Note: The following protocol outlines how to perform gRNA design using online tools (steps 1.1 - 1.4), which are common to all methods of gRNA plasmid construction detailed in this manuscript. Once the desired gRNAs are identified, steps for ordering the necessary oligonucleotides are described along with several different methods for introducing the oligonucleotides into expression vectors (e.g., pSB700). Presented are 2 methods for cloning single guide-expressing vectors based on either ligation into a predigested expression vector (steps 2 - 7.3) or Golden Gate cloning (steps 8 - 8.4). Further outlined is a strategy for cloning paired guide-expressing vectors using polymerase chain reaction (PCR) followed by Golden Gate cloning (steps 11 - 16). Finally, common methods for performing an E. coli chemical transformation (steps 9 - 9.6) and an expression vector sequence validation (steps 10 to 10.2.3) are also outlined.
<ol>
	<li>Design gRNA oligonucleotides using online tools as follows.
	<ol>
		<li>Design gRNAs using online tools such as the sgRNA Scorer 2.0 online tool (https://crispr.med.harvard.edu/sgRNAScorerV2/)13 or alternatives such as the Broad sgRNA design tool (http://portals.broadinstitute.org/gpp/public/analysis-tools/sgrna-design)14 and several others15.</li>
		<li>Use the gene name, symbol, or raw DNA target sequences to generate potential gRNA sequences.
		Note: A spreadsheet (.csv/.xls) file with all the potential gRNAs against the gene or the provided sequence is created. The quality of the potential gRNAs will be reported as Score if the sgRNA Scorer 2.0 online tool is being used, or as % on-target efficiency if the Broad sgRNA design tool is being used. Both measures are derived at based on the on-target cutting activity.</li>
		<li>Consider the Off-target activity in the gRNA selection when ranking the gRNAs.
		Note: Optimal guides are those with the greatest on-target efficiency and the least off-target activity. For activation (CRISPRa), gRNAs are designed to target the region from 1 - 200 bp upstream of the transcriptional start site (TSS)4,15. For inhibition (CRISPRi), gRNAs are designed to target the region from 50 bp upstream of the TSS until 300 bp downstream of the TSS5. To disable a gene using Cas9 cutting, gRNAs are designed to target the first 10 - 50% of the coding sequence downstream of the initiating codon (as gRNAs targeting the 3&#8217; end of the gene have been shown to be less effective)13.</li>
		<li>Ensure no internal BsmBI sites are present if oligonucleotides are being used for the Golden Gate cloning, as this will result in the annealed oligonucleotides being digested13.</li>
	</ol>
	</li>
	<li>Select the genomic target sequences and remove the 3&#8217; NGG PAM (leaving only the protospacer sequence) for the single gRNA oligonucleotide sequence modification (e.g., starting sequence: CGCGTGCTCTCCCTCATCCATGG).
	Note: If using a spreadsheet, the following formula will remove 3&#8217; NGG: =LEFT(A2,LEN(A2)-3), where A2 is the cell containing the target sequence and the PAM.
	<ol>
		<li>Append CACCG to the 5&#8217; end of the oligo.
		Note: Upon ligation to the pSB700 backbone, this sequence will comprise the 3&#8217; end of the U6 promoter driving the transcription of the gRNA. The &#8220;CACC&#8221; sequence ensures that the oligo is compatible with the overhangs of the BsmBI-digested pSB700 vector. The &#8220;G&#8221; is a requirement of Polymerase III promoters and ensures the efficient initiation of the transcription of the gRNA. Use the following formula in a spreadsheet to perform this task: =CONCATENATE(&#8220;CACCG&#8221;,(B2)), where B2 is the cell containing the protospacer sequence [e.g., adding the 5&#8217; CACCG sequence to the protospacer: CACCGCGCGTGCTCTCCCTCATCCA (this is the final forward oligo that is ordered)].</li>
		<li>Create a reverse complement (rc) of the protospacer sequence.
		Note: For example, the reverse complement of the aforementioned protospacer is TGGATGAGGGAGAGCACGCG.</li>
		<li>Append AAAC to the 5&#8217; end of the rc protospacer. Append an additional C to the 3&#8217; end of the rc protospacer (reverse oligo).
		Note: The &#8220;AAAC&#8221; sequence ensures that the oligo is compatible for cloning into the BsmBI-digested pSB700 vector. The additional &#8220;C&#8221; on the 3&#8217; end is needed to anneal the sequence to the initiating &#8220;G&#8221; added to the forward oligo. Use the following formula in a spreadsheet to perform this task =CONCATENATE(&#8220;AAAC&#8221;,(C2),&#8221;C&#8221;), where C2 is the cell containing the reverse complement sequence [e.g., AAACTGGATGAGGGAGAGCACGCGC (this is the final reverse oligo that is ordered)].</li>
	</ol>
	</li>
	<li>Order the oligonucleotides, with no additional modifications on the oligonucleotides.
	<ol>
		<li>Order the minimal amount of oligo required, as only very small amounts are needed for the cloning reactions.</li>
	</ol>
	</li>
	<li>Dilute lyophilized primers to a final concentration of 100 &#956;M in 1x TE buffer (10 mM Tris-Cl, pH 7.5 with 1 mM EDTA).</li>
	<li>Aliquot 1:1 forward and reverse oligonucleotides (e.g., 10 &#956;L each) into PCR strip-cap tubes.
	Note: This will allow the rapid cloning of many gRNAs at a time using a multichannel pipette.
	<ol>
		<li>Vortex and spin down the oligo mixtures (100 x g for 15 s). Incubate the reaction at room temperature for 5 min before setting up the ligation.
		Note: It is not necessary to heat and then cool the oligo mixtures to facilitate their annealing. It is worth noting that 3 - 4 pairs of gRNA oligonucleotides may be pooled and annealed in a single reaction (e.g., mix 3 &#956;L of forward and 3 &#956;L of reverse oligonucleotides together from up to 4 gRNA oligo pairs, giving a total volume of 24 &#956;L). The volume of the oligonucleotides used for the annealing may be adjusted to accommodate a user&#8217;s needs.
		Note: Steps 6 - 7.3 describe the predigestion of pSB700. For an alternative method, see step 8, which describes a single-step BsmBI restriction ligation.</li>
	</ol>
	</li>
	<li>Digest 1 - 5 &#956;g of the selected pSB700 guide expression vector with BsmBI (0.5 &#956;L per 1 &#956;g) for 1 h at 55 &#176;C15. Conduct the digestion of the pSB700 gRNA expression vector in a total volume of 40 &#956;L (Table 1).
	<ol>
		<li>Run the digestion products on 1.5% (wt/vol) low-melting agarose gel.</li>
		<li>Cut out the digested vector backbone band which corresponds to a fragment of ~9 kb in size and place the gel slice in a 1.5 mL microcentrifuge tube (Figure 1).</li>
		<li>Use a commercial gel purification kit to extract the DNA from the agarose gel according to the manufacturer&#8217;s instructions.</li>
		<li>Elute the DNA into 10 - 15 &#956;L of TE buffer (10 mM Tris, pH 7.5; 10 mM Tris, pH 8.0) to obtain a concentrated eluate.</li>
	</ol>
	</li>
	<li>Ligate the annealed gRNA oligonucleotides from step 4 into the BsmBI-digested pSB700 guide expression vector in a 20 &#956;L reaction (Table 2) for the cloning of the gRNA oligonucleotides into the pre-digested pSB700 expression vector.
	<ol>
		<li>First, add water, buffer, and DNA, then vortex the mixture and add enzyme, vortex 1 final time after adding the enzyme and spin down the solution (100 x g for 15 s). Incubate the reactions at room temperature overnight.</li>
		<li>Include a no-insert negative control reaction that has a BsmBI-digested vector alone, without an annealed gRNA oligo insert. 1 &#956;L of water may be used in place of the 1 &#956;L of gRNA oligonucleotides for the no-insert negative control.</li>
		<li>Proceed to the transformation (step 9).
		Note: Step 8 is an alternative method to the predigestion of pSB700 as described in steps 6 - 7.3.</li>
	</ol>
	</li>
	<li>Introduce gRNA oligonucleotides (outlined in steps 1 - 5.1) into the pSB700 vector through the use of Golden Gate cloning for the single-step BsmBI restriction ligation.
	<ol>
		<li>Assemble the master mix (1x)&#8212;if multiple gRNAs are being cloned, prepare the master mix without the insert oligonucleotides added (Table 3). Aliquot the master mix into PCR tubes and use a multichannel pipette to add the gRNA oligonucleotides from step 4.2. Include a no-insert control using 1 &#956;L of water.</li>
		<li>By including the BsmBI enzyme and T4 DNA ligase within the same reaction, simultaneous restriction digestion and ligation are achieved (i.e., Golden Gate cloning). Use the following Simple Gate protocol to digest the vector and ligate the inserts in 1 reaction: keep the reaction at 37 &#176;C for 2 h, at 50 &#176;C for 10 min, at 65 &#176;C for 15 min, at 80 &#176;C for 15 min, and finally, hold it at 4 &#176;C.
		<ol>
			<li>Of note, verify that the oligonucleotides do not contain BsmBI sites before using this method. If the gRNAs that are being cloned contain BsmBI restriction sites, they will be digested upon the addition of BsmBI. This will prevent the user from obtaining any transformants.</li>
		</ol>
		</li>
		<li>After the initial Simple Gate reaction, add an additional 0.5 &#956;L of BsmBI enzyme to each reaction and place them back at 55 &#176;C for 1 h. After the digestion, hold the reaction at 4 &#176;C or freeze it until ready to transform. This second round of restriction enzyme incubation removes any undigested or religated wild-type pSB700 vector backbone from the reaction mixture so that only vectors that have received the oligo inserts remain intact and will yield transformants.</li>
		<li>Proceed to the transformation (step 9).</li>
	</ol>
	</li>
	<li>Transform 0.5 &#956;L of the reaction mixture into 8 &#956;L of competent E. coli [e.g., NEB DH5a (1 - 3 x 109 cfu/&#181;g of pUC19 DNA) or NEB Stable 1 - 3 x 109 cfu/&#181;g of pUC19 DNA). For lentiviral plasmids, NEB Stable cells will provide more consistent plasmid yields.
	<ol>
		<li>Remove E. coli from storage at -80 &#176;C and thaw it on ice for 5 - 10 min.</li>
		<li>Add 0.5 &#956;L of the reaction mix to 8 &#956;L of competent E. coli and keep the mixture on ice for 30 min.</li>
		<li>Heat shock the mixture at 42 &#176;C for 45 s.</li>
		<li>Rest it on ice for 2 min.</li>
		<li>Recover the culture on a rotary shaker in 250 &#956;L of SOC media for 1 h at 37 &#176;C for NEB DH5a and at 30 &#176;C for NEB Stables.</li>
		<li>Plate 80 &#956;L of the culture on an appropriate antibiotic resistance Lysogeny Broth (LB) plate and incubate it overnight at 37 &#176;C for NEB DH5a and at 30 &#176;C for NEB Stables [e.g., pSB700 is plated on LB with ampicillin (100 &#956;g/mL) plates] (Figure 3).</li>
	</ol>
	</li>
	<li>Validate the sequence of gRNA expression plasmid: verify the sequence of each colony by Sanger sequencing using the primer 5&#8217;-GAGGGCCTATTTCCCATGATTCC-3&#8217; which primes at the U6 promoter upstream of the gRNA oligo insert.
	<ol>
		<li>Pick 2 - 3 colonies per reaction for sequencing (Table 4).
		Note: Several sequencing providers now offer services that can perform Sanger sequencing directly from bacterial colonies, which greatly reduces the time and costs by eliminating the need to purify the plasmids prior to sequencing. Alternatively, a plasmid isolation kit may be used to recover the plasmid DNA from the individual bacterial clones. Purified plasmids may then be submitted for sequencing. If a pooled ligation reaction is performed, use Table 4 as a guide for the number of colonies that should be selected and submitted for sequencing.</li>
		<li>Following the sequence confirmation, isolate the gRNA expression plasmids.
		<ol>
			<li>Use a sterile pipette tip to inoculate the desired colony into a 5 mL culture of LB medium containing 100 &#956;g/mL of ampicillin for pSB700 expression vectors.</li>
			<li>Grow the cells in a rotary incubator at 100 rpm at 37 &#176;C overnight (30 &#176;C if NEB Stables are being used).</li>
			<li>Isolate the plasmid DNA from the cultures using a plasmid prep kit, following the manufacturer&#8217;s protocol.
			Note: While the above methods enable users to create single gRNA-containing vectors, this protocol will allow users to create vectors that contain 2 gRNAs, each driven by their own RNA polymerase III promoter.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>For a paired gRNA design, use the output file from the sgRNA design tools outlined above (steps 1.1 - 1.4) and select 2 guides of interest.
	<ol>
		<li>For an activation or repression, select pairs of guides that are at least 30 nt apart.</li>
		<li>For gRNAs used for cutting, select guides that target 2 different exons within the gene.</li>
	</ol>
	</li>
	<li>For the instructions below, designate the first gRNA in the array gRNA-A and the second gRNA in the array gRNA-B, to create a paired gRNA oligonucleotide sequence modification.
	Note: The oligo used to create gRNA-A will be called fA, and the reverse oligo used to introduce gRNA-B will be referred to as rB. The cloning method below automatically appends an initiating G at the 5&#8217; end of each of the gRNAs.
	<ol>
		<li>Create the appropriate fA oligo as follows.
		Note: The 20 nucleotides comprising the gRNA targeting sequence for gRNA-A will constitute the initial fA sequence upon which the following steps will build (e.g., protospacer - aggggctacaccactcattg).
		<ol>
			<li>Append TTTTCGTCTCTCACCG to the 5&#8217; end of fA (e.g., of the sequence TTTTCGTCTCTCACCGaggggctacaccactcattg).</li>
			<li>Append GTTTTAGAGCTATGCTGAAAAGCA to the 3&#8217; end of fA (e.g., of the sequence TTTTCGTCTCTCACCGaggggctacaccactcattgGTTTTAGAGCTATGCTGAAAAGCA). This is the final version of the fA oligo that will be ordered.</li>
		</ol>
		</li>
		<li>Create the necessary rB oligo as follows.
		Note: The 20 nucleotides comprising the gRNA targeting sequence for gRNA-B will constitute the initial rB sequence upon which the following steps will build (e.g., of the starting sequence gtcccctccaccccacagtg).
		<ol>
			<li>Take the reverse complement of rB =(revcom)rB (e.g., cactgtggggtggaggggac).</li>
			<li>Append TTTTCGTCTCTAAAC to the 5&#8217; end of (revcom)rB (e.g., TTTTCGTCTCTAAACcactgtggggtggaggggac).</li>
			<li>Append CGGTGACCCAGGCGGCGCACAAG to the 3&#8217; end of (revcom)rB (e.g., TTTTCGTCTCTAAACcactgtggggtggaggggacCGGTGACCCAGGCGGCGCACAAG). This is the final version of the rB oligo that will be ordered.
			Note: The following formulas may be used with common spreadsheet software to automatically edit the oligo sequences: =CONCATENATE(&#34;TTTTCGTCTCTCACCG&#34;,(A2),&#34; GTTTTAGAGCTATGCTGAAAAGCA&#34;), where A2 is the cell containing the fA sequence, and =CONCATENATE(&#34;TTTTCGTCTCTAAAC&#34;,(B2),&#34; CGGTGACCCAGGCGGCGCACAAG&#34;), where B2 is the cell containing the (revcom)rB sequence.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Order the oligonucleotides from a synthesis vendor of choice. No additional modifications are required.</li>
	<li>Use the prepared plasmid DNA to perform PCR with both fA and rB primers. This will attach both the forward and the reverse gRNAs to the pSN007 PCR fragment generated from this plasmid and will allow each to be expressed from its own promoter (U6 and 7SK promoters&#8212;different promoters are used in this design to prevent viral recombination).
	<ol>
		<li>Use the Phusion GC Special PCR Protocol to create the needed fragment: keep the mixture at 98 &#176;C for 1 min (1 cycle), at 98 &#176;C for 15 s, at 53 &#176;C for 15 s, at 65 &#176;C for 2 min, and at 72 &#176;C for 4 min (30 cycles), and then hold it at 4 &#176;C (Table 5).</li>
		<li>Run the PCR product on a 1% agarose gel and verify that 1 band is seen at ~490 bp (Figure 2).</li>
		<li>Cut and extract this PCR product using a gel extraction kit of choice. Elute the DNA into 15 &#956;L of TE buffer (10 mM Tris, pH 7.5; 10 mM Tris, pH 8.0) or distilled water.</li>
		<li>Measure the concentration of the extracted product along with that of the pSB700 vector with a spectrophotometer for the DNA molarity calculation. Normalize both the PCR product and the vector to a concentration of 40 femtomoles/&#956;L.
		Note: Several websites are available to assist with the calculation of the molarity of a given DNA solution based on the length of the DNA and its concentration in solution (e.g., Promega: http://www.promega.com/a/apps/biomath/index.html?calc=ugpmols). The calculator uses the formula:
		<img alt="Equation" src="/files/ftp_upload/57998/57998eq1.jpg" />
		Here, N is the length of the nucleotide sequence.</li>
	</ol>
	</li>
	<li>Set up a simultaneous restriction digestion and ligation reaction using the protocol outlined in steps 8 - 8.4 to clone the pSN007&#160;PCR fragment into a pSB700 vector.
	<ol>
		<li>Instead of adding 1 &#956;L of primer solution to the reaction, add 1 &#956;L of 40 fmole/&#956;L of the PCR product. In addition, use 1 &#956;L of the pSB700 vector at a concentration of 40 fmole/&#956;L.
		Note: Equal molar ratios lead to consistent outcomes, although even in cases where exact ratios are not used, colonies can be obtained.</li>
	</ol>
	</li>
	<li>Upon completing the Golden Gate reaction process (steps 8 - 8.4), proceed to the transformation and sequence verification (steps 9 - 10.2.3).</li>
</ol>

<ol>
	<li>Gasiunas, G., Barrangou, R., Horvath, P., Siksnys, V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cas9-crRNA+ribonucleoprotein+complex+mediates+specific+DNA+cleavage+for+adaptive+immunity+in+bacteria.">Cas9-crRNA ribonucleoprotein complex mediates specific DNA cleavage for adaptive immunity in bacteria.</a> Proceedings of the National Academy of Sciences of the United States of America. 109 (39), E2579-E2586 (2012).</li><li>Jinek, M., Chylinski, K., Fonfara, I., Hauer, M., Doudna, J., Charpentier, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+Programmable+Dual-RNA-Guided+DNA+Endonuclease+in+Adaptive+Bacterial+Immunity.">A Programmable Dual-RNA-Guided DNA Endonuclease in Adaptive Bacterial Immunity.</a> Science. 337 (6096), 816-821 (2012).</li><li>Shalem, O., Sanjana, N., Zhang, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-throughput+functional+genomics+using+CRISPR-Cas9.">High-throughput functional genomics using CRISPR-Cas9.</a> Nature Reviews Genetics. 16 (5), 299-311 (2015).</li><li>Chavez, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly+efficient+Cas9-mediated+transcriptional+programming.">Highly efficient Cas9-mediated transcriptional programming.</a> Nature Methods. 12 (4), 326-328 (2015).</li><li>Gilbert, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CRISPR-Mediated+Modular+RNA-Guided+Regulation+of+Transcription+in+Eukaryotes.">CRISPR-Mediated Modular RNA-Guided Regulation of Transcription in Eukaryotes.</a> Cell. 154 (2), 442-451 (2013).</li><li>Yang, L., Yang, J., Byrne, S., Pan, J., Church, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CRISPR/Cas9-Directed+Genome+Editing+of+Cultured+Cells.">CRISPR/Cas9-Directed Genome Editing of Cultured Cells.</a> Current Protocols in Molecular Biology. , 31.1.1-31.1.17 (2014).</li><li>Yang, L., Mali, P., Kim-Kiselak, C., Church, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CRISPR-Cas-Mediated+Targeted+Genome+Editing+in+Human+Cells.">CRISPR-Cas-Mediated Targeted Genome Editing in Human Cells.</a> Methods in Molecular Biology. 1114, 245-267 (2014).</li><li>Vidigal, J., Ventura, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+and+efficient+one-step+generation+of+paired+gRNA+CRISPR-Cas9+libraries.">Rapid and efficient one-step generation of paired gRNA CRISPR-Cas9 libraries.</a> Nature Communications. 6, 8083 (2015).</li><li>Joung, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genome-scale+CRISPR-Cas9+knockout+and+transcriptional+activation+screening.">Genome-scale CRISPR-Cas9 knockout and transcriptional activation screening.</a> Nature Protocols. 12 (4), 828-863 (2017).</li><li>Kabadi, A., Ousterout, D., Hilton, I., Gersbach, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiplex+CRISPR/Cas9-based+genome+engineering+from+a+single+lentiviral+vector.">Multiplex CRISPR/Cas9-based genome engineering from a single lentiviral vector.</a> Nucleic Acids Research. 42 (19), e147 (2014).</li><li>Sakuma, T., Nishikawa, A., Kume, S., Chayama, K., Yamamoto, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Multiplex+genome+engineering+in+human+cells+using+all-in-one+CRISPR/Cas9+vector+system.">Multiplex genome engineering in human cells using all-in-one CRISPR/Cas9 vector system.</a> Scientific Reports. 4 (1), (2014).</li><li>Chari, R., Yeo, N., Chavez, A., Church, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=sgRNA+Scorer+2.0:+A+Species-Independent+Model+To+Predict+CRISPR/Cas9+Activity.">sgRNA Scorer 2.0: A Species-Independent Model To Predict CRISPR/Cas9 Activity.</a> ACS Synthetic Biology. 6 (5), 902-904 (2017).</li><li>Doench, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rational+design+of+highly+active+sgRNAs+for+CRISPR-Cas9-mediated+gene+inactivation.">Rational design of highly active sgRNAs for CRISPR-Cas9-mediated gene inactivation.</a> Nature Biotechnology. 32 (12), 1262-1267 (2014).</li><li>Konermann, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genome-scale+transcriptional+activation+by+an+engineered+CRISPR-Cas9+complex.">Genome-scale transcriptional activation by an engineered CRISPR-Cas9 complex.</a> Nature. 517 (7536), 583-588 (2014).</li><li>Engler, C., Marillonnet, S., Valla, S., Lale, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Golden+Gate+Cloning.">Golden Gate Cloning.</a> DNA Cloning and Assembly Methods. , 119-131 (2013).</li><li>Zetsche, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cpf1+Is+a+Single+RNA-Guided+Endonuclease+of+a+Class+2+CRISPR-Cas+System.">Cpf1 Is a Single RNA-Guided Endonuclease of a Class 2 CRISPR-Cas System.</a> Cell. 163 (3), 759-771 (2015).</li><li>Abudayyeh, O., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=C2c2+is+a+single-component+programmable+RNA-guided+RNA-targeting+CRISPR+effector.">C2c2 is a single-component programmable RNA-guided RNA-targeting CRISPR effector.</a> Science. 353 (6299), (2016).</li></ol>

George M. Church has equity in Editas and Caribou Biosciences, which aim to commercialize CRISPR-Cas9 genome editing technology (for a full disclosure list, please see http://arep.med.harvard.edu/gmc/tech.html).

A number of time- and cost-saving modifications have been made to the gRNA expression vector construction. A single-step restriction and ligation protocol is outlined as well as a method of paired gRNA expression vector construction. The paired gRNA expression is achieved through a PCR amplification using oligonucleotides containing both a forward gRNA target sequence (n20) and the reverse complement of another target (n20). This then introduces a secondary RNA Pol III promoter (7SK) as well as a sgRNA tail into conventionally expressing single gRNA expression plasmids.
A careful oligonucleotide design will ensure a successful PCR for the paired gRNA construction as well as a sticky-end ligation. Following the single-step restriction and ligation reaction, the addition of further BsmBI will ensure all unmodified expression vectors in the reaction are cut. This will significantly reduce the background upon the transformation. Using NEB-Stable competent E. coli and a growth at 30 &#176;C will increase the yield of a successful transformation.
The advantages this technique has over common practices include a simplification of the process of oligonucleotide annealing, a single-step restriction of the gRNA expression vector and the ligation of oligonucleotides, and the ability to utilize conventional single gRNA expression vectors for the expression of paired guides. While the protocol described here focuses on a set of mammalian vectors, the general strategy is plastic and is applicable to any organism, provided the appropriate gRNA vector is available. Overall, the protocol described saves time and costs.
However, it should be noted that the outlined procedure of purchasing individual oligonucleotides does not scale well for the generation of libraries containing thousands of gRNAs. For those purposes, alternative sources of oligonucleotide synthesis such as oligo chip synthesis are recommended.
It is beneficial to include a no-insert control when cloning gRNAs. This reaction can be easily set up in parallel with the reactions of interest and can be used to determine whether an incomplete digestion of the starting vector has contributed to the colonies observed at the end of the procedure. Furthermore, if one of the above cloning protocols has failed due to an incompletely digested vector backbone or poor ligation efficiency, we suggest trying the alternative cloning method we have outlined.
When using Golden Gate cloning to simultaneously digest the vector and ligate in the small oligonucleotides within a single reaction, it is important to check that the gRNA that are being cloned into the vector does not have a BsmBI site inside of it, as this will lead to the gRNA being cut and an absence of colonies upon transformation.
The gRNA cloning strategy we have outlined enables a rapid and cost-effective generation of gRNAs at ~10 U.S. dollars per guide, with the bulk of the costs coming from the oligonucleotide synthesis and the sequence verification. While the outlined method is designed to allow users to generate gRNAs for use with SpCas9, the protocol can easily be adapted for use with Cas9 orthologues or other RNA-guided endonucleases such as Cpf1 or C2C2, with slight modifications to the vector backbone and the oligonucleotide overhang sequences16,17.
The protocol outlined above will provide sequence-verified gRNA expression plasmids in 3 d (starting with appropriately designed oligonucleotides), which is significantly faster than current methods. This includes the gRNA design of 1 h (steps 1 - 2.3), the dilution and aliquot of the oligonucleotides of 10 min (steps 3 - 5.1), the digestion and purification of the pSB700 gRNA expression vector of 2 h (steps 6 - 6.4), the cloning of the gRNA oligonucleotides into a predigested pSB700 gRNA expression vector overnight at room temperature (steps 7 - 7.3), the single-step BsmBI restriction ligation of 3 h and 40 min (steps 8 - 8.4), the transformation of 16 h (steps 9 - 9.6), and the validation of the sequence of the gRNA expression plasmid of 24 h (with the duration depending on the sanger sequencing availability and the speed following the submission of the bacterial colony; step 10). The paired gRNA design and the sequence modification takes 1 h (steps 11 - 13). The paired gRNA PCR takes 3.5 h (steps 14 - 14.4). The cloning of the pSN007&#160;PCR fragment into a pSB700 vector takes 3h and 40 min (step 15 - 16).
The most likely issues that may be faced with this protocol relate to inefficiency in the Golden Gate assembly and transformation. Include a no-insert control during the Golden Gate assembly to visualize the efficiency of the assembly. During the transformation, the puc19 positive control will provide a transformation efficiency control. NEB-Stable E. coli should be used for lentiviral compatible plasmids and frequently require up to &#62; 16 h at 30 &#176;C to yield visible colonies.

CRISPR-associated protein 9 (Cas9) is an RNA-guided endonuclease which is directed towards a desired genomic target when complexed with an appropriately designed small guide RNA (gRNA)1,2. gRNAs comprise a 20-nucleotide sequence (the protospacer), which is complementary to the genomic target sequence. Next to the genomic target sequence is a 3&#39; protospacer-associated motif (PAM), which is required for Cas9 binding. In the case of Streptococcus Pyogenes Cas9 (SpCas9), this has the sequence NGG. Upon binding the DNA target, Cas9 cleaves both strands of DNA, thereby stimulating repair mechanisms that can be exploited to modify the locus of interest. The activation of the error-prone non-homologous end-joining (NHEJ) pathway can cause the disruption of a target gene. Alternatively, repairs made via a homologous recombination can stimulate the targeted integration of a desired DNA sequence if a donor template is provided6. Nuclease-dead Cas9 (dCas9) variants can also be generated3 by mutating the residues within Cas9 that are essential for endonucleolytic activity. dCas9 remains competent for DNA binding but does not cut its bound target. By fusing various effector domains to dCas9 and directing it near a gene&#39;s transcriptional start site, dCas9 can be used for selective gene induction or partial gene silencing4,5.
While incredibly powerful, the ability to use Cas9 to target a genomic sequence of interest requires that a user first generates a gRNA unique to the target site(s). A variety of methods for building gRNA expression vectors have previously been described, many of varying efficiency and cost6,7,8. Stand-alone PCR amplicons may be used as gRNAs for rapid screening, going from oligonucleotide delivery to transfection within several hours; however, this requires Ultramer (over 100 bp) oligo synthesis, which is expensive9. It is also possible to purchase gBlocks that are more cost-effective than Ultramers. As Cas9 has rapidly become an integral component of the modern molecular biology toolkit, a simple, inexpensive, and highly efficient method for gRNA cloning would be a boon to the field. The method described here has been employed in our group and collaborating laboratories for the past several years to generate over 2,000 unique gRNAs4.
The outlined method focuses on techniques for the cloning of lentiviral compatible vectors containing a single gRNA or at most two gRNAs. For the generation of plasmids containing more than two gRNAs, or to clone a library of gRNAs, alternative approaches are recommended9,10,11,12.

<table><tbody><tr><td>BsmBI</td><td>New England Biolabs</td><td>R0580L</td><td></td></tr><tr><td>T4 DNA ligase</td><td>Enzymatic/New England Biolabs</td><td>L6030-LC-L/M0202S</td><td></td></tr><tr><td>Buffer 3.1</td><td>New England Biolabs</td><td>B7203S</td><td></td></tr><tr><td>Adenosine 5&#039;-Triphosphate (ATP)</td><td>New England Biolabs</td><td>P0756S</td><td></td></tr><tr><td>QIAprep spin miniprep kit</td><td>Qiagen</td><td>27104</td><td></td></tr><tr><td>Chemically competent&lt;em&gt; E. coli&lt;/em&gt;</td><td>New England Biolabs</td><td>C3019l, C2987l, or C3040H</td><td></td></tr><tr><td>Standard microcentrifuge tubes, 1.5 mL</td><td>Eppendorf</td><td>0030 125.150</td><td></td></tr><tr><td>Axygen 8-Strip PCR tubes</td><td>Fischer Scientific</td><td>14-222-250</td><td></td></tr><tr><td>Thermocycler with programmable temperature-stepping control</td><td>BioRad,</td><td>1851148</td><td></td></tr><tr><td>UV spectrophotometer (NanoDrop 2000c)</td><td>Thermo Scientific</td><td></td><td></td></tr><tr><td>pSB700 plasmid</td><td>Addgene</td><td>#64046</td><td></td></tr><tr><td>NEB Stable Competent &lt;em&gt;E. coli &lt;/em&gt;(High Efficiency)</td><td>New England Biolabs</td><td>c3040</td><td></td></tr><tr><td>Lysogeny broth (LB)</td><td></td><td></td><td></td></tr><tr><td>Ampicillin</td><td></td><td></td><td></td></tr><tr><td>TE buffer (1 mM EDTA, 10 mM Tris-Cl, pH 7.5)</td><td></td><td></td><td></td></tr><tr><td>pSN007 plasmid</td><td>Addgene</td><td>&lt;a href=&quot;https://www.addgene.org/102440/&quot;&gt;102440&lt;/a&gt;</td><td></td></tr></tbody></table>

crispr guide rna cloning for mammalian systems

The outlined protocol describes streamlined methods for the efficient and cost-effective generation of Cas9-associated guide RNAs. Two alternative strategies for guide RNA (gRNA) cloning are outlined based on the usage of the Type IIS restriction enzyme BsmBI in combination with a set of compatible vectors. Outside of the access to Sanger sequencing services to validate the generated vectors, no special equipment or reagents are required aside from those that are standard to modern molecular biology laboratories. The outlined method is primarily intended for cloning one single gRNA or one paired gRNA-expressing vector at a time. This procedure does not scale well for the generation of libraries containing thousands of gRNAs. For those purposes, alternative sources of oligonucleotide synthesis such as oligo-chip synthesis are recommended. Finally, while this protocol focuses on a set of mammalian vectors, the general strategy is plastic and is applicable to any organism if the appropriate gRNA vector is available.

The methods outlined in this protocol are for the creation of either single or paired gRNA expression vectors. Single gRNA expressing vectors can be created by either predigesting the vector backbone (Figure 1) followed by ligating it in a series of short oligonucleotides or using Golden Gate cloning to simultaneously digest the vector backbone and ligate it in a series of short oligonucleotides in a single reaction. Also provided is a method of producing vectors that contain 2 gRNAs, each driven by its own independent promoter, by cloning a custom pSN007&#160;PCR fragment (Figure 2).
A successful cloning for any of the outlined protocols will result in the appearance of significantly more colonies for transformations with the appropriate insert DNA than on the no-insert control plate (Figure 3).
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/57998/57998fig1.jpg" />
Figure 1: The digestion of a pSB700 gRNA expression vector. 1% agarose gel is used. Lane 1: uncut pSB700. Lane 2: pSB700 cut with BsmBI.
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/57998/57998fig2.jpg" />
Figure 2: Paired gRNA PCR. 1% agarose gel is used. Lane 1: a paired guide pSN007&#160;PCR fragment of ~490 bp.
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/57998/57998fig3.jpg" />
Figure 3: The successful cloning and transformation of a gRNA plasmid. The left panel shows an LB and ampicillin plate with successfully transformed colonies. The right panel shows a no-insert control plate showing no colonies. <a href="https://www.jove.com/files/ftp_upload/57998/57998fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
Supplemental File.&#160; <a href="https://www.jove.com/files/ftp_upload/57998/Workflow diagram.docx" target="_blank">Please click here to download this file.</a>
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>pSB700 guide expression vector</td>
			<td>1-5 &#956;g</td>
		</tr>
		<tr>
			<td>NEB Buffer 3.1</td>
			<td>4 &#956;L</td>
		</tr>
		<tr>
			<td>BsmBI</td>
			<td>1 &#956;L</td>
		</tr>
		<tr>
			<td>Distilled water</td>
			<td>up to 40 &#956;L</td>
		</tr>
		<tr>
			<td>Total volume</td>
			<td>40 &#956;L</td>
		</tr>
	</tbody>
</table>
Table 1: The restriction digestion of a pSB700 gRNA expression vector with BsmBI.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Annealed gRNA oligos (either single or pooled reaction)</td>
			<td>1 &#956;L</td>
		</tr>
		<tr>
			<td>BsmBI-digested pSB700 guide expression vector</td>
			<td>1 &#956;L (~100-250 ng)</td>
		</tr>
		<tr>
			<td>10x T4 DNA Ligase Reaction Buffer</td>
			<td>2 &#956;L (1x final concentration)</td>
		</tr>
		<tr>
			<td>T4 DNA Ligase</td>
			<td>1 &#956;L (120 units)</td>
		</tr>
		<tr>
			<td>Distilled water</td>
			<td>15 &#956;L</td>
		</tr>
		<tr>
			<td>Total volume</td>
			<td>20 &#956;l</td>
		</tr>
	</tbody>
</table>
Table 2: A ligation reaction of gRNA oligonucleotides into a predigested pSB700 gRNA expression vector.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Reagent</td>
			<td>Volume (1x)</td>
		</tr>
		<tr>
			<td>H2O</td>
			<td>6 &#956;L</td>
		</tr>
		<tr>
			<td>T4 Ligase</td>
			<td>0.5 &#956;L</td>
		</tr>
		<tr>
			<td>ATP</td>
			<td>1 &#956;L</td>
		</tr>
		<tr>
			<td>BsmBI</td>
			<td>0.5 &#956;L</td>
		</tr>
		<tr>
			<td>NEB Buffer 3.1</td>
			<td>1 &#956;L</td>
		</tr>
		<tr>
			<td>Vector (e.g., pSB700) (40 fmol)</td>
			<td>1 &#956;lL</td>
		</tr>
		<tr>
			<td>Insert - forward and reverse oligos or pSN007&#160;PCR fragment for dual guide (40fmol)</td>
			<td>1 &#956;L (0.5 &#956;L forward and 0.5 &#956;L reverse)</td>
		</tr>
	</tbody>
</table>
Table 3: A single-step BsmBI restriction and gRNA ligation reaction mix.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>For 1 guide</td>
			<td>sequence 3 colonies</td>
		</tr>
		<tr>
			<td>For 2 guides</td>
			<td>sequence 5-10 colonies</td>
		</tr>
		<tr>
			<td>For 3 guides</td>
			<td>sequence 10-15 colonies</td>
		</tr>
		<tr>
			<td>For 4 guides</td>
			<td>sequence 15-20 colonies</td>
		</tr>
	</tbody>
</table>
Table 4: The recommended number of colonies to sequence for pooled gRNA cloning reactions.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>PCR Component</td>
			<td>50 &#181;L reaction</td>
		</tr>
		<tr>
			<td>10 &#181;M Forward Primer</td>
			<td>2.5 &#181;L</td>
		</tr>
		<tr>
			<td>10 &#181;M Reverse Primer</td>
			<td>2.5 &#181;L</td>
		</tr>
		<tr>
			<td>5x Phusion HF or GC Buffer</td>
			<td>10 &#181;L</td>
		</tr>
		<tr>
			<td>10 mM dNTPs</td>
			<td>1 &#181;L</td>
		</tr>
		<tr>
			<td>Template DNA</td>
			<td>100 ng</td>
		</tr>
		<tr>
			<td>Phusion DNA Polymerase</td>
			<td>0.5 &#181;L</td>
		</tr>
		<tr>
			<td>Nuclease-free water</td>
			<td>Up to 50 &#181;L</td>
		</tr>
	</tbody>
</table>
Table 5: A paired gRNA PCR mixture.

Watch this Scientific Journal Video about CRISPR Guide RNA Cloning for Mammalian Systems at JoVE.com

CRISPR Guide RNA Cloning for Mammalian Systems | Genetics | Video

CRISPR Guide RNA Cloning for Mammalian Systems

Here, a simple, efficient, and cost-effective method of sgRNA cloning is outlined.

The outlined protocol describes streamlined methods for the efficient and cost-effective generation of Cas9-associated guide RNAs. Two alternative ...

crispr-guide-rna-cloning-for-mammalian-systems

Nanyang Technological University

Research

Education

JoVE Journal

JoVE Core

Biology

Genetics

Biotechnology

SCIENTISTS IN ACTION

69.7K Views.  Harvard University. Here, a simple, efficient, and cost-effective method of sgRNA cloning is outlined.

Video: CRISPR Guide RNA Cloning for Mammalian Systems

Selection-dependent and Independent Generation of CRISPR/Cas9-mediated Gene Knockouts in Mammalian Cells

The CRISPR/Cas9 genome engineering system has revolutionized biology by allowing for precise genome editing with little effort. Guided by a single guide RNA (sgRNA) that confers specificity, the Cas9 protein cleaves both DNA strands at the targeted locus. The DNA break can trigger either non-homologous end joining (NHEJ) or homology directed repair (HDR). NHEJ can introduce small deletions or insertions which lead to frame-shift mutations, while HDR allows for larger and more precise perturbations. Here, we present protocols for generating knockout cell lines by coupling established CRISPR/Cas9 methods with two options for downstream selection/screening. The NHEJ approach uses a single sgRNA cut site and selection-independent screening, where protein production is assessed by dot immunoblot in a high-throughput manner. The HDR approach uses two sgRNA cut sites that span the gene of interest. Together with a provided HDR template, this method can achieve deletion of tens of kb, aided by the inserted selectable resistance marker. The appropriate applications and advantages of each method are discussed.

Recent advances in the ability to genetically manipulate somatic cell lines hold great potential for basic and applied research. Here, we present two approaches for CRISPR/Cas9 generated knockout production and screening in mammalian cell lines, with and without the use of selectable markers.

The CRISPR/Cas9 genome engineering system has revolutionized biology by allowing for precise genome editing with little effort. Guided by a single guide ...

CRISPR/Cas9-mediated Targeted Integration In Vivo Using a Homology-mediated End Joining-based Strategy

As a promising genome editing platform, the CRISPR/Cas9 system has great potential for efficient genetic manipulation, especially for targeted integration of transgenes. However, due to the low efficiency of homologous recombination (HR) and various indel mutations of non-homologous end joining (NHEJ)-based strategies in non-dividing cells, in vivo genome editing remains a great challenge. Here, we describe a homology-mediated end joining (HMEJ)-based CRISPR/Cas9 system for efficient in vivo precise targeted integration. In this system, the targeted genome and the donor vector containing homology arms (~800 bp) flanked by single guide RNA (sgRNA) target sequences are cleaved by CRISPR/Cas9. This HMEJ-based strategy achieves efficient transgene integration in mouse zygotes, as well as in hepatocytes in vivo. Moreover, a HMEJ-based strategy offers an efficient approach for correction of fumarylacetoacetate hydrolase (Fah) mutation in the hepatocytes and rescues Fah-deficiency induced liver failure mice. Taken together, focusing on targeted integration, this HMEJ-based strategy provides a promising tool for a variety of applications, including generation of genetically modified animal models and targeted gene therapies.

CRISPR/Cas9-mediated Targeted Integration In Vivo Using a Homology-mediated End Joining-based Strategy

The clustered regularly interspaced short palindromic repeats/CRISPR associated protein 9 (CRISPR/Cas9) system provides a promising tool for genetic engineering, and opens up the possibility of targeted integration of transgenes. We describe a homology-mediated end joining (HMEJ)-based strategy for efficient DNA targeted integration in vivo and targeted gene therapies using CRISPR/Cas9.

As a promising genome editing platform, the CRISPR/Cas9 system has great potential for efficient genetic manipulation, especially for targeted integration ...

Dissection of Enhancer Function Using Multiplex CRISPR-based Enhancer Interference in Cell Lines

Multiple enhancers often regulate a given gene, yet for most genes, it remains unclear which enhancers are necessary for gene expression, and how these enhancers combine to produce a transcriptional response. As millions of enhancers have been identified, high-throughput tools are needed to determine enhancer function on a genome-wide scale. Current methods for studying enhancer function include making genetic deletions using nuclease-proficient Cas9, but it is difficult to study the combinatorial effects of multiple enhancers using this technique, as multiple successive clonal cell lines must be generated. Here, we present Enhancer-i, a CRISPR interference-based method that allows for functional interrogation of multiple enhancers simultaneously at their endogenous loci. Enhancer-i makes use of two repressive domains fused to nuclease-deficient Cas9, SID and KRAB, to achieve enhancer deactivation via histone deacetylation at targeted loci. This protocol utilizes transient transfection of guide RNAs to enable transient inactivation of targeted regions and is particularly effective at blocking inducible transcriptional responses to stimuli in tissue culture settings. Enhancer-i is highly specific both in its genomic targeting and its effects on global gene expression. Results obtained from this protocol help to understand whether an enhancer is contributing to gene expression, the magnitude of the contribution, and how the contribution is affected by other nearby enhancers.

This protocol describes the steps needed to design and perform multiplexed targeting of enhancers with the deactivating fusion protein SID4X-dCas9-KRAB, also known as enhancer interference (Enhancer-i). This protocol enables the identification of enhancers that regulate gene expression and facilitates the dissection of relationships between enhancers regulating a common target gene.

Multiple enhancers often regulate a given gene, yet for most genes, it remains unclear which enhancers are necessary for gene expression, and how these ...

Endogenous Protein Tagging in Human Induced Pluripotent Stem Cells Using CRISPR/Cas9

A protocol is presented for generating human induced pluripotent stem cells (hiPSCs) that express endogenous proteins fused to in-frame&#160;N- or C-terminal fluorescent tags. The prokaryotic CRISPR/Cas9 system (clustered regularly interspaced short palindromic repeats/CRISPR-associated 9) may be used to introduce large exogenous sequences into genomic loci via homology directed repair (HDR). To achieve the desired knock-in, this protocol employs the ribonucleoprotein (RNP)-based approach where wild type Streptococcus pyogenes Cas9 protein, synthetic 2-part guide RNA (gRNA), and a donor template plasmid are delivered to the cells via electroporation. Putatively edited cells expressing the fluorescently tagged proteins are enriched by fluorescence activated cell sorting (FACS). Clonal lines are then generated and can be analyzed for precise editing outcomes. By introducing the fluorescent tag at the genomic locus of the gene of interest, the resulting subcellular localization and dynamics of the fusion protein can be studied under endogenous regulatory control, a key improvement over conventional overexpression systems. The use of hiPSCs as a model system for gene tagging provides the opportunity to study the tagged proteins in diploid, nontransformed cells. Since hiPSCs can be differentiated into multiple cell types, this approach provides the opportunity to create and study tagged proteins in a variety of isogenic cellular contexts.

Described here is a protocol for tagging endogenously expressed proteins with fluorescent tags in human induced pluripotent stem cells using CRISPR/Cas9. Putatively edited cells are enriched by fluorescence activated cell sorting and clonal cell lines are generated.

A protocol is presented for generating human induced pluripotent stem cells (hiPSCs) that express endogenous proteins fused to in-frame&#160;N- or ...

Genome Editing in Mammalian Cell Lines using CRISPR-Cas

The clustered regularly interspaced short palindromic repeats (CRISPR) system functions naturally in bacterial adaptive immunity, but has been successfully repurposed for genome engineering in many different living organisms. Most commonly, the wildtype CRISPR associated 9 (Cas9) or Cas12a endonuclease is used to cleave specific sites in the genome, after which the DNA double-stranded break is repaired via the non-homologous end joining (NHEJ) pathway or the homology-directed repair (HDR) pathway depending on whether a donor template is absent or present respectively. To date, CRISPR systems from different bacterial species have been shown to be capable of performing genome editing in mammalian cells. However, despite the apparent simplicity of the technology, multiple design parameters need to be considered, which often leave users perplexed about how best to carry out their genome editing experiments. Here, we describe a complete workflow from experimental design to identification of cell clones that carry desired DNA modifications, with the goal of facilitating successful execution of genome editing experiments in mammalian cell lines. We highlight key considerations for users to take note of, including the choice of CRISPR system, the spacer length, and the design of a single-stranded oligodeoxynucleotide (ssODN) donor template. We envision that this workflow will be useful for gene knockout studies, disease modeling efforts, or the generation of reporter cell lines.

CRISPR-Cas is a powerful technology to engineer the complex genomes of plants and animals. Here, we detail a protocol to efficiently edit the human genome using different Cas endonucleases. We highlight important considerations and design parameters to optimize editing efficiency.

The clustered regularly interspaced short palindromic repeats (CRISPR) system functions naturally in bacterial adaptive immunity, but has been ...

Development of Knock-Out Muscle Cell Lines using Lentivirus-Mediated CRISPR/Cas9 Gene Editing

One important application of clustered regulatory interspaced short palindromic repeats (CRISPR)/Cas 9 is the development of knock-out cell lines, specifically to study the function of new genes/proteins associated with a disease, identified during the genetic diagnosis. For the development of such cell lines, two major issues have to be untangled: insertion of the CRISPR tools (the Cas9 and the guide RNA) with high efficiency into the chosen cells, and restriction of the Cas9 activity to the specific deletion of the chosen gene. The protocol described here is dedicated to the insertion of the CRISPR tools in difficult to transfect cells, such as muscle cells. This protocol is based on the use of lentiviruses, produced with plasmids publicly available, for which all the cloning steps are described to target a gene of interest. The control of Cas9 activity has been performed using an adaptation of a previously described system called KamiCas9, in which the transduction of the cells with a lentivirus encoding a guide RNA targeting the Cas9 allows the progressive abolition of Cas9 expression. This protocol has been applied to the development of a RYR1-knock out human muscle cell line, which has been further characterized at the protein and functional level, to confirm the knockout of this important calcium channel involved in muscle intracellular calcium release and in excitation-contraction coupling. The procedure described here can easily be applied to other genes in muscle cells or in other difficult to transfect cells and produce valuable tools to study these genes in human cells.

The protocol describes how to generate knock-out myoblasts using CRISPR/Cas9, starting from the design of guide-RNAs to the cellular cloning and characterization of the knock-out clones.

One important application of clustered regulatory interspaced short palindromic repeats (CRISPR)/Cas 9 is the development of knock-out cell lines, ...

Efficient Genome Editing of Mice by CRISPR Electroporation of Zygotes

With exceptional efficiency, accuracy, and ease, the CRISPR/Cas9 system has significantly improved genome editing in cell culture and lab animal experiments. When generating animal models, the electroporation of zygotes offers higher efficiency, simplicity, cost, and throughput as an alternative to the gold standard method of microinjection. Electroporation is also gentler, with higher viability, and reliably delivers Cas9/single-guide RNA (sgRNA) ribonucleoproteins (RNPs) into the zygotes of common laboratory mouse strains (e.g., C57BL/6J and C57BL/6N) that approaches 100% delivery efficiency. This technique enables insertion/deletion (indels) mutations, point mutations, the deletion of whole genes or exons, and small insertions in the range of 100-200 bp to insert LoxP or short tags like FLAG, HA, or V5. While constantly being improved, here we present the current state of CRISPR-EZ in a protocol that includes sgRNA production through in vitro transcription, embryo processing, RNP assembly, electroporation, and the genotyping of preimplantation embryos. A graduate-level researcher with minimal experience manipulating embryos can obtain genetically edited embryos in less than 1 week using this protocol. Here, we offer a straightforward, low-cost, efficient, high-capacity method that could be used with mouse embryos.

Here, we describe a simple technique intended for the efficient generation of genetically modified mice called CRISPR RNP Electroporation of Zygotes (CRISPR-EZ). This method delivers editing reagents by electroporation into embryos at an efficiency approaching 100%. This protocol is effective for point mutations, small genomic insertions, and deletions in mammalian embryos.

With exceptional efficiency, accuracy, and ease, the CRISPR/Cas9 system has significantly improved genome editing in cell culture and lab animal ...

Developmental Biology

Construction of CRISPR Plasmids and Detection of Knockout Efficiency in Mammalian Cells through a Dual Luciferase Reporter System

Although highly efficient, modification of a genomic site by the CRISPR enzyme requires the generation of a sgRNA unique to the target site(s) beforehand. This work describes the key steps leading to the construction of efficient sgRNA vectors using a strategy that allows the efficient detection of the positive colonies by PCR prior to DNA sequencing. Since efficient genome editing using the CRISPR system requires a highly efficient sgRNA, a preselection of candidate sgRNA targets is necessary to save time and effort. A dual luciferase reporter system has been developed to evaluate knockout efficiency by examining double-strand break repair via single strand annealing. Here, we use this reporter system to pick up the preferred xCas9/sgRNA target from candidate sgRNA vectors for specific gene editing. The protocol outlined will provide a preferred sgRNA/CRISPR enzyme vector in 10 days (starting with appropriately designed oligonucleotides).

Here, we present a protocol describing a streamlined method for the efficient generation of plasmids expressing both the CRISPR enzyme and associated single guide RNA (sgRNAs). Co-transfection of mammalian cells with this sgRNA/CRISPR vector and a dual luciferase reporter vector that examines double-strand break repair allows evaluation of knockout efficiency.

Although highly efficient, modification of a genomic site by the CRISPR enzyme requires the generation of a sgRNA unique to the target site(s) beforehand. ...

Bioengineering

Gene Knock-in by CRISPR/Cas9 and Cell Sorting in Macrophage and T Cell Lines

Functional genomics studies of the immune system require genetic manipulations that involve both deletion of target genes and addition of elements to proteins of interest. Identification of gene functions in cell line models is important for gene discovery and exploration of cell-intrinsic mechanisms. However, genetic manipulations of immune cells such as T cells and macrophage cell lines using CRISPR/Cas9-mediated knock-in are difficult because of the low transfection efficiency of these cells, especially in a quiescent state. To modify genes in immune cells, drug-resistance selection and viral vectors are typically used to enrich for cells expressing the CRIPSR/Cas9 system, which inevitably results in undesirable intervention of the cells. In a previous study, we designed dual fluorescent reporters coupled to CRISPR/Cas9 that were transiently expressed after electroporation. This technical solution leads to rapid gene deletion in immune cells; however, gene knock-in in immune cells such as T cells and macrophages without the use of drug-resistance selection or viral vectors is even more challenging. In this article, we show that by using cell sorting to aid selection of cells transiently expressing CRISPR/Cas9 constructs targeting the Rosa26 locus in combination with a donor plasmid, gene knock-in can be achieved in both T cells and macrophages without drug-resistance enrichment. As an example, we show how to express human ACE2, a receptor of SARS-Cov-2, which is responsible for the current Covid-19 pandemic, in RAW264.7 macrophages by performing knock-in experiments. Such gene knock-in cells can be widely used for mechanistic studies.

This protocol uses fluorescent reporters and cell sorting to simplify knock-in experiments in macrophage and T cell lines. Two plasmids are used for these simplified knock-in experiments, namely a CRISPR/Cas9- and DsRed2-expressing plasmid and a homologous recombination donor plasmid expressing EBFP2, which is permanently integrated at the Rosa26 locus in immune cells.

Functional genomics studies of the immune system require genetic manipulations that involve both deletion of target genes and addition of elements to ...

Immunology and Infection

Generation of Genomic Deletions in Mammalian Cell Lines via CRISPR/Cas9

The prokaryotic clustered regularly interspaced short palindromic repeats (CRISPR)/CRISPR-associated (Cas) 9 system may be re-purposed for site-specific eukaryotic genome engineering. CRISPR/Cas9 is an inexpensive, facile, and efficient genome editing tool that allows genetic perturbation of genes and genetic elements. Here we present a simple methodology for CRISPR design, cloning, and delivery for the production of genomic deletions. In addition, we describe techniques for deletion, identification, and characterization. This strategy relies on cellular delivery of a pair of chimeric single guide RNAs (sgRNAs) to create two double strand breaks (DSBs) at a locus in order to delete the intervening DNA segment by non-homologous end joining (NHEJ) repair. Deletions have potential advantages as compared to single-site small indels given the efficiency of biallelic modification, ease of rapid identification by PCR, predictability of loss-of-function, and utility for the study of non-coding elements. This approach can be used for efficient loss-of-function studies of genes and genetic elements in mammalian cell lines.

CRISPR/Cas9 is a robust system to produce disruption of genes and genetic elements. Here we describe a protocol for the efficient creation of genomic deletions in mammalian cell lines using CRISPR/Cas9.

The prokaryotic clustered regularly interspaced short palindromic repeats (CRISPR)/CRISPR-associated (Cas) 9 system may be re-purposed for site-specific ...

CRISPR Guide RNA Cloning for Mammalian Systems

Summary

Explore More Videos

Chapters in this video

Selection-dependent and Independent Generation of CRISPR/Cas9-mediated Gene Knockouts in Mammalian Cells

CRISPR/Cas9-mediated Targeted Integration In Vivo Using a Homology-mediated End Joining-based Strategy

Dissection of Enhancer Function Using Multiplex CRISPR-based Enhancer Interference in Cell Lines

Endogenous Protein Tagging in Human Induced Pluripotent Stem Cells Using CRISPR/Cas9

Genome Editing in Mammalian Cell Lines using CRISPR-Cas

Development of Knock-Out Muscle Cell Lines using Lentivirus-Mediated CRISPR/Cas9 Gene Editing

Efficient Genome Editing of Mice by CRISPR Electroporation of Zygotes

Construction of CRISPR Plasmids and Detection of Knockout Efficiency in Mammalian Cells through a Dual Luciferase Reporter System

Gene Knock-in by CRISPR/Cas9 and Cell Sorting in Macrophage and T Cell Lines

Generation of Genomic Deletions in Mammalian Cell Lines via CRISPR/Cas9
