>
		<tr>
			<td>IX81 Inverted Microscope</td>
			<td>Olympus</td>
			<td></td>
			<td>Side-mounted Filtercube Assembly</td>
		</tr>
		<tr>
			<td>43 Series Ar-Ion Laser</td>
			<td>CVI Milles Griot Laser Optics</td>
			<td>543-AP-A01</td>
			<td>Tunable to 488 nm</td>
		</tr>
		<tr>
			<td>Sapphire 561 LP Diode Laser</td>
			<td>Coherent</td>
			<td></td>
			<td>561 nm</td>
		</tr>
		<tr>
			<td>Scanning Galvo Mirror System</td>
			<td>Thorlabs</td>
			<td>GVS102</td>
			<td></td>
		</tr>
		<tr>
			<td>VC3 Channel Focal Perfusion System</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA VC3X4PP</td>
			<td></td>
		</tr>
		<tr>
			<td>QMM Quartz MicroManifold</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA QMM-4</td>
			<td></td>
		</tr>
		<tr>
			<td>10 psi Pressure Regulator</td>
			<td>ALA Scientific Instruments</td>
			<td>ALA PR10</td>
			<td></td>
		</tr>
		<tr>
			<td>Manipulator</td>
			<td>Burleigh</td>
			<td>TS 5000-150</td>
			<td></td>
		</tr>
		<tr>
			<td>Mounted Achromatic Quarter-Wave Plate</td>
			<td>Thorlabs</td>
			<td>AQWP05M-600</td>
			<td></td>
		</tr>
		<tr>
			<td>420-680 nm Polarizing Beamsplitter Cube</td>
			<td>Thorlabs</td>
			<td>PBS201</td>
			<td></td>
		</tr>
		<tr>
			<td>Six Station Neutral Density Wheel</td>
			<td>Thorlabs</td>
			<td>FW1AND</td>
			<td></td>
		</tr>
		<tr>
			<td>Stepper-motor Driven SmartShutter</td>
			<td>Sutter Instruments</td>
			<td>IQ25-1219</td>
			<td></td>
		</tr>
		<tr>
			<td>HQ412lp Dichroic Filter</td>
			<td>Chroma</td>
			<td>NC255583</td>
			<td>Joins 488 nm and 561 nm beams</td>
		</tr>
		<tr>
			<td>Coated Plano-Concave Lens</td>
			<td>Edmund Optics</td>
			<td>PCV 100mm VIS 0</td>
			<td>Diverges 488 nm beam</td>
		</tr>
		<tr>
			<td>Coated Plano-Concave Lens</td>
			<td>Edmund Optics</td>
			<td>PCV 250mm VIS 0</td>
			<td>Diverges 561 nm beam</td>
		</tr>
		<tr>
			<td>Coated Plano-Convex Lens</td>
			<td>Edmund Optics</td>
			<td>PCX 125mm VIS 0</td>
			<td>Focuses both beams</td>
		</tr>
		<tr>
			<td>Coated Plano-Convex Lens</td>
			<td>Edmund Optics</td>
			<td>PCX 50mm VIS 0</td>
			<td>Cemented to filter cube assembly</td>
		</tr>
		<tr>
			<td>z488/561rpc Dichroic</td>
			<td>Chroma</td>
			<td>z488/561rpc</td>
			<td>Filtercube dichroic</td>
		</tr>
		<tr>
			<td>z488/561_TIRF Emission Filter</td>
			<td>Chroma</td>
			<td>z488/561m_TIRF</td>
			<td>Filtercube emission</td>
		</tr>
		<tr>
			<td>UIS2 60X Objective</td>
			<td>Olympus</td>
			<td>UPLSAPO 60XO</td>
			<td>NA 1.37</td>
		</tr>
		<tr>
			<td>Neon Transfection System</td>
			<td>Invitrogen</td>
			<td>MPK 5000</td>
			<td></td>
		</tr>
		<tr>
			<td>MetaMorph Imaging Software</td>
			<td>Molecular Devices</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>DiI Membrane Dye</td>
			<td>Invitrogen</td>
			<td>V-22885</td>
			<td>For Alignment Purposes</td>
		</tr>
		<tr>
			<td>TH Liberase</td>
			<td>Roche</td>
			<td>5401135001</td>
			<td></td>
		</tr>
		<tr>
			<td>TL Liberse</td>
			<td>Roche</td>
			<td>5401020001</td>
			<td></td>
		</tr>
		<tr>
			<td>DNAse I Type IV from bovine</td>
			<td>Sigma</td>
			<td>D5025</td>
			<td></td>
		</tr>
		<tr>
			<td>Hemocytometer</td>
			<td>Fisher</td>
			<td>0267110</td>
			<td></td>
		</tr>
		<tr>
			<td>DiD Membrane Dye</td>
			<td>Invitrogen</td>
			<td>D-7757</td>
			<td></td>
		</tr>
		<tr>
			<td>Rhodamine</td>
			<td>Invitrogen</td>
			<td>R634</td>
			<td></td>
		</tr>
		<tr>
			<td>0.22 &#956;m Membrane Syringe Filter Unit</td>
			<td>Millipore</td>
			<td>SLGS033SS</td>
			<td></td>
		</tr>
		<tr>
			<td>Fluoresbrite Polychromatic Red Microspheres</td>
			<td>Polysciences</td>
			<td>19507</td>
			<td>0.5 &#956;m</td>
		</tr>
		<tr>
			<td>Immersion Oil</td>
			<td>Sigma</td>
			<td>56822</td>
			<td></td>
		</tr>
		<tr>
			<td>LabVIEW</td>
			<td>National Instruments</td>
			<td></td>
			<td>Controls galvo mirrors</td>
		</tr>
		<tr>
			<td>Spinner Flask</td>
			<td>Bellco</td>
			<td>1965-00250</td>
			<td></td>
		</tr>
	</tbody>
</table>
Table 1. pTIRF Microscopy equipment.
<table>
	<tbody>
		<tr>
			<td>Contents</td>
			<td>Prep-PSS</td>
			<td>Basal-PSS</td>
			<td>Stim-PSS</td>
		</tr>
		<tr>
			<td>NaCl</td>
			<td>145 mM</td>
			<td>145 mM</td>
			<td>95 mM</td>
		</tr>
		<tr>
			<td>KCl</td>
			<td>5.6 mM</td>
			<td>5.6 mM</td>
			<td>56 mM</td>
		</tr>
		<tr>
			<td>MgCl2</td>
			<td>-</td>
			<td>0.5 mM</td>
			<td>0.5 mM</td>
		</tr>
		<tr>
			<td>CaCl2</td>
			<td>-</td>
			<td>2.2 mM</td>
			<td>5 mM</td>
		</tr>
		<tr>
			<td>HEPES</td>
			<td>15 mM</td>
			<td>15 mM</td>
			<td>15 mM</td>
		</tr>
		<tr>
			<td>pH</td>
			<td>7.4</td>
			<td>7.4</td>
			<td>7.4</td>
		</tr>
		<tr>
			<td>Glucose</td>
			<td>2.8 mM</td>
			<td>5.6 mM</td>
			<td>5.6 mM</td>
		</tr>
		<tr>
			<td>Pen-Strep</td>
			<td>1x</td>
			<td>-</td>
			<td>-</td>
		</tr>
	</tbody>
</table>
Table 2. Perfusion and chromaffin cell prep solutions.
<table>
	<tbody>
		<tr>
			<td>Contents</td>
			<td>Electroporating Media</td>
			<td>Normal Plating Media</td>
			<td>2x Antibiotic Media</td>
		</tr>
		<tr>
			<td>1x DMEM/F-12</td>
			<td>1 ml/plate</td>
			<td>2 ml/plate</td>
			<td>1 ml/plate</td>
		</tr>
		<tr>
			<td>FBS</td>
			<td>10%</td>
			<td>10%</td>
			<td>10%</td>
		</tr>
		<tr>
			<td>Cytosine Arabinofuranoside (CAF)</td>
			<td>-</td>
			<td>1 &#956;l/ml from 10 mM Stock</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Penicillin</td>
			<td>-</td>
			<td>100 units/ml</td>
			<td>200 units/ml</td>
		</tr>
		<tr>
			<td>Streptomycin</td>
			<td>-</td>
			<td>100 &#956;g/ml</td>
			<td>200 &#956;g/ml</td>
		</tr>
		<tr>
			<td>Gentamycin</td>
			<td>-</td>
			<td>25 &#956;g/ml</td>
			<td>50 &#956;g/ml</td>
		</tr>
	</tbody>
</table>
Table 3. Chromaffin Cell Media.
<table>
	<tbody>
		<tr>
			<td>Contents</td>
			<td>TH-PSS</td>
			<td>TL-PSS</td>
		</tr>
		<tr>
			<td>Liberase TH</td>
			<td>2 ml</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Liberase TL</td>
			<td>-</td>
			<td>0.85 ml</td>
		</tr>
		<tr>
			<td>Prep-PSS</td>
			<td>98.0 ml</td>
			<td>84.0 ml</td>
		</tr>
		<tr>
			<td>DNase</td>
			<td>8.75 mg</td>
			<td>7.4 mg</td>
		</tr>
	</tbody>
</table>
Table 4. TH-PSS and TL-PSS Solutions.

Watch this Scientific Journal Video about Imaging Plasma Membrane Deformations With pTIRFM at JoVE.com

Imaging Plasma Membrane Deformations With pTIRFM

Polarization-based Total Internal Reflection Fluorescence Microscopy (pTIRFM) enables real-time detection of cell membrane dynamics. This article describes the implementation of pTIRFM for the study of membrane remodeling during regulated exocytosis. The technique is generalizable to other processes in cell biology that directly or indirectly involve changes in membrane shape.

To gain novel insights into the dynamics of exocytosis, our group focuses on the changes in lipid bilayer shape that must be precisely regulated during ...

imaging-plasma-membrane-deformations-with-ptirfm

Microsoft Bing

Research

JoVE Journal

Biology

13.5K Views.  Wayne State University. Polarization-based Total Internal Reflection Fluorescence Microscopy (pTIRFM) enables real-time detection of cell membrane dynamics. This article describes the implementation of pTIRFM for the study of membrane remodeling during regulated exocytosis. The technique is generalizable to other processes in cell biology that directly or indirectly involve changes in membrane shape.

Video: Imaging Plasma Membrane Deformations With pTIRFM

Measuring Near Plasma Membrane and Global Intracellular Calcium Dynamics in Astrocytes

The brain contains glial cells.  Astrocytes, a type of glial cell, have long been known to provide a passive supportive role to neurons. However, increasing evidence suggests that astrocytes may also actively participate in brain function through functional interactions with neurons.  However, many fundamental aspects of astrocyte biology remain controversial, unclear and/or experimentally unexplored. One important issue is the dynamics of intracellular calcium transients in astrocytes. This is relevant because calcium is well established as an important second messenger and because it has been proposed that astrocyte calcium elevations can trigger the release of transmitters from astrocytes. However, there has not been any detailed or satisfying description of near plasma membrane calcium signaling in astrocytes. Total internal reflection fluorescence (TIRF) microscopy is a powerful tool to analyze physiologically relevant signaling events within about 100 nm of the plasma membrane of live cells. Here, we use TIRF microscopy and describe how to monitor near plasma membrane and global intracellular calcium dynamics almost simultaneously. The further refinement and systematic application of this approach has the potential to inform about the precise details of astrocyte calcium signaling. A detailed understanding of astrocyte calcium dynamics may provide a basis to understand if, how, when and why astrocytes and neurons undergo calcium-dependent functional interactions.

We describe how to measure near membrane and global intracellular calcium dynamics in cultured astrocytes using total internal reflection and epifluorescence microscopy.

The brain contains glial cells.  Astrocytes, a type of glial cell, have long been known to provide a passive supportive role to neurons. However, ...

Measuring Plasma Membrane Protein Endocytic Rates by Reversible Biotinylation

Plasma membrane proteins are a large, diverse group of proteins comprised of receptors, ion channels, transporters and pumps.  Activity of these proteins is responsible for a variety of key cellular events, including nutrient delivery, cellular excitability, and chemical signaling.  Many plasma membrane proteins are dynamically regulated by endocytic trafficking, which modulates protein function by altering protein surface expression.  The mechanisms that facilitate protein endocytosis are complex and are not fully understood for many membrane proteins.  In order to fully understand the mechanisms that control the endocytic trafficking of a given protein, it is critical that the protein s endocytic rate be precisely measured.  For many receptors, direct endocytic rate measurements are frequently achieved utilizing labeled receptor ligands.  However, for many classes of membrane proteins, such as transporters, pumps and ion channels, there is no convenient ligand that can be used to measure the endocytic rate.  In the present report, we describe a reversible biotinylation method that we employ to measure the dopamine transporter (DAT) endocytic rate.  This method provides a straightforward approach to measuring internalization rates, and can be easily employed for trafficking studies of most membrane proteins.

Regulated endocytosis governs the cell surface expression levels of the majority of membrane proteins. Here we utilize reducible, membrane impermeant biotinylation reagents to measure the endocytic rate of the dopamine transporter (DAT), a polytopic membrane protein. The method facilitates a straightforward approach to measuring the endocytic rate of most plasma membrane proteins.

Plasma membrane proteins are a large, diverse group of proteins comprised of receptors, ion channels, transporters and pumps.  Activity of these proteins ...

Quantitative Measurement of GLUT4 Translocation to the Plasma Membrane by Flow Cytometry

Glucose is the main source of energy for the body, requiring constant regulation of its blood concentration. Insulin release by the pancreas induces glucose uptake by insulin-sensitive tissues, most notably the brain, skeletal muscle, and adipocytes. Patients suffering from type-2 diabetes and/or obesity often develop insulin resistance and are unable to control their glucose homeostasis. New insights into the mechanisms of insulin resistance may provide new treatment strategies for type-2 diabetes.
The GLUT family of glucose transporters consists of thirteen members distributed on different tissues throughout the body1. Glucose transporter type 4 (GLUT4) is the major transporter that mediates glucose uptake by insulin sensitive tissues, such as the skeletal muscle. Upon binding of insulin to its receptor, vesicles containing GLUT4 translocate from the cytoplasm to the plasma membrane, inducing glucose uptake. Reduced GLUT4 translocation is one of the causes of insulin resistance in type-2 diabetes2,3.
The translocation of GLUT4 from the cytoplasm to the plasma membrane can be visualized by immunocytochemistry, using fluorophore-conjugated GLUT4-specific antibodies.
Here, we describe a technique to quantify total amounts of GLUT4 translocation to the plasma membrane of cells during a chosen duration, using flow cytometry. This protocol is rapid (less than 4 hours, including incubation with insulin) and allows the analysis of as few as 3,000 cells or as many as 1 million cells per condition in a single experiment. It relies on anti-GLUT4 antibodies directed to an external epitope of the transporter that bind to it as soon as it is exposed to the extracellular medium after translocation to the plasma membrane.

This protocol describes a rapid technique to quantify the translocation of GLUT4 from the cytoplasm to the plasma membrane of cells by flow cytometry.

Glucose is the main source of energy for the body, requiring constant regulation of its blood concentration. Insulin release by the pancreas induces ...

Quantification of Proteins Using Peptide Immunoaffinity Enrichment Coupled with Mass Spectrometry

There is a great need for quantitative assays in measuring proteins. Traditional sandwich immunoassays, largely considered the gold standard in quantitation, are associated with a high cost, long lead time, and are fraught with drawbacks (e.g. heterophilic antibodies, autoantibody interference, 'hook-effect').1 An alternative technique is affinity enrichment of peptides coupled with quantitative mass spectrometry, commonly referred to as SISCAPA (Stable Isotope Standards and Capture by Anti-Peptide Antibodies).2 In this technique, affinity enrichment of peptides with stable isotope dilution and detection by selected/multiple reaction monitoring mass spectrometry (SRM/MRM-MS) provides quantitative measurement of peptides as surrogates for their respective proteins. SRM/MRM-MS is well established for accurate quantitation of small molecules 3, 4 and more recently has been adapted to measure the concentrations of proteins in plasma and cell lysates.5-7 To achieve quantitation of proteins, these larger molecules are digested to component peptides using an enzyme such as trypsin. One or more selected peptides whose sequence is unique to the target protein in that species (i.e. "proteotypic" peptides) are then enriched from the sample using anti-peptide antibodies and measured as quantitative stoichiometric surrogates for protein concentration in the sample. Hence, coupled to stable isotope dilution (SID) methods (i.e. a spiked-in stable isotope labeled peptide standard), SRM/MRM can be used to measure concentrations of proteotypic peptides as surrogates for quantification of proteins in complex biological matrices. The assays have several advantages compared to traditional immunoassays. The reagents are relatively less expensive to generate, the specificity for the analyte is excellent, the assays can be highly multiplexed, enrichment can be performed from neat plasma (no depletion required), and the technique is amenable to a wide array of proteins or modifications of interest.8-13 In this video we demonstrate the basic protocol as adapted to a magnetic bead platform.

Stable Isotope Standards and Capture by Anti-Peptide Antibodies (SISCAPA) couples affinity enrichment of peptides with stable isotope dilution mass spectrometry (MRM-MS) to provide quantitative measurement of peptides as surrogates for their respective proteins. Here we describe the protocol using magnetic particles in a partially automated format.

There is a great need for quantitative assays in measuring proteins. Traditional sandwich immunoassays, largely considered the gold standard in ...

Mapping Molecular Diffusion in the Plasma Membrane by Multiple-Target Tracing (MTT)

Our goal is to obtain a comprehensive description of molecular processes occurring at cellular membranes in different biological functions. We aim at characterizing the complex organization and dynamics of the plasma membrane at single-molecule level, by developing analytic tools dedicated to Single-Particle Tracking (SPT) at high density: Multiple-Target Tracing (MTT)1. Single-molecule videomicroscopy, offering millisecond and nanometric resolution1-11, allows a detailed representation of membrane organization12-14 by accurately mapping descriptors such as cell receptors localization, mobility, confinement or interactions.
We revisited SPT, both experimentally and algorithmically. Experimental aspects included optimizing setup and cell labeling, with a particular emphasis on reaching the highest possible labeling density, in order to provide a dynamic snapshot of molecular dynamics as it occurs within the membrane. Algorithmic issues concerned each step used for rebuilding trajectories: peaks detection, estimation and reconnection, addressed by specific tools from image analysis15,16. Implementing deflation after detection allows rescuing peaks initially hidden by neighboring, stronger peaks. Of note, improving detection directly impacts reconnection, by reducing gaps within trajectories. Performances have been evaluated using Monte-Carlo simulations for various labeling density and noise values, which typically represent the two major limitations for parallel measurements at high spatiotemporal resolution.
The nanometric accuracy17 obtained for single molecules, using either successive on/off photoswitching or non-linear optics, can deliver exhaustive observations. This is the basis of nanoscopy methods17 such as STORM18, PALM19,20, RESOLFT21 or STED22,23, which may often require imaging fixed samples. The central task is the detection and estimation of diffraction-limited peaks emanating from single-molecules. Hence, providing adequate assumptions such as handling a constant positional accuracy instead of Brownian motion, MTT is straightforwardly suited for nanoscopic analyses. Furthermore, MTT can fundamentally be used at any scale: not only for molecules, but also for cells or animals, for instance. Hence, MTT is a powerful tracking algorithm that finds applications at molecular and cellular scales.

Mapping Molecular Diffusion in the Plasma Membrane by Multiple-Target Tracing MTT

Multiple-Target Tracing is a homemade algorithm developed for tracking individually labeled molecules within the plasma membrane of living cells. Efficiently detecting, estimating and tracing molecules over time at high-density provide a user-friendly, comprehensive tool to investigate nanoscale membrane dynamics.

Our goal is to obtain a comprehensive description of molecular processes occurring at cellular membranes in different biological functions. We aim at ...

The Cell-based L-Glutathione Protection Assays to Study Endocytosis and Recycling of Plasma Membrane Proteins

Membrane trafficking involves transport of proteins from the plasma membrane to the cell interior (i.e. endocytosis) followed by trafficking to lysosomes for degradation or to the plasma membrane for recycling. The cell based L-glutathione protection assays can be used to study endocytosis and recycling of protein receptors, channels, transporters, and adhesion molecules localized at the cell surface. The endocytic assay requires labeling of cell surface proteins with a cell membrane impermeable biotin containing a disulfide bond and the N-hydroxysuccinimide (NHS) ester at 4 &#186;C -&#160;a temperature at which membrane trafficking does not occur. Endocytosis of biotinylated plasma membrane proteins is induced by incubation at 37 &#186;C. Next, the temperature is decreased again to 4 &#186;C to stop endocytic trafficking and the disulfide bond in biotin covalently attached to proteins that have remained at the plasma membrane is reduced with L-glutathione. At this point, only proteins that were endocytosed remain protected from L-glutathione and thus remain biotinylated. After cell lysis, biotinylated proteins are isolated with streptavidin agarose, eluted from agarose, and the biotinylated protein of interest is detected by western blotting. During the recycling assay, after biotinylation cells are incubated at 37 &#176;C to load endocytic vesicles with biotinylated proteins and the disulfide bond in biotin covalently attached to proteins remaining at the plasma membrane is reduced with L-glutathione at 4 &#186;C as in the endocytic assay. Next, cells are incubated again at 37 &#176;C to allow biotinylated proteins from endocytic vesicles to recycle to the plasma membrane. Cells are then incubated at 4 &#186;C, and the disulfide bond in biotin attached to proteins that recycled to the plasma membranes is reduced with L-glutathione. The biotinylated proteins protected from L-glutathione are those that did not recycle to the plasma membrane.

Membrane trafficking involves transport of proteins from the plasma membrane to the cell interior (i.e. endocytosis) followed by trafficking to lysosomes for degradation or to the plasma membrane for recycling. Methods described in this article are designed to study endocytosis and recycling of plasma membrane proteins.

Membrane trafficking involves transport of proteins from the plasma membrane to the cell interior (i.e. endocytosis) followed by trafficking to lysosomes ...

Ground State Depletion Super-resolution Imaging in Mammalian Cells

Advances in fluorescent microscopy and cell biology are intimately correlated, with the enhanced ability to visualize cellular events often leading to dramatic leaps in our understanding of how cells function. The development and availability of super-resolution microscopy has considerably extended the limits of optical resolution from ~250-20 nm. Biologists are no longer limited to describing molecular interactions in terms of colocalization within a diffraction limited area, rather it is now possible to visualize the dynamic interactions of individual molecules. Here, we outline a protocol for the visualization and quantification of cellular proteins by ground-state depletion microscopy&#160;for fixed cell imaging. We provide examples from two different membrane proteins, an element of the endoplasmic reticulum translocon, sec61&#946;, and a plasma membrane-localized voltage-gated L-type Ca2+ channel (CaV1.2). Discussed are the specific microscope parameters, fixation methods, photo-switching buffer formulation, and pitfalls and challenges of image processing.

This article outlines a protocol for the detection of one or more plasma and/or intracellular membrane proteins using Ground State Depletion (GSD) super-resolution microscopy in mammalian cells. Here, we discuss the benefits and considerations of using such approaches for the visualization and quantification of cellular proteins.

Advances in fluorescent microscopy and cell biology are intimately correlated, with the enhanced ability to visualize cellular events often leading to ...

Determination of Plasma Membrane Partitioning for Peripherally-associated Proteins

This method provides a fast approach for the determination of plasma membrane partitioning of any fluorescently-tagged peripherally-associated protein using the profiles of fluorescence intensity across the plasma membrane. Measured fluorescence profiles are fitted by a model for membrane and cytoplasm fluorescence distribution along a line applied perpendicularly to the cell periphery. This model is constructed from the fluorescence intensity values in reference cells expressing a fluorescently-tagged marker for cytoplasm and with FM 4-64-labeled plasma membrane. The method can be applied to various cell types and organisms; however, only plasma membranes of non-neighboring cells can be evaluated. This fast microscopy-based method is suitable for experiments, where subtle and dynamic changes of plasma membrane-associated markers are expected and need to be quantified, e.g., in the analysis of mutant versions of proteins, inhibitor treatments, and signal transduction observations. The method is implemented in a multi-platform R package that is coupled with an ImageJ macro that serves as a user-friendly interface.

Here, we present a protocol to perform a quantitative analysis of the level of plasma-membrane association for fluorescently-tagged peripherally-associated protein. The method is based on the computational decomposition of membrane and cytoplasmic component of signal observed in cells labeled with plasma membrane fluorescent marker.

This method provides a fast approach for the determination of plasma membrane partitioning of any fluorescently-tagged peripherally-associated protein ...

Characterization of MLKL-mediated Plasma Membrane Rupture in Necroptosis

Necroptosis is a programmed cell death pathway triggered by activation of receptor interacting protein kinase 3 (RIPK3), which phosphorylates and activates the mixed lineage kinase-like domain pseudokinase, MLKL, to rupture or permeabilize the plasma membrane. Necroptosis is an inflammatory pathway associated with multiple pathologies including autoimmunity, infectious and cardiovascular diseases, stroke, neurodegeneration, and cancer. Here, we describe protocols that can be used to characterize MLKL as the executioner of plasma membrane rupture in necroptosis. We visualize the process of necroptosis in cells using live-cell imaging with conventional and confocal fluorescence&#160;microscopy, and in fixed cells using electron microscopy, which together revealed the redistribution of MLKL from the cytosol to the plasma membrane prior to induction of large holes in the plasma membrane. We present in vitro nuclear magnetic resonance (NMR) analysis using lipids to identify putative modulators of MLKL-mediated necroptosis. Based on this method, we identified quantitative lipid-binding preferences and phosphatidyl-inositol phosphates (PIPs) as critical binders of MLKL that are required for plasma membrane targeting and permeabilization in necroptosis.

We report methods for characterization of MLKL-mediated plasma membrane rupture in necroptosis including conventional and confocal live-cell microscopy imaging, scanning electron microscopy, and NMR-based lipid binding.

Necroptosis is a programmed cell death pathway triggered by activation of receptor interacting protein kinase 3 (RIPK3), which phosphorylates and ...

Isolating and Imaging Live, Intact Pacemaker Regions of Mouse Renal Pelvis by Vibratome Sectioning

The renal pelvis (RP) is a funnel-shaped, smooth muscle structure that facilitates normal urine transport from the kidney to the ureter by regular, propulsive contractions. Regular RP contractions rely on pacemaker activity, which originates from the most proximal region of the RP at the pelvis-kidney junction (PKJ). Due to the difficulty in accessing and preserving intact preparations of the PKJ, most investigations on RP pacemaking have focused on single-cell electrophysiology and Ca2+ imaging experiments. Although important revelations on RP pacemaking have emerged from such work, these experiments have several intrinsic limitations, including the inability to accurately determine cellular identity in mixed suspensions and the lack of in situ imaging of RP pacemaker activity. These factors have resulted in a limited understanding of the mechanisms that underlie normal rhythmic RP contractions. In this paper, a protocol is described to prepare intact segments of mouse PKJ using a vibratome sectioning technique. By combining this approach with mice expressing cell-specific reporters and genetically encoded Ca2+ indicators, investigators may be able to more accurately study the specific cell types and mechanisms responsible for peristaltic RP contractions that are vital for normal urine transport.

The goal of this protocol is to isolate intact pacemaker regions of the mouse renal pelvis using vibratome sectioning. These sections can then be used for in situ Ca2+ imaging to elucidate Ca2+ transient properties of pacemaker cells and other interstitial cells in vibratome slices.

The renal pelvis (RP) is a funnel-shaped, smooth muscle structure that facilitates normal urine transport from the kidney to the ureter by regular, ...
