The authors thank David Larson for developing the original protocol for imaging the live Drosophila pupal eye. We thank our colleagues Richard Carthew, Shoichiro Tsukita and Matthew Freeman, who developed the transgenic flies that we combined to generate our live-imaging fly lines. Brittany Baldwin-Hunter gave helpful comments on the manuscript. This work was supported by start-up funds awarded to Ruth Johnson by Wesleyan University.

Figure 3 shows a summary of the experimental procedure.
1. Tissue Preparation
<ol>
	<li>To determine the consequences of modified expression of a gene of interest, set up the following cross in duplicate and maintain at 25 &#176;C: UAS-transgene (males)X GMR-GAL4; UAS-&#945;-cat:GFP, ubi-DE-Cad:GFP ; + / SM5-TM6b (virgin females) NOTE: To obtain control tissue cross UAS-lacZ males to GMR-GAL4; UAS-&#945;-cat:GFP, ubi-DE-Cad:GFP females. &#946;-Galactosidase generates no defects in cell behavior in the retina.</li>
	<li>To enhance efficacy of RNAi transgenes, cross UAS-RNAi males to GMR-GAL4, UAS-Dcr-2; UAS-&#945;-cat:GFP, ubi-DE-Cad:GFP; + / SM5-TM6b virgin females.
	NOTE: Occasional defects in cell behavior in retinae expressing ectopic Dcr-2 have been observed (data not shown). Vigilance is recommended if using this approach.</li>
	<li>Select white pre-pupae of appropriate genotypes and place in 1.5 ml microcentrifuge tubes. If the pupae express Dcr-2, select either male or female pupae: expression of UAS-Dcr-2, an insert on the X chromosome, is stronger in males. Pupae should be sexed at 0 hr APF before pigmentation of the pupal case &#8211; the gonads of males are visible as large translucent globes on the lateral sides of the pupa (approximately one-third from the posterior).</li>
	<li>Incubate microcentrifuge tubes containing pupae, in a clean plastic tip-box at 25 &#176;C. To prevent desiccation of pupae place a 10 cm2 piece of tissue, soaked in distilled water, into the tip-box.
	NOTE: if the humidity in the tip-box becomes too high the pupal case may become soggy and difficult to dissect in subsequent steps.</li>
	<li>Incubate for appropriate time. To capture cell behaviors associated with patterning the eye, prepare pupae for imaging at around 17 hr APF, 20 hr APF or 24 hr APF. See Representative Results for further discussion on when specific cell behaviors are best observed.</li>
	<li>Place a piece of fresh double-sided tape onto a black sylgard dissection dish. Position a pupa, dorsal side up, with the head of the pupa adhered to the double-sided tape (Figure 1A).Try not to adhere the thoracic and abdominal regions of the pupa to the double-sided tape. With forceps carefully lift and remove the operculum to expose the pupal head. Tear along the side of the pupal case to expose the area around one eye.</li>
	<li>Gently remove the pupa from the adhesive tape. If the pupa remains adherent, apply a small volume of distilled water to the junction between the pupal case and tape to weaken adhesion.</li>
</ol>
2. Mounting
<ol>
	<li>Construct a small 15 mm2 frame from blotting paper and punch a hole in the middlethat is 5.5 mm in diameter (Figure 1B). Immerse in distilled water and place in the center of a microscope slide. Using a 30 cc syringe, squeeze out a uniform ring of petroleum jelly to surround the blotting paper frame. Ensure that the petroleum jelly ring is marginally higher than the width of the pupa and that the diameter of the ring is marginally less than the width of a cover slip.</li>
	<li>Add a small bead of petroleum jelly directly onto the slide, in the hole punched into the blotting paper(Figure 1C).Carefully arrange the pupa, on its side, supported by the petroleum jelly bead (Figure 1D).</li>
	<li>Place a coverslip on top of the petroleum jelly ring so that it contacts the epithelium above the eye neuroepithelium (Figure 1D). Gently compress the preparation to seal the coverslip against the petroleum jelly and generate a small flat contact surface between the pupal eye region and the coverslip.</li>
</ol>
3. Fluorescence Imaging
<ol>
	<li>Image the pupal preparation using a fluorescent microscope. Every 7 min capture serial sections through the apical domain of the eye neuroepithelium, in the region of the adherens junctions.
	NOTE: a) Appropriate serial sections are usually 4-5 per&#160;z-stack&#160;comprised of 0.2 &#956;m z-steps. b) Irregularities in the topology of the epithelium, including mild bumps and folds, may make it challenging to acquire in-focus images of large regions of tissue. While imaging, one may find part of an area of interest to be in-focus, and a neighboring region to be out-of-focus. Including a small droplet of distilled water between the pupal eye and coverslip can eliminate some acute tissue folds but not the mildly uneven topology characteristic of the early stages of pupal eye morphogenesis. In these instances oversample the tissue by extending the z-stack until in-focus slices are acquired for the entire field. c) Capturing serial sections every 7 min should enable live-imaging for 3 to 4 hr without a significant reduction in the intensity of GFP fluorescence that may compromise image quality. Shorter time-intervals may reduce the total time of imaging.</li>
	<li>Continue imaging for 3 to 4 hr. Do not use an automatic focus and time function that is available on many fluorescent microscopes since pupal growth and pumping of the hemolymph moves the position of the retina and vigilant re-focusing is required every 14-21 min. NOTE that imaging beyond 4 hours may slow or stall morphogenesis of the eye.</li>
	<li>Use appropriate deconvolution software to reduce background and enhance contrast of the serial section images. For each z-stack file, perform the following in LAS AF software (see Table of Materials): Navigate to the Tools panel, select 3D Deconvolution and click Apply.</li>
	<li>Generate a maximum projection (MP) image for each deconvoluted stack file: Navigate to the Tools panel, select 3D Projection and click Apply.
	NOTE: The Maximum Projection algorithm may fail to generate a uniformly in-focus image for tissue that has been oversampled. A technique for sharpening out-of-focus regions is outlined in step 5.2.</li>
</ol>
4. Post-imaging Pupal Rescue and Phenotype Verification
<ol>
	<li>To address whether artifacts were introduced or the pupa harmed during imaging, carefully remove the pupa from the imaging rig: using forceps remove the coverslip and transfer the pupa to a clean vial of food. Store at room temperature or 25 &#176;C until the adult fly emerges.</li>
	<li>Carefully examine the phenotype of the adult eye and compare to the eyes of adult flies emerging from the original fly cross.</li>
</ol>
5. Image Processing
<ol>
	<li>Automatic Image Alignment:
	NOTE: The live Drosophila tissue will shift and grow throughout the imaging process. Consequently, the centers of images gathered at successive time points may not correspond to the same point in the Drosophila tissue. In addition the entire retinal disc rotates about 30&#176; between ~21 and 23 hr APF. To highlight individual cell behaviors and reduce distractions caused by organismal growth,align each MP image.While this can be performed manually,the image editing software used here (see Table of Materials) has built-in algorithms that can expedite the process.
	<ol>
		<li>From the File tab of the main menu, open Scripts and select Load Files into Stack.</li>
		<li>Import the MP image files into the Load Layers panel and select OK. Make sure that the Attempt to Automatically Align Source Images option is not selected.
		NOTE: If this option is selected, the software may use an alignment algorithm that distorts the image data.</li>
		<li>Once all MP files have loaded into the Layers pane, make sure that all images are in chronological order such that the earliest time point is at the top of the layer stack. If the layers are not in the correct order, drag and drop them until they are ordered correctly.</li>
		<li>Select Auto-Align Layers from the Edit tab of the main menu. Choose Reposition and click OK.</li>
		<li>If the Auto-Align algorithm fails to orient the frames to a relevant focal point, make minor adjustments using the Move tool.</li>
	</ol>
	</li>
	<li>Composite Sharpening:
	NOTE: Out-of-focus regions of an initial MP image can be sharpened by &#8216;cropping&#8217; the corresponding deconvoluted stack in LAS AF software. Cropping a stack file allows one to manually restrict the interval of a z-stack that is subjected to the Maximum Projection algorithm.
	<ol>
		<li>Locate the Crop function in the Tools panel (under the Process tab). Manually restrict the initial and final slices such that they span only the adhesion belt within the initially out-of-focus region. Click Apply to generate a new stack file that is optimized for this region.</li>
		<li>Generate a new Maximum Projection for the locally optimized stack and export as a TIFF file.</li>
		<li>In the image editing software (see Table of Materials), open Scripts (located in the File tab of the main menu) and select Load Files into Stack.</li>
		<li>Import the initial MP image file and locally optimized MP file for a particular time point into the Load Layers panel and select OK. Make sure that the Attempt to Automatically Align Source Images option is not selected.</li>
		<li>Select both layers in the Layers pane and then choose Auto-Blend Layers (located in the Edit tab of the main menu) to automatically mask the appropriate regions of the two images, yielding a uniformly in-focus retinal field. Save this composite image as a TIFF file.</li>
		<li>Repeat steps 5.2.1 through 5.2.5 for all suboptimal MP images.</li>
	</ol>
	</li>
	<li>Further Adjustments: Rotate, crop, and Adjust the Levels of the Movie Layers:
	<ol>
		<li>With all of the layers selected, use the Transform tool (Edit &#62; Free Transform) to rotate the images so that the dorsal-ventral axis of the retina is aligned to the y-axis of the movie frame.</li>
		<li>If necessary, use the Crop tool to reduce the field of view to a desired size and shape.</li>
		<li>Use level adjustment (of individual frames) to help enhance contrast between the cell membrane and cell body.</li>
		<li>For stylistic purposes and to emphasize specific cell behaviors, introduce false color to highlight points of interest in each frame.</li>
	</ol>
	</li>
	<li>Animation: Convert the Images into a Movie:
	<ol>
		<li>Open the Animation pane from the Windows tab of the main menu. Select Make Frames from Layers from the menu located in the upper right hand corner of the Animation pane.</li>
		<li>Note that the layers are added to the animation pane in sequential order beginning from the bottom of the stack. To reverse the order of the frames, first select all of the frames and then select Reverse Frames from the Animation pane menu.</li>
		<li>Select a frame delay time for each frame using the dropdown menu below the frame thumbnail.
		NOTE: The frame delay for Movies 1 to 4 presented in this paper is 0.8 sec.</li>
		<li>From the File tab of the main menu, open Export and select Render Video. Choose QuickTime Export under File Options and select a desired video format. Under Render Options set Frame Rate to Custom, enter a frame rate of 15, and click Render.</li>
	</ol>
	</li>
</ol>

<ol>
	<li>Oda, H., Tsukita, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+imaging+of+cell-cell+adherens+junctions+reveals+that+Drosophila+mesoderm+invagination+begins+with+two+phases+of+apical+constriction+of+cells.">Real-time imaging of cell-cell adherens junctions reveals that Drosophila mesoderm invagination begins with two phases of apical constriction of cells.</a> J. Cell. Sci. 114, 493-501 (2001).</li><li>Oda, H., Tsukita, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamic+features+of+adherens+junctions+during+Drosophila+embryonic+epithelial+morphogenesis+revealed+by+a+Dalpha-catenin-GFP+fusion+protein.">Dynamic features of adherens junctions during Drosophila embryonic epithelial morphogenesis revealed by a Dalpha-catenin-GFP fusion protein.</a> Dev. Genes Evol. 209, 218-225 (1999).</li><li>Freeman, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Reiterative+use+of+the+EGF+receptor+triggers+differentiation+of+all+cell+types+in+the+Drosophila+eye.">Reiterative use of the EGF receptor triggers differentiation of all cell types in the Drosophila eye.</a> Cell. 87, 651-660 (1996).</li><li>Cagan, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cell+fate+specification+in+the+developing+Drosophila.+retina.">Cell fate specification in the developing Drosophila. retina.</a> Dev Suppl. , 19 (1993).</li><li>Wolff, T., Ready, D. F., Bate, M., Arias, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Pattern+formation+in+the+Drosophila.+retina.">Pattern formation in the Drosophila. retina.</a> The Development of Drosophila melanogaster. , 1277-1325 (1993).</li><li>Larson, D. E., Liberman, Z., Cagan, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cellular+behavior+in+the+developing.+Drosophila+pupal+retina.">Cellular behavior in the developing. Drosophila pupal retina.</a> Mech. Dev. 125, 223-234 (2008).</li><li>Monserrate, J. P., Brachmann, C. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Identification+of+the+death+zone:+a+spatially+restricted+region+for+programmed+cell+death+that+sculpts+the+fly+eye.">Identification of the death zone: a spatially restricted region for programmed cell death that sculpts the fly eye.</a> Cell Death Differ. 14, 209-217 (2007).</li><li>Lee, Y. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Distinct+roles+for+Drosophila+Dicer-1+and+Dicer-2+in+the+siRNA/miRNA+silencing+pathways.">Distinct roles for Drosophila Dicer-1 and Dicer-2 in the siRNA/miRNA silencing pathways.</a> Cell. 117, 69-81 (2004).</li><li>Zitserman, D., Roegiers, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Live-cell+imaging+of+sensory+organ+precursor+cells+in+intact+Drosophila+pupae.">Live-cell imaging of sensory organ precursor cells in intact Drosophila pupae.</a> J. Vis. Exp. (51), 2706 (2011).</li><li>Classen, A. K., Aigouy, B., Giangrande, A., Eaton, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+Drosophila+pupal+wing+morphogenesis.">Imaging Drosophila pupal wing morphogenesis.</a> Methods Mol. Biol. 420, 265-275 (2008).</li><li>Sato, M., Suzuki, T., Nakai, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Waves+of+differentiation+in+the+fly+visual+system.">Waves of differentiation in the fly visual system.</a> Dev. Biol. 380, 1-11 (2013).</li><li>Cordero, J., Jassim, O., Bao, S., Cagan, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+role+for+wingless+in+an+early+pupal+cell+death+event+that+contributes+to+patterning+the+Drosophila+eye.">A role for wingless in an early pupal cell death event that contributes to patterning the Drosophila eye.</a> Mech. Dev. 121, 1523-1530 (2004).</li><li>Larson, D. E., Johnson, R. I., Swat, M., Cordero, J. B., Glazier, J. A., Cagan, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Computer+simulation+of+cellular+patterning+within+the+Drosophila+pupal+eye.">Computer simulation of cellular patterning within the Drosophila pupal eye.</a> PLoS Comput. Biol. 6, e1000841 (2010).</li><li>Cagan, R. L., Ready, D. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+emergence+of+order+in+the+Drosophila+pupal+retina.">The emergence of order in the Drosophila pupal retina.</a> Dev. Biol. 136, 346-362 (1989).</li><li>Cagan, R. L., Ready, D. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Notch+is+required+for+successive+cell+decisions+in+the+developing+Drosophila+retina.">Notch is required for successive cell decisions in the developing Drosophila retina.</a> Genes Dev. 1099, 1112 (1989).</li><li>Miller, D. T., Cagan, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Local+induction+of+patterning+and+programmed+cell+death+in+the+developing+Drosophila+retina.">Local induction of patterning and programmed cell death in the developing Drosophila retina.</a> Development. 125, 2327-2335 (1998).</li><li>Sawamoto, K., Okano, H., Kobayakawa, Y., Hayashi, S., Mikoshiba, K., Tanimura, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+function+of+argos+in+regulating+cell+fate+decisions+during+Drosophila+eye+and+wing+vein+development.">The function of argos in regulating cell fate decisions during Drosophila eye and wing vein development.</a> Dev. Biol. 164, 267-276 (1994).</li><li>Yu, S. Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+pathway+of+signals+regulating+effector+and+initiator+caspases+in+the+developing+Drosophila+eye.">A pathway of signals regulating effector and initiator caspases in the developing Drosophila eye.</a> Development. 129, 3269-3278 (2002).</li><li>Liu, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanical+tugging+force+regulates+the+size+of+cell-cell+junctions.">Mechanical tugging force regulates the size of cell-cell junctions.</a> Proc. Natl. Acad. Sci. 107, 9944-9949 (2010).</li><li>Miyake, Y., Inoue, N., Nishimura, K., Kinoshita, N., Hosoya, H., Yonemura, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Actomyosin+tension+is+required+for+correct+recruitment+of+adherens+junction+components+and+zonula+occludens+formation.">Actomyosin tension is required for correct recruitment of adherens junction components and zonula occludens formation.</a> Exp. Cell Res. 312, 1637-1650 (2006).</li></ol>

The authors declare that they have no competing financial interests.

The description of wild-type development (above) forms the basis for comparisons of patterning events in RNAi or overexpression genotypes. Comparisons of live tissue development are invaluable when determining precisely which cell behaviors are regulated by a protein of interest. Further, and not described here, live cell imaging enables one to make qualitative and/or quantitative descriptions of the role of a gene of interest in the events that pattern the eye. By 30-32 hr APF most pigment cells have acquired stable pos...

The compound Drosophila eye is characterized by the stereotyped arrangement of its ~750 ommatidia separated by a honeycomb-lattice of accessory pigment cells 4,5. These pigment cells are patterned by a coordinated combination of events: local cell movements, cell growth, changes in cell shape, and apoptosis. Live visualization of this epithelium allows one to study the molecular mechanisms underpinning these events in a physiologically relevant and unperturbed three-dimensional context.
In contrast to previous protocols 6,7, the technique outlined here incorporates an efficient method for stabilizing extraneous tissue movement that cannot be uncoupled from the imaging process. This method enhances studies of cell behavior in the developing Drosophila pupal eye epithelium &#8211; a tissue that grows, rotates, and shifts over the course of imaging. In addition the motion-stabilization technique described here will be useful for studying cells in other contexts where extraneous movement occurs.
To visualize cell boundaries in the Drosophila retinal field, transgenic fly lines were generated that express ubi-DE-Cadherin:GFP as well as UAS-&#945;-catenin:GFP under control of the eye-specific driver GMR-GAL4 1-3. The use of two GFP-tagged membrane markers allows for the visualization of cell boundaries at lower intensity light. This minimizes tissue damage and photobleaching on repeated exposure to high-energy wavelengths, enabling increased frame rate and movie duration. To enhance efficacy of RNAi transgenes, UAS-Dcr-2 was also incorporated into a second fly line 8.
In a third update from previous protocols, a simpler imaging rig that is easily assembled in most laboratories is described. This apparatus obviates the requirement to have a specialized imaging rig generated by a university&#8217;s &#8216;machine shop&#8217; or similar service. This imaging rig is similar to that used to image other pupal tissues 9,10.
Presented here is a simple live-cell imaging protocol that can be used to directly assess the morphogenetic events that contribute to eye patterning from ~17 to 42 hr after puparium formation (hr APF). Specifically, this protocol enables one to determine the consequences of modifying gene expression during pupal development.

<table border="0" cellpadding="0" cellspacing="0" width="672">
	<tbody>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Name of Material/ Equipment</td>
			<td style="width:124px;">Company</td>
			<td style="width:119px;">Catalog Number</td>
			<td style="width:167px;">Comments/Description</td>
		</tr>
		<tr height="21">
			<td colspan="3" height="21" style="height:21px;">GMR-GAL4; UAS-a-cat:GFP, ubi-DE-Cadherin:GFP ; + / SM5-TM6b</td>
			<td>Available on request from authors</td>
		</tr>
		<tr height="21">
			<td colspan="3" height="21" style="height:21px;">UAS-dcr-2; UAS-a-cat:GFP, ubi-DE-Cadherin:GFP; + / SM5-TM6b&#160;</td>
			<td>Available on request from authors</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Scotch double stick tape</td>
			<td style="width:124px;">3M</td>
			<td style="width:119px;">665</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Black Sylgard dissection dish</td>
			<td style="width:124px;"></td>
			<td style="width:119px;"></td>
			<td>Fill glass petri dish to rim with Sylgard (colored black with finely-ground charcoal powder) or Sylgard 170; leave at room temperature for 24-48 h to polymerize</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Sylgard</td>
			<td style="width:124px;">Dow Corning</td>
			<td style="width:119px;">SYLG184</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Sylgard (Black)</td>
			<td style="width:124px;">Dow Corning</td>
			<td style="width:119px;">SYLG170</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Glass petri dish</td>
			<td style="width:124px;">Corning</td>
			<td style="width:119px;">7220-85</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">25 x 75 x 1 mm glass microscope slide</td>
			<td style="width:124px;">Fisher Scientific</td>
			<td style="width:119px;">12-550-413</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">22 x 40 mm glass coverslip</td>
			<td style="width:124px;">VWR</td>
			<td>48393-172</td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:263px;">Forceps&#160;</td>
			<td style="width:124px;">Fine Science Tools</td>
			<td style="width:119px;">91150-20</td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:263px;">Whatman 3mm Chromatography Paper</td>
			<td style="width:124px;">Fisher Scientific</td>
			<td style="width:119px;">05-713-336</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Vaseline</td>
			<td style="width:124px;">Fisher Scientific</td>
			<td style="width:119px;">19-086-291</td>
			<td>Or purchase at local pharmacy.</td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">30ml syringe</td>
			<td style="width:124px;">Fisher Scientific</td>
			<td style="width:119px;">S7510-30</td>
			<td></td>
		</tr>
		<tr height="21">
			<td height="21" style="height:21px;width:263px;">Adobe Photoshop CS5</td>
			<td style="width:124px;">Adobe</td>
			<td style="width:119px;"></td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:263px;">Leica TCS SP5 DM microscope</td>
			<td style="width:124px;">Leica Microsystems</td>
			<td style="width:119px;"></td>
			<td></td>
		</tr>
		<tr height="42">
			<td height="42" style="height:42px;width:263px;">LAS AF Version 2.6.0.7266 microscope software</td>
			<td style="width:124px;">Leica Microsystems</td>
			<td style="width:119px;"></td>
			<td></td>
		</tr>
	</tbody>
</table>
