Name: bioorthogonal chemical imaging of cell metabolism regulated by aromatic amino acids
Uploaded: 2023-05-12T12:50:00
Description: Watch this Scientific Journal Video about Bioorthogonal Chemical Imaging of Cell Metabolism Regulated by Aromatic Amino Acids at JoVE.com

We thank Dr. Yajuan Li and Anthony Fung for their technical support, and the Fraley lab for the cell line. We acknowledge the start-up funds from UCSD, NIH U54CA132378, NIH 5R01NS111039, NIH R21NS125395, NIHU54DK134301, NIHU54 HL165443, and Hellman Fellow Award.

1. Media preparation
<ol>
	<li>Prepare 10 mL of control and excess AAAs in Dulbecco&#39;s modified Eagle medium (DMEM) containing 50% D2O.
	<ol>
		<li>For the control media, measure and mix 10 mg of DMEM powder with 4.7 mL of double distilled water (ddH2O) in a 15 mL conical tube. The DMEM powder contains all the amino acids at standard concentrations. Thoroughly vortex and invert the tube to ensure the solution is well mixed. Add 4.7 mL of D2O, 0.5 mL of fetal bovine s...

<ol>
	<li>Wu, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Functional+amino+acids+in+nutrition+and+health.">Functional amino acids in nutrition and health.</a> Amino Acids. 45 (3), 407-411 (2013).</li><li>Wei, Z., Liu, X., Cheng, C., Yu, W., Yi, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Metabolism+of+amino+acids+in+cancer.">Metabolism of amino acids in cancer.</a> Frontiers in Cell and Developmental Biology. 8, 603837 (2020).</li><li>Parthasarathy, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+three-ring+circus:+Metabolism+of+the+three+proteogenic+aromatic+amino+acids+and+their+role+in+the+health+of+plants+and+animals.">A three-ring circus: Metabolism of the three proteogenic aromatic amino acids and their role in the health of plants and animals.</a> Frontiers in Molecular Biosciences. 5, 29 (2018).</li><li>Wang, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=l-tryptophan+activates+mammalian+target+of+rapamycin+and+enhances+expression+of+tight+junction+proteins+in+intestinal+porcine+epithelial+cells.">l-tryptophan activates mammalian target of rapamycin and enhances expression of tight junction proteins in intestinal porcine epithelial cells.</a> The Journal of Nutrition. 145 (6), 1156-1162 (2015).</li><li>Saxton, R. A., Sabatini, D. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=mTOR+signaling+in+growth,+metabolism,+and+disease.">mTOR signaling in growth, metabolism, and disease.</a> Cell. 168 (6), 960-976 (2017).</li><li>Mossmann, D., Park, S., Hall, M. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=mTOR+signalling+and+cellular+metabolism+are+mutual+determinants+in+cancer.">mTOR signalling and cellular metabolism are mutual determinants in cancer.</a> Nature Reviews. Cancer. 18 (12), 744-757 (2018).</li><li>Kimura, T., Watanabe, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tryptophan+protects+hepatocytes+against+reactive+oxygen+species-dependent+cell+death+via+multiple+pathways+including+Nrf2-dependent+gene+induction.">Tryptophan protects hepatocytes against reactive oxygen species-dependent cell death via multiple pathways including Nrf2-dependent gene induction.</a> Amino Acids. 48 (5), 1263-1274 (2016).</li><li>Ma, Q., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dietary+supplementation+with+aromatic+amino+acids+decreased+triglycerides+and+alleviated+hepatic+steatosis+by+stimulating+bile+acid+synthesis+in+mice.">Dietary supplementation with aromatic amino acids decreased triglycerides and alleviated hepatic steatosis by stimulating bile acid synthesis in mice.</a> Food and Function. 12 (1), 267-277 (2021).</li><li>Cheng, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Treatment+implications+of+natural+compounds+targeting+lipid+metabolism+in+nonalcoholic+fatty+liver+disease,+obesity+and+cancer.">Treatment implications of natural compounds targeting lipid metabolism in nonalcoholic fatty liver disease, obesity and cancer.</a> International Journal of Biological Sciences. 15 (8), 1654-1663 (2019).</li><li>Lubes, G., Goodarzi, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=GC-MS+based+metabolomics+used+for+the+identification+of+cancer+volatile+organic+compounds+as+biomarkers.">GC-MS based metabolomics used for the identification of cancer volatile organic compounds as biomarkers.</a> Journal of Pharmaceutical and Biomedical Analysis. 147, 313-322 (2018).</li><li>Di Gialleonardo, V., Wilson, D. M., Keshari, K. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+potential+of+metabolic+imaging.">The potential of metabolic imaging.</a> Seminars in Nuclear Medicine. 46 (1), 28-39 (2016).</li><li>Bowman, A. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaluation+of+lipid+coverage+and+high+spatial+resolution+MALDI-imaging+capabilities+of+oversampling+combined+with+laser+post-ionisation.">Evaluation of lipid coverage and high spatial resolution MALDI-imaging capabilities of oversampling combined with laser post-ionisation.</a> Analytical and Bioanalytical Chemistry. 412 (10), 2277-2289 (2020).</li><li>Murphy, R. C., Hankin, J. A., Barkley, R. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+of+lipid+species+by+MALDI+mass+spectrometry.">Imaging of lipid species by MALDI mass spectrometry.</a> Journal of Lipid Research. 50, 317-322 (2009).</li><li>Pirman, D. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Changes+in+cancer+cell+metabolism+revealed+by+direct+sample+analysis+with+MALDI+mass+spectrometry.">Changes in cancer cell metabolism revealed by direct sample analysis with MALDI mass spectrometry.</a> PLoS One. 8 (4), e61379 (2013).</li><li>Li, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single-cell+lipidomics+with+high+structural+specificity+by+mass+spectrometry.">Single-cell lipidomics with high structural specificity by mass spectrometry.</a> Nature Communications. 12 (1), 2869 (2021).</li><li>Miyagi, M., Kasumov, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Monitoring+the+synthesis+of+biomolecules+using+mass+spectrometry.">Monitoring the synthesis of biomolecules using mass spectrometry.</a> Philosophical Transactions. Series A, Mathematical, Physical and Engineering Sciences. 374 (2079), 20150378 (2016).</li><li>Wang, T., Shogomori, H., Hara, M., Yamada, T., Kobayashi, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nanomechanical+recognition+of+sphingomyelin-rich+membrane+domains+by+atomic+force+microscopy.">Nanomechanical recognition of sphingomyelin-rich membrane domains by atomic force microscopy.</a> Biochemistry. 51 (1), 74-82 (2012).</li><li>Fung, A. A., Shi, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mammalian+cell+and+tissue+imaging+using+Raman+and+coherent+Raman+microscopy.">Mammalian cell and tissue imaging using Raman and coherent Raman microscopy.</a> Wiley Interdisciplinary Reviews. Systems Biology and Medicine. 12 (6), e1501 (2020).</li><li>Shi, L., Fung, A. A., Zhou, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Advances+in+stimulated+Raman+scattering+imaging+for+tissues+and+animals.">Advances in stimulated Raman scattering imaging for tissues and animals.</a> Quantitative Imaging in Medicine and Surgery. 11 (3), 1078-1101 (2021).</li><li>Yamakoshi, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+of+EdU,+an+alkyne-tagged+cell+proliferation+probe,+by+Raman+microscopy.">Imaging of EdU, an alkyne-tagged cell proliferation probe, by Raman microscopy.</a> Journal of the American Chemical Society. 133 (16), 6102-6105 (2011).</li><li>Shi, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+imaging+of+metabolic+dynamics+in+animals.">Optical imaging of metabolic dynamics in animals.</a> Nature Communications. 9 (1), 2995 (2018).</li><li>Bagheri, P., Hoang, K., Fung, A. A., Hussain, S., Shi, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Visualizing+cancer+cell+metabolic+dynamics+regulated+with+aromatic+amino+acids+using+DO-SRS+and+2PEF+microscopy.">Visualizing cancer cell metabolic dynamics regulated with aromatic amino acids using DO-SRS and 2PEF microscopy.</a> Frontiers in Molecular Biosciences. 8, 779702 (2021).</li><li>Li, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Direct+imaging+of+lipid+metabolic+changes+in+drosophila+ovary+during+aging+using+DO-SRS+microscopy.">Direct imaging of lipid metabolic changes in drosophila ovary during aging using DO-SRS microscopy.</a> Frontiers in Aging. 2, 819903 (2022).</li><li>Li, Y., Zhang, W., Fung, A. A., Shi, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DO-SRS+imaging+of+metabolic+dynamics+in+aging+Drosophila.">DO-SRS imaging of metabolic dynamics in aging Drosophila.</a> Analyst. 146 (24), 7510-7519 (2021).</li><li>Zhang, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Spectral+tracing+of+deuterium+for+imaging+glucose+metabolism.">Spectral tracing of deuterium for imaging glucose metabolism.</a> Nature Biomedical Engineering. 3 (5), 402-413 (2019).</li><li>Fung, A. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+sub-cellular+methionine+and+insulin+interplay+in+triple+negative+breast+cancer+lipid+droplet+metabolism.">Imaging sub-cellular methionine and insulin interplay in triple negative breast cancer lipid droplet metabolism.</a> Frontiers in Oncology. 12, 858017 (2022).</li><li>Li, Y., Zhang, W., Fung, A. A., Shi, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=DO-SRS+imaging+of+diet+regulated+metabolic+activities+in+Drosophila+during+aging+processes.">DO-SRS imaging of diet regulated metabolic activities in Drosophila during aging processes.</a> Aging Cell. 21 (4), e13586 (2022).</li><li>Shi, L., Wei, M., Min, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly-multiplexed+tissue+imaging+with+raman+dyes.">Highly-multiplexed tissue imaging with raman dyes.</a> Journal of Visualized Experiments. (182), e63547 (2022).</li><li>Rysman, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=De+novo+lipogenesis+protects+cancer+cells+from+free+radicals+and+chemotherapeutics+by+promoting+membrane+lipid+saturation.">De novo lipogenesis protects cancer cells from free radicals and chemotherapeutics by promoting membrane lipid saturation.</a> Cancer Research. 70 (20), 8117-8126 (2010).</li><li>Lisec, J., Jaeger, C., Rashid, R., Munir, R., Zaidi, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cancer+cell+lipid+class+homeostasis+is+altered+under+nutrient-deprivation+but+stable+under+hypoxia.">Cancer cell lipid class homeostasis is altered under nutrient-deprivation but stable under hypoxia.</a> BMC Cancer. 19 (1), 501 (2019).</li><li>Thiam, A. R., Dugail, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+droplet-membrane+contact+sites+-+from+protein+binding+to+function.">Lipid droplet-membrane contact sites - from protein binding to function.</a> Journal of Cell Science. 132 (12), (2019).</li><li>Schott, M. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+droplet+size+directs+lipolysis+and+lipophagy+catabolism+in+hepatocytes.">Lipid droplet size directs lipolysis and lipophagy catabolism in hepatocytes.</a> The Journal of Cell Biology. 218 (10), 3320-3335 (2019).</li><li>Hoang, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Subcellular+resolution+DO-SRS+and+2PEF+imaging+of+metabolic+dynamics+regulated+by+L-methionine+in+amyotrophic+lateral+sclerosis.">Subcellular resolution DO-SRS and 2PEF imaging of metabolic dynamics regulated by L-methionine in amyotrophic lateral sclerosis.</a> Optical Biopsy XXI: Toward Real-Time Spectroscopic Imaging and Diagnosis. SPIE. 1237303, 6-13 (2023).</li><li>Jang, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Super-resolution+stimulated+Raman+scattering+microscopy+with+A-PoD.">Super-resolution stimulated Raman scattering microscopy with A-PoD.</a> bioRxiv. , (2022).</li><li>Li, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+metabolic+imaging+uncovers+sex-+and+diet-dependent+lipid+changes+in+aging+drosophila+brain.">Optical metabolic imaging uncovers sex- and diet-dependent lipid changes in aging drosophila brain.</a> bioRxiv. , (2022).</li><li>Zhang, W., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multi-molecular+hyperspectral+PRM-SRS+imaging.">Multi-molecular hyperspectral PRM-SRS imaging.</a> bioRxiv. , (2022).</li><li>Wei, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Volumetric+chemical+imaging+by+clearing-enhanced+stimulated+Raman+scattering+microscopy.">Volumetric chemical imaging by clearing-enhanced stimulated Raman scattering microscopy.</a> Proceedings of the National Academy of Sciences. 116 (14), 6608-6617 (2019).</li><li>Chang, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Non-invasive+monitoring+of+cell+metabolism+and+lipid+production+in+3D+engineered+human+adipose+tissues+using+label-free+multiphoton+microscopy.">Non-invasive monitoring of cell metabolism and lipid production in 3D engineered human adipose tissues using label-free multiphoton microscopy.</a> Biomaterials. 34 (34), 8607-8616 (2013).</li><li>Leica TCS SP8 CARS CARS Microscope - Label Free Imaging. Leica Microsystems Available from: <a target="_blank" href="https://www.leica-microsystems.com/products/confocal-microscopes/p/leica-tcs-sp8-cars/downloads/">https://www.leica-microsystems.com/products/confocal-microscopes/p/leica-tcs-sp8-cars/downloads/</a> (2023)</li></ol>

DO-SRS and 2PEF imaging have been applied to investigate metabolic dynamics in various ex vivo models, including Drosophila and human tissues21,22,23,24,26,27,33. The imaging modality used in this study integrates DO-SRS and 2PEF microscopy, which can outpace other molecule-specific...

Being essential aromatic amino acids (AAAs), phenylalanine (Phe) and tryptophan (Tryp) can be absorbed by the human body to synthesize new molecules for sustaining normal biological functions1. Phe is needed for the synthesis of proteins, melanin, and tyrosine, while Tryp is required for the synthesis of melatonin, serotonin, and niacin2,3. However, excess consumption of these AAAs can upregulate the mammalian target of the rapamycin (mTOR) pathway, inhibit AMP-activated protein kinase, and interfere with the mitochondrial metabolism, collectively altering macromolecule biosynthesis and leading to the production of malignant precursors, such as reactive oxygen species (ROS) in healthy cells4,5,6. Direct visualization of altered metabolic dynamics under excess AAA regulation is essential to understand AAAs&#39; roles in promoting cancer development and the growth of healthy cells7,8,9.
Traditional AAA studies rely on gas chromatography (GC)10. Other methods, such as magnetic resonance imaging (MRI), have limited spatial resolutions, making it hard to perform cellular and sub-cellular analysis of biological samples11. Recently, matrix-assisted laser desorption/ionization (MALDI) has been developed to elucidate the role of AAAs in lipid and protein syntheses in cancer proliferation with noninvasive biomarkers12,13,14. However, this technique still suffers from shallow imaging depths, poor spatial resolution, and extensive sample preparation. At the cellular level, nontoxic stable isotopes, such as nitrogen-15 and carbon-13, can be traced with multi-isotope imaging and nanoscale secondary ion mass spectrometry to understand their incorporation into macromolecules. However, these methods are destructive to living biological samples15,16. Atomic force microscopy (AFM) is another powerful technique that can visualize metabolic dynamics17. The slow rate of scanning during AFM imaging, on the other hand, may cause image distortion of the result from thermal drift.
We developed a noninvasive biorthogonal imaging modality by coupling deuterium-oxide (D2O) probed stimulated Raman scattering (DO-SRS) microscopy and label-free two-photon excitation fluorescence microscopy (2PEF). This modality achieves a high spatial resolution and chemical specificity when imaging biological samples18,19,20,21,22,23,24. This protocol introduces the applications of DO-SRS and 2PEF to examine the metabolic dynamics of lipids, protein, and redox ratio changes during cancer progressions. With D2O being a stable isotope form of water, cellular biomolecules can be labeled with deuterium (D) due to its quick compensation with total body water in cells, forming carbon-deuterium (C-D) bonds through enzymatic exchange21. The C-D bonds in newly synthesized macromolecules, including lipids, proteins, DNA/RNA, and carbohydrates, can be detected in the cell silent region of the Raman spectrum20,21,22,25,26,27. With two synchronized laser pulses, C-D bonds of newly synthesized lipids and proteins can be displayed on single cells via hyperspectral imaging (HSI) without extracting or labeling them with cytotoxic agents. In addition, SRS microscopy has the capability to construct three-dimensional (3D) models of selected regions of interest in biological samples by capturing and combining a set of cross-sectional images22,26. With hyperspectral and 3D volumetric imaging, DO-SRS can obtain spatial distributions of newly synthesized macromolecules in single cells, along with the type of organelles that facilitate the process of promoting cancer growth under AAA regulation22. Furthermore, using 2PEF, we can obtain autofluorescence signals of Flavin and nicotinamide adenine dinucleotide (NADH) with high resolution, deep penetration depth, and low-level damage in biological samples21,23,24. Flavin and NADH autofluorescence signals have been used to characterize redox homeostasis and lipid peroxidation in cancer cells22,26. As such, not only does the coupling of DO-SRS and 2PEF provide subcellular analysis of AAA-regulated metabolic dynamics in cancer cells with high spatial distribution, chemical specificity information, and minimal sample preparation, but the method also reduces the need to extract or label endogenous molecules with toxic reagents. In this protocol, we first present the procedures of D2O and amino acid preparation, as well as cancer cell culture. Then, we show the protocols of DO-SRS imaging and 2PEF imaging. Finally, we present the representative results of SRS and 2PEF imaging, which demonstrate AAA-regulated metabolic changes of lipids and protein, and redox ratio changes in cancer cells. A detailed illustration of the process is highlighted in Figure 1.

<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>10 mL Serological Pipettes&#160;</td>
			<td>Avantor (by VWR)</td>
			<td>75816-100</td>
			<td>https://us.vwr.com/store/product?keyword=75816-100</td>
		</tr>
		<tr>
			<td>15 mL Conical Centrifuge Tube</td>
			<td>VWR</td>
			<td>89039-664</td>
			<td>https://mms.mckesson.com/product/1001859/VWR-International-89039-664</td>
		</tr>
		<tr>
			<td>16% Formaldehyde, Methanol-free</td>
			<td>ThermoFisher Scientific</td>
			<td>28906</td>
			<td>https://www.thermofisher.com/order/catalog/product/28906</td>
		</tr>
		<tr>
			<td>24-well plate</td>
			<td>Fisherbrand</td>
			<td>FB0112929</td>
			<td>https://www.fishersci.com/shop/products/24-well-tc-multidish-100-cs/FB012929#?keyword=FB012929</td>
		</tr>
		<tr>
			<td>25 mm Syringe Filter, 2 &#956;m PES</td>
			<td>Foxx Life Sciences</td>
			<td>381-2216-OEM</td>
			<td>https://www.foxxlifesciences.com/collections/pes-syringe-filters/products/381-2216-oem?variant=16274336003</td>
		</tr>
		<tr>
			<td>460 nm Filter Cube</td>
			<td>Olympus</td>
			<td></td>
			<td>OCT-ET460/50M32</td>
		</tr>
		<tr>
			<td>AC Adapters of the Power Supply for LD OBIS 6 Laser Remote</td>
			<td>Olympus</td>
			<td></td>
			<td>Supply power to the laser</td>
		</tr>
		<tr>
			<td>Band-pass Filter</td>
			<td>KR Electronics</td>
			<td>KR2724</td>
			<td>8 MHz</td>
		</tr>
		<tr>
			<td>BNC 50 Ohm Terminator&#160;</td>
			<td>Mini Circuits</td>
			<td>STRM-50</td>
			<td></td>
		</tr>
		<tr>
			<td>BNC Cable</td>
			<td>Thorlabs</td>
			<td>2249-C</td>
			<td>Coaxial Cable, BNC Male/Male</td>
		</tr>
		<tr>
			<td>Broadband Dielectric Mirror</td>
			<td>Thorlabs</td>
			<td>BB1-E03</td>
			<td>750 - 1100 nm</td>
		</tr>
		<tr>
			<td>Centrifuge</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Condenser</td>
			<td>Olympus</td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Cover Glass</td>
			<td>Corning</td>
			<td>2850-25</td>
			<td>https://ecatalog.corning.com/life-sciences/b2b/NL/en/Glassware/Cover-Glass/Corning%C2%AE-Square-%231%C2%BD-Cover-Glass/p/2850-25</td>
		</tr>
		<tr>
			<td>DC power supply</td>
			<td>TopWard</td>
			<td>6302D</td>
			<td></td>
		</tr>
		<tr>
			<td>Dichroic Mount</td>
			<td>Thorlabs</td>
			<td>KM100CL</td>
			<td></td>
		</tr>
		<tr>
			<td>Dimethyl Sulfoxide Cell Culture Reagent</td>
			<td>mpbio&#160;</td>
			<td>196055</td>
			<td>https://www.mpbio.com/0219605525-dimethyl-sulfoxide-cf</td>
		</tr>
		<tr>
			<td>Dulbecco&#39;s Modified Eagle&#8217;s Medium without Methionine, Threonine, and Sodium Pyruvate</td>
			<td>MilliporeSigma</td>
			<td>38210000</td>
			<td>https://www.usbio.net/media/D9800-22/dulbeccorsquos-mem-dmem-wsodium-bicarbonate-wo-methionine-threonine-sodium-pyruvate-powder
			With Sodium Bicarbonate and without Methionine, Threonine, and Sodium Pyruvate&#160;</td>
		</tr>
		<tr>
			<td>Dulbecco&#8217;s Modified Eagle&#8217;s Medium</td>
			<td>Corning</td>
			<td>MT10027CV</td>
			<td>https://www.fishersci.com/shop/products/dmem-dulbecco-s-modified-eagle-s-medium-4/MT10027CV#:~:text=Dulbecco&#39;s%20Modified%20Eagle&#39;s%20Medium%20</td>
		</tr>
		<tr>
			<td>FIJI ImageJ</td>
			<td>ImageJ</td>
			<td>Version 1.53t 24 August 2022</td>
			<td>https://imagej.net/software/fiji/downloads</td>
		</tr>
		<tr>
			<td>Heavy Water (Deuterium Oxide)</td>
			<td>Cambridge Isotope Laboratories, Inc.</td>
			<td>7732-18-5</td>
			<td>https://shop.isotope.com/productdetails.aspx?itemno=DLM-4-1L</td>
		</tr>
		<tr>
			<td>Hela Cells</td>
			<td>ATCC</td>
			<td>CCL-2</td>
			<td>https://www.atcc.org/products/ccl-2</td>
		</tr>
		<tr>
			<td>Hemocymeter</td>
			<td>MilliporeSigma</td>
			<td>Z359629-1EA</td>
			<td>https://www.sigmaaldrich.com/US/en/product/sigma/z359629?gclid=Cj0KCQiA37KbBhDgARIsAI
			zce15A5FIy0WS7I6ec2KVk
			QPXVMEqlAnYis_bKB6P6lr
			SIZ-wAXOyAELIaAhhEEAL
			w_wcB&#38;gclsrc=aw.ds</td>
		</tr>
		<tr>
			<td>High O.D. Bandpass Filter</td>
			<td>Chroma Technology</td>
			<td>ET890/220m</td>
			<td>Filter the Stokes beam and transmit the pump beam</td>
		</tr>
		<tr>
			<td>HyClone Fetal Bovine Serum (FBS)</td>
			<td>Cytiva&#160;</td>
			<td>SH300880340</td>
			<td>https://www.fishersci.com/shop/products/hyclone-fetal-bovine-serum-u-s-standard-4/SH300880340</td>
		</tr>
		<tr>
			<td>HyClone Trypsin 0.25% (1x) Solution</td>
			<td>Cytiva</td>
			<td>SH30042.02</td>
			<td>https://www.cytivalifesciences.com/en/us/shop/cell-culture-and-fermentation/reagents-and-supplements/cell-disassociation-reagents/hyclone-trypsin-protease-p-00445</td>
		</tr>
		<tr>
			<td>Integrated SRS Laser System</td>
			<td>Applied Physics &#38; Electronics, Inc.</td>
			<td>picoEMERALD</td>
			<td>picoEMERALD provides an output pulse at 1031 nm with 6-ps pulse width and 80-MHz repetition rate, which serves as the Stokes beam.&#160; The frequency doubled beam at 532 nm is used to synchronously seed a picosecond optical parametric oscillator (OPO) to produce a mode-locked pulse train with five~6 ps pulse width (the idler beam of the OPO is blocked with an,interferometric filter). The output wavelength of the OPO is tunable from 720&#8211;950 nm, which serves as the pump beam. The intensity of the 1031 nm Stokes beam is modulated sinusoidally by a built-in EOM at 8 MHz with a modulation depth of more than 90%. The pump beam is spatially overlapped with the Stokes beam by using a dichroic mirror inside picoEMERALD. The temporal overlap between pump and Stokes pulses are achieved with a built-in delay stage and optimized by the SRS signal of pure D2O at the microscope.</td>
		</tr>
		<tr>
			<td>Inverted Laser-scanning Microscope</td>
			<td>Olympus</td>
			<td>FV1200MPE</td>
			<td></td>
		</tr>
		<tr>
			<td>IX3-CBH Control box</td>
			<td>Olympus</td>
			<td></td>
			<td>Control the laser-scanning microscope</td>
		</tr>
		<tr>
			<td>Kinematic Mirror Mount</td>
			<td>Thorlabs</td>
			<td>POLARIS-K1-2AH</td>
			<td>2 Low-Profile Hex Adjusters</td>
		</tr>
		<tr>
			<td>L-Phenalynine</td>
			<td>Sigma</td>
			<td>P5482-25G</td>
			<td>https://www.sigmaaldrich.com/US/en/product/sigma/p5482</td>
		</tr>
		<tr>
			<td>L-Tryptophan</td>
			<td>Sigma</td>
			<td>T8941-25G</td>
			<td>https://www.sigmaaldrich.com/US/en/product/sigma/t8941</td>
		</tr>
		<tr>
			<td>LabSpec 6</td>
			<td>Horiba XploRA</td>
			<td>N/A</td>
			<td>https://www.horiba.com/gbr/scientific/products/detail/action/show/Product/labspec-6-spectroscopy-suite-software-1843/</td>
		</tr>
		<tr>
			<td>Lock-In Amplifier</td>
			<td>Zurich Instruments</td>
			<td>N/A</td>
			<td>https://www.zhinst.com/americas/en/products/shfli-lock-in-amplifier</td>
		</tr>
		<tr>
			<td>Long-pass Dichroic Beam Splitter</td>
			<td>Semrock</td>
			<td>Di02-R980-25x36</td>
			<td>980 nm laser BrightLine single-edge laser-flat dichroic beamsplitter</td>
		</tr>
		<tr>
			<td>MATLAB</td>
			<td>MathWorks</td>
			<td>Version: R2022b</td>
			<td>https://www.mathworks.com/products/new_products/latest_features.html</td>
		</tr>
		<tr>
			<td>Microscope Slides</td>
			<td>Fisherbrand</td>
			<td>12-550-003</td>
			<td>https://www.fishersci.com/shop/products/fisherbrand-selectfrost-microscope-slides-9/12550003#?keyword=12-550-003</td>
		</tr>
		<tr>
			<td>Microscopy Imaging Software</td>
			<td>Olympus</td>
			<td>FluoView</td>
			<td></td>
		</tr>
		<tr>
			<td>MPLN 100x, Olympus</td>
			<td>Olympus</td>
			<td>MPLAPON</td>
			<td>https://www.olympus-ims.com/en/microscope/mplapon/#!cms[focus]=cmsContent11364</td>
		</tr>
		<tr>
			<td>MPLN 50x, Olympus</td>
			<td>Olympus</td>
			<td>MPLAPON&#160;</td>
			<td>https://www.olympus-ims.com/en/microscope/mplapon/#!cms[focus]=cmsContent11363</td>
		</tr>
		<tr>
			<td>NA Oil Condenser</td>
			<td>Olympus&#160;</td>
			<td>6-U130</td>
			<td>https://www.hitechinstruments.com/Product-Details/olympus-achromatic-aplanatic-high-na-condneser</td>
		</tr>
		<tr>
			<td>Nail Polish</td>
			<td>Wet n Wild</td>
			<td>B01EO2G5O4</td>
			<td>https://www.amazon.com/dp/B01EO2G5O4/ref=cm_sw_r_api_i_E609VVDWW
			HHQP38FXXDC_0</td>
		</tr>
		<tr>
			<td>Origin</td>
			<td>OriginLab</td>
			<td>Origin 2022b (9.95)</td>
			<td>https://www.originlab.com/index.aspx?go=PRODUCTS/Origin</td>
		</tr>
		<tr>
			<td>Parafilm</td>
			<td>Fisher Scientific</td>
			<td>S37440</td>
			<td>https://www.fishersci.com/shop/products/parafilm-m-wrapping-film-3/p-2379782</td>
		</tr>
		<tr>
			<td>PBS 1x (Dulbecco&#39;s Phosphate Buffered Saline)</td>
			<td>Thermofischer - Gibco</td>
			<td>14040117</td>
			<td>https://www.thermofisher.com/order/catalog/product/14040117?SID=srch-hj-14040117</td>
		</tr>
		<tr>
			<td>Penicillin/Streptomycin</td>
			<td>Thermofischer - Gibco</td>
			<td>15140122</td>
			<td>https://www.thermofisher.com/order/catalog/product/15140122</td>
		</tr>
		<tr>
			<td>Periscope Assembly</td>
			<td>Thorlabs</td>
			<td>RS99</td>
			<td>Includes the top and bottom units, &#216;1&#34; post, and clamping fork.</td>
		</tr>
		<tr>
			<td>picoEmerald System</td>
			<td>A.P.E</td>
			<td>N/A</td>
			<td>https://www.ape-berlin.de/en/cars-srs/</td>
		</tr>
		<tr>
			<td>Shielded Box with BNC Connectors</td>
			<td>Pomona Electronics</td>
			<td>2902</td>
			<td>Aluminum Box with Cover, BNC Female/Female</td>
		</tr>
		<tr>
			<td>Si Photodiode Detector</td>
			<td>Home Built</td>
			<td>N/A</td>
			<td>DYI series</td>
		</tr>
		<tr>
			<td>Silicon Wafer</td>
			<td></td>
			<td></td>
			<td></td>
		</tr>
		<tr>
			<td>Spacers</td>
			<td>Grace Bio-Labs</td>
			<td>654008</td>
			<td>https://gracebio.com/product/secureseal-imaging-spacers-654008/</td>
		</tr>
		<tr>
			<td>Spontaneous Raman spectroscopy</td>
			<td>Horiba XploRA</td>
			<td>N/A</td>
			<td>https://www.horiba.com/int/products/detail/action/show/Product/xploratm-plus-1528/</td>
		</tr>
		<tr>
			<td>Stimulated Raman Scattering Microscopy</td>
			<td>Home Built</td>
			<td>N/A</td>
			<td></td>
		</tr>
		<tr>
			<td>Touch&#160; Panel Controller</td>
			<td>Olympus</td>
			<td></td>
			<td>Control the X-Y direction of the laser-scanning microscope</td>
		</tr>
		<tr>
			<td>Trypan Blue 0.4% (0.85% NaCl)&#160;</td>
			<td>Lonza</td>
			<td>17-942E</td>
			<td>https://bioscience.lonza.com/lonza_bs/US/en/Culture-Media-and-Reagents/p/000000000000181876/Trypan-Blue%2C-0-4%25-Solution&#34;</td>
		</tr>
		<tr>
			<td>Tweezers</td>
			<td>Kaverme - Amazon</td>
			<td>B07RNVXXV1</td>
			<td>https://www.amazon.com/Precision-Anti-Static-Electronics-Laboratory-Jewelry-Making/dp/B07RNVXXV1&#34;</td>
		</tr>
		<tr>
			<td>Two Photon Excitation Fluorescence Microscopy</td>
			<td>Home Built</td>
			<td>N/A</td>
			<td></td>
		</tr>
		<tr>
			<td>Weighing Paper&#160;</td>
			<td>VWR</td>
			<td>12578-165</td>
			<td>https://us.vwr.com/store/product/4597617/vwr-weighing-paper</td>
		</tr>
		<tr>
			<td>Zurich LabOneQ Software</td>
			<td>Zurich Instruments</td>
			<td></td>
			<td>Control the Zurich lock-in amplifier</td>
		</tr>
	</tbody>
</table>

bioorthogonal chemical imaging of cell metabolism regulated by aromatic amino acids

Essential aromatic amino acids (AAAs) are building blocks for synthesizing new biomasses in cells and sustaining normal biological functions. For example, an abundant supply of AAAs is important for cancer cells to maintain their rapid growth and division. With this, there is a rising demand for a highly specific, noninvasive imaging approach with minimal sample preparation to directly visualize how cells harness AAAs for their metabolism in situ. Here, we develop an optical imaging platform that combines deuterium oxide (D2O) probing with stimulated Raman scattering (DO-SRS) and integrates DO-SRS with two-photon excitation fluorescence (2PEF) into a single microscope to directly visualize the metabolic activities of HeLa cells under AAA regulation. Collectively, the DO-SRS platform provides high spatial resolution and specificity of newly synthesized proteins and lipids in single HeLa cell units. In addition, the 2PEF modality can detect autofluorescence signals of nicotinamide adenine dinucleotide (NADH) and Flavin in a label-free manner. The imaging system described here is compatible with both in vitro and in vivo models, which is flexible for various experiments. The general workflow of this protocol includes cell culture, culture media preparation, cell synchronization, cell fixation, and sample imaging with DO-SRS and 2PEF modalities.

The addition of excess AAAs at 15x concentrations to the 50% D2O-containing cell culture media produced distinct C-D Raman bands of newly synthesized lipids and proteins in HeLa cells (Figure 2B). Previous experiments were performed with different concentration levels, such as 2x and 5x, and although the data is not presented, the 15x concentration produced the most distinct C-D Raman bands of newly synthesized lipids and proteins. Specifically, by investigating lipid droplets (LD...

Watch this Scientific Journal Video about Bioorthogonal Chemical Imaging of Cell Metabolism Regulated by Aromatic Amino Acids at JoVE.com

Bioorthogonal Chemical Imaging of Cell Metabolism Regulated by Aromatic Amino Acids

We present a protocol to directly visualize metabolic activities in cells regulated by amino acids using deuterium-oxide (heavy water D2O) probed stimulated Raman scattering (DO-SRS) microscopy, which is integrated with two-photon excitation fluorescence microscopy (2PEF).

Essential aromatic amino acids (AAAs) are building blocks for synthesizing new biomasses in cells and sustaining normal biological functions. For example, ...

We showcase a new imaging technique with label-free capability, high chemical specificity, and subcellular resolution. Our methodology can answer a questions about metabolic dysfunction in aging and diseases such as cancer Raman imaging, coupled with two photon fluorescence and second harmonic generation, offers a non-destructive and label-free imaging technology that requires minimal sample preparation and achieves high subcellular resolution without damaging the cell sample. Several imaging modalities are operated as a part of our platform.Individuals should follow our protocol to the best of their abilities, noting that our system is home-built. Along the way they should develop their own practice to ensure success. In two separate tubes begin by measuring and mixing 10 milligrams of DMEM powder with 4.7 milliliters of double distilled water in a 15 mL conical tube.Thoroughly vortex and invert the tube to ensure the solution is well mixed. For both tubes, add 4.7 mL of deuterium oxide, 0.5 mL of FBS, and 0.1 mL of penicillin and streptomycin before vortexing and inverting the tube. Next, add excess phenylalanine to one tube and excess tryptophan powder to the second tube and mix again.Add methionine and threonine at 30 and 95 mg per mL, respectively, to both tubes, followed by vortexing and inverting the tube. Afterward, filter the prepared media with a 25 millimeter syringe filter with 0.22 micrometer filters. Seal all the media contained conical tubes with Parafilm.Store prepared media at four degrees Celsius. Maintain healer cells in a culture flask using standard DMEM supplemented with 10%FBS, 1%penicillin and streptomycin. Subculture the healer cells at a split ratio of one to 10 until reaching 80%or higher cell viability.Before seeding the cells, submerged the sterilized Poly-D-Lysine, laminin-coated, round 12 mm diameter cover slips in 70%Ethanol. Dry the cover slips using lint free wipes, and placed the clean cover slips in the appropriate wells of the plate. Wash the cells once with PBS without magnesium and calcium ions.Add 0.25%trypsin to dissociate the adherence cells from the flask and incubate at 37 degrees Celsius and 5%carbon dioxide for three minutes. Then add DMEM supplemented with 10%FBS, 1%penicillin, and streptomycin to the cells. Gently pipette up and down.Collect the cells by centrifugation at 300 G for three minutes at room temperature. Next, re-suspend the cells in DMEM supplemented with 0.5%FBS and 1%penicillin and streptomycin. Count the trypan blue stain cells using a hemocytometer under a light microscope and seed at a density of two times 10 to the fifth cells per well of a 24 well plate.Distribute the cells evenly by shaking the plate gently. Incubate at 37 degrees Celsius and 5%carbon dioxide. After eight hours, replace the old culture media with 50%deuterium oxide and excess phenylalanine or 50%deuterium oxide and excess tryptophan media.Return the cells to the incubator at 37 degrees Celsius and 5%carbon dioxide for 36 hours. Now prepare microscope slides with imaging spaces nine mm in diameter. Place 15 microliters of PBS, supplemented with calcium and magnesium ions and rinse the cells with the same solution.Add 0.5 mL of 4%methanol-free paraformaldehyde solution and leave the plate under the biosafety hood for 15 minutes. Aspirate the paraformaldehyde solution and rinse it with PBS, supplemented with calcium and magnesium iron twice. Add one mL of PBS, supplemented with calcium and magnesium ions to each well.Utilize sterile tweezers to remove the cover slips from each well carefully. Invert them and place the cell containing side onto the imaging spaces in contact with the PBS. Seal the outer layer of the cover slip with the imaging spacer using transparent nail polish.Load the biological sample onto the sample holder directly underneath the objective lens. Then click the camera icon on the software to turn on the video camera and adjust the focus plane to identify a region of interest with the 50X objective lens. Switch to the 100X objective lens.Click the stop icon to turn off the video camera. Then select a grating of 1, 800 lines per mm and set the the acquisition range from 400 to 3, 150 centimeters inverse. Lastly, set the acquisition time to 90 seconds the accumulation to three and the binning to four for the least noise and most accurate spectrum.Click on start to warm up the laser. Start by pressing the main switch of the control box IX3CBH to On, followed by the main switch of the touch panel controller. Then turn on the main switch of the AC adapter of the power supply for LDOBIS6 laser remote connected to the main laser combiner FV31S comb.Also switch on the AC adapter of the LDOBIS6 laser remote power supply connected to the sub laser combiner FV31S comb. After that, press the main switches of the SI photodiode detector and lock-in amplifier on. Set the laser IR at 1031 nanometers Set the pico emerald system to at tunable wavelength between 720 to 990 nm.Mount the sample on the oil and place a large water droplet on the microscope slide where the sample is fixed. Select scan size as 512 by 512 pixels. Acquire and save the images as an Olympus.OIR graphic file. After setting the signal to 862.0, acquire a background image and save it. Adjust the dwell time to eight microseconds per pixel and the pixel size to 512 by 512 pixels.Set the laser shutter power parameter to 150 milliwatts For 3D image reconstruction, tune the stimulated Raman loss to 2, 850 cm inverse. Once the desired single cells have been identified, register the laser to scan from the top focus plane to detect the top and bottom layers of those cells. Deuterium oxide, probed, stimulated Raman scattering was used to visualize the spatial distribution of CD signals on single cells.The control cells displayed moderate CD, lipid and protein bands. However, the 15 x v and 15 x trip displayed stronger CD lipid and protein bans. Quantitative analysis indicated that excess aromatic amino acids may upregulate lipid synthesis by 10 to 17%but downregulate protein synthesis by 10%Ratio metric analysis of aromatic amino acids treated cells showed a 50%increase in flavin divided by flavin plus NADH and a 10%increase in unsaturated lipid divided by saturated lipid.The stimulated Raman 3D lipid droplet volume projection in healer cells under control and excess aromatic amino acids conditions are shown. Quantitative analyses of 3D lipid droplets showed an increase in counts, but a reduction in size in aromatic amino acids treated cells compared to the control. Imaging parameters for Raman and two photon fluorescent imaging should be optimized from one sample to the next to ensure best imaging quality.Individuals can couple our system with second harmonic generation to study the collagen structure, which elucidates early metabolic changes in aging and diseases, and understanding the progression of neurodegeneration or cancer. Our technology is the first of this kind to visualize lipid and protein synthesis in biological systems with high subcellular resolution. The technology can also be translated into clinic for non-invasive disease detection.

bioorthogonal-chemical-imaging-cell-metabolism-regulated-aromatic

Research

JoVE Journal

Bioengineering

High Resolution 3D Imaging of Ex-Vivo Biological Samples by Micro CT

Non-destructive volume visualization can be achieved only by tomographic techniques, of which the most efficient is the x-ray micro computerized tomography (&mu;CT).
High resolution &mu;CT is a very versatile yet accurate (1-2 microns of resolution) technique for 3D examination of ex-vivo biological samples1, 2. As opposed to electron tomography, the &mu;CT allows the examination of up to 4 cm thick samples. This technique requires only few hours of measurement as compared to weeks in histology. In addition, &mu;CT does not rely on 2D stereologic models, thus it may complement and in some cases can even replace histological methods3, 4, which are both time consuming and destructive. Sample conditioning and positioning in &mu;CT is straightforward and does not require high vacuum or low temperatures, which may adversely affect the structure. The sample is positioned and rotated 180&deg; or 360&deg;between a microfocused x-ray source and a detector, which includes a scintillator and an accurate CCD camera, For each angle a 2D image is taken, and then the entire volume is reconstructed using one of the different available algorithms5-7. The 3D resolution increases with the decrease of the rotation step. The present video protocol shows the main steps in preparation, immobilization and positioning of the sample followed by imaging at high resolution.

High Resolution 3D Imaging of Ex-Vivo Biological Samples by Micro CT

Non-destructive volume visualization can be achieved only by tomographic techniques, of which the most efficient is the x-ray micro computerized tomography ( CT).

Non-destructive volume visualization can be achieved only by tomographic techniques, of which the most efficient is the x-ray micro computerized ...

Analyzing Cellular Internalization of Nanoparticles and Bacteria by Multi-spectral Imaging Flow Cytometry

Nanoparticulate systems have emerged as valuable tools in vaccine delivery through their ability to efficiently deliver cargo, including proteins, to antigen presenting cells1-5. Internalization of nanoparticles (NP) by antigen presenting cells is a critical step in generating an effective immune response to the encapsulated antigen. To determine how changes in nanoparticle formulation impact function, we sought to develop a high throughput, quantitative experimental protocol that was compatible with detecting internalized nanoparticles as well as bacteria. To date, two independent techniques, microscopy and flow cytometry, have been the methods used to study the phagocytosis of nanoparticles. The high throughput nature of flow cytometry generates robust statistical data. However, due to low resolution, it fails to accurately quantify internalized versus cell bound nanoparticles. Microscopy generates images with high spatial resolution; however, it is time consuming and involves small sample sizes6-8. Multi-spectral imaging flow cytometry (MIFC) is a new technology that incorporates aspects of both microscopy and flow cytometry that performs multi-color spectral fluorescence and bright field imaging simultaneously through a laminar core. This capability provides an accurate analysis of fluorescent signal intensities and spatial relationships between different structures and cellular features at high speed.
	Herein, we describe a method utilizing MIFC to characterize the cell populations that have internalized polyanhydride nanoparticles or Salmonella enterica serovar Typhimurium. We also describe the preparation of nanoparticle suspensions, cell labeling, acquisition on an ImageStreamX system and analysis of the data using the IDEAS application. We also demonstrate the application of a technique that can be used to differentiate the internalization pathways for nanoparticles and bacteria by using cytochalasin-D as an inhibitor of actin-mediated phagocytosis.

In this article, we describe a method utilizing multi-spectral imaging flow cytometry to quantify the internalization of polyanhydride nanoparticles or bacteria by RAW 264.7 cells.

Nanoparticulate  systems have emerged as valuable tools in vaccine delivery through their  ability to efficiently deliver cargo, including proteins, to ...

In vitro Cell Culture Model for Toxic Inhaled Chemical Testing

Cell cultures are indispensable to develop and study efficacy of therapeutic agents, prior to their use in animal models. We have the unique ability to model well differentiated human airway epithelium and heart muscle cells. This could be an invaluable tool to study the deleterious effects of toxic inhaled chemicals, such as chlorine, that can normally interact with the cell surfaces, and form various byproducts upon reacting with water, and limiting their effects in submerged cultures. Our model using well differentiated human airway epithelial cell cultures at air-liqiuid interface circumvents this limitation as well as provides an opportunity to evaluate critical mechanisms of toxicity of potential poisonous inhaled chemicals. We describe enhanced loss of membrane integrity, caspase release and death upon toxic inhaled chemical such as chlorine exposure. In this article, we propose methods to model chlorine exposure in mammalian heart and airway epithelial cells in culture and simple tests to evaluate its effect on these cell types.

In vitro Cell Culture Model for Toxic Inhaled Chemical Testing

This protocol is designed to demonstrate exposure method of cell cultures to inhaled toxic chemicals. Exposure of differentiated air-liquid&#160;interface (ALI) cultures of airway epithelial cells provides a unique model of airway exposure to toxic gases such as chlorine. In this manuscript we describe effect of chlorine exposure on air-liquid&#160;interface cultures of epithelial cells and submerged culture of cardiomyocytes. In vitro exposure systems allow important mechanistic studies to evaluate pathways that could then be utilized to develop novel therapeutic agents.

Cell cultures are indispensable to develop and study efficacy of therapeutic agents, prior to their use in animal models. We have the unique ability to ...

Harnessing the Bioorthogonal Inverse Electron Demand Diels-Alder Cycloaddition for Pretargeted PET Imaging

Due to their exquisite affinity and specificity, antibodies have become extremely promising vectors for the delivery of radioisotopes to cancer cells for PET imaging. However, the necessity of labeling antibodies with radionuclides with long physical half-lives often results in high background radiation dose rates to non-target tissues. In order to circumvent this issue, we have employed a pretargeted PET imaging strategy based on the inverse electron demand Diels-Alder cycloaddition reaction. The methodology decouples the antibody from the radioactivity and thus exploits the positive characteristics of antibodies, while eschewing their pharmacokinetic drawbacks. The system is composed of four steps: (1) the injection of a mAb-trans-cyclooctene (TCO) conjugate; (2) a localization time period during which the antibody accumulates in the tumor and clears from the blood; (3) the injection of the radiolabeled tetrazine; and (4) the in vivo click ligation of the components followed by the clearance of excess radioligand. In the example presented in the work at hand, a 64Cu-NOTA-labeled tetrazine radioligand and a trans-cyclooctene-conjugated humanized antibody (huA33) were successfully used to delineate SW1222 colorectal cancer tumors with high tumor-to-background contrast. Further, the pretargeting methodology produces high quality images at only a fraction of the radiation dose to non-target tissue created by radioimmunoconjugates directly labeled with 64Cu or 89Zr. Ultimately, the modularity of this protocol is one of its greatest assets, as the trans-cyclooctene moiety can be appended to any non-internalizing antibody, and the tetrazine can be attached to a wide variety of radioisotopes.

The bioorthogonal inverse electron demand Diels-Alder cycloaddition has been harnessed to create an effective and modular pretargeted PET imaging strategy for cancer. In this protocol, the steps of this methodology are described in the context of a model system employing the colorectal cancer targeted antibody huA33 and a 64Cu-labeled radioligand.

Due to their exquisite affinity and specificity, antibodies have become extremely promising vectors for the delivery of radioisotopes to cancer cells for ...

Hand-held Clinical Photoacoustic Imaging System for Real-time Non-invasive Small Animal Imaging

Translation of photoacoustic imaging into the clinic is a major challenge. Handheld real-time clinical photoacoustic imaging systems are very rare. Here, we report a combined photoacoustic and clinical ultrasound imaging system by integrating an ultrasound probe with light delivery for small animal imaging. We demonstrate this by showing sentinel lymph node imaging in small animals along with minimally invasive real-time needle guidance. A clinical ultrasound platform with access to raw channel data allows the integration of photoacoustic imaging leading to a handheld real-time clinical photoacoustic imaging system. Methylene blue was used for sentinel lymph node imaging at 675 nm wavelength. Additionally, needle guidance with dual modal ultrasound and photoacoustic imaging was shown using the imaging system. Depth imaging of up to 1.5 cm was demonstrated with a 10 Hz laser at a photoacoustic imaging frame rate of 5 frames per second.

A clinical handheld photoacoustic imaging system will be demonstrated for real-time non-invasive small animal imaging.

Translation of photoacoustic imaging into the clinic is a major challenge. Handheld real-time clinical photoacoustic imaging systems are very rare. Here, ...

Engineering 'Golden' Fluorescence by Selective Pressure Incorporation of Non-canonical Amino Acids and Protein Analysis by Mass Spectrometry and Fluorescence

Fluorescent proteins are fundamental tools for the life sciences, in particular for fluorescence microscopy of living cells. While wild-type and engineered variants of the green fluorescent protein from Aequorea victoria (avGFP) as well as homologs from other species already cover large parts of the optical spectrum, a spectral gap remains in the near-infrared region, for which avGFP-based fluorophores are not available. Red-shifted fluorescent protein (FP) variants would substantially expand the toolkit for spectral unmixing of multiple molecular species, but the naturally occurring red-shifted FPs derived from corals or sea anemones have lower fluorescence quantum yield and inferior photo-stability compared to the avGFP variants. Further manipulation and possible expansion of the chromophore&#39;s conjugated system towards the far-red spectral region is also limited by the repertoire of 20 canonical amino acids prescribed by the genetic code. To overcome these limitations, synthetic biology can achieve further spectral red-shifting via insertion of non-canonical amino acids into the chromophore triad. We describe the application of SPI to engineer avGFP variants with novel spectral properties. Protein expression is performed in a tryptophan-auxotrophic E. coli strain and by supplementing growth media with suitable indole precursors. Inside the cells, these precursors are converted to the corresponding tryptophan analogs and incorporated into proteins by the ribosomal machinery in response to UGG codons. The replacement of Trp-66 in the enhanced &#34;cyan&#34; variant of avGFP (ECFP) by an electron-donating 4-aminotryptophan results in GdFP featuring a 108 nm Stokes shift and a strongly red-shifted emission maximum (574 nm), while being thermodynamically more stable than its predecessor ECFP. Residue-specific incorporation of the non-canonical amino acid is analyzed by mass spectrometry. The spectroscopic properties of GdFP are characterized by time-resolved fluorescence spectroscopy as one of the valuable applications of genetically encoded FPs in life sciences.

Engineering &#039;Golden&#039; Fluorescence by Selective Pressure Incorporation of Non-canonical Amino Acids and Protein Analysis by Mass Spectrometry and Fluorescence

Synthetic biology enables the engineering of proteins with unprecedented properties using the co-translational insertion of non-canonical amino acids. Here, we presented how a spectrally red-shifted variant of a GFP-type fluorophore with novel fluorescence spectroscopic properties, termed &#34;gold&#34; fluorescent protein (GdFP), is produced in E. coli via selective pressure incorporation (SPI).

Fluorescent proteins are fundamental tools for the life sciences, in particular for fluorescence microscopy of living cells. While wild-type and ...

Antimicrobial Peptides Produced by Selective Pressure Incorporation of Non-canonical Amino Acids

Nature has a variety of possibilities to create new protein functions by modifying the sequence of the individual amino acid building blocks. However, all variations are based on the 20 canonical amino acids (cAAs). As a way to introduce additional physicochemical properties into polypeptides, the incorporation of non-canonical amino acids (ncAAs) is increasingly used in protein engineering. Due to their relatively short length, the modification of ribosomally synthesized and post-translationally modified peptides by ncAAs is particularly attractive. New functionalities and chemical handles can be generated by specific modifications of individual residues. The selective pressure incorporation (SPI) method utilizes auxotrophic host strains that are deprived of an essential amino acid in chemically defined growth media. Several structurally and chemically similar amino acid analogs can then be activated by the corresponding aminoacyl-tRNA synthetase and provide residue-specific cAA(s) &#8594; ncAA(s) substitutions in the target peptide or protein sequence. Although, in the context of the SPI method, ncAAs are also incorporated into the host proteome during the phase of recombinant gene expression, the majority of the cell&#39;s resources are assigned to the expression of the target gene. This enables efficient residue-specific incorporation of ncAAs often accompanied with high amounts of modified target. The presented work describes the in vivo incorporation of six proline analogs into the antimicrobial peptide nisin, a lantibiotic naturally produced by Lactococcus lactis. Antimicrobial properties of nisin can be changed and further expanded during its fermentation and expression in auxotrophic Escherichia coli strains in defined growth media. Thereby, the effects of residue-specific replacement of cAAs with ncAAs can deliver changes in antimicrobial activity and specificity. Antimicrobial activity assays and fluorescence microscopy are used to test the new nisin variants for growth inhibition of a Gram-positive Lactococcus lactis indicator strain. Mass spectroscopy is used to confirm ncAA incorporation in bioactive nisin variants.

The protocol presents the Escherichia coli-based selective pressure incorporation of non-canonical amino acids (ncAAs) into the lactococcal antimicrobial peptide nisin. Its properties can be changed during recombinant expression via substitution with desired ncAAs in defined growth media. Resulting changes in bioactivity are mapped by growth inhibition assays and fluorescence microscopy.

Nature has a variety of possibilities to create new protein functions by modifying the sequence of the individual amino acid building blocks. However, all ...

Repressing Gene Transcription by Redirecting Cellular Machinery with Chemical Epigenetic Modifiers

Regulation of chromatin compaction is an important process that governs gene expression in higher eukaryotes. Although chromatin compaction and gene expression regulation are commonly disrupted in many diseases, a locus-specific, endogenous, and reversible method to study and control these mechanisms of action has been lacking. To address this issue, we have developed and characterized novel gene-regulating bifunctional molecules. One component of the bifunctional molecule binds to a DNA-protein anchor so that it will be recruited to an allele-specific locus. The other component engages endogenous cellular chromatin-modifying machinery, recruiting these proteins to a gene of interest. These small molecules, called chemical epigenetic modifiers (CEMs), are capable of controlling gene expression and the chromatin environment in a dose-dependent and reversible manner. Here, we detail a CEM approach and its application to decrease gene expression and histone tail acetylation at a Green Fluorescent Protein (GFP) reporter located at the Oct4 locus in mouse embryonic stem cells (mESCs). We characterize the lead CEM (CEM23) using fluorescent microscopy, flow cytometry, and chromatin immunoprecipitation (ChIP), followed by a quantitative polymerase chain reaction (qPCR). While the power of this system is demonstrated at the Oct4 locus, conceptually, the CEM technology is modular and can be applied in other cell types and at other genomic loci.

Regulation of the chromatin environment is an essential process required for proper gene expression. Here, we describe a method for controlling gene expression through the recruitment of chromatin-modifying machinery in a gene-specific and reversible manner.

Regulation of chromatin compaction is an important process that governs gene expression in higher eukaryotes. Although chromatin compaction and gene ...

Visualizing Adhesion Formation in Cells by Means of Advanced Spinning Disk-Total Internal Reflection Fluorescence Microscopy

In living cells, processes such as adhesion formation involve extensive structural changes in the plasma membrane and the cell interior. In order to visualize these highly dynamic events, two complementary light microscopy techniques that allow fast imaging of live samples were combined: spinning disk microscopy (SD) for fast and high-resolution volume recording and total internal reflection fluorescence (TIRF) microscopy for precise localization and visualization of the plasma membrane. A comprehensive and complete imaging protocol will be shown for guiding through sample preparation, microscope calibration, image formation and acquisition, resulting in multi-color SD-TIRF live imaging series with high spatio-temporal resolution. All necessary image post-processing steps to generate multi-dimensional live imaging datasets, i.e. registration and combination of the individual channels, are provided in a self-written macro for the open source software ImageJ. The imaging of fluorescent proteins during initiation and maturation of adhesion complexes, as well as the formation of the actin cytoskeletal network, was used as a proof of principle for this novel approach. The combination of high resolution 3D microscopy and TIRF provided a detailed description of these complex processes within the cellular environment and, at the same time, precise localization of the membrane-associated molecules detected with a high signal-to-background ratio.

An advanced microscope that permit fast and high-resolution imaging of both, the isolated plasma membrane and the surrounding intracellular volume, will be presented. The integration of spinning disk and total internal reflection fluorescence microscopy in one setup allows live imaging experiments at high acquisition rates up to 3.5 s per image stack.

In living cells, processes such as adhesion formation involve extensive structural changes in the plasma membrane and the cell interior. In order to ...

Detection of Endotoxin in Nano-formulations Using Limulus Amoebocyte Lysate (LAL) Assays

When present in pharmaceutical products, a Gram-negative bacterial cell wall component endotoxin (often also called lipopolysaccharide) can cause inflammation, fever, hypo- or hypertension, and, in extreme cases, can lead to tissue and organ damage that may become fatal. The amounts of endotoxin in pharmaceutical products, therefore, are strictly regulated. Among the methods available for endotoxin detection and quantification, the Limulus Amoebocyte Lysate (LAL) assay is commonly used worldwide. While any pharmaceutical product can interfere with the LAL assay, nano-formulations represent a particular challenge due to their complexity. The purpose of this paper is to provide a practical guide to researchers inexperienced in estimating endotoxins in engineered nanomaterials and nanoparticle-formulated drugs. Herein, practical recommendations for performing three LAL formats including turbidity, chromogenic and gel-clot assays are discussed. These assays can be used to determine endotoxin contamination in nanotechnology-based drug products, vaccines, and adjuvants.

Detection of Endotoxin in Nano-formulations Using Limulus Amoebocyte Lysate LAL Assays

Detection of endotoxins in engineered nanomaterials represents one of the grand challenges in the field of nanomedicine. Here, we present a case study that describes the framework composed of three different LAL formats to estimate potential endotoxin contamination in nanoparticles.
